Saivod Lv6 electron Manual

LAVASTOVIGLIE

Manuale uso e manutenzione

DISHWASHER

Use and maintenance handbook

GESCHIRRSPÜLAUTOMAT

Bedienungs- und Wartungshandbuch

LAVAVAJILLAS

Manual de uso y manutención

LAVE-VAISSELLE

Livret d’instructions et d’entretien

12345678901

BEFORE USING THE APPLIANCE

Norms and regulations to be respected

• The dishwasher may only be used to clean household dishes. If the appliance is used for other

purposes or in a wrong manner, the manufacturer declines all responsibilities for possible damages.

• For safety reasons, no modifications must be carried out on the appliance.

• Before connecting the appliance to the electric power supply system, check that the power supply at

the place of installation is compatible with the electric data indicated on the data tag.

• The installation must be carried out by qualified personnel.

Before running the appliance for the first time

• Make sure the dishwasher was not damaged during transport.Do not hook up the appliance if there

is any damage. In case of damage, contact the vendor.

For the safety of children

• Do not allow children to play with the appliance.

• Detergents can cause permanent damage to eyes, mouth and throat.

They should therefore be kept outside the reach of children.

• The water in the dishwasher is not drinkable.Any residues of detergent in the appliance constitute a

source of danger for children.They must therefore be kept away from the open dishwasher.

Daily use

• Do not turn on the dishwasher if the electric cable, or the water supply or water drainage pipes are

damaged, or if the control board, the work surface or the base are in very bad condition.

• In case of a malfunction, shut off the water supply, then turn off the appliance and pull the electric

plugfrom theoutlet.Ifthere isa permanent electricconnection, turnoff theservice switch(if present)

or remove the fuse (or fuses).

• To remove the plug from the electric outlet, hold the plug itself and pull;never pull the cable.

• Allrepairs of the dishwasher mustbe carriedout by specialisedpersonnel.Inappropriate repairscan

create a severe danger for the user.For repairs, you should therefore contact our technical customer

assistance service or a specialised vendor.

• The replacement of the supply cable must be carried out only by the technical service staff.

• If the pipes and tubes are deteriorated, substitute them with new original parts before hooking up

the appliance.

• Do not use detergent substances that could lead to an explosion.

• Do not sit or lean on the open door.The appliance might otherwise tilt over.

• Before adding special dishwasher salt, detergent and rinse aid, make sure that the manufacturer of

these substances recommends their use for household dishwashers.

• Always shut off the water supply when the dishwasher is not in use for longer periods of time, e.g.,

during your vacations.

1.1 SAFETY INSTRUCTIONS

1234567890

23456789

1234567890

UNPACKING – DISPOSAL

Remove the external plastic packaging material, the corner re-enforcements, and the styrofoam base.

Open the door and remove the styrofoam blocks from the inside baskets.

Collect and recycle the packaging materials.This will preserve primary materials and help reduce the

amount of waste.

Take the packaging materials to specialised recycling centres .

Whentheappliance eventuallyhasto bedisposedof,itshould bemadenon-functionalbeforeeliminating

it.

Attention! Some packaging materials (e.g., plastic bags, styrofoam) can be

dangerous for children. Children should therefore be kept away from them.

At the end of its life span, the appliance must be eliminated by a specialised company, respecting all

existing laws and regulations.

This will make it possible to dispose of the old appliance while at the same time recuperating and

sorting syntheticmaterialsthat arefitforrecycling, thuscontributing totheprotection ofthe environment.

2.2 FINAL DISPOSAL OF APPLIANCE

2.1 UNPACKING

3.1 WASHING DISHES IN AN ECONOMIC AND ECOLOGICAL WAY

GENERAL ADVICE

• Don’t rinse your dishes under running water before placing them in the dishwasher

• Run the appliance only when it is full, because only like this the process becomes economical and

respects the environment.

• Always choose a programme that is adequate for the kind of dishes you want to wash and that

corresponds to how dirty they are

• You should avoid to use too much detergent, dishwasher salt, and rinse aid. Refer to the dosages

recommended in the usage instructions provided by the manufacturers of these substances.

• Make sure that the water softness regulator is set correctly.

3.2 DISHES NOT TO BE WASHED IN THE DISHWASHER

You must not wash in this appliance:

- Cutting boards or small containers in wood

- Plastic objects that are not heat resistant

- Lead crystal

- Objects made from tin or copper

- Dishes or cutlery with glued components

- Old cutlery with heat sensitive glue

- Steel objects that are oxidised easily

- Cutlery with handles in wood, horn, antler, porcelain, or mother of pearl.

When purchasing dishes, cutlery, or glasses, make sure that they are

dishwasher resistant.

12345678901

LA2505-020

3 2

DESCRIPTION OF THE APPLIANCE

1) salt container (IF PRESENT)

2) rinse aid container

3) container for detergent

4) data tag

5) filters

6) lower spray-rotor

7) upper spray-rotor

8) electric cable

9) water supply tube

10) water drainage tube

11) lower basket

12) upper basket

13) cutlery container

14) hook for door closing mechanism

4.1 GENERAL PARTS

4.2 TECHNICAL DATA

capacity (standard settings): 12

pressure of water supply system

minimum pressure:0.05 Mpa

maximum pressure:1 Mpa

Attention: the necessary characteristics

of the electric supply grid are indicated

on the data tag.

0,05 - 1MPa Model. ......................

....A

MAX .......W

........V.....Hz

Made in EU

...................

1234567890

23456789

1234567890

5.1 LEVELLING

Place the appliance in the spot where you want to install

it. Use feet P (unscrew or screw in) to regulate (if

necessary) the height of each foot to assure that the

appliance is in a fully level position.

Ifthe applianceis positionedin alevelposition, its correct

functioning is assured.

Maximum error = 2 degrees

Afterlevellingthe appliance, regulatethe hookofthe door

closing mechanism, to assure that the door closes

perfectly.

In order to obtain a perfect seal adjust the door (Fig. 2.1

“M”) locking device but only after having levelled the

machine in its final installation position.

N.B.In versions like (fig. 2.2), the door closing catch “M”

is not adjustable.

INSTALLATION

5.2 WATER CONNECTION

The water supply tube C, which accompanies the

dishwasher, makes it possible to connect the appliance

to a faucet with a 3/4”attachment.

During the installation, the following instructions must

be followed:

• Attach tube Cto the cold water faucet A;place filter B

(suppliedwith theappliance) betweentubeand faucet.

• If the tube is being attached to new pipes that have

not been used for a long time, you should let the water

run for some time before attaching the tube in order to

make sure that dirt and rust residues are eliminated.

• Make sure that the water pressure corresponds to the

range indicated on the data tag.

Theappliancemaybeconnectedto thecoldwatersystem.

It must not be connected to the hot water system.

LA2505-040

2.2

2.1

LA2505-030

12345678901

min 32 cm

max 80 cm

LA2501-050

5.3 CONNECTION OF DRAINAGE WATER

The curved end of drainage tube T, which is being supplied with your appliance, should be hooked

onto the edge of a sink or into a drainage pipe.

A special siphon should be used to prevent bad odours.

During the assembly, the following precautions should be taken:

- the drainage tube must not be bent to avoid blockages;

- the tube’s end, relative to the top surface of the dishwasher (fig. 4), must be placed at a height

between 32 and 80 cm;

- the end of the tube must never be immersed in water;

- the drainage tube must not be extended to more than a maximum length of 1 metre.The extension

must have the same internal diameter.Furthermore, the maximum height at which the tube’s end

can be placed (in the case of an extended tube) must be reduced from 80 to 50 cm.

- If you use a drainage pipe, make sure its internal diameter is not inferior to 4 cm.

5.4 ELECTRIC CONNECTIONS

The appliance may only be connected to a properly installed electric outlet with

an earth (ground) contact.The connection must be carried out in correspondence

with existing laws and regulations and supplementary rules issued by the supplier

of electric power.

The tension shown on the data tag must correspond to the power tension of the electric

grid at the site of installation.

See data tag for the size and format of the electric outlet to be used.

1234567890

23456789

1234567890

USE

6.1 BEFORE USING THE APPLIANCE

Before turning on the appliance, make sure that the plug attached to the electric cable is

connected to the electric outlet, the water supply tube is connected to the faucet, the faucet is

turned on, the drainage tube has been connected according to the instructions.

LA2505-070

Use only special dishwasher salt. Other types of salt (e.g., regular household salt)

often contain substances that do not dissolve completely in water and can

therefore obstruct the water softener, thus making it unusable.

Regulation of the water softener system (IF PRESENT)

For the washing process it is better to use soft water (with a

low calcium content), to avoid calcium deposits on the dishes

and on the inside of the dishwasher. For this reason, the

appliance is equipped with a water softener (fig. 6) which is

automatically regenerated in regular intervals thanks to the

saline solution. The salt consumption for the regeneration

process depends on the hardness/softness of the local water

that is being used.

To find out the degree of hardness of your water contact

your town administration or use a commercial testing kit.

Opening of the door

Pull the handle forward. The door should open without effort. If you pull the handle while the

dishwasher is running, a safety mechanism will turn off the appliance.

Position

regulation device

French degrees

˚fH German degrees

˚dH

<15

>15 <25

>25 <40

>60 <90

<8,4

>8,4 <14

>14 <22,4

>33,6 <50,4

>=higher/<=lower

LA2505-060

Adding special dishwasher salt

(only in the salt container version)

• Open the door and take out the lower basket

• Remove the lid of the salt container by turning it anti-

clockwise

Onlyduringthe firsttimeyou carryout this operation:

fill about 1/2 litre of water into the salt container

• Use funnel Lto fill the special dishwasher salt into the

container (use about 1.0-1.5 kg of salt).

• Remove possiblesalt residues fromthe openingof the

container.

• Put the lid of the container back in its place by turning

it clockwise.

• If you don’t use the dishwasher immediately after fill-

ing the salt container, run the programme

pre-wash

rinse awaythewaterand saltparticles thatspilled over

from the container.

For safety reasons we recommend to refill the

container after seven wash cycles – always at the

beginning of a cycle.

To guarantee an optimal regeneration of the softener it is

necessary to set device Daccording to your local hardness

(see table) and to make sure that the salt container is always

filled with special dishwasher salt.

12345678901

LA2505-080

Refilling of rinse aid

The rinse aid, which is released automatically

during the final phase of the wash cycle,

guarantees that the dishes dry quickly and

prevents the formation of stains and calcium

sediments.

Indication of salt level (IF PRESENT)

Thegreenmarkunder thecapindicates thatthere

is still enough salt in the container. If the green

mark isno longer visible,the saltcontainer needs

to be refilled with special dishwasher salt.

LA2505-092

LA2505-096

Only use rinse aids for dishwashers. Other products won’t obtain the desired

effect.

The rinse aid container Sis located on the inside

of the door.

• Remove the container capTbyturning it_ revo-

lution anticlockwise.

• Fillcontainer withrinse aidup to the broken line.

Maximum quantity:about 140 ml.

• Put the cap back in its place.

• Clean off possible residues of rinse aid with a

cloth, otherwise too much foam might be pro-

duced during the rinsing process.

Indication of rinse aid level

More rinse aid needs to be added when the

indicator(located onthe containerF) isclear ( ).

When the container is full, the indicator has a dark

coloration.

1234567890

23456789

1234567890

LA2505-094

Regulation of rinse aid dosage

The regulation Rof the quantity of rinse aid that is

released can be found in the refill opening of the

rinse aid container.

It can be adjusted with a screwdriver.The possible

settings range from 1 to 4. 1 corresponds to a

release of one ml of rinse aid, 4 to four ml, etc.The

appliance has been set on 2 (two ml) by the

manufacturer.

A full rinse aid container is sufficient for about 50

washcycles.The quantityofrinseaid tobereleased

should be adjusted when the result of the wash

process is not satisfactory.

• Always wipe off with a cloth any rinse aid that

spilled over from the container.

It is important to check the level of rinse aid in

the container periodically – if possible every

31 wash cycles.

Adding the detergent

IMPORTANT! Do not use detergents in this

dishwasher that are made for dish washing by

hand! These substances produce large quantities

of foam but they do not clean the dishes in a

dishwasher.Theycan evenleadtoa malfunctioning

of the appliance.

You should therefore only use detergents that are

specifically made for household dishwashers.

Keep your detergent containers closed and in a

dry place.

Only when you use the pre-wash programme no

detergent is needed.

During aprogrammethedetergentis automatically

taken from the detergent container.

Werecommendthe useofabout 25g ofdetergent.

Detergents vary in their strength and efficiency.

You should therefore pay attention to the

dosage recommendations of each

manufacturer.

The container for the detergent is located on the

inside of the door.

If the lid is closed:

• Push forward closing mechanism P. The lid will

open with a “click”.

• Fill the detergent into the containerV.

• To close the lid, press until you hear a closing

“click”.

If your dishes are exceptionally dirty, you can also

fill some detergent into the indentation of the lid. In

this case, fill the indentation up to the edge. This

detergent will be available and active during the

pre-wash phase.

LA2505-090

LA2505-100

12345678901

LA2505-110

LA2505-112

There are two dish baskets that allow you to store

all different kinds of dishes.

• Remove from the dishes any larger pieces of

food to avoid an obstruction of the filter and the

development of bad odours.

• If pots and pans are particularly dirty and con-

taincrustsof food (afterfrying or roasting),soak

them in a water bath before washing them in the

dishwasher.

Use of the lower basket

The lower basket is intended to hold dishes that

are more difficult to clean, as well as the cutlery

basket.

Thelowerbasketholdsregular plates,soup bowls,

pans, soup tureens, lids, and serving dishes.Flat

and deep plates must be placed in a way that

leaves some space between the individual plates.

All plates must be in a vertical position so that the

water can pass freely.

Pansand potsmustalwaysbe placedupsidedown.

You can choose any kind of loading configuration,

but you should make sure that the dirtiest surface

of dishes, pots and pants faces the water spray

andthat the water canflowoffwithout hindrances.

Cutlery

For best cleaning results, cutlery should be inserted with its handles facing down.Spoons, forks, and

knifes must be placed in the specific areas of the cutlery basket that are designed for them.

How to load and unload the dishwasher

ATTENTION:

Particularly long cutlery, specifically “long knives”, should not be positioned pointing upwards but

should be placed horizontally in the top tray or washed by hand.

1234567890

23456789

1234567890

LA2505-120

LA2505-130

LA2505-134 LA2505-132

Use of the upper basket

The upper basket can be pulled out all the way.

It holds small and medium sized dishes such

as glasses, small plates, tea and coffee cups,

smallsalad bowls,and smallpans andpots that

arenot very dirty.Desert platesmustalwaysbe

placed vertically; glasses, cups, pots and pants

must be placed upside down. Light dishes

should be held by a support structure so that

they don’t get thrown around by the water jet.

An optimal arrangement of dishes inside the

dishwasherwillguaranteebestwashingresults,

allowing the appliance will be able to develop

its full effectiveness.

Height regulation of the upper basket

Use the handle on the side (only on left) to regulate the

basket’s height and inclination.

1 regulation of horizontal position

2 regulation of inclination

Because of the elevated temperature of the water used to wash the dishes and

of potential chemical reactions with the detergent, it is recommended not to

wash copper or aluminium dishes, cutlery with wood or horn handles, delicate

porcelains, or non heat resistant glass or plastic dishes in the appliance.

If you possess decorated porcelain, you should test one single piece to make

sure that the décor is not being damaged or altered.

12345678901

Pulling out the upper basket

The upper basket can be pulled out and removed

as shown in the figure.

Description of control buttons and

indication lights

(Model illustrated in fig. 18)

1) Indication programme LED

It is illuminated when the appliance is turned on.

2) On-Off buttons

On/Off – Press this button to turn on the appliance.

3) Programme selection button

4) Start-Stop/Pause programme button

5) Door handle

To open pull forward (an electric safety mechanism turns off the machine when the

door is being opened).

LA2505-160

-ON/OFF

213 4

Start

After checking the quantities of regeneration salt (only in the salt container version) and of rinse aid,

open the water faucet completely, place the dishes in the baskets, fill detergent into the detergent

container and add also detergent for the pre-wash (if necessary); then close the front door.

Now proceed as follows:

• Press the “ON-OFF”button ,“The LED corresponding to the last wash cycle performed lights up”.

Wash cycle selection

• When you press the button for the first time, you confirm the wash cycle that corresponds to the

flashing LED .The next times you press the button, the LED of the programme that corresponds to

the wash cycle you intend to select will light up. At the end of the cycle, the selected programme flashes.

Select the programme which you believe is best suited to the types of dishes which need to be washed.

Start Button

Press button with the appliance door shut, the dishwasher wash cycle will start and the LED of

the button itself lights up.

Incorrect setting of the programmes (programme change)

•To modify a wash cycle in progress, you must press the Start button for approximately6 seconds;

subsequently, the LED of the selected programme begins to flash.The RESET phase will end when

the Start button LED goes off. At this point, the appliance is ready to be set again.

• If you forget to put a dish in, you can interrupt the wash cycle (preferably only if it hasn’t been running

for long) by pressing the Start button which then flashes;open the appliance door and place the

dish inside. To restart the appliance, close the door and press the Start button again; the cycle will

resume from the point in which it was interrupted.

• To repeat the same cycle, press the programme button and then the Start button .

1234567890

23456789

1234567890

Table of wash programmes

Wah cycles

Cycle number

Rinse

Rapid

Delicate 40º C

Normal 55º C

(EN 50242)

Intensive 65º C

OFF

pre-wash

wash

Dishes

and

degree of dirt

Pans and dishes until

the next wash cycle

Little dirty dishes

Very dirty delicate dishes

Normally dirty dishes

Very dirty dishes (except

delicate pieces)

Short cold wash to prevent food residue from

drying up and forming crusts on the dishes

Main wash

2 rinses (1 cold – 1 warm)

Main wash

2 rinses (1 cold – 1 warm)

1 cold pre-wash – Main wash

2 rinses (1 cold – 1 warm)

1 warm Pre-wash – Main wash

3 rinses (2 cold – 1 warm)

Cycle

description

BUTTONS

DETERGENT

Description of controls and indicator lights (Model illustrated in fig. 18a)

1) Cycle indicator LED

It is illuminated when the appliance is turned on.

-ON/OFF

213

2) On-Off button

3) Cycle select button

Start

After checking the quantities of regeneration salt (only in the version fitted with a salt container) and

rinse aid, turn on the water tap completely, place the dishes in the racks, pour the detergent into the

detergent dispenser as well as any detergent for the pre-wash (if necessary).

Proceed as follows:

•

Press the“ON-OFF”button , wait until the LED corresponding to the last wash cycle performed

lights up.

Wash cycle selction

When you press the button for the first time, you confirm the wash cycle that corresponds to the

flashing LED .The next times you press the button, the LED of the programme that corresponds to

the wash cycle you intend to select will light up. Close the front door to start the wash.

At the end of the cycle, the selected programme flashes.

Select the programme which you believe is best suited to the types of dishes which need to be

washed.

Incorrect setting of the programmes (programme change)

•

To modify a wash cycle in progress you must open the appliance door, press the Cycle Select button

for approximately 6 seconds; subsequently, the LED of the selected programme begins to flash.

At this point, close the door; the Reset phase, which lasts approximately 1 minute, will end when the

flashing of the LED has slowed down;the appliance is now ready to be set again.

•

If you forget to put a dish in, you can interrupt the wash cycle (preferably only if it hasn’t been running

for long) by opening the front door and placing the dish inside.

To restart the appliance, close the door; the cycle will resume from the point in which it was

interrupted.

•

To repeat the same cycle, press the cycle selection button ; the LED changes from flashing to

being constantly on.At this point, all you need to do is close the front door to start the wash cycle.

Do not open the appliance after a programme has been initiated.

Stop

After the wash cycle the dishwasher will stop automatically and will emit a sound signal of 3 beeps (only

for the intermediate version), and the LED for the selected programme will flash.To turn it off, press

the button on/off.After each wash cycle, the water faucet must be closed to insulate the appliance from

the water supply system.

12345678901

7.2 CLEANING OF FILTERS

After each wash the filter group should be checked in order to remove possible dirt residues.Proceed

as follows:

• take out the central filter 1

• remove the external water filter 2

• take out mobile grid 3.

Clean all these components under running water.It is important to clean all filters thoroughly because

the dishwasher cannot function properly with obstructed filters.

We recommend to put the cleaned filters back in their positions immediately to avoid damage to the

wash pump.

LA2505-180

LA2505-190

LA2505-200

7.3 CLEANING OF THE WATER ENTRY FILTER

You should also clean filter Bperiodically. It is located

between the water faucet and the water entry tube.

• Close water faucet A.

• Unscrew attachment pieceC, take out filter B, and clean

it thoroughly under running water.

• Put the filter back in its place and screw the water entry

hose on.Check that there are no water leaks.

LA2505-040

MAINTENANCE

7.1 CLEANING OF SPAY-ROTORS

The spray-rotors can easily be removed for the periodic cleaning of the jets in order to prevent possible

obstructions.

Wash them thoroughly under running water and put them back in their correct position.

LA2505-210

LA2505-220

19 20

To remove the upper spray-rotor:

Unscrewanticlockwisethesupport of thespray-rotor.

To remove the lower spray-rotor:

Pull the spray-rotor upwards and take it out.

1234567890

23456789

1234567890

7.5 TABLE OF ERROR CODES - “basic version”

Action to be taken

- Reset the dishwasher

- Check

- Reset the dishwasher

- Call the authorised assistance centre

- Reset the dishwasher

-Verify the water pressure

- If the same problem reoccurs, contact the authorised

technical assistance centre immediately communica-

ting to them the type of error that is shown.

- Check

- Call the authorised assistance centre

- Clean the filter grills

- Check at the end of the cycle, position the pots

correctly during the next wash

Checks to carry out

-Tap closed

- Filter of loading tube blocked

- Drainage tube flat

- Drainage tube broken

-Water supply tube bent

- Insufficient water pressure

Repeat the washing cycle

-The drainage tube is bent

-The siphon is blocked

-The drainage pump is blocked

-The filter grills are blocked

- A pot is placed up side down

When this occurs

During the water cycle

(the program stops)

At the end

of the cycle

At the end

of the cycle

At the end

of the cycle

Error

LED 1

LED 2

LED 5

LED 4

N.B.: Upon contacting the authorised technical assistance centre always communicate the type of error encountered.

N.B.: Anomalies are signalled in the following way:

All the LEDs remain on, while the LED corresponding to the type of error flashes.

7.4 CLEANING OF THE DISHWASHER’S EXTERNAL SURFACES

The dishwasher’s surfaces (made of metal, and in the front of plastic) must be cleaned periodically.

Use a clean and soft piece of fabric. Never use acids or abrasive detergents.

If you don’t use the appliance for long periods of time

If the dishwasher is not being used for extended periods of time, you should proceed as follows:

• run the pre-wash programme twice

• remove the electric plug from the outlet

• disconnect the water supply tube

• leave the door slightly open to avoid the formation of bad odours.

7.5 TABLE OF ERROR CODES - “intermediate version”

Action to be taken

- Reset the dishwasher

- Check

- Reset the dishwasher

- Call the authorised assistance centre

- Reset the dishwasher

-Verify the water pressure

- If the same problem reoccurs, contact the authorised

technical assistance centre immediately communica-

ting to them the type of error that is shown.

- Check

- Call the authorised assistance centre

- Clean the filter grills

- Check at the end of the cycle, position the pots

correctly during the next wash

- Clean the filter grills

- Check at the end of the cycle, position the pots

correctly during the next wash

- If the same problem reoccurs, contact the authorised

technical assistance centre immediately communica-

ting to them the type of error that is shown.

Checks to carry out

-Tap closed

- Filter of loading tube blocked

- Drainage tube flat

- Drainage tube broken

-Water supply tube bent

- Insufficient water pressure

Repeat the washing cycle

-The drainage tube is bent

-The siphon is blocked

-The drainage pump is blocked

-The filter grills are blocked

- A pot is placed up side down

-The filter grills are blocked

- A pot is placed up side down

Repeat the washing cycle

When this occurs

During the water cycle

(the program stops)

At the end

of the cycle

At the end

of the cycle

At the end

of the cycle

At the end

of the cycle

At the end

of the cycle

Error

LED 1

LED 2

LED 5

LED 4

LED 1-2

N.B.: Upon contacting the authorised technical assistance centre always communicate the type of error encountered.

N.B.: Anomalies are signalled in the following way:

A) All the LEDs remain on, while the LED corresponding to the type of error flashes.

B) A continuous beep sounds until the programme with the error is reset.

12345678901

WHAT TO DO IN CASE OF MALFUNCTIONS

You should first check whether it is possible to rectify some minor problems yourself. Follow these

instructions. If you are unable to identify or remove the problem, you should contact the technical

client assistance service.

• The programme does not start

- Are the internal fuses broken? Is the dishwasher connected to the electric supply system?

- Is the door closed properly? Press on the door to close it completely.

• No water enters the appliance

- Is the water faucet open?

- Is the filter between the faucet and the water supply tube obstructed? If so, clean the filter.

- Is the water supply tube obstructed? Check the tube.

• The programme indicator does not move on from its starting position

- Is the water faucet completely open?

- Is the filter between the faucet and the water supply tube obstructed? If so, clean the filter.

- Is the water pressure lower than 0.05 Mpa?

• The used water is not removed from the dishwasher

- Is the waste disposal tube obstructed? Check the tube.

- The siphon is obstructed? Check the siphon.

• The dishes are not clean after washing them

- Did you choose an appropriate programme for the type of dishes and the degree of dirt you are

dealing with?

- Are the dishes arranged in a way that allows the water-jet to reach all their surfaces?

- Are the dishwasher’s baskets overloaded?

- Are the spray-rotors blocked by a dish or some cutlery?

- Are all filters at the bottom of the dishwasher clean? Are they all in their correct position?

- Did you add the correct amount of detergent?

- Is the water discharge tube connected properly?

- Is there still any special dishwasher salt in the appropriate container? (if present) Without salt the

water is not being softened.

- Was the water softening system (if present) adjusted according to the local amount of calcium in

the water?

• The dishes do not dry or they remain opaque

- Is there any rinse aid left in the appropriate container?

• Glasses and dishes show the formation of lines,spots,and stains or a shiny blue coloration

- During the rinse process too much rinse aid is being released.Adjust the rinse aid release.

• Glasses and dishes show stains of dried water

- During the rinse process too little rinse aid is being released.Adjust the rinse aid release.

Please note:

The appliance was tested and checked by the manufacturer. As a consequence,you may find

some traces of water inside.These will disappear after the first use.

1234567890

23456789

1234567890

VOR DER BENUTZUNG DES GERÄTS

Vorschriftsmäßige Benutzung

• Der Geschirrspüler darf nur zur Reinigung von Haushaltsgeschirr verwendet werden. Sollte das

Gerät für andere Zwecke oder unzweckmäßig gehandhabt werden, so kann die Herstellerfirma

keinerleiVerantwortung für eventuelle Schäden übernehmen.

• Aus Sicherheitsgründen ist es nicht erlaubt, am Geschirrspüler Umbauten oder Änderungen vorzu-

nehmen.

• Bevor das Gerät an das elektrische Stromnetz angeschlossen wird, prüfen, ob die auf dem Daten-

schild angegebenen Spannungs- und Stromdaten mit denWerten, die am Aufstellort gegeben sind,

übereinstimmen.

• Die Installation hat durch qualifiziertes Personal zu erfolgen.

Handhabungen vor dem ersten Starten

• Prüfen Sie , ob der Geschirrspüler beimTransport Schäden erlitten hat. Keinesfalls ein beschädig-

tes Gerät anschließen.Wenden Sie sich bei Schäden an IhrenVertragshändler.

Zur Sicherheit Ihrer Kinder

• Erlauben Sie Kindern nicht, mit dem Gerät zu spielen.

• Die Reinigungsmittel können unwiderrufliche Schäden an Augen, am Mund und im Hals verursa-

chen.

Reinigungsmittel deshalb außerhalb der Reichweite von Kindern aufbewahren.

• Das Wasser im Geschirrspüler ist kein Trinkwasser. Sollten sich im Gerät noch Reste des Reini-

gungsmittels befinden, besteht für Kinder weiterhin eine Gefahrensituation. Kinder müssen vom

geöffneten Geschirrspüler ferngehalten werden.

Zum täglichen Gebrauch

• SetzenSiedenGeschirrspüler niemalsinFunktion, wenndasStromkabel, derWasserzulaufschlauch

oder der Wasserabflussschlauch beschädigt sind, oder wenn die Schalterblende, die Arbeitsplatte

oder die Leiste in einem schlechten Zustand sind.

• Bei Störungen zuerst denWasserhahn abdrehen, dann das Gerät ausschalten und den Stecker aus

der Steckdose ziehen. Bei Festinstallation, den jeweiligen Schalter ausstellen oder die Sicherung

(oder die Sicherungen) herausdrehen.

• Den Stromstecker stets am Kopf und niemals am Kabel aus der Dose herausziehen.

• Die Reparaturen des Geschirrspülers dürfen nur durch geschultes Personal durchgeführt werden.

Unsachgemäße Reparaturen können den Benutzer in große Gefahr bringen. Wenn Sie sich des-

halb für eventuelle Reparaturen an unseren Kundendienst oder an Ihren eigenenVertragshändler.

• Das Austauschen des Speisekabel muß nur vom spezialisiertem Personal ausgeführt werden.

• Im Falle, dass die Schläuche in einem schlechten Zustand sind, müssen sie, um das Gerät anzu-

schließen, mit Originalschläuchen ersetzt werden.

• Geben Sie keine Lösungsmittel in den Geschirrspüler. Sie können Explosionen auslösen.

• Setzen oder lehnen Sie sich nicht auf die geöffneteTür: das Gerät könnte umkippen.

• Bevor Sie Spezialsalz, Reinigungsmittel oder Klarspüler einfüllen, müssen Sie sich vergewissern,

dass ihr Gebrauch vom Hersteller dieser Mittel für die Verwendung in Haushaltsgeschirrspülern

Popular Dishwasher manuals by other brands

Fisher & Paykel

Fisher & Paykel DISHDRAWER DD24DTI9 Preference Options

LG LDPH7972S.ASSESNA owner's manual

Sharp

Sharp QW-S24F443W-DE user manual

Baumatic

Baumatic BDI652 instruction manual

AEG Electrolux

AEG Electrolux FAVORIT 88015 VI user manual

Kleenmaid

Kleenmaid DW27I Instructions for use

Hotpoint

Hotpoint LFF 816 operating instructions

montpellier

montpellier MDI450-2 user manual

Amana

Amana W10435039A installation instructions

Concept2

Concept2 MNV3060 manual

Moyerdiebel

Moyerdiebel DFM7.5 Installation, Operation and Service Parts Manual

ECOSTAR

ECOSTAR 430f Translation of the original operating manual

Magic Chef

Magic Chef CDB4000 Use & care guide

Haier

Haier ESD200 user manual

Moyerdiebel

Moyerdiebel MD18 Technical manual

Scandomestic

Scandomestic SFO 3502 W user manual

Siemens

Siemens SN67ZX05CE user manual

AEG

AEG ESF97400ROX user manual

Saivod LV6 ELECTRON Manual

Popular Dishwasher manuals by other brands
