WOOSHIN WS-50C User manual

OWNER’S MANUAL
http://www.wsblackbox.com
#331-2, Sansung-dong, Joong-ku, Daejeon, Korea
TEL: [phone]
FAX: [phone]
ws051[email protected]
For WS-50C Series Owner’s Manual
4. Specification : 5. Additional Accessories (Option) :
ITEM SPECIFICATION
Image 1/3-Inch Sony Super HAD Color CCD
Resolution NTSC 510,000 / PAL 610,000 pixels
Lens Focal Length 2.5mm / MAX. Aperture F=2.0
FOV(Field of View) 150°
Sync Internal
Horizontal Resolution 680 TV Line
Required Illumination 0.001 Lux
Singnal to Noise Ratio Min 48dB(AGC off)
Video Out put 75Ω 1.0Vp-p Composite
Audio In put High Sensitive C-mic
Input Voltage 12 ~ 24V
Operating Temp -30°C ~ 70°C (-22°F ~ 158°F)
Dimensions 87(W) × 51(H) × 55(D)mm
*With out Sun-Visor & Mounting Bracket
*With out Sun-Visor & Mounting Bracket.
.
Weight 314g
Supplied Accessories
■ Camera Sun-Visor
■ Stainless Mounting Bracket & Hardware Kits
■ Installation Guide Book
■ Screw Kit, which Includes:
► 4 Self-Tapping, Philips Screws with Washers
►4 Hex-Head Machine Screws
► 1 Allen Wrench
20m Cable
10m Cable
*Accoding to your requested length of cable, we can supply them all.
1/3” SONY HAD CCD COLOR CAMERA-
WS-50C
*TAB EDIT 20160617-s
20160617

►One high resolution color camera with 1/3” Sony HAD CCD
Image sensor and the following features :
• Compact, lightweight, waterproof aluminum Die-Cast housing.
• Integrated Microphone.
• Wide Angle Lens.
• Auto-Iris lens that automatically adjusts to light conditions.
• Built-in Normal/Mirror Switch.
►One 75.5 foot (23 meter) waterproof extension cable.
►Standard adjustable stainless steel mounting bracket and
installation accessories.
When the camera is in Normal mode, the image is displayed
normally on the monitor (not supplied). When the camera is in
mirror mode, the image is displayed in reverse on the monitor, as
the image would appear in a rear-view mirror. The rear panel and
Normal/Mirror selector are shown in Figure 4.
Standard Mounting Bracket ;
1) Fasten the standard camera mounting bracket, using the
supplied self-tapping Philips screws, to the desired mounting
surface, as shown in the step 1 arrows of Figure 2.
2) Position the camera and sun shield in the camera mounting
bracket. Adjust the camera to the correct angle, and then attach
the camera to the camera mounting bracket using the supplied
hex-head machine screws with washers, as shown in step 2 and
step 3 arrows of Figure 2.
B) Route the extension cable from the camera location to the
location of the output device (not supplied), such as a monitor
or switcher.
C) Connect the male plug of the camera pigtail, which is
attached to the camera, to the female socket of the extension
cable, as shown in Figure 3.
D) Insert the male plug of the extension cable into the
appropriate female audio/video port of the output device (not
supplied), such as a monitor or switcher.
Caution:
To reduce the risk of electrical shock, disconnect the Battery
from the electrical system of the vehicle before starting the
installation.
A) Install the camera in the desired location, using the supplied
standard mounting bracket as follows.
Caution:
Inserting screws into the mounting surface, ensure that the
underside of the mounting surface is clear of equipment that
might be damaged by the screws.
1. System Overview 3.Normal/Mirror Selector :
2. Installation :
Figure 1. High Resolution 1/3-inch CCD Color Camera with 65-foot Extension Cable
For WS-50C Series Owner’s Manual For WS-50C Series Owner’s Manual For WS-50C Series Owner’s Manual
Figure 2. Installing the Camera in the standard Mounting Bracket.
CABLE
CABLE
PIN
MOLD CAP
Figure 3. Connecting the Camera Pigtail to the Extension Cable.
MOLD CAP
Figure 4. Rear Panel and Normal/Mirror Image Selector
12 VDCGround
Audio Video
▲Mirror Image
▲Normal Image
If eliminating the Magnet, it will be the Normal on Mirror.
If inserting the Magnet, it will be the input on Mirror in
Camera.
Figure 4. Norma/Mirror.
