Samsung TC222W User manual

User manual
TC222W
TC242W
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.

Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
7 Copyright
7 Icons used in this manual
8 Cleaning
9 Securing the Installation Space
9 Precautions for storage
10 Safety Precautions
10 Symbols
11 Electricity and Safety
12 Installation and Safety
14 Operation and Safety
18 Correct posture to use the product
PREPARATIONS 19 Checking the Contents
19 Checking the Components
20 Parts
20 Frontal Buttons
22 Rear View
23 Side View
24 Installation
24 Attaching the Stand
25 Adjusting the Product Tilt and Height
25 Rotating the Monitor
26 Installing a Wall-mount Kit or Desktop Stand
28 Anti-theft Lock
USING "WINDOWS
EMBEDDED STANDARD 7"
29 What is "Windows Embedded Standard
7" Client?
31 Connection to Use "Windows Embedded
Standard 7"
31 LAN Connection
31 Connecting USB Devices

Table Of Contents
Table Of Contents 3
32 Using "Windows Embedded Standard 7"
32 Logon
32 "Windows Embedded Standard 7" Desktop
33 Programs
40 Configuring Utilities
41 Recover the System
CONNECTING AND USING
A SOURCE DEVICE
43 Before Connecting
43 Pre-connection Checkpoints
43 Connecting and Using a PC
43 Connection Using the D-SUB Cable (Analog
Type)
44 Connecting to a Dual Monitor
45 Connecting to Headphones
45 Connecting a Microphone
46 Connecting the Power
47 Setting Optimum Resolution
SCREEN SETUP 48 Brightness
48 Configuring Brightness
49 Contrast
49 Configuring Contrast
50 Sharpness
50 Configuring Sharpness
51 Eye Saver Mode
51 Configuring Eye Saver Mode
52 Game Mode
52 Configuring Game Mode
53 SAMSUNG MAGIC Bright
53 Configuring SAMSUNG MAGIC Bright
54 SAMSUNG MAGIC Angle
54 Configuring SAMSUNG MAGIC Angle

Table Of Contents
Table Of Contents 4
56 SAMSUNG MAGIC Upscale
56 Configuring SAMSUNG MAGIC Upscale
57 Image Size
57 Changing the Image Size
58 H-Position & V-Position
58 Configuring H-Position & V-Position
59 Coarse
59 Adjusting Coarse
60 Fine
60 Adjusting Fine
CONFIGURING TINT 61 Red
61 Configuring Red
62 Green
62 Configuring Green
63 Blue
63 Configuring Blue
64 Color Tone
64 Configuring the Color Tone Settings
65 Gamma
65 Configuring Gamma
RESIZING OR
RELOCATING THE
SCREEN
66 Language
66 Changing the Language
67 Menu H-Position & Menu V-Position
67 Configuring Menu H-Position & Menu V-
Position
68 Display Time
68 Configuring Display Time
69 Transparency
69 Changing Transparency

Table Of Contents
Table Of Contents 5
SETUP AND RESET 70 Reset All
70 Initializing Settings (Reset All)
71 Smart Eco Saving
71 Configuring Smart Eco Saving
72 Off Timer Plus
72 Configuring Off Timer
74 Configuring Eco Timer
76 Key Repeat Time
76 Configuring Key Repeat Time
INFORMATION MENU AND
OTHERS
77 INFORMATION
77 Displaying INFORMATION
78 Configuring Brightness, Contrast and
Sharpness from the Initial Screen
INSTALLING THE
SOFTWARE
79 MagicRMS Pro
79 About MagicRMS Pro
79 Components
80 MagicRMS Pro Server
80 MagicRMS Pro Database
80 MagicRMS Pro Console
80 PXE
80 MagicRMS Pro Agent
TROUBLESHOOTING
GUIDE
81 Requirements Before Contacting
Samsung Customer Service Center
81 Testing the Product
81 Checking the Resolution and Frequency
81 Check the following.
84 Q & A
SPECIFICATIONS 86 General
88 PowerSaver

Table Of Contents
Table Of Contents 6
89 Standard Signal Mode Table
APPENDIX 91 Responsibility for the Pay Service (Cost
to Customers)
91 Not a product defect
91 A Product damage caused by customer's fault
91 Others
92 Correct Disposal
92 Correct disposal of batteries in this product
93 Terminology
INDEX

7
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2015 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
Icons used in this manual
An administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product
(i.e, where you have failed to read this user manual).
(b) you bring the unit to a repair center and there is no defect in the product
(i.e, where you have failed to read this user manual).
The amount of such administration charge will be advised to you before any work or home visit is
carried out.
The following images are for reference only. Real-life situations may
differ from what is shown in the images.

8
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
1. Power off the monitor and computer.
2. Disconnect the power cable from the monitor.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the monitor screen using a clean, soft and dry cloth.
Do not apply a cleaning agent that contains alcohol,
solvent, or surfactant to the monitor.
Do not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the monitor.
5. Connect the power cable to the product after cleaning the product.
6. Power on the monitor and computer.
!
!

9
Before Using the Product
Before Using the Product
Securing the Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire
and damage the product. Be sure to allow the amount of space as shown below or greater when
installing the product.
The exterior may differ depending on the product.
Precautions for storage
Be sure to contact Samsung Customer Service Center if the inside of the monitor needs cleaning.
(Service fee will be charged.)
10 cm (3.93 inches)
10 cm
(3.93 inches)
10 cm
(3.93 inches)
10 cm (3.93 inches)
10 cm (3.93 inches)

10
Before Using the Product
Before Using the Product
Safety Precautions
Symbols
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
