Sami Wearable WS-2338 User manual

WEARABLE
User Manual
WS-2338
Thank you for purchasing the Sami wearable WS-2338. Read the instructions carefully to obtain optimum results and
preserve it for future reference. Sami has developed wearable devices since 2015 and we use the best components
possible for the product.
DESCRIPTION OF THE WEARABLE
CONTENTS
Wearable, USB Clip charging cable, instruction manual.
CHARGING
Connect the device to a computer or laptop with the USB Clip charging cable. Insert the charging thimbles of the charger
into the charging points positioned in the back of your device. Kindly use only the USB cable included with the wearable. If
you use a power adapter for charging, the output of the power adapter should be 5V, 1A. Charging time: 2 hours. Please
charge the device fully before using it.
HOW TO POWER ON / POWER OFF?
1) To turn ON the smart band, long press the touch button for a few seconds. The touch button is situated on the
bottom of the screen.
2) To turn OFF the smart band, tap the touch button until you get in the “Others” interface, long press the touch
button to enter, short press the touch button a few times until you enter in the “Shut down” interface long press
the touch button for a few seconds to make it power off.
HOW TO CONTROL?
1) On the display screen , short press the touch button control to change between the different menus. Long press to
achieve the different functions.
HEALTH SENSOR
CHARGING POINTS
FIXED- POINT TOUCH CONTROL

GETTING STARTED:
- For Android
1) How to obtain the BT Connection APK (WEARFIT 2.0)
Search for the WEARFIT 2.0 APP in the Google Play Store; download it and install it in your Android smartphone, or go to our
website www.sami.es and download the application.
2) Installation of the WEARFIT 2.0 APK.
When installing the WEARFIT 2.0 application on your Android, you must allow all the Application Permissions, allow this
WEARFIT 2.0 app auto run.
The first time you run this WEARFIT 2.0, it will ask you to Enable Notifications, please tap OK and tap the WEARFIT 2.0 and
confirm OK. You must tap OK/Allow/Pair/Yes/Confirm for any pop-up request. On your Android permission management,
allow all application permissions.
3) How to make the wearable pair with your Android smart phone?
*First, turn on the Bluetooth of your Phone.
*Second, run the WEARFIT 2.0 app on your Phone, on the home page of WEARFIT 2.0, select “Third party log in” and select
the social network that appears to log in with this one in the app. Once you open the app select the “me” icon which is on
the right bottom of the interfacetap Connection Management tap again Connect band, and then the APP will search
for Bluetooth device(s), when the available Bluetooth device displays, please tap KY11 or WS-2338 (the BT name of this
device) to make it pair. The pairing will be finished in few seconds. When you finish select OK/Confirm/Allow for any pop-up
request.
* Now you can start using your desired functions of the smart band.
Important: To enable all notifications of different software’s such as WhatsAPP, Facebook, Skype, Twitter, you may need to
turn on the notifications on the APP manually. On the home page of WEARFIT 2.0, select the “me” icon situated on the right
bottom of the screen, and select ‘’Device management’’, ‘’ Smart reminder’’, ‘’app notification’’ and turn on all
the APP notifications you want to active.
- For iPhone
1) How to obtain the BT Connection APP? (WEARFIT 2.0)
On iPhone, please go to APP Store and search WEARFIT 2.0 and install the app.
2) How to make the wearable pair with your iPhone?
*First, turn on the Bluetooth of iPhone
* Run the WEARFIT 2.0 app on the iPhone, on the home page of WEARFIT 2.0, select “Third party log in” and select the
social network that appears to log in with this one in the app. Once you open the app tap the “MINE” icon which is on the
right bottom of the interface tap Connection Management tap again ”Bind Bracelet”, and then the APP will search for
Bluetooth device(s), when the available Bluetooth device displays, please tap KY11 or WS-2338 (the BT name of this device)
to make it pair. The pairing will be finished in few seconds. When you finish select OK/Confirm/Allow for any pop-up request.
* Now you can start using your desired functions of the smart band.
Important: To enable all notifications of different software’s such as WhatsAPP, Facebook, Skype, Twitter, you may need to
turn on the notifications on the APP manually. On the home page of WEARFIT 2.0, select the “MINE” icon situated on the
right bottom of the screen, and select ‘’Device management’’, ‘’ Intelligent reminder’’, ‘’app notification’’ and turn
on all the APP notifications you want to active.
PRODUCT FEATURES
BLUETOOTH (V 4.0)
TOUCH BUTTON
FIXED POINT TOUCH SCREEN. Capacitive touch screen 1.3"
BUILT IN VIBRATING MOTOR
BUILD IN HEART RATE SENSOR
BUILD IN GRAVITY SENSOR
GESTURE CONTROL TO LIGHT UP THE DISPLAY SCREEN- Flip over your wrist at an angle bigger than 90°to light up the screen.

DISPLAY SCREEN INTERFACE
1) Time/Date/ Battery/Distance /Steps/Heart rate
2) Clock Screens –two different home digital clocks; in the main screen, long press the button to change it.
3) Sports (Pedometer)
4) Sleep monitor
5) Heart rate monitor
6) Blood pressure test
7) Blood Oxygen (SPO2) test
8) Exercise (sports mode) –including Running/ Cycling/Alpinism
9) Others –long press the touch Button to enter, functions included are: Find a phone, Music control, Message, Native info,
Shut down (Power OFF).
10) Remote camera –Support at APK/APP
11) Find the bracelet–Support at APK/APP
12) Alarm clock –Support at APK/APP
13) Non-disturbing mode –Support at APK/APP
Data can be sync from the wearable to the smart phone on the WEARFIT 2.0 APK/APP.
Your smart phone will synchronize when the Bluetooth is paired with this device.
FUNCTIONS
PHONE CALL NOTIFICATION - vibrating reminder for incoming phone calls
MESSAGE NOTIFICATION - vibrating reminder for incoming messages, including SMS, WhatsApp, Facebook, Twitter, Skype
messages, etc.
CLOCK SCREENS two different home digital clocks; in the main screen, long press the button to change it.
SLEEP MONITOR - supported on the WEARFIT 2.0 APK/APP. This function automatically runs at night, and the data generates
in the mornings.
ALARM CLOCK - supported on the WEARFIT 2.0 APK/APP
SEDENTARY REMIDER(REMIND TO MOVE) - supported on the WEARFIT 2.0 APK/APP
FIND THE DEVICE (Looking for the SMART BAND) - supported on the WEARFIT 2.0 APK/APP
GESTURE CONTROL (Raise your hand to light up the screen. Before using this function, you need to make the adjustment on
the smart phone APP)
GPS MAP TRACE (view it on the BT APP/APK WEARFIT 2.0). On the home page of the WEARFIT 2.0, tap the icon which is
on the middle bottom of the interface tap the “RUN” or the “TAKE EXERCISE” icon tap Start tap the map icon to
view the GPS MAP Trace. GPS TRACE HISTORY can be shared to Facebook and other APPs. This function GPS MAP TRACE
won’t be available until the APP WEARFIT 2.0 is log on via Facebook.
Note: The text and icons in the smart band will be always in the English language
**** THIS IS NOT A MEDICAL INSTRUMENT, SO THE VALUES ARE APPROXIMATE
TECHNICAL SPECIFICATIONS:
Display screen: Fixed-point capacitive touch screen 1.3".
Screen resolution: 240x240 pixels.
Internal Memory: RAM 128KB, ROM 1 Mbit
System: Nucleus
CPU: HS6620D
Charge I/O port : USB CLIP charging cable
Battery: Built in Li-Polymer 150 mAh
Stand by time: 7~10 DAYS
Working time: 3~5 DAYS
Bluetooth: 4.0.
Water-resist Rating: IP67 (this device resists raindrops, it’s not water proof)
Weight: 45 g

Declaration of Conformity
Hereby we,
Name of manufacturer:
SANTOSHI SL
Address:
CALLE FELIPE ASENJO N.56
Zip code & City:
28947 - FUENLABRADA ( MADRID )
Country:
SPAIN
declare that this DoC is issued under our sole responsibility and that this product:
Product description:
Smart Band
Type designation(s):
WS-2338
Trademark:
SAMI WEARABLE
is in conformity with the relevant Union harmonization legislation:
DIRECTIVE EMC 2014/30/EU
DIRECTIVE LVD 2014/35/EU
Standard CE (RED): DIRECTIVE 2014/53/EU
Standard RoHS: 2011/65/EU: (RoHS) Restriction of Hazardous Substance.
with reference to the following standards applied:
EN 60950-1: 2006+A11:2009+A1:2010+A12:2011+A2:2013
EN 62479:2010
EN 301 489-1 V2.1.1 (2017-02)
EN 301 489-17 V3.1.1 (2017-02)
EN 300 328 V2.1.1 (2016-11)
Signature
Full name: VISHAL MIRPURI
Position: ADMINISTRATOR
Date: 05 / 12 / 2019
