Salto inRoomNode User manual

IRN03... series
Eng
D
Installation guide
Montageanleitung
Guide d'intallation
Guía de instalación
Guia de instalação
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any item
in this catalog, its design, construction, and/or materials.
© 2019 SALTO Systems S.L.
226007-ED.-19/09/2019
Installation Montageanleitung Installation Instalación Instalação
inRoomNode
POWER
PPD
- inRoomNode -
BLUEnet
P1927
Model: IRN0
SALTO SYSTEMS S.L.
Pol. Lanbarren, 20180
MADE IN SPAIN
Contains:
FCC ID: QOQBGM111
IC:5123A-BGM111
35
42
8
Eng
123
1/4
F
E
P
D F E P
Electrical characteristics Elektrische Eigenschaften Caractéristiques electriques Características eléctricas
Características elétricas
D
Eng
FE
P
Tx/Rx does not count with under/over voltage protections.
Temperature Indoor
Humidity
OPERATING CONDITIONS
0
÷
50ºC
0 ÷ 95% (No condensing)
Frecuency range 2400-2483.5 Mhz
Standard Bluetooth Low Energy
Indoor Radio Range 10/15m
Max output power 8dBm
SALTO BLUEnet CHARACTERISTICS
Min. -
Max. 21mA
POWER CONSUMPTION
Eng
PARAMETER Symbol Min. Typ. Max. Unit
Power supply 3.3 - 12 V
Tx Output High Voltage
Sourcing 20mA
2.6 - - V
Tx Output Low Voltage
Sinking 20mA
- - 0.7 V
Rx Input High Voltage 2.3 - 5.25 V
Rx Input Low Voltage - - 1 V
ELECTRIC CHARACTERISTICS










4
(V , V )
I L I H
(V , V )
O L O H
V
I N
Yellow / Gelb / Jaune / Amarillo / Amarelo: Rx Input inRoomNode
Green / Grün / Vert / Verde / Verde: Tx Output inRoomNode
Red / Rot / Rouge / Rojo / Vermelho:
Black / Schwarz / Noir / Negro / Preto: GND
Controller
Press
& Fix!
Connect
Controller
Controller
Follow user manual to initialize the device.
Befolgen Sie die Bedienungsanleitung, um das Gerät zu initialisieren.
Suivre le manuel utilisateur pour mettre en service l'équipement.
Seguir el manual de usuario para inicializar el dispositivo.
Siga o manual do utilizador para inicializar o dispositivo.
5

All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any item
in this catalog, its design, construction, and/or materials.
© 2019 SALTO Systems S.L.
226007-ED.-19/09/2019
PARAMETER Symbol Min. Typ. Max. Unit
Netzteil 3.3 - 12 V
Tx ausgabe
hachspannung 20mA
2.6 - - V
Tx ausgabe
niederspannung 20mA
- - 0.7 V
Rx Eingang Höchstpegel 2.3 - 5.25 V
Rx Eingang Niedrigpegel - - 1 V
ELEKTRONISCHE EIGENSCHAFTEN










Tx/Rx zählt nicht mit unter/über schultz.
Temperatur Innenbereich
Luftfeuchtigkeit
UMGEBUNGSBEDINGUNGEN
0
÷
50ºC
0 ÷ 95% (Keine kondensation)
Min. -
Max. 21mA
LEISTUNGSAUFNAHME
Frequenzbereich 2400-2483.5 Mhz
Funkstandard Bluetooth Low Energy
Reichweite Innenbereich 10/15m
Max. Ausgangleistung 8dBm
SALTO BLUEnet EIGENSCHAFTEN
D
PARAMÈTRE Symbole Min. Typ. Max. Unit
Voltage 3.3 - 12 V
Haute Voltage de Sortir
Tx 20 mA
2.6 - - V
Faible Voltage de Sortir
20 mA
- - 0.7 V
Haute Voltage d'entrée
Rx
2.3 - 5.25 V
Faible Voltage d'entrée
Rx
- - 1 V
CARACTERISTIQUES ELECTRIQUE










F
Tx/Rx ne sont pas pris en comptes pour les protections de sous/surtension.
Température intérierur
Humidité
CONDITIONS D'UTILISASTION
0
÷
50ºC
0 ÷ 95% (No condensing)
Min. -
Max. 21mA
CONSOMMATION DÉNERGIE
Gamme de fréquences 2400-2483.5 Mhz
Norme Bluetooth Low Energy
Portée Radio intérieur 10/15m
Puissance max de sortie 8dBm
SALTO BLUEnet CARACTERISTIQUES
PARÁMETRO Símbolo Min. TIp. Max. Unidad
Tensión 3.3 - 12 V
Alta tensión de
salida Tx 20mA
2.6 - - V
Baja tensión de
salida 20mA
- - 0.7 V
Alta tensión de
entrada Rx
2.3 - 5.25 V
Baja tensión de
entrada Rx
- - 1 V
CARACTERÍSTICAS ELÉCTRICAS










Tx/Rx no cuenta con protecciones para sub/sobretensiones.
Temperatura interior
Humedad
CONDICIONES AMBIENTALES
0
÷
50ºC
0 ÷ 95% (Sin condensación)
Min. -
Max. 21mA
CONSUMO ENERGÍA
Rango frecuencia 2400-2483.5 Mhz
Estándar Bluetooth Low Energy
Rango interior radio 10/15m
Potencia máxima salida 8dBm
CARACTERÍSTICAS SALTO BLUEnet
PARÂMETRO Símbolo Min. Tip. Máx. Unidade
Tensão 3.3 - 12 V
Alta Tensão de Saída
Tx 20mA
2.6 - - V
Saída Tx Baixa Tensão
Afundando 20mA
- - 0.7 V
Alta Tensão de
Entrada Rx
2.3 - 5.25 V
Baixa Tensão de Entrada
Rx
- - 1 V
CARACTERÍSTICAS ELÉTRICAS










Tx/Rx não tem em conta proteções para sub/sobretensões.
Temperatura interior
Humidade
CONDIÇÕES DE OPERAÇÃO
0
÷
50ºC
0 ÷ 95% (Sem condensação)
Min. -
Max. 21mA
CONSUMO DE ENERGIA
Intervalo frequência 2400-2483.5 Mhz
Norma Bluetooth Low Energy
Alcance interior rádio 10/15m
Potência máxima saída 8dBm
CARACTERÍSTICA SALTO BLUEnet
E
P
2/4

LED MODE LED DEVICE STATUS
Led Off
Not powered
Blinking GREEN
Powered from the controller but not
good UART link
Permanent GREEN
Powered and UART link OK
Led Off
Not inicialized with Lock-ID
Blinking GREEN
Pairing process
(Searching lock to pair with)
Permanent GREEN
Wireless connection to the lock is OK
LED MODUS LED GERÄTEZUSTAND
LED aus
Keine Stromversorgung
Blinikend GRÜN
Stromversorgung durch Steuergerät aber keine
gute UART-Verbindung
Dauerhaft GRÜN
Stromversorgung und UART-V erbindung OK
LED aus
Nich mit Türschloss-ID initialisiert
Blinikend GRÜN
Kopplungsvorgang
(Suche Türschloss un Verbindung herzustellen)
Dauerhaft GRÜN
Funkverbirdung zum Türschloss OK
ETAT DE LA LED LED STATUT DE DISPOSITIF
LED Off
Pas d'alimentation
VERT Clignotante
Alimenté par le contrôleur mais mauvaise
lien avec UART
VERT Fixe
Alimentation et UART OK
LED Off
Non initialisé avec Lock-ID
VERT Clignotante
Processus de jumelage
(
Recherche d'une serrure à jumeler)
VERT Fixe
Connexion RF à la serrure OK
POWER
LED
BLUEnet
LED
BETRIEBS
LED
BLUEnet
LED
LED
POWER
BLUEnet
LED
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any item
in this catalog, its design, construction, and/or materials.
© 2019 SALTO Systems S.L.
226007-ED.-19/09/2019
3/4
Installation example Installationsbeispiel Exemple d'installation Ejemplo de instalación Exemplo de instalação
D
Eng
FEP
POWER
PPD
- inRoomNode -
BLUEnet
P1927
POWER
PPD
- inRoomNode -
BLUEnet
P1927
Model: IRN0
SALTO SYSTEM S S.L.
Pol. Lanbarr en, 20180
MADE IN SPAIN
Contai ns:
FCC ID: QOQBGM111
IC:5123A -BGM111
15m max. 3m max.
Lock
inRoomNode
Controller
Operational test Funktionsprüfung Test opérationnel Test operacional Teste operacional
D
Eng
F E P
Once the lock and the inRoomNode are installed, check that the lock is active in SALTO's software.
Sobald das Schloss und das inRoomNode installiert sind, ob das Schloss in der SALTO Software aktiv ist.
Une fois le verrou et l'inRoomNode installés, vérifiez que le verrou est actif dans le logiciel SALTO.
Una vez instalada la cerradura y el inRoomNode, comprobar que la cerradura está activa en el software de SALTO.
Uma vez que a fechadura e o inRoomNode esão instalados, verifique se a fechadura está activa no software de SALTO.
Eng
D
Signalling Signale Signalisation Señalética Sinalização
D
Eng
F E P
POWER
PPD
- inRoomNode -
BLUEnetPOWER
PPD
- inRoomNode -
BLUEnet
P1927
Model: IRN0
SALTO SYSTEMS S.L.
Pol. Lanbarren, 20180
MADE IN SPAIN
Contains:
FCC ID: QOQBGM111
IC:5123A-BGM111
F
E
P
Wenn das Gerät von Metall umgeben oder
abgedeckt ist, kann die Funkleistung erheblich
beeinträchtigt werden.
Caso o dispositivo esteja perto de superfícies
metálicas ou ambiente metálico, o desempenho
das ondas de rádio pode ser seriamente afetado.
Dans le cas où l'équipement est entouré de surfaces
métalliques ou d'un environnement métallique, les
performances radio peuvent être sérieusement
affectées.
Eng
D
F
E
P
In case the device is surrounded by metal surfaces
or metallic environment, radio performance could
be seriously affected.
En caso de que el dispositivo esté rodeado de
superficies metálicas o entorno metálico, el
rendimiento de radio podría verse seriamente
afectado.

All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any item
in this catalog, its design, construction, and/or materials.
© 2019 SALTO Systems S.L.
226007-ED.-19/09/2019
4/4
MODO LED LED ESTADO DISPOSITIVO
Led Apagado
Sin alimentación
Parpadeo VERDE
Alimentado por el controlador,
conesión UART incorrecta
VERDE Permanente
Alimentado y conexión UART OK
Led Apagado
No inicializado con Lock-ID
Parpadeo VERDE
Proceso de emparejamiento
(Buscando cerradura para emparejar)
VERDE Permanente
Conexión Wireless con la cerradura OK
LED MODE LED DEVICE STATUS
LED Desligado
Desligado
Piscar VERDE
Ligado a partit do controlador mas com link UART
fraco ou inexistente
Permanente VERDE
Ligado e link UART OK
LED Desligado
Não inicializado com a Fechadura
Piscar VERDE
Processo de emparelhamento
(À procura de uma fechadura para se emparelhar)
Permanente VERDE
Wireless connection to the lock is OK
LED
POWER
LED
BLUEnet
LED
POWER
LED
BLUEnet
POWER
PPD
- inRoomNode -
BLUEnetPOWER
PPD
- inRoomNode -
BLUEnet
P1927
Model: IRN0
SALTO SYSTEMS S.L.
Pol. Lanbarren, 20180
MADE IN SPAIN
Contains:
FCC ID: QOQBGM111
IC:5123A-BGM111
