Samsung XA100F Operational manual

1
Outdoor P10 Product User Manual
Model Name: XA100F
Model Code: LH100XAFSSC/**

2
Table of contents
1. Safety.....................................................................................................................4
1.1 Warning& Symbols..................................................................................4
1.2 Safety Guidelines.................................................................................... 5
1.3 Installation instructions......................................................................... 6
2. Open Package..................................................................................................... 7
2.1 Front view.................................................................................................. 7
2.2 Side view....................................................................................................8
3. Outdoor P10 Product introduction................................................................9
3.1 Product Specification............................................................................. 9
3.2 Product Appearance............................................................................. 11
3.3 Product design.......................................................................................12
3.4 Product main components................................................................. 14
4. LED display screen components.................................................................16
5. Parts List And Parts BOM List......................................................................18
5.1 Accessories list..................................................................................... 18
5.2 Spares list................................................................................................19
5.3 Parts BOM List....................................................................................... 20
5.4 Service BOM List.................................................................................. 21
6. Trouble shooting list....................................................................................... 23
6.1 Display screen problem.......................................................................23
6.2 Cabinet problem.................................................................................... 26
6.3 Module problem.....................................................................................28
7. Installation Guides...........................................................................................32
7.1 Mechanical requirements and installation..................................... 32
7.2 Electrical requirements........................................................................36
8. Connection of the LED screen..................................................................... 38
8.1 Connection for equipments................................................................38
8.2 Port of Cabinet and serial number paint......................................... 39
8.3 Connection for power cables.............................................................40
8.4 Connection for data cables................................................................ 41
8.5 Cabinet arrangement drawings sample.......................................... 42
9. Control system setting................................................................................... 43
9.1 Software setup....................................................................................... 43
9.2 NovaLCT-Mars Main interface............................................................44
9.3 Main Menu............................................................................................... 45
9.4 Tool Bar....................................................................................................47
9.5 Screen Config.........................................................................................48
9.6 Advanced color configuration........................................................... 52
9.7 Adjust the brightness, Gamma and Current Gain........................ 58
9.8 Display Control...................................................................................... 70
9.9 Check Hardware Info............................................................................ 71
9.10 Brightness/Color Calibration............................................................. 72
9.11 Monitor the System...............................................................................91

3
10. Servicing.......................................................................................................101
10.1 Cleaning.................................................................................................101
10.2 Calibration.............................................................................................102
10.3 Replacement steps............................................................................. 103
11. Appendix.......................................................................................................117
11.1 Responsibility for the Pay Service(Cost to Customers)...........117

4
1. Safety
1.1 Warning& Symbols
Grounding
The combination of multiple cabinets in an installation results in increased levels of
leakage current. In order to avoid risk of electric shock due to high leakage current, proper
grounding of the installation is required.
Defeating the purpose of the grounding type plug will expose you to the risk of electric
shock.
Grounding symbols
Electric safety
Do not open equipments with below symbols. To reduce the risk of electric shock, do not
remove cover (or back). No user-serviceable parts inside. Qualified service personnel is
required for serving.
High voltage symbols
High voltage symbols
The lighting flash with an arrowhead within a triangle is intended to tell the user that parts
inside this product may cause a risk of electrical shock to persons.

5
1.2 Safety Guidelines
Personal protection
Ensure you understand and follow all the safety guidelines, installation instruction,
warnings and symbols.
Mind yourself while working with heavy loads and high voltage.
Contact with high voltage may cause death or serious injury. Always disconnect power
to the display cabinet or cabinets prior to servicing.
All personnel at the LED Video Board installation site are required to have personal
protection equipment (PPE) such as hard hats, safety glasses, gloves, harnesses, and
other appropriate safety equipment.
Equipment protection
This installation must be performed by authorized and qualified technical personnel only.
Accredited safety officers must ensure the safety of the site, construction, assembly,
connection, use, dismantling, transport etc.
Assembly parts are designed for use only with Samsung displays.
LEDs use specific materials and manufacturing processing in order to achieve unique
advantages.Donotmodify and/or replicate any components.
Ground the LED display screen before connecting the power source.Contacting displays
that are not earth-grounded may cause death or serious injury.
Do not use the LED display screen ground lugs for installation equipment such as welding
equipment.
Structural & mounting components should be kept dry, clean, lubricated (only if
recommended), coated properly, and maintained in a manner consistent with part design.
LED products must be installed and operated in a manner to reply on its design and
inspection a routine basis for security, wear, deformation, corrosion and any other
circumstances that may affect the load handling capability of the part.
We recommend inspections at regular intervals for all installations and increasing in
frequency for more critical installations. A part is damaged which may cause a decrease in
load capability. The part must be removed for service or replaced immediately.
Always follow LED display screen installation instruction.
Contact the support technical person if user has any question regarding the safety of an
application. The manufacturer assumes no liability for incorrect, inadequate, irresponsible
or unsafe assembly of systems.

6
1.3 Installation instructions
Instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not block ventilation openings. Please install in accordance with the manufactures
instructions.
Avoid installation near heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat. We suggest the user install some
equipment to reduce the heat if any.
Do not break the safety purpose of polarized or grounding type plugs/sockets. If the
provided sockets/plugs are damaged then replacement of the detective parts must be
undertaken immediately.
Protect the power/data cords from being taken off or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus. Replace
damaged power/data cords immediately.
Only use attachments/accessories specified or provided by the manufacturer.
Use with caution during lifting/moving or transporting to avoid damage by possible crash.
After receiving the LED display screen, please uncover all the boxes and cases, count
and check all things compare with the packing list. If there is any problem such as missing
or damaged part, contact the manufacture immediately.
Installation guide details are shown in charter 7&8.

7
2. Open Package
2.1 Front view
Step 1: Open the top wooden cover
Step 2: Open the side wooden cover
Step 3: Take the cabinet out from the wooden box.

8
2.2 Side view
Step 1: Open the top wooden cover
Step 2: Open the side wooden cover
Step 3: Take the cabinet out from the wooden box.

9
3. Outdoor P10 Product introduction
3.1 Product Specification
No.
Parameter
Specification
1
Attribute
Outdoor P10
2
Model name
XA100F
3
Pixel Pitch (mm)
10
4
LED vendor
Nationstar
5
LED package type
SMD3535
6
LED package part name
RS-3535MWAR
7
LED Lifetime Hr
( 24Hr, Luminance 50% down)
100,000
8
Size of LED color bin combination
R: 5nm, G:4nm, B:4nm
9
Number of LED color bin
combination
1ea, up to 2ea
10
Driver IC vendor
MBI
11
Driver IC part name
MBI5051B
12
T-CON vendor
Novastar
13
T-CON part name
MCTRL600-S/MRV500
14
SMPS vendor
Great Wall
15
SMPS part name
GW-XSP300WV5 5V/60A
16
Module Dimension, LxH (mm)
320x320
17
Module Resolution, LxH
32x32
18
Cabinet Dimension, LxHxD (mm)
960x960x142
19
Cabinet Dimension With
Waterproof cover ,LxH (mm)
960x960x208
20
Cabinet Resolution, LxH
96x96
21
Cabinet Weight (kg/cabinet)
52
22
Cabinet Construction
Steel
23
Package Method
2pcs in 1wooden case
24
Package Dimension ,LxHxD(mm)
1050 x 1145 x 510
25
Packing accuracy（mm）
＋10
26
Package Weight(per wooden box)
26kg
27
Brightness (cd/m²) Before
Calibration
>7500
28
Brightness (cd/m²) After
Calibration
>6750
29
Contrast Ratio(C/R)
3000：1
30
Front Mask for C/R
Louver/Mask
31
Viewing angle - Horizontal (o)
140

10
32
Viewing angle - Vertical (o)
80
33
Bit-depth(bit)
14
34
Refreshrate(Hz)
≧2000
35
Scanrate (lines)
3
36
Power consumption - Max
(W/㎡)
<900W
37
Powerconsumption-Typical
(W/㎡)
<320W
38 Power AC100-120V or 220-240V, 47~63Hz
39 Working Temperature (℃)-30°C to 50°C
40 Operation Humidity 10% to 90%
41 Storage Temperature -30°C to 60°C
42 Storage Humidity 10% to 90%
43 Color Temperature
44 - Default 6500K±500K
45 Adjustable range 2800~16000K（8ea）
46 Cooling Fan
47 IP Rating Front IP65/Rear IP45
48 Accessory in Box
Modulemask,screws, powercables,signal
cable,ConnectingPlate,door keys.
49
EMC Certification
Class A
50
SafetyCertification
51
Service
Back service

11
3.2 Product Appearance

12
3.3 Product design
Decomposition chart

13
Assembly drawing

14
3.4 Product main components
Module
Power Supply
Receiving card
Fan

15
DC output cables（9 pcs）
Flat cables (9 pcs)

16
4. LED display screen components
LED display screen connection
Sending box(Model Name: LSFNS, Model Code: VG-LSFNS/ZX)
PowerLEDand Switch:
Poweronorpoweroffthesendingbox,theLEDshowthestatusofsendingbox.
Power supply:
ACpowerinput,offerpower forsendingbox.
PowerLEDonback:
Showthestatusofsendingcard.
Audio:
Audioinput,connecttotheaudiosource,receivingtheaudiosignal
USB:
Controlport,connecttothecomputer,receivingcontrolsignal
DVIinput:
DVIvideo input,connectto thevideosource, receivingthevideo signal
HDMIinput:
HDMIvideoinput,connecttothevideosource,receivingthevideosignal
Ethernetport:
Signaloutputports,connecttothedisplay,passsignal
Cascade:
Cascadecontrolinandout,connecttoanothersendingbox
LightSensorinterface:
Connecttothe light sensor,supportbrightness adjustmentautomatically.

17
Function of sending box:
1. HDMI/DVI input;
2. HDMI/external audio input;
3. 12bit/10bit/8bit HD video source；
4. Resolution supported: 2048x1152, 1920x1200, 2560x960;
5. Resolution supported: 1440x900;
6. 1 light sensor interface;
7. Cascading supported;
8. 18bit gray scale processing and presentation;
9. Video format:RGB, YCrCb4:2:2, YCrCb4:4:4;
10. Standard 1U housing; independent power supply;
1U chassis, Size: 482.6mm(width)*44.45mm(height)*250mm(depth).dd
Weight: 4.15Kg Net weight: 2.7Kg
Computer
Note: Usually the sending box and he PC should be running in control
room.
LED display screen

18
5. PartsList AndParts BOMList
5.1 Accessories list
Sending box U Disk 3 core plug DVI cable
BN81-15303A BN81-15333A BN81-15312A BN81-15310A
R2S8-22-1721 2S8-22-2038 R2J8-22-0125 R2L3-27-0104
USB cable AC power input cable Signal input cable AC power cascade cable
BN81-15311ADifferentcodebydifferent projectBN81-15313A
R2L3-27-0105Differentcode bydifferentproject3D2-22-2588
SignalcascadecableConnectplateM10BowlsKeyforbackdoor
BN81-15314ABN81-15326ABN81-15334ABN81-15335A
3D3-23-0788R2J8-42-0072R2W8-22-0466R2W8-29-3277
Remark:Thefinalquantityissubjecttoeachorder.

19
5.2 Spares list
Sending box Receiving card and hub board Module Power supply
BN81-15303A BN81-15305A BN81-15301A BN81-15304A
R2S8-22-1721 R2S8-22-1569 R4B3-10-0305 R2D8-25-0082
Fan LED package Driver IC Mask
BN81-16098ABN81-15302A BN81-15325A BN81-15332A
R2F8-88-0430 R3G1-27-0054 R2K2-22-0219 R2A8-24-0133
ScrewsforMaskACpowerinputcableSignal cascadecableACpowercascadecable
BN81-15336ADifferentcodebydifferentprojectBN81-15313A
R2W8-22-1410Differentcodebydifferentproject3D2-22-2588
DC output cable Flat cables Other materials
BN81-15315A(...) BN81-15321A(...)
3D2-22-6880(...) 3D4-23-0659(...)
Remark: The final quantity is subject to each order. 3% spare parts will be sent within each
order.

20
5.3 Parts BOM List
Samsung Code Code Name Spec Unit Quantity
BN81-15303A R2S8-22-1721 Sending box MCTRL600-S（ROHS）PCS
Dependon
project
BN82-02274B R2W8-27-5322 Outdoor Cabinet 960*960*120mm PCS
BN81-15301A R4B3-10-0305 P10 module
3S 32*32 EMC Nova
system(ROHS)
PCS
BN81-15312A R2J8-22-0125 3 core plug L 1.5M PCS
2S8-22-2038 U Disk Control software/Setting files PCS
BN81-15310A R2L3-27-0104 DVI cable L 1.5M PCS
BN81-15311A R2L3-27-0105 USB cable L 1.5M PCS
BN81-15305A R2S8-22-1569 Receiving card MRV500-1（ROHS）PCS
BN81-15306A R3C6-88-0293 Hub Board
Hub06-RT(3DATAOUT6
GROUP)V3.0ROHS
PCS
Dependon
project
Dependon
project
Signalinput
cable
Cat-5typeL(dependon
project)
PCS
Dependon
project
Dependon
project
ACpowerinput
cable
3*2.5m㎡L(dependon
project)
PCS
BN81-15313A
3D2-22-2588
ACPower
cascadecable
3*2.5m ㎡
130CM(UL)2.5-40，2.5-40
PCS
BN81-15314A
3D3-23-0788
Signalcascade
cable
Cat-5type150CM(UL)
PCS
BN81-15326A
R2J8-42-0072
Connectplate
130*130*4（ROHS）
PCS
BN81-15334A
R2W8-22-0466
M10Bowls
Sixangle(stainlesssteel)
（ROHS）
PCS
BN81-15335A
R2W8-29-3277
Keyforback
door
Circlewithears
PCS
BN81-15304A R2D8-25-0082 Power supply
GW-XSP300WV55V/60A
（UL/CE/CCC）(ROHS)
PCS
R2F8-88-0430 Fan
SA12038CA2
120*120*38(220-240V）/
0.12A CCC/CE/UL
PCS
BN81-15302A R3G1-27-0054 LED package
NationStar3535
(RS-3535-MWAR)
PCS
BN81-15325A
R2K2-22-0219
Driver IC
MBI5051BGP
MSSOP24L-150-0.635
PCS
BN81-15332A R2A8-24-0259 Mask
MaskP10(16*16)H-5mm
0ROHS
PCS
BN81-15336A R2W8-22-1410 Screws for Mask Black (φ2.8) ROHS PCS
BN81-15315A(...) 3D2-22-6880(...) DC output cable
2.5m ㎡2.5-40,6P3.96
65CM(UL)…
PCS
BN81-15321A(...)
3D4-23-0659(...)
Flatcables
20P20CM(UL)…
PCS
BN81-15333A
BN81-16098A
