Samsung DW80M3021 Series User manual

Dishwasher
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
DW80M3021 Series
DW80M3021_DD81-02549A-00_EN.indd 1DW80M3021_DD81-02549A-00_EN.indd 1 2017-08-02  2:42:352017-08-02  2:42:35

English - 2
contents
SETTING UP YOUR DISHWASHER
6
6Unpacking your dishwasher
6Checking parts
7Meeting installation requirements
USING YOUR DISHWASHER
8
8Control panel
10 Cycle selector
10 Basic guidelines for operation
12 Removing the plate support
13 Adjusting the height of the upper rack
14 Removing the upper rack
14 Loading the lower rack
15 Loading the upper rack
16 Using the cutlery rack
17 Using detergent
CLEANING AND MAINTAINING YOUR
DISHWASHER
19
19 Cleaning the exterior
19 Cleaning the interior
19 Cleaning the nozzles
20 Storing your dishwasher
CYCLES
21
21 Cycle chart
TROUBLESHOOTING
22
22 Check these points if your dishwasher…
25 Information codes
APPENDIX
26
26 Helping the environment
26 Specifications
DW80M3021_DD81-02549A-00_EN.indd 2DW80M3021_DD81-02549A-00_EN.indd 2 2017-08-02  2:42:402017-08-02  2:42:40

English - 3
safety information
Throughout this manual, you’ll see Warning and Caution notes. These
important safety instructions do not cover all possible situations that might occur.
It is your responsibility to use caution when installing, maintaining, and operating
your dishwasher. Samsung will not be liable for any damage resulting from
improper use.
IMPORTANT SAFETY INSTRUCTIONS
What the icons and signs in this user manual mean :
WARNING Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in personal injury or property
damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when using
your dishwasher, follow these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicity.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
When using the dishwasher, follow basic precautions, including the following:
Read all instructions before using the dishwasher.
As with any equipment using electricity, water, and moving parts, potential hazards exist.
Use the dishwasher only for its intended function.
Use only detergents or wetting agents recommended for use in a dishwasher, and keep
them out of the reach of children.
When loading items to be washed:
- Locate sharp items so that they are not likely to damage the door seal, and
- Load sharp knives with the handles up to reduce the risk of cut-type injuries.
Do not wash plastic items unless they are marked “dishwasher safe” or the equivalent.
For plastic items not so marked, check the manufacturer’s recommendations.
Do not touch the HEATING ELEMENT during or immediately after use.
WARNING
SAVE THESE INSTRUCTIONS
Safety information
DW80M3021_DD81-02549A-00_EN.indd 3DW80M3021_DD81-02549A-00_EN.indd 3 2017-08-02  2:42:402017-08-02  2:42:40

English - 4
WARNING : When using your dishwasher, follow basic precautions, including the following:
1. Read all instructions before using the dishwasher.
2. Use the dishwasher only for its intended function.
3. Use only detergents or wetting agents recommended for use in a dishwasher and keep them
out of the reach of children.
4. When loading items to be washed:
- locate sharp items so that they are not likely to damage the door seal, and
- load sharp knives with the handles up to reduce the risk of cut-type injuries.
5. Do not wash plastic items unless they are marked “dishwasher safe” or the equivalent. For
plastic items not so marked, check the manufacturer’s recommendations.
6. Do not touch the HEATING ELEMENT during or immediately after use.
7. Do not operate your dishwasher unless all ENCLOSURE panels are properly in place.
8. Do not tamper with controls.
9. Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
10. To reduce the risk of injury, do not allow children to play in or on a dishwasher.
11. Under certain conditions, hydrogen gas may be produced in a hot-water system that has
not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water
system has not been used for such a period, before using the dishwasher turn on all hot-
water faucets and let the water flow from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open flame
during this time.
12. Remove the door to the washing compartment when removing an old dishwasher from
service or discarding it.
State of California Proposition 65 Warning (US only)
WARNING: This product contains chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
• After unpacking the dishwasher, keep the packaging out of the reach of children.
• The dishwasher is extremely heavy. Do not attempt to move or carry the dishwasher by
yourself. Two or more people are needed to move a dishwasher and avoid potential injuries.
• As with any equipment using electricity, water, and moving parts, potential hazards exist.
• Do not install the dishwasher near electrical components. Keep the dishwasher away from
open flames.
• Install and level your dishwasher on an uncarpeted floor that can support its weight.
• Your dishwasher must be properly grounded. Never connect it to an ungrounded outlet. See
page 7for more information on grounding your dishwasher.
• Connect the ground wire to the green ground connector in the terminal box.
• After the dishwasher is installed, check that the drain hose is properly connected and
that there is no leakage from the hose connectors. If the drain hose is loose, it may cause
property damage.
• The water supply line is susceptible to breakage. As time goes by, it becomes less flexible.
Check the line periodically. If it is swollen, torn, cut, or there is a water leak, replace it
immediately.
• To safely operate this appliance, familiarize yourself with its operations and exercise care
when using it.
WARNING
WARNING
CAUTION
safety information
SAVE THESE INSTRUCTIONS
DW80M3021_DD81-02549A-00_EN.indd 4DW80M3021_DD81-02549A-00_EN.indd 4 2017-08-02  2:42:412017-08-02  2:42:41

English - 5
• Do not put gasoline, solvents, or other flammable materials inside the dishwasher. Do not
wash dishes exposed to these materials.
• Keep your dishwasher detergent out of the reach of children. Detergent has an adverse
effect on human organs. It contains elements for polishing and is corrosive. Avoid letting the
detergent come into contact with your skin and eyes.
• Do not push or place pressure on the door when it is open, as this may damage the
dishwasher or cause harm.
• Do not allow children to play in or on the dishwasher. They may harm themselves or damage
the dishwasher.
• Disconnect the power cable (or set the circuit breaker to off) before servicing your
dishwasher.
• Do not repair, replace, or service any part of your dishwasher yourself. Disassembly, repairs,
and modifications are permitted by authorized service technicians only. Work done by an
unauthorized person may void your warranty.
• Before disposing of your dishwasher, remove the door of the washing compartment or the
door latch so that children or small animals cannot get trapped inside.
• If the dishwasher is left unused for an extended period of time, turn off the water supply.
• This dishwasher is intended for residential use only.
BEFORE USING YOUR DISHWASHER
WARNING
Tip-Over Hazard
- Do not use the dishwasher until it is correctly installed.
- Do not push down on an open door.
- Do not place excessive weight on the open door.
Electric Shock Hazard
Failure to follow these instructions can result in death, fire, or electric shock:
- Electrically ground the dishwasher
- Connect the ground wire to the green ground connector in the junction box.
- Do not use an extension cord.
WARNING
SAVE THESE INSTRUCTIONS
Safety information
DW80M3021_DD81-02549A-00_EN.indd 5DW80M3021_DD81-02549A-00_EN.indd 5 2017-08-02  2:42:412017-08-02  2:42:41

English - 6
setting up your dishwasher
Be sure to have your installer follow these instructions closely so that your new
dishwasher works properly and that you’re not at risk of injury when washing
dishes.
UNPACKING YOUR DISHWASHER
• Once your new dishwasher has been delivered to you, carefully unpack it and check for any damage.
If the dishwasher has been damaged, make note of it on the waybill and keep a copy. Do not install the
dishwasher, and contact Samsung Customer Service at the number listed below.
• If there is no damage to the product, you can proceed with the installation. If you are going to install it
yourself, make sure to read through the installation guide and follow the directions inside.
• After unpacking your dishwasher, keep the packaging out of the reach of children to ensure their safety.
CHECKING PARTS
When your dishwasher has been unpacked, make sure you’ve received all the parts shown below.
If your dishwasher was damaged during shipping, or if you do not have all the parts, contact Samsung
Customer Service at 1-800-SAMSUNG (726-7864).
Air brake
Base
Door
Dispenser
Lower nozzle
Vapor vent cover
Control panel
Middle nozzle
Upper rack Lower rack Cutlery rack
Accessory parts - User/Installation manual, Installation Kit.
DW80M3021_DD81-02549A-00_EN.indd 6DW80M3021_DD81-02549A-00_EN.indd 6 2017-08-02  2:42:412017-08-02  2:42:41

English - 7
MEETING INSTALLATION REQUIREMENTS
Electrical supply and grounding
To prevent the risk of fire, electric shock, or personal injury, all wiring and grounding must be
done in accordance with the National Electrical Code ANSI/FNPA, No. 70 Latest Revision and
local codes and ordinances. It is the personal responsibility of the appliance owner to provide
adequate electrical service for this appliance.
Never use an extension cord.
When preparing for installation, ensure that your power supply provides:
• An individual branch circuit serving only your dishwasher with a 120 V~, 60 Hz,15 AMP fuse
or circuit breaker.
Your dishwasher must be grounded. If your dishwasher malfunctions or breaks down, grounding
will reduce the risk of electric shock by providing a path of least resistance for the electric
current.
Never connect the ground wire to plastic plumbing lines, gas lines, or hot water pipes.
GROUNDING INSTRUCTIONS
For a permanently connected appliance:
This appliance must be connected to a grounded metal, permanent wiring system, or an
equipment-grounding conductor must be run with the circuit conductors and then connected to
the equipment-grounding terminal or lead on the appliance.
Water supply
The hot water supply line pressure must be between 20 - 120 psi (140 - 830 kPa).
Adjust the water heater to deliver water between 120 °F (49 °C) - 149 °F (65 °C).
Most plumbing supply stores sell water supply lines of various lengths up to 10 feet
(305cm) long.
You can reduce the risk of leaks and water damage by:
• Making water faucets easily accessible.
• Turning off faucets when the dishwasher is not in use.
• Periodically checking for leaks at water supply line fittings.
Before using your dishwasher for the first time, check all connections at the water supply valve
and faucets for leaks.
Flooring
For safety, your dishwasher must be installed on a solidly constructed floor.
Never install your dishwasher on a platform or poorly supported structure.
Your dishwasher must be properly installed in accordance with the Installation Guide before you use it.
If you did not receive an Installation Guide with your dishwasher, you can obtain one by visiting our website
at www.samsung.com.
CAUTION
WARNING
WARNING
Setting up your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 7DW80M3021_DD81-02549A-00_EN.indd 7 2017-08-02  2:42:422017-08-02  2:42:42

English - 8
using your dishwasher
CONTROL PANEL
DW80M3021 Series
1 2 3 654 7
1POWER
When you press the POWER button, the Cycle On light for the most recently
started cycle turns on. When the selected cycle is complete, the dishwasher
powers off automatically.
2Cycle Selector Select the appropriate wash cycle depending on the soil level of your dishes.
After you select a cycle, the cycle on light for that cycle lights up.
3Hi-Temp Wash Raises the main wash temperature to improve cleaning for loads containing
tough, baked-on food.
4
Sanitize /
(Control Lock)
The temperature rises to 163 ˚F (73 ˚C) in the final rinse cycle for high
temperature sanitization.
If you select the Sanitize option, the “Sanitize” lamp blinks when the water
temperature reaches the sanitary temperature (over 155 ˚F (68 ˚C)), and
then remains illuminated until the Sanitize option ends. When you press the
POWER button, the “Sanitize” lamp turns off.
The Normal cycle with the Sanitize option selected is NSF certified.
The Sanitize feature operates in accordance with NSF/ANSI Standard
184for Residential Dishwashers. Certified residential dishwashers are
not intended for licensed food establishments. Your dishwasher is NSF
Certified.
Control Lock allows you to lock the buttons on the control panel so children
cannot accidently start the dishwasher by pressing the buttons on the panel.
To lock and unlock the buttons on the control panel, hold the Sanitize
button down for three (3) seconds when power is On.
5
Display
Displays cycle time and remaining hours and minutes, Delay Start hours, and
Information codes. If a problem occurs during operation, an information code
appears with a warning sound. Refer to the information codes page.
Control Lock indicator
- Turns on if the Control Lock is set (or the dishwasher is in the standby
or pause modes).
- Turns off while the dishwasher is operating.
- When Control Lock is on, the Control Lock indicator blinks for several
seconds if any button except the POWER button is pressed.
Rinse Refill indicator
- Turns on if the dishwasher runs out of rinse aid.
Delay Start indicator
- Turns on if you set Delay Start (including the time range).
- Turns off when the set time range of Delay Start has ended.
DW80M3021_DD81-02549A-00_EN.indd 8DW80M3021_DD81-02549A-00_EN.indd 8 2017-08-02  2:42:422017-08-02  2:42:42

English - 9
6
Delay Start
Delay a cycle for up to 24 hours in one-hour increments. To increase the delay
start time, press or hold the Delay Start button. The hour displayed indicates
the time at which the wash will start.
- After setting the delay time, press the START button, and then close the
door to start the cycle.
- If you want to change the delay time once the dishwasher has started,
press the Cancel button and turn off the dishwasher. Then, turn on the
dishwasher again and select a new cycle with a new delay setting.
7START
To start a cycle, press the START button before closing the door.
*Cancel: To cancel a currently running cycle and drain the dishwasher, press
and hold the START button for three (3) seconds.
Once the dishwasher is reset, select a cycle and option, and then press
START to restart the dishwasher.
You can select options (Hi-Temp Wash, Sanitize) before starting a cycle. If you change the cycle after
selecting an option, the original cycle is reset.
To prevent the touchpad from losing response sensitivity, follow these instructions:
- Touch the center of each keypad using one finger. Do not push.
- Clean the touch control’s surface regularly with a soft, damp cloth.
- Be careful not to touch more than one touch key pad at a time, except as directed.
When you pause a cycle by opening the door during operation, press the START button before closing
the door to continue the cycle.
Push door firmly closed within 3 seconds of pressing START button.
If the door is not closed within 3 seconds, the cycle will not start.
OO X
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 9DW80M3021_DD81-02549A-00_EN.indd 9 2017-08-02  2:42:432017-08-02  2:42:43

English - 10
CYCLE SELECTOR
DW80M3021 Series
1 2 3 4
1Auto This cycle detects the level of soil and automatically initiates the optimal cycle
after a few minutes of operation.
2Normal Use this cycle for normally soiled dinner dishes.
3Heavy Use this cycle for heavily soiled dishes and dishes with heavy soil.
4Express 60 Use this cycle for lightly soiled dishes.
BASIC GUIDELINES FOR OPERATION
1. Open the door and load your dishes (see page 14).
- Remove any food remains from the dishes before placing them in the rack(s).
- Place dishes into the upper and lower racks.
- After placing the dishes into the racks, rotate the nozzles by hand to check whether any of the
dishes will interfere with them.
- Make sure the dishes will not prevent the detergent dispenser from opening.
2. Add detergent to the dispenser (see page 17).
- Make sure to use only automatic dishwasher detergent.
- Refer to “Using detergent” on how to add detergent.
3. Press the POWER button.
- When you press the POWER button, the cycle light of the most recently started cycle lights up.
- If “Rinse Refill” ( ) is illuminated, you should refill the rinse aid dispenser to improve washing and
drying performance.
4. Select an appropriate cleaning cycle depending on the soil level of the dishes (see pages 10
and21).
- Press the appropriate cycle button.
- When you press a cycle button, the cycle indicator light is illuminated.
- For information about selecting a cycle according to the soil level of the dishes, see “Cycle
selector” on page 10.
5. Press the START button, and then close the door.
- After you close the door and press the START button or you press the START button and close the
door, the dishwasher starts the selected cycle after a few seconds.
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 10DW80M3021_DD81-02549A-00_EN.indd 10 2017-08-02  2:42:432017-08-02  2:42:43

English - 11
6. When the wash cycle is completed.
- The “0” light illuminates and the dishwasher sounds a chime.
- Power is automatically turned off after one minute.
If you want to load more dishes or pause the dishwasher while it is already running, make sure to open
the door slowly and carefully as there is a possibility of injury from the hot steam or water inside the
dishwasher. (If the door is opened while the dishwasher is running, a safety mechanism is activated
that stops the cycle.)
To resume operation, press the START button, and then close the door.
Note that adding dishes several minutes after the dishwasher started operating may aect the
performance.
You should use rinse aids for better drying performance. You can further improve drying performance
by also selecting the Sanitize option.
Delay start
When you select the Delay Start option, your dishwasher will begin the selected cycle when the
delay time expires.
Your dishwasher will operate the selected cycle when the delay time expires.
When using the dishwasher, try to arrange the dishes properly as described on page 14to15.
• You should remove food remains such as bones, fruit seeds, etc. and any other waste such
as toothpicks, paper, etc. from the dishes as these may cause damage to the dishes, create
noise, or cause the dishwasher to malfunction.
• Select the appropriate cycle depending on the level of soil and the type of dishes.
• Use only the proper amount of detergent and rinsing agent.
Do not wash the following items
• Acrylic or Aluminum items: Dishes with printed gold rim decoration may become
discolored.
• Dishes treated with adhesive: Treated plastics, wood, ivory, copper, and tin may come
loose.
• Plastics with a temperature tolerance less than 194 ˚F (90 ˚C): Thin plastics wash and dry
poorly, and may be damaged due to elevated wash temperatures.
• Tin: Tin should be washed by hand and dried immediately as it may rust.
• Wooden utensils: Wooden items may crack.
CAUTION
WARNING
WARNING
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 11DW80M3021_DD81-02549A-00_EN.indd 11 2017-08-02  2:42:432017-08-02  2:42:43

English - 12
REMOVING THE PLATE SUPPORT
You can adjust the angle of the tines in the upper rack to three different positions to match the size and
shape of your dishes. To adjust the tines, grasp the handle at the back of the rack and push it left or right.
See the illustration below.
In the lower rack, you can easily remove the plate support to make room for large items such as pots and
pans. To remove the plate support, lift up the handles (A). To refit the plate support, align it so it is in place,
and then push down on the handles (A). To fold down the fold-down tines on the lower rack, remove the
rack from the dishwasher, turn the rack over, grasp the tine (B), and then adjust it backward. See the
illustration below.
Upper rack
Lower rack
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 12DW80M3021_DD81-02549A-00_EN.indd 12 2017-08-02  2:42:432017-08-02  2:42:43

English - 13
ADJUSTING THE HEIGHT OF THE UPPER RACK
You can adjust the height of the upper rack in your Samsung dishwasher so that the lower rack can
accommodate larger sized dishes. Depending on where you set the upper rack height, the lower rack can
accommodate plates up to 14 in. (36 cm) in diameter and the upper rack can accommodated plates up to
12 in. (30 cm) in diameter.
DW80M3021 Series
To adjust the height of the upper rack, follow these steps:
1. Remove the upper rack following the directions in Removing the Upper Rack below.
2. If you want to lower the upper rack, re-install the rack as shown in Figure Ato the right.
3. If you want to raise the upper rack, re-install the rack as shown in Figure Bto the right.
We recommend adjusting the height of the upper rack before loading dishes into the rack. If you adjust
the the rack after loading the dishes, you may damage the dishes.
CAUTION
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 13DW80M3021_DD81-02549A-00_EN.indd 13 2017-08-02  2:42:442017-08-02  2:42:44

English - 14
REMOVING THE UPPER RACK
Pull the upper rack towards the front and then remove it by lifting it up slightly and pulling it towards the
front. See the illustrations below.
While the upper rack is removable, it must be installed for the dishwasher to operate properly.
If you attempt to operate the dishwasher without the rack, noise will occur and the dishwasher will
perform poorly.
Step 1. Step 2. Step 3.
LOADING THE LOWER RACK
Load cookware (pots, pans, etc.), up to 14 in. (36 cm) in diameter into the lower rack. The lower rack has
been especially designed for dinner dishes, soup bowls, plates, pots, lids, casserole dishes, and plates.
Load your plates into the center column of the rack so their open sides face towards the right. Load large
items such as pans and pots into the dishwasher so their open sides face downwards. We recommend
loading cups, stemware, and small plates into the upper rack.
See the recommended loading patterns below.
10 place setting 12 place setting
CAUTION
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 14DW80M3021_DD81-02549A-00_EN.indd 14 2017-08-02  2:42:442017-08-02  2:42:44

English - 15
LOADING THE UPPER RACK
The upper rack has been designed for small plates, mugs, glasses, and plastic items marked “dishwasher
safe”. Load your plates into the dishwasher so their open sides face each other.
Make sure the loaded dishes do not interfere with the rotation of the nozzle which is located at the bottom
of the upper rack. (Check this by rotating the nozzle by hand.)
When loading dishes, pull the upper rack out sufficiently so you can load it without striking the counter
above.
10 place setting 12 place setting
Using the glass support
You can load cups or glasses onto the glass support. This is also
very convenient for washing wine glasses. Hang your wine glasses
onto the pegs of the glass support.
You can fold the glass support back when it is not being used.
Loading the large items
You can load large items such as pans and pots into the lower rack.
Make sure pot handles and other items do not interfere with rotation of
the nozzles.
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 15DW80M3021_DD81-02549A-00_EN.indd 15 2017-08-02  2:42:442017-08-02  2:42:44

English - 16
USING THE CUTLERY RACK
The cutlery basket consists of two compartments.
You can place each knife, spoon, or fork separately into the spoon stands in the basket’s covers to prevent
chipping and discoloration.
DO NOT let any item extend through the bottom.
1Small forks
2Spoons
3Knives
4Large spoons and forks
5Medium-sized forks
6Remaining items
The spoon stands as seen from above with the suggested placement of cutlery items. Match the numbers
in the diagram to the numbers in the list of cutlery items above.
You can use the cutlery basket with the cover open. Refer to the
illustration to the right.
using your dishwasher
1 532 4
DW80M3021_DD81-02549A-00_EN.indd 16DW80M3021_DD81-02549A-00_EN.indd 16 2017-08-02  2:42:452017-08-02  2:42:45

English - 17
USING DETERGENT
All dishwasher cycles require detergent in the detergent compartment.
Add the correct amount of detergent for the selected cycle to ensure the best performance.
Use dishwasher detergent only. Regular detergent produces too much foam, which may decrease the
dishwasher’s performance or cause it to malfunction.
Do not swallow dishwasher detergent. Avoid breathing in the fumes. Dishwasher detergent contains
irritants and caustic chemicals that can induce respiratory conditions. If you have swallowed
dishwasher detergent or inhaled the fumes, seek medical attention immediately.
Keep dishwasher detergent out of the reach of children.
Filling the detergent dispenser
1. Open the detergent dispenser flap by pushing the detergent
dispenser release catch.
The flap is always open at the end of a dishwashing cycle.
2. Add the recommended amount of detergent to the main
wash detergent compartment.
3. Close the flap by sliding it to the left and then pressing it
down.
4. For better cleaning result, especially if you have very dirt
items, pour a small amount (about 1/2 of an ounce or 15g) of
detergent onto the door.
The additional detergent will activate during the pre-wash
phase.
CAUTION
WARNING
WARNING
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 17DW80M3021_DD81-02549A-00_EN.indd 17 2017-08-02  2:42:452017-08-02  2:42:45

English - 18
The cover opens automatically to dispense the detergent during the wash.
Cycle
Amount of detergent
Main wash dispenser Onto the door for pre-wash
Auto, Normal 3/4 oz (20 g) 1/3 oz (10 g)
Heavy, Express 60 1 oz (30 g) 1/2 oz (15 g)
The numbers inside the dispenser refer to grams.
Filling the rinse aid reservoir
When the Rinse Refill indicator lights up on the control panel, refill the reservoir with rinse aid.
Your dishwasher has been designed to use liquid rinse aid only.
Using a powdered rinse aid will clog the reservoir opening and cause the dishwasher to
malfunction.
Rinse aid improves the drying performance of the dishwasher.
Do not add regular detergent to the rinse aid reservoir.
1. Remove the rinse aid reservoir cap by rotating it
counterclockwise.
2. Fill the rinse aid reservoir with rinse aid.
Use the viewing port when filling the rinse aid reservoir.
Do not fill the reservoir above the full level indicator.
Excess rinse aid can overflow during the wash cycle.
3. Turn the rinse aid indicator dial to a number between 1 and
6. The higher the number, the more rinse aid the dishwasher
uses. If you are unable to rotate the rinse aid dial easily, try
using a coin.
4. Close the rinse aid reservoir cap by rotating it clockwise.
CAUTION
CAUTION
using your dishwasher
DW80M3021_DD81-02549A-00_EN.indd 18DW80M3021_DD81-02549A-00_EN.indd 18 2017-08-02  2:42:462017-08-02  2:42:46

English - 19
cleaning and maintaining your
dishwasher
Keeping your dishwasher clean improves its performance, reduces unnecessary
repairs, and lengthens its life.
CLEANING THE EXTERIOR
It’s best to clean spills on the outside of your dishwasher as they occur. Use a soft, damp cloth on the
control panel to gently wipe away spills and dust. Do not use benzene, wax, thinner, chlorine bleach, or
alcohol. These materials may discolor the inner walls and cause stains. Do not clean the dishwasher by
sprinkling water over it and avoid letting water come into contact with any of the electrical parts.
If your dishwasher has a stainless steel door panel, you can clean it with a stainless steel cleaner for
home appliances or a similar product using a clean, soft cloth.
CLEANING THE INTERIOR
Clean the interior of your dishwasher periodically to remove any dirt or food particles. Wipe the inside of
the dishwasher and the inner part of the door with a wet dishcloth. We recommend filling the detergent
dispenser with dish detergent, and then running the dishwasher empty periodically using the Normal cycle
with the sanitize option. This will keep your dishwasher clean.
If white spots and odor are still present in your dishwasher, run the Normal cycle with the dishwasher
empty and without detergent until it flushes. Then, interrupt the cycle and put an 8 ounce cup of white
vinegar into the lower basket. Close the dishwasher and let the cycle finish.
Do not remove the tub front seal (the long rubber seal enclosing the opening of the dishwasher).
CLEANING THE NOZZLES
If your dishwasher does not seem to be cleaning adequately or the nozzles seem clogged, you can clean
each of the nozzles. When removing the nozzles, take care as they may break.
Lower nozzle
1. Check whether the nozzle holes are
clogged by food particles.
2. If cleaning is needed, remove the nozzle by
pulling it upwards.
3. Clean the nozzle, and then push it back
into place.
4. Check whether the nozzle is engaged
correctly by rotating it by hand.
CAUTION
Cleaning and maintaining
DW80M3021_DD81-02549A-00_EN.indd 19DW80M3021_DD81-02549A-00_EN.indd 19 2017-08-02  2:42:462017-08-02  2:42:46

English - 20
Middle nozzle
1. Pull the upper rack towards the front and
remove it.
2. Check whether the nozzle holes are
clogged by food particles.
3. If cleaning is needed, remove the nozzle.
4. To remove the nozzle, unfasten and
remove the nut, and then remove the
nozzle.
5. Clean the nozzle, re-insert it, and then
fasten the nut.
6. When fastening the nut, turn it firmly by
hand.
7. Check whether the nozzle is engaged
correctly by rotating it by hand.
Upper nozzle
1. Check whether the nozzle holes are
clogged by food particles.
2. If cleaning is needed, remove the nozzle.
3. To remove the nozzle, pull out the upper
rack first, unfasten the nozzle cap by
turning it counterclockwise, and then
remove the upper nozzle.
4. Clean the nozzle, re-insert it, and then
fasten the nozzle cap to the nozzle by
turning the cap clockwise.
5. Check whether the nozzle is engaged
correctly by rotating it by hand.
STORING YOUR DISHWASHER
If you need to store your dishwasher for an extended period of time, first drain and disconnect it. If you
leave water in the hoses and internal components, you can damage the dishwasher.
After draining and disconnecting the dishwasher, be sure to turn off the water supply valve and circuit
breaker.
cleaning and maintaining your
dishwasher
1
2
Cap nozzle
DW80M3021_DD81-02549A-00_EN.indd 20DW80M3021_DD81-02549A-00_EN.indd 20 2017-08-02  2:42:462017-08-02  2:42:46
