Samsung AC TNXDKG Series User manual

Air conditioner
Installation manual
AC***TNXDKG
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this Installation manual carefully and retain it for future
reference.
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 1 2020-02-10 오전 11:14:26

2
English
Contents
Safety Information 3
Safety Information 3
Installation 6
Preparation 6
Step 1-1 Choosing the installation location 6
Step 1-2 Checking and preparing accessories and tools 7
Indoor Unit Installation 8
Step 2-1 Attaching the mounting bracket to the wall 8
Step 2-2 Drilling the wall penetration 8
Step 2-3 Connecting the refrigerant pipes 9
Step 2-4 Connecting the power and communication cables 10
Step 2-5 Optional: Extending the power cable 12
Step 2-6 Connecting the drain hose 13
Step 2-7 Taping the pipes, cables, and drain hose 14
Step 2-8 Performing leak test 15
Step 2-9 Commissioning the unit 15
Appendix 26
Troubleshooting 26
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 2 2020-02-10 오전 11:14:27

3
English
Safety Information
WARNING: Read This Manual
• Read and follow all safety information and instructions
before installation, use, or maintenance of this
appliance. Incorrect installation, use, or maintenance
of this appliance can result in death, serious injury, or
property damage. Keep these instructions with this
appliance. This manual is subject to change. For the
latest version, visit www.samsung.com.
Notices and notes
To make you aware of safety messages and highlighted
information, we use the following notices and notes
throughout this manual:
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
IMPORTANT
Information of special interest
NOTE
Supplementary information that may be useful
WARNING: Low burning
velocity material (This
appliance is filled with R-32.)
The user and installer guides
should be read carefully.
The user and installer guides
should be read carefully.
The service guide should be
read carefully.
WARNING
The installation and testing of this appliance must be
performed by a qualified technician.
• The instructions in this manual are not intended as a
substitute for proper training or adequate experience in
the safe installation of the appliance.
Always install the air conditionerin compliance with current
local, state, and federal safety standards.
This unit is a partial unit air conditioner, complying with
partial unit requirements of this International Standard,
and must only be connected to other units that have been
confirmed as complying with corresponding partial unit
requirements of this International Standard.
General information
WARNING
• Carefully read the content of this manual before
installing the air conditioner and store the manual in a
safe place in order to be able to use it as reference after
installation.
• For maximum safety, installers should always carefully
read the following warnings.
• Store the operation and installation manual in a safe
location and remember to hand it over to the new
owner if the air conditioner is sold or transferred.
• This manual explains how to install an indoor unit with
a split system with two SAMSUNG units. The use of
other types of units with different control systems may
damage the units and invalidate the warranty. The
manufacturer shall not be responsible for damages
arising from the use of non compliant units.
• The manufacturer shall not be responsible for damage
originating from unauthorized changes or the improper
connection of electric and requirements set forth in the
“Operating limits” table, included in the manual, shall
immediately invalidate the warranty.
• The air conditioner should be used only for the
applications for which it has been designed: the indoor
unit is not suitable to be installed in areas used for
laundry.
• Do not use the units if damaged. If problems occur,
switch the unit off and disconnect it from the power
supply.
Safety Information
Safety Information
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 3 2020-02-10 오전 11:14:27

4
Safety Information
English
Safety Information
• In order to prevent electric shocks, fires or injuries,
always stop the unit, disable the protection switch
and contact SAMSUNG’s technical support if the unit
produces smoke, if the power cable is hot or damaged
or if the unit is very noisy.
• Always remember to inspect the unit, electric
connections, refrigerant tubes and protections
regularly. These operations should be performed by
qualified personnel only.
• The unit contains moving parts, which should always be
kept out of the reach of children.
• Do not attempt to repair, move, alter or reinstall the
unit. If performed by unauthorized personnel, these
operations may cause electric shocks or fires.
• Do not place containers with liquids or other objects
on the unit.
• All the materials used for the manufacture and
packaging of the air conditioner are recyclable.
• The packing material and exhaust batteries of the
remote controller(optional) must be disposed of in
accordance with current laws.
• The air conditioner contains a refrigerant that has to be
disposed of as special waste. At the end of its life cycle,
the air conditioner must be disposed of in authorised
centres or returned to the retailer so that it can be
disposed of correctly and safely.
• Do not use means to accelerate the defrost operation or
to clean, other than those recommended by Samsung.
• Do not pierce or burn.
• Be aware that refrigerants may not contain an odour.
Installing the unit
WARNING
IMPORTANT: When installing the unit, always rememberto
connect first the refrigerant tubes, then the electrical lines.
• Always disassemble the electric lines before the
refrigerant tubes.
• Upon receipt, inspect the product to verify that it has
not been damaged during transport. If the product
appears damaged, DO NOT INSTALL it and immediately
report the damage to the carrier or retailer (if the
installer or the authorized technician has collected the
material from the retailer.)
• After completing the installation, always carry out a
functional test and provide the instructions on how to
operate the air conditioner to the user.
• Do not use the air conditioner in environments with
hazardous substances or close to equipment that
release free flames to avoid the occurrence of fires,
explosions or injuries.
• Our units should be installed in compliance with the
spaces shown in the installation manual, to ensure
accessibility from both sides and allow repairs or
maintenance operations to be carried out. The
unit’s components should be accessible and easy to
disassemble without endangering people and objects.
For this reason, when provisions of the installation
manual are not complied with, the cost required to
access and repair the units (in SAFETY CONDITIONS,
as set out in prevailing regulations) with harnesses,
ladders, scaffolding or any other elevation system will
NOT be considered part of the warranty and will be
charged to the end customer.
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 4 2020-02-10 오전 11:14:27

5
English
Safety Information
Power supply line, fuse or circuit breaker
WARNING
• Always make sure that the power supply is compliant
with current safety standards. Always install the air
conditioner in compliance with current local safety
standards.
• Always verify that a suitable grounding connection is
available.
• Verify that the voltage and frequency of the power
supply comply with the specifications and that the
installed power is sufficient to ensure the operation of
any other domestic appliance connected to the same
electric lines.
• Always verify that the cut-off and protection switches
are suitably dimensioned.
• Verify that the air conditioner is connected to the power
supply in accordance with the instructions provided in
the wiring diagram included in the manual.
• Always verify that electric connections (cable entry,
section of leads, protections…) are compliant with
the electric specifications and with the instructions
provided in the wiring scheme. Always verify that all
connections comply with the standards applicable to
the installation of air conditioners.
• Devices disconnected from the power supply should
be completely disconnected in the condition of
overvoltage category.
• Be sure not to perform power cable modification,
extension wiring, and multiple wire connection.
‐It may cause electric shock or fire due to poor
connection, poor insulation, or current limit
override.
‐When extension wiring is required due to power
line damage, refer to "Step 2-5 Optional: Extending
the power cable" in the installation manual.
CAUTION
Make sure that you earth the cables.
• Do not connect the earth wire to the gas pipe, water
pipe, lighting rod or telephone wire. If earthing is not
complete, electric shock or fire may occur.
Install the circuit breaker.
• If the circuit breaker is not installed, electric shock or
fire may occur.
Make sure that the condensed water dripping from the drain
hose runs out properly and safely.
Install the powercable and communication cable of the
indoor and outdoor unit at least1m away from the electric
appliance.
Install the indoor unit away from lighting apparatus using
the ballast.
• If you use the wireless remote control, reception error
may occur due to the ballast of the lighting apparatus.
Do not use the indoorunit forpreservation of food
items, plants, equipment, and art works. This may cause
deterioration of their quality.
Do not install the indoorunit if it has any drainage problem.
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 5 2020-02-10 오전 11:14:27

6
English
Installation
Step 1-1 Choosing the installation
location
Installation location requirements
• There must be no obstacles near the air inlet and
outlet.
• Install the indoor unit on a ceiling that can support its
weight.
• Maintain sufficient clearance around the indoor unit.
• Before installing the indoor unit, be sure to check
whether the chosen location is well-drained.
WARNING
• If appliances contain R-32 refrigerant, then the floor
area of the room in which the appliances are installed,
operated and stored must be larger than the minimum
floor area defined in table below A (m²).
Minimum required room area (A, m²)
m (kg) Wall-mounted type
≤ 1.842 No requirement
1.843 4.45
1.9 4.58
2.0 4.83
2.2 5.31
2.4 5.79
2.6 6.39
2.8 7.41
3.0 8.51
3.2 9.68
3.4 10.9
3.6 12.3
3.8 13.7
4.0 15.1
4.2 16.7
4.4 18.3
4.6 20.0
4.8 21.8
5.0 23.6
• m : Total refrigerant charge in the system
• A : Minimum required room area
• IMPORTANT: it’s mandatory to consider either the table
1 or taking into consideration the local law regarding
the minimum living space of the premises.
• Minimum installation height of indoor unit is 0.6 m for
floor mounted, 1.8 m for wall, 2.2 m for ceiling.
CAUTION
Do not install the airconditioner in following places.
• The place where there is mineral oil or arsenic acid.
Resin parts flame and the accessories may drop or
water may leak. The capacity of the heat exchanger may
reduce or the air conditioner may be out of order.
• The place where corrosive gas such as sulfurous
acid gas generates from the vent pipe or air outlet.
The copper pipe or connection pipe may corrode and
refrigerant may leak.
• The place where there is a machine that generates
electromagnetic waves. The air conditioner may not
operate normally due to control system.
• The place where there is a danger of existing
combustible gas, carbon fiber or flammable dust.
• The place where thinner or gasoline is handled. Gas
may leak and it may cause fire.
• The place where animals may urinate on the product.
Ammonia may be generated.
• The place where is close to heat sources.
Preparation
Installation
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 6 2020-02-10 오전 11:14:27

7
English
Installation
Overviewof installation location requirements
125 mm
or more
(recommended)
Drain hose hole
You can select the direction of
draining (left or right).
Make at least one round to
reduce noise and vibration.
Maximum pipe height: 8 m
Maximum pipe length: 15 m
The actual units may look different from
the images depicted here.
Outdoor
Unit
Outer wall
Indoor
Unit
Cut insulation to have
rainwater drained
Make a U-trap (A) on the
pipe (which is connected to
the indoor unit) at outerwall
and cut the bottom part of
the insulation (about 10 mm)
to prevent rainwaterfrom
getting inside through the
insulation.
CAUTION
100 mm or more
(recommended) 125 mm
or more
(recommended)
(Unit : m)
Model Pipe length Pipe height
Minimum Maximum Maximum
AC026/035TNXDKG 320 15
AC052TNXDKG 330 20
AC071TNXDKG 350 30
CAUTION
• Comply with the length and height limits described in
the figure above.
• For the product that uses the R-32 refrigerant, Install
the indoor unit on the wall 1.8 m or higher from the
floor.
Step 1-2 Checking and preparing
accessories and tools
Accessories
Accessories in the indoor unit package
AC***TNXDKG
Mounting bracket (1)
AC026/035TNXDKG
Mounting bracket (1)
AC052/071TNXDKG
Remote control (1) Remote control battery (2)
General information (1) Quick guide (1)
Installation manual (1) Holder remocon (1)
Extra M4 x12
tapping screw (2)
Tools
General tools
• Vacuum pump
(Backward flowing
prevention)
• Manifold gauge
• Stud finder
• Torque wrench
• Pipe cutter
• Reamer
• Pipe bender
• Spirit level
• Screwdriver
• Spanner
• Drill
• L-wrench
• Measuring tape
Tools for test operation
• Thermometer
• Resistance meter
• Electroscope
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 7 2020-02-10 오전 11:14:27

8
English
Installation
Step 2-1 Attaching the mounting
bracket to the wall
1 Hold the mounting bracket against the wall at the
selected installation position (Step1-1 on page 6),
making sure that the screw holes align with the center of
the studs in the wall. If the screw locations do not align
with the studs, use wall anchors.
CAUTION
• The recommended best practice is to attach the
mounting bracket directly to the studs in the wall. If
you did not find a suitable location with studs (in Step
1-1 on page 6), or if the wall is concrete, you must
use wall anchors of a suitable type and weight capacity,
and install them according to the manufacturer’s
instructions. Failure to do so may cause the material
surrounding the joints to crumble over time and the
screws to be loosened and stripped. This may result
in the unit falling from the wall, which could cause
physical injury or equipment damage.
2 Using a level, make sure that the mounting bracket is
level, then mark the location of the screw holes on the
wall.
3 If using wall anchors, install them at the screw hole
positions, following the manufacturer’s instructions.
4 Using six field-supplied mounting screws and anchors (if
applicable), attach the bracket to the wall.
Screw Location x 4ea
Level
Step 2-2 Drilling the wall penetration
1 Determine the position of the hole through which the
piping bundle (consisting of power and communication
cables, refrigerant pipes, and the drain hose) will pass.
Consider the following:
‐The hole inner diameter must be 65 mm.
‐The recommended hole location is behind the unit
so that the hole and the piping bundle will not
be visible in the room. The minimum distances
between the hole and the mounting bracket are:
a
b c
Center of indoor unit (B)
Centerof indoor unit (A)
Possible positions for hole behind unit
(Unit: mm)
Model a b c
AC026/035TNXDKG 165 305 416
AC052/071TNXDKG 150 305 650.5
‐If the hole cannot be positioned behind the unit,
find a position as close to the unit as possible. The
piping bundle that exits the unit and extends to the
hole will need to be attached to the wall and will be
visible inside the room.
‐In relation to the bracket shown above, the unit
is shipped with the drain hose connection on the
right, the drain hose exits the unit on the left, and
the refrigerant pipes are bent to exit on the left.
Thus, positioning the hole to the left requires the
least effort. If you position the hole to the right
or below the unit, you will need to move the drain
hose connection to the left and bend the pipes so
that the hose and pipes exit to the right or bottom.
See the figure in step 3 on page 9.
Indoor Unit Installation
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 8 2020-02-10 오전 11:14:28

9
English
Installation
2 Use a standard 65 mm hole saw to drill one hole at the
selected location, at a 15° downward angle so that the
drain hose will drain properly.
Wall
Drain hose
Indoor unit
3 Based on the hole location, determine where the piping
bundle (drain hose, refrigerant pipes, and cables) will exit
the unit.
<Front view>
<Side view>
Right
bottom
Rear right or left
Left
NOTE
• The left, right, or bottom exit will only be used if the
hole is not positioned behind the unit.
Step 2-3 Connecting the refrigerant
pipes
Connect indoor and outdoor units with field-supplied copper
pipes by means of flare connections. Use insulated seamless
refrigeration grade pipe only, (Cu DHP type according to
ISO1337), degreased and deoxidized, suitable for operating
pressures of at least 4200 kPa and for burst pressure of at
least 20700 kPa. Under no circumstances must sanitary type
copper pipe be used.
IMPORTANT
• When installing the unit, always connect the
refrigerant pipes first, followed by the electrical cables.
For disassembly, always disassemble the electric cables
before the refrigerant pipes.
Two short refrigerant pipes are already attached to the air
conditioner:
• The smaller-diameter pipe is for the high-pressure,
two-phase refrigerant.
• The larger-diameter pipe is for the low-pressure
refrigerant vapor.
Refrigerant
pipes
(assembly pipe)
Connection hoseDrain hose
In Step 2-2, step 3 you determined the exit position for the
piping bundle. The unit has three knockouts available forthe
left, right, and bottom exits. When the bundle exits directly
from the rear, none of the knockouts are used.
1 If the pipes will exit directly from the rear, skip to step 3.
Otherwise, cut out the appropriate knockout piece (left,
right, or bottom).
2 Use a razor knife to clean the cut edges (flashing).
3 The left exit is the only position that does not require
bending the pipes. For other positions, bend the pipes so
that they will exit in the selected exit position.
‐The bending radius should be greater than 100 mm.
‐Bend the smaller pipe gradually to prevent kinking.
The larger pipe has a preinstalled spring bender to
prevent kinking.
‐Make sure that the pipes do not protrude from the
back of the unit in a way that will make it difficult to
attach the unit to the mounting bracket.
‐For right and bottom exits, pull the pipes out through
the selected knockout opening. For left exits, the
piping connections will be made in the service space
behind the indoor unit (under the cover panel).
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 9 2020-02-10 오전 11:14:28

10
Indoor Unit Installation
English
Installation
NOTE
• If you are using the right rear exit, the pipes should
be long enough to extend through the wall without
needing to connect the line set first. It may be easier
to connect the line set outside of the building, after
you have bundled the pipes and cables and passed the
bundle through the wall. In this case, do not connect
the line set now. Instead, complete Step 2-4 through
Step 2-7, then go outside and connect the line set as
described below.
4 Slowly remove the protective caps on the refrigerant pipe
connections to relieve the nitrogen holding charge.
5 Connect the line set to each pipe.
Indoor outlet pipe Connecting pipe
Flare nut
6 Hand-tighten the flare nuts to make sure that they do not
become stripped.
Liquid service port
<High pressure>
Gas service port
<Low pressure>
7 Torque the flare connections to the following values:
Outer diameter (mm) Torque (N·m)
ø 6.35 14–18
ø 9.52 34–42
ø 12.70 49–61
ø 15.88 68–82
CAUTION
• Tighten the flare nuts only to the specified torque. If
a flare nut is overtightened, the flare face may crack,
causing refrigerant leakage.
8 Do not box in or cover the pipe connections. Make sure
that the connections are accessible for testing later in the
installation process and for future servicing.
9 Tape over the end of the pipes so that debris will not enter
the piping when it is passed through the wall. The pipes
will be insulated later in the installation process.
Step 2-4 Connecting the power and
communication cables
If using a multi system, install as described in the
installation manual supplied with the outdoor unit.
WARNING
• Do not modify the power cable in any way. Doing so may cause
electric shock orfire due to poorconnection, poor insulation, or
current limit override. Make sure to complywith the technical
standards of electrical installations and the wiring regulations
in the local area.
• This appliance must be properly grounded. Do not ground the
appliance to a gas pipe, plastic waterpipe, or telephone line.
Failure to comply may result in electric shock, fire, and explosion.
• Make sure that cabling is not subject to wear, corrosion,
excessive pressure, vibration, sharp edges, or adverse
environmental effects. Take into account the effects of aging or
continual vibration from sources such as compressors or fans.
1 Connect each wire to its corresponding terminal number.
Model AC026/035/052TNXDKG AC071TNXDKG
Power cable
(Outdoorunit) 3G X 2.5 mm², H05RN-F 3G X 2.5 mm²,
H05RN-F
Outdoor-to-
indoorpower
cable
3G X 0.75~1 mm²,
H05RN-F
3G X 0.75~1 mm²,
H05RN-F
Communication
cable
3G X 0.75 mm²,
H05RN-F
3G X 0.75 mm²,
H05RN-F
Type GL 16 A 20 A
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 10 2020-02-10 오전 11:14:28

11
English
Installation
Control box
Before
connecting
Correct Upside
down Damaged Non-circular
After
connecting
Correct
(Front view)
Correct
(Side view)
Upside
down Non-fitted
<Circular terminal>
CAUTION
• Connect the wires firmly so that wires cannot be pulled
out. Loose wires can cause the connection to overheat.
Each circular terminal must match the size of its
corresponding screw in the terminal block.
CAUTION
• For the terminal block wiring, use a wire with a
ring terminal socket only. Regular wires without a
ring terminal socket may become a hazard as the
connections may loosen during operation.
For the product that uses the R-32 refrigerant, be cautious not
to generate a spark by keeping the following requirements:
‐Do not remove the fuses with power on.
‐Do not disconnect the power plug from the wall
outlet with power on.
‐It is recommended to locate the outlet in a high
position. Place the cords so that they are not tangled.
2 Tighten the terminal block screw.
L1L2F1 F2
3 In Step 2-2, step 3 you determined the exit position for the
piping bundle. If using the left, right, or bottom exits, pass
the cables through the selected knockout.
NOTE
• Power supply cords of parts of appliances for outdoor
use shall not be lighter than polychloroprene sheathed
flexible cord. (Code designation IEC: 60245 IEC66/
CENELEC: H07RN-F, IEC: 60245 IEC57 CENELEC:
H05RN-F, IEC: 60227 IEC53: H05VV-F)
• Power & Communication cable shall not exceed 30 m.
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 11 2020-02-10 오전 11:14:28

12
Indoor Unit Installation
English
Installation
Step 2-5 Optional: Extending the power
cable
1 Prepare the following tools.
Tools Spec Shape
Crimping pliers MH-14
Connection sleeve
(mm) 20xØ6.5 (HxOD)
Insulation tape Width 19 mm
Contraction tube
(mm) 70xØ8.0 (LxOD)
2 As shown in the figure, peel off the shields from the
rubber and wire of the power cable.
• Peel off 20 mm of cable shields from the pre-
installed tube.
CAUTION
• For information about the power cable specifications
for indoor and outdoor units, refer to the installation
manual.
• After peeling off cable wires from the pre-installed
tube, insert a contraction tube.
• If cable wires are connected without using connecting
sleeves, their contact area becomes reduced, or
corrosion develops on the outer surfaces of the wires
(copper wires) over a long time. This may cause an
increase of resistance (reduction of passing current)
and consequently may result in a fire.
Power cable
20
60
20 20 20
Pre-installed
tube for the
power cable
20 20
60
120
120
180
180
(Unit: mm)
3 Insert both sides of core wire of the power cable into the
connection sleeve.
• Method 1: Push the core wire into the sleeve from
both sides.
• Method 2: Twist the wire cores together and push it
into the sleeve.
Method 1
Connection sleeve Connection sleeve
Method 2
4 Using a crimping tool, compress the two points and flip
it over and compress another two points in the same
location.
• The compression dimension should be 8.0.
Compression
dimension
• After compressing it, pull both sides of the wire to
make sure it is firmly pressed.
Method 1 Method 2
Compress it 4 times
5 mm 5 mm
Compress it 4 times
5 Wrap it with the insulation tape twice or more and
position your contraction tube in the middle of the
insulation tape.
Method 1 Method 2
Insulation tape
40 mm 35 mm
Insulation tape
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 12 2020-02-10 오전 11:14:29

13
English
Installation
6 Apply heat to the contraction tube to contract it.
Method 1 Method 2
Contraction tube Contraction tube
7 After tube contraction work is completed, wrap it with the
insulation tape to finish.
Three or more layers of insulation are required.
Method 1 Method 2
Insulation tape Insulation tape
CAUTION
• Make sure that the connection parts are not exposed
to outside.
• Be sure to use insulation tape and a contraction tube
made of approved reinforced insulating materials
that have the same level of withstand voltage with
the power cable. (Comply with the local regulations on
extensions.)
WARNING
• In case of extending the electric wire, please DO NOT use
a round-shaped Pressing socket.
‐Incomplete wire connections can cause electric
shock or a fire.
Step 2-6 Connecting the drain hose
1 In Step 2-2, step 3 you determined the exit position for the
piping bundle. If using the right, bottom, or right rear exit,
change the drain hose connection from the right to the
left so that the drain hose will lie along the inside of the
unit and exit to the right.
Drain pan outlet
Rubber cap
CAUTION
• Be careful not to puncture the plug with the
screwdriver when installing it.
2 If using the left, right, or bottom exit, pass the drain hose
through the selected knockout.
Refrigerant pipes
(assembly pipe)
Drain hose Connection hose
3 Connect a 15.88 mm ID extension drain hose to the main
drain hose.
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 13 2020-02-10 오전 11:14:29

14
Indoor Unit Installation
English
Installation
CAUTION
• If the diameter of the connection hose is smaller than
the product’s drain hose, leakage may occur.
(A) (B)
40~45 mm
Drain hose (A)
Drain hose Extension drain hose
40~45mm
20 mm or more
Vinyl tape
Foam insulation
Extension drain hose (B)
4 Do not box in or cover the drain hose connection. It must
be accessible for testing later in the installation process
and for future servicing.
5 If the drain hose is routed inside the room, insulate the
hose so that dripping condensation does not damage the
furniture or floors.
Step 2-7 Taping the pipes, cables, and
drain hose
1 Wrap foam insulation around the refrigerant pipes, up
to the connection points. The connections must remain
accessible for testing later in the installation process.
Either leave slits in the insulation or do not cover the
connections.
Insulation
Refrigerant pipes
Test parts for the
indoor unit
2 Make a piping bundle by using vinyl tape to wrap together
the refrigerant pipes, power cable, communication cable,
and drain hose, up to the connection points. Connection
points must remain accessible fortesting later in the
installation process.
Mounting bracket
Vinyl tape
Power and communication
cables (assembly cable)
Refrigerant pipes
(assembly pipe)
Drain hose
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 14 2020-02-10 오전 11:14:29

15
English
Installation
Step 2-8 Performing leak test
Leak test
LEAK TESTWITH NITROGEN (before opening valves)
In order to detect basic refrigerant leaks, before recreating
the vacuum and recirculating the R-32, it’s responsible of
installer to pressurize the whole system with nitrogen (using a
pressure regulator) at a pressure above 4.1MPa (gauge).
LEAK TESTWITH R-32 (after opening valves)
Before opening valves, discharge all the nitrogen into the
system and create vacuum. After opening valves check leaks
using a leak detectorfor refrigerant R-32.
Test parts for the
indoor unit
CAUTION
• Discharge all the nitrogen to create a vacuum and
charge the system.
Step 2-9 Commissioning the unit
Common steps forsetting the addresses and
options
Entering mode for
setting option
Option setting
mode
High Temp Button
Mode change
High Fan Button
Low Fan Button
Low Temp Button
NOTE
• The remote control display and buttons may vary
depending on the model.
1 Enter the mode for setting the options:
a Remove the batteries from the remote control, and
then insert them again.
b While holding down the (High Temp) and (Low
Temp) buttons simultaneously, insert the batteries
into the remote control.
c Make sure that you are entered to the mode for
setting the options:
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 15 2020-02-10 오전 11:14:30

16
Indoor Unit Installation
English
Installation
2 Set the option values.
CAUTION
• The total number of available options are 24: SEG1 to
SEG24.
• Because SEG1, SEG7, SEG13, and SEG19 are the page
options used by the previous remote control models,
the modes to set values for these options are skipped
automatically.
• Set a 2-digit value for each option pair in the following
order: SEG2 and SEG3 → SEG4 and SEG5 → SEG6 and
SEG8 → SEG9 and SEG10 → SEG11 and SEG12 → SEG14
and SEG15 → SEG16 and SEG17 → SEG18 and SEG20 →
SEG21 and SEG22 → SEG23 and SEG24
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
0XXXXX
SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
1XXXXX
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
2XXXXX
SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
3XXXXX
On (SEG1 to SEG12)Off (SEG13 to SEG24)
Take the steps presented in the following table:
Option setting Status
1 Setting SEG2, SEG3 option
a Press Low Fan button to enter SEG2 value.
b Press High Fan button to enter SEG3 value.
Each time you press the button, will be selected in rotation. SEG2 SEG3
2 Setting Cool mode
Press Mode button to be changed to Cool mode in the ON status.
3 Setting SEG4, SEG5 option
a Press Low Fan button to enter SEG4 value.
b Press High Fan button to enter SEG5 value.
Each time you press the button, will be selected in rotation. SEG4 SEG5
4 Setting Dry mode
Press Mode button to be changed to Dry mode in the ON status.
5 Setting SEG6, SEG8 option
a Press Low Fan button to enter SEG6 value.
b Press High Fan button to enter SEG8 value.
Each time you press the button, will be selected in rotation. SEG6 SEG8
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 16 2020-02-10 오전 11:14:30

17
English
Installation
Option setting Status
6 Setting Fan mode
Press Mode button to be changed to Fan mode in the ON status.
7 Setting SEG9, SEG10 option
a Press Low Fan button to enter SEG9 value.
b Press High Fan button to enter SEG10 value.
Each time you press the button, will be selected in rotation. SEG9 SEG10
8 Setting Heat mode
Press Mode button to be changed to Heat mode in the ON status.
9 Setting SEG11, SEG12 option
a Press Low Fan button to enter SEG11 value.
b Press High Fan button to enter SEG12 value.
Each time you press the button, will be selected in rotation. SEG11 SEG12
10 Setting Auto mode
Press Mode button to be changed to Auto mode in the OFF status.
11 Setting SEG14, SEG15 option
a Press Low Fan button to enter SEG14 value.
b Press High Fan button to enter SEG15 value.
Each time you press the button, will be selected in rotation. SEG14 SEG15
12 Setting Cool mode
Press Mode button to be changed to Cool mode in the OFF status.
13 Setting SEG16, SEG17 option
a Press Low Fan button to enter SEG16 value.
b Press High Fan button to enter SEG17 value.
Each time you press the button, will be selected in rotation. SEG16 SEG17
14 Setting Dry mode
Press Mode button to be changed to Dry mode in the OFF status.
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 17 2020-02-10 오전 11:14:31

18
Indoor Unit Installation
English
Installation
Option setting Status
15 Setting SEG18, SEG20 option
a Press Low Fan button to enter SEG18 value.
b Press High Fan button to enter SEG20 value.
Each time you press the button, will be selected in rotation. SEG18 SEG20
16 Setting Fan mode
Press Mode button to be changed to Fan mode in the OFF status.
17 Setting SEG21, SEG22 option
a Press Low Fan button to enter SEG21 value.
b Press High Fan button to enter SEG22 value.
Each time you press the button, will be selected in rotation. SEG21 SEG22
18 Setting Heat mode
Press Mode button to be changed to Heat mode in the OFF status.
19 Setting SEG23, SEG24 option
a Press Low Fan button to enter SEG23 value.
b Press High Fan button to enter SEG24 value.
Each time you press the button, will be selected in rotation. SEG23 SEG24
3 Check whether the option values that you have set are correct by pressing the button repeatedly.
[SEG2, SEG3]
[SEG21, SEG22] [SEG23, SEG24]
[SEG4, SEG5] [SEG6, SEG8] [SEG9, SEG10] [SEG11, SEG12] [SEG14, SEG15] [SEG16, SEG17] [SEG18, SEG20]
4 Save the option values into the indoor unit:
Press the button with the direction of remote control for set. For correcting option values, input the option values twice.
5 Check whetherthe air conditioner operates in accordance with the option values you have set:
a Reset the indoor unit by pressing the Reset button on the indoor or outdoor unit.
b Remove the batteries from the remote control, insert them again, and then press the button on the remote control.
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 18 2020-02-10 오전 11:14:32

19
English
Installation
Emergency Temperature Output (ETO) function
CAUTION
• In order to deploy the ETO function, the MIM-B14, an external contact interface module, must be installed in each
indoor unit.
‐The ETO is a concept of emergency operation of indoor units. If the indoor unit 1 (main indoor unit) stops because of
an error, the indoor unit 2 (sub indoor unit) starts to operate.
‐Basically, the indoor unit 2 operates in the previous mode. [For the first time operation, it starts in 24 °C (75 °F)
Auto mode.]
‐To set more detailed operation conditions for the indoor unit 2, use the S-net Pro.
Setting up the ETO
Communication between
indoor and outdoor units
(F1 and F2)
External contact
interface module
MIM-B14
Error output port (1, 2)
Contact input port (5, 6)
Main indoor unit
Sub indoor unit
1 Main indoor unit
‐Disable the external contact control (Default).
‐Connect the S-net pro2 to F1 and F2.
‐Enable the ETO function and set the temperature and time.
2 Sub indoor unit
‐(Required) Enable the external contact control (with the installation option SEG14 - Reverse Control).
‐Connect the S-net pro2 to F1 and F2.
‐Enable the entrance control and set the mode, set temperature, and fan speed.
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 19 2020-02-10 오전 11:14:32

20
Indoor Unit Installation
English
Installation
[Master] [Slave]
ETO operation specifications
1 Main indoor unit
‐Based on the external contact control settings, the main indoor unit decides whether to generate output when an
error (indoor unit stop) occurs.
‐Based on the ETO settings, the main indoor unit decides whether to generate output according to the temperature
and time conditions.
2 Sub indoor unit
‐Based on the entrance control settings, the sub indoor unit decides the mode, set temperature, and fan speed when
contact inputs are given.
Main indoor unit
Enable of ETO Enable of external
contact Error port output
X X N/A
X O Output due to an error
O X Output by ETO entrance conditions
(temperature / time / error occurrence)
O O
Output by ETO entrance conditions
(temperature / time / error occurrence)
※Ready to control the main contact input
Sub indoor unit
Enable of entrance
control
Enable of external
contact Operation when outputting Main
X X N/A
X O On with the previous operation conditions
O O On with the entrance control enabled
DB68-08947A-00_IM_CAC QMD_EU_EN_.indd 20 2020-02-10 오전 11:14:32
