Safety Xpress APARKLOCK User manual

www.safetyxpress.com.au
PRODUCT INFORMATION &
INSTALLATION GUIDE
1300 394 240
1Page of 4Installation Manual: Automatic Parking Lock
Automatic Parking Lock
Specications
SKU APARKLOCK
Components
Automatic Parking Lock
Remote Control x 2
Keys x 2
D Batteries x 4
Colour Yellow (bar) Black (base)
Size
Width 430mm
Height 420mm (Raised)
OR 75mm (when down)
Depth 320mm (Raised )
OR 430mm (when down)
Range Remote Control:
30 meter
APP Range:
30 meter
Fixings Mounting Bolts Included x 3
Warranty 12 Months Warranty
Description:
Control access of your parking lot using Bluetooth
Technology via a Smartphone. Battery operated,
simply press the Up/Down button on Remote Control or
through the APP to raise or lower the barrier discreetly.
Installation:
Before installation, make sure you nd a suitable
spot in the middle of your car park space.
We recommend you follow our instructions to set up
APP and Remote Control functions rst before you
bolt the product down.
APP
2 x Keys
2 x Remote
Controls
WATER
RESISTANT
Water
Resistant
4 x
NOT INCLUDED
Batteries
Included
30 Meter
Range
Smartphone
Control
Blue Tooth
Available
3 x
4 x
Fixings
Included
APP
Available
Available
APP
Available
Available
APP
Available
Available
Motor
Box
Battery
Box
Buzzer
Ultrasonic
Sensor
Up
Down
Up
Down
CAR PARK
Please Install Automatic Parking Lock
in the Middle of Parking Space
PRESS
Installation Video
You can also watch our installation video
online by scanning the QR code below:
https://www.youtube.com/
watch?v=KZvHGLziuZY

www.safetyxpress.com.au
PRODUCT INFORMATION &
INSTALLATION GUIDE
1300 394 240
2Page of 4Installation Manual: Automatic Parking Lock
2
User Center Interface
Connection & Remote Control A
1. Use the supplied keys to open base cover.
2. Connect the Battery Box to the Motor Box.
3. Open Battery Box, put in 4 x D type Batteries
4. You will hear a ‘Beep’ sound which indicates
the unit is connected correctly.
5. You can now close the Battery Box.
6. Remote Control A comes already paird with the
main unit. Make sure nothing is in the path of the
main unit raising / lowering, Press Up / Down button
to test Remote Control A.
Remote
Control A
Motor
Box
Battery
Box
Buzzer
Ultrasonic
Sensor
Up
Down
Up
Down
CAR PARK
Please Install Automatic Parking Lock
in the Middle of Parking Space
PRESS
Up Down
Motor
Box
Battery
Box
Buzzer
Ultrasonic
Sensor
Up
Down
Up
Down
CAR PARK
Please Install Automatic Parking Lock
in the Middle of Parking Space
PRESS
1
Motor
Box
Battery
Box
Buzzer
Ultrasonic
Sensor
Up
Down
Up
Down
CAR PARK
Please Install Automatic Parking Lock
in the Middle of Parking Space
PRESS
3
2
Bolt the base down using 3 x screws
supplied.
APP Pairing
Download and install KAVASS App on your Smart Phone
from Google Play Store (Android) or Apple Store (iOS).
Open the APP, after registeration, you will see interface
as shown below
Make sure your SmartPhone and Remote Controls are
nearby and within operating range of the main unit.
Lock
My Parking User Center
Unlock
My Parking
Switch Lock
Remote Control Pairing
Automatic Sensor Pairing
User CenterMy Parking
1
1. Click User Center
2. Click My Parking
3. Click ADD
4. Open Base Cover to nd your Lock ID and Bind ID.
Please note these IDs are case sensitive.
5. Click Conrm
6. You can now Lock/Unlock your parking lock using the APP
Note: Multiple parking locks can be connected and controlled
via the APP on a single mobile device by following same steps
above, and go to Switch Lock to switch between locks
3
4
5
Lock
My Parking User Center
Unlock
My Parking
Switch Lock
Remote Control Pairing
Automatic Sensor Pairing
6
NOTE: You can also scan QR codes to download our control APP

www.safetyxpress.com.au
PRODUCT INFORMATION &
INSTALLATION GUIDE
1300 394 240
3Page of 4Installation Manual: Automatic Parking Lock
Lock
My Parking User Center
Unlock
My Parking
Switch Lock
Remote Control Pairing
Automatic Sensor Pairing
Remote Control B Pairing
Open KAVASS App, on right hand side top corner,
click the 3 dots, and Select > Remote Control Pairing.
Follow prompts on the next interface:
- Press both buttons on Remote Control B
simultaneously, after hearing a ‘beep’ sound, your
Automatic Parking Lock should be paired with your
Smart Phone.
You can now test the remote control functions as
follows:
Multiple User Control - APP
Owner can give access to other users - such as
visitors by following below steps
Note: if you have purchased
additonal remote control units, the
same steps would apply to pair all
additional remote countrols.
Motor
Box
Battery
Box
Buzzer
Ultrasonic
Sensor
Up
Down
Up
Down
CAR PARK
Please Install Automatic Parking Lock
in the Middle of Parking Space
PRESS
Up Down
Remote
Control B
Motor
Box
Battery
Box
Buzzer
Ultrasonic
Sensor
Up
Down
Up
Down
CAR PARK
Please Install Automatic Parking Lock
in the Middle of Parking Space
PRESS
Motor
Box
Battery
Box
Buzzer
Ultrasonic
Sensor
Up
Down
Up
Down
CAR PARK
Please Install Automatic Parking Lock
in the Middle of Parking Space
PRESS
Press Button with Lock image
to raise the barrier bar up.
Press Button with Unlock image:
to lower the barrier bar up.
1. Click User Center (at bottom right of main screen)
2. Click My Parking
3. Pick the Parking Lock you want to give visitor access to
4. Add Authorised Person (visitor)
5. Enter visitor’s Mobile and Name
6. Click Share
7. Once sharing is successful, all users should see the same
interface (blue and white interface as shown on left)
User Center Interface
Note:
Owner has control to add/
delete visitors at any time
Max. 10 people can be
given temp. access as
visitors to the Parking Lock.
(by repeating the same
steps)
Step 1
Step 1
Step 2
Step 3
Step 4
Step 5
enter visitor’s mobile
enter visitor’s name
Visitors need to download
and install KAVASS APP on
their phone rst, and both
owner and visitor need to be
within the operating range
of the Automatic Parking
Bollard.
Once successful, both owner
and visitor will see the same
blue/white interface
If unsuccessful, visitor won’t
see the blue/ white interface
at all.

www.safetyxpress.com.au
PRODUCT INFORMATION &
INSTALLATION GUIDE
1300 394 240
4Page of 4Installation Manual: Automatic Parking Lock
Automatic Parking Lock - Features
Water Resistant:
Automatic Parking Lock can withstand the weather.
eg. in case of heavy rainfall the device can still work for at least an hour without any adverse a󰀨ect.
Self Protection:
In case of misuse or that a vehicle has rolled onto the Automatic Parking Lock, the unit itself can
self protect by:
- Rotate back and forth to protect itself at 180°
- Pressure resistance <= 2000kg.
- Automatic reset if it is being pushed by force when operating.
Battery Life:
When the batteries are about to run out, the Automatic Parking Lock will make an alarm sound to
remind user to replace batteries.
DO NOT try to rise the Automatic Parking Lock barrier bar when it is under vehicle.
DO NOT try to park the car when the Automatic Parking Lock barrier bar is rising or lowering.
Battery Type
Dry Battery Lead Acid Battery Lithium Battery
Charging Method -- Chargeable Chargeable
Battery Life 12 Months 24 Months 5 Years
Working Temperature -10°C to 50°C -10°C to 50°C -22°C to 55°C
Life Span 3 - 6 Months 3 Months 8 - 12 Months
Note:
WATER
RESISTANT
Water
Resistant
Up to 1 hour
Pressure
Resistant
Up to 2000kg
180°
Degrees
Rotation
