Samsung DW60M9970 Series User manual

Dishwasher
Installation manual
DW60M9970**/DW60M9550**/DW60M9530**
DW9000M_DD68-00193B-02_EN.indd 1 2018-04-10  12:58:48

Contents
English2
Contents
What’s included 3
Installation kit (provided) 3
Installation kit (not provided) 5
Tools required (not provided) 5
Installation requirements 6
Power supply 6
Grounding 6
Water supply 6
To reduce a risk of leaks: 6
Aqua Stop 6
Drain 7
Flooring 7
Ambient temperature 7
Test run 7
Step-by-step installation 8
Cabinet dimensions 9
SBI (Semi Built-In, DW60M9***S*) models 14
FBI (Fully Built-In) models 20
Skirting board 27
Pre-cut skirting board (DW60M9****US Series) 27
Skirting board 28
Kick plate (applicable models only) 29
DW9000M_DD68-00193B-02_EN.indd 2 2018-04-10  12:58:48

Installation
English 3
Installation
What’s included
Make sure all the parts are included in the product package. If you have a question about
the dishwasher or the parts, contact a local Samsung customer centre or your retailer. The
actual appearance of the dishwasher may differ, depending on your model and country.
CAUTION
After unpacking the dishwasher, keep packaging materials out of children’s reach to
ensure their safety.
Installation kit (provided)
FBI (Fully Built-In, DW60M9***BB)
Top brackets (2 ea) Ø4 X 12 screws
(8 ea)
Protective sticker Sub foot
Custom panel
xers (wood panel
holders, 2 ea)
Ø4 X 43 screws
(4 ea)
Ø4 X 16 screws
(2 ea)
Rubber skirt
DW9000M_DD68-00193B-02_EN.indd 3 2018-04-10  12:58:49

Installation
Installation
English4
SBI (Semi Built-In, DW60M9***S*)
Top brackets (2 ea) Ø4 X 12 screws
(8 ea)
Protective sticker Sub foot
Custom panel
xers (wood panel
holders, 2 ea)
Ø4 X 43 screws
(4 ea)
Ø4 X 16 screws
(2 ea)
Rubber skirt
5 mm wood spacers
(7 ea)
BU (Built Under, DW60M9***U*)
Top brackets (2 ea) Ø4 X 12 screws
(8 ea)
Protective sticker Sub foot
Ø4 X 8 screws
(2 ea)
Kick plate brackets
(2 ea)
Kick plate Lower felt
DW9000M_DD68-00193B-02_EN.indd 4 2018-04-10  12:58:50

Installation
English 5
Installation kit (not provided)
Hose clamp
Tools required (not provided)
Safety glasses Gloves Flashlight Wrench (22 mm) for
the front foot
Torx T20 Pliers Nipper Tape measure
Pencil Phillips screwdriver Flat head
screwdriver
Cutting knife
Level Hole saw
DW9000M_DD68-00193B-02_EN.indd 5 2018-04-10  12:58:50

Installation
Installation
English6
Installation requirements
To prevent a risk of re, electric shock, or
personal injury, all wiring and grounding
must be done by a qualied technician.
Power supply
• An individual 220-240 V, 50 Hz
branch circuit that is dedicated to the
dishwasher.
• Power outlet with a maximum allowable
current of 16 A (maximum 11 A for the
dishwasher)
WARNING
• Do not use an extension cord.
• Use only the power plug that comes
with the dishwasher.
• After installation is complete, make sure
the power plug is not bent or damaged.
Grounding
For permanent grounding, the dishwasher
must be properly grounded to a grounded
metal or permanent wiring system. The
grounding conductor must be run with
the circuit conductors and then connected
to the grounding terminal or lead on the
dishwasher.
WARNING
• Do not connect the ground wire to
plastic plumbing, gas lines, or hot water
pipes. Improperly connected grounding
conductors may cause electric shock.
• Do not modify the power plug of the
dishwasher. If the power plug does
not t the outlet, have a proper outlet
installed by a qualied electrician.
Water supply
• The water supply line must support
water pressures between 0.05 and
0.8 MPa.
• Water temperatures must be lower than
60 °C.
• A stopcock with a ⁄” male thread must
be installed on the water tap.
To reduce a risk of leaks:
• Make sure water taps are easily
accessible.
• Turn the water tap off when the
dishwasher is not in use.
• Check for any leaks at the water hose
ttings on a regular basis.
• To stop any leak, seal the water line
connections and joints using Teon tape
or sealing compound.
Aqua Stop
The Aqua Stop is an electrical component
that is designed to prevent water leaks.
The Aqua Stop is attached to the water
hose and automatically cuts off the water
ow in the event of damage to the hose.
CAUTION
• Handle the Aqua Stop with care.
• Do not kink or twist the water hose
connected to the Aqua Stop. If the
Aqua Stop is damaged, shut off the
water taps and unplug the power plug
immediately. Then, contact a local
Samsung customer centre or a qualied
technician.
DW9000M_DD68-00193B-02_EN.indd 6 2018-04-10  12:58:50

Installation
English 7
Drain
If you are using a drain system dedicated
to the dishwasher, connect the drain hose
to a drain system that is between 30 cm
and 70 cm off the ground. Connecting
the drain hose to a drain system more
than 80 cm off the ground can cause the
drained water to ow backward.
Flooring
For safety, the dishwasher must be
installed on a solidly constructed oor.
Wooden oors may need to be reinforced
to minimize vibrations. Avoid installing
on carpet or soft tile. Carpeting and soft
tile may cause vibrations and may cause
your dishwasher to move slightly while
operating.
WARNING
Do not install the dishwasher on a poorly
supported structure.
Ambient temperature
Do not install the dishwasher in an area
exposed to freezing temperatures. The
dishwasher always retains some water in
the water valve, pump, and hose. If the
water freezes in the dishwasher or hoses,
it may damage the dishwasher and its
components.
Test run
After installing the dishwasher, run the
Quick cycle to make sure the dishwasher is
installed correctly.
DW9000M_DD68-00193B-02_EN.indd 7 2018-04-10  12:58:50

Installation
Installation
English8
Step-by-step installation
The installation procedure may differ depending on the model.
STEP 1 Select a location
A
B
Select a location that meets the following
conditions.
• The location must have a solid oor that
can support the weight of the dishwasher.
• The location must be near a sink with
easy access to the water supply, drain
system, and electrical outlet.
• The location must let you load dishes into
the dishwasher easily.
• The location must have sufcient space
for the dishwasher door to open easily
and provide enough space between the
dishwasher and the cabinet sides.
• The rear wall must be free of obstructions.
Installation in a new location
If you install the dishwasher in a new
location, follow these instructions before
installing the dishwasher.
1. Using a hole saw, cut a hole into the side
of the cabinet that holds the sink (A).
2. If the base inside the sink cabinet is raised
above the kitchen oor and is higher than
the connections on the dishwasher, make
a hole in the base inside the cabinet and in
the cabinet side (B).
NOTE
• If you are replacing an old dishwasher, check the existing connections for compatibility
with the new dishwasher and replace the connections as needed.
• You may need to cut a hole in the opposite side of the cabinet according to the location of
the electrical outlet.
DW9000M_DD68-00193B-02_EN.indd 8 2018-04-10  12:58:51

Installation
English 9
Cabinet dimensions
Max. 720
594
575600
598
575
817-875 mm
820-890 mm
53
100 50
NOTE
Check if the distance between the oor and the bottom of the worktop is more than 860 mm.
If so, replace the rear foot with the sub foot included in the installation kit. For details, see the
next section. If the distance is less than 860 mm, skip to STEP 3.
DW9000M_DD68-00193B-02_EN.indd 9 2018-04-10  12:58:51

Installation
Installation
English10
STEP 2 To replace the rear foot
If the distance between the oor and the bottom of the worktop is more than 860 mm,
replace the rear foot with the sub foot provided before starting installation.
1. Lay the dishwasher on its back.
CAUTION
Do not lay down the dishwasher to a side.
Water may leak.
2. Locate the rear foot at the rear bottom
of the dishwasher.
3. Turn the Torx T20 screwdriver counter
clockwise as shown to remove the rear
foot.
DW9000M_DD68-00193B-02_EN.indd 10 2018-04-10  12:58:51

Installation
English 11
4. Find the sub foot in the installation
kit. Insert the sub foot into the hole of
the rear foot’s place, and then turn the
screwdriver clockwise to tighten the
sub foot.
5. When the sub foot is xed, turn the
front foot to align with the sub foot.
Fine-tuning will be done in STEP 5.
CAUTION
Use caution when moving the dishwasher.
Do not drag the dishwasher on the oor.
This can damage the front and sub foot.
STEP 3 Check the water line
• The water line pressure must be between 0.05 and 0.8 MPa.
• Make sure that the water temperature does not exceed 60 °C. Hot water over 60 °C
may cause the dishwasher to malfunction.
• Make sure that the water supply valve is turned off before connecting the water supply
line to the dishwasher.
DW9000M_DD68-00193B-02_EN.indd 11 2018-04-10  12:58:51

Installation
Installation
English12
STEP 4 Arrange the hoses
1. Clean the bottom of the countertop.
2. Attach the protective sticker as shown.
3. Arrange the power plug, the water
hose, and the drain hose.
4. Pull them through the sink hole.
CAUTION
• Use caution not to kink or step on the
power plug or the hoses.
• Do not remove the brown paper on the
back of the dishwasher. The paper is
used to keep the rear side clean against
the wall.
DW9000M_DD68-00193B-02_EN.indd 12 2018-04-10  12:58:52

Installation
English 13
STEP 5 Level the dishwasher
For FBI (Fully Built-In) models, go to STEP 6 and install the custom panel rst. Then, return
to the current step (STEP 5) and level the dishwasher.
0-60 mm
0-45 mm
45-60 mm
Normal Tall-kitchen
(Switch to the sub foot)
You can adjust the height of the
dishwasher to level it. Note that in these
steps, the dishwasher is currently inserted
halfway.
1. Use the level to check if the dishwasher
is level.
2. To adjust the front height, use a 22 mm
wrench.
• To lower the height, turn the foot
counter clockwise.
• To raise the height, turn the foot
clockwise.
3. To adjust the rear height, insert the
Torx T20 screwdriver in the bottom
center of the dishwasher.
• To lower the height, turn the
screwdriver clockwise.
• To raise the height, turn the
screwdriver counter clockwise.
4. When levelling is complete, check if the
door opens and closes properly.
DW9000M_DD68-00193B-02_EN.indd 13 2018-04-10  12:58:52

Installation
Installation
English14
STEP 6 Install the custom panel (SBI/FBI models only)
SBI (Semi Built-In, DW60M9***S*) models
A
1. Insert the supplied rubber skirt (A) into
the 3 holes at the bottom of the door.
(applicable models only)
NOTE
If the rubber skirt is wider than the
dishwasher, cut the skirt to match the
width of the dishwasher.
A
B
2. Select to align the custom panel to
either the top or bottom edge of the
cabinets.
A. To align the custom panel to the top
edge of a cabinet.
B. To align the custom panel to the
bottom edge of a cabinet.
CAUTION
Note that installation method differs for A
and B.
DW9000M_DD68-00193B-02_EN.indd 14 2018-04-10  12:58:52

Installation
English 15
SBI (Semi Built-In, DW60M9***S*) models
A
B
max. 115
max. 720
594
3. Fully insert the dishwasher under the
countertop.
4. Align the top of the installation
template to the bottom of the
dishwasher’s door handle.
5. On both sides of the installation
template, mark the spot according to
your alignment.
• For A: At the top edge of a cabinet.
• For B: At the bottom edge of a cabinet.
DW9000M_DD68-00193B-02_EN.indd 15 2018-04-10  12:58:52

Installation
Installation
English16
SBI (Semi Built-In, DW60M9***S*) models
B
A
6. Put the installation template on the
back of the custom panel.
• For A: Align the marks on the
installation template to the top edge of
the custom panel.
• For B: Align the marks on the
installation template to the bottom edge
of the custom panel.
7. Use transparent tape to temporarily x
the installation template to the custom
panel.
8. On the custom panel, mark the location
of the 6 screw holes according to the
installation template.
NOTE
The rear of the custom panel will be
attached to the dishwasher door.
CAUTION
Use a custom panel between 2.5 kg and
8 kg.
B
C
B
C
9. Remove the installation template and
tighten the custom panel xers (B) near
the bottom with 2 screws (C, Ø4 X 16)
as shown.
DW9000M_DD68-00193B-02_EN.indd 16 2018-04-10  12:58:52

Installation
English 17
SBI (Semi Built-In, DW60M9***S*) models
1 spacer
2 spacers
3 spacers
4 spacers 7 spacers
6 spacers
5 spacers
5-9 mm
10-14 mm
25-29 mm
30-34 mm
35-39 mm
15-19 mm
20-24 mm
10. Pull out the dishwasher halfway from
under the countertop.
11. Attach single or multiple wood spacers
whose overall height lls the gap
between the sink cabinet and the
control panel.
• The gap here is the same as the
measurement in step 5 above.
• For positioning and the number of
spacers, see the gures on the left.
CAUTION
Do not let the overall height of the wood
spacers exceed the measured height
difference. Otherwise, the custom panel
may not t.
DW9000M_DD68-00193B-02_EN.indd 17 2018-04-10  12:58:53

Installation
Installation
English18
SBI (Semi Built-In, DW60M9***S*) models
B
12. While holding the custom panel, attach
it to the door and insert the custom
panel xers (B) into the corresponding
holes near the bottom of the door as
shown.
13. Push the custom panel upward to x.
14. Open the dishwasher door and remove
the 2 screws.
CAUTION
Use caution when opening the door. The
door might open or close unexpectedly
if the spring level is not adjusted
appropriately, resulting in physical injury.
DW9000M_DD68-00193B-02_EN.indd 18 2018-04-10  12:58:54

Installation
English 19
SBI (Semi Built-In, DW60M9***S*) models
15. Secure the custom panel to the door by
fastening the 4 screws (Ø4 X 43).
12345
30˚
16. Refer to the table below and adjust the
spring level by turning the spring screw
with Torx T20 screwdriver on the front
of the dishwasher.
• Adjust the spring level while the door is
approximately opened at 30 degrees.
• The door should hold its position. It
should not fall open.
CAUTION
Do not adjust the spring level while the
door is completely opened.
Recommended spring levels
Level Weight of the custom panel (kg)
Level 1-2 2-5
Level 2-3 5-6
Level 3-4 6-7
Level 4-5 7-9
CAUTION
If the custom panel weighs more than 9 kg, the door may fall open. Custom panels
weighing more than 9 kg are not recommended.
DW9000M_DD68-00193B-02_EN.indd 19 2018-04-10  12:58:55

Installation
Installation
English20
FBI (Fully Built-In) models
A
1. Insert the supplied rubber skirt (A) into
the 3 holes at the bottom of the door.
(applicable models only)
Ø2
10~12
2. Put the installation template on the
back of the custom panel and x it
temporarily using transparent tape.
Note that the rear of the custom panel
will be attached to the dishwasher door.
CAUTION
• The top end of the custom panel must
be aligned with the top end of the
installation template.
• Use a custom panel between 4 kg and
9 kg.
3. Mark 6 points guided on the installation
template.
B
C
B
C
4. Remove the installation template and
tighten the custom panel xers (B) at
the top with 2 screws (C, Ø4 X 16) as
shown.
DW9000M_DD68-00193B-02_EN.indd 20 2018-04-10  12:58:55
