Saivod STE84C User manual

Dryer
User Manual
Secador
Manual do utilizador
Secadora
Manual del usuario
STE84C

2 / 80 EN Dryer / User Manual
2960310904_EN/260514.1753
Please read this user manual first!
Dear Customer,
Thank you for prefering this product. We hope that your product which has been manufactured with high quality and
technology will give you the best results. We advise you to read through this manual and the other accompanying
documentation carefully before using your product and keep it for future reference. If you transfer the product to
someone else, give its manual as well. Pay attention to all details and warnings specified in the user manual and follow
the instructions given therein.
Use this user manual for the model indicated on the cover page.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about
usage.
AWarning for hazardous situations with regard to
life and property.
BWarning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard them to the dedicated
collection points designated by the local authorities.

3 / 80 EN
Dryer / User Manual
1 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of
personal injury or property damage. Failure to follow these instructions shall
void any warranty.
1.1 General safety
•The dryer can be used by children at and above 8 years old and by
persons whose physical, sensory or mental capabilities were not fully
developed or who lack experience and knowledge provided that they
are supervised or trained on the safe usage of the product and the risks
it brings out. Children should not play with the product. Cleaning and
maintenance works should not be performed by children unless they are
supervised by someone.
•Adjustable feet should not be removed.The gap between the dryer and
the floor should not be reduced with materials such as carpet, wood and
tape. This will cause problems with the dryer.
•Always have the installation and repairing procedures carried out by the
Authorized Service. Manufacturer shall not be held liable for damages
that may arise from procedures carried out by unauthorized persons.
•Never wash the dryer by spraying or pouring water onto it! There is the
risk of electric shock!

4 / 80 EN Dryer / User Manual
Important instructions for safety and environment
1.1.1 Electrical safety
AElectrical safety instructions should be followed while electrical
connection is made during the installation.
•Connect the dryer to a grounded outlet protected by a fuse at the value
specified on the type label. Have the grounding installation performed by
a qualified electrician. Our company shall not be liable for any damages
that will arise when the dryer is used without grounding in accordance
with the local regulations.
•The voltage and allowed fuse protection is stated on the type label plate.
•The voltage specified on the type label must be equal to your mains
voltage.
•Unplug the dryer when it is not in use.
•Unplug the dryer from the mains during installation, maintenance,
cleaning and repair works.
•Do not touch the plug with wet hands! Never unplug by pulling on the
cable, always pull out by grabbing the plug.
•Do not use extension cords, multi-plugs or adaptors to connect the dryer
to power supply in order to decrease the risk of fire and electric shock.
•Power cable plug must be easily accessible after installation.
BDamaged mains cable should be changed notifying the Authorized
Service.
BIf the dryer is faulty, it must not be operated unless it is repaired
by an authorized service agent! There is the risk of electric shock!

5 / 80 EN
Dryer / User Manual
Important instructions for safety and environment
1.1.2 Product safety
Points to be taken into consideration for fire hazard:
Below specified laundry or items must not be dried
in the dryer considering fire hazard.
•Unwashed laundry items
•Items soiled with oil, acetone, alcohol, fuel oil, kerosene, stain
removers, turpentine, paraffin or paraffin removers must be
washed in hot water with plenty of detergent before being dried
in the dryer.
For this reason especially the items containing the above
specified
stains must be washed very well, to do this
use adequate detergent and choose a high washing
temperature.
Below specified laundry or items must not be dried in the
dryer due to the fire hazard:
•Garments or pillows bolstered with rubber foam (latex foam),
shower bonnets, water resistant textiles, materials with rubber
reinforcement and rubber foam pads.
•Clothing cleaned with industrial chemicals.
Items such as lighter, match, coins, metal parts, needle etc.
may damage the drum set or may lead to functional problems.
Therefore check all the laundry that you will load into your dryer.
Never stop your dryer before
the programme completes. If you must do this, remove all
laundry
quickly and lay them out to dissipate the heat.
Clothes that are washed inadequately may ignite on their own
and even may ignite after drying ends.

6 / 80 EN Dryer / User Manual
Important instructions for safety and environment
•You must provide enough ventilation in order to prevent gases exiting
from devices operating with other types of fuels including the naked flame
from accumulating in the room due to the back fire effect.
AUnderwear that contains metal reinforcements should not be
dried
in the dryer. Dryer may be damaged if metal reinforcements come
loose and break off during drying.
CUse softeners and similar products in accordance with the
instructions of their manufacturers.
CAlways clean the lint filter before or after each loading. Never
operate the dryer without the lint filter installed.
•Never attempt to repair the dryer by yourself. Do not perform any repair
or replacement procedures on the product even if you know or have the
ability to perform the required procedure unless it is clearly suggested in
the operating instructions or the published service manual. Otherwise,
you will be putting your life and others’ lives in danger.
•There must not be a lockable, sliding or hinged door that may block
the opening of the loading door in the place where your dryer is to be
installed.
•Install your dryer at places suitable for home use. (Bathroom, closed
balcony, garage etc.)
•Make sure that pets do not enter the dryer. Check the inside of the dryer
before operating it.
•Do not lean on the loading door of your dryer when it is open, otherwise it
may fall over.
•The lint must not be allowed to accumulate around the tumble dryer
1.2 Mounting over a washing machine
•A fixing device should be used between the two machines when installing
the dryer above a washing machine. The fitting device must be installed
by the authorized service agent.

7 / 80 EN
Dryer / User Manual
Important instructions for safety and environment
•Total weight of the washing machine and the dryer -with full load- when
they are placed on top of each other reaches to approx. 180 kilograms.
Place the products on a solid floor that has sufficient load carrying
capacity!
AWashing machine cannot be placed on the dryer. Pay attention
to the above warnings during the installation on your washing
machine.
Installation Table for Washing Machine and Dryer
Dryer Depth Washing Machine Depth
62cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm Can be
installed Can be installed Can be installed Can be installed Can be installed Can be installed Cannot be installed
60 cm Can be
installed Can be
installed Can be installed Can be installed Can be installed Cannot be installed Cannot be installed
1.3 Intended use
•Dryer has been designed for domestic use. It is not suitable for
commercial use and it must not be used out of its intended use.
•Use the dryer only for drying laundry that are marked accordingly.
•The manufacturer waives any responsibility arisen from incorrect usage
or transportation.
•The service life of the dryer that you purchased is 10 years. During this
period, original spare parts will be available to operate the dryer properly.

8 / 80 EN Dryer / User Manual
Important instructions for safety and environment
1.4 Child safety
•Packaging materials are dangerous for the children. Keep packaging
materials away from children.
•Electrical products are dangerous for the children. Keep children away
from the product when it is operating. Do not let them tamper with the
dryer. Use the child-proof lock in order to prevent the children to tamper
with the dryer.
CChild-proof lock is on the control panel. (See 5.16 Child lock)
•Keep loading door closed even when the dryer is not in use.
1.5 Compliance with the WEEE regulation
and disposing of the waste product
This product does not contain the harmful and prohibited
substances which are specified in the “Control of the Waste
Electrical and Electronic Equipment” as published by Republic of
Turkey Ministry of Environment and Urbanization. It complies with
the WEEE Directive.
This product was made of high quality items and materials which
are recyclable and reusable. Therefore, do not dispose of the product at
the end of its service life with the domestic and other wastes. Take it to
a collection point for the recycling of electrical and electronic equipment.
Please consult your local authorities to learn the nearest collection point.
Help protect the environment and natural resources by recycling used
products. For children’s safety, cut the power cable and break the locking
mechanism of the door, if any, so that it will be non-functional before
disposing of the product.
1.6 Package information
Packaging materials of the product are manufactured from recyclable
materials in accordance with our National Environment Regulations. Do
not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated
by the local authorities.

9 / 80 EN
Dryer / User Manual
Important instructions for safety and environment
1.7 Technical Specifications
EN
Height (min. / max.) 84,6 cm / 86,6 cm*
Width 59,5 cm
Depth 59,8 cm
Capacity (max.) 8 kg**
Net weight (plastic front door usage) 38 kg
Net weight (glass front door usage) 40 kg
Voltage
See type label***Rated power input
Model code
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
CTechnical specifications of the dryer are subject to specification
without notice to improve the quality of the product.
CFigures in this manual are schematic and may not match the
product exactly.
CValues stated on markers on the dryer or in the other published
documentation accompanying with the dryer are obtained in
laboratory in accordance with the relevant standards. Depending
on operational and environmental conditions of the dryer, these
values may vary.

10 / 80 EN Dryer / User Manual
2 Your Dryer
2.1 Package Contents
12 3 5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.

11 / 80 EN
Dryer / User Manual
3 Installation
Before the calling the nearest Authorized Service for the
installation of the dryer, ensure that electrical installation
and water drain is appropriate referring to the user's
manual.(See 3.4 Connecting to the drain and 3.6
Electrical connection) If they are not suitable, contact
a qualified electrician and technician to make necessary
arrangements.
CPreparation of the dryer's location as well as
the electrical and waste water installations is
under customer's responsibility.
APrior to installation, visually check if the dryer
has any defects on it. If the drier is damaged,
do not have it installed. Damaged products
cause risks for your safety.
3.1 Appropriate installation location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated, dust-free
environment.
• The gap between the dryer and the surface should
not be reduced by the materials such as carpet,
wood and tape.
• Do not cover the ventilation grills of the dryer.
• There must not be a lockable, sliding or hinged
door that may block the opening of the loading
door in the place where your dryer is to be
installed.
• Once the dryer is installed, it should stay at the
same place where its connections have been
made. When installing the dryer, make sure that
its rear wall does not touch anywhere (tap, socket,
etc.).
• Place the dryer at least 1 cm away from the edges
of other furniture.
• Your dryer can be operated at temperatures
between +5°C and +35°C. If the operating
conditions fall outside of this range, operation of
the dryer will be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer shall be
placed against a wall.
BDo not place the dryer on the power
cable.
3.2 Removing the transportation
safety assembly
ARemove the transportation safety assembly
before using the dryer for the first time.
• Open the loading door.
• There is a nylon bag inside the drum that contains
a piece of styrofoam. Hold it from its section
marked with XX XX.
• Pull the nylon towards yourself and remove the
transportation safety assembly.
ACheck that no part of the transportation safety
assembly remains inside the drum.
3.3 Under counter installation
• This product can be installed under a counter if the
height of the counter is sufficient.
ACAUTION: While using the under counter
dryer, never operate the dryer without under
counter installation part.
Dryer Depth 60 cm 54 cm
Stock number of under-
bench installation part 2979700200 2973600200
• Leave at least 3 cm of space around the sides and
the rear wall of the product when installing it under
a counter or in a cupboard.

12 / 80 EN Dryer / User Manual
Installation
3.4 Connecting to the drain
In products equipped with condenser unit, water
accumulates in the water tank during the drying cycle.
You should drain accumulated water after each drying
cycle.
You can directly drain accumulated water through the
water drain hose supplied with the product instead of
periodically draining the water collected in the water
tank.
Connecting the water drain hose
1-2 Pull hose at the behind of the dryer by hand in
order to disconnect it from where it is connected.
Do not use any tools to remove the hose.
3Connect one end of the drain hose supplied with
the dryer to the connection point from where you
removed the hose of the product in previous step.
4Connect the other end of the drain hose directly to
the wastewater drain or to the washbasin.
1
3 4
2
AHose connection should be made in a safe
manner. Your drain house will be flooded if the
hose comes out of its housing during water
discharge.
CWater drain hose should be attached to a
height of maximum 80 cm.
CMake sure that the water drain hose is not
stepped on and it is not folded between the
drain and the machine.
3.5 Adjusting the feet
• In order to ensure that the dryer operates more
silently and vibration-free, it must stand level and
balanced on its feet. Balance the machine by
adjusting the feet.
• Turn the feet to left or right until the dryer stands
level and firmly.
CNever unscrew the adjustable feet from their
housings.
3.6 Electrical connection
For specific instructions for electrical connection
required during installation (see 1.1.1 Electrical
Safety)
3.7 Transportation of the dryer
Unplug the dryer before transporting it.
Drain all water that has remained in the dryer.
If direct water drain connection is made, then remove
the hose connections.
A
We recommend carrying the dryer in
upright position. If it is not possible to carry
the machine in the upright position, we
recommend carrying it by tilting towards the
right side when looked from the front.

13 / 80 EN
Dryer / User Manual
4 Preparation
4.1 Laundry suitable for drying in the dryer
Always obey the instructions given on the garment tags. Dry only the laundry having a label stating that they are
suitable for drying in a dryer and make sure that you select the appropriate programme.
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
Dry or Steam Iron at high
temperature
Iron at medium
temperature Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature 200 0C150 0C110 0C
LAUNDRY DRYING SYMBOLS
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
4.2 Laundry not suitable for drying in
the dryer
CDelicate embroidered fabrics, woolen, silk
garments, delicate and valuable fabrics,
airtight items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other after
washing. Separate the laundry items before
placing them into the dryer.
• Dry garments having metal accessories such as
zippers, inside out.
• Fasten the zippers, hooks and buckles and button
sheets.
4.4 Things to be done for energy
saving
Following information will help you use the dryer in an
ecological and energy-efficient manner.
• Spin your laundry at the highest speed possible
when washing them. Thus, the drying time
is shortened and energy consumption is
reduced.(See 5.5 Programme selection and
consumption table)
• Sort out the laundry depending on their type and
thickness. Dry the same type of laundry together.
For example thin kitchen towels and table clothes
dries earlier than thick bathroom towels.
• Follow the instructions in the user manual for
programme selection.
• Do not open the loading door of the machine
during drying unless necessary. If you must
certainly open the loading door, do not to keep it
open for a long time.
• Do not add wet laundry while the dryer is in
operation
• Clean the lint filter before or after each drying
cycle. (See 6 Maintenance and cleaning)
• In models with condenser, make sure that you
clean the condenser regularly at least once every
month or after every 30 drying cycles. (See 6
Maintenance and cleaning)
• Ventilate the room, where the dryer is located, well
during drying.

14 / 80 EN Dryer / User Manual
Preparation
4.5 Correct load capacity
Follow the instructions in the “Programme selection and
consumption table”. Do not load more than the capacity
values stated in the table.
CIt is not recommended to load the dryer with
laundry exceeding the level indicated in the
figure. Drying performance will degrade when
the machine is overloaded. Furthermore, dryer
and the laundry can get damaged.
Following weights are given as examples.
Laundry Approximate weights
(g)*
Cotton quit covers (double) 1500
Cotton quit covers (single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 200
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10 pieces) 100
T-Shirts 125
*Dry laundry weight before washing.

15 / 80 EN
Dryer / User Manual
Spin speed / Timer programs*
Operation symbol
Pause symbol
Water Tank warning symbol
Filter cleaning warning symbol
Filter Drawer Cleaning warning symbol
Remaining Time indicator**
Child-proof Lock warning symbol
Time Delay mode
Loading door open warning symbol
Anti-creasing mode
Audio Warning Level / Cancel Audio Warning
Dryness Level
Anti-creasing is activated
* Spin speed is used to show the remaining time more accurately. It does not
affect the performance of your machine.
** Time that appears on display indicates the remaining time until the end of the
programme and changes according to the dampness level of the laundry.
5 Selecting a Programme and Operating Your Machine
5.1 Control panel
1. Washing machine spin speed*/ Timer programme
selection
Spin speed used to spin the laundry in the washing
macthine / Indicates the time for timer programs.
2. Display
Indicates the status of the machine.
3. Start/Pause/Cancel button
Used to start, pause or cancel the programme.
4. Programme selection knob
Used to select a programme.
5. On/Off button
Used to turn on and off the machine.
1 2 3 4 5
6789
6. Anti-creasing
Prevents the laundry from creasing after the machine
completes its programme.
7. Dryness level
Used to adjust the required dryness level.
8. Cancel audio warning
Used to cancel the audio warning given at the end of
the programme.
9. Time delaying buttons
Used to set the time delay.

16 / 80 EN Dryer / User Manual
Selecting a Programme and Operating Your Machine
5.2 Preparing the machine
1. Plug in your machine.
2. Place the laundry in the machine.
3. Press the “On/Off” button.
CPressing the “On/Off” button does not
necessarily mean that the programme has
started. Press “Start/Pause/Cancel” button of
the machine to start the programme.
5.3 Programme selection
Decide the appropriate programme from the table below
which includes drying temperatures in degrees. Select
the desired programme with the programme selection
knob.
Extra dry
Drying at high temperature
only for cotton laundry. Thick
and multi layered laundry
(E.g.: towels, linens, jeans) are
dried in a way that they do not
require ironing before placing in
the wardrobe.
Cupboard dry
Normal laundry (E.g.:
tablecloths, underwear) are
dried in a way that they do not
require ironing before placing in
the wardrobe.
Iron dry Normal laundry (E.g., Shirts, dresses) are dried ready to be
ironed.
CFor further programme details, see, “Programme
Selection Table”
Main programmes
Depending on the type of laundry, the following main
programmes are available:
•Cottons
You can dry your durable laundry with this programme.
Dries at high temperature. It is recommended to use
for your cotton items (such as bed sheets, quilt cover,
underclothing, etc.).
•Synthetics
You can dry your less durable laundry with this
programme. It dries at a lower temperature compared
to the cottons programme. It is recommended for your
synthetic laundry (such as shirts, blouses, synthetic/
cotton blended laundry, etc.).
CDo not dry curtains and lace in your machine.
Special programmes
For special cases, there are also extra programmes
available:
CAdditional programmes may differ according to
the model of your machine.
•Express 35
You can use this programme to dry your cotton laundry
that you have spun at high speeds in your washing
machine.This program dries 2 kg cotton laundry (2
Shirts / 5 T-shirts) in 35 minutes.
CTo obtain better results from your dryer,
your laundry must be washed at suitable
programmes and spun at the recommended
spin speeds in the washing machine.
•Shirt
This programme dries the shirts more sensitively and
creases them less and thus, helps to iron them more
easily.
CThere may be a little humidity on your shirts at
the end of the programme. We recommend you
not to leave the shirts in the dryer.
•Jeans
You can use this programme to dry your jeans that you
have spun at high speeds in your washing machine.
CReview the relevant section in the programme
table.
•Mixed
Used to dry synthetic and cotton laundry that do not
release colour. Used for laundry that is suitable for
drying.
•Sport
Used to dry the laundry that are made of synthetic,
cotton or mixed fabrics and have a tag indicating that
they are suitable for drying.
•Wool Refresh
You can use this function to ventilate and soften your
woolen laundry that can be washed in the washing
machine. Do not use this function to dry your laundry
completely. Take out your laundry and ventilate them
immediately after the program is over.
•Daily
This programme is used to dry cottons and synthetics
daily.
•BabyProtect
This programme is used for baby clothes that bear
machine dryable approval on its label.
•Delicates
You can dry your highly delicate laundry that are suitable
for drying or laundry which is advised to be hand-washed
at a lower temperature.

17 / 80 EN
Dryer / User Manual
Selecting a Programme and Operating Your Machine
CIt is recommended to use a cloth bag to prevent
certain delicate laundry from getting creased or
damaged. Take your laundry immediately out of
the dryer and hang them after the programme
ends in order to prevent them being creased.
•Ventilation
Only ventilation is performed for 10 Tminutes without
blowing hot air. You can air your clothes that have
been kept at closed environments for a long time
and deodourise unpleasant odours thanks to this
programme.
•Timer programs
You can select one of the 10 min., 20 min., 30 min., 40
min., 50 min., 60 min., 80 min., 100 min., 120 min.,
140 min. and 160 min. timer programmes to achieve
the desired final drying level at low temperatures.
Programme dries at the selected time regardless of the
drying temperature.
5.4 Time display
The display shows the time remaining for the
programme to complete while a programme is running.
Time is displayed in hours and minutes as “02:30”. The
exemplary display image shows the dryer when it is
running and child-proof lock is active.
CProgramme duration may differ from the
values in the consumption table subject
to the changes in the water hardness and
temperature, ambient temperature, type and
amount of laundry, auxiliary functions selected,
and changes in the supply voltage..

18 / 80 EN Dryer / User Manual
5.5 Programme selection and consumption table
* : Energy Label standard programme (EN 61121:2012)
All values given in the table have been fixed according to EN 61121:2012 Standard. These values may
deviate from the table according to the laundry type, laundry spin speed, environmental conditions and voltage
fluctuations.
“Cotton cupboard dry programme” used at full and partial load is the standard drying programme to which the
information in the label and the fiche relates, that this programme is suitable for drying normal wet cotton laundry
and that it is the most efficient programme in terms of energy consumption for cotton..
EN
Programs Capacity (kg) Spin speed in washing machine
(rpm)
Approximate
amount of remaining
humidity
Drying time
(minutes)
Cottons / Coloreds
AExtra dry 8 1000 % 60 138
ACupboard dry 8 1000 % 60 130
AIron dry 8 1000 % 60 105
Express 35’ 2 1200 % 50 35
Shirt 1.5 1200 % 50 40
Jeans 4 1200 % 50 80
Mixed 4 1000 % 60 83
Sport 4 1000 % 60 92
Wool Refresh 1.5 600 % 50 6
Daily 4 1200 % 50 59
Baby Protect 3 1000 % 60 65
Synthetics
BCupboard dry 4 800 % 40 53
Delicates
BCupboard dry 2 600 % 40 40
Energy consumption values
Programs Capacity (kg) Spin speed in washing machine
(rpm)
Approximate
amount of remaining
humidity
Energy
consumption value
kWh
Cottons linen Ready to wear* 8 1000 % 60 4,71
Cottons Ready to iron 8 1000 % 60 3,8
Synthetics Ready to wear 4 800 % 40 1,8
Power consumption of the off-mode for the standart cotton programme at full load, PO (W) 0,3
Power consumption of the left-on mode for the standart cotton programme at full load, PL (W) 1,0

19 / 80 EN
Dryer / User Manual
Selecting a Programme and Operating Your Machine
5.6 Auxiliary function
Audio Warning
Cancel
audio warning
Audio warning
level 1
Audio warning
level 2
Audio warning
level 3
Your dryer will give an audio warning when the
programme comes to an end. If you do not want to
hear this buzzing or want to change the volume level,
you need to press the “Volume level” button. No audio
warning will be given when “x” appears on the screen.
CYou can select this function either before or
after the programme starts.
5.7 Drying degree
Used to adjust the required dryness level. More drying
is performed compared to the default settings when “+”
sign appears and less drying is performed when “-” sign
appears. Programme duration can change depending on
the selection.
AThis function must be selected before the
programme starts.
5.8 Anti-creasing
A 2-hour anti creasing programme to prevent laundry
from creasing will be activated if you do not take
the laundry out after the programme is over. This
programme rotates the laundry in 600-second intervals
to prevent creasing. Press “Anti-creasing” button to
activate.
Anti-creasing is activated but the programme is running
in the first exemplary figure. Drying is over and the first
step of anti-creasing has started in the second figure.
5.9 Changing the contrast
Contrast can be adjusted in order to make the symbols
on the display appear clearer. It may particularly be
necessary to change the contrast setting of the display
when the dryer is installed over a washing machine.
press and
Press and hold the Spin Speed/Time button for 3
seconds.
When the contrast is changed at the end of 3 seconds,
all symbols on the display will become visible for
3 seconds in order to indicate that the process is
complete.
Perform the same procedure to revert back to the
previous contrast setting.
5.10 Warning indicators
CWarning indicators may differ according to the
model of your machine.
Filter cleaning
A warning symbol will appear to remind filter cleaning
after the programme finishes.
CIf the filter cleaning symbol flashes continuously,
please refer to “Suggested solutions for
problems”.
Water tank
A warning symbol will turn on at the end of the
programme or when the tank is full with water. The
machine stops operating if the warning symbol turns on
when a programme is running. To restart the machine,
please drain the water in the water tank. Press “Start/
Pause/Cancel” button to start the programme after you
have emptied the water tank. The warning symbol turns
off and the programme resumes operating.

20 / 80 EN Dryer / User Manual
Selecting a Programme and Operating Your Machine
Cleaning the condenser
Warning symbol turns on with certain intervals to remind
that the condenser needs cleaning.
Door open
Dryer door open symbol lights up.
5.11 Time delay
With the “Time delay” function you can delay the
programme start up to 24 hours.
1. Open the loading door and put the laundry in.
2. Set the drying programme and spin speed, and if
required, select the auxiliary functions.
3. Press “Time delaying” buttons “+” and “-” to set the
desired time delay. The time delay symbol will flash.
4. Press “Start/Pause/Cancel” button. Then the time
delay starts to count down. The Time delay symbol
lights up. Start symbol lights up.
The “:” in the middle of the displayed time delay will
start flashing.
More laundry may be loaded or taken out during
the time delay period. At the end of the time delay
countdown process, time delay symbol fades, drying
process starts and the programme duration is displayed.
The time on the display is the total of normal drying time
and delay time.
Time delay is started by pressing the start/pause/cancel
button in the exemplary figure.
Changing the delay time
If you want to change the time during the countdown:
1. Press “Start/Pause/Cancel” button for 3 seconds to
cancel the programme. Time delay function must be
set again for the required time.
2. Press Time delay buttons “+” or “-” to set the desired
time delay.
3. Press “Start/Pause/Cancel” button. The Time delay
symbol lights up. Pause symbol fades. Start symbol
lights up.
4. The “:” in the middle of the displayed time delay will
start flashing.
Canceling the time delay
If you want to cancel the time delay countdown and start
the programme immediately:
1. Press “Start/Pause/Cancel” button for 3 seconds to
cancel the programme.
2. Then, press “Start/Pause/Cancel” button to start the
desired programme.
5.12 Starting the programme
1. Press “Start/Pause/Cancel” button to start the
programme.
2. “Start/Pause” symbol will light up to indicate that
the programme has started and “:” symbol between
the remaining time will continue flashing.
5.13 Progress of programme
Drying
Iron
Wardrobe
(Extra)
Ventilation
Anti-
creasing
The progress of a running programme is shown through
a number of symbols on the screen.
At the beginning of each programme step, the relevant
symbol in the series of symbols will light up and thus, all
symbols will remain lit up at the end of the programme.
The symbol that is lit up at the far right of the series of
symbols indicates the step that is being carried out.
“Drying”:
- Lights up in all programmes apart from drying and
ventilation.
“Iron Dry”:
- Starts to illuminate when the drying degree reaches
“iron dry” step and remains illuminated until the next
step.
“Cupboard Dry”:
Starts to illuminate when the drying degree reaches
“wardrobe dry” step, and remains illuminated until the
next step.
“Extra Dry”:
Starts to illuminate when the drying degree reach to
“wardrobe dry extra” step.
