Safety Vision SV-LCD56B1
Color TFT LCD Collision Avoidance System
Quick Installation Guide
Overview
The Safety Vision SV-LCD56B1 Color TFT LCD Collision
Avoidance System is designed for rugged, mobile
environments and turns on automatically when the
vehicle transmission is in reverse gear. Each system
includes a 5.6-inch monitor, camera, and system power
cable with inline control box. The system monitor has an
integrated speaker, and the system camera has an
integrated microphone, permitting the driver to both see
and hear activity within the camera’s range. One camera
can be connected to the SV-LCD56B1 system, and one
camera is provided with the system.
Components of the SV-LCD56B1 system include:
Safety Vision SV-LCD56B1 Monitor, which features:
yA 5.6-inch TFT LCD screen
yWide field of view
yIntegrated speaker
Safety Vision SV-625B-KIT, which includes the
camera (Part Number SV-625B) and a 65-foot
extension cable (Part Number SV-523B) and has the
following features:
yRugged, water-resistant housing
yCCD image sensor for improved image quality
yWide field of view (135° diagonal, 108° horizontal)
yLEDs that generate infrared light for improved
image quality in low-light situations
yIntegrated microphone
Safety Vision SV-ILCB system power cable with inline
control box , which provides DC power to the monitor
and camera and has 1 audio/video input and 1
audio/video output
Important Safety Precautions
Install and operate the SV-LCD56B1 system with the
following safety precautions in mind:
The ground (black) wire of the system power cable
must be connected directly to the vehicle chassis.
Use only the correct voltage (12 to 24 VDC).
To reduce the risk of electrical shock, disconnect the
battery from the electrical system of the vehicle before
starting the installation.
Do not expose the monitor to water or other liquids.
To avoid the risk of electric shock, do not disassemble
the system components, and keep cables away from
sharp objects.
Do not block the ventilation holes in the monitor
housing.
This system is designed to assist the vehicle driver
with rear vision only. Do not attempt to view the
monitor while driving forward.
Select inconspicuous cable routes that do not interfere
with normal driver or passenger mobility.

SV-LCD56B1 Quick Installation Guide September 2007
Supplied Hardware
The following hardware is supplied for installation with
each SV-LCD56B1 system:
Hardware Item Quantity
SV-LCD56B1 Monitor 1
Monitor Cable 1
Monitor Mounting Bracket 1
Monitor Screw Kit 1
SV-ILCB System Power Cable with Inline
Control Box 1
SV-625B Camera 1
Camera Extension Cable (65-foot) 1
Camera Sun Visor 1
Camera Mounting Bracket 1
Camera Screw Kit 1
SV-LCD56B1 QIG Ver.1.0.doc 2
System Components
SV-LCD56B1 Monitor
A POWER LED—indicates that the monitor has power
B DAY/NIGHT SENSOR—senses available light and
adjusts monitor brightness accordingly
C MENU BUTTON—when pressed and held for a few
seconds, initiates display of onscreen user controls
for image contrast and brightness and speaker
volume
D + BUTTON—UP button—increases the value for
Setup menu items, such as Volume
E – BUTTON—DOWN button—decreases the value
for Setup menu items, such as Volume
FPOWER BUTTON— turns the monitor ON or OFF
G NORMAL/MIRROR SWITCH—switches image
display to Normal or Reverse (as it would appear in
a rear-view mirror)
H MONITOR CABLE—receives power and camera
images from the inline control box
I BRACKET SLOT—accepts the adjustable mounting
bracket
SV-625B Camera
A Infrared LEDs—generate light to compensate for
low-light situations
B INTEGRATED MICROPHONE

SV-LCD56B1 Quick Installation Guide September 2007
SV-ILCB System Power Cable with Inline Control
Box
SV-LCD56B1 QIG Ver.1.0.doc 3
A Monitor connector—accepts the connector of the
monitor cable and supplies DC power to the monitor
B Red wire—connects to vehicle wire that has 12
VDC when the vehicle ignition is on
C Black wire—GROUND—connects to vehicle
chassis
D Green wire—connects to vehicle wire that has 12
VDC when the vehicle transmission is in reverse
gear (typically the wire for the backup lights)
E Yellow wire—optional—connects to vehicle wire
that has 12 VDC when audio input is desired (for
example, the wire for the backup lights). (The yellow
wire enables or disables audio input from the
camera.)
F Camera connector—accepts the connector for the
supplied camera extension cable and supplies DC
power to the camera
Optional Components
Devices other than the components supplied with the
SV-LCD56B1 system can be connected to the system.
Typical Installation
SV-LCD56B1 Monitor
1. Select a mounting surface for the monitor, which can
be mounted overhead or elsewhere in the vehicle
cabin (including on the floor or console). The mounting
surface should:
yBe level, waterproof, ventilated adequately, and
capable of supporting the weight of the monitor and
mounting bracket
yNot be close to a vehicle speaker (to prevent
interference from the speaker’s magnetic field)
yNot be extremely hot or humid
2. Affix the monitor bracket to the mounting surface with
the supplied screws.
ÏInstalling the Monitor Bracket
3. Position the monitor in the monitor mounting bracket,
adjust the angle as necessary, and tighten the handle
screw.
ÏInstalling the Monitor in the Bracket
4. Connect the connector of the monitor cable to the
monitor connector of the inline control box.

SV-LCD56B1 Quick Installation Guide September 2007
SV-625B Camera
1. Select an appropriate mounting location for the
camera, which should be mounted on a solid, flat
surface at the highest possible point on the vehicle.
2. With the provided hardware, affix the camera
mounting bracket to the mounting surface, and secure
the camera and sun visor in the bracket.
ÏInstalling the Camera
SV-LCD56B1 QIG Ver.1.0.doc 4
3. Connect the male connector of the camera pigtail to
the female connector of the provided 65-foot extension
cable. Align the arrows on both cable connectors, and
then hand-tighten, as follows:
ÏConnecting the Camera Pigtail to the Extension Cable
4. Connect the connector of the camera extension cable
to the camera connector of the inline control box.
SV-ILCB System Power Cable with Inline
Control Box
Connect the unterminated wires of the inline control box
as follows:
Wire Color Vehicle Location
Red Vehicle wire that has 12 VDC when
the vehicle ignition is on
Black
(Ground) Vehicle chassis
Green
(Trigger) Vehicle wire that has 12 VDC when the vehicle transmission is in reverse
gear (typically the wire for the backup
lights)
Yellow*
(Optional) Vehicle wire that has 12 VDC when audio input is desired (for example,
the wire for the backup lights). (The
yellow wire enables or disables audio
input from the camera.)
.
System Operation
Initial Setup
To initiate display of the main menu, press and hold the
MENU button on the front panel of the monitor. Use the
UP and DOWN buttons to increase and decrease values
for menu items.
NOTE: After several seconds of inactivity, the menu is no
longer displayed, and the MENU button must be
pressed again to initiate display of the main menu
again.
Menu items can be changed as follows:
Menu Item Function
CONTRAST Adjusts the contrast level between dark
and light images
BRIGHT Adjusts the brightness intensity level
VOLUME Adjusts the volume of the integrated
speaker


SV-LCD56B1 Quick Installation Guide September 2007
SV-LCD56B1 QIG Ver.1.0.doc 5
System Power
In typical installations, the system is placed into Standby
mode automatically when the sensor wire for the vehicle
ignition is activated, and the monitor automatically
displays camera input when the sensor wire for the
vehicle backup lights is activated.
Cleaning
Turn the system off and disconnect components from
power before cleaning. Use a damp cloth for cleaning. Do
not use harsh cleaners.
Specifications
SV-LCD56B1 Monitor
Item Specification
LCD Panel Size 5.6-inch (diagonal)
Video System NTSC standard signal
Power Input 12 VDC (with control box 12/24 VDC)
Power Consumption Maximum 5 watts
Sync System Internal
Resolution 336,960 pixels
Power Connector 4-pin wire S-video connector
Speaker Impedance 16 ohms, 0.5 watt maximum
Impact Rating 4 G
LCD Profile Wide-
Screen Ratio 4:3
Response Time 30 ms (at 25°C)
View Angle (CR>10) 40/65/65/65 (up/down/left/right)
Field of View 135° diagonal, 108° horizontal
Brightness 500 cd/m2
Contrast Ratio 300:1
Automatic Brightness
Control Light sensor, Day/Night switch
On-Screen Display
Controls Brightness, Contrast, Volume Color, Languages
Operating Temperature 5°F to 149°F (-15°C to 65°C)
Storage Temperature -13°F to 185°F (-25°C to 85°C)
Weight 0.75 pounds (0.34 kg)
Dimensions
Width x Height x Depth 6.5 x 4.5 x 1.1 inch
(165 x 115 x 29 mm)
Supplied Accessories Adjustable mounting bracket
Extension cable
Screw kit
SV-625B Camera
Item Specification
Image Type Color CCD
Horizontal Resolution 420 TV lines
Vertical Resolution 390 TV lines
Number of Pixels EIA 270,000
Power Supply 12 VDC
Power Consumption 1.5 watts
Signal-to-Noise Ratio Better than 48 db
Sync System Internal
Scanning System 2:1 interface
Scanning Frequency 1/60 ~ 1/120,000 seconds
Field of View 110°
Impact Rating 10 G
Operating Temperature -22°F to +149°F (-30°C to 65°C)
Storage Temperature -42°F to +185°F (-40°C to 85°C)
Dimensions
(Width x Height x Depth) 3.2 x 2.9 x 2.3 inches (82 x 73 x 58 mm)
Weight 0.84 pounds (0.38 kg) (including
bracket)
Supplied Accessories Adjustable mounting bracket
Extension cable
Screw kit
Minimum Illumination 0 lux (IR on), 0.1 lux (IR off)
SV-ILCB System Power Cable with Inline
Control Box
Item Specification
Power Input 10 ~ 28 VDC
Power Consumption < 2 watts
Audio/Video Input 1
Audio/Video Output 1
Warranty Information
LIMITED 1-YEAR NEW PRODUCT WARRANTY
Safety Vision, L.P. (“SV”) makes the following limited warranty,
which is effective at the time of the original end-user purchase.
NOTE: Optional warranty products are available for all SV
products and may be purchased at the time of the original
end-user purchase or any time during the original Limited
1-Year New Product Warranty period.
SV warrants this product against defects in materials for a
period of 1 year after the date of purchase. During this period,
SV will repair or replace a defective product or part without
charge to the customer. The customer must send the defective
product or part to SV or an authorized SV dealer. The customer
must pay for all transportation and insurance charges for
sending the unit to be repaired. SV’s total liability is limited to
the original product cost.
Quick Installation Guide
The customer should thoroughly read this guide before
operating this product.

SV-LCD56B1 Quick Installation Guide September 2007
SV-LCD56B1 QIG Ver.1.0.doc 6
Customer’s Responsibility
The above warranty is subject to the following conditions:
Customer must notify SV within 10 days of discovering the
defective product or part and provide a description of the
defect and complete information about the manner of its
discovery.
All warranty servicing of this product must be performed by
SV or an authorized servicing agent.
Warranty extends only to defects in materials as limited
above. Warranty does not extend to any product or part that
has been lost or discarded by the customer; to damage to
products or parts caused by misuse, accident, improper
installation, improper maintenance, or use in violation of
instructions furnished with the product; to units that have
been altered or modified without authorization of SV; to
damage to products or parts thereof that have had the serial
number removed, altered, defaced, or rendered illegible; or
to any failure of the product to function caused by burglary,
fire, flood, war, riot, civil commotion, Acts of God, or any
other condition beyond the control of SV.
Obtaining Warranty Service
To obtain warranty service, the customer must contact the SV
Service and Warranty Manager at 713.896.6600 or
800.880.8855 to report a defective product. (The customer must
report the model number and serial number if available.) The
Service and Warranty Manager will assist in troubleshooting the
problem and, if necessary, issue a return material authorization
(RMA) number. The customer must include this number on the
outside of each package shipped to SV.
Important Packing and Shipping Instructions
When a product requires service, only the affected component
must be returned. The customer must use proper packing
material to ensure against damage during shipping. Any
shipping damage caused by improper packing is not covered
under this warranty. In addition, the customer must include a
return material authorization (RMA) number on the outside of
each package shipped to SV and a letter explaining the defect
with the product.
How to Reach Us
If you have exhausted the information in this document and
require further assistance or information, please contact Safety
Vision toll-free at 1-800-880-8855 or send an e-mail message
requesting assistance to: [e-mail].
Document Change Log
Version Filename Date
Changes
Made
1.0 SV-LCD56B1 QIG VER.1.0.DOC September
2007 New document
