PRODUCT SPECIFICATION SHEET
MIXERS
TYPE:
L SERIES
PRODUCT DESCRIPTION
L2400 4-BUS MIXING CONSOLE
SERIES CATEGORY
L SERIES MIXERS
GENERAL DESCRIPTION
Perfect for installation purposes, especially in clubs,
schools, theaters and churches, the L2400 is a 24-
channel, 4-bus mixing console with USB functionality.
Housed in an ergonomically correct, attractively
appointed enclosure, this mixer includes professional
features such as high-quality mic preamps, 3-band
swept mid EQ and 6 auxiliary buses with up to eight
mixes possible. There are even 100mm faders on all
the channels and groups. And each fader feels tight with a
smooth action, ensuring optimal comfort for any engineer.
Connecting microphones and instruments is easy, with
16 mic/line inputs plus four additional stereo channels.
In addition, each console has two extra mic preamps
on the stereo channels, bringing the total number of
mic inputs to 18 on this mixer. There are also dedicated
stereo effects returns for the 100 on-board studio-
quality digital effects, which can be applied to vocals
or instruments using the built-in 24-bit multi-effects
processor.
The L2400 also features large, backlit mute buttons that
make console navigation in dimly lit club and theater
settings easy and convenient. Additionally, there are
two large 12-segment LED meters for the main mix,
groups and PFL/AFL. A convenient talkback system also
makes communicating with musicians and performers
onstage no problem. Plus, the XLR mono output has an
adjustable low-pass filter specific for subwoofer output.
Recognizing the presence of computers in contemporary
audio, we’ve included USB functionality so any sound
operator can record and playback digital audio from
virtually any computer running recording software. The
flexible routing option also lets a user assign the USB output
to send the signal from the main stereo mix, or use the aux
sends to record a completely independent mix. The USB
input can be routed to the main LR mix or to channel
23 and 24.
The L2400 will provide clean, clear sound reproduction
thanks to advanced circuit topology, high-quality
components, low noise microphone preamps and a low
impedance mix bus design. Perfectly suited for recording,
live sound reinforcement and commercial installations,
the L2400 combines comprehensive features and intuitive
design, resulting in a truly remarkable mixer that’s as
versatile as it is reliable.
FEATURES
> 24 input channels
> XLR Mic: 16 mono channels + 4 stereo channels
> 4 stereo line inputs, 2 with mic inputs
> 100mm faders
>
2 × 12-segment LED level meter for Main L/R,
PFL/AFL, Group 1-4
> Large illuminated mute switches and 100mm faders
> 3-band EQ with sweepable mids
> Dual DSP with 100 digital multi-effects
> 6 aux sends and 2 stereo aux returns
>
USB I/O (send from Aux or Main, return to Main
or last stereo channels)
> Talkback mic input
©2008 Samson v1.0 6/08
31.5”
21”
6.25”

L2400
PRODUCT SPECIFICATION SHEET
SERIES DESCRIPTION CATEGORY
L SERIES 4-BUS MIXING CONSOLE MIXERS
L2400 LIVE 24-CHANNEL SPECIFICATIONS
Maximum Output Level (0.5% THD at 1 kHz)
......................................... +24 dB (MAIN L/R) @ 10kΩ
......................................... +20 dB (INSERT) @10kΩ
......................................... +20 dB (GROUP, AUX/EFX,
CTRL ROOM) @10kΩ
......................................... More than100mW (HEADPHONES)
@ 33Ω
Frequency Response......................... 20 Hz~20 kHz, +1/-2 dB
(MIX L/R, GROUP, AUX/EFX SEND)
@ 10kΩ
Hum and Noise................................. -128 dBu: Equivalent input noise
(Rs = 150Ω)
......................................... -95 dBu: Residual noise (MAIN L/R,
MONO, MAIN B, GROUP, AUX/EFX OUT)
......................................... -83 dBu: MAIN, MONO, GROUP Master
fader at nominal level and all channel
fader minimum
......................................... -76 dBu: AUX Master control at nominal
level and all channel control minimum
Crosstalk (at 1 kHz).......................... -70 dB between input channels
......................................... -70 dB between input/output channels
(CH INPUT)
Gain Control (Mono Input Channel)...... 44 dB Variable (-50 dB ~ -6 dB),
(-30 dB ~ +14 dB)
Gain (Stereo Input Channel) ............... 40 dB Variable (-20 dB ~ +20 dB)
High-Pass Filter ............................... 75 Hz, 18 dB/Octave
Input Channel Equalization (Mono)...... HIGH: 12 kHz shelving ± 15 dB
......................................... MID: 100~8 kHz peaking ± 15 dB”
......................................... LOW: 80 Hz shelving ± 15 dB
Input Channel Equalization (Stereo)
......................................... HIGH: 12 kHz shelving ± 15 dB
......................................... HI-MID: 3 kHz peaking ± 15 dB
......................................... LO-MID: 500 Hz peaking ± 15 dB
......................................... LOW: 80 Hz shelving ± 15 dB
LED Meters ...................................... 12-point LED x 2 MAIN L/R,
PFL/AFL, GROUP (1~4)
Internal Digital Effects ...................... 2 × 24-BIT DSP, 100 selectable presets
......................................... FOOT switch (ON/OFF)
Channel Indicators ........................... Peak: An indicator for each channel
turns on when the pre-channel fader
signal is 5 dB below clipping.
Phantom Power................................ +48V DC
USB Bus Power ................................ +5V DC 0.5A max USB A-TYPE FEMALE
Power Source / Power Consumption .... AC 120V/230V/240V, 50/60Hz
......................................... L2400: 60W
Dimensions (W × D × H) .................... 31.5˝ × 6.25˝ × 21˝
798mm × 159mm × 533mm
Weight ......................................... 35.6 lbs (16.2 kg)
ARCHITECT’S & ENGINEER’S SPECIFICATIONS
The Samson L2400 shall be a tabletop audio mixer. It shall be
a 24-channel design with 16 channels having XLR mic inputs
and 4 channels being stereo channels, two with XLR’s included.
The XLR Mic channels are equipped with 3 band EQ with
sweepable mids, line input, insert point, mic/line trim control,
75Hz low cut filter, aux 1 and 2 send pre-fader, aux 3 and 4
send with pre/post switch, EFX 1 and 2 send to the 2 internal
24 bit DSP effects units with EFX bypass switch to send to
aux 5 and 6 outputs, pan, solo, lighted mute, 60mm fader,
buss 1-2 switch, bus 3-4 switch and main mix routing switch.
Two of the stereo channels shall have 4 band fixed frequency
EQ, line input on 2 – 1⁄4 inch jacks, mic/line trim control, XLR
mic inputs, aux 1 and 2 send pre-fader, aux 3 and 4 send with
pre/post switch, EFX 1 and 2 send to the 2 internal 24 bit DSP
effects units with EFX bypass switch to send to aux 5 and 6
outputs, pan, solo, lighted mute, 60mm fader, buss 1-2 switch,
bus 3-4 switch and main mix routing switch. The other two
stereo channels have stereo RCA inputs instead of the added
mic inputs. The main section shall have 6-1⁄4 inch outputs
for the 6 aux sends with level controls and PFL switches plus
EFX out 1 and 2 on 1⁄4 inch jacks with level controls and PFL
switches. Aux return 1 and 2 shall be stereo returns on 1⁄4
inch jacks with level controls, PFL, and level controls to send
to aux 1, 2, and a shift button to send to aux 3,4. The L2400
shall have a stereo CD/Tape in on RCA jacks with level control
and PFL. It shall have a record out on RCA jacks. There shall
be 4 group outputs on 1⁄4 inch jacks with 4 inserts on TRS
1⁄4 inch jacks controlled by 100mm faders, AFL, pan controls
and assign buttons to main mix. The L2400 shall have a mono
XLR output with insert, AFL, and 100mm fader that can also
be used as a sub-woofer output via a Sub-woofer on/off button
with variable frequency control from 20Hz to 200Hz. The
L2400 shall have 2 internal DSP units with LED indicators for
the 100 presets, routing to aux 1, 2, 3, and 4, bus 1-2, 3-4,
and main mix, lighted effect on buttons, PFL and 100mm
effect return faders. There shall be a rear panel 1⁄4 inch jack
for a footswitch that bypasses the second DSP unit. The main
mix shall have balanced XLR outputs and 1⁄4 inch inserts
controlled by a stereo 100mm fader with AFL switch. There
shall also be a main B rotary control that sends the main mix
to a mix B output on 2- 1⁄4 inch jacks. The L2400 shall have a
front panel headphone output with rotary volume control. There
shall be a global 48V phantom power switch, an LED power
indicator and 12V lamp socket on the top panel. There shall be
2 stereo LED ladders. One to indicate left and right mix or bus
1 and 2 via a push switch, the other indicating PFL and AFL or
bus 3 and 4 via the same push switch. The L2400 shall have
provisions for a talkback mic on an XLR jack with 48V phantom
power. It shall have a level control and routing on switches to
aux 1-2, 3-4, group 1-2, 3-4 and main mix. The L2400 shall
have a USB interface. It shall stream a stereo mix either from
the main mix or from aux 1-2 via a top panel switch. The USB
can signal can be returned to either the main mix or to channel
23-24 via a top panel switch. The USB signal coming back to
the mixer can also be routed to the headphone section via a top
panel switch. The mixer shall have an internal power supply and
a rear panel IEC connector.

L2400
PRODUCT SPECIFICATION SHEET
SERIES DESCRIPTION CATEGORY
L SERIES 4-BUS MIXING CONSOLE MIXERS
