Salto IQ2.0 User manual

225452-ED.- -08/03/2017
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
© 2017 SALTO Systems S.L.
146
(5-3/4")
146
(5-3/4")
Eng
D
E
Installation guide
Guía de instalación
Montageanleitung
Guide d'installation
Guia de instalação
F
P
Installation Instalación Installation Installation Instalação
Eng
ED F P
1
ETHERNET + CELLULAR MODEL
a
2-a
Plug
Conectar
Verbinden
Branchez
Conectar
3-a
Plug
Conectar
Verbinden
Branchez
Conectar
4-a
Plug
Conectar
Verbinden
Branchez
Conectar
ETHERNET + WIFI MODEL
b
2-b
Plug
Conectar
Verbinden
Branchez
Conectar
Plug
Conectar
Verbinden
Branchez
Conectar
3-b
ETHERNET + CELLULAR MODEL ETHERNET + WIFI MODEL
ETHERNET + POE MODEL ETHERNET MODEL
a
c
b
d
1
2
1
2
1/2
( )Not included/ No incluido / Nicht enthalten/ Non inclus / Não incluso
*
*
*
Installation guide
IQ2.0
30
(1-316")
(x2) (x2)
PZ2

225452-ED.- -08/03/2017
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
© 2017 SALTO Systems S.L.
ETHERNET + POE MODEL
c
2-c
Plug
Conectar
Verbinden
Branchez
Conectar
3-c
Plug
Conectar
Verbinden
Branchez
Conectar
ETHERNET MODEL
d
2-d
Plug
Conectar
Verbinden
Branchez
Conectar
Plug
Conectar
Verbinden
Branchez
Conectar
4-d
Plug
Conectar
Verbinden
Branchez
Conectar
Eng
D
E
Electrical features
Características eléctricas
Electrische espezifikationen
Caracteristiques electriques
Características eléctricas
F
P
OPERATION CONDITIONS
Min
Max
Unit
Temperature
0
4
0
ºC
2.4 Ghz RF C ARACTERISTICS
Frequency Range
2
405
-
2480
Mhz
(ISM band)
RF Standard
IEEE 802.15.4
Indoor Radio Range
7m
POWER SUPPLY C ARACTERISTICS
( Only for se with KS´s power s pply )
Unit
Input Voltage
12
V
Max
Current
800
mA
OT ER C ARACTERISTICS:
WIFI
IEEE 802.11 b/g/n radio
BLE
Bluetooth 4.2 Compliant
Integrated antenna
TX power: up to +8dBm
RX sensitivity: down to -92dBm
Range: up to 200 meters
POE
The POE connection complies to IEEE 802.3af
(max 15.40W, also known as 802.3a Type 1)
To ensure a correct operation, do not install the device near a metallic surface.
Para asegurar un correcto funcionamiento, no instalar el dispositivo cerca de una superficie metálica.
Um einen einwandfreien Betrieb zu gewährleisten, installieren Sie das Gerät dann nicht in der Nähe von einer
metallischen Oberfläche.
Pour assurer un fonctionnement correct, n’installez pas l’appareil près d’une surface métallique.
Para assegurar o funcionamento adequado, não instale o aparelho perto de uma superfície de metal
3-d
2/2
Installation guide
IQ2.0
