Samsung AC BNPDKH Series User manual

Air conditioner
Installation manual
AC***BNPDKH / AC***BXPD*H
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this installation manual carefully and retain it for future
reference.
ki]_TXX_[YhTWWptwhjGtl|luUGGGX YWYYTW\TY\GGG㝘㤸G_a\_aZ[

2English
Contents
Safety Information 3
Installation Procedure 6
Step 1 Choosing the installation location 6
Step 2 Unpacking 9
Step 3 Checking and preparing accessories 9
Step 4 Drilling a hole through a wall 9
Step 5 Taping the pipes, cables, and drain hose 9
Step 6 Connecting the refrigerant pipes 10
Step 7 Optional: Cutting and flaring the pipes 12
Step 8 Connecting the powerand communication cables 12
Step 9 Optional: Extending the power cable 16
Step 10 Checking the earthing 18
Step 11 Performing gas leakage test 18
Step 12 Evacuating the air 19
Step 13 Charging the refrigerant 19
Step 14 Fixing and insulating the connection part for refrigerant pipes 21
Step 15 Installing and connecting the drain hose 21
Step 16 Performing drainage test 22
Step 17 Checking the earthing 22
Step 18 Performing the final check and trial operation 23
Step 19 Pumping down refrigerant 27
Appendix 28
Troubleshooting 28
COMMISSION DELEGATED REGULATION (EU) No 626/2011 i)
PRODUCT FICHE (ENERGY LABELLING OF AIR CONDITIONERS) ii) 30
ki]_TXX_[YhTWWptwhjGtl|luUGGGY YWYYTW\TY\GGG㝘㤸G_a\_aZ\

3
English
Safety Information
Safety Information
Carefully follow the precautions listed as below because they
are essential to guarantee the safety of SAMSUNG product.
WARNING
• Always disconnect the air conditioner from the power
supply before servicing it or accessing its internal
components.
• Verify that installation and testing operations are
performed by qualified personnel.
• Verify that the air conditioner is not installed in an
easily accessible area.
General information
• Carefully read the content of this manual before
installing the air conditioner and store the manual in a
safe place in order to be able to use it as reference after
installation.
• For maximum safety, installers should always carefully
read the following warnings.
• Store the manual in a safe location and remember to
hand it over to the new owner if the air conditioner is
sold or transferred.
• This manual explains how to install an indoor unit with
a split system with two SAMSUNG units. The use of
other types of units with different control systems may
damage the units and invalidate the warranty. The
manufacturer shall not be responsible for damages
arising from the use of non compliant units.
• The manufacturer shall not be responsible for damage
originating from unauthorized changes or the improper
connection of electric and hydraulic lines. Failure to
comply with these instructions or to comply with the
requirements set forth in the “Operating limits” table,
included in the manual, shall immediately invalidate
the warranty.
• The air conditioner should be used only for the
applications forwhich it has been designed: the indoor
unit is not suitable to be installed in areas used for
laundry.
• Do not use the units if damaged. If problems occur,
switch the unit off and disconnect it from the power
supply.
• In order to prevent electric shocks, fires or injuries,
always stop the unit, disable the protection switch
and contact SAMSUNG’s technical support if the unit
produces smoke, if the power cable is hot or damaged
or if the unit is very noisy.
• Always remember to inspect the unit, electric
connections, refrigerant tubes and protections
regularly. These operations should be performed by
qualified personnel only.
• The unit contains moving parts, which should always be
kept out of the reach of children.
• Do not attempt to repair, move, alter or reinstall the
unit. If performed by unauthorized personnel, these
operations may cause electric shocks or fires.
• Do not place containers with liquids or other objects
on the unit.
• All the materials used for the manufacture and
packaging of the air conditioner are recyclable.
• The packing material and exhaust batteries of the
remote control (optional) must be disposed of in
accordance with current laws.
• The air conditioner contains a refrigerant that has to be
disposed of as special waste. At the end of its life cycle,
the air conditioner must be disposed of in authorized
centers or returned to the retailer so that it can be
disposed of correctly and safely.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, without supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
• Wear protective equipment (such as safety gloves,
goggles, and headgear) during installation and
maintenance works. Installation/repair technicians
may be injured if protective equipment is not properly
equipped.
• For use in Europe: This appliance can be used by
children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
ki]_TXX_[YhTWWptwhjGtl|luUGGGZ YWYYTW\TY\GGG㝘㤸G_a\_aZ\

4English
Safety Information
Safety Information
Installing the unit
IMPORTANT: When installing the unit, always rememberto
connect first the refrigerant tubes, then the electrical lines.
Always disassemble the electric lines before the refrigerant tubes.
• Upon receipt, inspect the product to verify that it has not been
damaged during transport. If the product appears damaged,
DO NOT INSTALL it and immediately report the damage to the
carrier or retailer (if the installer or the authorized technician
has collected the material from the retailer).
• Aftercompleting the installation, always carry out a functional
test and provide the instructions on how to operate the air
conditionerto the user.
• Do not use the airconditionerin environments with hazardous
substances or close to equipment that release free flames to
avoid the occurrence of fires, explosions orinjuries.
• Ourunits must be installed in compliance with the spaces
indicated in the manual to ensure either accessibility from both
sides or ability to perform routine maintenance and repairs.
The units’ components must be accessible and that can be
disassembled in conditions of complete safety eitherfor people
orthings. Forthis reason, where it is not observed as indicated
into the manual, the cost necessary to reach and repairthe
unit (in safety, as required by current regulations in force) with
slings, trucks, scaffolding orany othermeans of elevation won’t
be considered in-warranty and charged to end user.
Power supply line, fuse or circuit breaker
• Forthis reason, when provisions of the installation manual
are not complied with, the cost required to access and repair
the units (in SAFETY CONDITIONS, as set out in prevailing
regulations) with harnesses, ladders, scaffolding orany other
elevation system will NOT be considered part of the warranty
and will be charged to the end customer.
• Always make sure that the powersupply is compliant with
current safety standards. Always install the airconditioner in
compliance with current local safety standards.
• Always verify that a suitable grounding connection is available.
• Verifythat the voltage and frequency of the power supply
complywith the specifications and that the installed power
is sufficient to ensure the operation of any other domestic
appliance connected to the same electric lines.
• Always verify that the cut-off and protection switches are
suitably dimensioned.
• Verifythat the airconditioneris connected to the powersupply
in accordance with the instructions provided in the wiring
diagram included in the manual.
• Always verify that electric connections (cable entry, section
of leads, protections…) are compliant with the electric
specifications and with the instructions provided in the wiring
scheme. Always verifythat all connections comply with the
standards applicable to the installation of air conditioners.
CAUTION
• Make sure that you earth the cables.
– Do not connect the earth wire to the gas pipe, water pipe,
lighting rod ortelephone wire. If earthing is not complete,
electric shock orfire may occur.
• Install the circuit breaker.
– If the circuit breaker is not installed, electric shock orfire
may occur.
• Make sure that the condensed water dripping from the drain
hose runs out properly and safely.
• Install the power cable and communication cable of the indoor
and outdoor unit at least 1m away from the electric appliance.
• Install the indoorunit away from lighting apparatus using
the ballast.
– If you use the wireless remote control, reception error
may occur due to the ballast of the lighting apparatus.
• Do not install the airconditionerin following places.
– Place where there is mineral oil or arsenic acid. Resin parts
flame and the accessories maydrop orwatermay leak.
The capacity of the heat exchangermay reduce orthe air
conditioner may be out of order.
– The place where corrosive gas such as sulfurous acid gas
generates from the vent pipe orairoutlet. The copperpipe
or connection pipe may corrode and refrigerant may leak.
– The place where there is a machine that generates
electromagnetic waves. The air conditioner may not
operate normally due to control system.
– The place where there is a dangerof existing combustible
gas, carbon fiberorflammable dust. The place where thinner
or gasoline is handled. Gas may leak and it may cause fire.
• Be sure not to perform power cable modification, extension
wiring, and multiple wire connection.
– It may cause electric shock orfire due to poor connection,
poor insulation, or current limit override.
– When extension wiring is required due to powerline
damage, referto "Step 9 Optional: Extending the power
cable" in the installation manual.
ki]_TXX_[YhTWWptwhjGtl|luUGGG[ YWYYTW\TY\GGG㝘㤸G_a\_aZ\

5
English
Safety Information
Checking auxiliary power switch
ON
1 phase circuit breaker 3 phase 4 wire circuit
breaker
Turn on the auxiliary power switch which is installed separately.
NOTE
Auxiliary power switch (ELCB, ELB)
• Auxiliary power switch is not included in the package. Purchase and install it separately.
• Auxiliary power switch is a device for preventing over-current or short circuit. Turn off the auxiliary power switch when
you are cleaning the product or not going to use the product for long period of time.
• If ELB has already been installed in the switch box of the building, it is not mandatory for you to install the auxiliary
power switch.
Operating temperature and humidity
Mode Outdoor temperature Indoor temperature Indoor humidity
Cool mode -15°C to 50°C 18°C to 32°C 80% or less
Heat Mode -20°C to 24°C 30°C or less -
Dry mode -15°C to 50°C 18°C to 32°C 80% or less
CAUTION
• If you use the air conditioner at a relative humidity above 80%, it may cause a formation of condensation and a leakage
of water on the floor.
• If the indoor unit is out of the operating temperature and humidity range, the safery device may operate and the air
conditioner may stops.
Operation Features
ki]_TXX_[YhTWWptwhjGtl|luUGGG\ YWYYTW\TY\GGG㝘㤸G_a\_aZ\

6English
Installation Procedure
Step 1 Choosing the installation
location
Determine the installation location considering the following
conditions and obtain the user approval.
Indoor unit
• Install the unit where the pipes and cables can be easily
connected to the outdoor unit.
• Install the unit where there are no obstacles against
the wind around the air intake and air outlet.
• Install the unit on a flat and stable surface that
can hold the unit’s weight. Otherwise, the unit may
generate noise and vibrations.
• Do not install the unit near highly frequented doors and
passages.
• Do not install the unit in a location exposed to direct
sunlight.
Top view Side view
<Cornerinstallation>
<Wall installation>
More than 60 cm
More than 50 cm
Airoutlet
Airintake
More than100 cm
Outdoor unit
• Install the unit where it will not experience oil leakages, salt
collection, gas exposure, orsulfide gas risk, and keep it and safe
from otherdangers.
• Install the unit where does not disturb yourneighbors as they
may be affected by the noise or airflow coming from the unit.
• Install the unit where no rainwater can collect on ornear it.
• Install the unit in a well-ventilated location away from direct
sunlight or strong winds.
• Install the unit where the pipes and cables can be easily
connected to the indoorunit.
• Maintain sufficient space for repairs and service.
• Make sure that condensed waterdripping from the drain hose is
directed away safely.
• If there is any unavoidable reason to install the unit at
such a place, take the following measures:
– When installing the unit at a roadside concentrated with
buildings, install it parallel to the road.
– Install the unit so that the air outlet faces the wall such
as rooftop that may be subjected to strong wind.
Strong wind
Rooftop
• When installing the outdoor unit near the seashore,
make sure that it is not directly exposed to sea breeze.
If you cannot find an adequate place, a protection wall
should be constructed.
– Install the outdoorunit at a place (such as neara
building) where it can be protected from sea breeze.
Failure to do so may cause damage to the outdoor unit.
Sea breeze Sea breeze
OutdoorUnit Outdoor Unit
Sea Sea
• If you cannot avoid a place nearthe seashore, construct a
protection wall around the outdoor unit.
Sea
Sea breeze
OutdoorUnit
Protection wall
• Construct a protection wall made of solid material such as
concrete to block sea breeze. Make sure that its height andwidth
are1.5 times greaterthan the size of the outdoorunit. In addition,
secure a space largerthan 600 mm between the protection wall
and the outdoor unit for exhausted air to ventilate.
• Install the unit at a placewherewatercan drain smoothly.
• If you have anydifficulty in finding an installation location, contact
yourmanufacturer.
• Be sure to clean sea waterand dust on the heat exchangerof the
outdoorunit and applya corrosion inhibitoron it (at least once
in a year).
Installation Procedure
ki]_TXX_[YhTWWptwhjGtl|luUGGG] YWYYTW\TY\GGG㝘㤸G_a\_aZ\

7
English
Installation Procedure
Outdoorunit installation request
• The suggested space is based on the outdoortemperature
of 35°C while in operation. If the outdoortemperature is
higherthan 35°C, secure more space.
• Be sure to secure sufficient clearance for a person and air
flow passage.
• See the clearances and dimensions in Minimum clearances
forthe outdoor unit (page 7) when installing the
outdoor unit.
• If you install multiple outdoorunits in the same place, be
sure to secure enough space for ventilation and free airflow.
• If the space forventilation is insufficient, the air conditioner
may not perform well as designed.
• Check the condition of the product periodically.
– Check the installation site every 3 months and
perform anti-corrosion treatment such as R-Pro
supplied by SAMSUNG (Code: MOK-220SA) or
commercial water repellent grease and wax, etc.,
based on the product condition.
– When the product is to be shut down for a long
period of time, such as off-peak hours, take
appropriate measures like covering the product.
• If the product installed within 500m of seashore, special
anti-corrosion treatment is required.
࢜Please contact your local SAMSUNG representative for
further details.
Minimum clearances forthe outdoorunit
When installing 1 outdoor unit
(Unit: mm)
300 ormore
1500 ormore
300 ormore
300 or
more 600 or more
1500 ormore
2000 or
more
600 ormore
300 or
more
300 ormore
1500 ormore
When installing more than 1 outdoor unit
(Unit: mm)
1500 or
more 3000 or more 3000 or more 300 or
more
600 or
more
300 or
more 600 or
more 600 or more 600 or
more
300 ormore
1500 or
more
300 ormore
1500 ormore
600 or
more
600 or
more
500 or
more
300 or
more
300 or
more
500 or
more
ki]_TXX_[YhTWWptwhjGtl|luUGGG^ YWYYTW\TY\GGG㝘㤸G_a\_aZ]

8English
Installation Procedure
Installation Procedure
WARNING
• Should adopt bar type louver. Don’t use a type of rain
resistance louver.
[Bartype louver] [Rain resistance louver]
• Louver specifications.
– Angle criteria : less than 20°
– Opening ratio criteria : greater than 80%
WARNING
• After installing the outdoor unit, apply rust inhibitor on
the internal pipes and heat exchanger.
– Airborne corrosive gas such as sulfur compounds,
hydrogen sulfide, and ammonia, or salty dust may
cause pipe corrosion. This corrosion may result in
refrigerant leakage.
– Inspect the outdoor unit at least once a year and
re-apply the rust inhibitorwhere it is damaged or
worn out.
• When applying rust inhibitor, be sure to follow the
instructions below:
– Turn off the power before spraying the rust
inhibitor.
– Wear protective goggles and a mask in advance.
– Clean the dusty surface with clean fabric or paper
before spraying the inhibitor.
– Make sure that wind is blowing from behind the
worker.
– Do not spray on the PCB panel and electric parts.
CAUTION
• Install the indoor unit away from any interference,
such as radios, computers, and stereo devices, and
also select the place where the electrical wiring work
is possible.
– Keep the unit at least 3 m away from electronic
devices that generate electromagnetic waves, and
install a protection tube for the main power cable
and communication cable.
– Make sure that there is no device that can generate
electromagnetic waves. Otherwise, a malfunction
of the control system may occur. For example, the
indoor unit remote control sensor may not properly
receive signals near fluorescent lamps because of
interference.
• Be sure to install the outdoor unit in a safe place
where it is not affected by snowfall. The frame should
be installed in a place where the air inlet and heat
exchanger of the unit are not buried under snow.
• A ventilation system is required when the outdoor unit
is installed in a closed space or room, even though
R-410A is not poisonous or flammable.
• Install the railing around the outdoor unit to prevent
falling when installed at a high place.
• Avoid installation near exhaust pipes and ventilating
openings exposed to corrosive gas, sulfur oxide,
ammonia, or sulfur gas herbicide. Installations near
these places require anticorrosive treatments. Contact
the manufacturer to avoid corrosion of copper pipes or
soldered parts.
• Depending on the power supply, electric noise or
unstable voltage may happen after malfunctions of the
electrical parts or the control system particularly on
ships or other places using generators.
Fixing the outdoorunit in place
Fix the outdoorunit with anchor bolts. Make sure that the
anchor bolts are 20 mm or higher from the base surface.
Anchorbolt hole
330
360
620
940
384
(Unit: mm)
CAUTION
• Install a drain outlet at the lowest end around the base
for the outdoor unit drainage.
• When installing the outdoor unit on the roof,
waterproof the unit and check ceiling strength.
ki]_TXX_[YhTWWptwhjGtl|luUGGG_ YWYYTW\TY\GGG㝘㤸G_a\_aZ]

9
English
Installation Procedure
Step 2 Unpacking
Unpacking the indoor unit
1 Open the indoor unit package.
2 Remove the top and middle cushions.
3 Remove the bottom cushion.
Unpacking the outdoor unit
1 Pull out the outdoor unit from the package.
2 Remove the top cushion.
3 Remove the 4 screws from the wooden pallet.
4 Remove the wooden pallet.
Step 3 Checking and preparing
accessories
The following accessories are supplied with the air
conditioner. Their type and quantity may differ depending on
the specifications.
Accessories in the indoor unit package
Fixing bracket for indoor unit (1) Remote control (1)
MANUAL (2) Remote control holder (1)
Batteries for remote control (2) Insulation for piping(1)
M4 X L12 screws (4) M4 X L14 screws (4)
Pipe outlet protection rubber(1) Insulation fordrain hose (1)
Accessories in the outdoorunit package
Drain cap (3) Drain plug out (1)
Rubber leg (4)
Step 4 Drilling a hole through a wall
1 Determine the position of a 60 to 65 mm hole considering
possible directions of the pipe bundle and minimum
distances between the hole and installation plate.
2 Drill the hole that slopes slightly downward (15°).
Indoorunit
Outdoor
Ø 60~65 mm
Step 5 Taping the pipes, cables, and
drain hose
1 Wrap the refrigerant pipes with the provided insulation.
This wrapping minimises condensation.
Insulation
Refrigerant pipes
ki]_TXX_[YhTWWptwhjGtl|luUGGG` YWYYTW\TY\GGG㝘㤸G_a\_aZ]

10 English
Installation Procedure
Installation Procedure
2 Wind the refrigerant pipes, powercable, communication
cable, and drain hose with vinyl tape to make a pipe
bundle.
Pipe insulator
Vinyl tape
Drain hose
Indoor/outdoor unit
communication cable
NOTE
• Be sure to insulate the pipes without gaps or cracks,
and use adhesive between the connecting parts of the
insulation to prevent moisture from entering.
• When bending the pipe, try to secure a large bending
radius (over100 mm) to prevent the copper pipe from
distorting.
• Use the polyethylene or EPDM foam insulation with a
thickness over 7 mm.
• If pipes are installed in a place with humidity over 80%
(such as in a building site pit, basement, seashore, near
hot springs, or lakes), use an insulation of a thickness
over10 mm.
• Make sure that the thickness of the insulation does not
get thinner on the pipe's bending area.
• When the insulation thickness becomes thinner, use
extra insulation to maintain thickness.
• When installing the pipe hanger, use extra PE- foam
insulation (over 5 mm) to make the width of the
insulation 3 times wider than the hanger. Do not use
cable ties as a pipe hanger.
Step 6 Connecting the refrigerant
pipes
Items Maximum allowable length
Outdoor unit models AC100BXPDKH AC140BXPDNH
Main pipe (L1) 50 m 75 m
Max. height difference
between outdoorand indoor
units (h1)
30 m 30 m
n=1
øࠁ
˵ࠁ
Outdoor
Indoor
• Temper grade and minimum thickness of the
refrigerant pipe
Outer diameter [mm] Minimum thickness [mm] Temper grade
ø6.35 0.7
C1220T-O
ø9.52 0.7
ø12.70 0.8
ø15.88 1
ø15.88 0.8 C1220T-1/2H OR
C1220T-H
ø19.05 0.9
ø22.23 0.9
1 Connect each assembly pipe to the appropriate valves on
the indoor and outdoor units and fasten the flare nuts.
2 As depicted in the illustration below, tighten the flare
nut manually, and then apply the following torque with a
torque wrench.
Indoor unit
Liquid side service valve Gas side service valve
ki]_TXX_[YhTWWptwhjGtl|luUGGGXW YWYYTW\TY\GGG㝘㤸G_a\_aZ]

11
English
Installation Procedure
Outdoor unit
Liquid Gas
D
A
Flare
Pipe
OuterDiameter (D, mm) Fastening torque (N·m) Depth (A, mm)
6.35 14 to 18 1.3
9.52 34 to 42 1.8
12.7 49 to 61 2
15.88 68 to 82 2.2
19.05 100 to 120 2.2
WARNING
• During installation, make sure that there is no gas
leakage. When collecting refrigerant, first stop the
compressor. If the refrigerant pipe is not properly
connected and compressor runs with the service valve
open, the pipe takes in air and the pressure rises, which
may cause explosion or injury.
CAUTION
• Be sure to use C1220T-1/2H (Semi-hard) pipe for bigger
than Ø19.05 mm. If you use C1220T-0(Soft) for bigger
than Ø19.05 mm, the pipe may be broken, which can
result in an injury.
Make at least one round:
It will reduce noise and vibration
Afterconnectiong
the pipes, block
the part .
(A) Heat radiation holes
Do not block the holes.
• The appearance of the unit may be different from the
diagram depending on the model.
CAUTION
Pipe outlet
• Cut the pipe outlet to the exact pipe size. In addition,
remove foreign substances and burres aroud the outlet.
•ťʪθ˙ͱθʀЇϩϩ˝иϩ˵ͱцɇʀЇϩϩʪθ࣑ʪу࢏ΧΧʪθ࣒ɇʒ
never tap with a hammer near the pipe outlet.
Otherwise, it may cause product damage such as
warping of the cabinet.
• After connecting the pipes with Pipe outlet, plug the
space around the pipes.
• After connecting the pipes, proceed exactly as directed
in the guide to prevent interference with the internal
parts.
• Tighten the nuts to the specified torques. If
overtightened, the nuts could be broken so refrigerant
may leak.
• Protect or enclose refrigerant tubing to avoid
mechanical damage.
• After installing pipes, block the unused knock hole
to prevent small animal from entering. However, the
radiant heat hole(A) should be able to intake air.
ki]_TXX_[YhTWWptwhjGtl|luUGGGXX YWYYTW\TY\GGG㝘㤸G_a\_aZ^

12 English
Installation Procedure
Installation Procedure
Step 7 Optional: Cutting and flaring
the pipes
1 Make sure that you have the required tools; pipe cutter,
reamer, flaring tool, and pipe holder.
2 If you want to shorten the pipes, cut it with a pipe cutter,
making sure that the cut edge remains at a 90° angle to
the side of the pipe. See the illustrations below for the
correct edge cut.
90° Oblique Rough Burr
3 To prevent gas leakage, remove all burrs at the cut edge
of the pipe with a reamer.
Pipe
Reamer
4 Slide a flare nut onto the pipe.
5 Modify the flare with a flaring tool.
Flaring tool
6 Check that the flaring has been properly made, referring
to the illustrations below.
Correct Inclined Damaged
Surface Uneven Thickness
Cracked
Step 8 Connecting the power and
communication cables
CAUTION
• Always remember to connect the refrigerant pipes
before performing the electric connections.
When disconnecting the system, always disconnect the
electric cables before disconnecting the refrigerant
pipes.
• Always remember to connect the air conditioner to
the grounding system before performing the electric
connections. Use a crimp ring terminal at the end of
each wire.
Electrical work must be done by the certified personnel.
• Wiring work should be performed in compliance with
related regulations following technical specifications
and installation guide.
• Be sure to install an exclusive power supply. If you use a
power strip for multiple electrical connections, there is
a risk of electric shock or fire.
• Be sure to install a circuit breaker with a rated current
sensitivity of over 30 mA.
• Fasten the screws on the terminal block to be within
the rated range and so that they do not loosen.
• Be sure to connect the ground wire. Install the power
wire and make sure it is shorter than 50 m. If the length
of the powerwire exceeds 50 m, the product may not
work properly or the wire may be damaged.
1 Remove the screw on the electrical component box and
remove the cover plate.
2 Route the cables through the sides orback of the indoor
unit and then connect them to the terminals noting the
figure below.
3 Route the otherend of the cable to the outdoor unit
through the ceiling & the hole on the wall.
4 Reassemble the electrical component box cover, carefully
tightening the screw.
ki]_TXX_[YhTWWptwhjGtl|luUGGGXY YWYYTW\TY\GGG㝘㤸G_a\_aZ^

13
English
Installation Procedure
AC100BNPDKH (1-phase)
IndoorUnit
OutdoorUnit
Cable clamp
1(L)
1(L)
2(N)
2(N)
F1
L
F2
N
DC12V
Communication
F1/F2
Wi-Fi Kit Connection
V1/V2 Connector
Indoor power
cable
Main power
cable
Cable tie
Communication
cable
AC140BNPDKH (3-phase)
IndoorUnit
OutdoorUnit
Cable clamp
1(L)
1(L)
2(N)
2(N)
F1
L1(R)
F2
L2(S) LN
DC12V
Communication
F1/F2
Wi-Fi Kit Connection
Indoor power
cable Main power
cable
Cable tie
Communication
cable
V1/V2 Connector
NOTE
• DC12V Connection forWi-Fi Kit: Cut the wires of the V1/V2
connector and then connect the wires to the Wi-Fi Kit.
• Indoor does not support wire remote controller.
Outdoor-to-indoor power and communication
cables specifications
Indoor power supply
Power supply Max/Min (V) Indoor power cable
ߣףࡥߤߤߢࣛߤߦߢǤࡥߧߢࢩߨߢ²і ±10% ߢ࢏ߩߧࠌࡥߥиθʪϑ
Communication cable
0.75 mm², 2 wires
NOTE
• For outdoor use, the power supply cords of
the appliances must not be lighter than the
polychloroprene sheathed flexible cord. (Code
designation IEC: 60245 IEC 57 / CENELEC: H05RN-F or
IEC: 60245 IEC66 / CENELEC H07RN-F)
• When installing the indoor unit in a computer room
or net work room, use the double shielded (tape
aluminium / polyester braid + copper ) cable of
FROHH2R type.
CAUTION
• Use rated cables or products only, with heat resistance
over105°C, as well as properly rated switches or fuses
in the cabinet panel.
• Make sure that the cables connected do not produce
sparks around the auxiliary power switch or that they
are not installed in a place subject to high temperature.
High ambient temperature decreases allowable
current.
• Install the auxiliary power switch in a dry place, install
the panel board or electrical component box, and then
install the circuit breaker in the panel board.
• When connecting the main power cable, press the cable
to the terminal for a secure connection.
• Select a ring terminal for use.
R
2
B
B
d1
D
F
L
E
d2 Silversolder
ki]_TXX_[YhTWWptwhjGtl|luUGGGXZ YWYYTW\TY\GGG㝘㤸G_a\_aZ^

14 English
Installation Procedure
Installation Procedure
Thickness of the wire (mm²) B (mm) d2 (mm)
2.5 Less than 9.5 More than 4.5
4.5 Less than 9.5 More than 4.5
6.0 Less than 9.5 More than 4.5
10.0 Less than 15 More than 8.4
Connecting the cable to the powerterminal
Connect the cables to the terminal board with the ring
terminals.
NOTE
• Be sure to use the certified and rated cables and firmly
connect them without applying any external force to
the ring terminal.
• Connect with a driver and wrench that can apply the
rated torque to the screws.
• Connect the terminal screws in compliance with the
rated tightening torques.
• If the terminal is loose, a fire may occur, caused by
arcing electricity. If the terminal is connected too
firmly, the terminal may be damaged.
Screw Ɵ˝˵ϩʪ˝ϩͱθαЇʪ˙ͱθϩʪθɇ࣑˝˙ʀ࣒
M3 5 to 7.5
M3.5 8 to 12
M4 12 to 18
M5 20 to 30
M6 25 to 37.5
R
S
T
N
Solderless ring
terminal
When connecting two cables to a ring terminal, separate the ring terminal
up ordown to prevent it from getting loose. Place the thin cable upward
and the thick cable downward. Fix the powercables with a cable tie.
Cable tie
Thin cable
Thick cable
Connecting the cables
AC100BXPDKH
• This product uses a single phase power, with 220 to
240V supply.
• When connecting the outdoor-to-indoor power cables,
be sure to match the numbers (or letters) between the
outdoor and indoor units. Connect the communication
cable to the connector included in the electrical
component box for each unit. When the outdoor-
to-indoor power cables are connected incorrectly, a
malfunction of the product may occur.
• When connecting the communication and outdoor-to-
indoor power cables, make sure these cables do not
touch the service valve on the refrigerant pipe on the
gas side or the pipes without proper insulation. Fix the
outdoor-to-indoor power cables to the insulated pipes.
• Be sure to comply with the wiring standards, as there
may be a risk of fire.
• Make sure to install the circuit breaker firmly inside the
electrical component box.
Entire system diagram
Communication cable
Outdoor-to-indoor power cable
Main power cable
Electrical panel
NFB Single
phase 220 to
240V, 50 Hz
ELB
Outdoorunit Indoor unit
Earthing
Ground wire
Powerwiring diagram
Outdoor-to-indoor
powercable
1(L) 2(N) L F1 NF2
powersupply cable (Single phase AC 220-240V,
should be purchased on-site)
Communication
cable
Cable tie
ki]_TXX_[YhTWWptwhjGtl|luUGGGX[ YWYYTW\TY\GGG㝘㤸G_a\_aZ^

15
English
Installation Procedure
Indoor and outdoor unit connection diagram
Indoorunit
Outdoorunit
1(L) 2(N) L F1 1(L) 2(N) F1 F1NF2
AC140BXPDNH
• This product uses a 3-phase 4-wire electrical system,
with 380 to 415V supply.
• When connecting the outdoor-to-indoor power cables,
be sure to match the numbers (or letters) between the
outdoor and indoor units. Connect the communication
cable to the connector included in the electrical
component box for each unit. When the outdoor-
to-indoor power cables are connected incorrectly, a
malfunction of the product may occur.
• When connecting the communication and outdoor-to-
indoor power cables, make sure these cables do not
touch the service valve on the refrigerant pipe on the
gas side or the pipes, without proper insulation. Fix the
outdoor-to-indoor power cables to the insulated pipes.
• Make sure to comply with the wiring standards, as
there may be a risk of fire.
• Make sure to install the circuit breaker firmly inside the
electrical component box.
• Install a 3-phase 4-wire circuit breaker.
• When using the power (R, S, T, N) with the NFB
(overcurrent breaker), be sure to connect the main
power cable (R, S, T, N) to the R, S, T and N terminal on
the outdoor unit.
Entire system diagram
Communication cable
Outdoor-to-indoor power cable
Main power cable
Electrical panel
NFB 3phase 4
wires, 380 to
415V, 50 Hz
ELB
Outdoorunit Indoor unit
Earthing
Ground wire
Powerwiring diagram
Outdoor-to-indoor
powercable
1(L) 2(N) L1(R)
F1
L2(S) L3(T) NF2
powersupply cable (Single phase AC 230V,
should be purchased on-site)
Communication
cable
Cable tie
Indoor and outdoor unit connection diagram
Outdoorunit
Indoorunit
1(L) 1(L) 2(N) 2(N) L1(R) F1
F1
L2(S) F2L3(T) NF2
Main power cable specifications
The powercable is not supplied with air conditioner.
• Select the power supply cable in accordance with relevant local and national regulations.
• Wire size must comply with the applicable local and national code.
• Specifications for local wiring power cord and branch wiring are in compliance with local cord.
Model Outdoorunit Input Current (A) Powersupply
Outdoorunit Indoor unit Rated Voltage Range Outdoor(Down_Amp) Indoor Total MCA MFA
Hz Volts Min. Max. Cooling Heating
AC100BXPDKH AC100BNPDKH 50/60 220 ~ 240 198 264 24.0 24.0 2.0 26.0 26.0 30.0
AC140BXPDNH AC140BNPDKH 50/60 380 ~ 415 342 456.5 14.1 14.1 2.0 16.1 16.1 16.1
ki]_TXX_[YhTWWptwhjGtl|luUGGGX\ YWYYTW\TY\GGG㝘㤸G_a\_aZ_

16 English
Installation Procedure
Installation Procedure
NOTE
1 Voltage range
• Units are suitable for use on electrical systems
where voltage supplied to unit terminal is not
below or above listed range limits
2 Maximum allowable voltage variation between phases
is 2%.
3 Wire size & type must complywith the applicable local
and national code.
• Wire size: Based on the value of MCA.
• Wire type: 60245 IEC57(IEC) or H05RN-F(CENELEC)
grade or more.
4 MFA is used to select the circuit breaker and the ground
fault circuit interrupter(earth leakage circuit breaker).
5 MCA represents maximum input current.
• MFA represents capacity which may accept MCA
• Abbreviations
MCA: Min. Circuit Amps. (A)
MFA: Max. Fuse Amps. (A)
6 This equipment complies with IEC 61000-3-12 provided
that the short-circuit power Ssc is greaterthan or equal
to Ssc (*2) at the interface point between the user’s
supply and the public system. It is the responsibility
of the installeror user of the equipment to ensure, by
consultation with the distribution network operator if
necessary, that the equipment is connected only to a
supplywith a short-circuit powerSsc greater than or equal
to Ssc(*2).
MODEL Ssc
AC100BXPDKH 0.42
AC140BXPDNH 3.20
Step 9 Optional: Extending the power
cable
1 Prepare the following tools.
Tools Spec Shape
Crimping pliers MH-14
Connection sleeve (mm) 20 x Ø 6.5 (H x OD)
Insulation tape Width19 mm
Contraction tube (mm) 70 x Ø 8.0 (Lx OD)
2 As shown in the figure, peel off the shields from the
rubber and wire of the power cable.
• Peel off 20 mm of cable shields from the pre-
installed tube.
Power cable
Pre-installed tube
for the power
cable
(Unit: mm)
20 20 20
20 20 20
60
60
120
120
180
180
CAUTION
• For information about the power cable specifications
for indoor and outdoor units, refer to the installation
manual.
• After peeling off cable wires from the pre-installed
tube, insert a contraction tube.
ki]_TXX_[YhTWWptwhjGtl|luUGGGX] YWYYTW\TY\GGG㝘㤸G_a\_aZ_

17
English
Installation Procedure
3 Insert both sides of core wire of the powercable into the
connection sleeve.
• Method 1: Push the core wire into the sleeve from
both sides.
• Method 2: Twist the wire cores together and push it
into the sleeve.
Method1 Method 2
Connection sleeve Connection sleeve
CAUTION
• If cable wires are connected without using connecting
sleeves, their contact area becomes reduced, or
corrosion develops on the outer surfaces of the wires
(copper wires) over a long time. This may cause an
increase of resistance (reduction of passing current)
and consequently may result in a fire.
4 Using a crimping tool, compress the two points and flip
it overand compress anothertwo points in the same
location.
• The compression dimension should be 8.0.
Compression
dimension
• After compressing it, pull both sides of the wire to
make sure it is firmly pressed.
Method1 Method 2
Compress it 4 times.
5 mm 5 mm
Compress it 4 times.
5 Apply heat to the contraction tube to contract it.
Method1 Method 2
Contraction tube Contraction tube
6 Wrap it with the insulation tape twice ormore and
position your contraction tube in the middle of the
insulation tape.
Method1 Method 2
Insulation tape
40 mm 40 mm
Insulation tape
7 Aftertube contraction work is completed, wrap it with the
insulation tape to finish.
Three ormore layers of insulation are required.
Method1 Method 2
Insulation tape Insulation tape
CAUTION
• Make sure that the connection parts are not exposed
to outside.
• Be sure to use insulation tape and a contraction tube
made of approved reinforced insulating materials
that have the same level of withstand voltage with
the power cable. (Comply with the local regulations on
extensions.)
WARNING
• In case of extending the electric wire, please DO NOT
use a round-shaped Pressing socket.
– Incomplete wire connections can cause electric
shock or a fire.
ki]_TXX_[YhTWWptwhjGtl|luUGGGX^ YWYYTW\TY\GGG㝘㤸G_a\_aZ_

18 English
Installation Procedure
Installation Procedure
Step 10 Checking the earthing
If the powerdistribution circuit does not have a earthing or
the earthing does not complywith specifications, an earthing
electrode must be installed. The corresponding accessories
are not supplied with the air conditioner.
1 Select an earthing electrode that complies with the
specifications given in the illustration.
2 Connect the flexible hose to the flexible hose port.
• In damp hard soil ratherthan loose sandy or gravel
soil that has a higher earthing resistance.
• Away from underground structures or facilities,
such as gas pipes, water pipes, telephone lines and
underground cables.
• At least two metres away from a lightening
conductor earthing electrode and its cable.
NOTE
• The earthing wire for the telephone line cannot be used
to ground the air conditioner.
Carbon plastic
50 cm
30 cm
To grounding screw
Steel core
Terminal M4
PVC-insulated
green/yellowwire
3 Finish wrapping insulating tape around the rest of the
pipes leading to the outdoor unit.
4 Install a green/yellow coloured earthing wire:
• If the earthing wire is too short, connect an
extension lead in a mechanical way and wrap it with
insulating tape (do not bury the connection).
• Secure the earthing wire in position with staples.
NOTE
• If the earthing electrode is installed in an area with
heavy traffic, its wire must be connected securely.
5 Carefully check the installation by measuring the earthing
resistance with a earth resistance tester. If the resistance
is above the required level, drive the electrode deeper into
the ground orincrease the numberof earthing electrodes.
6 Connect the earthing wire to the electrical component
box inside of the outdoor unit.
Step 11 Performing gas leakage test
Use nitrogen gas at a pressure range between 0.2 and 4.1 MPa
when testing the gas leakage. If you apply pressure at over 4.1
MPa, the refrigerant pipes may be damaged.
Outdoorunit
Manifold gauge
High pressure side
Low pressure side
Gas
Liquid
1
1
Nitrogen gas
Vacuum
pump
1 Connect the charging hose of low pressure side of
manifold gauge to the packed valve having a service port
as shown at the figure.
NOTE
• The designs and shape are subject to change according
to the model.
2 Open the valve of the low pressure side (A) of the
manifold gauge anticlockwise.
3 Connect the manifold gauge to the nitrogen gas.
4 Apply nitrogen gas.
5 Check the change of pressure with a pressure regulator.
6 Check the gas leakage at the connection part or brazed
part by using soap water.
7 Open the manifold gauge to discharge nitrogen.
ki]_TXX_[YhTWWptwhjGtl|luUGGGX_ YWYYTW\TY\GGG㝘㤸G_a\_aZ_

19
English
Installation Procedure
Step 12 Evacuating the air
1 Connect the manifold gauge to a vacuum pump.
2 Purge the airfrom the system using the vacuum pump for
about 30 minutes.
• Make sure that pressure gauge shows -0.1006 Mpa
after about 30 minutes.
• ƸϑʪɇЭɇʀЇЇΧЇΧϩ˵ɇϩϑɇϩʪɇϑϩߣߦߢএࢩ
capacity.
• Make sure that vacuuming timing is longerwhen
the piping gets longer.
• Pressure will not drop even after 5 minutes of
vacuuming when there is moisture within the pipe.
In this case, apply nitrogen gas again, and then
purge the air again.
Step 13 Charging the refrigerant
Important information regulation regarding
the refrigerant used
This product contains fluorinated greenhouse gases. Do not
vent gases into the atmosphere.
CAUTION
• Ã˙ͱθЇϑʪθ˙ϑцϑϩʪʀͱϩɇϑߧϩAĮࠂʪͱθͱθʪͱ˙
fluorinated greenhouse gases. In this case, it has to
be checked for leakage at least once every12 months,
according to regulation n° 517/2014. This activity has
to be covered by qualified personnel only. In case
ϑϩЇɇϩͱɇɵͱЭʪ࣑ߧϩAĮࠂʪͱθͱθʪͱ˙ŵࣛߦߣߢ࣒ࡥϑϩɇʪθ
(or recognised person which has responsability forfinal
check) has to provide a maintenance book, with all the
information recorded according to REGULATION (EU)
N° 517/2014 OF THE EUROPEAN PARLIAMENT AND OF
THE COUNCIL of 16 April 2014 on certain fluorinated
greenhouse gases.
Please fill in the following with indelible ink on the refrigerant
charge label supplied with the product and on this manual.
• 1: The factory refrigerant charge of the product.
• 2: The additional refrigerant amount charged in the
field.
• 1+ 2: The total refrigerant charge.
Indoorunit Outdoorunit
d
2
1
Unit kg ϩAĮࠂʪ
1, a
2, b
1+ 2, C
Refrigerant type GWP value
R-410A 2088
• GWP= Global Warming Potential
• AɇʀЇɇϩ˝ϩAĮࠂʪࡤ˝уǮťࢩߣߢߢߢ
(Unit: g)
abc
AC100BXPDKH 3000 1000 4000
AC140BXPDNH 3500 2250 5750
1 Measure the quantity of refrigerant depending on the
length of the liquid side pipe.
NOTE
• When the pipe length exceeds the standard pipe length
of 30 m, charge refrigerant according to the increased
length. Do not charge refrigerant by assuming the
quantity through the pressure gauge. When the pipe
length is shorter than the standard, you do not need to
charge refrigerant.
Model name
Refrigerant amount
Standard
(less 30m)
Additional
(over30m)
AC100BXPDKH 3000 50
AC140BXPDNH 3500 50
ki]_TXX_[YhTWWptwhjGtl|luUGGGX` YWYYTW\TY\GGG㝘㤸G_a\_aZ`

20 English
Installation Procedure
Installation Procedure
Indoorunit
Outdoorunit (Scale)
Ref.
Vacuum
pump
Liquid side service valve
Gas side service valve
Manifold gauge
High pressure side
Low pressure side
Open the manifold gauge valve connected to the liquid service
valve and add refrigerant to reach the fixed quantity noting
the scale.
NOTE
• If you cannot add refrigerant when the operation of the
outdoor unit is stopped, open the gas and liquid service
valves and add remaining refrigerant by pressing the
cooling trial operation button.
• After charging, completely open the spindles of the
both the gas and liquid side service valves by rotating
them anti-clockwise. (Do not press them further if the
spindle hits the stopper.)
• Fasten the caps of the service valves for the gas and
liquid pipes including the cap nut of the charging port.
– There may be slight refrigerant leakage when you
open the spindle with a wrench. This is not a failure
of the product.
– Use a wrench that can apply the appropriate force.
Tightening torque forbody cap
(Referto the table)
Spindle
Charging core
R-22: Thread of the screw - 7/16-2OUNF
R-410A: Thread of the screw-1/2-2OUNF
Tightening torque forcharging port cap (Refer to the table)
Outer diameter (mm) Tightening torque
Body cap (N•m) Charging port cap (N•m)
ø 6.35 20 to 25
10 to 12
ø 9.52 20 to 25
ø 12.70 25 to 30
ø 15.88 30 to 35
Over ø 19.05 35 to 40
(1 N•m =10 kgf•cm)
NOTE
• Be extra cautious forthe gas leakage from the 3-way
valve’s stem nuts (gas side), and from the service port
cap.
Pressure table foreach temperature
If extra refrigerant charging is required due to gas leakage or
product relocation, see the following table.
Cooling operation
Unit: [kPa, G]
Indoor temperature (°C)
(Dry bulb /
Wet bulb)
Outdoor temperature (°C)
32/23 27/19 21/15
50 1110 960 820
35 920 750 640
21 830 690 590
7690610560
-15 550 450 400
Heating operation
Unit: [kPa, G]
Indoor temperature (°C)
(Dry bulb /
Wet bulb)
Outdoor temperature (°C)
27/15 20/15 13/10
24 3130 2970 2580
7 2850 2620 2250
-5 2550 2250 1840
-20 2130 1790 1570
NOTE
• Pressure for each temperature was measured at the
gas side service valve.
ki]_TXX_[YhTWWptwhjGtl|luUGGGYW YWYYTW\TY\GGG㝘㤸G_a\_aZ`
