Salton ID-1172 User manual

Induction Cooker
Instruction Booklet
Model: ID-1172
®
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 1

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical hazards, do not immerse cord, plugs, or the
appliance in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near
children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to Salton for examination, repair or adjustment. See Warranty.
7. If the appliance is not working as described in this instruction booklet
discontinue use and contact Salton Canada. See Warranty.
8. The use of accessories or attachments not recommended by Salton may
cause hazards.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter, or touch hot surfaces.
11. A fire may occur if surface is covered or touching flammable material such
as curtains, draperies, walls and the like when in operation.
12. Always disconnect appliance from outlet when not in use. To disconnect,
turn any control to ‘OFF’, then remove plug from wall outlet.
13. Do not use appliance for other than intended use.
14. Do not place on or near a hot gas or electric burner, or in a heated oven.
15. Extreme caution must be used when moving an appliance containing hot
liquids. Do not overfill Cookware used on the appliance to avoid spilling
when contents are boiling.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
2
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 2

3
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician. Do not modify the plug in any way.
DESCRIPTION OF PARTS
1. Induction Cooktop
2. Timer Buttons
3. LED Display
4. On/Off Button with Cooking
Level Adjustment (Power)
HOW TO USE
1. Place the cookware within the white circle on the Induction Cooktop.
NOTE: Ensure that the bottom of the cookware is clean as dirt may cause
the bottom to stick to the Induction Cooktop.
2. Plug into a 120 volt wall outlet. The Induction Cooker will beep once and
display ‘-‘.
3. Turn the On/Off Button clockwise to turn the unit on. To set the
temperature, turn the Cooking Level Adjustment Button clockwise. There
are 6 cooking levels between ‘Keep Warm’ and ‘High’ to choose from. Refer
to the table below.
1
4
3
2
Power Setting Temperature Wattage
-Off -
0Standby -
1Keep Warm 120
2Low 500
3Low-High 800
4Medium 1000
5Medium-High 1300
6 High 1500
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 3

4. If you wish to use the timer, press the ‘+’ or ‘-‘ Timer Button. The default
time starts at 30 minutes, however you may increase or decrease that time
by pressing the ‘+’ or ‘-‘ buttons. Press either of these buttons once to
increase/decrease the time in 1 minute increments or hold down the
button to increase/decrease in increments of 10 minutes. The timer can be
set anywhere between 1 and 99 minutes. The unit will automatically turn
off when the Timer has counted down to 0.
5. Turn the On/Off Button counterclockwise to turn the unit off.
NOTE: When the unit is turned off, the fan will continue running for
approximately one minute. The display window may also display ‘H’ until
the temperature of the Induction Cooktop is below 122°F (50°C).
IMPORTANT:
The Induction Cooker has a default running time of 2 hours. After 2 hours of
continuous use, the unit will automatically shut off. If you would like to use the
Induction Cooker longer than 2 hours, simply Restart the Induction Cooker after
it has shut off.
IMPORTANT NOTES:
1. This Induction Cooktop will only operate with compatible Cookware. The
most common types are cast iron, enameled and stainless steel. The
Induction Cooktop will not operate when using aluminum, ceramic, copper,
glass or pyrex or cookware that has a concave bottom or a diameter less
than 12cm (5”) or more than 18cm (7”).
2. If the Induction Cooker has been turned on without a compatible pot in
place the unit will beep 5 times then shut off.
3. Make sure to turn the unit off before you remove the Cookware from the
Cooktop. If the Cookware is removed from the Induction Cooktop without
first turning the knob to the ‘Off’ position, the unit will beep 5 times then
shut off.
4. The unit will show an error code of E8 if the voltage rises over 140 volts or
an error code of E7 if the voltage drops to less than 90 volts. Restart the
Induction Cooker in the desired mode.
5. This unit is equipped with a ‘Dry Pot’ protection feature. The Error code E3
will be shown in the Display Window and the unit will not heat.
4
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 4

CARE AND CLEANING
1) Unplug from the wall outlet.
2) Clean the Induction Cooktop and the Control Panel with a damp cloth.
NOTE:
• Do not use a brush or abrasive cleansers. This may damage the Cooktop.
• Do not immerse the unit in water or any other liquid.
3) Dry with a soft cloth.
4) Clean the unit after each use.
TROUBLESHOOTTING:
5
Error Codes Reason Solution
E3, E6
Overheating or dry
• Ensure that the air inlet or
the exhaust outlet are not
blocked.
• Ensure that the fan is running
• Check to see if the pot has boiled
dry. If so, turn off the cooker and
let it cool down.
E7, E8
Voltage not suitable
• The voltage has either increased
over 140V or decreased below
90V
E1, E2, E4,
E5, Eb, EC
Internal parts are either
overheating, have an open
or short circuit
• Contact the service centre. See
last page of the instruction
booklet for contact information.
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 5

RECIPES
Vegetable Medley
1 small onion, diced
1/3 cup (85 ml) canola oil
1 cup (250 ml) chicken broth
1 clove garlic, minced
1/2 cup (125 ml) parsley, chopped
2 large tomatoes, cut in chunks and seeds removed
8 new potatoes, peeled and cut in 1/2" (13mm) cubes
2 carrots, large, cut in 1/2" (13 mm) slices
1 green pepper, seeds removed, cut in 1/4" (6mm) slices
8 oz. ( 225 g) frozen peas
salt and pepper to taste
1. Add canola oil to pan and sauté onions on power 6 until onions are
softened.
2. Add garlic and parsley. Stir.
3. Add broth, vegetables, salt and pepper. Cover pan with lid. Cook until
contents boil. Reduce power to 4 and cook until vegetables are
tender, stirring occasionally.
4. Drain excess liquid and serve.
Stuffed Tomatoes
4 to 6 medium tomatoes
3/4 cup (180 ml) white rice, cooked
1/2 cup (125 ml) parsley, chopped
1/2 yellow onion, small dice
1 lb. (450 g) ground beef
2 cups (500 ml) pasta sauce
salt and pepper to taste
1. Cut tops off tomatoes and carefully scoop out the seeds and the inner
flesh. Set aside.
2. Place ground beef in skillet and brown in power 6. Add onion in the
last minute of cooking. Drain fat from pan.
3. Add rice, parsley, salt and pepper to the ground beef and onion. Stir. Set
aside to cool when cooked.
4. Fill the tomatoes with the mixture.
5. Place stuffed tomatoes in the pan and pour sauce over the tomatoes.
Cover. Cook on power 6 until the contents boil. Lower power to 4 and
cook for 5 – 8 minutes.
6. Remove to a serving platter.
6
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 6

Vegetable Rice Pilaf
2 tbsp. (30 ml) vegetable oil
1 cup (250 ml) carrots, chopped
1/2 onion, chopped
1 clove garlic, minced
1/2 tsp (2 ml) ground cumin
1/4 tsp. (1 ml) pepper, white or black
1 cup (250 ml) rice, long grain
2 cups (500 ml) chicken broth
1 cup (250 ml) frozen corn
1 cup (250 ml) broccoli florets, thinly sliced
1/4 cup (50 ml) fresh parsley, chopped
1. Place oil in pan. Follow the directions above in the ‘How To’ section and
heat oil on power level 2.
2. Increase power level to 5 and add carrots, onion, garlic, cumin and pepper.
Cook until onion is softened. Add rice and stir for 1 minute. Stir in chicken
broth until it comes to a boil.
3. Reduce power level to 2. Cover and simmer until rice is tender and liquid
is absorbed.
4. Increase power to 4. Add corn, broccoli and parsley. Stir until heated
through.
5. Turn off induction cooker, cover and let stand for 5 minutes.
7
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 7

Mushroom-Sauced Tournedos
6 - 6 oz. ( 170 g) beef tenderloin steaks
1/2 lb. (225 g) sliced mushrooms
2 tbsp. (30 ml) butter
1/3 cup ( ml) red wine
1/2 cup (125 ml) whipping cream
1. Trim any excess fat from steaks.
2. Add butter to pan and melt on power level 2.
3. Add mushrooms to butter. Fry on power level 5 until soft then remove and
keep aside.
4. Fry steaks in the same skillet. Cook to desired doneness, turning once.
Season with a little salt and pepper and transfer to a serving platter.
Keep warm.
5. Add wine to skillet and stir to loosen crust bits from the bottom of pan.
Decrease temperature to 2 and add cream. Stir. Cook until sauce is
slightly thickened. Stir mushrooms into sauce. Pour over steaks and serve.
Chicken with Peppers
2 lbs. (1 kg) boneless chicken thighs
1 onion
2 cloves garlic, minced
4 green peppers, cut in 1” (2.5 cm) strips
1 can (28oz/796 ml) diced tomatoes
1/4 cup (50 ml) fresh parsley, chopped
1-1/2 tsp. (7 ml) each salt and pepper
1 tbsp. (15 ml) olive oil
1. Sprinkle chicken with 1/2 tsp. (2 ml) salt and pepper.
2. Place 1 tbsp (15 ml) olive oil in pan on power level 2. When oil is hot,
brown chicken in batches. Transfer to a plate.
3. Drain fat from pan. Add onion, garlic and green pepper, stirring
occasionally, until softened.
4. Drain tomatoes reserving 1/4 cup (50 ml) of the juice. Add juice to pan;
cook, scraping up the brown bits from the bottom of the pan. Cook until
almost all liquid is evaporated.
5. Add tomatoes and 1 tsp (5 ml) salt and pepper to pan. Return chicken and
any accumulated juices to the pan, spooning sauce over top.
6. Change the power level to 6 until mixture comes to a boil. Reduce power
level to 2. Cover and simmer, stirring occasionally, until juices run clean
when chicken is pierced.
7. Transfer chicken and peppers to a serving plate and keep warm.
8. Increase power to 5 and cook until sauce is thickened. Pour over
chicken.
8
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 8

Beef Stew
1 lb. (500 g) stewing beef, cut into 1” (2.5 cm) cubes
2 tbsp. (30 ml) olive oil
2 carrots, peeled and sliced 1/2" (13mm)
2 stalks celery, sliced 1/2" (13mm)
1 cup (250 ml) onion, large dice
1 tbsp. (15 ml) brown sugar
2 tsp. (10 ml) all purpose flour
1 cup (250 ml) beef broth
salt and pepper to taste
1. Sprinkle beef with salt and pepper.
2. Heat oil in skillet on power level 2. When oil is hot, add beef and fry
until browned. Transfer beef to bowl.
3. Reduce power to 5 and add carrots, celery and onions to skillet. Toss.
4. Add flour. Stir.
5. Add broth and brown sugar. Stir.
6. Add beef and any accumulated juices back to the skillet. Cover and
simmer on power level 2 until beef and vegetables are tender. Stir
occasionally. Season with salt and pepper.
9
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 9

A short supply cord is provided to reduce the hazards of becoming entangled
in or tripping over a long cord. Extension cords may be used if care is
exercised in their use. If an extension cord is used, the marked electrical rating
of the detachable power-supply cord or extension cord should be at least as
great as the electrical rating of the appliance. If the appliance is of the
grounded type, the extension cord should be a grounded 3-wire cord. The
extension cord should be arranged so that it will not drape over the counter
top or table top, where it can be pulled on by children or tripped over.
10
LIMITED WARRANTY
Salton Canada warrants that this appliance shall be free from defects in material and
workmanship for a period of one year from the date of purchase. During this
‘in-warranty’ period, defective products will be repaired or replaced at the discretion
of the retailer and/or Salton Canada. This warranty covers normal domestic usage
and does not cover damage which occurs in shipment or failure which results from
alteration, accident, misuse, abuse, glass breakage, neglect, commercial use or
improper maintenance.
A defective product should be returned to the original place of purchase within the
retailer’s stipulated return/exchange period*. If you are unable to have a defective
product replaced under warranty by the retailer, please check our website at
“www.salton.com” for the service centre nearest you. You may also contact us for
assistance by mail, e-mail, fax or telephone as listed below.
To ensure prompt ‘in-warranty’ service securely package and return the product to us
prepaid. Be sure to include the original proof of purchase and a description of the
defect along with your address and postal code.
For repairs not covered by the warranty, please contact us for assistance.
SALTON CANADA
Customer Service Department
81A Brunswick,
Dollard-des-Ormeaux,
Quebec, Canada H9B 2J5
website: www.salton.com
E-mail: [email protected]
Fax: [phone]
Tel: [phone]
* Return/exchange policies at each retailer vary and may differ from the SALTON Canada 1 year limited
warranty period.
Booklet_ID-1172_ENG.qxd:Salton Booklet 7/15/09 10:28 AM Page 10
