Safety Vision 36 Series User manual

36 SERIES
USER GUIDE

2
Important Notices
Title: 36 Series IP Camera User Guide
Document Version 1.0

PN: 36-xxIR-IP

Safety Vision attempts to provide information contained in this manual
based on the latest product information available at the time of publication.
However, because of Safety Vision’s policy of continual product improvement,
Safety Vision reserves the right to amend the information in this document at
any time without prior notice.

This material is confidential and the property of Safety Vision. It is shared with
your company for the sole purpose of helping you with the operation of the
described equipment.

Safety Vision makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Safety Vision shall not be liable for errors
contained herein or for incidental or consequential damages in connection
with the furnishing, performance, or use of this material.

Safety Vision expressly disclaims all responsibility and liability for the
installation, use, performance, maintenance, and support of third-party
products. Customers are advised to make their independent evaluation of
such products.
No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Safety Vision.

Safety Vision is a registered trademark of Safety Vision, LLC. All other products or
name brands mentioned in this document are trademarks of their respective
owners. For more information about Safety Vision and its products, go to
www.safetyvision.com or call 800-880-8855.

3
Safety Instructions..............................................................
Overview...........................................................................
Cables Description..............................................................
Installation.........................................................................
Camera Mounting..............................................................
Installation of Network Cable Water-proof Jacket (Optional)...
Water-proof Jacket Components.........................................
Preparation before using the webcam..................................
Specifications...................................................................
FCC Compliance Statement................................................
Table of Contents
4
6
7
9
10
13
13
15
17
18

4
Safety Instructions
These instructions are intended to ensure that users can use the product
correctly and avoid danger or property damage.
Precautions are divided into Warnings and Cautions.
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
WARNING
You must be in strict compliance with the electrical safety regulations you
reside and/or operate in.
Input voltage should meet both the SELV (Safety Extra Low Voltage)
and the Limited Power Source with 24 VAC or 12 VDC according to the
IEC60950-1 standard.
Do not connect several devices to one power adapter as overload and/or
overheating may create a fire hazard.
Please make sure that all connector are firmly secured. When the product
is mounted on a wall or ceiling, the product should be securely installed.
If smoke, odor, or noise emits from the device, remove power at once and
unplug all cables.
Proper configuration of all passwords and other security settings is the
responsibility of the installer and/or end-user.

5
CAUTION
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is necessary, use
clean cloth with a bit of ethanol and wipe it gently. If the camera will not
be used for an extended period, please replace the lens cap to protect the
sensor from dirt.
Do not aim the camera at the sun or extra bright places. Blooming or
smearing may occur otherwise (which is not a malfunction), and affect the
endurance of sensor at the same time.
The sensor may be burned out by a laser beam, so when any laser e
quipment is in using, make sure that the surface of sensor will not be
exposed to the laser beam.
Do not place the camera in extremely hot, cold (the operating
temperature shall be -30°C ~+60°C, or -40°C ~ +60°C if the camera model
has an “H” in its suffix), dusty or damp locations, and do not expose it to
high electromagnetic radiation.

6
Overview
36 series IP Camera Components
1. Cover
2. Lens shield
3. Infrared (IR) LED
4. Mounting Base
5. 3-Axis Adjustable Camera
Module
NOTE - Press the Reset Button for approximately 10 seconds while the
camera is powering on to restore the default settings.
2
1
35
4

Cables Description
7
1. RJ45 Network Cable
2. M12 D-Coded Connectors
3. BNC FemaleTerminal
The following describes the different connectors that may be encountered on
this camera series.
RJ45
BNC
M12 D-code

The relation between M12 (left) and RJ45 (right) connections are shown in the
following figure and table.
8
Cables Description(cont.)
DESCRIPTION M12 RJ45
TX+ 1 1
TX- 3 2
RX+ 2 3
RX- 4 6
1 2
3 8 14

9
Ensure the camera is in good condition and all accessories were included.
Ensure the recorder is powered off during installation.
Ensure the mounting surface is sufficient to support the weight of the
camera.
Before you start:
Installation

10
Do not remove the protective film from the dome until installation is
complete.
Do not touch the inside of the cover.
Before you start:
Camera Mounting
1. Paste the drill template to the desired mounting place.
A
1
1
1
1

11
2. Drill the four screw holes and a cable hole in the vehicle shell according
to the Hole 1 and Hole A on the drill template.
3. Install the screws.
4. Disassemble the camera
Loosen the four screws on the camera cover, and separate the cover from
the mounting base.
5. Align the mounting holes on the mounting base with the holes on the
drilling template on the mounting surface, and insert the prepared
self-tapping screws (see step 2) into the holes.
6. Tighten the four nuts on the back of the surface to secure the mounting
base.

12
7. Adjust the camera angle.
1) View the camera image via a live view on the camera’s or
recorder’s firmware.
2) Slightly loosen the adjusting screws next to the retaining bracket.
3)Tighten the adjustment screw after adjusting the camera angle.
Adjust the screws

13
If the camera is installed outdoors, you can adapt the water-proof
accessory for the network cable after the camera is secured on the
installation surface.
8. Align the cover to camera and fix it by securely tightening the screws
which are embedded together with the cover.
9. Remove the protective film on the dome after installation is complete.
1. Camera’s Network Interface
Socket
2. O-Type Gasket
3. Network Plug
4. Waterproof Endcap
5. Waterproof Rubber Gasket
6. Lock Nut
7. Network Cable from Router/
Switch
Water-proof Jacket Components
Installation of Network Cable Water-proof Jacket (Optional)
NOTE - Four screws must be tight to assure internal gasket is properly
sealed.

14
Feed the plugless network cable (7) through the lock nut (6),
waterproof rubber gasket (5) (the rubber gasket inset ridge must face
the waterproof endcap), and the waterproof endcap (4) in order.
Crimp an RJ-45 network plug (3) onto the end of the cable, taking care
to insert the twisted pairs of wires in correct order.
Place the O-type gasket (2) onto the end of the camera’s network
interface socket (1).
Insert the network plug (3) into the camera’s network interface socket (1).
Insert the waterproof rubber gasket (5) into the waterproof endcap (4),
and secure the lock nut (6) with the waterproof endcap (4).
Align the snap on the waterproof endcap (4) with the notch on
the camera’s network interface socket (1), and then secure the
waterproof endcap (4) to the camera’s network interface socket (1)
to finish the installation.
1.
2.
3.
4.
5.
6.

15
Modifying the IP Address, please input the default IP Address (10.100.100.101)
in a web browser initially and to go on the steps as following;
1)To access on our webcam by default user name “admin”and
password”Sv123456”
2) Press “setting the network”to modify or edit IP Address,subnet mask,
network gateway or HTTP port.
3) Press “login”to activate.
2. Setting IP Address via HTML
1) Run Onvif free open source software
Download link:
https://nchc.dl.sourceforge.net/project/onvifdm/onvifdm-v2.2.250/odm-v2.2.250.msi
2) Press “Refresh” will indicate all available devices on the screen.
3)To get the IP Address of the webcam from device list.
1. To use Onvif free open source software to access IP Address
Ensure the power cable,audio cable,camera RJ-45 network connector is being
connected before using the webcam.
Please inquire your network administrator to set IP Address, for each webcam
IP Address default as 10.100.100.101.
Users are access to the default IP Address, it will take modifying or confirming
the camera’s network connection settings.
Preparation before using the webcam

16
Confirmed your web browser is access to run signed ActiveX controls on PC,
“download the signed ActiveX controls” setting as “prompt”, and enable
“run ActiveX controls and plug-in”.
All the settings route is Internet Explorer, tools, international internet options,
security, reset custom level.
After completing the settings, you may input the default IP Address in the web
browser to access the real-time image of the IP camera. A security alert dialog
box will pop up on the screen, please click”OK”to download ActiveX
components directly from the webcam.
3. Web browser settings and required software components
To access the camera by selecting of admin or guest identity. Default user name
as admin, password: Sv123456. Input and press “login”to access.
4. Accessing

17
Specifications
SPECIFICATIONS
Image Sensor
Resolution
Focal Length
FOV (H / V / D)
Minimum illumination
IP Rating
Power Requirement
OperatingTemperature
Video Compression
Frame Rate
Weight
1/2.8"_2.9μm CMOS
2M (1920X1080)
2.8mm;3.6mm;6mm (optional)
85.8°/46.2°/98°(2.8mm)
Color:0.02 Lux at F2.0；
B/W:0.003 Lux at F2.0；
0 Lux with IR LED ON
IP68
PoE (802.3 af)
-10°C ~ 50°C
H.265/H.264/MJPEG
60Hz:30fps
0.84kg

18
This device has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules.These limits are designed to
provide reasonable protection against harmful interference when the equip-
ment is operated in a commercial environment.This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference
in which case the user will be required to correct the interference at his own
expense.
Any changes or modifications in construction of this device which are not ex-
pressly approved by the party responsible for the compliance could void the
user’s authority to operate the equipment.
FCC Compliance Statement
NOTE
CAUTION

19
