Samick SSP30 User manual

SAFETY PRECAUTIONS AND INSTRUCTIONS
WARNING
Make sure that the voltage set is suitable for the instrument (the voltage is indicated next to the
power inlet).
When using electric products, always follow basic precautions, including the following:
1 Read all of these instructions before using the product.
2 To reduce the risk of injury, close supervision is necessary when the product is used near
children.
3 Do not use this product near water -for example, near a bathtub, washbowl, kitchen sink,
in a wet basement, near a swimming pool, or the like.
4 This product, either alone or in combination with an amplifier and headphones, or
speakers may be capable of producing sound levels that could cause permanent hearing
loss. Do not operate for a long period of time at a high volume level, or at a level that is
uncomfortable. If you experience any hearing loss, or ringing in your ears, you should
consult an audiologist.
5 The product should be located so that its location, or position, does not interfere with
proper ventilation.
6 This product should only be located away from heat sources such as radiators, heat
registers, and other products that cause heat.
7 The product should be connected only to the type of power supply described in the
operating instructions, or as marked on the product.
8 This product may be equipped with a polarised plug. This is a safety feature. If you are
unable to insert the plug into the outlet, contact an electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the plug.
9 The power-supply cord of the product should be unplugged from the outlet when left
unused for a long period of time. When re-plugging unit, turn on the instrument and leave
on for 3-5 hours to recharge internal battery. The battery may need to be replaced after
two or three years of use.
10 Care should be taken so that objects do not fall, and liquids are not spilled, into the
cabinet through openings.
11 The product should be serviced by qualified personnel when:
aThe power-supply cord or the plug has been damaged; or
b Objects have fallen, or liquid has been spilled, into the product, or
cThe product has been exposed to rain, or
d The product does not appear to operate normally, or exhibits a marked change in
performance, or
e The product has been dropped, or the cabinet damaged
12 Do not attempt to service the product beyond that described in the maintenance
instructions. All other servicing should be referred to qualified service personnel.
2

GROUNDING INSTRUCTIONS
This product must be grounded (earthed). In the event of a malfunction or breakdown, grounding
provides a path of least resistance for electric current to reduce the risk of electric shock. This
product is equipped with a cord having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded
in accordance with the local codes and regulations.
DANGER
Do not modify the plug provided with the product -if it will not fit -have a proper outlet
installed by a qualified electrician.
TEMPO / VALUE DISPLAY
The messages contained in the Display may not always match the display pages They are merely
examples of the many features of the product.
DISCLAIMER
The information contained in this manual has been very carefully revised. Due to the constant
effort to improve the product, the product specifications might differ to those in the manual. The
specifications are subject to modification without prior notice.
TAKING CARE OF YOUR INSTRUMENT
Your instrument is a fine instrument and deserves careful treatment.
Follow carefully the next few points, to keep it at it’s best for many years.
-Never open the case and touch the internal circuits.
-Always switch the power Off after use.
-Use a cloth or a damp sponge. If the dirt is particularly persistent, use a neutral detergent
to remove it. Never use solvents or alcohol.
-Do not place your instrument near electric motors, neon or fluorescent lamps as these
may generate disturbances.
-In most cases you just need to change the position of the instrument to avoid interference.
-Keep your instrument away from dusty environments, high humidity, and high
temperatures.
-Do not use on the same AC outlet with electrical appliances, neon lights or variable
lighting system.
-Before turning on the instrument, make sure that any external amplifier and speaker
system that you have connected to your instrument are turned off.
-Computer controlled instruments can be interrupted by spikes, surges and dropouts on the
power line. If your instrument stops working because of a power line disturbance, switch
it off for a few seconds and then switch it on again.
-Never disconnect the power cable without turning the power switch off.
3

The SG310 and the SDP 31 have as standard
If necessary the SSP30 can be used with an optional 3 Pedals
The SSP30 is supplied
POWER SUPPLY
Plug the DC output cable from the power adapter into DC IN jack in the rear panel of your
instrument, then plug the AC cable of your power adapter into a convenient wall AC power socket.
Turn on the instrument by pressing the POWER ON/OFF switch located in the back panel. Set the
MASTER VOLUME to the desired level. The MASTER VOLUME controls the
overall volume for the entire instrument.
USING HEADPHONES OR AN EXTERNAL SOUND SYSTEM
A standard stereo headphone can be plugged into the PHONES socket for private practice or late-
night playing. The internal speaker system is automatically switched off, when the headphone is
plugged into the PHONE socket. There are two sockets available in the rear panel and allow the
use of two headphone at the same time.
The LINE OUT (Left and Right) sockets can be used to deliver the output of the sound to an
external amplifier, stereo sound system, mixing console or tape recorder.
SUSTAIN PEDAL (supplied) –SSP30 only.
with a Sustain pedal.
Connect it to the Pedal Input number 2 to obtain the Sustain effect when used. It has the same
function as the ''sustain'' pedal on the piano.
It provides sustain and lets the sound slowly decay after the keys have been released.
SOFT/SOSTENUTO/SUSTAIN PEDAL (optional) –SSP30 only
pedal board.
Insert the mono jack to the Pedal Input number 1 and the stereo jack in the Pedal Input 2.
The instrument works now with a set of three pedals giving the following functions:
SOFT: gives the piano voices a ''softer'' sound.
SOSTENUTO: this allows only the notes pressed on the keyboard before the Sostenuto pedal
is activated to sustain and no subsequent notes played afterwards.
SUSTAIN: has the same function as the ''sustain'' pedal on the piano. It provides sustain
and lets the sound slowly decay after the keys have been released.
NOTE: the 3 pedals assembly built
in their own cabinet.
4

SLIDER CONTROLS
The Master Volume slider controls the overall volume of the instrument. It control the volume also
when connected to an headphone set. Moving the slider to the right it will make the sound lauder,
moving it to the left it will make the sound softer.
The Brilliance Control slider control adjusts the brightness of the sound. Moving the slider to the
right it will make the sound brighter , moving it to the left it will make the sound mellower.
PANEL DISPLAY INDICATIONS
Your instrument features a large multi-function display (INFORMATION DISPLAY) that shows
all the important settings for the instrument. At power up it shows:
DEMO SONGS
There are 26 demo songs in the internal memory. Listen to the pre-programmed demonstration
songs and they will give you a good idea of what the instrument can do.
-With the Power ON and Set the Master Volume at half way.
-Press the [DEMO] to activate the DEMO function. The name of the selected DEMO will
appear on the INFORMATION DISPLAY. You can select the demo songs by using the
[/\][\/] buttons.
-Press [DEMO] button again to stop the DEMO song.
5
