Sage the Dose Control Pro User manual

the Dose Control™Pro
SCG600
EN QUICK GUIDE
DK QUICK GUIDE
SE QUICK GUIDE
NO QUICK GUIDE
FI PIKAOPAS

2
CONTENTSCONTENTS
SAGE®
RECOMMENDS
SAFETY FIRST
At Sage®we are very safety
conscious.We design and
manufacture appliances with
your safety foremost in mind.
In addition, we ask that you
exercise a degree of care
when using any electrical
appliance and adhere to the
following precautions.
IMPORTANT
SAFEGUARDS
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE
FOR FUTURE REFERENCE
• A downloadable version of
this document is also available
at sageappliances.com
• Before using the rst time
ensure your electricity supply
is the same as shown on the
label on the underside of the
appliance.
• Remove and safely discard
any packaging materials
before rst use.
• To eliminate a choking hazard
for young children, safely
discard the protective cover
tted to the power plug.
• This appliance is for household
use only.Do not use the
appliance for anything other
than its intended use.Do not
use in moving vehicles or boats.
Do not use outdoors.Misuse
may cause injury.
• Fully unwind the power cord
before operating.
• Position the appliance on
a stable, heat resistant, level,
dry surface away from the edge
and do not operate on or near
a heat source such as a hot
plate, oven or gas hob.
• Do not let the power cord hang
over the edge of a bench or
table, touch hot surfaces or
become knotted.
• Do not leave the appliance
unattended when in use.
• Always ensure the appliance
is turned OFF, unplugged at
the power outlet and has been
2Sage®Recommends Safety First
5Getting To KnowYour New Appliance
6OperatingYour New Appliance
10 Care, Cleaning & Storage
11 Troubleshooting
12 Guarantee

3
EN
WE RECOMMEND SAFETY FIRST
allowed to cool before cleaning,
attempting to move or storing.
• Always turn the appliance to
the OFF position, switch o
at the power outlet and unplug
at the power outlet when the
appliance is not in use.
• Do not use the appliance if the
power cord, plug, or appliance
becomes damaged in any way.
If damaged and maintenance
other than cleaning is
required please contact Sage
Customer Service or go to
sageappliances.com
• Any maintenance other than
cleaning should be performed
by an authorised Sage®
service centre.
• Children should not play with
the appliance.
• Cleaning of the appliance
should not be carried out by
children unless they are 8 years
or older and supervised.
• The appliance and its cord
should be kept out of reach
of children aged 8 years
and younger.
• The installation of a residual
current safety switch is
recommended to provide
additional safety when using
all electrical appliances.
Safety switches with a rated
operating current not more
than 30mA are recommended.
Consult an electrician
for professional advice.
• Do not use attachments
other than those provided
with the appliance.
• Do not attempt to operate
the appliance by any method
other than those described
in this booklet.
• Do not move the appliance
whilst in operation.
• Do not touch hot surfaces.
Allow the appliance to cool
down before moving or
cleaning any parts.
• This appliance shall not be
used by children. Keep the
appliance and its cord out
of reach of children.
• This appliance can be used by
persons with reduced physical,
sensory or mental capabilities
or a lack of experience and
knowledge, only if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved.
• Do not operate the grinder
without the hopper lid in
position. Keep ngers,
hands, hair, clothing and
utensils away from the
hopper during operation.

4
WE RECOMMEND SAFETY FIRST
The symbol shown
indicates that this appliance
should not be disposed of
in normal household waste.
It should be taken to a local
authority waste collection centre
designated for this purpose or
to a dealer providing this service.
For more information, please
contact your local council oce.
To protect against electric
shock, do not immerse the
power plug, cord or appliance in
water or any liquid.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS

5
EN
GETTING TO KNOW YOUR NEW APPLIANCE
B
C
D
E
F
G
I
HK
L
J
AA. Bean Hopper Lid
B. Bean Hopper
C. Hardened Stainless Steel
Conical Burrs.
Removable and Adjustable
Upper Burr
D. Grind Size Collar
E. GRIND TIME Dial
F. START / CANCEL Button
G. Grind Outlet
H. 50mm blade
I. Grind Tray
ACCESSORIES
J. Adjustable Razor™Dose
Trimming Tool
K. Portafilter Cradle 50–54mm
L. Portalter Cradle 58mm
Rating Information
220–240V ~ 50Hz 130W

6
BEFORE FIRST USE
Remove and safely discard all promotional labels
and packing materials attached to your Sage®
appliance.Wash hopper, and cradles in warm
soapy water and dry thoroughly. Wipe exterior of
grinder with a soft damp cloth and dry thoroughly.
Place grinder on at level surface and plug power
cord into 220-240V outlet and switch Power ‘ON’.
ASSEMBLING YOUR SAGE
CONTROL DOSE™PRO
Bean Hopper
Align tabs on the base of the bean hopper and
insert hopper into position. Holding the hopper,
press down rmly and turn the bean hopper dial
45° to lock into position.
A “click” sound will be heard when the hopper is
properly locked in place.
X
Ensure the hopper and the Grind Size
Collar is aligned properly.
Fill with fresh coee beans and secure lid on top of
bean hopper.
NOTE
If the bean hopper has not been locked into
position, the GRIND TIME dial will not be
illuminated.
GRINDING FOR ESPRESSO
COFFEE
Use single wall lter baskets when grinding fresh
coee beans. Use the ner 1–25 settings in the
ESPRESSO range.
Step 1:
Insert the appropriate portalter cradle size. Insert
your portalter into the cradle.
50-54mm
58mm
CRADLES
PUSH
Step 2:
Selecting Grind Amount
Select the desired amount of ground coee
required by turning the GRIND TIME dial.
Sec
Step 3:
Tamping the Ground Coee
After dosing the portalter with freshly ground
coee, tamp down with between 15-20kg
of pressure.
OPERATING YOUR NEW APPLIANCE

7
EN
OPERATING YOUR NEW APPLIANCE
Step 4:
Trimming the Dose
The adjustable Razor™Dose Trimming Tool
allows you to trim the puck to the right level for
a consistent extraction.
Select the correct width blade of the Razor™
to match the diameter of your lter basket. The
Razor™has three blades of varying widths: 58mm,
54mm and 50mm.The 58mm and 54mm are
already tted within the Razor™body.The 50mm
is separate.
If you require the 50mm blade, turn the adjustment
dial past #1 until the 54mm blade is fully extended
and able to be pulled from the body.
ADDITIONAL BLADE
54mm 50mm
If you require the 50mm blade, turn the Adjustable
Dial past #1 until the 54mm blade is fully extended
and able to be pulled from the body.
54mm
NOTE
The Adjustable Dial may feel tight as you
continue to wind it towards the end of its travel.
Insert the 50mm blade into the body.Wind the
Adjustable Dial until the blade is retracted past #4.
Press the 50mm and 58mm blades at the same
time, towards the centre of the body until a “click”
sound can be heard.
50mm
'CLICK'
APPLY PRESSURE
AT BOTH ENDS
Adjust the Razor™to the setting in the table below
for your Sage® espresso machine.This is a starting
point for your dose height.
Sage
®
Espresso
Machine
Portalter
Size
Dose
Height
Model name
starting with “SES9”
58mm
2
Model name
starting with “SES8”
54mm 2.5
After tamping the coee, insert the Razor™into
the lter basket until it rests on the rim of the
basket.The blade of the dosing tool should
penetrate the surface of the tamped coee.
If the blade does not penetrate the surface of
the tamped coee, your coee is under dosed.
Increase the amount of dosed coee by adjusting
the GRIND TIME dial.
Rotate the Razor™back and forth while holding the
portalter on an angle over the knock box to trim o
a little excess coee.

8
Step 5:
Select Your Grind Size
For espresso, we recommend starting with grind
size setting 15 and rotating the Hopper (to adjust
the Grind Size Collar) either coarser or ner.
NOTE
If the Grind Size Collar is tight, run the grinder
by pressing the START / CANCEL button
while turning the Hopper.This will release
coee grounds caught between the burrs.
GRINDING INTO A GRINDS
CONTAINER OR COFFEE FILTER
Step 1:
Remove cradle by sliding out from under the
grind outlet.
PULL
Place your container or coee lter directly under
grind outlet.
Step 2:
Select the required amount of ground coee
by rotating the GRINDTIME dial.
Step 3:
Select Your Grind Size
Rotate the Hopper to adjust the Grind Size Collar
until it reaches the required brewing method range.
FEATURES OF YOUR SAGE
DOSE CONTROL™PRO
Pause Function
You can pause the grinder during
operation, allowing you to collapse or
settle the coee in the Portalter.
• Press the START / CANCEL button to start
the grinding operation.
• During grinding, press the START / CANCEL
button to pause the grinding operation for
up to 10 seconds.
The START / CANCEL button will slowly ash
while paused.
• Press START / CANCEL again within this
time to resume grinding the remaining dose.
Or press and hold the START / CANCEL
button for 1 second to cancel.
Manual
Grinding manually allows you to have complete
control over how much coee is dispensed.
• Press and hold the START / CANCEL button
to grind for as long as you require.
• Release START / CANCEL button to
stop grinding.
OPERATING YOUR NEW APPLIANCE

9
EN
OPERATING YOUR NEW APPLIANCE
COFFEE CHART*
Brewing Method Espresso Percolator Drip French Press
or Plunger
Grind Size Fine Medium Medium Coarse Coarse
Grind Setting 1-25 26-34 35-45 46-55
Amount
(Shot / Cup)
6 secs per shot
10 secs per 2 shots 3 secs per cup 3 secs per cup 2 secs per cup
*This coee chart should be used as starting point to adjust your grind time and / or size, as both may vary when using
dierent coee bean types, age and degree of roast.
ADJUSTING CONICAL BURRS
Some types of coee may require a wider grind range to achieve an ideal extraction or brew.
A feature of your Dose Control™Pro is the ability to extend this range with an adjustable upper burr.
Hold hopper over container & turn
dial to release beans into container
Align hopper
into position
Run grinder
until empty
Remove hopper
Un
lock hopper
Move adjustable
top burr, 1 number,
coarseror finer
Default setting
is 6
R
emove wire
h
andle from both
si
des of the burr
Align the number
with the handle
opening
Remove upper
burr
Insert wire
handle from both
sides of the burr
Push upper burr
firmly into
position
Lock upper burr
Press down
firmly & rotate to
lock into position
Check your
extraction
Align hopper
into position

10
CARE, CLEANING & STORAGE
CARE, CLEANING & STORAGE
1. Empty beans from the hopper and grind
out any excess beans (see below).
2. Unplug power cord from power outlet
before cleaning.
3. Wash the hopper lid and bean hopper
in warm soapy water, rinse and
dry thoroughly.
4. Wipe and polish exterior of appliance
with a soft damp cloth.
CLEANING CONICAL BURRS
Regular cleaning helps the burrs achieve consistent grinding results which is especially important when
grinding for espresso coee.
NOTE
Do not use alkaline or abrasive cleaning
agents, steel wool scouring pads, as these
can damage the surface.
NOTE
Please do not clean any grinder parts or
accessories in the dishwasher.
Hold hopper over container & turn
dial to release beans into container
Align hopper
into position
Run grinder
until empty
Remove hopper
Un
lock hopper
Cleangrind outlet
with brush
Cleanlower burr
with cleaning brush
Clea
n upper burr
wi
th a brush
Push upper burr
firmly into position
Remove upper
burr
Lock upper burr Align hopper into
position
Lock hopper
