Samsung AP30M1 Series Guide

QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
U.A.E 800-SAMSUNG (726-7864) www.samsung.com
OMAN 800-SAMSUNG(726-7864) www.samsung.com
KUWAIT 183-2255 www.samsung.com
BAHRAIN 8000-4726 www.samsung.com
EGYPT 08000-726786 www.samsung.com
JORDAN 800-22273 www.samsung.com
MOROCCO 080 100 2255 www.samsung.com
SAUDI ARABIA 9200-21230 www.samsung.com
TURKEY 444 77 11 www.samsung.com
This product is not manufactured for Iran. SVC Warraty will not be
applicable and the user will be responsible for service
expenses when the product is used in Iran.
Mirage_AP30M0@_IBIM_E_34518A(1).indd 56 2012-02-01 오후 4:07:59

AP30M0 Series
AP30M1 Series
Air Conditioner
user & installation manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please
register your product at
www.samsung.com/register
E S F P A DB98-34518A(1)
Mirage_AP30M0@_IBIM_E_34518A(1).indd 57 2012-02-01 오후 4:07:59

2
Features of your new air conditioner
Strong Turbo/Long Function
Your new air conditioner supports Turbo function which makes you cool fast for 30 minutes and Long function which makes
the cool air goes to much further place.
Look for Everywhere
The elegant and harmonious design gives priority to the esthetics of your space and complements any of your existing
interior décor. With its soft color and latest design, the new air conditioner adds class to any room. Enjoy what your air
conditioner offers both functionally and esthetically.
Contents
Safety precautions ....................................................................................................... 3
Viewing your air conditioner ............................................................................................. 8
Operating basic function ................................................................................................ 12
Using advanced functions .............................................................................................. 17
Cleaning and maintaining the air conditioner ........................................................................... 27
Appendix ............................................................................................................... 30
Safety precautions ...................................................................................................... 32
Accessory parts list ...................................................................................................... 34
Selection of installation place ........................................................................................... 37
Preparing the installation ............................................................................................... 39
Electrical work .......................................................................................................... 41
Installation method ..................................................................................................... 44
Air purge ............................................................................................................... 49
Refrigerant charging .................................................................................................... 50
Check and test operation ............................................................................................... 51
Packing and unpacking guide ........................................................................................... 53
How to connect your extended power cables ........................................................................... 55
User manual
Installation manual
Mirage_AP30M0@_IBIM_E_34518A(1).indd 2 2012-02-01 오후 4:07:09

3
ENGLISH
Safety precautions
Before using your new air conditioner, please read this manual thoroughly to ensure that you know how to safely and
efficiently operate the extensive features and functions of your new appliance.
Because the following operating instructions cover various models, the characteristics of your air conditioner may differ
slightly from those described in this manual. If you have any questions, call your nearest contact center or find help and
information online at www.samsung.com.
Important safety symbols and precautions:
WARNING Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage.
CAUTION To reduce the risk of fire, explosion, electric shock, or personal injury when using your air
conditioner, follow these basic safety instructions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the contact center for help.
These warning signs are here to prevent injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe place for future reference.
WARNING
SEVERE WARNING SIGNS
Do not place the air conditioner near hazardous substances or equipment that releases free flames to avoid fire,
explosions or injuries.
 Potential risk of fire hazard or explosion.
Do not install the outdoor unit at an unstable place or elevated surface where there is potential risk of falling.
 If the outdoor unit falls, it may cause personal injury or loss of property.
Failure or damage may occur if any changes or modification that is not stated in the manual was performed. In
this case, user will be responsible for the repair expenses.
Install the air conditioner away from direct exposure to sunlight, heating apparatus, and humid places.
 Hang curtains on windows to boost cooling efficiency and to avoid the risk of electric shock.
Do not yank the power cable with hands.
 Potential risk of fire or electric shock.
User manual
Mirage_AP30M0@_IBIM_E_34518A(1).indd 3 2012-02-01 오후 4:07:09

4
Safety precautions
WARNING
SEVERE WARNING SIGNS
Never use a damaged or dusted power cable, or loosened power receptacle.
 Potential risk of fire or electric shock.
Install an exclusive circuit breaker and short-circuit breaker for the air conditioner.
 Potential risk of electric shock or fire.
Do not insert anything such as fingers or branches into the air conditioner vents while the air conditioner is
running.
 Keep the children away from the air conditioner to prevent them from putting their finger on the air conditioner.
Potential risk of personal injury.
Ensure no water gets into the air conditioner.
 Potential risk or electric shock.
 If the water gets into the air conditioner, stop and unplug the power source immediately.
Turn off the air conditioner using the provided remote controller or control accessory (if provided). Do not
unplug to turn off the unit (unless there is an immediate danger).
Do not run the air conditioner for an extended period of time in a room with the door closed or with babies,
elderly or disabled people.
 Open the door or windows to ventilate your room at least once an hour to prevent oxygen shortage.
The air conditioner is composed of moving parts. Keep children away from the unit to avoid physical injury.
Make sure that children take precautions against access to the air conditioner and they do not play with the
unit.
Do not clean the interior of air conditioner on your own.
 You may damage the parts which can cause electric shock or fire.
 Consult contact center for cleaning the interior of the air conditioner.
Do not connect the air conditioner with heating apparatus or attempt to disassemble, remodel or repair it by
yourself.
 Potential risk of malfunction, electric shock or fire. If repairs are needed, consult the contact center.
Consult the place of purchase or contact center to install the air conditioner.
 Improper installation carries a risk of unit malfunction, water leakage, electric shock or fire.
 If installing in specialty areas, such as a factory complex or saline coastal area, consult the place of purchase or
contact center for specific installation details.
 The units must be installed according to distances declared, in order to permit accessibility from each side, either
to guarantee correct operation of maintenance or repairing products. The unit’s parts must be reachable and
removable completely under safety condition (for people or things).
Consult a dealer regarding the appropriate measures to prevent the allowable concentration from being
exceeded.
 If the refrigerant leaks, and cause the concentration limit to be exceeded, hazards due to lack of oxygen in the
room may result.
If the indoor unit gets wet, turn the power off immediately and call your nearest contact center.
 Potential risk of fire or electric shock.
Mirage_AP30M0@_IBIM_E_34518A(1).indd 4 2012-02-01 오후 4:07:09

5
ENGLISH
Always make sure that the power supply is compliant with current safety standards. Always install the air
conditioner in compliance with current local safety standards.
Verify that the voltage and frequency of the power supply comply with the specifications and that the installed
power is sufficient to ensure the operation of any other domestic appliance connected to the same electric lines.
Use a rated circuit breaker only.
 Never use steel wires or copper wires as a circuit breaker. It may cause fire or unit malfunctions.
Do not put undue stress or place heavy object on the power cable.
Do not bend the power cable excessively.
 Potential risk of fire or electric shock.
To protect the product from water and possible shock, you should keep the power cable and the connection
cord of the indoor and outdoor units in the protection tube.
Disconnect the air conditioner from power supply before it is repaired or disassembled.
Clean the air conditioner after the inner fan stops operating.
 Potential risk of injury or electric shock.
Use a receptacle that has a ground terminal. The receptacle must be used exclusively for the air conditioner.
 Improper electrical grounding may cause electric shock or fire.
Be sure to ground the unit. Do not connect the ground wire to gas or water pipes, lighting rods, or telephone
grounding lines.
 If the unit is not properly grounded, electric shock may result.
If you smell burning plastic, hear strange sounds, or see smoke coming from the unit, unplug the air conditioner
immediately and call a contact center.
 Potential risk of fire or electric shock.
CAUTION
CAUTION SIGNS
Do not block or place items in front of the air conditioner. Do not step, hang onto, or place heavy items on the air
conditioner.
 Potential risk of personal injury.
If failure or damage occurs on the conditions of improper use not followed by the manual, there will be an extra
labor charge for installing and construction.
 Potential risk of malfunction, electric shock or fire if repairs or installations are attempted by a non-qualified
service technician.
Do not spray flammable gases such as insecticide near the air conditioner.
 Potential risk of electric shock, fire or unit malfunction.
Do not open the front panel during operation.
 Potential risk of electric shock or unit malfunction.
Cool air should not flow directly towards people, pets, and plants.
 It is harmful to your health, pets, and plants.
Do not drink drain water coming out of the air conditioner.
 Potential risk of health hazard.
Mirage_AP30M0@_IBIM_E_34518A(1).indd 5 2012-02-01 오후 4:07:09

6
Safety precautions
CAUTION
CAUTION SIGNS
Do not allow children to climb on the air conditioner.
Do not use the air conditioner as a cooling precision instrument for food, pets, plants, cosmetics or machinery.
Do not pull or give excessive shock to the air conditioner.
 Potential risk of fire, or unit malfunction and there are risk of personal injury because unit may fall down.
Do not spray water directly on the air conditioner or use benzene, thinner or alcohol to clean the surface of the
unit.
 Potential risk of electric shock or fire.
 Potential risk of damage to the air conditioner.
Do not place any objects, especially containers with liquid.
Do not touch the pipe connected to the air conditioner.
Install the indoor unit away from lighting apparatus using the ballast.
 If you use the wireless remote controller, reception error may occur due to the ballast of the lighting apparatus.
Install the outdoor unit where operating noise and vibration will not disturb your neighbor and in a well-
ventilated area with no obstacle.
 Potential risk of malfunction.
 Operating noise may disturb your neighbor.
Make sure that there are no obstacles or covers that block the air conditioner.
Allow sufficient space for air circulation.
 Insufficient ventilation may result in poor performance.
If the power cable is damaged, the manufacturer or a qualified service technician must replace it.
If a power outage occurs while the air conditioner is working, turn off the power source immediately.
Max current is measured according to IEC standard for safety and current is measured according to ISO standard
for energy efficiency.
Check for damage on delivery. If damaged, do not install the air conditioner and call the place of purchase
immediately.
Keep indoor temperatures stable and not extremely cold, especially where there are children, elderly or
disabled people.
The packaging material and used batteries of the remote controller (optional) must be disposed of in
accordance with the national standards.
The refrigerant used in the air conditioner must be treated as chemical waste. Dispose the refrigerant following
national standards.
Have a qualified service technician install the air conditioner and perform a trial operation.
Firmly connect the drain hose to the air conditioner for proper water drainage.
Check for damages on the outdoor unit installation pad at least once a year.
 Potential risk of personal injury or property loss.
Mirage_AP30M0@_IBIM_E_34518A(1).indd 6 2012-02-01 오후 4:07:09

7
ENGLISH
When using a wireless remote controller, the distance should not be more than 7 meters from the air
conditioner.
If the remote controller is not used for a long period of time, remove the batteries to prevent leakage of
electrolyte.
When cleaning the outdoor unit, touch the heat exchanger radiator fins with extreme care.
 Wearing thick gloves can protect your hands.
Make sure that the condensed water dripping from the drain hose runs out properly and safely.
The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety: Young children should be supervised to
ensure that they do not play with the appliance.
Inspect the condition, electric connections, pipes and external case of the air conditioner regularly by a qualified
service technician.
Do not open doors and windows in the room being cooled during operation unless necessary.
Do not block the air conditioner vents. If objects block the air flow, it may cause unit malfunction or poor
performance.
The air conditioner should be used only for the applications for which it has been designed: the indoor unit is
not suitable to be installed in areas used for laundry.
Ensure the off-on and protection switches are properly installed.
Do not use the air conditioner if damaged. If problems occur, immediately stop operation and disconnect the
plug from the power supply.
If the air conditioner will not be used for an extended period of time (for example, over several months), unplug
the power from the wall.
Call the place of purchase or a contact center if repairs are needed.
 Potential risk of fire or electric shock if disassembly or repairs are attempted by a non-qualified service technician.
Mirage_AP30M0@_IBIM_E_34518A(1).indd 7 2012-02-01 오후 4:07:09

8
Viewing your air conditioner
Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool
with optimal efficiency.
Please read the manual to get started and to make the best use of the air conditioner.
Checking the indoor unit and display
Carefully unpack your air conditioner and check the indoor unit to make sure it is not damaged.
Main parts
Air flow blade
(up/down orientation)
Air flow blade
(right/left orientation)
Control panel
Air intake
Air filter
To open the panel
 Hold the upper part of the
panel, then pull it slightly
forward.
• Don’t open the panel
when it is operating.
It may cause a
malfunction or an
electrical hazard.
CAUTION
Air outlet
Your air conditioner may slightly look different from illustration shown above depending on your model.
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 8 2012-02-01 오후 4:07:10

9
ENGLISH
Control panel
You can operate the air conditioner with the control panel when you can’t or don’t want to operate the air conditioner with
the remote controller. (see pages 24~26)
Air swing (Up/Down) button
Turbo button
Fan speed indicator
Air swing (Left/Right)
button
Fan speed adjustment button
Temperature
adjustment buttons
Power
button
Timer indicator
Defrost indicator
( Defrost is applicable for AP30M1 model only)
S.Saver indicator
Outdoor unit operation indicator
Turbo indicator
Air swing (Left/Right) indicator
Air swing (Up/Down) indicator
Long function indicator
Lock indicator
Temperature setting
Operation mode indicators
(Heat is applicable for AP30M1 model only)
Mode selection button
Remote controller receiver
Heater and Purity function is not supported by this model.
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 9 2012-02-01 오후 4:07:10

10
Viewing your air conditioner
Checking the remote controller
You can activate the air conditioner by pointing the remote controller away from it. When using the remote controller, always
point it directly at the air conditioner.
Remote controller display
Power
Turn on/off the air conditioner
Temp + -
Increase/Decrease the temperature
by 1˚C
Turbo/Long
Set the Turbo/Long function
Air swing(Left/Right)
Activate/Deactivate air flow blade
movement automatically right and left
Cancel
Cancel the timer
Set
Set the timer
Fan
Adjust how much air flows through
the air conditioner with the 4 different
fan speeds such as Auto/Low/
Medium/High
Time Up
Increase the time when
setting the timer
Time Down
Decrease the time when
setting the timer
Mode
Set one of the 5 operation modes
(see pages 12~16 for instructions)
Air swing(Up/Down)
Activate/Deactivate air flow blade
movement automatically up and
down
Smart saver
Save energy consumption while
maintaining cool air
On Timer
Set the On Timer on
Off Timer
Set the Off Timer on
This button is not functional
• When you press the button, a short ring will sound and a transmit indicator( )appears on the remote controller
display.
• Heater and Purity functions are not supported by this model.
• Remote controller will remember the most recent temperature setting if you turn off the air conditioner and then
turn it on again.
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 10 2012-02-01 오후 4:07:10

11
ENGLISH
Remote controller display
Air swing indicator
Transmit indicator
Set temperature/time
indicator
Fan speed indicator
Auto
Low
Medium
High
Low battery indicator
On/Off timer indicator
Operation mode indicator
(Heat is applicable for AP30M1
model only)
Using the remote controller
Point the remote controller towards the remote controller receiver of the indoor unit (see page 9 to find the location of
remote controller receiver).
When you properly press the button on the remote controller, you will hear ring sound from the indoor unit.
• The signal may not be received well of electronic lighting style fluorescent lamps such as inverter fluorescent lamps
are in the same space.
• If other electrical products operate by the remote controller, call your nearest contact center.
Installing the batteries
1. Push the lever as arrow
indicates on the rear side of the
remote controller and pull up.
2. Insert two AAA batteries.
Check and match the “+” and “-”
signs accordingly. Make sure you
have inserted the batteries in
correct position.
3. Close the cover by place it back
to its original position.
You should hear click sound
when the cover is locked
properly.
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 11 2012-02-01 오후 4:07:11

12
Operating basic function
Turning the air conditioner on and off
Press the Power button on the remote controller.
You will hear a ring and the air flow blade will move automatically when
the air conditioner is properly on. The air conditioner will operate in the
most recent operation mode used or Auto mode.
When you turn off the air conditioner, air flow blade will stop moving.
Turning on/off your air conditioner without the remote controller.
You can operate your air conditioner by pressing the Power button on the indoor unit control panel.
Selecting operation mode
Auto
In Auto mode, the air conditioner will automatically set the temperature and fan speed depending on the room temperature
detected by the room temperature sensor.
1. Turn on the air conditioner.
Press the Power button on the remote controller.
2. Set the operation mode.
Press the Mode button on the remote controller until Auto mode
and Auto fan speed indicator appear on the remote controller
display.
The air conditioner will automatically set the operation mode to Cool
depends on the room temperature.
Each time you press the Mode button, the mode will change
in order of Auto, Cool, Dry, Fan and Heat*. (*Heat mode is
applicable for AP30M1 model only.)
3. Adjust the temperature (if you need to increase or decrease the
room temperature).
Press the Temp + or - button on the remote controller to increase or
decrease the desired temperature.
You can set the desired temperature between the range of
18˚C~30˚C.
You can increase/decrease the temperature by 1˚C.
• While the air conditioner is already operating in another mode, press the Mode button until Auto mode indicator
appears on the remote controller display.
• When you are using the remote controller, make sure correct indicator which matches your selection appears on
the remote controller display.
• Air flow can be adjusted manually (see page 20 for instructions).
NOTE
NOTE
NOTE
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 12 2012-02-01 오후 4:07:13

13
ENGLISH
Cool
In Cool mode, the air conditioner will cool your room. You can adjust the temperature and the fan speed to feel cooler in hot
season.
1. Turn on the air conditioner.
Press the Power button on the remote controller.
2. Set the operation mode.
Press the Mode button on the remote controller until Cool mode
indicator appears on the remote controller display.
The air conditioner operates in Cool mode and it will lower the
temperature in your room.
Each time you press the Mode button, the mode will change
in order of Auto, Cool, Dry, Fan and Heat*. (*Heat mode is
applicable for AP30M1 model only.)
3. Set the temperature.
Press the Temp + or - button on the remote controller to increase or
decrease the desired temperature.
You can set the desired temperature between the range of
18˚C~30˚C.
You can increase/decrease the temperature by 1˚C.
4. Set the fan speed.
Press the Fan or button on the remote controller to set the
desired fan speed.
If room temperature reaches desired value, the air conditioner will
shut off cooling for a while and just the fan runs.
Each time you press the Fan or button, fan speed will
change in order of Auto, Low, Medium and High.
• While you are using the remote controller, make sure correct indicator which matches your selection appears on the
remote controller display.
• Air flow can be adjusted manually (see page 20 for instructions).
• If current outside temperatures are much higher than the selected indoor temperature, it may take time to bring
the inner temperature to the desired coolness.
• If you operate the air conditioner right after stopping the cooling operation or the temperature reaches to the
desired temperature, cool air will not come out around 3 minutes for compressor protection.
NOTE
NOTE
NOTE
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 13 2012-02-01 오후 4:07:15

14
Operating basic function
Dry
The air conditioner in Dry mode acts like a dehumidifier by removing moisture from the indoor air. Dry mode makes the air
feel refreshing in a humid climate.
1. Turn on the air conditioner.
Press the Power button on the remote controller.
2. Set the operation mode.
Press the Mode button on the remote controller until Dry mode
indicator appears on the remote controller display.
The air conditioner operates in Dry mode and automatically adjust
the fan speed to Auto.
Each time you press the Mode button, the mode will change
in order of Auto, Cool, Dry, Fan and Heat*. (*Heat mode is
applicable for AP30M1 model only.)
3. Set the temperature.
Press the Temp + or - button on the remote controller to increase or
decrease the desired temperature.
You can set the desired temperature between the range of
18˚C~30˚C.
You can increase/decrease the temperature by 1˚C.
• While you are using the remote controller, make sure correct indicator which matches your selection appears on the
remote controller display.
• Air flow can be adjusted manually (see page 20 for instructions).
NOTE
NOTE
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 14 2012-02-01 오후 4:07:17

15
ENGLISH
Fan
Fan mode can be selected to ventilate your room. Fan mode will be helpful to refresh the stale air in your room.
1. Turn on the air conditioner.
Press the Power button on the remote controller.
2. Set the operation mode.
Press the Mode button on the remote controller until Fan mode
indicator appears on the remote controller display.
The air conditioner operates in Fan mode and circulate the indoor air.
Each time you press the Mode button, the mode will change
in order of Auto, Cool, Dry, Fan and Heat*. (*Heat mode is
applicable for AP30M1 model only.)
3. Set the fan speed.
Press the Fan or button on the remote controller to set the
desired fan speed.
Each time you press the Fan or button, fan speed will
change in order of Low, Medium and High.
• While you are using the remote controller, make sure correct indicator which matches your selection appears on the
remote controller display.
• Air flow can be adjusted manually (see page 20 for instructions).
NOTE
NOTE
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 15 2012-02-01 오후 4:07:18

16
Operating basic function
Heat (Only applicable for AP30M1 model)
The air conditioner heats as well as cools. Warm your room with this versatile appliance in the cold of winter.
1. Turn on the air conditioner.
Press the Power button on the remote controller.
2. Set the operating mode.
Press the Mode button on the remote controller until Heat mode
indicator appears on the remote controller display.
The air conditioner operates in Heat mode and warms your room.
Each time you press the Mode button, the mode will change in
order of Auto, Cool, Dry, Fan and Heat.
3. Set the temperature.
Press the Temp + or – button on the remote control to increase or
decrease the desired temperature.
You can set the desired temperature between the range of
16˚C~30˚C.
You can increase/decrease the temperature by 1˚C.
4. Set the fan speed.
Press the Fan or button on the remote controller to set the
desired fan speed.
If room temperature reaches desired value, heating will stop for a
while.
• Each time you press the Fan or button, fan speed will
change in order of Auto, Low, Medium and High.
• Fan may not operate for about 3~5 minutes at the beginning
to prevent any cold blasts while the air conditioner is warming
up.
• Air flow can be adjusted manually (see page 20 for instructions).
• Since the air conditioner heats the room by taking heat energy from outdoor air, the heating capacity may decrease
when outdoor temperature is extremely low. Use an additional heating appliance in combination with the air
conditioner if you feel the air conditioner heats insufficiently.
• Frost may form in outdoor unit during Heat mode. Defrost indicator will light up on the indoor unit display
when the outdoor unit starts removing frost and it will disappear when the operation is done.
NOTE
NOTE
NOTE
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 16 2012-02-01 오후 4:07:20

17
ENGLISH
Using advanced functions
Using the Turbo function
Turbo function will be helpful to cool or heat your room quickly and effectively by operating at the maximum fan speed for
30 minutes.
1. Turn on the air conditioner.
Press the Power button on the remote controller.
2. Set the operation mode.
Press the Turbo/Long button on the remote controller once. Turbo
indicator will appear on the remote controller display.
The air conditioner operates in High fan speed and automatically
adjusts the temperature according to the current room temperature.
The unit operates for 30 minutes and then operates in last used
mode or in Auto mode if Dry/Fan mode is most recent mode used.
• Turbo function is only available in Auto/Cool/Heat* mode.
(*Heat mode is applicable for AP30M1 model only.)
If Turbo function is selected in Dry/Fan mode, operation mode changes to Auto.
• You cannot use Turbo and Long function at the same time.
To deactivate Turbo function
1. Press the Turbo/Long button on the remote controller twice while Turbo function is on.
The air conditioner operates in last used mode or in Auto mode if Dry/Fan mode is most recent mode used.
• While you are using the remote controller, make sure corresponding indicator appears on the remote controller
display.
• Temperature/Fan speed cannot be adjusted while using this function.
• Air flow can be adjusted manually (see page 20 for instructions).
• If you press the Mode button while the Turbo function is on, it will cancel the function.
NOTE
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 17 2012-02-01 오후 4:07:21

18
Using advanced functions
Using the Long function
Long function will be helpful when you want the cool or warm air to go to much further place.
1. Turn on the air conditioner.
Press the Power button on the remote controller.
2. Set the operation mode.
Press the Turbo/Long button on the remote controller twice. Long
indicator will appear on the remote controller display.
The air conditioner operates in High fan speed and you can adjust
the desired temperature.
• Long function is only available in Auto/Cool/Heat* mode.
(*Heat mode is applicable for AP30M1 model only.)
If Long function is selected in Dry/Fan mode, operation mode changes to Auto.
• When using Long function, the air flow blades face upward and vertical air flow direction control is not possible.
• You cannot use Turbo and Long function at the same time.
To deactivate Long function
1. Press the Turbo/Long button on the remote controller while Long function is on.
The air conditioner operates in last used mode, or in Auto mode if Dry/Fan mode is most recent mode used.
• While you are using the remote controller, make sure corresponding indicator appears on the remote controller
display.
• Press Temp + or - button to adjust desired temperature. Each time you press the button, the temperature changes
by 1°C.
• Fan speed is set as High only and cannot be adjusted in Long function.
• In Long function, air flow can be adjusted in horizontal direction only (see page 20 for instructions).
NOTE
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 18 2012-02-01 오후 4:07:22

19
ENGLISH
Using the Smart Saver function
This function will set the temperature range limit to help you save energy while the air conditioner is operating in Cool mode.
1. Press the Smart Saver button on the remote controller while the air
conditioner is operating in Cool mode.
Smart Saver indicator appears automatically on the remote
controller display.
• Smart Saver function is only available in Cool mode and when Smart Saver function is canceled, air conditioner will
operate in Cool mode.
• Air flow direction can be adjusted vertically and horizontally. (See page 20 for instructions.)
• Temperature/Fan speed can also be adjusted (see step 3~4 on page 13 for instructions.)
• If you select Smart Saver function during Turbo/Long function, it will cancel the Turbo/Long function.
To deactivate the Smart Saver function.
1. Press the Smart Saver button on the remote controller.
Smart Saver function will be canceled and Smart Saver indicator will disappear on the remote controller display.
NOTE
Mirage_AP30M0@_IBIM_E_34518A(1).indd 19 2012-02-01 오후 4:07:22
