Samsung Scx 3205 User manual

Service Manual

Mono Laser MFP

SCX-3200/3205

SCX-3205W

5. Interfaces

• One USB port

• One 10/100 Base TX network connector (SCX-3205W)

• One 802.11b/g/n wireless module (SCX-3205W)

6. Toner cartridge

• Initial : 700 pages

• Sales : 1,500 pages

7. Machine life

• 30,000 sheets or 3 years (whichever comes rst)

1. Print / Copy Speed

• 17 ppm in letter

2. Processor

• Jupiter5 375 Mhz

3. Printer Language Emulations

• SPL, PCL5e

4. Memory

• 32 MB (SCX-3200/3205)

• 128 MB (SCX-3205W)

The keynote of Product

ⓒ

Samsung Electronics Co.,Ltd. February. 2010

Printed in Korea.

VERSION NO. : 1.00 CODE : 3200-00000E

GSPN (Global Service Partner Network)

North America : service.samsungportal.com

Latin America : latin.samsungportal.com

CIS : cis.samsungportal.com

Europe : europe.samsungportal.com

China : china.samsungportal.com

Asia : asia.samsungportal.com

Mideast & Africa : mea.samsungportal.com

1.1 Safety Warning …………………………………………………… 1-1

1.2 Caution for safety ………………………………………………… 1-2

1.2.1 Toxic material………………………………………………… 1-2

1.2.2 Electric Shock and Fire Safety Precautions ……………… 1-2

1.2.3 Handling Precautions ……………………………………… 1-3

1.2.4 Assembly / Disassembly Precautions …………………… 1-3

1.2.5 Disregarding this warning may cause bodily injury ……… 1-4

1.3 ESD Precautions ………………………………………………… 1-5

2.1 Product Specications …………………………………………… 2-1

2.1.1 Product Overview …………………………………………… 2-1

2.1.2 Specications………………………………………………… 2-2

2.1.3 Model Comparison Table …………………………………… 2-11

2.2 System Overview ………………………………………………… 2-12

2.2.1 Front View …………………………………………………… 2-12

2.2.2 Rear View …………………………………………………… 2-13

2.2.3 System Layout ……………………………………………… 2-14

2.2.4 Engine H/W Specications ………………………………… 2-21

2.2.5 Engine F/W Contol Algorithm ……………………………… 2-27

2.2.6 S/W Descriptions …………………………………………… 2-29

3.1 Precautions when replacing parts ……………………………… 3-1

3.1.1 Precautions when assembling and disassembling ……… 3-1

3.1.2 Preautions when handling PBA …………………………… 3-1

3.1.3 Releasing Plastic Latches ………………………………… 3-1

chapter 1 Precautions

chapter 2 Product Overview

Contents

chapter 3 Maintenance and Disassembly

3.2 Screws used in the printer ……………………………………… 3-2

3.3 Left / Right cover ………………………………………………… 3-3

3.4 Scanner unit ……………………………………………………… 3-4

3.4.1 OPE unit ……………………………………………………… 3-5

3.4.2 CIS unit ……………………………………………………… 3-6

3.4.3 Scan motor…………………………………………………… 3-7

3.5 Middle cover and COVER-OPEN ……………………………… 3-9

3.6 Front and Rear cover …………………………………………… 3-10

3.7 Main PBA ………………………………………………………… 3-10

3.8 SMPS / HVPS board …………………………………………… 3-11

3.9 Fuser unit ………………………………………………………… 3-12

3.10 LSU ……………………………………………………………… 3-13

3.11 Drive unit ………………………………………………………… 3-14

3.12 Step motor ……………………………………………………… 3-15

3.13 Pick up roller …………………………………………………… 3-16

3.14 Transfer roller …………………………………………………… 3-17

4.1 Alignment and Adjustments……………………………………… 4-1

4.1.1 Control Panel ………………………………………………… 4-1

4.1.2 Understanding the status LED …………………………… 4-2

4.1.3 JAM Removal ……………………………………………… 4-3

4.1.4 EDC mode …………………………………………………… 4-6

4.1.5 Tech mode …………………………………………………… 4-9

4.1.6 Upgrade Firmware ………………………………………… 4-17

4.1.7 Periodic Defective Image…………………………………… 4-21

4.2 Troubleshooting…………………………………………………… 4-22

4.2.1 Procedure of Checking the Symptoms …………………… 4-22

4.2.2 Error code and troubleshooting …………………………… 4-23

4.2.3 Printing quality problems …………………………………… 4-44

4.2.4 Copy Problems ……………………………………………… 4-58

4.2.5 Scan problems ……………………………………………… 4-62

4.2.6 Other errors ………………………………………………… 4-64

chapter 4 Alignment and Troubleshooting

Contents

5.1 Block Diagram …………………………………………………… 5-1

5.2 Connection Diagram……………………………………………… 5-2

6.1 Tool for Troubleshooting ………………………………………… 6-1

6.2 Acronyms and Abbreviations …………………………………… 6-2

6.2.1 Acronyms …………………………………………………… 6-2

6.2.2 Service Parts ………………………………………………… 6-4

6.3 A4 ISO 19798 Standard Pattern………………………………… 6-8

6.3.1 A4 ISO 19752 Standard Pattern …………………………… 6-8

6.4 Selecting a location ……………………………………………… 6-9

Contents

chapter 6 Reference Information

chapter 5 System Diagram

attached Exploded Views & Parts List

Precautions

Service Manual

1-1 Samsung Electronics

In order to prevent accidents and damages to the equipment please read the precautions listed below

carefully before servicing the product and follow them closely.

1.1 Safety warning

(1) Only to be serviced by a factory trained service technician.

High voltages and lasers inside this product are dangerous. This product should only be serviced by a

factory trained service technician.

(2) Use only Samsung replacement parts.

There are no user serviceable parts inside the product. Do not make any unauthorized changes or

additions to the product as these could cause the product to malfunctions and create an electric shocks

or re hazards.

(3) Laser Safety Statement

The product is certied in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1

Subchapter J for Class 1(1) laser products, and elsewhere, it is certied as a Class I laser product con-

forming to the requirements of IEC 825. Class I laser products are not considered to be hazardous. The

laser system and product are designed so there is never any human access to laser radiation above a

Class I level during normal operation, user maintenance, or prescribed service condition.

Warning >> Never operate or service the product with the protective cover removed from Laser/Scanner

assembly. The reected beam, although invisible, can damage your eyes.

When using this product, these basic safety pre-cautions should always be followed to reduce

risk of re, electric shock, and personal injury.

1. Precautions

Precautions

Service Manual

1-2 Samsung Electronics

1.2 Caution for safety

1.2.1 Toxic material

This product contains toxic materials that could cause illness if ingested.

(1) If the LCD control panel is damaged, it is possible for the liquid inside to leak. This liquid is toxic.

Contact with the skin should be avoided. Wash any splashes from eyes or skin immediately and contact

your doctor. If the liquid gets into the mouth or is swallowed, see a doctor immediately.

(2) Please keep imaging unit and toner cartridge away from children. The toner powder contained in the

imaging unit and toner cartridge may be harmful, and if swallowed, you should contact a doctor.

1.2.2 Electric shock and re safety precautions

Failure to follow the following instructions could cause electric shock or potentially cause a re.

(1) Use only the correct voltage, failure to do so could damage the product and potentially cause a re or

electric shock.

(2) Use only the power cable supplied with the product. Use of an incorrectly specied cable could cause the

cable to overheat and potentially cause a re.

(3) Do not overload the power socket, this could lead to overheating of the cables inside the wall and could

lead to a re, and/or cause your ceiling or lamp lights to icker.

(4) Do not allow water or other liquids to spill into the product, this can cause electric shock. Do not allow

paper clips, pins or other foreign objects to fall into the product, these could cause a short circuit leading

to an electric shock or re hazard.

(5) Never touch the plugs on either end of the power cable with wet hands, this can cause electric shock.

When servicing the product, remove the power plug from the wall socket.

(6) Use caution when inserting or removing the power connector. When removing the power connector, grip it

rmly and pull. The power connector must be inserted completely, otherwise a poor contact could cause

overheating possibly leading to a re.

(7) Take care of the power cable. Do not allow it to become twisted, bent sharply around corners or wise

damaged. Do not place objects on top of the power cable. If the power cable is damaged it could overheat

and cause a re. Exposed cables could cause an electric shock. Replace the damaged power cable

immediately, do not reuse or repair the damaged cable. Some chemicals can attack the coating on the

power cable, weakening the cover or exposing cables causing re and shock risks.

(8) Ensure that the power sockets and plugs are not cracked or broken in any way. Any such defects should

be repaired immediately. Take care not to cut or damage the power cable or plugs when moving the

machine.

(9) Use caution during thunder or lightning storms. Samsung recommends that this machine be disconnected

from the power source when such weather conditions are expected. Do not touch the machine or the

power cord if it is still connected to the wall socket in these weather conditions.

(10) Avoid damp or dusty areas, install the product in a clean well ventilated location. Do not position the

machine near a humidier or in front of an air conditioner. Moisture and dust built up inside the machine

can lead to overheating and cause a re or cause parts to rust.

(11) Do not position the product in direct sunlight. This will cause the temperature inside the product to rise

possibly leading to the product failing to work properly and in extreme conditions could lead to a re.

(12) Do not insert any metal objects into the machine through the ventilator fan or other part of the casing, it

could make contact with a high voltage conductor inside the machine and cause an electric shock.

Precautions

Service Manual

1-3 Samsung Electronics

1.2.3 Handling precautions

The following instructions are for your own personal safety to avoid injury and so as not to damage the

product.

(1) Ensure the product is installed on a level surface, capable of supporting its weight. Failure to do so could

cause copy quality problems, and/or the product to tip or fall.

(2) The product contains many rollers, gears and fans. Take great care to ensure that you do not catch your

ngers, hair or clothing in any of these rotating devices.

(3) Do not place any small metal objects, containers of water, chemicals or other liquids close to the product

which if spilled could get into the machine and cause damage or a shock or re hazard.

(4) Do not install the machine in areas with high dust or moisture levels, beside on open window or close to a

humidier or heater. Damage could be caused to the product in such areas.

(5) Do not place candles, burning cigarettes, etc on the product, These could cause a re.

1.2.4 Assembly / Disassembly precautions

Replace parts carefully and always use Samsung parts. Take care to note the exact location of parts and also

cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly.

Please carry out the following procedures before dismantling the product or replacing any parts.

(1) Check the contents of the machine memory and make a note of any user settings. These will be erased if

the main board or network card is replaced.

(2) Ensure that power is disconnected before servicing or replacing any electrical parts.

(3) Disconnect interface cables and power cables.

(4) Only use approved spare parts. Ensure that part number, product name, any voltage, current or

temperature rating are correct.

(5) When removing or re-tting any parts do not use excessive force, especially when tting screws into

plastic.

(6) Take care not to drop any small parts into the machine.

(7) Handling of the OPC Drum

- The OPC Drum can be irreparably damaged if it exposed to light.

Take care not to expose the OPC Drum either to direct sunlight or to uorescent or incandescent room

lighting. Exposure for as little as 5 minutes can damage the surface of the photoconductive properties

and will result in print quality degradation. Take extra care when servicing the product. Remove the OPC

Drum and store it in a black bag or other lightproof container. Take care when working with the Covers

(especially the top cover) open as light is admitted to the OPC area and can damage the OPC Drum.

- Take care not to scratch the green surface of OPC Drum Unit.

If the green surface of the Drum Cartridge is scratched or touched the print quality will be compromised.

Precautions

Service Manual

1-4 Samsung Electronics

1.2.5 Disregarding this warning may cause bodily injury

(1) Be careful with the high temperature part.

The fuser unit works at a high temperature. Use caution when working on the printer. Wait for the fuser to

cool down before disassembly.

(2) Do not put nger or hair into the rotating parts.

When operating a printer, do not put hand or hair into the rotating parts (Paper feeding entrance, motor,

fan, etc.). If done, you can get harmed.

(3) When you move the printer.

This printer weighs 4.72kg (10.41 lbs) including toner cartridge and cassette. Use safe lifting and handling

techniques. Use the lifting handles located on each side of the machine. Back injury could be caused if

you do not lift carefully.

(4) Ensure the printer is installed safely.

The printer weighs 4.72kg (10.41 lbs), ensure the printer is installed on a level surface, capable of

supporting its weight. Failure to do so could cause the printer to tip or fall possibly causing personal injury

or damaging the printer.

(5) Do not install the printer on a sloping or unstable surface. After installation, double check that the printer

is stable.

Precautions

Service Manual

1-5 Samsung Electronics

1.3 ESD precautions

Certain semiconductor devices can be easily damaged by static electricity. Such components are commonly

called “Electrostatically Sensitive (ES) Devices” or ESDs. Examples of typical ESDs are: integrated

circuits,some eld effect transistors, and semiconductor “chip” components.

The techniques outlined below should be followed to help reduce the incidence of component damage

caused by static electricity.

Caution >>Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.

1. Immediately before handling a semiconductor component or semiconductor-equipped assembly, drain

off any electrostatic charge on your body by touching a known earth ground. Alternatively, employ a

commercially available wrist strap device, which should be removed for your personal safety reasons prior

to applying power to the unit under test.

2. After removing an electrical assembly equipped with ESDs, place the assembly on a conductive surface,

such as aluminum or copper foil, or conductive foam, to prevent electrostatic charge buildup in the vicinity

of the assembly.

3. Use only a grounded tip soldering iron to solder or desolder ESDs.

4. Use only an “anti-static” solder removal device. Some solder removal devices not classied as “anti-static”

can generate electrical charges sufcient to damage ESDs.

5. Do not use Freon-propelled chemicals. When sprayed, these can generate electrical charges sufcient to

damage ESDs.

6. Do not remove a replacement ESD from its protective packaging until immediately before installing it.

Most replacement ESDs are packaged with all leads shorted together by conductive foam, aluminum foil,

or a comparable conductive material.

7. Immediately before removing the protective shorting material from the leads of a replacement ESD, touch

the protective material to the chassis or circuit assembly into which the device will be installed.

8. Maintain continuous electrical contact between the ESD and the assembly into which it will be installed,

until completely plugged or soldered into the circuit.

9. Minimize bodily motions when handling unpackaged replacement ESDs. Normal motions, such as

the brushing together of clothing fabric and lifting one’s foot from a carpeted oor, can generate static

electricity sufcient to damage an ESD.

Product spec and feature

Service Manual

2-1 Samsung Electronics

2.1 Product Specications

2.1.1 Product Overview

2. Product spec and feature

1. Print / Copy Speed

• 17 ppm in letter

2. Processor

• Jupiter5 375 Mhz

3. Printer Language Emulations

• SPL, PCL5e

4. Memory

• 32 MB (SCX-3200/3205)

• 128 MB (SCX-3205W)

5. Interfaces

• One USB port

• One 10/100 Base TX network connector (SCX-3205W)

• One 802.11b/g/n wireless module (SCX-3205W)

6. Toner cartridge

• Initial : 700 pages

• Sales : 1,500 pages

7. Machine life

• 30,000 sheets or 3 years (whichever comes rst)

SCX-3200/3205

SCX-3205W

Product spec and feature

Service Manual

2-2 Samsung Electronics

2.1.2 Specications

• Product Specications are subject to change without notice. See below for product specications.

2.1.2.1 General Specication

Items SCX-3200/3205 SCX-3205W

Major Functions Standard - Copy

- Print

- Scan

- Copy

- Print & N/W Print

- Scan

- Wireless LAN

- DLNA

Option - -

Dimension (WxDxH) 15.28 x 11.77 x 9.21 inches

(388 x 299 x 234 mm)

15.28 x 11.77 x 9.21 inches

(388 x 299 x 234 mm)

Weight with Package 7.5 Kg (16.63 lbs) 7.5 Kg (16.63 lbs)

LCD 7-Segment(2-Digit) 7-Segment(2-Digit)

I/O Interface Standard Hi-Speed USB 2.0 Hi-Speed USB 2.0,

Ethernet 10/100 Base TX

(Embedded type)

Wireless LAN 802.11 b/g/n

Option - -

Power

Consumption Avg operation Less than 270 W Less than 270 W

Sleep Mode Less than 3.8 W Less than 5.6 W

Standby Mode Less than 36 W Less than 36 W

Noise (Sound

Pressure)

Operating Printing : 49dBA

Copying : 49dBA

Printing : 49dBA

Copying : 49dBA

Standby Less than 26 dBA Less than 26 dBA

Warm Up Time from Sleep Start Less than 15 sec Less than 15 sec

Machine Life Monthly Duty Cycle 5,000 pages 5,000 pages

Average Monthly Print

Volume 101 pages 101 pages

Average Monthly Scan

Volume - -

Machine Life Engine :30,000 sheets or 3 years

(whichever comes rst)

Engine :30,000 sheets or 3 years

(whichever comes rst)

ADF Feed Roller - -

ADF Rubber Pad - -

Pick-up Roller 30,000 pages 30,000 pages

Transfer Roller 30,000 pages 30,000 pages

Fuser Unit 30,000 pages 30,000 pages

CPU 375 MHz 375 MHz

Product spec and feature

Service Manual

2-3 Samsung Electronics

2.1.2.2 Print Specication

Items SCX-3200/3205 SCX-3205W

Print Speed Up to 16 ppm in A4

(17 ppm in Letter)

Up to 16 ppm in A4 (17 ppm in Letter)

Print Language (Emulation) SPL, PCL5e SPL, PCL5e

Power Save Yes (1, 5, 10, 15, 20, 30, 45, 60, 120

minutes)

Yes (1, 5, 10, 15, 20, 30, 45, 60, 120

minutes)

Power rating 110 ~ 127 VAC(-10%-6%), 50/60Hz, 4.0A

220 ~ 240 VAC(-10%-6%), 50/60Hz, 2.0A

110 ~ 127 VAC(-10%-6%), 50/60Hz, 4.0A

220 ~ 240 VAC(-10%-6%), 50/60Hz, 2.0A

Resolution Up to 1200 dpi Effective Output

(Addressable 1200 x 1200 dpi)

Up to 1200 dpi Effective Output

(Addressable 1200 x 1200 dpi)

Memory 32 MB 128 MB

FPOT Less than 10 sec (from Ready mode)

Less than 30 sec (from Sleep mode)

Less than 10 sec (from Ready mode)

Less than 30sec (from Sleep mode)

Duplex Print

Halftone(Gray Scale) 256 Levels 256 Levels

N/W Print Compatibility -Windows 2000/

XP(32/64bit)/2003(32/64bit)/

Vista(32/64bit)/2008(32/64bit)/

in7(32/64bit)/

2008R2(64bit)

Various Linux OS:

- RedHat Enterprise Linux WS 4, 5

(32/64bit)

- Fedora Core 2~9 (32/64bit)

- Mandriva 2005, 2006, 2007,

2008(32/64bit)

- openSuSE 9.1, 9.2, 9.3, 10.0, 10.1,

10.2, 10.3, 11.0 (32bit)

- SuSE Linux Enterprise Desktop 9, 10

(32/64bit)

- Ubuntu 6.04, 6.10, 7.04, 7.10, 8.04

(32/64bit)

- Debian 3.1, 4.0 (32/64bit)

Mac OS 10.3~10.6

Unix AT&T system V(Rel 4.2), BSD4.3,

HP-UX (Rel 9.x & Rel 10.x), SCO 5.x,

SUNOS 5.5, Sparc or Solaris 2.5

Printing

Protocols -TCP/IPv4/IPv6, HTTP, SNMPv1/v2c/v3,

LDAP, SMTP, Ethertalk

Novell N/W

Print Service

-Netware 5.x, 6.x (TCP/IP Only)

Device

Discovery

-Rendezvous(Bonjour), SLP, UPnP

Product spec and feature

Service Manual

2-4 Samsung Electronics

2.1.2.3 Scan Specication

Items SCX-3200/3205 SCX-3205W

Scan Method Color CIS Color CIS

Scan Speed Linearity,

Halftone

15 sec (at Pc scan : P4-2.4GHz,
