Samsung AM NN1DKH Series User manual

Airconditioner
Usermanual
AM***NN1PEH/AM***NN1DEH/AM***NN1DKH***
•Thank you forpurchasing this Samsung airconditioner.
•Before operating this unit, please read this manual carefullyand retain it forfuture reference.
DB68-07560A-03
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGX YWYWTXYTYXGGG㝘㤸GXXaZ^a\X

2English
Contents
Correct Disposal of This Product
(WasteElectrical& ElectronicEquipment)
(Applicableincountrieswith separatecollectionsystems)
This marking on the product, accessories orliterature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with otherhouseholdwaste at the end of theirworking life. To
prevent possible harm to the environment orhuman health from uncontrolledwaste disposal, please separate these
items from othertypes of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact eitherthe retailerwhere theypurchased this product, ortheir local government office, for
details ofwhere and howthey cantake these items forenvironmentallysafe recycling.
Business users should contacttheirsupplier and checkthe terms and conditions of the purchase contract. This product
and its electronic accessories should not be mixedwith othercommercialwastes fordisposal.
SafetyInformation 3
SafetyInformation 3
AtaGlance 10
IndoorUnit Overview 10
Main parts 10
Operation Features 12
Operating temperature and humidity• Pairing an indoorunit with a remote control 12
Cleaningand Maintenance 13
Cleaning and Maintaining 13
Cleaning the indoorunit exterior• Cleaning the outdoorunit heat exchanger 13
Cleaning the airfilter 14
Periodical maintenance 18
Troubleshooting 19
Technical specifications 23
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGY YWYWTXYTYXGGG㝘㤸GXXaZ^a\X

3
English
SafetyInformation
SafetyInformation
Before usingyournewairconditioner, please read this manual thoroughly
to ensure thatyou knowhowto safelyand efficientlyoperate the extensive
features and functions ofyournewappliance.
Because thefollowing operating instructions covervarious models, the
characteristics of yourairconditionermaydifferslightlyfrom those described in
this manual. Ifyou have anyquestions, callyournearest contact centre orfind
help and information online at www.samsung.com.
WARNING
Hazards orunsafe practices that mayresult in severe personal injuryordeath.
CAUTION
Hazards orunsafe practices that mayresult in minorpersonal injuryorproperty
damage.
Followdirections.
Do NOTattempt.
Make sure the machine is grounded to prevent electric shock.
Cut-off the powersupply.
Do NOTdisassemble.
FORINSTALLATION
WARNING
Usethepowerlinewiththe powerspecificationsofthe productorhigher
andusethe powerlineforthisapplianceonly. In addition,do notuse an
extension line.
• Extendingthe powerline mayresult in electric shock orfire.
• Do not use an electrictransformer. This mayresult in electric shock or
fire.
• If thevoltage/frequency/rated current condition is different, it maycause
fire.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGZ YWYWTXYTYXGGG㝘㤸GXXaZ^a\X

4English
SafetyInformation
SafetyInformation
Theinstallation ofthisappliancemustbe performedbya qualified
technicianorservice company.
• Failing to do so mayresult in electric shock, fire, explosion, problemswith
the product, orinjury.
Installa switchand circuit breakerdedicatedtotheairconditioner.
• Failing to do so mayresult in electric shock orfire.
Fixtheoutdoorunitfirmlysothatthe electricpart oftheoutdoorunit is
notexposed.
• Failing to do so mayresult in electric shock orfire.
Donotinstallthis appliance neara heater,inflammablematerial.Do
notinstallthis appliance ina humid, oilyordustylocation, ina location
exposedtodirectsunlightandwater(raindrops).Donotinstallthis
applianceinalocationwheregasmayleak.
• This mayresult in electric shock orfire.
Neverinstalltheoutdoorunitin alocationsuchas ona highexternalwall
whereitcouldfall.
• If the outdoorunit falls, it mayresult in injury, death orpropertydamage.
Thisappliancemustbe properlygrounded.Donot ground the applianceto
agas pipe,plasticwaterpipe,ortelephoneline.
• Failure to do so may result in electric shock, fire, an explosion, orother
problems with the product.
CAUTION
Installyourapplianceon a level andhardfloorthatcansupport itsweight.
• Failing to do so may result in abnormalvibrations, noise, orproblemswith
the product.
Installthedrainhose properlysothatwaterisdrainedcorrectly.
• Failing to do so mayresult inwateroverflowing and property damage.
Avoid adding drain towaste pipes as odours mayarise in thefuture.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGG[ YWYWTXYTYXGGG㝘㤸GXXaZ^a\X

5
English
SafetyInformation
Wheninstallingtheoutdoorunit, makesure toconnectthedrainhoseso
thatdrainingis performed correctly.
• Thewatergenerated during the heating operation in the outdoorunit
mayoverflowand result in property damage.
In particular, inwinter, if a block of ice falls, it mayresult in injury, death
orpropertydamage.
FORPOWER SUPPLY
WARNING
Whenthecircuitbreakerisdamaged, contactyournearestservicecentre.
Donotpull orexcessivelybendthepowerline.Donottwistortiethe
powerline.Donot hookthepowerlineoverametalobject, placea heavy
objectonthe powerline,insertthe powerlinebetweenobjects, orpush
thepowerlineintothespacebehind the appliance.
• This mayresult in electric shock orfire.
CAUTION
Whennot usingtheairconditionerfora longperiodoftime orduringa
thunder/lightningstorm,cutthepoweratthe circuitbreaker.
• Failing to do so mayresult in electric shock orfire.
FOR USING
WARNING
Iftheapplianceisflooded,pleasecontactyournearestservicecentre.
• Failing to do so mayresult in electric shock orfire.
Iftheappliancegeneratesastrangenoise,a burning smellorsmoke,cut-
offthepowersupplyimmediatelyandcontactthenearestservicecenter.
• Failing to do so mayresult in electric shock orfire.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGG\ YWYWTXYTYXGGG㝘㤸GXXaZ^a\X

6English
SafetyInformation
SafetyInformation
Intheeventof a gasleak(such aspropanegas, LPgas,etc.),ventilate
immediatelywithout touchingthe powerline.Donottouchtheappliance
orpowerline.
• Do not use aventilating fan.
• A spark mayresult in an explosion orfire.
Toreinstalltheairconditioner, pleasecontactyournearestservicecentre.
• Failing to do so mayresult in problemswith the product,waterleakage,
electric shock, orfire.
• A deliveryservice forthe product is not provided. Ifyou reinstall the
product in anotherlocation, additional construction expenses and an
installation fee will be charged.
• Especially,when youwish to install the product in an unusual location
such as in an industrial area ornearthe seasidewhere it is exposed to salt
in the air, please contactyournearest service centre.
Donottouchthecircuitbreakerwithwet hands.
• This mayresult in electric shock.
Donotturnthe airconditioneroffwiththecircuitbreakerwhileit is
operating.
• Turning the airconditioneroff and then on again withthe circuit breaker
maycause a spark and result in electric shock orfire.
Afterunpackingtheairconditioner, keepallpackagingmaterialswell
outofthe reachof children, aspackagingmaterialscan be dangerousto
children.
• If a child places a bag overits head, it mayresult in suffocation.
Donottouchthefrontpanelwithyourhandsorfingers duringtheheating
operation.
• This mayresult in electric shock orburns.
Donotinsertyourfingersorforeign substancesintotheoutletwhenthe
airconditioneris operatingorthefrontpanelisclosing.
• Take special carethat children do not injure themselves byinserting their
fingers into the product.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGG] YWYWTXYTYXGGG㝘㤸GXXaZ^a\Y

7
English
SafetyInformation
Donotinsertyourfingersorforeign substancesintotheairinlet/outletof
theairconditioner.
• Take special carethat children do not injure themselves byinserting their
fingers into the product.
Donotstrikeorpulltheairconditionerwith excessiveforce.
• This mayresult in fire, injury, orproblemswith the product.
Donotplace an objectnearthe outdoorunitthatallowschildren toclimb
ontothemachine.
• This mayresult in children seriouslyinjuring themselves.
Donotusethis airconditionerforlongperiodsoftime inbadlyventilated
locationsornearinfirm people.
• Since this may be dangerous due to a lack of oxygen, open awindowat
least once an hour.
Ifanyforeign substancesuchaswaterhas enteredtheappliance, cut-off
thepowersupplyandcontactthe nearestservicecenter.
• Failing to do so mayresult in electric shock orfire.
Donotattempttorepair,disassemble, ormodifythe applianceyourself.
• Do not use anyfuse (such as copper, steelwire, etc.)otherthan the
standard fuse.
• Failing to do so mayresult in electric shock, fire, problemswith the
product, orinjury.
CAUTION
Donotplace objects ordevicesunderthe indoorunit.
• Waterdripping from the indoorunit mayresult in fire orpropertydamage.
Checkthattheinstallationframeofthe outdoorunitis notbroken atleast
onceayear.
• Failing to do so mayresult in injury, death orpropertydamage.
Maxcurrentismeasuredaccording toIECstandardforsafetyandcurrent
ismeasuredaccording to ISOstandardforenergyefficiency.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGG^ YWYWTXYTYXGGG㝘㤸GXXaZ^a\Y

8English
SafetyInformation
SafetyInformation
Donotstand ontopoftheapplianceorplace objects(such as laundry,
lighted candles,lightedcigarettes, dishes,chemicals, metal objects,etc.)
ontheappliance.
• This mayresult in electric shock, fire, problemswith the product, orinjury.
Donotoperatetheappliancewithwet hands.
• Ɵ˵ϑɇцθʪϑЇϩʪʪʀϩθʀϑ˵ͱʀ࢏
Donotsprayvolatile materialsuchas insecticideontothesurfaceofthe
appliance.
• Aswell as being harmful to humans, it mayalso result in electric shock,
fire orproblems withthe product.
Donotdrinkthewaterfromtheairconditioner.
• Thewatermaybe harmful to humans.
Donotapplya strong impacttotheremotecontrollerand do not
disassembletheremotecontroller.
Donottouchthepipes connectedwith the product.
• This mayresult in burns orinjury.
Donotusethis airconditionertopreserveprecisionequipment,food,
animals,plants orcosmetics,orforanyotherunusual purposes.
• This mayresult in propertydamage.
Avoiddirectlyexposinghumans,animalsorplantstotheairflowfromthe
airconditionerforlongperiodsoftime.
• This mayresult in harm to humans, animals orplants.
Thisapplianceisnot intendedforuse bypersons(includingchildren)with
reduced physical,sensoryormentalcapabilities,orlack ofexperienceand
knowledge, unlesstheyhavebeen givensupervisionorinstructionconcerning
useofthe appliance byaperson responsiblefortheirsafety.Childrenshould
besupervisedto ensurethattheydo not playwiththeappliance.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGG_ YWYWTXYTYXGGG㝘㤸GXXaZ^a\Y

9
English
SafetyInformation
FORCLEANING
WARNING
Donotcleanthe appliancebysprayingwaterdirectlyontoit. Donotuse
benzene,thinner,alcoholoracetoneto cleantheappliance.
• This mayresult in discoloration, deformation, damage, electric shock or
fire.
Before cleaningorperformingmaintenance,cut-offthepowersupplyand
waituntilthefanstops.
• Failing to do so mayresult in electric shock orfire.
CAUTION
Takecarewhencleaningthesurfaceofthe heatexchangeroftheoutdoor
unitsince it hassharp edges.
• To avoid cutting yourfingers,wearthick cotton gloveswhen cleaning it.
• This should be done bya qualified technician please contactyourinstaller
orservice centre.
Donotcleanthe inside oftheairconditionerbyyourself.
• Forcleaning inside the appliance, contactyournearest service centre.
• When cleaning the internal filter, referto the descriptions in the ‘Cleaning
and Maintaining’ section.
• Failure to do may result in damage, electric shock orfire.
• Make sure to prevent anyinjuryfrom sharp edges of the surfacewhen
handling the heat exchanger.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGG` YWYWTXYTYXGGG㝘㤸GXXaZ^a\Y

10 English
AtaGlance
IndoorUnitOverview
Mainparts
The indoorunit and its displaymay look slightlydifferent from the illustration shown below,
depending on the model and the paneltype.
PC1*WFMAN/ PC1*WCMAN
02
01
04
05
03
01 Display
02 Remote control sensor
03 Airflowblade
04 Wind-Free panel
(You can use theWind-Free Cooling function
when the Cool, Dry, orFan mode is running.)
(Referto the remote control manualfor
product operation)
05 Airintake
Indication Function
Operation indicator
• Heating and cooling model:
Operation(Blue) / Defrost(Yellow)
• Cooling onlymodel:
Operation indicator
Timerindicator
Fan indicator
Filtercleaning indicator
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGXW YWYWTXYTYXGGG㝘㤸GXXaZ^a\Z

11
English
AtaGlance
PC1NUSMAN/PC1NUPMAN/PC1MWSKAN/PC1NWSMAN/PC1BWSMAN
02
03
04
01
01 Display
02 Airflowblade
03 Panel
04 Airintake
Indication Function
Remote control sensor
Operation indicator
• Heating and cooling model:
Operation(Blue) / Defrost(Yellow)
• Cooling onlymodel:
Operation indicator
Timerindicator
Fan indicator
Filtercleaning indicator
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGXX YWYWTXYTYXGGG㝘㤸GXXaZ^a\Z

12 English
AtaGlance
OperationFeatures
Operatingtemperatureandhumidity
When using the airconditionerfollowthe operating temperature and humidityranges.
Mode Outdoortemperature Indoortemperature Indoorhumidity
Cool mode Depending on the outdoor
unit specifications
18°C to 32°C 80% orless
Heat mode 30°C orless -
Dry mode 18°C to 32°C
CAUTION
• Ifyou use the airconditionerat a relative humidity above 80%, it maycause a formation of
condensation and a leakage ofwateron thefloor.
• The rated heating capacityis based on an outdoortemperature of 7°C. If the outdoortemperature
goes down below 0°C, heating efficiencies may decrease depending on the temperature
conditions.
• If the indoorunit is out of the operating temperature and humidityrange, the saferydevice may
operate and the airconditionermaystops.
Pairinganindoorunitwith a remotecontrol
When using multiple indoorunit,you can control individually pairing remote control and indoorunit.
Set byremote controlwhen the indoorunit is off.
Zone1~4   ࣑ߧϑʪʀ࣒
NOTE
• Afterpush the , have to push within 60 seconds.
• Each indoorunit numbersetting must be set bythe installerwhen installing. Contact service
centre to reset indoorunit number.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGXY YWYWTXYTYXGGG㝘㤸GXXaZ^a\Z

13
English
CleaningandMaintenance
CleaningandMaintaining
Cleaningtheindoorunitexterior
Wipe the surface of the indoorunit with atepid
damp cloth.
Removethe dust accumulated in the narrow
gaps of the product with a soft brush.
CAUTION
• Do not use alkaline detergent, sulphuric
acid, hydrochloric acid, ororganic solvents
(such as thinner, kerosene, and acetone) to
clean the surfaces.
• Do not attach anystickers on the surfaces
because this may cause damage.
• Whenyou cleanthe heat exchangeronthe
indoorunit,you need to disassemble the
indoorunit. Therefore,you must contact the
local service centerforhelp.
Cleaningtheoutdoorunitheatexchanger
Spraywatertocleanthe dust.
CAUTION
• The heat exchangerof the outdoorunit has
sharp edges. Take care when cleaning its
surface.
NOTE
• If it is difficult to clean the heat exchanger
of the outdoorunit, contactthe local service
center.
Before cleaning the indoorunit, be sureto turn off the auxiliarypowerswitch.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGXZ YWYWTXYTYXGGG㝘㤸GXXaZ^a\[

14 English
CleaningandMaintaining
CleaningandMaintenance
Cleaningtheairfilter
CAUTION
• Before cleaning the indoorunit, be sureto turn off the auxiliarypowerswitch.
• Be sureto hold the grille with a hand to prevent dropping fromthe opening of the front grille.
NOTE
• When removing the grill completely, unhookthe safetyhooks on both sides of the grill.
PC1*WFMAN/ PC1*WCMAN / PC1NUSMAN
1 Detaching the airfilter
PUSH
Press the Push signs on thefront panel, then
open the grille.
ťθʪϑϑϩ˵ʪťЇϑ˵ϑ˝ϑ࣑࣒ͱϩ˵ʪɇθ˙ϩʪθ࢏
Grab the handle of the airfilterand pull it out
from the indoorunitwith yourhand.
Pull the airfilterout ofthe indoorunit.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGX[ YWYWTXYTYXGGG㝘㤸GXXaZ^a\\

15
English
CleaningandMaintenance
PC1NUPMAN
Insert a driverat the marked points and open
the front grille.
Press the Push signs on the airfilter.
Grab the handle of the airfilterand pull it out
from the indoorunit.
PC1MWSKAN/PC1NWSMAN/PC1BWSMAN
Insertyourhand into the front grille and pull
out the front grille to open it.
Press the Push signs on the airfilter.
Grab the handle of the airfilterand pull it out
from the indoorunit.
CAUTION
• The grille is connected to the panel. Do not
forciblydetach the grille. If the connection
structure is broken, the grille may fall down,
which maycause an injury.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGX\ YWYWTXYTYXGGG㝘㤸GXXaZ^a\]

16 English
CleaningandMaintaining
CleaningandMaintenance
2 Cleaning the airfilter
Clean the airfilterwith avacuum cleanerorsoft
brush. If dust is too heavy, then rinse itwith
runningwaterand dryit in a ventilated area.
CAUTION
Do not scrub the airfilterwith a brush orother
cleaning utensil. This may damage thefilter.
NOTE
• If the airfilterdries in a humid area, it may
produce offensive odours. Clean it again and
dryit in awell-ventilated area.
• The cleaning period maydifferdepending
on the usage and environmental conditions,
so clean the airfiltereveryweek ifthe air
conditioneris in the dustyarea.
• You can request afiltercleaning service.
Note that it is a charged service.
3 Reassembling the airfilter
To assemble the airfilter, proceed in reverse
orderof detaching.
CAUTION
• If the indoorunit is usedwithout the airfilter,
it maybe damaged due to dust.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGX] YWYWTXYTYXGGG㝘㤸GXXaZ^a\^

17
English
CleaningandMaintenance
4 Resetting the airfilter
Aftercleaning and reassemblingthe airfilter,
be sureto resetthe filter-cleaning reminderas
follows:
• Indoorunitwith thewired remote control:
Press the FilterReset button.
• Indoorunitwith thewireless remote control:
Press the OptionsɵЇϩϩͱͱθ࣑Filter
Reset࣒9˝Χθʪϑϑϩ˵ʪSET button.
NOTE
• Be sure to reset the filter-cleaning reminder
everytime you clean the airfilteralthough
the filterreset indicator( ) does not blink.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGX^ YWYWTXYTYXGGG㝘㤸GXXaZ^a\^

18 English
CleaningandMaintaining
CleaningandMaintenance
Periodicalmaintenance
Unit Maintenance item Interval Requires qualified
technicians
Indoor
unit
Clean the airfilter. At least once a month
Clean the condensate drain pan. Once ayear Required
Clean up the heat exchange. Once ayear Required
Clean the condensate drain pipe. Once every 4 months Required
Replace the remote control batteries. At least once ayear
Outdoor
unit
Clean the heat exchangeron the
outside of the unit. Once every4 months Required
Clean the heat exchangeron the
inside of the unit. Once a year Required
Clean the electric components with
jets of air. Once ayear Required
Verify that all the electric
components are firmly tightened. Once ayear Required
Clean the fan. Once a year Required
Verify that the fan assemblies are
firmlytightened. Once ayear Required
Clean the condensate drain pan. Once ayear Required
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGX_ YWYWTXYTYXGGG㝘㤸GXXaZ^a\^

19
English
CleaningandMaintenance
Troubleshooting
Referto the following chart if the airconditioneroperates abnormally. This maysave time and
unnecessaryexpense.
Problem Solution
The airconditioner
does not operate
immediately afterit
has been restarted.
• Because of the protective mechanism, the appliance does not start
operating immediatelyto keepthe unit from overloading. The air
conditionerwill start in 3 minutes.
The airconditioner
does not operate
at all.
• Check if the powerplug is properly connected.
• Checkwhetherthe auxiliary powerswitch (MCCB, ELB) is turned on.
• If the auxiliarypowerswitch (MCCB, ELB) is turned off, the air
conditionerdoes notwork althoughyou pressthe (Power) button.
• Whenyou cleanthe airconditionerordo not use it foran extended
period of time,turn off the auxiliary powerswitch (MCCB, ELB).
• Afterthe airconditioneris not usedforan extended period of time, be
sureto turn on the auxiliarypowerswitch (MCCB, ELB) 6 hours before
starting operation.
NOTE
• The auxiliary powerswitch (MCCB, ELB) is sold separately.
• Make sure that auxiliarypowerswitch (MCCB, ELB) is installed in
the distribution box insidethe building.
• If the airconditioneris turned off bythe Timed off function, turn on the
airconditioneragain by pressing the (Power) button.
Thetemperature
does not change.
• Checkwhetherthe Fan mode is running. Inthe Fan mode, the air
conditionercontrols the set temperature automatically, and you cannot
change the set temperature.
Warm airdoes not
come out of the air
conditioner.
• Checkwhetherthe outdoorunit is designed forcooling only. In this case,
warm airdoes not come out althoughyou select the Heat mode.
• Checkwhetherthe remote control is designed onlyforcooling only. Use
a remote control that supports both cooling and heating.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGX` YWYWTXYTYXGGG㝘㤸GXXaZ^a\^

20 English
CleaningandMaintaining
CleaningandMaintenance
Problem Solution
The fan speed does
not change.
• CheckwhethertheAuto orDrymode is running. In these modes,the
airconditionercontrols the fan speed automatically, and you cannot
change the fan speed.
Thewireless
remote control
does not operate.
• Checkwhetherthe batteries are discharged. Replacethe batterieswith
newones.
• Make sure that nothing is blocking the remote control sensor.
• Checkwhetheranystrong lighting sources are nearthe airconditioner.
Strong lightwhich comes from fluorescent bulbs orneon signs may
interfere with the remote control.
Thewired remote
control does not
operate.
• Checkwhetherthe indicatoris displayed at the bottom right of the
remote control display. In this case, turn off boththe airconditionerand
the auxiliary powerswitch, andthen contact a service centre.
The airconditioner
is not turned on or
off immediately
withthewired
remote control.
• Checkwhetherthewired remote control is setforgroup control. In this
case,the airconditioners connected to the wired remote control are
turned on oroff sequentially. This operation takes upto 32 seconds.
The Timed on/off
function does not
operate. • Check whetheryou pressed the (SET) button on the remote control
aftersetting the on/off time. Set the on/off time.
The indoorunit
displayblinks
continuously.
• Turn on the airconditioneragain bypressing the (Power) button.
• Turn off and then turn on the auxiliarypowerswitch, and then turn on
the conditioner.
• If the indoorunit displayis still blinking, contact a service centre.
I want to get cooler
air. • Operate the airconditionerwith a electric fan to save energy and enhance the cooling efficiency.
ki]_TW^\]WhTWZpik}tG~GmGX{rluUGGGYW YWYWTXYTYXGGG㝘㤸GXXaZ^a\^
