Samsung CLX-330x series User manual

ColorLaserMFP
CLX-330xseries
CLX-330x/330xW/330xFN/
330xFW
(Ver1.0)
SERVICEMANUAL
ColorLaserMFPContents
1.Precautions
2.Productspecicationanddescription
3.DisassemblyandReassembly
4.AlignmentandTroubleshooting
5.SystemDiagram
6.ReferenceInformation
RefertotheservicemanualintheGSPN(seetherearcover)formoreinformation.

Contents
Contents
1.Precautions......................................................................................................................................1−1
1.1.Safetywarning........................................................................................................................1−1
1.2.Cautionforsafety....................................................................................................................1−2
1.2.1.Toxicmaterial.............................................................................................................1−2
1.2.2.Electricshockandresafetyprecautions.........................................................................1−2
1.2.3.Handlingprecautions...................................................................................................1−3
1.2.4.AssemblyandDisassemblyprecautions...........................................................................1−3
1.2.5.Disregardingthiswarningmaycausebodilyinjury............................................................1−4
1.3.ESDprecautions......................................................................................................................1−5
2.Productspecicationanddescription.....................................................................................................2−1
2.1.ProductSpecication................................................................................................................2−1
2.1.1.ProductOverview........................................................................................................2−1
2.1.2.Specications.............................................................................................................2−2
2.1.2.1.GeneralPrintEngine......................................................................................2−2
2.1.2.2.Copy...........................................................................................................2−2
2.1.2.3.Scan...........................................................................................................2−4
2.1.2.4.Fax(CLX-330xFN_330xFWonly)...................................................................2−4
2.1.2.5.ControllerandSoftware..................................................................................2−5
2.1.2.6.PaperHandling.............................................................................................2−7
2.1.2.7.ReliabilityandService...................................................................................2−8
2.1.2.8.Environment................................................................................................2−8
2.1.2.9.Consumables................................................................................................2−9
2.1.2.10.MaintenanceParts.........................................................................................2−10
2.1.3.ModelComparisonTable..............................................................................................2−11
2.2.SystemOverview.....................................................................................................................2−12
2.2.1.FrontView.................................................................................................................2−12
2.2.2.RearView..................................................................................................................2−14
2.2.3.PaperPath..................................................................................................................2−15
2.2.4.SystemLayout............................................................................................................2−16
2.2.4.1.FeedingSection............................................................................................2−17
2.2.4.2.TransferRoller.............................................................................................2−18
2.2.4.3.DriveUnit...................................................................................................2−18
2.2.4.4.FuserUnit....................................................................................................2−19
2.2.4.5.LSU(LaserScannerUnit)...............................................................................2−20
2.2.4.6.TonerCartridgesandImagingUnit...................................................................2−21
2.2.5.Hardwareconguration................................................................................................2−22
2.2.5.1.Mainboard..................................................................................................2−24
2.2.5.2.OPEboard...................................................................................................2−26
iCopyright©1995-2012SAMSUNG.Allrightsreserved.

Contents
2.2.5.3.Faxboard....................................................................................................2−28
2.2.5.4.Connectionboard..........................................................................................2−28
2.2.5.5.CTD(ColorToneDensity)board.....................................................................2−29
2.2.5.6.CRUMJointboard........................................................................................2−29
2.2.5.7.USBHost....................................................................................................2−30
2.2.5.8.WirelessLANboard(CLX-330xW_330xFWonly).............................................2−30
2.2.5.9.SMPS(SwitchingModePowerSupply)Board....................................................2−31
2.2.5.10.HVPSboard.................................................................................................2−33
2.2.5.11.ElectricalPartsLocation.................................................................................2−34
2.2.6.EngineF/WControlAlgorithm......................................................................................2−35
2.2.6.1.Feeding.......................................................................................................2−35
2.2.6.2.Transfer.......................................................................................................2−35
2.2.6.3.Fusing.........................................................................................................2−36
2.2.6.4.LSU............................................................................................................2−36
2.2.7.SoftwareDescriptions..................................................................................................2−37
2.2.7.1.Softwaresystemoverview..............................................................................2−37
2.2.7.2.Architecture.................................................................................................2−37
2.2.7.3.DataandControlFlow...................................................................................2−38
3.DisassemblyandReassembly..............................................................................................................3−1
3.1.Precautionswhenreplacingparts................................................................................................3−1
3.1.1.Precautionswhenassemblinganddisassembling...............................................................3−1
3.1.2.PrecautionswhenhandlingPBA.....................................................................................3−1
3.1.3.ReleasingPlasticLatches..............................................................................................3−2
3.2.Screwsusedintheprinter..........................................................................................................3−3
3.3.Replacingthemaintenanceparts.................................................................................................3−5
3.3.1.ITBUnit....................................................................................................................3−5
3.3.2.FuserUnit..................................................................................................................3−7
3.3.3.Transfer(T2)roller.......................................................................................................3−8
3.3.4.Pickuproller..............................................................................................................3−8
3.4.ReplacingthemainSVCparts....................................................................................................3−9
3.4.1.Cover........................................................................................................................3−9
3.4.2.ADFUnit...................................................................................................................3−10
3.4.3.OPEUnit...................................................................................................................3−10
3.4.4.PlatenUnit.................................................................................................................3−11
3.4.5.CISunitandScanDriveunit.........................................................................................3−12
3.4.6.MiddleCover.............................................................................................................3−13
3.4.7.Faxboard...................................................................................................................3−13
3.4.8.HVPSboard...............................................................................................................3−14
3.4.9.LSU..........................................................................................................................3−14
3.4.10.FRAMEBASE-PAPERPATH.......................................................................................3−15
Copyright©1995-2012SAMSUNG.Allrightsreserved.ii

Contents
3.4.11.RegiclutchandPickupsolenoid....................................................................................3−16
3.4.12.FeedsensorandEmptysensor.......................................................................................3−16
3.4.13.Mainboard.................................................................................................................3−17
3.4.14.SMPSboard...............................................................................................................3−17
3.4.15.CamSolenoid.............................................................................................................3−18
3.4.16.MainDriveUnit..........................................................................................................3−19
4.AlignmentandTroubleshooting...........................................................................................................4−1
4.1.AlignmentandAdjustments.......................................................................................................4−1
4.1.1.Controlpanel..............................................................................................................4−1
4.1.2.UnderstandingthestatusLED........................................................................................4−4
4.1.3.JAMremoval..............................................................................................................4−5
4.1.3.1.Clearingoriginaldocumentjams......................................................................4−5
4.1.3.2.Clearingpaperjams.......................................................................................4−8
4.1.4.Usefulmenuitemforservice.........................................................................................4−11
4.1.5.PeriodicDefectiveImage..............................................................................................4−13
4.1.6.Usefulmanagementtools..............................................................................................4−14
4.1.6.1.UsingSamsungEasyPrinterManager(WindowsandMacintoshonly)....................4−14
4.1.6.2.UsingSamsungPrinterStatus(Windowsonly)...................................................4−16
4.1.6.3.UsingSyncThruWebService(SWS)................................................................4−17
4.1.7.UpdatingFirmware......................................................................................................4−18
4.1.7.1.UpdatethermwarebyusingtheUSBport........................................................4−18
4.1.7.2.Updatethermwarebyusingthenetwork..........................................................4−19
4.1.8.Techmode.................................................................................................................4−21
4.2.Troubleshooting......................................................................................................................4−26
4.2.1.Procedureofcheckingthesymptoms...............................................................................4−26
4.2.1.1.BasicCheckList...........................................................................................4−27
4.2.2.ErrorCodeandTroubleshooting.....................................................................................4−28
4.2.3.Imagequalityproblems................................................................................................4−45
5.SystemDiagram................................................................................................................................5−1
5.1.BlockDiagram........................................................................................................................5−1
5.2.ConnectionDiagram.................................................................................................................5−2
6.ReferenceInformation........................................................................................................................6−1
6.1.ToolforTroubleshooting...........................................................................................................6−1
6.2.Glossary.................................................................................................................................6−2
iiiCopyright©1995-2012SAMSUNG.Allrightsreserved.

1.Precautions
1.Precautions
Inordertopreventaccidentsanddamagestotheequipmentpleasereadtheprecautionslistedbelowcarefullybefore
servicingtheproductandfollowthemclosely.
1.1.Safetywarning
1)Onlytobeservicedbyafactorytrainedservicetechnician.
Highvoltagesandlasersinsidethisproductaredangerous.Thisproductshouldonlybeservicedbyafactorytrained
servicetechnician.
2)UseonlySamsungreplacementparts.
Therearenouserserviceablepartsinsidetheproduct.Donotmakeanyunauthorizedchangesoradditionstothe
productasthesecouldcausetheproducttomalfunctionsandcreateanelectricshocksorrehazards.
3)LaserSafetyStatement
TheprinteriscertiedintheU.S.toconformtotherequirementsofDHHS21CFR,chapter1SubchapterJfor
ClassI(1)laserproducts,andelsewhereiscertiedasaClassIlaserproductconformingtotherequirementsofIEC
60825-1.ClassIlaserproductsarenotconsideredtobehazardous.Thelasersystemandprinteraredesignedso
thereisneveranyhumanaccesstolaserradiationaboveaClassIlevelduringnormaloperation,usermaintenance
orprescribedservicecondition.
•Wavelength:788nm(-13/+12)
•Beamdivergence
-Paraller:8degrees(-2/+4)
-Perpendicular:31degrees(-6/+4)
•Maximumpowerofenergyoutput:12mW
WARNING
NeveroperateorservicetheproductwiththeprotectivecoverremovedfromLaser/Scannerassembly.Thereected
beam,althoughinvisible,candamageyoureyes.
Whenusingthisproduct,thesebasicsafetyprecautionsshouldalwaysbefollowedtoreduceriskofre,electricshock,
andpersonalinjury.
Copyright©1995-2012SAMSUNG.Allrightsreserved.1-1

1.Precautions
1.2.Cautionforsafety
1.2.1.Toxicmaterial
Thisproductcontainstoxicmaterialsthatcouldcauseillnessifingested.
1)Pleasekeepimagingunitandtonercartridgeawayfromchildren.Thetonerpowdercontainedintheimagingunitand
tonercartridgemaybeharmful,andifswallowed,youshouldcontactadoctor.
1.2.2.Electricshockandresafetyprecautions
Failuretofollowthefollowinginstructionscouldcauseelectricshockorpotentiallycauseare.
1)Useonlythecorrectvoltage,failuretodosocoulddamagetheproductandpotentiallycauseareorelectricshock.
2)Useonlythepowercablesuppliedwiththeproduct.Useofanincorrectlyspeciedcablecouldcausethecableto
overheatandpotentiallycauseare.
3)Donotoverloadthepowersocket,thiscouldleadtooverheatingofthecablesinsidethewallandcouldleadtoare.
4)Donotallowwaterorotherliquidstospillintotheproduct,thiscancauseelectricshock.Donotallowpaperclips,pins
orotherforeignobjectstofallintotheproduct,thesecouldcauseashortcircuitleadingtoanelectricshockorrehazard.
5)Nevertouchtheplugsoneitherendofthepowercablewithwethands,thiscancauseelectricshock.Whenservicing
theproduct,removethepowerplugfromthewallsocket.
6)Usecautionwheninsertingorremovingthepowercord.Whenremovingthepowercord,gripitrmlyandpull.The
powercordmustbeinsertedcompletely,otherwiseapoorcontactcouldcauseoverheatingleadingtoare.
7)Takecareofthepowercable.Donotallowittobecometwisted,bentsharplyaroundcornersorpowercablemaybe
damaged.Donotplaceobjectsontopofthepowercable.Ifthepowercableisdamageditcouldoverheatandcausea
re.Exposedcablescouldcauseanelectricshock.Replacethedamagedpowercableimmediately,donotreuseor
repairthedamagedcable.Somechemicalscanattackthecoatingonthepowercable,weakeningthecoverorexposing
cablescausingreandshockrisks.
8)Ensurethatthepowersocketsandplugsarenotcrackedorbrokeninanyway.Anysuchdefectsshouldberepaired
immediately.Takecarenottocutordamagethepowercableorplugswhenmovingthemachine.
9)Usecautionduringthunderorlightningstorms.Samsungrecommendsthatthismachinebedisconnectedfromthe
powersourcewhensuchweatherconditionsareexpected.Donottouchthemachineorthepowercordifitisstill
connectedtothewallsocketintheseweatherconditions.
10)Avoiddampordustyareas,installtheproductinacleanwellventilatedlocation.Donotpositionthemachineneara
humidierorinfrontofanairconditioner.Moistureanddustbuiltupinsidethemachinecanleadtooverheatingand
causeareorcausepartstorust.
11)Donotpositiontheproductindirectsunlight.Thiswillcausethetemperatureinsidetheproducttorisepossiblyleading
totheproductfailingtoworkproperlyandinextremeconditionscouldleadtoare.
12)Donotinsertanymetalobjectsintothemachinethroughtheventilatorfanorotherpartofthecasing,itcouldmake
contactwithahighvoltageconductorinsidethemachineandcauseanelectricshock.
13)WhenreplacingtheSMPSboard,pleasewait5minutesafterunpluggingthepowercord,thenreplaceit.You
cangetashockbytheelectricdischarge.
1-2Copyright©1995-2012SAMSUNG.Allrightsreserved.

1.Precautions
1.2.3.Handlingprecautions
Thefollowinginstructionsareforyourownpersonalsafetytoavoidinjuryandsoasnottodamagetheproduct.
1)Ensuretheproductisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcause
theproducttotiporfall.
2)Theproductcontainsmanyrollers,gearsandfans.Takegreatcaretoensurethatyoudonotcatchyourngers,hairor
clothinginanyoftheserotatingdevices.
3)Donotplaceanysmallmetalobjects,containersofwater,chemicalsorotherliquidsclosetotheproductwhichifspilled
couldgetintothemachineandcausedamageorashockorrehazard.
4)Donotinstallthemachineinareaswithhighdustormoisturelevels,besideonopenwindoworclosetoahumidieror
heater.Damagecouldbecausedtotheproductinsuchareas.
5)Donotplacecandles,burningcigarettes,etcontheproduct,Thesecouldcauseare.
1.2.4.AssemblyandDisassemblyprecautions
1)ReplacepartscarefullyandalwaysuseSamsungparts.Takecaretonotetheexactlocationofpartsandalsocable
routingbeforedismantlinganypartofthemachine.Ensureallpartsandcablesarereplacedcorrectly.Pleasecarryout
thefollowingproceduresbeforedismantlingtheproductorreplacinganyparts.
2)Ensurethatpowerisdisconnectedbeforeservicingorreplacinganyelectricalparts.
3)Disconnectinterfacecablesandpowercables.
4)Onlyuseapprovedspareparts.Ensurethatpartnumber,productname,anyvoltage,currentortemperaturerating
arecorrect.
5)Whenremovingorre-ttinganypartsdonotuseexcessiveforce,especiallywhenttingscrewsintoplastic.
6)Takecarenottodropanysmallpartsintothemachine.
7)HandlingoftheOPCDrum
•TheOPCDrumcanbeirreparablydamagedifitexposedtolight.TakecarenottoexposetheOPCDrumeither
todirectsunlightortouorescentorincandescentroomlighting.Exposureforaslittleas5minutescandamage
thesurfaceofthephotoconductivepropertiesandwillresultinprintqualitydegradation.Takeextracarewhen
servicingtheproduct.RemovetheOPCDrumandstoreitinablackbagorotherlightproofcontainer.Take
carewhenworkingwiththeCovers(especiallythetopcover)openaslightisadmittedtotheOPCareaandcan
damagetheOPCDrum.
•TakecarenottoscratchthegreensurfaceofOPCDrumUnit.IfthegreensurfaceoftheDrumCartridgeis
scratchedortouchedtheprintqualitywillbecompromised.
Copyright©1995-2012SAMSUNG.Allrightsreserved.1-3

1.Precautions
1.2.5.Disregardingthiswarningmaycausebodilyinjury
1)Becarefulwiththehightemperaturepart.
Thefuserunitworksatahightemperature.Usecautionwhenworkingontheprinter.Waitforthefuserunitto
cooldownbeforedisassembly.
2)Donotputngersorhairintotherotatingparts.
Whenoperatingaprinter,donotputhandorhairintotherotatingparts(Paperfeedingentrance,motor,fan,etc.).
Ifdo,youcangetharm.
3)Whenyoumovetheprinter,usesafeliftingandhandlingtechniques.
Thisprinterisheavy.Usetheliftinghandleslocatedoneachsideofthemachine.Backinjurycouldbecausedif
youdonotliftcarefully.
4)Ensuretheprinterisinstalledsafely.
Ensuretheprinterisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcausethe
printertotiporfallpossiblycausingpersonalinjuryordamagingtheprinter.
5)Donotinstalltheprinteronaslopingorunstablesurface.Afterinstallation,doublecheckthattheprinterisstable.
1-4Copyright©1995-2012SAMSUNG.Allrightsreserved.

1.Precautions
1.3.ESDprecautions
Certainsemiconductordevicescanbeeasilydamagedbystaticelectricity.Suchcomponentsarecommonlycalled
“ElectrostaticallySensitive(ES)Devices”orESDs.ExamplesoftypicalESDsare:integratedcircuits,someeldeffect
transistors,andsemiconductor“chip”components.Thetechniquesoutlinedbelowshouldbefollowedtohelpreducethe
incidenceofcomponentdamagecausedbystaticelectricity.
CAUTION
Besurenopowerisappliedtothechassisorcircuit,andobserveallothersafetyprecautions.
1)Immediatelybeforehandlingasemiconductorcomponentorsemiconductor-equippedassembly,drainoffany
electrostaticchargeonyourbodybytouchingaknownearthground.Alternatively,employacommerciallyavailable
wriststrapdevice,whichshouldberemovedforyourpersonalsafetyreasonspriortoapplyingpowertotheunit
undertest.
2)AfterremovinganelectricalassemblyequippedwithESDs,placetheassemblyonaconductivesurface,suchas
aluminumorcopperfoil,orconductivefoam,topreventelectrostaticchargebuildupinthevicinityoftheassembly.
3)UseonlyagroundedtipsolderingirontosolderordesolderESDs.
4)Useonlyan“anti-static”solderremovaldevice.Somesolderremovaldevicesnotclassiedas“anti-static”can
generateelectricalchargessufcienttodamageESDs.
5)DonotuseFreon-propelledchemicals.Whensprayed,thesecangenerateelectricalchargessufcienttodamageESDs.
6)DonotremoveareplacementESDfromitsprotectivepackaginguntilimmediatelybeforeinstallingit.Most
replacementESDsarepackagedwithallleadsshortedtogetherbyconductivefoam,aluminumfoil,oracomparable
conductivematerial.
7)ImmediatelybeforeremovingtheprotectiveshortingmaterialfromtheleadsofareplacementESD,touchtheprotective
materialtothechassisorcircuitassemblyintowhichthedevicewillbeinstalled.
8)MaintaincontinuouselectricalcontactbetweentheESDandtheassemblyintowhichitwillbeinstalled,until
completelypluggedorsolderedintothecircuit.
9)MinimizebodilymotionswhenhandlingunpackagedreplacementESDs.Normalmotions,suchasthebrushingtogether
ofclothingfabricandliftingone’sfootfromacarpetedoor,cangeneratestaticelectricitysufcienttodamageanESD.
Copyright©1995-2012SAMSUNG.Allrightsreserved.1-5

2.Productspecicationanddescription
2.Productspecicationanddescription
2.1.ProductSpecication
2.1.1.ProductOverview
[CLX-330xFN/330xFW]
[CLX-330x/330xW]
1)PrintingSpeed
•18(Mono)/4(Color)ppminA4(19/4ppminLetter)
2)Processor
•533MHz
3)PrinterLanguage
•SPLC-B,PCL-5c/6,PS3,URF
4)Memory
•128MB(Standard)/128MB(Max)
5)Interface
•HighSpeedUSB2.0
•10/100BaseTXnetworkconnector(CLX-330xW/330xFN/
330xFWonly)
•802.11b/g/nwirelessLAN(CLX-330xW/330xFWonly)
6)Tonercartridge
•Initial:1.5K(K)/1K(CMY)
•Sales:1.5K(K)/1K(CMY)
2-1Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
2.1.2.Specications
NOTE
ProductSpecicationsaresubjecttochangewithoutnotice.
2.1.2.1.GeneralPrintEngine
ItemSpecication
Simplex(C/M)•Mono:19ppm@Letter,18ppm@A4
•Color:4ppm@Letter,A4
EngineSpeed
DuplexN/A
FromReady(C/M)Lessthan26/14sec
FPOTFromSleep(C/M)Lessthan29.5/29.5sec
Resolution•Best600x6002bit(Default)
•Normal600x6001bit
2.1.2.2.Copy
ItemSpecication
Simplex(SDMC:SingleDocument
MultipleCopy)
•Mono:19cpm/Ltr,18cpm/A4
•Color:4cpm/A4,Ltr
CopySpeed
DuplexN/A
FromReady•Color:Lessthan26seconds
•Mono:Lessthan18seconds
FCOT
FromSleep•Color:Lessthan29.5seconds
•Mono:Lessthan29.5seconds
TextScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MixedScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MagazineScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
Platen
PhotoScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
TextScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MixedScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MagazineScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
OriginalType
(Color)
ADF
(CLX-3300FN/
3305FWonly)
PhotoScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-2

2.Productspecicationanddescription
ItemSpecication
TextScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MixedScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MagazineScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
Platen
PhotoScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
TextScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MixedScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MagazineScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
OriginalType
(Mono)
ADF
(CLX-3300FN/
3305FWonly)
PhotoScan:600x600dpi(Optical600x600dpi),Printing:600x
600x2bit
MultiCopy1~99
DuplexCopyNo
DarknessControl11levels
BasicCopy
Reduce&Enlarge
*ZoomRange:
25%to400%inPlaten
25%to400%inADF
*Preset[Original(100%)]
[AutoFit]
[A4→A5(70%)]
[LGL→LTR(78%)]==>CLX-3300FN/3305FWonly
[LGL→A4(83%)]==>CLX-3300FN/3305FWonly
[A4→LTR(94%)]
[EN/AE→LTR(104%)]
[A5→A4(141%)]
25%,50%,150%,200%,400%[Custom:25-400%)]
AutoFitCopyYes(Platenonly)
IDCopyYes(Platenonly)
CloneNo
PosterNo
OtherFeatures
N-up2/4up
2-3Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
2.1.2.3.Scan
ItemSpecication
ScanmethodColor3channelCIS
LineartApprox.7sec
GrayApprox.7sec
ScanSpeedthrough
ADF(300dpi)
NOTE
CLX-3300FN/
3305FWonly
ColorApprox.13sec
LineartApprox.5sec
GrayApprox.5sec
ScanSpeedthrough
Platen(300dpi)
ColorApprox.13sec
Optical600x600dpi
ResolutionEnhanced4,800x4,800dpi
Halftone256levels
Max.DocumentWidthMax.216mm(8.5")
ScanSizeEffectiveScanWidthMax.208mm(8.2")
Color•Internal:16bitx3
•External:8bitx3
ScanDepth
Mono•1bitforLineart&Halftone
•8BitsforGrayscale
Scan-toEmailScan-to-Application,Scan-to-USB
2.1.2.4.Fax(CLX-330xFN_330xFWonly)
ItemSpecication
CompatibilityITU-TG3
CommunicationSystemPSTN/PABX
ModemSpeed33.6Kbps
TxSpeedApprox.3sec(Mono/Standard/ECM-MMR/MemoryTx,ITU-TG3
No.1chart)
CompressionMH/MR/MMR/JBIG/JPEG
ColorFaxY es
ECMYes
Std203x98dpi
Fine203x196dpi Resolution(Mono)
S.Fine300x300dpi
Resolution(Color)200*200dpi
Std5sec/LTR
Fine5sec/LTR ScanSpeed(ADF)
S.Fine5sec/LTR
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-4

2.Productspecicationanddescription
ItemSpecication
RxfaxduplexprintoutNo
Multiplepagescanspeed18ppm/LTR,Stdmode
ReceiveModeFax,TEL,Ans/Fax,DRPD(Option)
JunkFaxbarrierYes
SecureReceiveYes
MemoryBack-upY es(FlashMemory)
BatteryBackupNo
RxFAXDuplexPrintOutNo
ReceiveModeFax,TEL,Ans/Fax
Capacity(SerialFlash)400pages,5MB(NandFlash)
OptionalMemoryNo
Maxlocationstostoreto1GroupDial100Locations
FaxForwardtoFAXYes(On/Off),bothSentandReceived,MonoOnly
FaxForwardtoe-mailNo
Broadcastingupto209locations(MonoOnly)
CoverpageNo
DelayedfaxYes(Txonly,MonoOnly)
MemoryRXYes
V oiceRequestNo
MailBox(Electronic)No
TTIYes
RTIYes
PollingNo
Earth/RecallNo
AutoReductionYes(On,Off)
SMSNo
RDSNo
2.1.2.5.ControllerandSoftware
ItemSpecication
ProcessorSamsung533MHz
Std.128MB
MemoryMax.128MB
PrinterLanguagesSPLC-B,PCL-5c/6,PS3,URF
Fonts•PCL:104ScalableFonts(includeOCR-A,OCR-B),1bitmap
•PS:136ScalableFonts
2-5Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
ItemSpecication
DefaultDriverSPLC-B
[WINDOW]
•WindowsXP/2003/Vista/2008,Windows7/2008R2
[Linux]
•RedHatEnterpriseLinuxWS4,5(32/64bit)
•Fedora5,6,7,8,9,10,11,12,13(32/64bit)
•SuSELinux10.1(32bit)
•OpenSuSE10.2,10.3,11.0,11.1,11.2(32/64bit)
•Mandriva2007,2008,2009,2009.1,2010(32/64bit)
•Ubuntu6.06,6.10,7.04,7.10,8.04,8.10,9.04,9.10,10.04(32/64
bit)
•SuSELinuxEnterpriseDesktop10,11(32/64bit)
•Debian4.0,5.0(32/64bit)
SupportingOS
MacOSX10.4~10.7
PrinterDriver
WHQLWindows2000/XP/2003/Vista,Windows7
SupportingOS
•WindowsXP/2003/Vista/2008,Win7/2008R2
•MacOSX10.4~10.7
•Linux
•RedHatEnterpriseLinuxWS4,5(32/64bit)
•Fedora5,6,7,8,9,10,11,12,13(32/64bit)
•SuSELinux10.1(32bit)
•OpenSuSE10.2,10.3,11.0,11.1,11.2(32/64bit)
•Mandriva2007,2008,2009,2009.1,2010(32/64bit)
•Ubuntu6.06,6.10,7.04,7.10,8.04,8.10,9.04,9.10,10.04
(32/64bit)
•SuSELinuxEnterpriseDesktop10,11(32/64bit)
•Debian4.0,5.0(32/64bit)
ScanDriver
DriverTwain,WIA,ICDM,SANE
Protocol
•CLX-330x:N/A
•CLX-330xW/330xFW
•TCP/IPv4/IPv6,StandardTCP/IPprinting,LPR,IPP ,
SNMPv1/2/3,HTTP,SLP ,Bonjour
•Authentication:WPA2personal(PSK)
•Encryption:WEP,TKIP ,AES
•CLX-330xFN
•TCP/IPv4/IPv6,StandardTCP/IPprinting,LPR,IPP ,
SNMPv1/2/3,HTTP,SLP ,Bonjour
NetworkInterface
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-6

2.Productspecicationanddescription
ItemSpecication
NetworkOS
•Windows:7/XP(32/64bit)/2003Server(32/64bit)/Vista(32/64
bit)
•MACOSX:10.3~5(TCP/IPOnly)
•Linux(Printeronly)OS:
•Fedora2,~9(32/6b4it)
•openSuSE9.1,9.2,9.3,10.0,10.1,10.2,10.3,11.0(32/64bit)
•Ubuntu6.04,6.10,7.04,7.10,8.04(32/64bit)
•Mandriva10.0,10.1,2005,2006,2007,2008(32/64bit)
•Debian3.1,4.0(32/64bit)
•RedhatEnterpriseLinuxWS4,5(32/64bit)
•SuSELinuxEnterpriseDesktop9,10(32/64bit)
•Novell:NetWare5.x,6.x(TCP/IPOnly)
•Others:UnixHP-UX,Solaris,SunOS,SCOUNIX
EasyPrinterManagerYES Application
NetworkManagementSetIP .SW AS&SWS(Linux,Macnotsupport,SW AS&SWSneedexplorer
5.0orHigher)
■Interface
ItemSpecication
ParallelOptionInterfaceN/A
USBHostUSBHost2.0(ScantoUSB)
USBDeviceUSBDevice2.0
WiredNetwork•CLX-330x:N/A
•CLX-330xW/330xFN/330xFW:Ethernet10/100baseTx
WirelessNetwork•CLX-330x/330xFN:N/A
•CLX-330xW/330xFW:802.11b/g/n
UserInterfaceLCD16x2LineLCD
2.1.2.6.PaperHandling
ItemSpecication
StandardCapacity•130-sheetCassetteTray@80g/m²
Max.Size216x356mm(8.5"x14")
PrintingMin.Size76x152.4mm(3.0"x6.0")
Multi-purposetrayN/A
Capacity
•130sheets@80g/m²
•Label,thickpaper:5Sheets
•GlossyPhoto220g/m²:1Sheets
MediasizesA4,A5,A6,Letter,Legal,Executive,Folio,ISOB5,JISB5GlossyPhoto
220g/m²
StandardCassetteTray
2-7Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
ItemSpecication
Mediaweight
•Plain:60~85g/m²
•ThickPaper:86~120g/m²
•Cardstock:121~163g/m²
•Photo:220g/m²
OptionCassette(SCF)N/A
Capacity
•50sheets@80g/m²
•Label,thickpaper:5Sheets
•GlossyPhoto220g/m²:1Sheets
•Custom:10Sheets@80g/m²
OutputStacking
OutputFullsensingYes
Capacity40sheet@80g/m²
2-sidedDocument
Scanning
No
DocumentWeight16~28lb(60to105g/m²)
ADF
DocumentSize•Width:148~216mm(5.8"~8.5")
•Length:148~356mm(5.8"~14.0")
2.1.2.7.ReliabilityandService
ItemSpecication
AverageMonthlyV olumeColor46pages,Mono140pages
Max.MonthlyDuty20,000images
2.1.2.8.Environment
ItemSpecication
TemperatureOperation10to32°C(50to89.6°F)
HumidityOperation20to80%RH
ReadymodeLessthan26dB(A)
PrintmodeLessthan50dB(A)
Copymode•Scannerglass:Lessthan50dB(A)
•Documentfeeder:Lessthan52dB(A)
AcousticNoise
Level(Sound
Power/Pressure)
Scanmode•Scannerglass:Lessthan52dB(A)
•Documentfeeder:Lessthan54dB(A)
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-8

2.Productspecicationanddescription
ItemSpecication
Averageoperating
modeLessthan290W
ReadymodeLessthan60W
Powersavemode
•CLX-330xSeries:Lessthan1.2W
•CLX-330xWSeries:Lessthan1.7W
•CLX-330xFNSeries:Lessthan1.6W
•CLX-330xFWSeries:Lessthan2.1W
PowerConsumption
PoweroffmodeLessthan0.45W
Dimension(WxDxH)
•CLX-330x/330xWseries:406x362x288.6mm(16.0x14.3x
11.4inch)
•CLX-330xFN/330xFWseries:406x362x333.5mm(16x14.3
x13.1inches)
WeightMachinewith
consumables
•CLX-330x/330xWseries:13.2kg(29.1lb)
•CLX-330xFN/330xFWseries:14.3kg(31.5lb)
2.1.2.9.Consumables
ItemSpecication
Model
•K406(CLT-K406S):Black
•C406(CLT-Y406S):Y ellow
•M406(CLT-M406S):Magenta
•Y406(CLT-C406S):Cyan
TonerCartridge
Yield*
•Averagecontinuousblackcartridgeyield:Apporx.1,500standard
pages(Black)
•Averagecontinuouscolorcartridgeyield:Apporx.1,000standard
pages(Yellow/Magenta/Cyan)
ModelCLT-R406
ImagingUnitYield*Approx.16,000images**
ModelCLT-W406
WasteTonerContainerYield*Approx.7,000images**
NOTE
*DeclaredyieldvalueinaccordancewithISO/IEC19798.Thenumberofpagesmaybeaffectedbyoperatingenvironment,
printinginterval,graphics,mediatypeandmediasize.
**Imagecountsbasedononecoloroneachpage.Ifyouprintdocumentsinfullcolor(Cyan,Magenta,Yellow,Black),
thelifeofthisitemwillbereducedby25%.
2-9Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
2.1.2.10.MaintenanceParts
ItemSpecication
PartCodeJC93-00708A TransferrollerAssy
Life20,000pages
PartCode•JC91-01137A(110V)
•JC91-01138A(220V)
Fuserunit
LifeApprox.20,000imagesB&Wor5,000imagesColor
PartCodeJC73-00309A Pick-Uproller
Life20,000pages
PartCodeJC96-06292A ITBunit
LifeApprox.20,000imagesB&Wor5,000imagesColor
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-10

2.Productspecicationanddescription
2.1.3.ModelComparisonTable
SamsungCLX-3305FWSamsungCLX-3185FWHPCM1415
Mono/ColorSpeed
(A4)
18/4ppm16/4ppm12/8ppm
Processor533MHz360MHz600MHz
Memory(Std/Max)128MB/128MB128MB/128MB160MB/160MB
PrintLanguageSPL-B,PCL-5c/6,PS3,URFSPL,PCLHPPCL6,HPPCL5c,HP
postscript3
PaperInput150sheetsCassette150sheetsCassette150sheetsCassette
DuplexN/AN/AN/A
InterfaceHighSpeedUSB2.0
10/100BaseTX
IEEE802.11b/g/n
HighSpeedUSB2.0
10/100BaseTX
IEEE802.11b/g/n
HighSpeedUSB2.0
10/100BaseTX
Size(mm)406x362x333.5mm454x380.5x355.4mm443x472x415mm
TonerCartridge
(K/CMY)
1.5K/1K1.5K/1K2K/1.3K
2-11Copyright©1995-2012SAMSUNG.Allrightsreserved.
