Samsung MFP SCX-6345N User manual

Samsung MFP SCX-6345N
Digital Copier | Network Printer | Colour Scanner | Network Fax

imagine an office solution capable
of the highest workflow demands
Take a look at this one-stop digital solution that can manage your
entire printing workflow. An MFP copier that can match the output of
large contract-based A3 copiers, and can also scan, print and fax.
Add in high performance features like duplex, high capacity paper
trays and simple one touch operations and you have a solution capa-
ble of the highest workflow demands. With Samsung SCX-6345N, it's
not that hard to imagine.
04 Quick Overview
06 Product Concept & Positioning
07 Product Configuration
08 Why A4 Copier?
09 Why SCX-6345N?
10 Because it is Effortless
12 Because it is Effective
17 Because it is Economical
18 Because it is Enhanced
22 Samsung Printers Service
24 Product Line-up
28 Options & Supplies
30 Specifications

Quick Overview
Quick Overview
Standard Features
• 43cpm Copier Based MFP
• 2 Beam Laser Scanning Unit and Electro Photography
• 50 Sheet Duplex-ADF
• Duplex Copy / Print
• Ethernet 10/100 base TX
• Half VGA size touch screen pannel
• JAM-Trouble Shooting Animation Guide
• FCOT Less than 6.0 seconds
• 256MB memory (max 384MB available)
• 45ppm digital scanning speed at 600dpi
• 1-999 multiple copying (number keypad)
• 550-sheet cassette & 100 by pass tray
• Digital copier features such as Scan-Once - Copy-Many / ID Copying / Legal Size / Standard Duplex /
Auto-fit / Clone / Poster / N-up (up to 16) / Margin Shift / Book copy / Auto Suppress / Outline erased /
Cover / Transparent film / Booklet
• Internal 40Gbyte HDD
• Colour CCD Scan Type
• Standard PCL6, PostScript3 Emulation
• Foreign Device Interface
Optional Features
• Maximum 2,180-sheet input paper capacity
• Finisher (50-sheet stapler, offset catching)
• Maximum 384Mbyte Memory Capacity
• Colour Fax (If receiver’s fax available)
• Duplex Transmission and 2-sided printing
• JBIG Data Compression Method
• Super G3 Facsimile
• Advanced Fax Communication such as Secure Fax / Delay Fax / Toll-Saving Fax /
Priority Fax / Batch TX / Fax Forwarding / ECM (Error Correction Mode)
• Network Scan Kit Enable Kit

Product Concept & Positioning
Concept
Samsung Digital Multi Function Printer | 4+ 5
Product Concept
The SCX-6345N has been developed to expand Samsung’s copier-based
Laser MFP Line-up with SCX-6322DN/6122FN. In addition, this model is
designed to make inroads into A3 Copier markets.
The SCX-6345N fits into the general office environments, whatever the
department. As it comes with 43 PPM speed, an embedded network
card, Scalable paper handling Capacity(Max 2180 Sheet capacity), Simple
Finisher with staple and collation(Optional), Wide Touch Screen Panel,
network scan function that supports various OS, and device manage-
ment tool without installation, it can be easily installed in
any network environment. In the past, the entire office
had to use one centralized device. The needs of the
office environment have been changing and today
people what efficient and easy-to-use networked
multi-function product functionality.
Customers today will no longer hesitate to buy new Laser
MFPs because they are now more efficient and offer high per-
formance with economic device maintenance cost.
The Samsung SCX-6345N has a lower TCO and an easy to use
interface that can replace centralized A3 copiers in the office.
Moreover, one centric A3 copier can be easily replaced by one or more
SCX-6345N.
Product Positioning
Product Positioning Strategies
A) Cost Efficiency Approach
This A) positioning is based on speed and allows a much improved approach on cost efficiency. In this case the SCX-6345N has
advantages in Total Cost of Ownership.
B) Performance Efficiency approach
On the other hand, when applying the B) positioning the performance-efficiency can be promoted thanks to its various features
including speed.
All prices in this part are US retail averages price (June 2006)
Type
Benefit
Better Cost
- Lower Purchasing Cost
- Better TCO
- Easy to Install & Maintenance
Better Performance
- Speed : Copy and Print
- Easy to Use : User Interface
A - Positioning B - Positioning

Product Configuration
Configuration
Standard Feature
Optional Feature
SCX-6345N
• Printing Resolution : 600 x 600 dpi ( 1200 dpi class )
• Internal HDD : 40 GB Capacity
• Wide Touch Screen Panel (640 x 240)
• 50-sheet Duplex Auto Document Feeder Standard
• Standard Paper Cassettes (250 sheets)
• USB 2.0 & Ethernet 10/100 base TX
(SCX-D6345A) 20K
Toner
(SCX-R6345A) 60K
Drum
1
12
2
Optional Finisher Short StandOptional Cassette
SCX-DSK10S
Tall Stand
SCX-DSK10TSCX-S6345A SCX-FIN10S
FDI Kit
SCX-KIT11S
N/W Scan Kit Optional Fax KitOptional Fax Kit
SCX-FAX101
Memory
256 MB MemorySCX-FAX100 SCX-FIN10S
Staple Cartridge
SCX-6320NA

Samsung Mono Laser MFP SCX-6345N
Just unpack and
get to work in no time!
1 Optional Cassette
520 sheets
Max 3 Optional Cassette
520 sheets X 3
Trays can be
interchangeable
Atype
Btype
Samsung Digital Multi Function Printer | 6+ 7
Positioning Configuration
The SCX-6345N is a digital multifunctional system designed as a console unit. It is ready for external expansion with vertical additions of paper-handling options.

In the past customers always considered they needed an A3 Copier However,
according to a recent report *, just 2.35% of the total page volume printed is on
A3 paper. Given that the average office worker produces 8,636 pages a year,
just 202 pages are A3, which is less than a page a day. Because people are
moving towards scanning and printing original documents, which can be
scaled to fit the paper size available, the need for A3 output has declined. In
addition, a few years ago there was no software such as Microsoft Office,
Acrobat Reader and several types of Internet Browsers. Just think. When is
the last time you copied or printed on an A3 Copier?
Office space is also a big issue. In general, A3 centric copiers
occupy more office space. Typically, the footprint of a mono A3
capable device is much larger than that of an A4 device, 70%*
larger by volume on average. An A3 device takes up a lot
of space with its console. But an A4 device only
needs the corner of your desk or room.
In terms of TCO then generally,
the A3 copier is more expensive
to purchase and maintain than an
A4 MFP. The premium is between
100% and 220%* depending on the man-
ufacturer. Also the cost of a maintenance
kit for an A3 copier is 26%* higher than
that of an A4.
Finally, an A3 capable MFP device
consumes more operating power
and cost as the fuser unit is 41%
larger.
It doesn’t matter if an A4 page is being
printed or an A3 page because the whole
fuser unit is heated up.
*Source:
UK Research Study 2006
“NewField IT” Report
Samsung Mono Laser MFP SCX-6345N
Why A4 Copier?
Why A4 Copier?

Because it is Enhanced
Because it is Economical
Because it is Effortless
Why choose the Samsung SCX-6345N among the many other A4 MFPs? In addition to its economical features
and A4 copying/printing capability, this model offers simple user interface and easy administration tool, mean-
ing that users don’t have to study in great detail the User’s Manual and IT managers don’t have to spend too
much time monitoring the device. The SCX-6345N can drastically decrease the cost of maintenance.
Because it is Effective
Samsung Digital Multi Function Printer | 8+ 9
Why SCX-6345N?
Why SCX-6345N?

Effortless
Because it is Effortless
Keyboard Network Scan
Main Menu Copy Setting Admin Setting
to Use
• Wide Touch Screen/UI design
Samsung’s exclusive 640 x 240 wide LCD touch screen and 3-dimen-
tional UI design can help users make selection simple and reduces time
spent learning user manuals and educating new staff members.
• Paper Handling
Additional paper trays can be added to provide up to 2,180 sheets of
paper on line, reducing the need to frequently refill with paper .
Also print job rescheduling manages the printing jobs based on FIFO
(First In First Out) order. So when the previous printing job mismatches
the property of the paper the next job can continue to print so reducing
working time and running on the system.
50-sheet DADF
100-sheet Bypass Tray
520-sheet CST Tray
520-sheet 2
nd
CST Tray (Option)
