Samsung SWA-9100S User manual

SAFETY INFORMATION
Thank you for purchasing this product (SWA-9100S).
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols which may
be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates that
it does not require a safety connection to
electrical earth (ground).
If this symbol is not present on a product with
a power cord, the product MUST have a reliable
connection to protective earth (ground).
AC voltage : This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
DC voltage : This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.
Caution, Consult instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
•The slots and openings in the cabinet and in the back or bottom
are provided for necessary ventilation. To ensure reliable
operation of this apparatus, and to protect it from overheating,
these slots and openings must never be blocked or covered.
– Do not place this apparatus in a conned space, such as a
bookcase, or built-in cabinet, unless proper ventilation is
provided.
– Do not place this apparatus near or over a radiator or heat
register, or where it is exposed to direct sunlight.
– Do not place vessels (vases etc.) containing water on this
apparatus. A water spill can cause a re or electric shock.
•Do not expose this apparatus to rain or place it near water
(near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.). If this apparatus
accidentally gets wet, unplug it and contact an authorized dealer
immediately.
•Do not overload wall outlets, extension cords or adaptors beyond
their capacity, since this can result in re or electric shock.
•Route power-supply cords so that they are not likely to be walked
on or pinched by items placed on or against them. Pay particular
attention to cords at the plug end, at wall outlets, and the point
where they exit from the apparatus.
•To protect this apparatus from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the set due to lightning and power line
surges.
•Before connecting the AC power cord to the DC adaptor
outlet, make sure the voltage designation of the DC adaptor
corresponds to the local electrical supply.
•Never insert anything metallic into the open parts of this
apparatus. Doing so may create a danger of electric shock.
•To avoid electric shock, never touch the inside of this apparatus.
Only a qualied technician should open this apparatus.
•Make sure to plug the power cord in until it is rmly seated.
When unplugging the power cord from a wall outlet, always pull
on the power cord’s plug. Never unplug by pulling on the power
cord. Do not touch the power cord with wet hands.
•If this apparatus does not operate normally - in particular, if
there are any unusual sounds or smells coming from it - unplug it
immediately and contact an authorized dealer or service centre.
•Maintenance of Cabinet.
– Before connecting other components to this product, be sure
to turn them off.
•Be sure to pull the power plug out of the outlet if the product is
to remain unused or if you are leaving the house for an extended
period of time (especially when children, elderly, or disabled
people will be left alone in the house).
– Accumulated dust can cause an electric shock, an electric
leakage, or a re by causing the power cord to generate sparks
and heat or the insulation to deteriorate.
•Contact an authorized service centre for information if you
intend to install your product in a location with heavy dust, high
or low temperatures, high humidity, chemical substances, or
where it will operate 24 hours a day such as in an airport, a train
station, etc. Failing to do so may cause serious damage to your
product.
•Use only a properly grounded plug and wall outlet.
– An improper ground may cause electric shock or equipment
damage. (Class l Equipment only.)
•To turn this apparatus off completely, you must disconnect it
from the wall outlet. Consequently, the wall outlet and power
plug must be readily accessible at all times.
•Do not allow children to hang on the product.
•Store the accessories (battery, etc.) in a location safely out of the
reach of children.
•Do not install the product in an unstable location such as a shaky
self, a slanted oor, or a location exposed to vibration.
•Do not drop or strike the product. If the product is damaged,
disconnect the power cord and contact a service centre.
•To clean this apparatus, unplug the power cord from the wall
outlet, and then wipe the product using a soft, dry cloth. Do
not use any chemicals such as wax, benzene, alcohol, thinners,
insecticide, air fresheners, lubricants, or detergent. These
chemicals can damage the appearance of the product or erase
the printing on the product.
•Do not expose this apparatus to dripping or splashing. Do not put
objects lled with liquids, such as vases, on the apparatus.
•Do not plug multiple electric devices into the same wall socket.
Overloading a socket can cause it to overheat, resulting in a re.
WARNING :
•TO PREVENT THE SPREAD OF FIRE, KEEP
CANDLES AND OTHER ITEMS WITH OPEN
FLAMES AWAY FROM THIS PRODUCT AT ALL
TIMES.
•To reduce the risk of re or electric shock, do not
expose this appliance to rain or moisture.
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
PRECAUTIONS
1. Ensure that the AC or DC power supply in your house complies
with the power requirements listed on the identication sticker
located on the back of your product. Install your product
horizontally, on a suitable base (furniture), with enough space
around it for ventilation (7~10 cm).
Make sure the ventilation slots are not covered. Do not place the
unit on ampliers or other equipment which may become hot.
This unit is designed for continuous use.
To fully turn off the unit, disconnect the AC plug from the wall
outlet.
2. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the unit to
malfunction.
3. Unplug the Power cord from the AC wall socket if the unit
malfunctions. Your product is not intended for industrial use. It
is for personal use only. Condensation may occur if your product
has been stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the unit has
reached room temperature before using it.
4. If the electricity supplied to your home is rated at 240V AC, use
a suitable plug adapter to connect this unit to your electrical
outlets.
© 2021 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care
Centre.
Country /Area Samsung Service Centre  Web Site
` Asia Pacifi c
CHINA 400-810-5858 www.samsung.com/cn/support
TAIWAN 0800-329-999
0809-00-5237 ( B2B / Dealer) www.samsung.com/tw/support
HONG KONG 3698 4698 www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
MACAU 0800 333
SINGAPORE 1800 7267864 | 1800-SAMSUNG www.samsung.com/sg/support
AUSTRALIA 1300 362 603 www.samsung.com/au/support
NEW ZEALAND 0800 726 786 www.samsung.com/nz/support
VIETNAM 1800 588 889 www.samsung.com/vn/support
THAILAND 1800-29-3232 (Toll free for all product) www.samsung.com/th/support
MYANMAR [phone] www.samsung.com/mm/support
CAMBODIA 1800-20-3232 (Toll free) www.samsung.com/th/support
LAOS [phone]
MALAYSIA 1800-88-9999
[phone] (Overseas contact) www.samsung.com/my/support
INDONESIA 021-5699-7777
0800-112-8888 (All Product, Toll Free) www.samsung.com/id/support
PHILIPPINES
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and Mobile ]
02-8-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
INDIA 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free)
1800 5 SAMSUNG (1800 5 7267864) (Toll-Free)
www.samsung.com/in/support
NEPAL 16600172667 (Toll Free for NTC Only)
9801572667 (Toll Free for Ncell users)
BANGLADESH 08000-300-300 (Toll free)
09612-300-300
SRI LANKA 011 SAMSUNG (011 7267864)
USER MANUAL
SWA-9100S
VA81-01112W-01
NSPBI00848A-01

SAFETY INFORMATION
Thank you for purchasing this product (SWA-9100S).
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols which may
be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates that
it does not require a safety connection to
electrical earth (ground).
If this symbol is not present on a product with
a power cord, the product MUST have a reliable
connection to protective earth (ground).
AC voltage : This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
DC voltage : This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.
Caution, Consult instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
•The slots and openings in the cabinet and in the back or bottom
are provided for necessary ventilation. To ensure reliable
operation of this apparatus, and to protect it from overheating,
these slots and openings must never be blocked or covered.
– Do not place this apparatus in a conned space, such as a
bookcase, or built-in cabinet, unless proper ventilation is
provided.
– Do not place this apparatus near or over a radiator or heat
register, or where it is exposed to direct sunlight.
– Do not place vessels (vases etc.) containing water on this
apparatus. A water spill can cause a re or electric shock.
•Do not expose this apparatus to rain or place it near water
(near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.). If this apparatus
accidentally gets wet, unplug it and contact an authorized dealer
immediately.
•Do not overload wall outlets, extension cords or adaptors beyond
their capacity, since this can result in re or electric shock.
•Route power-supply cords so that they are not likely to be walked
on or pinched by items placed on or against them. Pay particular
attention to cords at the plug end, at wall outlets, and the point
where they exit from the apparatus.
•To protect this apparatus from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the set due to lightning and power line
surges.
•Before connecting the AC power cord to the DC adaptor
outlet, make sure the voltage designation of the DC adaptor
corresponds to the local electrical supply.
•Never insert anything metallic into the open parts of this
apparatus. Doing so may create a danger of electric shock.
•To avoid electric shock, never touch the inside of this apparatus.
Only a qualied technician should open this apparatus.
•Make sure to plug the power cord in until it is rmly seated.
When unplugging the power cord from a wall outlet, always pull
on the power cord’s plug. Never unplug by pulling on the power
cord. Do not touch the power cord with wet hands.
•If this apparatus does not operate normally - in particular, if
there are any unusual sounds or smells coming from it - unplug it
immediately and contact an authorized dealer or service centre.
•Maintenance of Cabinet.
– Before connecting other components to this product, be sure
to turn them off.
•Be sure to pull the power plug out of the outlet if the product is
to remain unused or if you are leaving the house for an extended
period of time (especially when children, elderly, or disabled
people will be left alone in the house).
– Accumulated dust can cause an electric shock, an electric
leakage, or a re by causing the power cord to generate sparks
and heat or the insulation to deteriorate.
•Contact an authorized service centre for information if you
intend to install your product in a location with heavy dust, high
or low temperatures, high humidity, chemical substances, or
where it will operate 24 hours a day such as in an airport, a train
station, etc. Failing to do so may cause serious damage to your
product.
•Use only a properly grounded plug and wall outlet.
– An improper ground may cause electric shock or equipment
damage. (Class l Equipment only.)
•To turn this apparatus off completely, you must disconnect it
from the wall outlet. Consequently, the wall outlet and power
plug must be readily accessible at all times.
•Do not allow children to hang on the product.
•Store the accessories (battery, etc.) in a location safely out of the
reach of children.
•Do not install the product in an unstable location such as a shaky
self, a slanted oor, or a location exposed to vibration.
•Do not drop or strike the product. If the product is damaged,
disconnect the power cord and contact a service centre.
•To clean this apparatus, unplug the power cord from the wall
outlet, and then wipe the product using a soft, dry cloth. Do
not use any chemicals such as wax, benzene, alcohol, thinners,
insecticide, air fresheners, lubricants, or detergent. These
chemicals can damage the appearance of the product or erase
the printing on the product.
•Do not expose this apparatus to dripping or splashing. Do not put
objects lled with liquids, such as vases, on the apparatus.
•Do not plug multiple electric devices into the same wall socket.
Overloading a socket can cause it to overheat, resulting in a re.
WARNING :
•TO PREVENT THE SPREAD OF FIRE, KEEP
CANDLES AND OTHER ITEMS WITH OPEN
FLAMES AWAY FROM THIS PRODUCT AT ALL
TIMES.
•To reduce the risk of re or electric shock, do not
expose this appliance to rain or moisture.
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14.Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
PRECAUTIONS
1. Ensure that the AC or DC power supply in your house complies
with the power requirements listed on the identication sticker
located on the back of your product. Install your product
horizontally, on a suitable base (furniture), with enough space
around it for ventilation (7~10 cm).
Make sure the ventilation slots are not covered. Do not place the
unit on ampliers or other equipment which may become hot.
This unit is designed for continuous use.
To fully turn off the unit, disconnect the AC plug from the wall
outlet.
2. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the unit to
malfunction.
3. Unplug the Power cord from the AC wall socket if the unit
malfunctions. Your product is not intended for industrial use. It
is for personal use only. Condensation may occur if your product
has been stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the unit has
reached room temperature before using it.
4. If the electricity supplied to your home is rated at 240V AC, use
a suitable plug adapter to connect this unit to your electrical
outlets.
© 2021 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care
Centre.
Country /Area Samsung Service Centre  Web Site
` Asia Pacifi c
CHINA 400-810-5858 www.samsung.com/cn/support
TAIWAN 0800-329-999
0809-00-5237 ( B2B / Dealer) www.samsung.com/tw/support
HONG KONG 3698 4698 www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
MACAU 0800 333
SINGAPORE 1800 7267864 | 1800-SAMSUNG www.samsung.com/sg/support
AUSTRALIA 1300 362 603 www.samsung.com/au/support
NEW ZEALAND 0800 726 786 www.samsung.com/nz/support
VIETNAM 1800 588 889 www.samsung.com/vn/support
THAILAND 1800-29-3232 (Toll free for all product) www.samsung.com/th/support
MYANMAR [phone] www.samsung.com/mm/support
CAMBODIA 1800-20-3232 (Toll free) www.samsung.com/th/support
LAOS [phone]
MALAYSIA 1800-88-9999
[phone] (Overseas contact) www.samsung.com/my/support
INDONESIA 021-5699-7777
0800-112-8888 (All Product, Toll Free) www.samsung.com/id/support
PHILIPPINES
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and Mobile ]
02-8-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
INDIA 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free)
1800 5 SAMSUNG (1800 5 7267864) (Toll-Free)
www.samsung.com/in/support
NEPAL 16600172667 (Toll Free for NTC Only)
9801572667 (Toll Free for Ncell users)
BANGLADESH 08000-300-300 (Toll free)
09612-300-300
SRI LANKA 011 SAMSUNG (011 7267864)
USER MANUAL
SWA-9100S
VA81-01112W-01
NSPBI00848A-01

SAFETY INFORMATION
Thank you for purchasing this product (SWA-9100S).
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols which may
be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates that
it does not require a safety connection to
electrical earth (ground).
If this symbol is not present on a product with
a power cord, the product MUST have a reliable
connection to protective earth (ground).
AC voltage : This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
DC voltage : This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.
Caution, Consult instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
•The slots and openings in the cabinet and in the back or bottom
are provided for necessary ventilation. To ensure reliable
operation of this apparatus, and to protect it from overheating,
these slots and openings must never be blocked or covered.
– Do not place this apparatus in a conned space, such as a
bookcase, or built-in cabinet, unless proper ventilation is
provided.
– Do not place this apparatus near or over a radiator or heat
register, or where it is exposed to direct sunlight.
– Do not place vessels (vases etc.) containing water on this
apparatus. A water spill can cause a re or electric shock.
•Do not expose this apparatus to rain or place it near water
(near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.). If this apparatus
accidentally gets wet, unplug it and contact an authorized dealer
immediately.
•Do not overload wall outlets, extension cords or adaptors beyond
their capacity, since this can result in re or electric shock.
•Route power-supply cords so that they are not likely to be walked
on or pinched by items placed on or against them. Pay particular
attention to cords at the plug end, at wall outlets, and the point
where they exit from the apparatus.
•To protect this apparatus from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the set due to lightning and power line
surges.
•Before connecting the AC power cord to the DC adaptor
outlet, make sure the voltage designation of the DC adaptor
corresponds to the local electrical supply.
•Never insert anything metallic into the open parts of this
apparatus. Doing so may create a danger of electric shock.
•To avoid electric shock, never touch the inside of this apparatus.
Only a qualied technician should open this apparatus.
•Make sure to plug the power cord in until it is rmly seated.
When unplugging the power cord from a wall outlet, always pull
on the power cord’s plug. Never unplug by pulling on the power
cord. Do not touch the power cord with wet hands.
•If this apparatus does not operate normally - in particular, if
there are any unusual sounds or smells coming from it - unplug it
immediately and contact an authorized dealer or service centre.
•Maintenance of Cabinet.
– Before connecting other components to this product, be sure
to turn them off.
•Be sure to pull the power plug out of the outlet if the product is
to remain unused or if you are leaving the house for an extended
period of time (especially when children, elderly, or disabled
people will be left alone in the house).
– Accumulated dust can cause an electric shock, an electric
leakage, or a re by causing the power cord to generate sparks
and heat or the insulation to deteriorate.
•Contact an authorized service centre for information if you
intend to install your product in a location with heavy dust, high
or low temperatures, high humidity, chemical substances, or
where it will operate 24 hours a day such as in an airport, a train
station, etc. Failing to do so may cause serious damage to your
product.
•Use only a properly grounded plug and wall outlet.
– An improper ground may cause electric shock or equipment
damage. (Class l Equipment only.)
•To turn this apparatus off completely, you must disconnect it
from the wall outlet. Consequently, the wall outlet and power
plug must be readily accessible at all times.
•Do not allow children to hang on the product.
•Store the accessories (battery, etc.) in a location safely out of the
reach of children.
•Do not install the product in an unstable location such as a shaky
self, a slanted oor, or a location exposed to vibration.
•Do not drop or strike the product. If the product is damaged,
disconnect the power cord and contact a service centre.
•To clean this apparatus, unplug the power cord from the wall
outlet, and then wipe the product using a soft, dry cloth. Do
not use any chemicals such as wax, benzene, alcohol, thinners,
insecticide, air fresheners, lubricants, or detergent. These
chemicals can damage the appearance of the product or erase
the printing on the product.
•Do not expose this apparatus to dripping or splashing. Do not put
objects lled with liquids, such as vases, on the apparatus.
•Do not plug multiple electric devices into the same wall socket.
Overloading a socket can cause it to overheat, resulting in a re.
WARNING :
•TO PREVENT THE SPREAD OF FIRE, KEEP
CANDLES AND OTHER ITEMS WITH OPEN
FLAMES AWAY FROM THIS PRODUCT AT ALL
TIMES.
•To reduce the risk of re or electric shock, do not
expose this appliance to rain or moisture.
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14.Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
PRECAUTIONS
1. Ensure that the AC or DC power supply in your house complies
with the power requirements listed on the identication sticker
located on the back of your product. Install your product
horizontally, on a suitable base (furniture), with enough space
around it for ventilation (7~10 cm).
Make sure the ventilation slots are not covered. Do not place the
unit on ampliers or other equipment which may become hot.
This unit is designed for continuous use.
To fully turn off the unit, disconnect the AC plug from the wall
outlet.
2. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the unit to
malfunction.
3. Unplug the Power cord from the AC wall socket if the unit
malfunctions. Your product is not intended for industrial use. It
is for personal use only. Condensation may occur if your product
has been stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the unit has
reached room temperature before using it.
4. If the electricity supplied to your home is rated at 240V AC, use
a suitable plug adapter to connect this unit to your electrical
outlets.
© 2021 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care
Centre.
Country /Area Samsung Service Centre  Web Site
` Asia Pacifi c
CHINA 400-810-5858 www.samsung.com/cn/support
TAIWAN 0800-329-999
0809-00-5237 ( B2B / Dealer) www.samsung.com/tw/support
HONG KONG 3698 4698 www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
MACAU 0800 333
SINGAPORE 1800 7267864 | 1800-SAMSUNG www.samsung.com/sg/support
AUSTRALIA 1300 362 603 www.samsung.com/au/support
NEW ZEALAND 0800 726 786 www.samsung.com/nz/support
VIETNAM 1800 588 889 www.samsung.com/vn/support
THAILAND 1800-29-3232 (Toll free for all product) www.samsung.com/th/support
MYANMAR [phone] www.samsung.com/mm/support
CAMBODIA 1800-20-3232 (Toll free) www.samsung.com/th/support
LAOS [phone]
MALAYSIA 1800-88-9999
[phone] (Overseas contact) www.samsung.com/my/support
INDONESIA 021-5699-7777
0800-112-8888 (All Product, Toll Free) www.samsung.com/id/support
PHILIPPINES
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and Mobile ]
02-8-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
INDIA 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free)
1800 5 SAMSUNG (1800 5 7267864) (Toll-Free)
www.samsung.com/in/support
NEPAL 16600172667 (Toll Free for NTC Only)
9801572667 (Toll Free for Ncell users)
BANGLADESH 08000-300-300 (Toll free)
09612-300-300
SRI LANKA 011 SAMSUNG (011 7267864)
USER MANUAL
SWA-9100S
VA81-01112W-01
NSPBI00848A-01

SAFETY INFORMATION
Thank you for purchasing this product (SWA-9100S).
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols which may
be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates that
it does not require a safety connection to
electrical earth (ground).
If this symbol is not present on a product with
a power cord, the product MUST have a reliable
connection to protective earth (ground).
AC voltage : This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
DC voltage : This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.
Caution, Consult instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
•The slots and openings in the cabinet and in the back or bottom
are provided for necessary ventilation. To ensure reliable
operation of this apparatus, and to protect it from overheating,
these slots and openings must never be blocked or covered.
– Do not place this apparatus in a conned space, such as a
bookcase, or built-in cabinet, unless proper ventilation is
provided.
– Do not place this apparatus near or over a radiator or heat
register, or where it is exposed to direct sunlight.
– Do not place vessels (vases etc.) containing water on this
apparatus. A water spill can cause a re or electric shock.
•Do not expose this apparatus to rain or place it near water
(near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.). If this apparatus
accidentally gets wet, unplug it and contact an authorized dealer
immediately.
•Do not overload wall outlets, extension cords or adaptors beyond
their capacity, since this can result in re or electric shock.
•Route power-supply cords so that they are not likely to be walked
on or pinched by items placed on or against them. Pay particular
attention to cords at the plug end, at wall outlets, and the point
where they exit from the apparatus.
•To protect this apparatus from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the set due to lightning and power line
surges.
•Before connecting the AC power cord to the DC adaptor
outlet, make sure the voltage designation of the DC adaptor
corresponds to the local electrical supply.
•Never insert anything metallic into the open parts of this
apparatus. Doing so may create a danger of electric shock.
•To avoid electric shock, never touch the inside of this apparatus.
Only a qualied technician should open this apparatus.
•Make sure to plug the power cord in until it is rmly seated.
When unplugging the power cord from a wall outlet, always pull
on the power cord’s plug. Never unplug by pulling on the power
cord. Do not touch the power cord with wet hands.
•If this apparatus does not operate normally - in particular, if
there are any unusual sounds or smells coming from it - unplug it
immediately and contact an authorized dealer or service centre.
•Maintenance of Cabinet.
– Before connecting other components to this product, be sure
to turn them off.
•Be sure to pull the power plug out of the outlet if the product is
to remain unused or if you are leaving the house for an extended
period of time (especially when children, elderly, or disabled
people will be left alone in the house).
– Accumulated dust can cause an electric shock, an electric
leakage, or a re by causing the power cord to generate sparks
and heat or the insulation to deteriorate.
•Contact an authorized service centre for information if you
intend to install your product in a location with heavy dust, high
or low temperatures, high humidity, chemical substances, or
where it will operate 24 hours a day such as in an airport, a train
station, etc. Failing to do so may cause serious damage to your
product.
•Use only a properly grounded plug and wall outlet.
– An improper ground may cause electric shock or equipment
damage. (Class l Equipment only.)
•To turn this apparatus off completely, you must disconnect it
from the wall outlet. Consequently, the wall outlet and power
plug must be readily accessible at all times.
•Do not allow children to hang on the product.
•Store the accessories (battery, etc.) in a location safely out of the
reach of children.
•Do not install the product in an unstable location such as a shaky
self, a slanted oor, or a location exposed to vibration.
•Do not drop or strike the product. If the product is damaged,
disconnect the power cord and contact a service centre.
•To clean this apparatus, unplug the power cord from the wall
outlet, and then wipe the product using a soft, dry cloth. Do
not use any chemicals such as wax, benzene, alcohol, thinners,
insecticide, air fresheners, lubricants, or detergent. These
chemicals can damage the appearance of the product or erase
the printing on the product.
•Do not expose this apparatus to dripping or splashing. Do not put
objects lled with liquids, such as vases, on the apparatus.
•Do not plug multiple electric devices into the same wall socket.
Overloading a socket can cause it to overheat, resulting in a re.
WARNING :
•TO PREVENT THE SPREAD OF FIRE, KEEP
CANDLES AND OTHER ITEMS WITH OPEN
FLAMES AWAY FROM THIS PRODUCT AT ALL
TIMES.
•To reduce the risk of re or electric shock, do not
expose this appliance to rain or moisture.
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14.Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
PRECAUTIONS
1. Ensure that the AC or DC power supply in your house complies
with the power requirements listed on the identication sticker
located on the back of your product. Install your product
horizontally, on a suitable base (furniture), with enough space
around it for ventilation (7~10 cm).
Make sure the ventilation slots are not covered. Do not place the
unit on ampliers or other equipment which may become hot.
This unit is designed for continuous use.
To fully turn off the unit, disconnect the AC plug from the wall
outlet.
2. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the unit to
malfunction.
3. Unplug the Power cord from the AC wall socket if the unit
malfunctions. Your product is not intended for industrial use. It
is for personal use only. Condensation may occur if your product
has been stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the unit has
reached room temperature before using it.
4. If the electricity supplied to your home is rated at 240V AC, use
a suitable plug adapter to connect this unit to your electrical
outlets.
© 2021 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care
Centre.
Country /Area Samsung Service Centre  Web Site
` Asia Pacifi c
CHINA 400-810-5858 www.samsung.com/cn/support
TAIWAN 0800-329-999
0809-00-5237 ( B2B / Dealer) www.samsung.com/tw/support
HONG KONG 3698 4698 www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
MACAU 0800 333
SINGAPORE 1800 7267864 | 1800-SAMSUNG www.samsung.com/sg/support
AUSTRALIA 1300 362 603 www.samsung.com/au/support
NEW ZEALAND 0800 726 786 www.samsung.com/nz/support
VIETNAM 1800 588 889 www.samsung.com/vn/support
THAILAND 1800-29-3232 (Toll free for all product) www.samsung.com/th/support
MYANMAR [phone] www.samsung.com/mm/support
CAMBODIA 1800-20-3232 (Toll free) www.samsung.com/th/support
LAOS [phone]
MALAYSIA 1800-88-9999
[phone] (Overseas contact) www.samsung.com/my/support
INDONESIA 021-5699-7777
0800-112-8888 (All Product, Toll Free) www.samsung.com/id/support
PHILIPPINES
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and Mobile ]
02-8-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
INDIA 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free)
1800 5 SAMSUNG (1800 5 7267864) (Toll-Free)
www.samsung.com/in/support
NEPAL 16600172667 (Toll Free for NTC Only)
9801572667 (Toll Free for Ncell users)
BANGLADESH 08000-300-300 (Toll free)
09612-300-300
SRI LANKA 011 SAMSUNG (011 7267864)
USER MANUAL
SWA-9100S
VA81-01112W-01
NSPBI00848A-01

SAFETY INFORMATION
Thank you for purchasing this product (SWA-9100S).
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols which may
be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates that
it does not require a safety connection to
electrical earth (ground).
If this symbol is not present on a product with
a power cord, the product MUST have a reliable
connection to protective earth (ground).
AC voltage : This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
DC voltage : This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.
Caution, Consult instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
•The slots and openings in the cabinet and in the back or bottom
are provided for necessary ventilation. To ensure reliable
operation of this apparatus, and to protect it from overheating,
these slots and openings must never be blocked or covered.
– Do not place this apparatus in a conned space, such as a
bookcase, or built-in cabinet, unless proper ventilation is
provided.
– Do not place this apparatus near or over a radiator or heat
register, or where it is exposed to direct sunlight.
– Do not place vessels (vases etc.) containing water on this
apparatus. A water spill can cause a re or electric shock.
•Do not expose this apparatus to rain or place it near water
(near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.). If this apparatus
accidentally gets wet, unplug it and contact an authorized dealer
immediately.
•Do not overload wall outlets, extension cords or adaptors beyond
their capacity, since this can result in re or electric shock.
•Route power-supply cords so that they are not likely to be walked
on or pinched by items placed on or against them. Pay particular
attention to cords at the plug end, at wall outlets, and the point
where they exit from the apparatus.
•To protect this apparatus from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the set due to lightning and power line
surges.
•Before connecting the AC power cord to the DC adaptor
outlet, make sure the voltage designation of the DC adaptor
corresponds to the local electrical supply.
•Never insert anything metallic into the open parts of this
apparatus. Doing so may create a danger of electric shock.
•To avoid electric shock, never touch the inside of this apparatus.
Only a qualied technician should open this apparatus.
•Make sure to plug the power cord in until it is rmly seated.
When unplugging the power cord from a wall outlet, always pull
on the power cord’s plug. Never unplug by pulling on the power
cord. Do not touch the power cord with wet hands.
•If this apparatus does not operate normally - in particular, if
there are any unusual sounds or smells coming from it - unplug it
immediately and contact an authorized dealer or service centre.
•Maintenance of Cabinet.
– Before connecting other components to this product, be sure
to turn them off.
•Be sure to pull the power plug out of the outlet if the product is
to remain unused or if you are leaving the house for an extended
period of time (especially when children, elderly, or disabled
people will be left alone in the house).
– Accumulated dust can cause an electric shock, an electric
leakage, or a re by causing the power cord to generate sparks
and heat or the insulation to deteriorate.
•Contact an authorized service centre for information if you
intend to install your product in a location with heavy dust, high
or low temperatures, high humidity, chemical substances, or
where it will operate 24 hours a day such as in an airport, a train
station, etc. Failing to do so may cause serious damage to your
product.
•Use only a properly grounded plug and wall outlet.
– An improper ground may cause electric shock or equipment
damage. (Class l Equipment only.)
•To turn this apparatus off completely, you must disconnect it
from the wall outlet. Consequently, the wall outlet and power
plug must be readily accessible at all times.
•Do not allow children to hang on the product.
•Store the accessories (battery, etc.) in a location safely out of the
reach of children.
•Do not install the product in an unstable location such as a shaky
self, a slanted oor, or a location exposed to vibration.
•Do not drop or strike the product. If the product is damaged,
disconnect the power cord and contact a service centre.
•To clean this apparatus, unplug the power cord from the wall
outlet, and then wipe the product using a soft, dry cloth. Do
not use any chemicals such as wax, benzene, alcohol, thinners,
insecticide, air fresheners, lubricants, or detergent. These
chemicals can damage the appearance of the product or erase
the printing on the product.
•Do not expose this apparatus to dripping or splashing. Do not put
objects lled with liquids, such as vases, on the apparatus.
•Do not plug multiple electric devices into the same wall socket.
Overloading a socket can cause it to overheat, resulting in a re.
WARNING :
•TO PREVENT THE SPREAD OF FIRE, KEEP
CANDLES AND OTHER ITEMS WITH OPEN
FLAMES AWAY FROM THIS PRODUCT AT ALL
TIMES.
•To reduce the risk of re or electric shock, do not
expose this appliance to rain or moisture.
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14.Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
PRECAUTIONS
1. Ensure that the AC or DC power supply in your house complies
with the power requirements listed on the identication sticker
located on the back of your product. Install your product
horizontally, on a suitable base (furniture), with enough space
around it for ventilation (7~10 cm).
Make sure the ventilation slots are not covered. Do not place the
unit on ampliers or other equipment which may become hot.
This unit is designed for continuous use.
To fully turn off the unit, disconnect the AC plug from the wall
outlet.
2. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the unit to
malfunction.
3. Unplug the Power cord from the AC wall socket if the unit
malfunctions. Your product is not intended for industrial use. It
is for personal use only. Condensation may occur if your product
has been stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the unit has
reached room temperature before using it.
4. If the electricity supplied to your home is rated at 240V AC, use
a suitable plug adapter to connect this unit to your electrical
outlets.
© 2021 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care
Centre.
Country /Area Samsung Service Centre  Web Site
` Asia Pacifi c
CHINA 400-810-5858 www.samsung.com/cn/support
TAIWAN 0800-329-999
0809-00-5237 ( B2B / Dealer) www.samsung.com/tw/support
HONG KONG 3698 4698 www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
MACAU 0800 333
SINGAPORE 1800 7267864 | 1800-SAMSUNG www.samsung.com/sg/support
AUSTRALIA 1300 362 603 www.samsung.com/au/support
NEW ZEALAND 0800 726 786 www.samsung.com/nz/support
VIETNAM 1800 588 889 www.samsung.com/vn/support
THAILAND 1800-29-3232 (Toll free for all product) www.samsung.com/th/support
MYANMAR [phone] www.samsung.com/mm/support
CAMBODIA 1800-20-3232 (Toll free) www.samsung.com/th/support
LAOS [phone]
MALAYSIA 1800-88-9999
[phone] (Overseas contact) www.samsung.com/my/support
INDONESIA 021-5699-7777
0800-112-8888 (All Product, Toll Free) www.samsung.com/id/support
PHILIPPINES
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and Mobile ]
02-8-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
INDIA 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free)
1800 5 SAMSUNG (1800 5 7267864) (Toll-Free)
www.samsung.com/in/support
NEPAL 16600172667 (Toll Free for NTC Only)
9801572667 (Toll Free for Ncell users)
BANGLADESH 08000-300-300 (Toll free)
09612-300-300
SRI LANKA 011 SAMSUNG (011 7267864)
USER MANUAL
SWA-9100S
VA81-01112W-01
NSPBI00848A-01

SAFETY INFORMATION
Thank you for purchasing this product (SWA-9100S).
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols which may
be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates that
it does not require a safety connection to
electrical earth (ground).
If this symbol is not present on a product with
a power cord, the product MUST have a reliable
connection to protective earth (ground).
AC voltage : This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
DC voltage : This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.
Caution, Consult instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
•The slots and openings in the cabinet and in the back or bottom
are provided for necessary ventilation. To ensure reliable
operation of this apparatus, and to protect it from overheating,
these slots and openings must never be blocked or covered.
– Do not place this apparatus in a conned space, such as a
bookcase, or built-in cabinet, unless proper ventilation is
provided.
– Do not place this apparatus near or over a radiator or heat
register, or where it is exposed to direct sunlight.
– Do not place vessels (vases etc.) containing water on this
apparatus. A water spill can cause a re or electric shock.
•Do not expose this apparatus to rain or place it near water
(near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.). If this apparatus
accidentally gets wet, unplug it and contact an authorized dealer
immediately.
•Do not overload wall outlets, extension cords or adaptors beyond
their capacity, since this can result in re or electric shock.
•Route power-supply cords so that they are not likely to be walked
on or pinched by items placed on or against them. Pay particular
attention to cords at the plug end, at wall outlets, and the point
where they exit from the apparatus.
•To protect this apparatus from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the set due to lightning and power line
surges.
•Before connecting the AC power cord to the DC adaptor
outlet, make sure the voltage designation of the DC adaptor
corresponds to the local electrical supply.
•Never insert anything metallic into the open parts of this
apparatus. Doing so may create a danger of electric shock.
•To avoid electric shock, never touch the inside of this apparatus.
Only a qualied technician should open this apparatus.
•Make sure to plug the power cord in until it is rmly seated.
When unplugging the power cord from a wall outlet, always pull
on the power cord’s plug. Never unplug by pulling on the power
cord. Do not touch the power cord with wet hands.
•If this apparatus does not operate normally - in particular, if
there are any unusual sounds or smells coming from it - unplug it
immediately and contact an authorized dealer or service centre.
•Maintenance of Cabinet.
– Before connecting other components to this product, be sure
to turn them off.
•Be sure to pull the power plug out of the outlet if the product is
to remain unused or if you are leaving the house for an extended
period of time (especially when children, elderly, or disabled
people will be left alone in the house).
– Accumulated dust can cause an electric shock, an electric
leakage, or a re by causing the power cord to generate sparks
and heat or the insulation to deteriorate.
•Contact an authorized service centre for information if you
intend to install your product in a location with heavy dust, high
or low temperatures, high humidity, chemical substances, or
where it will operate 24 hours a day such as in an airport, a train
station, etc. Failing to do so may cause serious damage to your
product.
•Use only a properly grounded plug and wall outlet.
– An improper ground may cause electric shock or equipment
damage. (Class l Equipment only.)
•To turn this apparatus off completely, you must disconnect it
from the wall outlet. Consequently, the wall outlet and power
plug must be readily accessible at all times.
•Do not allow children to hang on the product.
•Store the accessories (battery, etc.) in a location safely out of the
reach of children.
•Do not install the product in an unstable location such as a shaky
self, a slanted oor, or a location exposed to vibration.
•Do not drop or strike the product. If the product is damaged,
disconnect the power cord and contact a service centre.
•To clean this apparatus, unplug the power cord from the wall
outlet, and then wipe the product using a soft, dry cloth. Do
not use any chemicals such as wax, benzene, alcohol, thinners,
insecticide, air fresheners, lubricants, or detergent. These
chemicals can damage the appearance of the product or erase
the printing on the product.
•Do not expose this apparatus to dripping or splashing. Do not put
objects lled with liquids, such as vases, on the apparatus.
•Do not plug multiple electric devices into the same wall socket.
Overloading a socket can cause it to overheat, resulting in a re.
WARNING :
•TO PREVENT THE SPREAD OF FIRE, KEEP
CANDLES AND OTHER ITEMS WITH OPEN
FLAMES AWAY FROM THIS PRODUCT AT ALL
TIMES.
•To reduce the risk of re or electric shock, do not
expose this appliance to rain or moisture.
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14.Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
PRECAUTIONS
1. Ensure that the AC or DC power supply in your house complies
with the power requirements listed on the identication sticker
located on the back of your product. Install your product
horizontally, on a suitable base (furniture), with enough space
around it for ventilation (7~10 cm).
Make sure the ventilation slots are not covered. Do not place the
unit on ampliers or other equipment which may become hot.
This unit is designed for continuous use.
To fully turn off the unit, disconnect the AC plug from the wall
outlet.
2. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the unit to
malfunction.
3. Unplug the Power cord from the AC wall socket if the unit
malfunctions. Your product is not intended for industrial use. It
is for personal use only. Condensation may occur if your product
has been stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the unit has
reached room temperature before using it.
4. If the electricity supplied to your home is rated at 240V AC, use
a suitable plug adapter to connect this unit to your electrical
outlets.
© 2021 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care
Centre.
Country /Area Samsung Service Centre  Web Site
` Asia Pacifi c
CHINA 400-810-5858 www.samsung.com/cn/support
TAIWAN 0800-329-999
0809-00-5237 ( B2B / Dealer) www.samsung.com/tw/support
HONG KONG 3698 4698 www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
MACAU 0800 333
SINGAPORE 1800 7267864 | 1800-SAMSUNG www.samsung.com/sg/support
AUSTRALIA 1300 362 603 www.samsung.com/au/support
NEW ZEALAND 0800 726 786 www.samsung.com/nz/support
VIETNAM 1800 588 889 www.samsung.com/vn/support
THAILAND 1800-29-3232 (Toll free for all product) www.samsung.com/th/support
MYANMAR [phone] www.samsung.com/mm/support
CAMBODIA 1800-20-3232 (Toll free) www.samsung.com/th/support
LAOS [phone]
MALAYSIA 1800-88-9999
[phone] (Overseas contact) www.samsung.com/my/support
INDONESIA 021-5699-7777
0800-112-8888 (All Product, Toll Free) www.samsung.com/id/support
PHILIPPINES
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and Mobile ]
02-8-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
INDIA 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free)
1800 5 SAMSUNG (1800 5 7267864) (Toll-Free)
www.samsung.com/in/support
NEPAL 16600172667 (Toll Free for NTC Only)
9801572667 (Toll Free for Ncell users)
BANGLADESH 08000-300-300 (Toll free)
09612-300-300
SRI LANKA 011 SAMSUNG (011 7267864)
USER MANUAL
SWA-9100S
VA81-01112W-01
NSPBI00848A-01

01 CHECKING THE
COMPONENTS
Wireless Receiver Module / Surround Speaker X 2 / Speaker
Cable X 2 / Power Cord
NOTES
•For more information about the power supply and power
consumption, refer to the label attached to the product.
(Label: Rear of the Main Unit)
•Design and specications are subject to change without prior
notice.
02 CONNECTING THE
SWA-9100S TO A
SOUNDBAR
1. Connect the Wireless Receiver Module to
2 Surround Speakers
Use the speaker cables to connect the two surround sound
speakers to the Wireless Receiver Module.
•When connecting the speaker cable, connect the core wire to
the speaker.
SURROUND-RIGHT
SURROUND-RIGHT
•The speaker cables are colour coded.
SURROUND-LEFT
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
SURROUND-RIGHT
SURROUND-LEFT SURROUND-RIGHT
•When connecting the speaker cables to the Wireless Receiver
Module, follow these steps:
1. Insert the grey plug into the grey jack on the Wireless
Receiver.
2. Insert the blue plug into the blue jack on the Wireless
Receiver.
•When connecting the speaker cables to the surround speakers,
follow these steps:
1. Match the speaker cable connected to the grey jack to the
speaker with the grey label.
2. Match the speaker cable connected to the blue jack to the
speaker with the blue label.
3. Insert the red and black coloured ends of each speaker cable
into the red and black jacks of the appropriate speaker.
•The labels are on the backs of the speakers.
2. Check the standby status after plugging into
an electrical outlet
Plug the Wireless Receiver Module power cord into an electrical
outlet and into the Wireless Receiver Module to turn on the
Wireless Receiver Module. The LINK LED indicator (blue LED) on
the Wireless Receiver Module blinks. If the LED does not blink,
refer to step 6.
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
Blue blinking
3. Turn off the Soundbar
Turn off the Soundbar using the Soundbar’s remote control or by
pressing the (Power) button on the main Soundbar unit.
BYE
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
4. Congure “ID SET” using the Soundbar’s
remote control
Press the Up button on the Soundbar remote control for 5 seconds.
•The ID SET message appears on the Soundbar main unit’s display
for a short time and then disappears.
•After the ID SET process, the Soundbar power is automatically
turned on.
SOUND
MODE
PAIR
5 Sec ID SET
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
5. Check if the LINK LED is solid blue
(connection complete)
STANDBY
LINK
STANDBY
LINK
Blue is On
The LINK LED indicator stops
blinking and glows a solid
blue when a connection is
established between the
Soundbar and the Wireless
Receiver Module.
6. If the SWA-9100S does not connect, take
the necessary steps according to the LED
Indicator’s status
LINK (Blue) On : Connected with the Soundbar.
LINK (Blue) Blinking : Connection standby status.
•Check if the Soundbar is turned on.
•Repeat steps 3 through 5.
STANDBY (Red) On : Connection failure.
•Check if the Soundbar is turned on.
•1. Press the ID SET button on the back of the Wireless
Receiver Module with a pen tip for 5~6 seconds until the
LINK LED indicator blinks (in Blue).
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
5 Sec
2. Repeat steps 3 through 5.
Others : Errors
•Contact a Samsung Service Centre.
03 COMPATIBLE MODELS
•Compatible with select Samsung Soundbar. Please visit the
Soundbar product page at www.samsung.com/support for more
information.
•Compatible model list is subject to change without further notice.
04 OPEN SOURCE LICENCE
NOTICE
To send inquiries and requests for questions regarding open
sources, contact Samsung Open Source
(http://opensource.samsung.com)
05 SPECIFICATIONS AND
GUIDE
Specications
Model Name
SWA-9100S
Weight
Wireless Receiver Module
0.7 kg
Surround Speaker
0.6 kg
Dimensions (W x H x D)
Wireless Receiver Module
50.0 x 201.3 x 132.0 mm
Surround Speaker
87.5 X 147.0 X 87.5 mm
Operating Temperature Range
+5°C to +35°C
Operating Humidity Range
10 % ~ 75 %
Frequency range
20Hz~20kHz
NOTES
•Samsung Electronics Co., Ltd reserves the right to change the
specications without notice.
•Weight and dimensions are approximate.
•For India Only
“This product is RoHS compliant”

01 CHECKING THE
COMPONENTS
Wireless Receiver Module / Surround Speaker X 2 / Speaker
Cable X 2 / Power Cord
NOTES
•For more information about the power supply and power
consumption, refer to the label attached to the product.
(Label: Rear of the Main Unit)
•Design and specications are subject to change without prior
notice.
02 CONNECTING THE
SWA-9100S TO A
SOUNDBAR
1. Connect the Wireless Receiver Module to
2 Surround Speakers
Use the speaker cables to connect the two surround sound
speakers to the Wireless Receiver Module.
•When connecting the speaker cable, connect the core wire to
the speaker.
SURROUND-RIGHT
SURROUND-RIGHT
•The speaker cables are colour coded.
SURROUND-LEFT
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
SURROUND-RIGHT
SURROUND-LEFT SURROUND-RIGHT
•When connecting the speaker cables to the Wireless Receiver
Module, follow these steps:
1. Insert the grey plug into the grey jack on the Wireless
Receiver.
2. Insert the blue plug into the blue jack on the Wireless
Receiver.
•When connecting the speaker cables to the surround speakers,
follow these steps:
1. Match the speaker cable connected to the grey jack to the
speaker with the grey label.
2. Match the speaker cable connected to the blue jack to the
speaker with the blue label.
3. Insert the red and black coloured ends of each speaker cable
into the red and black jacks of the appropriate speaker.
•The labels are on the backs of the speakers.
2. Check the standby status after plugging into
an electrical outlet
Plug the Wireless Receiver Module power cord into an electrical
outlet and into the Wireless Receiver Module to turn on the
Wireless Receiver Module. The LINK LED indicator (blue LED) on
the Wireless Receiver Module blinks. If the LED does not blink,
refer to step 6.
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
Blue blinking
3. Turn off the Soundbar
Turn off the Soundbar using the Soundbar’s remote control or by
pressing the (Power) button on the main Soundbar unit.
BYE
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
4. Congure “ID SET” using the Soundbar’s
remote control
Press the Up button on the Soundbar remote control for 5 seconds.
•The ID SET message appears on the Soundbar main unit’s display
for a short time and then disappears.
•After the ID SET process, the Soundbar power is automatically
turned on.
SOUND
MODE
PAIR
5 Sec ID SET
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
5. Check if the LINK LED is solid blue
(connection complete)
STANDBY
LINK
STANDBY
LINK
Blue is On
The LINK LED indicator stops
blinking and glows a solid
blue when a connection is
established between the
Soundbar and the Wireless
Receiver Module.
6. If the SWA-9100S does not connect, take
the necessary steps according to the LED
Indicator’s status
LINK (Blue) On : Connected with the Soundbar.
LINK (Blue) Blinking : Connection standby status.
•Check if the Soundbar is turned on.
•Repeat steps 3 through 5.
STANDBY (Red) On : Connection failure.
•Check if the Soundbar is turned on.
•1. Press the ID SET button on the back of the Wireless
Receiver Module with a pen tip for 5~6 seconds until the
LINK LED indicator blinks (in Blue).
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
5 Sec
2. Repeat steps 3 through 5.
Others : Errors
•Contact a Samsung Service Centre.
03 COMPATIBLE MODELS
•Compatible with select Samsung Soundbar. Please visit the
Soundbar product page at www.samsung.com/support for more
information.
•Compatible model list is subject to change without further notice.
04 OPEN SOURCE LICENCE
NOTICE
To send inquiries and requests for questions regarding open
sources, contact Samsung Open Source
(http://opensource.samsung.com)
05 SPECIFICATIONS AND
GUIDE
Specications
Model Name
SWA-9100S
Weight
Wireless Receiver Module
0.7 kg
Surround Speaker
0.6 kg
Dimensions (W x H x D)
Wireless Receiver Module
50.0 x 201.3 x 132.0 mm
Surround Speaker
87.5 X 147.0 X 87.5 mm
Operating Temperature Range
+5°C to +35°C
Operating Humidity Range
10 % ~ 75 %
Frequency range
20Hz~20kHz
NOTES
•Samsung Electronics Co., Ltd reserves the right to change the
specications without notice.
•Weight and dimensions are approximate.
•For India Only
“This product is RoHS compliant”

01 CHECKING THE
COMPONENTS
Wireless Receiver Module / Surround Speaker X 2 / Speaker
Cable X 2 / Power Cord
NOTES
•For more information about the power supply and power
consumption, refer to the label attached to the product.
(Label: Rear of the Main Unit)
•Design and specications are subject to change without prior
notice.
02 CONNECTING THE
SWA-9100S TO A
SOUNDBAR
1. Connect the Wireless Receiver Module to
2 Surround Speakers
Use the speaker cables to connect the two surround sound
speakers to the Wireless Receiver Module.
•When connecting the speaker cable, connect the core wire to
the speaker.
SURROUND-RIGHT
SURROUND-RIGHT
•The speaker cables are colour coded.
SURROUND-LEFT
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
SURROUND-RIGHT
SURROUND-LEFT SURROUND-RIGHT
•When connecting the speaker cables to the Wireless Receiver
Module, follow these steps:
1. Insert the grey plug into the grey jack on the Wireless
Receiver.
2. Insert the blue plug into the blue jack on the Wireless
Receiver.
•When connecting the speaker cables to the surround speakers,
follow these steps:
1. Match the speaker cable connected to the grey jack to the
speaker with the grey label.
2. Match the speaker cable connected to the blue jack to the
speaker with the blue label.
3. Insert the red and black coloured ends of each speaker cable
into the red and black jacks of the appropriate speaker.
•The labels are on the backs of the speakers.
2. Check the standby status after plugging into
an electrical outlet
Plug the Wireless Receiver Module power cord into an electrical
outlet and into the Wireless Receiver Module to turn on the
Wireless Receiver Module. The LINK LED indicator (blue LED) on
the Wireless Receiver Module blinks. If the LED does not blink,
refer to step 6.
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
Blue blinking
3. Turn off the Soundbar
Turn off the Soundbar using the Soundbar’s remote control or by
pressing the (Power) button on the main Soundbar unit.
BYE
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
4. Congure “ID SET” using the Soundbar’s
remote control
Press the Up button on the Soundbar remote control for 5 seconds.
•The ID SET message appears on the Soundbar main unit’s display
for a short time and then disappears.
•After the ID SET process, the Soundbar power is automatically
turned on.
SOUND
MODE
PAIR
5 Sec ID SET
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
5. Check if the LINK LED is solid blue
(connection complete)
STANDBY
LINK
STANDBY
LINK
Blue is On
The LINK LED indicator stops
blinking and glows a solid
blue when a connection is
established between the
Soundbar and the Wireless
Receiver Module.
6. If the SWA-9100S does not connect, take
the necessary steps according to the LED
Indicator’s status
LINK (Blue) On : Connected with the Soundbar.
LINK (Blue) Blinking : Connection standby status.
•Check if the Soundbar is turned on.
•Repeat steps 3 through 5.
STANDBY (Red) On : Connection failure.
•Check if the Soundbar is turned on.
•1. Press the ID SET button on the back of the Wireless
Receiver Module with a pen tip for 5~6 seconds until the
LINK LED indicator blinks (in Blue).
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
5 Sec
2. Repeat steps 3 through 5.
Others : Errors
•Contact a Samsung Service Centre.
03 COMPATIBLE MODELS
•Compatible with select Samsung Soundbar. Please visit the
Soundbar product page at www.samsung.com/support for more
information.
•Compatible model list is subject to change without further notice.
04 OPEN SOURCE LICENCE
NOTICE
To send inquiries and requests for questions regarding open
sources, contact Samsung Open Source
(http://opensource.samsung.com)
05 SPECIFICATIONS AND
GUIDE
Specications
Model Name
SWA-9100S
Weight
Wireless Receiver Module
0.7 kg
Surround Speaker
0.6 kg
Dimensions (W x H x D)
Wireless Receiver Module
50.0 x 201.3 x 132.0 mm
Surround Speaker
87.5 X 147.0 X 87.5 mm
Operating Temperature Range
+5°C to +35°C
Operating Humidity Range
10 % ~ 75 %
Frequency range
20Hz~20kHz
NOTES
•Samsung Electronics Co., Ltd reserves the right to change the
specications without notice.
•Weight and dimensions are approximate.
•For India Only
“This product is RoHS compliant”

01 CHECKING THE
COMPONENTS
Wireless Receiver Module / Surround Speaker X 2 / Speaker
Cable X 2 / Power Cord
NOTES
•For more information about the power supply and power
consumption, refer to the label attached to the product.
(Label: Rear of the Main Unit)
•Design and specications are subject to change without prior
notice.
02 CONNECTING THE
SWA-9100S TO A
SOUNDBAR
1. Connect the Wireless Receiver Module to
2 Surround Speakers
Use the speaker cables to connect the two surround sound
speakers to the Wireless Receiver Module.
•When connecting the speaker cable, connect the core wire to
the speaker.
SURROUND-RIGHT
SURROUND-RIGHT
•The speaker cables are colour coded.
SURROUND-LEFT
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
SURROUND-RIGHT
SURROUND-LEFT SURROUND-RIGHT
•When connecting the speaker cables to the Wireless Receiver
Module, follow these steps:
1. Insert the grey plug into the grey jack on the Wireless
Receiver.
2. Insert the blue plug into the blue jack on the Wireless
Receiver.
•When connecting the speaker cables to the surround speakers,
follow these steps:
1. Match the speaker cable connected to the grey jack to the
speaker with the grey label.
2. Match the speaker cable connected to the blue jack to the
speaker with the blue label.
3. Insert the red and black coloured ends of each speaker cable
into the red and black jacks of the appropriate speaker.
•The labels are on the backs of the speakers.
2. Check the standby status after plugging into
an electrical outlet
Plug the Wireless Receiver Module power cord into an electrical
outlet and into the Wireless Receiver Module to turn on the
Wireless Receiver Module. The LINK LED indicator (blue LED) on
the Wireless Receiver Module blinks. If the LED does not blink,
refer to step 6.
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
Blue blinking
3. Turn off the Soundbar
Turn off the Soundbar using the Soundbar’s remote control or by
pressing the (Power) button on the main Soundbar unit.
BYE
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
4. Congure “ID SET” using the Soundbar’s
remote control
Press the Up button on the Soundbar remote control for 5 seconds.
•The ID SET message appears on the Soundbar main unit’s display
for a short time and then disappears.
•After the ID SET process, the Soundbar power is automatically
turned on.
SOUND
MODE
PAIR
5 Sec ID SET
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
5. Check if the LINK LED is solid blue
(connection complete)
STANDBY
LINK
STANDBY
LINK
Blue is On
The LINK LED indicator stops
blinking and glows a solid
blue when a connection is
established between the
Soundbar and the Wireless
Receiver Module.
6. If the SWA-9100S does not connect, take
the necessary steps according to the LED
Indicator’s status
LINK (Blue) On : Connected with the Soundbar.
LINK (Blue) Blinking : Connection standby status.
•Check if the Soundbar is turned on.
•Repeat steps 3 through 5.
STANDBY (Red) On : Connection failure.
•Check if the Soundbar is turned on.
•1. Press the ID SET button on the back of the Wireless
Receiver Module with a pen tip for 5~6 seconds until the
LINK LED indicator blinks (in Blue).
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
5 Sec
2. Repeat steps 3 through 5.
Others : Errors
•Contact a Samsung Service Centre.
03 COMPATIBLE MODELS
•Compatible with select Samsung Soundbar. Please visit the
Soundbar product page at www.samsung.com/support for more
information.
•Compatible model list is subject to change without further notice.
04 OPEN SOURCE LICENCE
NOTICE
To send inquiries and requests for questions regarding open
sources, contact Samsung Open Source
(http://opensource.samsung.com)
05 SPECIFICATIONS AND
GUIDE
Specications
Model Name
SWA-9100S
Weight
Wireless Receiver Module
0.7 kg
Surround Speaker
0.6 kg
Dimensions (W x H x D)
Wireless Receiver Module
50.0 x 201.3 x 132.0 mm
Surround Speaker
87.5 X 147.0 X 87.5 mm
Operating Temperature Range
+5°C to +35°C
Operating Humidity Range
10 % ~ 75 %
Frequency range
20Hz~20kHz
NOTES
•Samsung Electronics Co., Ltd reserves the right to change the
specications without notice.
•Weight and dimensions are approximate.
•For India Only
“This product is RoHS compliant”

01 CHECKING THE
COMPONENTS
Wireless Receiver Module / Surround Speaker X 2 / Speaker
Cable X 2 / Power Cord
NOTES
•For more information about the power supply and power
consumption, refer to the label attached to the product.
(Label: Rear of the Main Unit)
•Design and specications are subject to change without prior
notice.
02 CONNECTING THE
SWA-9100S TO A
SOUNDBAR
1. Connect the Wireless Receiver Module to
2 Surround Speakers
Use the speaker cables to connect the two surround sound
speakers to the Wireless Receiver Module.
•When connecting the speaker cable, connect the core wire to
the speaker.
SURROUND-RIGHT
SURROUND-RIGHT
•The speaker cables are colour coded.
SURROUND-LEFT
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
SURROUND-RIGHT
SURROUND-LEFT SURROUND-RIGHT
•When connecting the speaker cables to the Wireless Receiver
Module, follow these steps:
1. Insert the grey plug into the grey jack on the Wireless
Receiver.
2. Insert the blue plug into the blue jack on the Wireless
Receiver.
•When connecting the speaker cables to the surround speakers,
follow these steps:
1. Match the speaker cable connected to the grey jack to the
speaker with the grey label.
2. Match the speaker cable connected to the blue jack to the
speaker with the blue label.
3. Insert the red and black coloured ends of each speaker cable
into the red and black jacks of the appropriate speaker.
•The labels are on the backs of the speakers.
2. Check the standby status after plugging into
an electrical outlet
Plug the Wireless Receiver Module power cord into an electrical
outlet and into the Wireless Receiver Module to turn on the
Wireless Receiver Module. The LINK LED indicator (blue LED) on
the Wireless Receiver Module blinks. If the LED does not blink,
refer to step 6.
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
POWER
STANDBY
LINK
STANDBY
LINK
Blue blinking
3. Turn off the Soundbar
Turn off the Soundbar using the Soundbar’s remote control or by
pressing the (Power) button on the main Soundbar unit.
BYE
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
4. Congure “ID SET” using the Soundbar’s
remote control
Press the Up button on the Soundbar remote control for 5 seconds.
•The ID SET message appears on the Soundbar main unit’s display
for a short time and then disappears.
•After the ID SET process, the Soundbar power is automatically
turned on.
SOUND
MODE
PAIR
5 Sec ID SET
•The image of the Soundbar may differ from your Soundbar,
depending on the model.
5. Check if the LINK LED is solid blue
(connection complete)
STANDBY
LINK
STANDBY
LINK
Blue is On
The LINK LED indicator stops
blinking and glows a solid
blue when a connection is
established between the
Soundbar and the Wireless
Receiver Module.
6. If the SWA-9100S does not connect, take
the necessary steps according to the LED
Indicator’s status
LINK (Blue) On : Connected with the Soundbar.
LINK (Blue) Blinking : Connection standby status.
•Check if the Soundbar is turned on.
•Repeat steps 3 through 5.
STANDBY (Red) On : Connection failure.
•Check if the Soundbar is turned on.
•1. Press the ID SET button on the back of the Wireless
Receiver Module with a pen tip for 5~6 seconds until the
LINK LED indicator blinks (in Blue).
ID SET
L R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
5 Sec
2. Repeat steps 3 through 5.
Others : Errors
•Contact a Samsung Service Centre.
03 COMPATIBLE MODELS
•Compatible with select Samsung Soundbar. Please visit the
Soundbar product page at www.samsung.com/support for more
information.
•Compatible model list is subject to change without further notice.
04 OPEN SOURCE LICENCE
NOTICE
To send inquiries and requests for questions regarding open
sources, contact Samsung Open Source
(http://opensource.samsung.com)
05 SPECIFICATIONS AND
GUIDE
Specications
Model Name
SWA-9100S
Weight
Wireless Receiver Module
0.7 kg
Surround Speaker
0.6 kg
Dimensions (W x H x D)
Wireless Receiver Module
50.0 x 201.3 x 132.0 mm
Surround Speaker
87.5 X 147.0 X 87.5 mm
Operating Temperature Range
+5°C to +35°C
Operating Humidity Range
10 % ~ 75 %
Frequency range
20Hz~20kHz
NOTES
•Samsung Electronics Co., Ltd reserves the right to change the
specications without notice.
•Weight and dimensions are approximate.
•For India Only
“This product is RoHS compliant”
