Samsung CLX-3175N/XAZ User manual

Color Laser MFP
CLX-317x series
CLX-3170/3170N/3170FN/3170FW
CLX-3175/3175N/3175FN/3175FW
SERVICEManual
Samsung Color Laser MFP The keynote of Product
The smallest / The lowest noise
High Quality Muti-path Color MFP
- Model : CLX-317x series
- Speed
. Mono : Up to 16 ppm in A4 (17 ppm in Letter)
. Color : Up to 4 ppm in A4 (4 ppm in Letter)
- Printing Resolution
. Max. 2400x600 dpi effective output
- Processor
. CHORUS3 (360Mhz), Proprietary SOC
Emulations : SPL-Color
- Memory : DDR2 SDRAM 128 MB
- Interfaces
. USB Device 2.0
. One 10/100 Base Tx network connector
. Wireless N/W (317xFW)
- Toner cartridge
. Black : 1K (initial) / 1.5K (sales)
. Color : 0.7K (initial) / 1K (sales)
- 150 Cassette, ADF
- Printer Life : 100K pages
CLX-317x series
Model : CLX-3175N/XAZ

Contents
1. Precautions
1.1 Safety Warning1-1
1.2 Caution for safety1-2
1.3 ESD Precautions1-5
2. Product spec and feature
 3URGXFW6SHFL¿FDWLRQV2-1
2.1.1 Product Overview2-1
 3URXGXFW6SHFL¿FDWLRQ2-2
2.1.3 Model Comparison Table 2-12
2.2 System Overview 2-13
2.2.1 System Structure 2-13
2.2.2 H/W description 2-23
2.2.3 CRUM 2-30
2.3 S/W Structure and Descriptions 2-31
2.3.1 Architecture 2-31
2.3.2 Language Monitor 2-31
2.3.3 Status Monitor 2-31
2.3.4 Network Interface 2-32
2.3.5 Printer Driver <-> Status Monitor 2-32
2.3.6 System F/W Flow 2-33
2.3.7 Alarm Shortage 2-34
2.3.8 Error status 2-34
2.3.9 CRUM Overview 2-35
2.3.10 Initailize Flow 2-36

Continued
3. Disassembly and Reassembly
3.1 Precautions when replacing parts3-1
3.1.1 Precautions when assembling and disassembling3-1
3.1.2 Preautions when handling PBA3-1
3.1.3 Releasing Plastic Latches3-1
3.2 Parts for Maintenance and Repair3-2
3.2.1 Replacement interval for parts with a limited life3-2
3.2.2 Printer Cleaning3-3
3.3 Information Related to Disassembly and Assembly3-4
3.3.1 Special service parts3-4
3.3.2 Screws used in the printer3-5
3.4 Disassembly Procedure3-8
3.4.1 Cover3-8
3.4.2 Scan Assy3-9
3.4.3 ADF Assy 3-10
3.4.4 OPE unit 3-12
3.4.5 Sheet ADF 3-13
3.4.6 CIS unit 3-14
3.4.7 Middle Cover 3-15
3.4.8 ITB3-16
3.4.9 Fuser 3-16
3.4.10 HVPS board 3-17
3.4.11 Main PBA 3-17
3.4.12 SMPS board 3-18
3.4.13 LSU Unit 3-18
3.4.14 Holder Pad 3-19
3.4.15 Transfer Unit 3-19
3.4.16 Pick up roller 3-20

Continued
4. Alignment & Troubleshooting
4.1 Alignment and Adjustments4-1
4.1.1 Control Panel overview4-1
4.1.2 Understanding The Status LED4-2
4.1.3 Paper path4-3
4.1.4 Menu Map4-9
4.1.5 F/W Upgrade 4-11
4.1.6 Tech Mode 4-12
4.1.7 EDC Mode  4-17
4.1.8 Periodic Defective Image 4-21
4.1.9 Error Message 4-22
4.2 Troubleshooting 4-27
4.2.1 Procedure of Checking the Symptoms 4-27
4.2.2 Troubleshooting Checklist 4-28
4.2.3 Solving General Printing Problems 4-29
4.2.4 Solving Print Quality Problems 4-40
4.2.5 Common Windows Problems 4-58
4.2.6 Common Macintosh Problems 4-59
4.2.7 Common Linux Problems 4-60
4.2.8 Major Problems Trouble shooting 4-64
4.2.9 Fax & Phone Problems 4-80
4.2.10 Copy Problems 4-88
4.2.11 Scanner, OPE problems 4-92
5. Exploded Views & Parts List
Thumbnail5-2
5.1 Main5-3
5.2 Cover Middle5-6
5.3 Cover Rear5-8
5.4 Cover Front 5-10

Continued
5.5 Scan Unit(4 in 1) 5-12
5.6 Standard ADF 5-14
5.7 Path Lower Unit 5-16
5.8 Scan Lower Unit 5-18
5.9 OPE Unit 5-20
5.10 Scan Upper Unit 5-22
5.11 Scan Unit(3 in 1) 5-24
5.12 Frame1 5-26
5.13 Frame2 5-28
5.14 Main Drive1 5-30
5.15 Main Drive2 5-33
5.16 Fuser Unit 5-35
5.17 Cartridge Transfer Unit 5-38
5.18 Tank Waste Unit 5-41
5.19 Cassette 5-43
6. System Diagram
6.1 Block Diagram6-1
6.2 Connection Diagram6-2
7. Reference Information
7.1 Tool for Troubleshooting7-1
7.2 Acronyms and Abbreviations7-2
7.3 Select a location for the printer7-4
7.4 A4 ISO 19752 Standard Pattern7-5

Precautions
Service Manual
1-1 Samsung Electronics
In order to prevent accidents and to prevent damage to the equipment please read the precautions listed
below carefully before servicing the printer and follow them closely.
1.1 Safety Warning
(1) Only to be serviced by appropriately qualified service engineers.
High voltages and lasers inside this product are dangerous. This printer should only be serviced by a
suitably trained and qualified service engineer.
(2) Use only Samsung replacement parts
There are no user serviceable parts inside the printer. Do not make any unauthorized changes or
additions to the printer, these could cause the printer to malfunction and create electric shock or fire haz-
ards.
(3) Laser Safety Statement
The Printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter
J for Class 1(1) laser products, and elsewhere, it is certified as a Class I laser product con-forming to the
requirements of IEC 825. Class I laser products are not considered to be hazardous. The laser system
and printer are designed so there is never any human access to laser radiation above a Class I level
during normal operation, user maintenance, or prescribed service condition.
Warning >> Never operate or service the printer with the protective cover removed from Laser/
Scanner assembly. The reflected beam, although invisible, can damage your eyes.
When using this product, these basic safety pre-cautions should always be followed to
reduce risk of fire, electric shock, and injury to persons.
1. Precautions

Precautions
Service Manual
1-2 Samsung Electronics
1.2 Caution for safety
1.2.1 Toxic material
This product contains toxic materials that could cause illness if ingested.
(1) If the LCD control panel is damaged it is possible for the liquid inside to leak. This liquid is toxic. Contact
with the skin should be avoided, wash any splashes from eyes or skin immediately and contact your
doctor. If the liquid gets into the mouth or is swallowed see a doctor immediately.
(2) Please keep Drum cartridge and Toner Cartridge away from children. The toner powder contained in the
Drum cartridge and Toner Cartridge may be harmful and if swallowed you should contact a doctor.
1.2.2 Electric Shock and Fire Safety Precautions
Failure to follow the following instructions could cause electric shock or potentially cause a fire.
(1) Use only the correct voltage, failure to do so could damage the printer and potentially cause a fire or
electric shock.
(2) Use only the power cable supplied with the printer. Use of an incorrectly specified cable could cause the
cable to overheat and potentially cause a fire.
(3) Do not overload the power socket, this could lead to overheating of the cables inside the wall and could
lead to a fire.
(4) Do not allow water or other liquids to spill into the printer, this can cause electric shock. Do not allow
paper clips, pins or other foreign objects to fall into the printer these could cause a short circuit leading to
an electric shock or fire hazard.
(5) Never touch the plugs on either end of the power cable with wet hands, this can cause electric shock.
When servicing the printer remove the power plug from the wall socket.
(6) Use caution when inserting or removing the power connector. The power connector must be inserted
completely otherwise a poor contact could cause overheating possibly leading to a fire. When removing
the power connector grip it firmly and pull.
(7) Take care of the power cable. Do not allow it to become twisted, bent sharply round corners or other
wise damaged. Do not place objects on top of the power cable. If the power cable is damaged it could
overheat and cause a fire or exposed cables could cause an electric shock. Replace a damaged power
cable immediately, do not reuse or repair the damaged cable. Some chemicals can attack the coating on
the power cable, weakening the cover or exposing cables causing fire and shock risks.
(8) Ensure that the power sockets and plugs are not cracked or broken in any way. Any such defects should
be repaired immediately. Take care not to cut or damage the power cable or plugs when moving the
machine.
(9) Use caution during thunder or lightening storms. Samsung recommend that this machine be disconnected
from the power source when such weather conditions are expected. Do not touch the machine or the
power cord if it is still connected to the wall socket in these weather conditions.
(10) Avoid damp or dusty areas, install the printer in a clean well ventilated location. Do not position the
machine near a humidifier. Damp and dust build up inside the machine can lead to overheating and
cause a fire.
(11) Do not position the printer in direct sunlight. This will cause the temperature inside the printer to rise
possibly leading to the printer failing to work properly and in extreme conditions could lead to a fire.
(12) Do not insert any metal objects into the machine through the ventilator fan or other part of the casing, it
could make contact with a high voltage conductor inside the machine and cause an electric shock.

Precautions
Service Manual
1-3 Samsung Electronics
1.2.3 Handling Precautions
The following instructions are for your own personal safety, to avoid injury and so as not to damage the
printer
(1) Ensure the printer is installed on a level surface, capable of supporting its weight. Failure to do so could
cause the printer to tip or fall.
(2) The printer contains many rollers, gears and fans. Take great care to ensure that you do not catch your
fingers, hair or clothing in any of these rotating devices.
(3) Do not place any small metal objects, containers of water, chemicals or other liquids close to the printer
which if spilled could get into the machine and cause damage or a shock or fire hazard.
(4) Do not install the machine in areas with high dust or moisture levels, beside on open window or close to a
humidifier or heater. Damage could be caused to the printer in such areas.
(5) Do not place candles, burning cigarettes, etc on the printer, These could cause a fire.
1.2.4 Assembly / Disassembly Precautions
Replace parts carefully, always use Samsung parts. Take care to note the exact location of parts and also
cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly.
Please carry out the following procedures before dismantling the printer or replacing any parts.
(1) Check the contents of the machine memory and make a note of any user settings. These will be erased if
the mainboard or network card is replaced.
(2) Ensure that power is disconnected before servicing or replacing any electrical parts.
(3) Disconnect printer interface cables and power cables.
(4) Only use approved spare parts. Ensure that part number, product name, any voltage, current or
temperature rating are correct.
(5) When removing or re-fitting any parts do not use excessive force, especially when fitting screws into
plastic.
(6) Take care not to drop any small parts into the machine.
(7) Handling of the OPC Drum
- The OPC Drum can be irreparably damaged if it exposed to light.
Take care not to expose the OPC Drum either to direct sunlight or to fluorescent or incandescent
room lighting. Exposure for as little as 5 mins can damage the surface? photoconductive properties
and will result in print quality degradation. Take extra care when servicing the printer. Remove the
OPC Drum and store it in a black bag or other lightproof container. Take care when working with the
covers(especially the top cover) open as light is admitted to the OPC area and can damage the OPC
Drum.
- Take care not to scratch the green surface of OPC Drum Unit.
If the green surface of the Drum Cartridge is scratched or touched the print quality will be compromised.

Precautions
Service Manual
1-4 Samsung Electronics
1.2.5 Disregarding this warning may cause bodily injury
(1) Be careful with the high temperature part.
The fuser unit works at a high temperature. Use caution when working on the printer. Wait for the fuser to
cool down before disassembly.
(2) Do not put finger or hair into the rotating parts.
When operating a printer, do not put hand or hair into the rotating parts (Paper feeding entrance, motor,
fan, etc.). If do, you can get harm.
(3) When you move the printer
- The equipment weighs approximately 15.2 Kg (including consumables), therefore pay attention when
handling it.
- Be sure not to hold the movable parts or units (e.g. the control panel, ADF) when transporting the
equipment.
- Be sure to use a dedicated outlet with 110V/220Vpower input.
- The equipment must be grounded for safety.
- Select a suitable place for installation. Avoid excessive heat, high humidity, dust, vibration and direct
sunlight.
- Provide proper ventilation since the equipment emits a slight amount of ozone.
- The equipment shall be installed near the socket outlet and shall be accessible.
- Be sure to fix and plug in the power cable securely after the installation so that no one trips over it.

Precautions
Service Manual
1-5 Samsung Electronics
1.3 ESD Precautions
Certain semiconductor devices can be easily damaged by static electricity. Such components are commonly
called “Electrostatically Sensitive (ES) Devices” or ESDs. Examples of typical ESDs are: integrated circuits,
some field effect transistors, and semiconductor “chip” components.
The techniques outlined below should be followed to help reduce the incidence of component damage
caused by static electricity.
Caution >>Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
1. Immediately before handling a semiconductor component or semiconductor-equipped assembly, drain
off any electrostatic charge on your body by touching a known earth ground. Alternatively, employ a
commercially available wrist strap device, which should be removed for your personal safety reasons prior
to applying power to the unit under test.
2. After removing an electrical assembly equipped with ESDs, place the assembly on a conductive surface,
such as aluminum or copper foil, or conductive foam, to prevent electrostatic charge buildup in the vicinity
of the assembly.
3. Use only a grounded tip soldering iron to solder or desolder ESDs.
4. Use only an “anti-static” solder removal device. Some solder removal devices not classified as “anti-static”
can generate electrical charges sufficient to damage ESDs.
5. Do not use Freon-propelled chemicals. When sprayed, these can generate electrical charges sufficient to
damage ESDs.
6. Do not remove a replacement ESD from its protective packaging until immediately before installing it. Most
replacement ESDs are packaged with all leads shorted together by conductive foam, aluminum foil, or a
comparable conductive material.
7. Immediately before removing the protective shorting material from the leads of a replacement ESD, touch
the protective material to the chassis or circuit assembly into which the device will be installed.
8. Maintain continuous electrical contact between the ESD and the assembly into which it will be installed,
until completely plugged or soldered into the circuit.
9. Minimize bodily motions when handling unpackaged replacement ESDs. Normal motions, such as
the brushing together of clothing fabric and lifting one’s foot from a carpeted floor, can generate static
electricity sufficient to damage an ESD.

Product spec and feature
Service Manual
2-1 Samsung Electronics
2.1 Product Specications
2.1.1 Product Overview
2. Product spec and feature
Concept
Target
The smallest & quietest C-MFP in the world
Home & SOHO
1.Speed
. Mono : Up to 16 ppm in A4 (17 ppm in Letter)
. Color : Up to 4 ppm in A4 (4 ppm in Letter)
2.Printing Resolution
. Max. 2400x600 dpi effective output
3.Processor
. CHORUS3 (360Mhz), Proprietary SOC
4.Printer Language Emulations
. SPL-Color
5.Memory
- DDR2 SDRAM 128 MB
6.Interfaces
. USB Device 2.0
. One 10/100 Base Tx network connector
- Wireless N/W (317xFW)
7. Toner cartridge
. Black : 1K (initial) / 1.5K (sales)
. Color : 0.7K (initial) / 1K (sales)
8. 150 Cassette, ADF
9. Color
Dark gray : CLX-3170 series
Black : CLX-3175 Series
CLX-3170 series
CLX-3175 series (4 in 1)
CLX-3175 series (3 in 1)

Product spec and feature
Service Manual
2-2 Samsung Electronics
2.1.2 Prouduct Specication
Specications are correct at the time of printing. Product specications are subject to change without notice.
See below for product specications.
2.1.2.1 General Specications
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Major Features Multi-Pass Color Laser Multi-Pass Color Laser
2400dpi class 2400dpi class
USB2.0 USB2.0
Ethernet 10/100 Base-Tx Ethernet 10/100 Base-Tx
Wireless LAN(IEEE 802.11b/g) :
Only CLX-317xFW
Size (W*D*H) 415 x 360 x 311 mm 415 x 373 x 342mm
Net Weight (Including Toner Cartridge) 14.3kg 15.2kg
MPU CHORUS3-360MHz CHORUS3-360MHz
Power
Consumption
Ready Less than 160WH Less than 160WH
Average Less than 350W
(Current:8A(110V)/3.5A(220V)
Less than 350W
(Current:8A(110V)/3.5A(220V)
Max/Peak 700W/1KW 700W/1KW
Sleep/Power off Less than 30W Less than 30W
Power Supply Input Voltage Low Voltage : 110 ~ 127VAC
High Voltage : 220 ~ 240VAC
Low Voltage : 110 ~ 127VAC
High Voltage : 220 ~ 240VAC
Input Frequency 50 / 60Hz(+/- 3Hz) 50 / 60Hz(+/- 3Hz)
Noise Printing Mono : 48dBA
Color : 47dBA
Mono : 48dBA
Color : 47dBA
Copy 50dBA Platen: 50dBA
ADF: 52dBA
Warm up time From Cold Status
(At rated volt)
Less than 35 seconds Less than 35 seconds
Max Monthly Volume
(Duty Cycle)
Color(50%) 4,000 pages
Mono(50%) 4,000 pages
Color(50%) 4,000 pages
Mono(50%) 4,000 pages
Average Monthly Volume Color(50%) 130 pages
Mono(50%) 130 pages
Color(50%) 130 pages
Mono(50%) 130 pages
Machine Life 100k images (Color 25K or
Mono 100K Pages or 5 years
whichever comes rst)
100k images (Color 25K or
Mono 100K Pages or 5 years
whichever comes rst)
Temperature Operating 10~32.5ç10~32.5ç
Storage (Un-Packed) 5~35 ç5~35ç
Storage (Packed) -20~40ç-20~40ç

Product spec and feature
Service Manual
2-3 Samsung Electronics
2.1.2.2 Print Specifications
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Print Speed Simplex B&W : 17ppm@Letter /16ppm@A4
Color : 4ppm@A4,.Letter
B&W : 17ppm@Letter /16ppm@A4
Color : 4ppm@A4,.Letter
Duplex N/A N/A
Print Emulation SPL-C SPL-C
Auto Emulation Sensing N/A N/A
Font Type N/A N/A
Number N/A N/A
Power Save Yes (5/10/15/30/60/120min.) Yes (5/10/15/30/60/120min.)
Resolution Normal Up to 2400X600dpi Class
(Default 1200x600 dpi)
Optical: 600x600 Dpi
Up to 2400X600dpi Class
(Default 1200x600 dpi)
Optical: 600x600 Dpi
Toner Save N/A N/A
FPOT From Ready Less than 26 sec ( Color )
Less than 14 sec ( B&W )
Less than 26 sec ( Color )
Less than 14 sec ( B&W )
From Idle Less than 57 sec ( Color )
Less than 45 sec (B&W)
Less than 57 sec ( Color )
Less than 45 sec (B&W)
From Cold Boot Less than 57 sec ( Color )
Less than 45 sec (B&W)
Less than 57 sec ( Color )
Less than 45 sec (B&W)
Duplex Print NA NA
Printable Area 210 x 297 mm (A4)
216 x 279 mm (Letter)
216 x 355.6 mm (Legal)
210 x 297 mm (A4)
216 x 279 mm (Letter)
216 x 355.6 mm (Legal)
Print Margin Side Margin: 4.23±2mm
Top Margin: 4.23±3mm
Side Margin: 4.23±2mm
Top Margin: 4.23±3mm
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Humidity Operating 30~80% RH 30~80% RH
Storage (Un-
Packed)
30~80% RH 30~80% RH
Storage (Packed) 30~85% RH 30~85% RH
Memory Standard / Max. 128MB / 128MB 128MB / 128MB
Type DDR2 SDRAM DDR2 SDRAM
Expand Memory Slot N/A N/A
Compression Technology YES YES

Product spec and feature
Service Manual
2-4 Samsung Electronics
2.1.2.3 Scan Specifications
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Scan Method Color CIS Color CIS
Scan Speed
through ADF
B/W N/A Approx. 18sec
Gray N/A Approx. 25sec
Color N/A Approx. 35sec
Scan Speed
through Platen
B/W Approx. 15sec Approx. 15sec
Gray Approx. 20sec Approx. 20sec
Color 75dpi/300dpi Approx. 30sec Approx. 30sec
Resolution Optical 1200*1200dpi 1200*1200dpi
Enhanced 4800dpi 4800dpi
Halftone 256 levels 256 levels
Scan Size Max. Document
Width
Max.216mm(8.5") Max.216mm(8.5")
Effective Scan
Width
Max 208mm(8.2”) Max 208mm(8.2”)
Scan-to Scan-to-Application Scan-to-Application
Scan-to-USB Scan-to-USB
Scan Depth Color 24 bits 24 bits
Mono 1bit for Line, Halftone , 8 Bit for
Gray scale
1bit for Line, Halftone , 8 Bit for
Gray scale
Scan to email Yes Yes
Compatibility Microsoft Windows:
2000/XP(Include 64bit)
Vista
Linux OS:
Red Hat 8~9, Fedora Core 1~4
Mandrake 9.2~10.1
SuSE 8.2~9.2
Microsoft Windows:
2000/XP(Include 64bit)
Vista
Linux OS:
Red Hat 8~9, Fedora Core 1~4
Mandrake 9.2~10.1
SuSE 8.2~9.2

Product spec and feature
Service Manual
2-5 Samsung Electronics
2.1.2.4 Copy Specifications
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Copy Quality
Selection or
Original Image
type selection
Mode: (Color)
Text
(Platen & ADF)
600x600dpi(Optical: 300x300dpi)
for Platen
600x600dpi(Optical: 300x300dpi)
Mixed
(Platen & ADF)
600x600dpi(Optical: 300x300dpi)
for Platen
600x600dpi(Optical: 300x300dpi)
Magazine 600x600dpi(Optical: 300x300dpi)
for Platen
600x600dpi(Optical: 300x300dpi)
for Platen
N/A 600x600dpi(Optical: 300x300dpi)
for ADF
Film Photo 1200x1200dpi(Optical:
600x600dpi) for Platen
1200x1200dpi(Optical:
600x600dpi) for Platen
Copy Quality
Selection or
Original Image
type selection
Mode:
(Black & White)
Text
(Platen & ADF)
600x600dpi(Optical: 300x300dpi)
for Platen
600x600dpi(Optical: 300x300dpi)
Mixed
(Platen & ADF)
600x600dpi(Optical: 300x300dpi)
for Platen
600x600dpi(Optical: 300x300dpi)
Photo 1200x1200dpi(Optical:
600x600dpi)
1200x1200dpi(Optical:
600x600dpi)
N/A 600x600dpi(Optical: 300x300dpi)
Magazine 600x600dpi(Optical: 300x300dpi)
for Platen
600x600dpi(Optical: 300x300dpi)
for Platen
N/A 600x600dpi(Optical: 300x300dpi)
for ADF
FCOT From Ready Mono : Less than 18 sec
Color : Less than 34 sec
Mono : Less than 18 sec
Color : Less than 34 sec
Copy Speed SDMC* at all mode 16cpm/A4(Mono),
17cpm/Ltr(Mono),
4cpm/A4,Ltr(Color)
16cpm/A4(Mono),
17cpm/Ltr(Mono),
4cpm/A4,Ltr(Color)
Origin
Alignment
Platen REAR LEFT REAR LEFT
ADF N/A Center
Zoom Range 25% to 400% for Platen 25% to 400% for Platen
25% to 100% for ADF
Number of Copies(Multi Copy) 1~99 1~99
Preset Original(100%)
A4 ( A5(71%)
A4 ( LTR(94%)
EXE ( LTR(94%)
A5 ( A4(141%)
50%, 150%, 200%
Custom 50%~200%
Original(100%)
A4 ( A5(71%)
A4 ( LTR(94%)
EXE ( LTR(94%)
A5 ( A4(141%)
50%, 150%, 200%
Custom 50%~200%
Contrast Levels 3 level 3 level

Product spec and feature
Service Manual
2-6 Samsung Electronics
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Copy Mode(=Quality) Text, Mixed, Magazine, Film
Text, Mixed, Magazine, Film
Auto return to default mode Yes Yes
Changeable Default mode Contrast, Image, Reduce/Enlarge,
No. of Copies
Contrast, Image, Reduce/Enlarge,
No. of Copies
Special Copy Auto Fit Copy Yes Yes(Platen only)
ID Copy Yes Yes(Platen Only)
Clone Yes Yes(Platen only)
Poster Yes(X9 Only) Yes(Platen only, X9 Only)
Special Copy 2-up,4-upYes Yes
*SDMC : Single Document Multiple Copy
2.1.2.5 Telephone Specifications
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Handset N/A No
On hook Dial N/A Yes
1-Touch Dial N/A No
Speed Dial N/A 240 locations
TAD I/F N/A Yes
Tone/Pulse N/A Selectable in Tech mode
Pause N/A Yes
Auto Redial N/A Yes
Last Number Redial N/A Yes
Distinctive Ring N/A Yes
Caller ID N/A No
External Phone Interface N/A Yes
Report & List
Print out
Tx/Rx Journal N/A Yes
Confirmation N/A 2 Types available (with Image
TCR,W/O Image TCR. Mono
Only)
Help List N/A No
Auto Dial List N/A Yes
System Data List N/A List all user setting
Sound Control Ring Volume N/A Yes(Off, Low, MED, HIGH)
Key Volume Yes Yes
Alarm Volume Yes Yes
Speaker N/A Yes(On, Off)

Product spec and feature
Service Manual
2-7 Samsung Electronics
2.1.2.6 Fax Specifications
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Compatibility N/A ITU-T G3
Communication System N/A PSTN/PABX
Modem Speed N/A 33.6Kbps
TX Speed N/A 3sec(Mono/Standard/ECM-MMR.
ITU-T G3 No1.standard)
Compression N/A MH/MR/MMR/JPEG/JBIG
Color Fax N/A Yes
ECM N/A Yes
Resolution Mono.Std N/A 203*98dpi
Mono.Fine N/A 203*196dpi
Mono.S.Fine N/A 300*300dpi
Color N/A 200*200dpi
Scan
Speed(ADF)
Std N/A 3 sec/ LTR
Fine N/A 5 sec/ LTR
S.Fine N/A 6 sec/ LTR
Rx fax duplex print out N/A No
Multiple page scan speed N/A 17ppm/LTR, Std mode
(203*98dpi, ITU-T #1)
Receive Mode N/A Fax, TEL, Ans/Fax, DRPD
Memory Capacity N/A 2MB
Optional Memory N/A No
Max locations to
store to 1 Group Dial
N/A 240 locations
Fax Forward N/A Yes(On/Off), both Sent and
Received
Broadcasting N/A up to 200 locations
Cover page N/A No
Delayed fax N/A Yes (Mono only)
Memory RX N/A Yes
Functions Voice Request N/A No
TTI N/A Yes
RTI N/A Yes
Polling N/A No
Earth/Recall N/A No
Auto Reduction N/A Yes (On,Off)
SMS N/A No
RDS N/A N/A

Product spec and feature
Service Manual
2-8 Samsung Electronics
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Junk Fax barrier N/A Yes
Secure Receive N/A Yes
Memory Back-up N/A Yes(Flash Memory)
Battery Backup N/A Yes
Rx FAX Duplex Print Out N/A No
Receive Mode N/A Fax, TEL, Ans/Fax
Capacity N/A 2MB(100 Pages) (Mono)
Optional Memory N/A No
Max locations to store to N/A 240 Locations
1 Group Dial
Fax Forward to FAX N/A Yes(On/Off), both Sent and
Received, Mono Only
Fax Forward to e-mail N/A No
Broadcasting N/A up to 249 locations, Mono Only
Cover page N/A No
Delayed fax N/A Yes (Tx only, Mono Only)
Memory RX N/A Yes
Mail Box(Electronic) N/A No
2.1.2.7 Paper Handling
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Capacity
(20lbs)
Cassette 150sheets@75g/m2 (Max) 150sheets@75g/m2 (Max)
Envelop : 5 Sheets Envelop : 5 Sheets
Transparency : 1 Sheets Transparency : 1 Sheets
Label , thick paper : 5 Sheets Label , thick paper : 5 Sheets
MP Tray N/A N/A
Output Capacity Face Down: 100Sheets/20lb
Envelop : 5 Sheets
Transparency : 1 Sheet
Label , thick paper : 5 Sheets
GlossyPhoto160 g/m2 : 1 Sheets
Face Down: 100Sheets/20lb
Envelop : 5 Sheets
Transparency : 1 Sheet
Label , thick paper : 5 Sheets
GlossyPhoto160 g/m2 : 1 Sheets
Output Full Sensing No No
Duplex N/A N/A
Paper Type Cassette A4, A5, A6, Letter, Legal,
Executive, Folio, ISO B5, JIS B5
A4, A5, A6, Letter, Legal,
Executive, Folio, ISO B5, JIS B5
Transparency : (Mono Print Only) Transparency : (Mono Print Only)
GlossyPhoto160 g/m2 GlossyPhoto160 g/m2
MP Tray N/A N/A

Product spec and feature
Service Manual
2-9 Samsung Electronics
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Paper Weight Cassette 16~43 lb. (60 to 163g/) 16~43 lb. (60 to 163g/)
Paper Path Standard output Bottom to Top Front (FIFO) Bottom to Top Front (FIFO)
Straight Through N/A N/A
Paper Size Max 216 x 355.6mm(8.5"x14") 216 x 355.6mm(8.5"x14")
Min 76 x 160mm(3"x6.3") 76 x 160mm(3"x6.3")
ADF Paper Weight N/A
Capacity N/A 15 pages
2.1.2.8 Driver
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Supporting OS Microsoft Windows:
2000/2003/XP(Include 64bit),Vista
MacOS:10.3,10.4
Linux(Printer only)OS:
Red Hat 8~9, Fedora Core 1~4
Mandrake 9.2~10.1
SuSE 8.2~9.2
Microsoft Windows:
2000/2003/XP(Include 64bit),Vista
MacOS:10.3,10.4
Linux(Printer only)OS:
Red Hat 8~9, Fedora Core 1~4
Mandrake 9.2~10.1
SuSE 8.2~9.2
Default Driver SPL-C SPL-C
Driver feature Microsoft Windows:
- Watermark
- N-up printing
- Poster printing
- Manual Dulpex
- Quality(Best,Normal,Draft)
- Color mode(Color, Gray scale)
- Device Color Support
- Color Management Support
[Mac]
- N-up printing
- Quality(Best,Normal,Draft)
- Color mode(Color, Gray scale)
- Color Management Support
[Linux]
- N-up printing
- Quality(Best,Normal,Draft)
- Color Management Support
- Color mode(Color, Gray scale)
[Common]
- N/W Install
during driver install
Microsoft Windows:
- Watermark
- N-up printing
- Poster printing
- Manual Dulpex
- Quality(Best,Normal,Draft)
- Color mode(Color, Gray scale)
- Device Color Support
- Color Management Support
[Mac]
- N-up printing
- Quality(Best,Normal,Draft)
- Color mode(Color, Gray scale)
- Color Management Support
[Linux]
- N-up printing
- Quality(Best,Normal,Draft)
- Color Management Support
- Color mode(Color, Gray scale)
[Common]
- N/W Install
during driver install
WHQL Windows 2000 including vista Windows 2000 including vista

Product spec and feature
Service Manual
2-10 Samsung Electronics
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
Language Locallization [Windows]
- Korean, English, French, Germa N,
Italian, Spanish, Russian, Dutch,
E.Portuguese, B.Portuguese, Fi
Nish, Swedish, Norwegian, Danish
S.Chinese, T.Chinese, Polish,
Hungarian, Greek, Czech, Turkish
[Mac]
- Korean, English, French, Germa N,
Italian, Spanish, Dutch, Portunuese,
S.Chinese, T.Chinese
[Linux]
- English Only
[Windows]
- Korean, English, French, Germa N,
Italian, Spanish, Russian, Dutch,
E.Portuguese, B.Portuguese, Fi
Nish, Swedish, Norwegian, Danish
S.Chinese, T.Chinese, Polish,
Hungarian, Greek, Czech, Turkish
[Mac]
- Korean, English, French, Germa N,
Italian, Spanish, Dutch, Portunuese,
S.Chinese, T.Chinese
[Linux]
- English Only
Smart Panel USB USB/Network
Default Install Default Install
Network Management Set IP.SWAS &SWS
(Linux, Mac not support, SWAS&SWS
need I explorer 5.0 or Higher)
Set IP.SWAS &SWS
(Linux, Mac not support, SWAS&SWS
need I explorer 5.0 or Higher)
Smart Thru Smart Thru 4 Smart Thru 4
TWAIN Yes Yes
2.1.2.9 Interface
Item CLX-317x/CLX-317xN CLX-317xFN/CLX-317xFW
USB USB Device 2.0
USB Host 2.0(Scan to USB,
Direct Print, PictBridge)
USB Device 2.0
USB Host 2.0(Scan to USB,
Direct Print, PictBridge)
Network Ethernet 10/100 base Tx Ethernet 10/100 base Tx
Wireless No IEEE 802.11b/g (CLX-3175FW only)
Protocol TCP/IP,IPP,SNMPv2 TCP/IP,IPP,SNMPv2 TCP/IP,IPP,SNMPv2
Network OS - Microsoft Windows:
2000/XP(32/64Bit)/2003
Server(32/64Bit) Vista
- Mac OS: 10.3~10.5(Printing
Only TCP/IP)
- Linux OS: Red Hat 8~9, Fedora
Core 1~4
Mandrake 9.2~10.1 & Suse
8.2~9.2
- Unix HP-UX, Solaris,SunOS
SCO UNIX
- Microsoft Windows:
2000/XP(32/64Bit)/2003
Server(32/64Bit) Vista
- Mac OS: 10.3~10.5(Printing Only
TCP/IP)
- Linux OS: Red Hat 8~9, Fedora
Core 1~4
Mandrake 9.2~10.1 & Suse
8.2~9.2
- Unix HP-UX, Solaris,SunOS
SCO UNIX
