Safespaces Siesta Hi-Lo User manual

Siesta®Hi-Lo
Assembly Instructions
01706 816274 | [e-mail] | www.safespaces.co.uk
Safespaces,361 Burnley Road, Todmorden,OL14 7DH
Company Registration No. 5733564 | VAT No. 797 1269 81

Version: 2023.3
LIST OF MATERIALS
Item
Quantity
PVC Fabric
1
Siesta Bed Base
1
Aluminium Profile Uprights Poles
4
Closed Cell Foam Topper
1
M8 Hexagonal Bolts
8
T-Bolts
8
M8 Slide Block Spring Nut
8
M8 Flange Nuts
8
Mattress
1

Tools Required
1x 13mm Spanner
IMPORTANT!
READ and FOLLOW these instructions carefully.
Review all instructions before beginning assembly.
These instructions are provided to avoid problems that may occur from
improper assembly or installation.
ASSEMBLY INSTRUCTIONS
IMPORTANT!
Please ensure you are familiar with the fixing
bolts and the aluminium profile uprights.
The T-bolt has a rectangular head with a slot
indicator in the end of the bolt, this indicates
if the T-bolt is correctly located.
1
Place the Cell Foam on the Bed Base
When the bed base is in place, grab the cell
foam topper and place it onto the bed base.
Assembly Instructions - Siesta Hi-Lo 1

2
Insert the Vertical Bars
At each corner of the bed base, insert two T-bolts through the corner bracket, insert
the bolt through the bracket into the aluminium slider to tighten once lined up with
the marker on the bar.
Once it is in place, put the flange nut on to clamp the pole into place. Tighten the
flange nuts with the 13mm spanner to keep the bar secured in place.
Repeat this step on each Corner
3
Place the PVC Fabric on top of the Foam
Place the PVC Fabric on top of the already placed Cell Foam. Straighten out the
material so that you can get access to the four corners and fully unzip all of them.
Assembly Instructions - Siesta Hi-Lo 2

4
Unzip the fabric and place over the vertical bars
Unzip one of the opening panels to release some tension on the fabric. Then place
the corners of the fabric over the vertical bars.
Top Tip: Easier to complete by doing it diagonally.
5
Attach the Fabric to the Vertical Bars
At each corner of the Siesta attach the fabric to the vertical bars with the clips.
6
Check Tension of Fabric & Zip Up the Corners
After attaching the Fabric to the Vertical Bars, unzip the opening panels to test the
tension to make sure that the zip opens and closes without any problems.
If there is too much tension, loosen the straps till the zips opens without any
problems
If satisfied with the tension, at each corner zip up the corners to hide the straps.
Assembly Instructions - Siesta Hi-Lo 3

7
Clip the Fabric onto the Bed Base
Raise up the bed base and then attach the clips
to the underside of the bed base all the way
around the bed base.
8
Mattress
Place the mattress inside the bed.
Your Siesta Hi-Lo is now ready to use!
Assembly Instructions - Siesta Hi-Lo 4

Read User Manual Before Use
It is important to fully understand the content of the user manual before
attempting to use the equipment.
If you have any questions or concerns, please
call us on 01706 816274 or email [e-mail]
Assembly Instructions - Siesta Hi-Lo 5
