WDR DAY/NIGHT COLOR CAMERA
SCC-B2305(P)/B2005P
User’s Manual
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지1

E
2 3
Important Safety Instructions
E
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, or other apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being from being walked on or
pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a used,
caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-
over.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or been dropped.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE REAR
COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED
SERVICE PERSONNEL.
To prevent damage which may result in fire or electric shock hazard,
do not expose this appliance to rain or moisture.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions.
1) This device may not cause harmful interference, and
2) This device must accept any interference that may cause undesired
operation.
CAUTION:
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
This symbo indicates
high vo tage is present
inside. It is dangerous to
make any kind of contact
with any inside part of
this product.
This symbo a erts you
that important iterature
concerning operation and
maintenance has been
inc uded with this
product.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지2

E
4 5
Chapter 1 Introduction
E
Contents
Cha ter 1 Introduction ........................................................ 5
Cha ter 2 Specia Features ............................................. 6
Cha ter 3 Part Names and Functions ............................... 7
Cha ter 4 Insta ation .......................................................... 12
Cautions for Insta ation and Use .......................13
Connecting Automatic Shutter Lens Connector ........... 14
Fixing Lens and Adjusting Lens Se ection Switch ....... 15
Adjusting Back Focus ........................................ 16
Connecting Cab es ............................................ 18
Cha ter 5 Camera Set-Up ................................................. 20
A endix Product Specification ........................................ 39
The WDR(Wide Dynamic Range)DAY/NIGHT camera sha be used to
express both dark and bright part distinctive y in the screen with a dua
shutter. The conventiona camera c ips the screen white when a bright
object ike a window occupies the screen whi e this camera is a technica y
integrated state-of-the-art product to revive even a brighter part distinctive y.
The DAY/NIGHT Camera operates in a co or mode in an the i umination
over the standard va ue and otherwise in B/W mode by de eting the IR Cut
function, which contributes to the improvement of sensitivity so that it is
ca ed a ow i umination camera which is ab e to identify objects in a dark
area. Meanwhi e, it has incorporated a Sense Up function owing to a ow
speed shutter and a fie d accumu ation method to improve its ow
i umination feature prominent y.
The DAY/NIGHT Camera is most y used in dark p aces ike basement
parking ots with a comparative y ow i umination. In daytime, it provides a
co or screen of high density with a horizonta reso ution of 480, and, at
night, it uti izes the DAY/NIGHT function as we as the Sense Up function
to identify objects. In same cases, you may use this camera in re ation to
the infrared ray emission equipment additiona y.
[WDR(Wide Dynamic Range)]
The WDR camera is a state of art to en arge the screen profit
effectivey, especia y for taking photos of a window in a bui ding. In
short it revives both the indoor and outdoor status as they are ceary.
[DAY/NIGHT]
It is a function of a co or camera to de ete the fiter with the IR Cut
function in an i umination be ow the standard va ue so that it has
a better sensitivity.
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지4

6 7
Chapter 2 Special Features Chapter 3 Part Names and Functions
EE
High Sensitivity
It has an up-to-date 1/3" Super-HAD P/S CCD for an image of high
sensitivity.
Function of WDR
The WDR camera is state-of-the-art to en arge the screen profit effective y,
especia y for taking photos of a window in a bui ding. In short it revives
both the indoor and outdoor status as they are c ear y.
Low Illumination Function
It has both a ow i umination function and DAY/NIGHT function based on
digita signa techno ogy in order to operate in the worst environment
without ight.
Su erior Back Light Adjustment Function
In case the object has a bright i umination or sun ight behind it, this camera
adjusts the image shaded by the back ight for c ear photographs.
Digital Power Su ly Synchronization Method
The Fu Digita Method Line Lock is rea ized in this camera, which adjusts
the vertica camera synchronization direct y to improve contro abi ity and
re iabi ity of the camera.
High Resolution
It rea izes high reso ution resu ting from fu digita image processing
supported by a state-of-art digita signa techno ogy.
Out ut Signal Setting
You may se ect the REVERSE (horizonta y, vertica y, or both) function of
the video output signa and the private, horizonta , and vertica profi e.
Side View
Mount Ada ter Fixing Groove
This groove is used for screwing the mount adapter, a part of the bracket
where the camera wi be insta ed.
Camera Lens(O tion)
This ens is insta ed in the camera.
* A camera ens with a stained surface shou d be c eaned soft y with a ens
tissue or ethano painted cotton c oth.
Auto Iris Lens Connector
This connector provides the automatic shutter ens with power supp y,
contro signa , video signa , or DC signa necessary for the contro of the
ens shutter
Automatic Shutter
Lens Contro Cab e
ALC Lens
Se ection Switch
Auto Iris Lens
Connector
Mount Adapter Fixing
Groove
Back Focus
Contro Bar
Camera Lens
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지6

EE
8 9
Auto Iris Lens Control Cable
This cable transmits the control signal from the camera to control the lens
shutter.
Back Focus Control Bar
It controls the back focus.
ALC Lens Setting Switch
This switch sets the Auto Iris lens type for use.
 DC : When you attach an Auto Iris lens requiring the DC control signal,
please put this switch in the DC position.
 IDEO : When you attach an Auto Iris lens requiring the video control
signal, please put this switch in the IDEO position.
① Power Display LED
When the camera is supplied with power, LED is on.
➁ideo Output Terminal
The monitor video input terminal is connected with this terminal through
which the camera video signal comes out.
➂Remote Input Terminal(RS-232)
This terminal is used for camera control at the production plant.
SCC-B2305(P) Rear iew
AC 220-240
SCC-B2005P Rear iew
1 2 3 4
1 TXD
2 RXD
3+5
4 GND
00371A SCC-B2305(P)-eng 2003.6.27 2:57 PM 페이지8

EE
10 11
➃ DAY/NIGHT External Signal In ut & Alarm Signal Out ut
This is a function to receive the externa DAY/NIGHT signa from the
sensor(option) and convert the signa into BW. The MOTION DET
function generates an a arm signa when a movement is detected.
⑤ Camera O eration Switch(Setu Switch)
The function of the camera operation switch changes depending on
whether the camera is current y in the usua operation mode(No setup
menu is seen on the screen) or the setup menu mode.
[UP/DOWN] key : These keys move up or down the cursor.
[LEFT/RIGHT] key : These keys move the cursor to the eft or right or
identify the va ues sequentia y which can be
assigned in each setup menu.
[ENTER] key : It is used to enter the Setup menu.(Press it about 2
seconds.)
It is used to enter a sub-menu of a setup menu by
c icking the setup menu or to set the current va ue.
➅ Power Connection Port
This port is connected to the power(adapter) cab e.
①
➁
DAY/NIGHT IN
GND
ALARM OUT
Connect an externa sensor to the DAY/NIGHT termina as shown in ①then
connect any externa device such as a buzzer or amp to the ALARM
termina as shown in ➁.
The ALARM output termina is an open co ector with the fo owing capacity:
DC 16V and 100mA.
OFF : Open contact
ON : Be ow 100mA
The DAY/NIGHT input termina has the input of DC 5V pu -up and over
0.2mA.
OFF : Open contact
ON : C osed contact
[LEFT/RIGHT] key
[ENTER] key
[UP/DOWN] key
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지10

E
12 13
Chapter 4 Installation
E
This chapter describes what shou d be checked before insta ation, how to
set the insta ation environment, and what shou d be done during
insta ation. Then, it describes how to insta the camera and connect the
cab e in actua circumstances. ① Do not disassemb e the camera on your own.
➁Be carefu when hand ing the camera at a times. Do not strike the
camera with your fists or shake it. The camera shou d be stored and
treated with care to avoid any damage.
➂Do not put or operate the camera in rain or wet p aces.
➃ Do not scrub the camera body with rough sandpaper when it is stained.
P ease use a dry c oth at a times.
⑤ Put the camera in a coo area free from direct ight. Otherwise, the
camera may be damaged.
Be sure to check if the fo owing items are inc uded in the package.
Before Installation
Checking the contents of the ackage
What should be done during installation and use
Camera Camera Ho der(Mount)
C Mount Adapter Auto Iris
Lens Connector
User's Manua
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지12

EE
14 15
Connecting Auto Iris Lens Connector
Prepare the Auto Iris ens connector, a camera auxi iary, as fo ows :
Connect each uncovered shutter contro cab e wire to the Auto Iris ens
connector as fo ows.
Pin No. DC Contro Type VIDEO Contro Type
1 Damp(-) Power (+12V)
2 Damp(+) N/A
3 Drive(+) VIDEO Signa
4 Drive(-) GROUND
Installation
Lens Fixing
In case of CS lenses
Turn the CS ens c ockwise unti it is fixed as shown as fo ows.
In case of C lenses
Turn the C-mount adapter c ockwise to fix it. Then turn the C ens
c ockwise unti it is fixed as fo ows.
CS lens
C lens
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지14

EE
16 17
Setting Switch Control
Back Focus Adjustment
You shou d change the position of the ens setting switch on the side of the
camera according to the ens type. Depending on whether you fixed the DC
contro type Auto Iris ens or video contro type automatic shutter ens, you
shou d put the switch in "DC" or "VIDEO" position respective y.
The camera back focus is adjusted at the p ant before de ivery, but some
enses are out of focus though the number differs in types. If it's the case,
you shou d make the back focus adjustment as fo ows. First, this is the
back focus adjustment procedure for fixed focus enses.
Lenses with zoom function
① Image an object with high reso ution(etticed) at a distance of 3 to 5 m
and zoom in the ens as c ose to TELE as possib e. Then adjust the ens
focus bar unti the object is seen best.
➁Zoom in the ens as c ose to WIDE as possib e and adjust the BACK
FOCUS adjustment bar unti the object is seen best.
➂Repeat from ①to ➁above 2 or 3 times unti the focus on the ZOOM
TELE side is in ine with that on the ZOOM WIDE side.
Lenses without zoom function
① Image an object with high reso ution( etticed) at more than 10m distance
and put the ens focus ring in the infinite(∞) position.
➁Rotate the BACK FOCUS contro bar unti the object is seen best.
➂Tighten the BACK FOCUS contro bar fixing screw.
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지16

EE
18 19
Connecting Cables and Checking O eration
1 First, connect the connector of the BNC cab e to the Video Out termina
2 Second, connect the other connector of the BNC cab e to the Video In
termina .
3 Then, connect the power adapter. Connect a part of the power adapter
composed of 2 ines to the Camera Power In termina with a f at-head
driver as fo ows.(GND : marked with a white ine)
* Power source may be AC24V or DC12V irrespective of po arity
BNC cab e
Video Out Termina
Video In Termina of
Monitor Rear Surface
SCC-B2305(P)
SCC-B2005P
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지18

E
20 21
Chapter 5 Camera Set-Up
E
This chapter describes how to set up the camera. The first part
describes the who e set up menu and composition and the second part
describes the function of each menu. This CAMERA ID menu designates a CAMERA ID on the monitor screen
connected to the camera. If you turn on the CAMERA ID menu and press
the [ENTER] key, the sub-screen wi appear to designate a CAMERA ID.
The CAMERA ID may be composed of etters, numbers, specia texts, or a
combination of these up to 20 digits. The designated CAMERA ID can be
ocated at any p ace as desired by using the submenu
CAMERA ID
press the
[ENTER] key
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW COLOR
SHUTTER OFF
AGC OFF
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
(CAMERA ID)
A B C D E F G H I J K L
M N O P Q R S T U V W
X Y Z 0 1 2 3 4 5 6 7 8 9
: ! - + * ( ) /
SP ❿❿➛➛ SP
LOCATION...
RET
....................
CAMERA ID
ON.../OFF
CAMERA ID AND
LOCATION SETUP
SETUP
MENU
IRIS
DC... /VIDEO/ELC...
DC IRIS SETUP
ELC LEVEL SETUP
BLC AREA SETUP
BOTTOM...TOP...
LEFT...RIGHT...
CENTER...
LEVEL SETUP
FLICKERLESS SETUP
BURST ON/OFF
BURST ON/OFF
LEVEL DURATION
BURST ON/OFF
PHASE SETUP
3200K/5600K/USER
RED-BLUE SETUP
PRIVACY TYPE &
AREA SETUP
AREA SETUP
SENSITIVITY SETUP
BAUD RATE, REVERSE,
POSI/NEGA, DETAIL,
MOTION DET...,
PRIVACY..., LANGUAGE
BLC/WDR
OFF
/BLC...
/WDR...
SHUTTER
OFF/ 1/100~1/10K
OFF/ AUTO
X2~X160
AGC
OFF/LOW/HIGH
MOTION
S.SLOW/SLOW/
NORM/FAST/F.FAST
WHITE BAL
ATW/AWC/MANU...
SYNC
INT/LINE...
SPECIAL
...
EXIT
QUIT/SAVE/PRESET
COLOR/BW
COLOR/BW...
/AUTO.../EXT...
MANU...
LINE...
SPECIAL...
PRIVACY...
MOTION
DET...
ELC...
DC...
BW...
AUTO...
WDR...
EXT...
BLC...
ON...
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지20

EE
22 23
This CAMERA has an IRIS function for automatic contro of the brightness
eve through the intensity of radiation. The ALC can se ect the DC IRIS
eve , VIDEO IRIS, and ELC LEVEL.
❿DC...
If you se ect the DC menu and press the [ENTER] key, the sub-screen
wi appear to set the brightness eve. Here, you are ab e to set the
brightness eve by pressing the LEFT or RIGHT key in the LEVEL
menu. Leve setting is avai abe on y by using the DC IRIS ens.
Then, you sha puts the ALC LENS se ection switch on the side of the
camera in the “DC” position.
❿VIDEO
It is used whi e the VIDEO ens is in use. You sha use the variab e
resistor attached to the IRIS LEVEL LENS for the contro . Then put the
ALC LENS se ection switch on the camera side in “VIDEO” position.
❿ELC...
This menu contro s the High Speed Shutter Leve within a imited range
in the event of too intensive radiation from outside whi e using the
Manua Lens. If you se ect the ELC in the IRIS menu and press the
[ENTER] key, the fo owing subscreen wi appear. Here, you are ab e to
set the eve by pressing the LEFT or RIGHT key.
IRIS
press the
[ENTER] key
press the
[ENTER] key
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW COLOR
SHUTTER OFF
AGC OFF
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
(IRIS/DC)
LEVEL (0) ----I----
RET
CAMERA ID OFF
IRIS VIDEO
BLC/WDR OFF
COLOR/BW COLOR
SHUTTER OFF
AGC OFF
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
CAMERA ID ON...
IRIS ELC...
BLC/WDR OFF
COLOR/BW COLOR
SHUTTER OFF
AGC OFF
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
(IRIS/ELC)
LEVEL (0) ----I----
RET
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지22

EE
24 25
❿BLC...
If you use an ordinary camera when there is an intense and concentrated
i umination behind an object, the back ight wi shade the image on the
monitor screen. The BLC function prevents such a back ight effect to secure
a c ear image under a i umination environments. Press the LEFT or RIGHT
key at OFF to set the USER function for a setting of the a ready set 5 areas
incuding BOTTOM..., TOP..., LEFT..., RIGHT..., and CENTER. If you se ect
the BOTTOM... in the BLC menu and press the [ENTER] key, you wi be ab e
to certify the a ready set BOTTOM area.
❿WDR...
The WDR camera is state of the art to en arge the screen profit effectivey,
especia y for taking photos of a window in a bui ding. In short it revives both
the indoor and outdoor status as they are c ear y.
BLC/WDR
press the
[ENTER] key
press the
[ENTER] key
CAMERA ID ON...
IRIS ELC...
BLC/WDR BLC...
COLOR/BW COLOR
SHUTTER OFF
AGC OFF
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
(BLC)
AREA BOTTOM...
RET
CAMERA ID OFF
IRIS DC
BLC/WDR WDR...
COLOR/BW COLOR
SHUTTER OFF
AGC OFF
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
press the
[ENTER] key
(WDR)
LEVEL L - - - I - - - H
FLICKERLESS OFF
RET
❖ The eve of DC IRIS can be set at the time of WDR function setup.
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지24

EE
26 27
The COLOR/BW menu turns the IR(Infrared) Fi ter on or off. In ow
i umination environments, the BW mode wi turn off the IR Fi ter and the
sensitivity wi be as high as that of BW cameras. Otherwise, the BW mode
wi turn on the IR Fi ter and the sensitivity wi return to norma to recover
the norma screen.
❿COLOR
In this mode, the camera outputs the video image on y in co or.
COLOR/BW
press the
[ENTER] key
❿BW...
This is the IR Fi ter OFF Mode in b ack and white.(high sensitivity ike
BW cameras) If you se ect the BW... and press the [Enter] key, the BW
submenu screen wi appear. You wi be ab e to send out the BURST
signa by turning on or off in this menu.
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW COLOR
SHUTTER OFF
AGC OFF
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW BW...
SHUTTER OFF
AGC OFF
WHITE BAL ---
SYNC INT
SPECIAL ...
EXIT QUIT
(BW)
BURST ON
RET
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지26

EE
28 29
❿AUTO...
This menu automatica y converts the COLOR Mode into the BW Mode
or vice versa depending on i umination. In ow i umination
environments, it turns off the IR Fi ter to raise sensitivity, otherwise it
turns on the IR Fi ter to ower sensitivity.
If you se ect the AUTO menu and press the [Enter] key, the BW LEVEL
Contro AUTO BW submenu wi appear on the menu screen. You wi be
ab e to send out the BURST signa by turning on or off in this menu, set
up the DURATION TIME for conversion, or set up the standard
brightness eve for converting the COLOR mode into the BW mode.
press the
[ENTER] key
❿EXT...
This menu automatica y converts the COLOR Mode into the BW Mode
or vice versa depending on i umination with an externa sensor. If you
se ect the EXIT menu and press the [Enter] key, the EXTERNAL BW
submenu wi appear on the menu screen. You wi be ab e to send out
the BURST signa by turning on or off in this menu.
press the
[ENTER] key
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW AUTO...
SHUTTER OFF
AGC ---
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
(AUTO BW)
BURST ON
LEVEL LOW
DURATION S -I-----L
RET
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW EXT...
SHUTTER OFF
AGC OFF
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
(EXTERNAL BW)
BURST ON
RET
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지28

EE
30 31
❿AGC
The AGC menu ightens the screen be ow the standard brightness
because of the object taken in dark i umination. Setting up the AGC
menu is avai abe on y in either High Speed Shutter mode or OFF mode.
If you press the LEFT or RIGHT key to reach the LOW or HIGH position,
the AGC function wi start activating. LOW is used for the ower AGC
GAIN whereas HIGH is used for the higher AGC GAIN.
Whi e the COLOR/BW menu is set to AUTO, the AGC menu is a --- and
the maximum AGC GAIN stays at HIGH.
The SHUTTER menu sets up the high speed e ectronic shutter, AUTO
ow speed shutter. The high speed e ectronic shutter covers 7 shutter
speeds from 1/100 to 1/10K seconds and is common y used for imaging
fast moving objects. Both the ow speed shutter cover 10 shutter speeds
from x2 to x160, which s ows the shutter speed to make c earer and
brighter the screen images taken in dark i umination. If you want to s ow
the shutter speed automatica y depending on the degree of darkness by
sensing the intensity of radiation, p ease se ect the AUTO ow speed.
If you keep pressing the LEFT or RIGHT key, the fo owing speeds appear
in sequence.
OFF → AUTO X2 → AUTO X4 → AUTO X6 → AUTO X8 → AUTO X12 → AUTO X16 → AUTO
X20
→ AUTO X40 → AUTO X80 → AUTO X160 → OFF → 1/100(NTSC), 1/20(PAL) → 1/250 →
1/500 → 1/1000 → 1/2000 → 1/4000 → 1/10K → OFF
❖ Whi e the IRIS mode is in ELC or the BLC/WDR mode is WDR, you may
use the fo owing modes on y.
OFF → AUTO X2 → AUTO X4 → AUTO X6 → AUTO X8 → AUTO X12 → AUTO X16 → AUTO
X20
→ AUTO X40 → AUTO X80 → AUTO X160 → OFF
SHUTTER AGC/MOTION
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW AUTO...
SHUTTER OFF
AGC ---
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW AUTO...
SHUTTER OFF
AGC ---
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지30

EE
32 33
❿MOTION
The MOTION function is avai ab e on y in the AUTO mode with these 5
steps: S.SLOW, SLOW, NORM, FAST, F.FAST.
 The S.SLOW minimizes the intensity of the AGC to monitor stab e
objects in the dark
 The SLOW keeps the intensity of AGC ow to monitor objects with a
itt e movement in the dark.
 The NORM standardizes the intensity of AGC to monitor moving
objects in the dark.
 The FAST keeps the intensity of AGC high to monitor fast moving
objects in the dark.
 The F.FAST maximize the intensity of AGC to monitor very fast
moving objects in the dark.
To activate the MOTION function, you shou d press the DOWN key to
move the cursor to the MOTION menu and press the LEFT or RIGHT
key whi e the SHUTTER menu is set to AUTO. Pressing the LEFT and
RIGHT key enab es you to move to the SLOW mode and FAST mode
respective y
❿ATW
If you se ect the ATW mode in the WHITE BAL menu, you wi be ab e to
monitor the co or temperature change by rea time and set up the White
Ba ance to the rea time co or temperature automatica y.
❿AWC
If you se ect the AWC mode in the WHITE BAL menu, you wi be ab e to
set up the White Ba ance to the rea time co or temperature on y once
which wi be maintained thereafter. If you se ect the AWC mode in the
WHITE BAL menu, fix a screen that you want to image, and press the
[ENTER] key. Then the AWC function wi start activating.
❿MANU...
If you se ect the MANU.. mode in the WHITE BAL menu, you wi be ab e
to set up the White Ba ance in consideration of the current i umination
manua y. If you se ect the MANU... item and press the [ENTER] key, the
MANU... submenu wi appear to se ect the White Ba ance. If you press
the LEFT or RIGHT key in the PRESET menu, you wi be ab e to se ect
the 3200K, 5600K, or USER mode.
 3200K : Set the co or temperature to 3200°K
 5600K : Set the co or temperature to 5600°K.
 USER : Use the RED and BLUE contro bar to se ect a proper va ue
for setup.
WHITE BAL
press the
[ENTER] key
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW AUTO...
SHUTTER AUTO X2
MOTION F.FAST
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW EXT...
SHUTTER OFF
AGC OFF
WHITE BAL MANU...
SYNC INT
SPECIAL ...
EXIT QUIT
(AWB/MANU)
PRESET 3200K
RET
❿
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지32

EE
34 35
The INT mode is necessary for using the interna synchronization and
the LINE... mode is necessary for the operation of mu ti cameras
because it synchronizes the camera phase by using the externa
signa (AC Signa ). A itt e phase deviation for some sets may be a igned
by adjusting the PHASE. The SYNC function is avai abe on y with AC
power source. Put the cursor on the SYNC, press the LEFT/RIGHT key
to se ect the LINE... item, and press the [ENTER] key. Now, you wi see
the submenu to adjust the PHASE. The PHASE ranges from -106H to
+106H(NTSC), -138H to +138H(PAL).
❖ When you use DC power source, the SYNC Menu is fu --- and you can
not use the SYNC function.
SYNC
You can contro the BAUD RATE, REVERSE, POSI/NEGA, DETAIL, and
MOTION DET function by yourse f in the SPECIAL menu. If your se ect the
SPECIAL menu and press the [ENTER] key, the SPECIAL submenu screen
wi appear.
SPECIAL
press the
[ENTER] key
❿BAUD RATE : Sets the communication speed to 4800, 9600, 19200, or
38400bps for RS-232 communication.
❿REVERSE : REVERSES THE SCREEN IN 3 MODES, LEFT/RIGHT,
UP/DOWN, OR LEFT/RIGHT/UP/DOWN.
❖Note: P ease reset the BLC, MOTION, PRIVACY area because they don’t change
by a means.
❿POSI/NEGA : Outputs the video brightness signa norma y or reverse y.
The brightness eve is high at inverted output.
❿DETAIL : Adjusts the horizonta and vertica sharpness.
❿MOTION DET : MOTION DET detects any movement of objects. if you
activate the MOTION DET function at the time when you expect nobody
to move, the function wi detect the movement of an intruder Once
detected, the function outputs the ALARM signa . The MOTION DET
function detects any movement and se ects the movement sensitivity
and the area to detect the movement. If you se ect the ON... mode and
press the [ENTER] key, the MOTION DET submenu screen wi appear.
press the
[Left/Right]
key
press the
[ENTER] key
(AWB/MANU)
PRESET 3200K
RET
(AWB/MANU)
PRESET OFF (USER)..
RED ( 00) ----I----
BLUE ( 00) ----I----
RET
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW EXT...
SHUTTER OFF
AGC OFF
WHITE BAL MANU...
SYNC LINE...
SPECIAL ...
EXIT QUIT
(LINE LOCK)
PHASE (-106) I--------
RET
CAMERA ID ON...
IRIS DC...
BLC/WDR OFF
COLOR/BW EXT...
SHUTTER OFF
AGC OFF
WHITE BAL MANU...
SYNC INT
SPECIAL ...
EXIT QUIT
(SPECIAL)
BAUD RATE 38400
REVERSE OFF
POSI/NEGA +
DETAIL (0)----I--
MOTION DET OFF
PRIVACY ...
RET
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지34

EE
36 37
The AREA is set in the same way with the AREA in the BLC menu whi e
designating one among ALL, CENTER, BOTTOM, TOP, LEFT, or RIGHT. If
you se ect BOTTOM and hit the ENTER key, the se ected area wi be
disp ayed in the screen.
The SENSITIVITY is used to setup the strength of the MOTION
DETECTION in 7 eve s.
❿PRIVACY : This function is aiming at the protection of persona privacy,
se ecting a screen part b ack not to be disp ayed in the screen.
This function permits the contro of the strength eve in 8 eves.
You may setup the size and ocation of the area.
(SPECIAL)
BAUD RATE 38400
REVERSE OFF
POSI/NEGA +
DETAIL (0)----I--
MOTION DET ON...
PRIVACY ...
RET
(MOTION DET)
AREA BOTTOM...
SENSITIVITY L---I---H
RET
press the
[ENTER] key
press the
[ENTER] key
POSITION
SIZE
UP/DOWN
KEY
POSITION..
LEFT/RIGHT
KEY
press the
[ENTER] key
press the
[ENTER] key
press the
[ENTER] key
(PRIVACY ZONE)
PRIVACY1 ON...
PRIVACY2 OFF
PRIVACY3 OFF
PRIVACY4 OFF
PRIVACY5 OFF
PRIVACY6 OFF
PRIVACY7 OFF
PRIVACY8 OFF
RET
(SPECIAL)
BAUD RATE 38400
REVERSE OFF
POSI/NEGA +
DETAIL (0)----I--
MOTION DET ON...
PRIVACY ...
RET
SIZE
SIZE
UP/DOWN
KEY
POSITION..
LEFT/RIGHT
KEY
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지36

EE
38 39
The EXIT menu is used for the termination of the CAMERA SETUP menu.
❿QUIT
Ignores any change and returns to the previous y saved SETUP menu.
❿SAVE
Saves a the changes to the menu unti now.
❿PRESET
Ignores any change and returns to the initia va ue of the CAMERA
SETUP menu which was set for the product shipment.
EXIT
ITEM DESCRIPTION
Definition
CCTV CAMERA (WDR & DAY/NIGHT)
Power Source SCC-B2305(P) : AC 24V ± 10% (NTSC:60Hz ±
0.1Hz, PAL:50Hz ± 0.1Hz), DC12V +10% ~ -5%
SCC-B2005P : AC220V ~ AC240V (50Hz
±0.1Hz)
Power Consum tion SCC-B2305(P) : Approx. 4.5W
SCC-B2005P : Approx. 5W
Broadcasting System SCC-B2305:NTSC Standard Co or System
SCC-B2305(P),SCC-B2005P:PAL Standard
Co or System
Imaging Device 1/3 inch P/S CCD
Effective Pixel NTSC:
768(H) X 494(V)
PAL: 752(H) X 582(V)
Scanning Method NTSC:525 Line, 2:1 Inter ace
PAL:625 Line, 2:1 Inter ace
Line Frequency Horizonta(NTSC) : 15,734 Hz(INT) / 15,750 Hz(L/L)
Horizonta(PAL) : 15,625 Hz(INT) / 15,625 Hz(L/L)
Vertica (NTSC) : 59.94 Hz(INT) / 60 Hz(L/L)
Vertica(PAL) : 50 Hz(INT) / 50 Hz(L/L)
Synchronization Method INT/Line Lock
Resolution 480 TV Lines
S/N Ratio Over 50dB (AGC Off)
Product Specification
SCC-B2305(P)/B2005P Special Features
CAMERA ID OFF
IRIS DC...
BLC/WDR OFF
COLOR/BW AUTO...
SHUTTER AUTO X2
AGC F.FAST
WHITE BAL ATW
SYNC INT
SPECIAL ...
EXIT QUIT
00371A SCC-B2305(P)-eng 2003.6.27 11:16 AM 페이지38
