Sami Wearable WS-2370 User manual

WEARABLE
User Manual
WS-2370
Thank you for purchasing the Sami wearable WS-2370. Read the instructions carefully to obtain optimum results and preserve it
for future reference. Sami has developed wearable devices since 2015 and we use the best components possible for the
product.
DESCRIPTION OF THE WEARABLE.
CONTENTS.
Wearable, Magnetic USB cable, instruction manual.
CHARGING.
Use a power adapter to connect with the provided magnetic charging cable for charging. Let the magnetic end of the cable
to contact the charging contacts which are positioned on back of the smartband properly. The Output of the power adapter
should be 5V, 1A. Kindly use only the USB cable included with the wearable. Charging time: 2 hours. Please charge the device
fully before using it.
Attention: when the cable connect to a power adapter and power supplies, do not let the metal contacts which are on one
end of the cable, to contact any metal surface of other objects, otherwise it may cause a short circuit and damage the cable.
HOW TO POWER ON / POWER OFF?
1) To turn ON the smart band, long press the Power button for few seconds to make it Power On.
2) To turn OFF the smart band, long press the Power button for few seconds until Power off interface displays, confirm yes to
Power OFF; or on the smartband, find and tap the Setting Power Off, confirm yes to Power OFF.
HOW TO CONTROL?
1) On the display screen(touchscreen), short tap the touchscreen to select; long touch the screen to enter; tap and slide from
the left towards right to return; tap and slide towards left/right/up/down to change between the different menu pages.
2) Short press the Power button to return. Long press the Power Button to make it Power On/Off.
GETTING STARTED:
- For Android
Heartrate sensor
Charging point
1.1" Full touch screen
Power button

1) How to obtain the BT Connection APK (GLORYFIT)
Search for the GLORYFIT in the Google Play; download it and install it in your Android smartphone, or go to our website
www.sami.es and download the application.
2) Installation of the GLORYFIT APK.
When installing the GLORYFIT application on your Android, you must allow all the Application Permissions, allow this GLORYFIT
app auto run.
The first time you run this GLORYFIT it will ask you to Enable Notifications, please tap OK and tap the GLORYFIT and confirm OK.
You must tap OK/Allow/Pair/Yes/Confirm for any pop-up request. On your Android permission management, allow all
application permissions. Please allow locations services and background permission for correct use of the device.
3) How to make the wearable pair with your Android smart phone
*First, turn on the Bluetooth of your Phone.
*Second, run the GLORYFIT app on your Phone, on the home page of GLORYFIT, select below menu device and then“SELECT
DEVICE”, the APP will search for new Bluetooth device(s), when the available Bluetooth device displays, please select
WS-2370(the BT name of this device) to make it pair. The pairing will be finished in a few seconds. When you pair for the first time,
the app GLORYFIT will ask you to fill some personal information such as gender/age/height/weight. Must select
OK/Confirm/Allow/Yes for any pop-up requests. Please allow locations services and background permission for correct use of
the device.
* Now you can start using your desired functions of the smart band.
Important: To enable all notifications of different softwares such as WhatsAPP, Facebook, Skype, Twitter, you may need to turn on
the notifications on the APP manually. On the GLORYFIT homepage, select the Device icon (middle icon situated at the
bottom of the interface) then select App Reminder, and turn on all the APP notifications you want to active.
- For iPhone
1) How to obtain the BT Connection APP? GLORYFIT
On iPhone, please go to APP Store and search GLORYFIT and install the app.
2) How to make the wearable pair with your iPhone
*First, turn on the Bluetooth of iPhone
* Run the GLORYFIT app on the iPhone, on the home page of GLORYFIT, tap “ADD A DEVICE” the APP will search for new
Bluetooth device(s), when the available Bluetooth device displays, please tap WS-2370 (the BT name of this device) to make it
pair. The pairing will be finished in few seconds. When you pair for the first time, the app GLORYFIT will ask you to fill some
personal information such as gender/age/height/weight. Must select OK/Confirm/Allow/Yes for any pop-up requests. Please
allow locations services and background permission for correct use of the device.
*Now you can start using your desired functions of the smart band.
Important: To enable all notifications of different softwares such as WhatsAPP, Facebook, Skype, Twitter, you may need to turn on
the notifications on the APP manually. On the GLORYFIT homepage, select the Device icon (middle icon situated at the
bottom of the interface) then select App Reminder, and turn on all the APP notifications you want to active.
PRODUCT FEATURES
BLUETOOTH (v5.0)
FULL TOUCH SCREEN. TFT touch screen 1.10"
BUILT IN VIBRATING MOTOR
BUILD IN HEART RATE SENSOR
BUILD IN GRAVITY SENSOR
GESTURE CONTROL TO LIGHT UP THE DISPLAY SCREEN (Quick View) - raise up your hand to light up the display screen
DISPLAY SCREEN INTERFACE
*** to switch Dials ***
On home screen, long touch the display screen until it zooms out to change dials. More dials available at Glory Fit apk/app.

***On home screen, swipe from right to left to go to next pages with functions***
1) Sports (pedometer) –steps, distance, calories.
2) HR(heart rate monitor)
3) Blood Pressure test
4) Blood Oxygen SPO2 test
5) Sleep monitor –automatically run at night.
6) Training(sport modes) –Running, Cycling, Table Tennis, Skipping, Badminton, Tennis, Walking, Hiking, Basketball, Football,
Baseball, Volleyball, Cricket, Rugby, Hockey, Indoor Cycle, Dancing, Gymnastic, Jumping, Rowing, Abdominals, Yoga,
Indoor Walk.
7) Weather –the Weather icon and function won’t be seen until the device paired with a smartphone
8) Player(Music player controller)
***On home screen, swipe from down to up***
Messages (PUSH messages sync from your smartphone.)
***On home screen, swipe from top downwards ***
1) Bluetooth connection status
2) About the device(device info)
3) Brightness
4) Find phone
5) Settings –off, reset, device info, app QR code.
***On home screen, swipe from left to right***
1) Training
2) Measure Heart Rate
3) Measure Blood Pressure
4) SPO2 (blood oxygen)
5) Status (pedometer) –steps, distance, calories.
6) Sleep
7) Player (music player)
8) Stopwatch
9) Weather
10) Messages
11) Settings –off, reset, device info, app QR code.
NOTE: If the weather does not appear on the smart device after the Bluetooth pairing, please set your weather city at the Glory
Fit APP, then restart the smart device. The location service on your phone should be activated also.
Data can be sync from the wearable to the smart phone on the GLORY FIT APK/APP. Your smart phone will synchronized when
the Bluetooth is paired with this device.
***More functions in Gloryfit APP***
1) Watch faces (dials) –discover more dials and download it and sync it to the smartband, set personalized dial
2) Notifications –turn on/off for push notifications for Incoming Phone Calls, SMS, Facebook, Twitter, WhatsApp, etc.
3) Sedentary reminder
4) Alarms –Up to 3 Alarm clocks
5) Screen ON - on screen when raise hand
6) Do Not Disturb Mode: Select period for not receiving notification or screen on
7) Others –Camera shutter, Find device, Units selection, Find phone settings, Screen on time (5/10/15 seconds), 12/24h

selection, Language.
8) GPS MAP TRACE (view it on the Gloryfit app). On the home page of the Gloryfit, tap and select the sports icon. On the top
part you can select your sports and on the setting icon you can have different adjustments such as hear rate alerts, voice
alerts, etc.
9) GOAL TRACKING- supported on the Gloryfit APK/APP
**** This product is not a medical device, the data results are for reference only, not as a basis for diagnosis and treatment.
TECHNICAL SPECIFICATIONS:
Display screen: TFT fully touch screen 1.10"
Screen resolution: 240x240 pixels
Internal Memory: 64M RAM 160K+ ROM 384K
System: Nucleus
CPU: Realtek 8762C
Charge I/O port : USB Magnetic cable
Battery: Built in Li-polymer battery 200mAh
Stand by time: 15-20 DAYS
Working time: 5-8 DAYS
Bluetooth: v5.0
Hear Rate Sensor: VC11
3 Axis Sensor: STK8321
Water-resist Rating: IP67. Resist water splashes. Not suitable for swimming or shower.
Weight: 45g

Declaration of Conformity
Hereby we,
Name of manufacturer:
SANTOSHI SL
Address:
CALLE FELIPE ASENJO N.56
Zip code & City:
28947 - FUENLABRADA ( MADRID )
Country:
SPAIN
declare that this DoC is issued under our sole responsibility and that this product:
Product description:
Smart Band
Type designation(s):
WS-2370
Trademark:
SAMI WEARABLE
is in conformity with the relevant Union harmonization legislation:
DIRECTIVE EMC 2014/30/EU
DIRECTIVE LVD 2014/35/EU
Standard CE (RED): DIRECTIVE 2014/53/EU
Standard RoHS: 2011/65/EU: (RoHS) Restriction of Hazardous Substance.
with reference to the following standards applied:
EN 60950-1: 2006+A11:2009+A1:2010+A12:2011+A2:2013
EN 62479:2010
EN 301 489-1 V2.1.1 (2017-02)
EN 301 489-17 V3.1.1 (2017-02)
EN 300 328 V2.1.1 (2016-11)
Signature
Full name: VISHAL MIRPURI
Position: ADMINISTRATOR
Date: 17/06/2022
