SaMASZ RAM 250 User manual

SaMASZ Sp. z o.o.
ul. Trawiasta 1
16-060 Zabłudów
Polska
tel. (+48) (85) 664 70 31
fax (+48) (85) 664 70 41
e-mail: [email protected]
www.samasz.pl
OPERATOR’S MANUAL
Serial No
The original operator’s manual
ENGLISH
IN0489EN001
14.10.2015
EDITION 1
SNOW PLOW
RAM 250
RAM 270
RAM 300

2
RAM
SNOW PLOW
OPERATOR’S MANUAL
The proven designs and the correct selection of materials ensure a high reliability and a long
service life of our products.
SaMASZ is confident that your purchase of this machine is the right choice and you will have a
great experience when operating it.
GENERAL WARNING
Follow the hazard warnings and the safety instructions indicated
with this symbol throughout the Operating Manual to operate the
machine.
ATTENTION:
It is forbidden to use the plow having not read the Operating
Manual or by persons without a license to drive, especially
children. Every plow user should be fully aware of the risks
involved and should know how to avoid them.
ATTENTION:
Keep this manual for future reference.

3
OPERATOR’S MANUAL
SNOW PLOW
RAM
Table of Contents
1. IDENTIFICATION.......................................................................................................................4
2. INTRODUCTION ........................................................................................................................4
3. PROPER USE.............................................................................................................................5
3.1. Technical data ...................................................................................................................5
3.2. Construction ......................................................................................................................6
3.3. Equipment..........................................................................................................................7
3.3.1. Standard equipment ....................................................................................................7
3.3.2. Optional equipment.....................................................................................................7
3.4. Spare parts ........................................................................................................................8
4. SAFETY ADVICE........................................................................................................................8
4.1. Safety rules and regulations ...............................................................................................8
4.2. Dangers and prohibitions....................................................................................................9
4.3. Operator’s qualifications ....................................................................................................9
4.4. Transport...........................................................................................................................9
4.4.1. Handling the machine onto a vehicle for transporting purpose....................................10
4.5. Warning signs ..................................................................................................................12
5. OPERATION............................................................................................................................13
5.1. Connecting ......................................................................................................................13
5.2. Plow control.....................................................................................................................14
5.3. Plow transport and parking positions................................................................................14
5.4. Preparing the plow for operation.......................................................................................15
5.5. Operation.........................................................................................................................16
5.6. Plow's allowable snow load and protections .....................................................................16
5.7. Maintenance ....................................................................................................................20
6. MAINTENANCE AND STORAGE ...............................................................................................20
7. REPAIR AND DISPOSAL...........................................................................................................21
7.1. Repair ..............................................................................................................................21
7.2. Disassembly and disposal ................................................................................................21
7.3. The environment ..............................................................................................................21
8. WARRANTY ............................................................................................................................22
8.1. Warranty card...................................................................................................................22
8.2. Warranty conditions .........................................................................................................22
8.3. Record of warranty repairs................................................................................................24
DEFINING THE TOTAL WEIGHT, AXIS LOAD, TYRE LOAD CAPACITY AND MINIMUM LOAD................25

4
RAM
SNOW PLOW
OPERATOR’S MANUAL
1. IDENTIFICATION
Every snow plow can be clearly identified using the identification plate which is permanently attached
to the suspension body, as is shown below Fig. 1.
Fig. 1. Data plate and its placement
Data plate includes:
❑name and adress of the manufacturer,
❑model year,
❑CE marking means, that the produce conforms to
❑version number,
2006/42/EC Directive and harmonized standards,
❑machine weight,
❑machine symbol,
❑id number,
❑date of manufacture,
❑barcode.
ATTENTION!
The data plate is a document and it is forbidden to change it or to allow it to
become illegible.
UWAGA!
The data plate contains essential information necessary when contacting the
manufacturer in the event of any questions or doubts.
UWAGA!
When ordering spare parts for a device, please include data from the data plate
of that device: name, model, serial number and date of manufacture.
2. INTRODUCTION
❑The Operating Manual should be considered an integral part of the machine. When handing over the
machine to a new user, it must be in good repair and complete with this Operating Manual and the
assigned essential equipment.
❑Before you start operating the plow, read and understand this Operating Manual and the general
work safety regulations.
❑The machine has been designed and built in compliance with applicable safety standards.
❑Compliance with the guidelines of this Operating Manual will ensure full operating safety.
❑If you have any doubts about starting up and operating the machine, consult the manufacturer.

5
OPERATOR’S MANUAL
SNOW PLOW
RAM
❑The Operating Manual is an indispensable part of every machine. It provides to the machine user
an explanation of the correct operation and use of the machine, and the potential operating hazards.
3. PROPER USE
Ram series Snow Plow with inclined shield is a middle class plow with admissible even head load of up
to 6 tons, designed for clearing snow from roads, parking lots and squares with minor unevenness and
other similar works. It can operate both with municipal tractors featuring high power in relation to
tractor’s overall weight, farming tractors and other low-speed vehicles equipped with 3-point linkage
Cat. II. as well as other self-propelled vehicles (e.g. telescopic loaders, excavator-loaders etc.). Meeting
requirements concerning operation, use and repair as advised by the manufacturer and their thorough
following is condition for operation as designed.
Not withstanding the rules of the machine's utilization, its proper use consists of maintenance and
keeping it in good condition as well as the use exclusively of original spare parts.
ATTENTION!
Do not use the machine for purposes other than specified as the intended use
in this Operating Manual. Other purposes will be non-intended use of the
machine and may void the manufacturer's liability for all damage from non-
intended use.
The machine must only be used, operated, and repaired by personnel familiar
with its detailed characteristics and safety procedures. The manufacturer shall
not be liable for any damage or loss resulting from unauthorized modifications
of the machine’s design.
3.1. Technical data
SaMASZ® manufactured Ram snow plows feature the following parameters:

6
RAM
SNOW PLOW
OPERATOR’S MANUAL
Tab. 1. Technical data
Plow type
Ram 250
Ram 270
Ram 300
Mounting manner
3-point linkage category II
Turning left/right
to 30°
Operating width: depending on
operating positions [mm]
min 2180
max 2500
min 2350
max 2700
min 2600
max 3000
Blade’s height [mm]
850
Number of hydraulic connectors
2 (1 pair)
Control
Hydraulic
Dimensions:
Length [mm]
1060
Width [mm]
2580
2780
3080
Height [mm]
1070
Weight [kg]
280
300
330
Clearance LED lighting
YES
Divided shield
NO
Rubber or steel clearing bar, Rubber-
corondum bar, or poliurethan bar
Up to Client’s choice
Optional equipment
Additional rubber or steel clearing bar
YES
Support wheels
YES
Slides
YES
3.2. Construction
Ram snow plow generally consists of linkage (1), operating assembly, which can be turned to up to 30°
on both sides thanks to hydraulic cylinders (2) (Fig. 2). Hydraulic cylinders are controlled by tractor’s
hydraulics through cross sweep valve (3). Plow has inclined shield consisting of two independent
segments (4), which incline when the machine drives onto an obstacle protecting working parts against
damage. Linkage is connected to the working unit by protective springs (5) with changeable hitch frame
(6) at the end.

7
OPERATOR’S MANUAL
SNOW PLOW
RAM
Fig. 2. Construction of the Ram plow
1 –mounting system
6 –hitch frame
2 –actuator
7 –clearance flaglets
3 –cross sweep valve
8 –clearing bar
4 –mouldboard
9 –support foot
5 –protective springs
10 - safety bumper
11 - locking pawl
3.3. Equipment
3.3.1. Standard equipment
❑warranty card,
❑operating manual and spare parts catalogue,
❑rubber clearing bars,
❑shield's protection with springs with locking pawl,
❑support leg,
❑marker lights,
❑linkage with transverse ground following,
❑spray paint (150 ml).
3.3.2. Optional equipment
❑set of support wheels,
❑set of support skids,
❑doctor blade wear-resistantsteel,
❑clearing bars Kombi and Rubber-corondum,
❑clearing bars poliurethan.
1
2
4
5
6
3
7
7
8
9
10
11

8
RAM
SNOW PLOW
OPERATOR’S MANUAL
3.4. Spare parts
Spare part should be ordered according to the spare parts catalogue, using full name of the part and
the part number from the catalogue.
ATTENTION!
Use only original equipment and spare parts from the SaMASZ Company. Parts
from an unknown source or home made parts are less durable and have a
negative influence on the operation of the plow and work safety.
As an option, Ram plows can be equipped with ordered support wheels or slides, owing to which the
plow’s pressure onto the ground can be reduced, and therefore life of either clearing bars can be
extended.
4. SAFETY ADVICE
4.1. Safety rules and regulations
❑Before operation the operator must read this operating manual.
❑Unfamiliarity with the operating manual can lead to damaging of the plow.
❑It is not permitted to use the plow for purposes other than those specified in the intended use.
❑The plow’s hitch is supplied with a mechanical overload protection in the form of bolts.
If broken, any resulting damage shall not be covered by the warranty.
❑No changes to the structure shall be allowed without agreeing on them with the manufacturer.
❑Unauthorized personnel can not remain in the vicinity of the plow.
❑Before starting work conduct a check of the device and especially the condition of the main
connections of the plow and the connection of the plow to the tractor.
❑In the event of the necessity of working under a plow raised on the TPH of the tractor the plow
must be secured so that it does not fall.
❑The condition of bolt connections and other connecting elements should be periodically checked.
Operation with damaged connections is forbidden.
❑Carrying people or loads on the plow during transport or operation is forbidden.
❑Use original pins and safeguards to connect the plow to the tractor.
❑When standing the plow should be in the parking position (Fig. 8 poz. a).
❑Damaged hydraulic hoses and other elements of the hydraulic system should be replaced.
❑Use only original spare parts which are purchased at our company store or at a dealership.
❑During operation, maintenance or adjustment always use protective gloves.
❑Do not leave the tractor and plow on inclines. If such need occurs turn off the engine, engage the
parking brake and lower the plow.
❑The plow should be stored in a covered area in the retracted position –with the actuators retracted
to protect the piston rods.
❑In the event of failure, pull up, stop the vehicle's engine and remove the ignition key. Next, contact
the SaMASZ authorized service. In the event of an accident (including a road accident), follow the
good practices of first medical aid and contact relevant services.
❑Never leave the vehicle during rides.

9
OPERATOR’S MANUAL
SNOW PLOW
RAM
4.2. Dangers and prohibitions
ATTENTION!
Even though the manufacturer of the plow SaMASZ Sp. z o. o. Bialystok, in order
to eliminate danger, assumes responsibility for the design and construction of
its plows, some elements of risk (so called residual risk) are unavoidable during
plow use.
ATTENTION!
Existing residual risk mainly results from inappropriate behavior of the snow
plow operator and not adhering to the rules of the operating manual.
ATTENTION!
While assessing residual risk the snow plow is treated as a machine which to
the moment of its manufacture was designed and constructed according to the
level of technology used at the time of its manufacture.
ATTENTION!
Some residual risk is still present even if all specified guidelines and
prohibitions are adhered to.
ATTENTION!
The danger of injury occurs during replacement of any working elements with
sharp edges. During all repairs or maintenance always wear protective gloves.
PROHIBITIONS!
Remember the following prohibitions during snow plow operation.
❑Operation of the plow under the influence of alcohol, drugs or medications which reduce motor
skills is forbidden.
❑Operation of the plow by unauthorized or untrained personnel is forbidden.
❑Using the plow for activities other than those described in the operating manual is forbidden.
❑It is forbidden to operate the plow if it is technically defective or damaged parts are evident.
4.3. Operator’s qualifications
For the safety of operation of this machine, all its operators must:
❑Have a driving license, be able to drive vehicles safely and be familiar with road traffic regulations
❑Be in a suitable mental and physical condition to be able to operate this machine
❑Refrain from the use of alcohol, narcotics or any medications which may affect their driving of
vehicles and operation of machines
❑Read, understand and follow the provisions of this Operating Manual
❑Understand the operating principle of both the tractor and this machine and be able to identify and
avoid the hazards caused by operation of the combination.
4.4. Transport
❑Do not carry anyone or anything on the machine.

10
RAM
SNOW PLOW
OPERATOR’S MANUAL
❑Adapt the driving speed to the road conditions and the national Highway Code regulations.
❑Operating speeds of the tractor-plow unit should be appropriate to working conditions, such as:
level of unevenness, rocks, curbs and other immovable obstacles.
❑Low operating speeds are recommended –using low gears of the tractor. Use of higher speeds can
cause injury to the driver and damage to the plow and the front TPH (three-point hitch) of the tractor.
❑All alteration of the plow position may be made only after you ensure no bystanders and animals
are nearby.
❑The person who handles the machine is responsible for ensuring the movement area and the action
itself are safe.
4.4.1. Handling the machine onto a vehicle for transporting purpose
NOTE:
The snow plow is delivered assembled, fully adjusted and ready for use.
Both the carrier and the driver shall be responsible for the plow transport safety. Any
equipment and parts must be secured properly for transport. In order to safely relocate the snow plow
onto another vehicle, please follow these rules:
❑to lift the mower, use only lifting devices with hoisting capacity bigger than the mower weight
❑provided on data plate. It also applies to ropes and chains used for lifting,
❑transport belts, belt suspensions, ropes cannot be damaged. Whenever damages to these parts are
spotted replace these with new ones,
❑seize the mower by any lifting device only in places indicated on the machine with the hook sign
(Fig. 3),
Fig. 3. Points of lifting plow when moving

11
OPERATOR’S MANUAL
SNOW PLOW
RAM
Fig. 4. Location of centre of gravity
Tab. 2. Location of centre of gravity
Dimension
[mm]
Model
Ram 250
Ram 270
Ram 300
A
405
440
440
B
310
380
380
L
1250
1350
1500
❑when mounting slings, chains, handles etc. always pay attention to setting the machine's center of
gravity properly,
❑to catch machines, pick ropes of adequate length, so that the angle between them is no greater than
120°, and the angle between the strand and the vertical is no greater than 60°,
❑collapsible parts should be blocked in transport position,
❑during putting the mower onto another vehicle it is forbidden for anybody to remain in transport
area,
❑on the vehicle’s trailer the machine should be secured against moving.
A
B

12
RAM
SNOW PLOW
OPERATOR’S MANUAL
4.5. Warning signs
ATTENTION!
Always observe the instructions on warning signs on the plow which warn of
dangers.
ATTENTION!
a) All warning labels should be clean and legible.
b) In the event of loss or damage of labels they should be replaced.
c) Labels can be purchased from the manufacturer.
ATTENTION!
Any replaced parts should posses all warning signs required by
the manufacturer.
Tab. 3. Warning labels located on the plow
N-03
Read the operating
manual before operation
N-04
Turn off power before
starting servicing or
repairs
N-40
Transport hook for lifting
of the plow
N-52
Use protective gloves
N-100
Use protective glasses
N-101
Use protective clothing
N-102
Use head protection
N-103
Use hearing protection
N-104
Use protective shoes

13
OPERATOR’S MANUAL
SNOW PLOW
RAM
Fig. 5. Safety signs on the machine
5. OPERATION
5.1. Connecting
Conditions for connecting the plow to the tractor:
❑the Ram plows have been designed as front mounted plows with the cat. II TPH type mounting
system. Depending on Client's individual needs, the frame can be mounted with other hitch type,
❑the tractor must have a 12 V power outlet (cigarette lighter outlet),
❑the tractor must have at least one pair of hydraulic connections.
Fig. 6. Mounting the Ram plow on the three point hitch (A –pins with cotter pins,
B –hydraulic connections, C –support foot, D –tractor's lower arms,
E –upper tie, F –turning axis of the moldboard)
A
B
C
D
E
90°
F

14
RAM
SNOW PLOW
OPERATOR’S MANUAL
In order to mount the plow on the tractor approach the plow so that the lower lifting arms of the three
point hitch are inserted into the mountings of the plow's suspension. Secure the mounting using pins
and cotter pins. Connect the upper part of the suspension system using a regulated tie and secure them
with pins and cotter pins.
Next, connect the hydraulic connections and the power plug along with the control switch. The rotation
axis of the moldboards should be perpendicular to the ground. After lifting the plow the support foot
should be lifted and secured with a pin. If the plow has been equipped with support wheels or skids
they should be adjusted to the correct height.
ATTENTION!
The manufacturer is not responsible for damages to the device resulting from
improper mounting of the plow on the TPH of the tractor. During operation
periodically check weather the plow is still properly mounted.
5.2. Plow control
After connecting the hydraulic system (B) (Fig. 6) take the electrical cable into the tractor's cabin and
insert the plug into the 12 V cigarette lighter outlet (I) (Fig. 7).
In order to lift/lower the plow we use the control lever (H) of the front TPH of the tractor. To rotate the
moldboard, use the hydraulic control lever (H) (Fig. 7). Turn the marker lights on or off insert or remove
the electrical cable plug from the cigarette lighter outlet.
Fig. 7. Controlling the Ram plow: I –cigarette lighter plug, H –front TPH and hydraulic control lever
(* - this is different in different types of tractors)
5.3. Plow transport and parking positions
During plow transport it should be lifted and prevented from lowering on its own (ex. locking the
tractor's TPH). When standing the plow mounted on the tractor should have the plowshare resting on
the ground. Plow not connected to the tractor's TPH should be resting on the support foot. In all
positions mentioned above the plow should be in the retracted position which means with the actuators
retracted (Fig. 8).
H
I

15
OPERATOR’S MANUAL
SNOW PLOW
RAM
Fig. 8. The RAM plow a) –parking position, b) –transport position
5.4. Preparing the plow for operation
ATTENTION!
During storing of the machines in company SaMASZ the cylinders are protected
by special grease in order to secure them against weather which may cause their
premature wear. Before starting the operation excess grease should be removed
from the cylinders.
After correctly mounting the plow on the tractor it should be inspected and it should be determined if
the plow has a worn blade insert or loose bolts. If necessary replace worn elements and tighten the
bolts. If the plow is ready for use it should be placed in the desired position and plowing may be started.
Fig. 9 presents basic operating positions of the plow. While working on public roads turn on the marker
lights.
Fig. 9. Basic operating positions of the plow, a) –plowing snow left,
b) –plowing snow right, c), –moving the snow
Plow has a locking pawl, which is unlocked when lower part of the shield hits an obstacle. Application
of such solution enables the shield's unlocking force adjustment by adjusting tensioning force of spring
under the pawl.
a)
b)
c)
a)
b)

16
RAM
SNOW PLOW
OPERATOR’S MANUAL
In order to adjust the force loosen nuts (N), and then adjust screw connection by loosening or tightening
the spring (S) (Fig. 10). Once these are done tighten locknuts.
Fig. 10.Adjusting shield's unlocking force
5.5. Operation
ATTENTION!
While plowing the driving speed should be appropriate to existing road
conditions. During operation driving faster than 25 mph is forbidden.
ATTENTION!
Reversing is forbidden when working with a plow equipped with support wheels.
Support wheels do not rotate around the vertical axis and therefore reversing
may damage them.
5.6. Plow's allowable snow load and protections
Ram plows are middle class snow plows that are able to tackle snow mass of up to 6 tones. A
schematic of permissible load distribution has been presented in Tab. 4 positions a, b and c). Plows
often operate on uneven terrain and are subject to meeting immovable obstacles which the operator
often can not see, especially when covered by snow. For this reason the Smart plows have been
equipped with a moldboard which tilts back 65 which allows the plow to easily move over obstacles up
to 10 cm (Tab. 6). A condition of this safeguard is that the TPH must be set to the floating setting.
S
N

17
OPERATOR’S MANUAL
SNOW PLOW
RAM
Tab. 4. Schematic visualization of the permissible loading of the Ram plow
Tab. 5. Approximate force Fhacting on the plow, at speed Vand stopping distance Shwith a tractor weight equal
to 6 tons –according to Tab. 4d.
Braking distance
Sh= [cm]
Estimated head force Fh= [T], for braking of tractor with mounted plow at
speeds V
5 km/h
10 km/h
20 km/h
10
1
11
16
20
0,5
3
8
30
0,3
1,2
3
40
0,2
0,5
2
The table above is a demonstration to show the operator how suddenly the forces change depending
on speed and stopping distance.
The initial force under which the moldboard starts to tilt depends on the initial spring setting. The initial
spring setting can be adjusted in the range of 0to approximately 60 mm using the four tension bolts
located in the upper part of the moldboard. As evident in Tab. 6 this force is not constant as the
moldboard tilts but rather changes unevenly. The table above shows the working of the blade with the
initial spring setting at 30 mm. The greatest resistance force Fu is created in the moldboard between
tilt angles of 55oand 65ofrom starting position. By increasing the initial spring setting the Fu is also
increased along with the pressure on the entire plow, which can lead to damage of the plow especially
with greater operating speeds. If the initial spring setting is high then great care should be taken to
a)
Schematic of the permissible loads affecting the
Ram plows
uchylająca odkładnicę
Distribution of permissible loads of the Ram
plows with GCJ-63-36x300 up to 6 Ton
Schematic of the permissible loads of the
Ram plows
b)
c)
d)
up to 6 tons
Force tilting
the blade
Ground

18
RAM
SNOW PLOW
OPERATOR’S MANUAL
maintain low plowing speed, since in the event of encountering an obstacle this will allow the operator
to quickly stop the tractor.
Lateral coping is achieved thanks to the oval, vertical openings in the mountings of the front TPH of
municipal tractors. If the front TPH is not equipped with this solution then care should be taken during
plowing, especially on uneven terrain.
The forces which are created in the plow at the moment of hitting or grazing an obstacle have been
presented in Tab. 5. Depending on the type of an obstacle the stopping time may vary.
Tab. 6. The working of the blade
This concerns the entire moldboard with the initial spring setting at 30 mm.
α [º]
Fu [kg]
Ram 250
Ram 270, Ram 300
0
~ 90
~ 135
15
~ 250
~ 375
25
~ 350
~ 530
35
~ 450
~ 675
45
~ 540
~810
55
~ 625
~910
65
~ 700
~1050
Ram plow is equipped with frame system protecting it against snow load greater than 6 tones and
sudden hitting a solid obstacle. Working principle is based on hit's energy absorption by partial or
complete tearing of 8 bolts M10 of 8.8 class, as well as and plastic deformation of hitch’s impact plates.
Additional protection is provided by fitting the plow with side safety bumpers protecting it against hits
from sides, e.g. hitting a curb.

19
OPERATOR’S MANUAL
SNOW PLOW
RAM
Fig. 11.Types of hitch frames for Ram plows
a) frame Cat. II
b) EURO frame
c) frame Cat.I
d) SMS frame
e) frame on-frame enclosure
f) enclosure plate
g) frame for municipal triangle hitch
h) frame for triangle hitch Cat. I
i) frame for triangle hitch Cat. 0
A
B
C
D
E
F
G
H
I

20
RAM
SNOW PLOW
OPERATOR’S MANUAL
5.7. Maintenance
ATTENTION:
Each time the plow is disconnected from the vehicle's hydraulic system, the
partial pressure in the hydraulic system must be reduced.
Every time before starting work:
❑make certain that the plow is properly connected to the tractor,
❑check the condition of the hydraulic hoses and fittings,
❑check the hydraulic system and marker lights,
❑check the level of wear on the blade insert and replace if necessary,
❑check the tightness of all bolts and nuts according to Tab. 7,
❑when installed adjust the height of support wheels or skids,
❑in the event of broken bolts or damaged parts - replace them.
After 5 workhours:
❑check the condition of blade inserts,
❑check the condition of mount securing bolts and replace if necessary,
❑when installed adjust the height of support wheels or skids if necessary.
After finishing work:
❑carefully clean and wash the plow.
Tab. 7. Values of bolt tightness MA
6. MAINTENANCE AND STORAGE
In the event when the plow will be parked for a period longer than two weeks, always perform the
following maintenance:
❑carefully clean and wash the plow,
❑if the plow requires repairs, adjustments, gasket replacement, or hose replacement this should be
completed,
KL
A
6,8
8,8
10,9
12,9
MA[Nm]
M4
2,2
3,0
4,4
5,1
M5
4,5
5,9
8,7
10
M6
7,6
10
15
18
M8
18
25
36
43
M10
37
49
72
84
M12
64
85
125
145
M14
100
135
200
235
M16
160
210
310
365
M18
220
300
430
500
M20
310
425
610
710
M22
425
580
820
960
M24
535
730
1050
1220
