Samsung DW80BB70 Series User manual

Dishwasher
Installation manual
DW80BB70* Series, DW80B70* Series, DW80B60* Series
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 1DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 1 2023-02-03  10:55:572023-02-03  10:55:57

Contents
English2
Contents
Safety instructions 3
Important safety instructions 3
Before using your dishwasher 5
Installation 6
Product dimensions 11
Cabinet dimensions 12
Specications 38
Scan the QR code* to view our
helpful installation videos.
* Requires reader to be installed on your
smartphone.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 2DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 2 2023-02-03  10:56:002023-02-03  10:56:00

Safety instructions
English 3
SAVE THESE INSTRUCTIONS
Safety instructions
Throughout this manual, you will see Warning and Caution notes. The warnings, cautions,
and the important safety instructions that follow do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution, and care
when installing, maintaining, and operating the dishwasher. Samsung is not liable for
damages resulting from improper use.
Important safety instructions
What the icons and signs in this installation guide mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in personal injury or property damage.
CAUTION
To reduce the risk of re, explosion, electric shock, or personal injury when using the
dishwasher, follow these basic safety precautions:
NOTE
Indicates that a risk of personal injury or material damage exists.
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
STOP
These installation instructions are intended for use by qualied installers.
If you are having problems installing this dishwasher
U.S.A
Please call: 1-800-SAMSUNG (726-7864)
1-844-SAM-PAYS (726-7297)
for assistance: www.samsung.com/us/support
CANADA
Please call: 1-800-SAMSUNG (726-7864)
for assistance: www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 3DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 3 2023-02-03  10:56:002023-02-03  10:56:00

Safety instructions
Safety instructions
English4
SAVE THESE INSTRUCTIONS
California Proposition 65 Warning
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Read all instructions before using the appliance.
Install and store the dishwasher inside, away from exposure to weather.
CAUTION
• Do not install the dishwasher near electrical components. Keep the dishwasher away
from open ames.
• Do not install the dishwasher on a carpet as this is a re hazard.
• Do not install the dishwasher in a location where the water may freeze (where the
temperature falls below 32 °F (0 °C)). Frozen water in the hoses or pipes may damage
the dishwasher.
• As with all equipment using electricity, water, and moving parts, potential hazards
exist. To safely operate this appliance, become familiar with its operation and exercise
care when using it.
The dishwasher must be properly grounded. Never connect it to an ungrounded outlet.
Prior to removal of original dishwasher and the installation of your new unit, make
sure to switch off your circuit breaker. Do not connect the dishwasher until you have
completed the installation. Connecting the power cable is the last step when installing the
dishwasher.
All wiring and grounding must be done in accordance with the electrical code applicable
to the region.
GROUNDING INSTRUCTIONS
For a permanently connected appliance:
This appliance must be connected to grounded metal, a permanent wiring system, or an
equipment-grounding conductor must be run with the circuit conductors and connected to
the equipment-grounding terminal or lead on the appliance.
The dishwasher is very heavy. Do not attempt to move or carry a dishwasher alone. Two
or more people are needed to move a dishwasher and avoid potential injuries.
CAUTION
• If the power cable is damaged, it must be replaced by the manufacturer, a service
agent or similarly qualied person in order to avoid a hazard.
• Do not touch the power cable with wet hands.
• Do not connect another appliance to the same power outlet as the dishwasher.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 4DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 4 2023-02-03  10:56:002023-02-03  10:56:00

Safety instructions
English 5
SAVE THESE INSTRUCTIONS
Make sure to use a new water supply line. Old lines are susceptible to breakage because
they become hardened and may cause property damage due to a water leakage.
The dishwasher must be connected to a hot water supply with a temperature between
120 °F (49 °C)~149 °F (65 °C). This temperature range provides the best washing result
and shortest cycle time. Temperature should not exceed 149 °F (65 °C) to prevent damage
to dishes.
Ensure that the water supplied to the dishwasher does not freeze. Frozen water can
damage the hoses, valves, pump, or other components.
Certied residential dishwashers are not intended for licensed food establishments.
(NSF/ANSI Standard 184 for Residential Dishwashers)
For a full list of safety information, please refer to the User Manual.
Before using your dishwasher
WARNING
Tip-Over Hazard
• Do not use the dishwasher until it is correctly installed.
• Do not push down on the dishwasher door when it is open.
• Do not place excessive weight on the dishwasher door when it is open.
Electric Shock Hazard
Failure to follow these instructions can result in death, re, or electric
shock:
• Electrically ground the dishwasher.
• Connect the ground wire to the green ground connector in the junction
box.
• Do not use an extension cord.
To reduce the risk of electric shock, re, or injury to persons, the installer
must ensure that the dishwasher is completely enclosed at the time of
installation.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 5DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 5 2023-02-03  10:56:002023-02-03  10:56:00

Installation
English6
Installation
Be sure that you or your installer follow these instructions closely so that the new
dishwasher works properly and that you are not at risk of injury when washing dishes.
STEP 1 Check the parts and tools
Before starting on the installation, prepare all the necessary tools and parts required to
install the dishwasher. This will save installation time and simplify the installation process.
Parts required
Provided with the dishwasher. Check when you unbox the dishwasher in STEP 5.
2 Installation brackets Kick Plate 4 screws
(for the Bracket Installation)
Protective sticker Nut connector & seal
(for
3
/ 4 " 90° tting)
6 plastic caps
2 black color screws
(for the Kick plate)
2 screws
(for the bespoke door)
2 plastic caps
(for the bespoke door)
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 6DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 6 2023-02-03  10:56:012023-02-03  10:56:01

English 7
Installation
Not provided
Power cable Twist on wire
connector
Strain relief Electrical tape &
Standard duct tape
Hot water supply
line
90° Fitting (
3
/ 4 ") Tube ttings Air gap
Rubber connector Hose clamp
NOTE
For the hot water supply line – We strongly recommend using
3
/ 8 " minimum O.D. copper
tubing with a compression tting or a exible stainless steel braided hot water supply
line.
[Warning: Do not use plastic tubing. Plastic tubing can deteriorate over time and cause a
leak inside the tube tting.]
You also need a 90° Fitting with
3
/ 4 " N.P.T. external pipe threads on one end and a tting
sized to t your hot water supply line (copper tubing/compression tting or braided hose)
on the other.
For the power cable, we recommend a jacketed 12-2 cable with ground. Note that some
local codes may require the cable to have a BX style metal jacket.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 7DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 7 2023-02-03  10:56:012023-02-03  10:56:01

Installation
Installation
English8
Tools required
Electric drill Safety glasses Gloves Flashlight
Adjustable wrench Wire stripper Pliers Nipper
Tape measure Pencil Phillips screwdriver Flat screwdriver
Tubing cutter Cutting knife Hole saw Level
Torx t20 Hex L-wrench Suction cup
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 8DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 8 2023-02-03  10:56:022023-02-03  10:56:02

English 9
Installation
NOTE
New installation
If the dishwasher is a new installation, most of the installation work must be done before
the dishwasher is moved into place.
Replacement
If the dishwasher is replacing an old dishwasher, you must check the exising dishwasher
connections for compatibility with the new dishwasher. Replace the existing connections
as necessary.
STEP 2 Select the best location for the dishwasher
The following criteria are important to ensure the best location for the dishwasher:
• The location must have a solid oor that is able to support the weight of the
dishwasher.
• The location must be near a sink with easy access to the water supply, drain, and
electrical outlet.
NOTE
For the drain to operate properly, the dishwasher should be installed within 9.8 ft (3 m)
of the sink.
• The location must let you load your dishes into the dishwasher easily.
• The location must have sufcient space for the dishwasher door to open easily and
provide enough space between the dishwasher and the cabinet sides (at least 0.1 in
(2 mm)).
NOTE
If the dishwasher is installed in a corner, ensure that the side of the dishwasher is more
than 2 in. (50 mm) from the wall or cabinet to its right or left.
• The wall at the back must be free of obstructions.
• Make sure the cabinet for the dishwasher is secured to the oor. If the cabinet is not
secured, it may increase noise when the dishwasher is operating.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 9DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 9 2023-02-03  10:56:032023-02-03  10:56:03

Installation
Installation
English10
If this is a new installation, follow these steps:
1. Using a 2
1
/ 2 inch hole saw, cut a hole into the side of the cabinet that holds the sink as
shown in Figure 1-1 below.
2. If the base inside the sink cabinet is raised above the kitchen oor and is higher than the
connections on the dishwasher, make a hole in the base inside the cabinet and in the cabinet
side as shown in Figure 1-2.
NOTE
Depending on where your electrical outlet is, you may need to cut a hole in the opposite
cabinet side.
Figure 1-1
The hole for the water supply line, drain
The hole for the water supply line, drain
hose and power cables.
hose and power cables.
Figure 1-2
CAUTION
Make sure the edges of the cabinet hole are smooth before you insert the drain hose
through the hole. Sharp edges from the cabinet hole may cause damage to the drain hose,
resulting in a leak from the hose.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 10DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 10 2023-02-03  10:56:032023-02-03  10:56:03

English 11
Installation
Product dimensions
Front view
Front view
DW80BB7070**, DW80B7070**, DW80B6060**
DW80BB7070**, DW80B7070**, DW80B6060**
DW80B7071**, DW80B6061**
DW80B7071**, DW80B6061**
Junction box
Junction box
Junction box
Junction box
23
23
7
7
/
/
8
8
" (605 mm)
" (605 mm)
23
23
7
7
/
/
8
8
" (605 mm)
" (605 mm)
33⅞-35" (860-890 mm)
33⅞-35" (860-890 mm)
33⅞-35" (860-890 mm)
33⅞-35" (860-890 mm)
DW80BB7070**, DW80B7070**
DW80BB7070**, DW80B7070**
DW80B7071**
DW80B7071**
Side view
Side view
27
27
5
5
/
/
16
16
" (693 mm)
" (693 mm)
20
20
1
1
/
/
2
2
" (520 mm)
" (520 mm)
2
2
3
3
/
/
4
4
" (70 mm)
" (70 mm)
2
2
1
1
/
/
2
2
" (60 mm)
" (60 mm)
2
2
1
1
/
/
2
2
" (60 mm)
" (60 mm)
5
5
3
3
/
/
4
4
" (140 mm)
" (140 mm)
20
20
1
1
/
/
2
2
" (520 mm)
" (520 mm)
25" (636 mm)
25" (636 mm)
25" (636 mm)
25" (636 mm)
4
4
1
1
/
/
5
5
" (107 mm)
" (107 mm)
You must arrange the
You must arrange the
water supply line,
water supply line,
power cable and drain
power cable and drain
hose in the space
hose in the space
behind the dishwasher.
behind the dishwasher.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 11DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 11 2023-02-03  10:56:042023-02-03  10:56:04

Installation
Installation
English12
Cabinet dimensions
24" (610 mm) minimum
24" (610 mm) minimum
34⅛-35⅓" (867-897 mm)
34⅛-35⅓" (867-897 mm)
24" (610 mm)
24" (610 mm)
minimum
minimum
NOTE
This dishwasher is designed to be enclosed
on the top and on both sides by a standard
residential kitchen cabinet unit.
The installation cabinet must be clean and
free of any obstructions.
The cabinet must be at least 24 inches wide,
24 inches deep, and 341/8inches high.
For the front door of the dishwasher to be
ush with the leading edge of the counter
top, the counter top must be at least
25 inches deep.
DW80B6060**
DW80B6060**
DW80B6061**
DW80B6061**
Side view
Side view
27
27
5
5
/
/
16
16
" (693 mm)
" (693 mm)
20
20
1
1
/
/
2
2
" (520 mm)
" (520 mm)
2
2
3
3
/
/
4
4
" (70 mm)
" (70 mm)
2
2
1
1
/
/
2
2
" (60 mm)
" (60 mm)
2
2
1
1
/
/
2
2
" (60 mm)
" (60 mm)
5
5
3
3
/
/
4
4
" (140 mm)
" (140 mm)
20
20
1
1
/
/
2
2
" (520 mm)
" (520 mm)
25" (636 mm)
25" (636 mm)
25" (636 mm)
25" (636 mm)
4
4
1
1
/
/
5
5
" (107 mm)
" (107 mm)
You must arrange the
You must arrange the
water supply line,
water supply line,
power cable and drain
power cable and drain
hose in the space
hose in the space
behind the dishwasher.
behind the dishwasher.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 12DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 12 2023-02-03  10:56:042023-02-03  10:56:04

English 13
Installation
STEP 3 Check water supply requirements and cautions
• The hot water supply line pressure must be between 20~120 psi (140~830 kPa).
• Adjust the water heater to deliver water between 120 °F (49 °C)~149 °F (65 °C).
- The dishwasher must be connected to a hot water supply between 120 °F
(49 °C)~149 °F (65 °C). This temperature range provides the best washing result
and shortest cycle time. Temperature should not exceed 149 °F (65 °C) to prevent
damage to dishes.
- Ensure that the water supply valve is turned off before connecting the hot water
supply line to the dishwasher.
- Seal the hot water supply line connections using teon tape or sealing compound to
stop any water leakage.
- The drain hose connected to the dishwasher must be run through the hole in the
side wall so it can be connected to the drain outlet of the sink. When you install the
dishwasher, ensure there is nothing on the drain hose and be careful not to damage
it during the installation process.
Figure 2
Dishwasher bottom
Dishwasher bottom
Hot Water
Hot Water
Supply Line
Supply Line
4¼-6¼ in.
4¼-6¼ in.
(110-160 mm)
(110-160 mm)
Power cable
Power cable
Inlet valve
Inlet valve
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 13DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 13 2023-02-03  10:56:042023-02-03  10:56:04

Installation
Installation
English14
STEP 4 Check the electrical requirements and cautions
The electrical requirements for the dishwasher are as follows:
• In the United States, install in accordance with the National Electric Code/State and
Municipal codes and/or local codes.
• In Canada, install in accordance with the Canadian Electric Code C22.1-latest edition/
Provincial and Municipal codes and/or local codes.
• For cable direct connections.
- Use exible, armored or non-metallic sheathed, copper wire with a grounding wire
that meets the wiring requirements for your local codes and ordinances.
- Use the strain relief method provided with the wiring junction box or install a U.L.-
listed/CSA-certied clamp connector to the wiring junction box. If using conduit, use
a U.L.-listed/CSA-certied conduit connector.
Figure 3
Dishwasher bottom
Dishwasher bottom
Hot Water
Hot Water
Supply Line
Supply Line
Power cable
Power cable
2
2
1
1
/
/
2
2
-3
-3
1
1
/
/
2
2
in.
in.
(64-89 mm)
(64-89 mm)
Power cable channel
Power cable channel
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 14DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 14 2023-02-03  10:56:042023-02-03  10:56:04

English 15
Installation
STEP 5 Unpacking and inspecting the dishwasher
Unpack the dishwasher in an open area free of obstruction both around the packaging
and overhead. We recommend that you retain all of the packing materials until the
dishwasher is fully installed and operational to ensure you have removed all the product’s
components from the packing materials prior to disposal.
Unpacking
1. Position the carton right-side-up with
top arrows pointing upwards.
2. Unbuckle or cut the straps securing the
packaging.
3. Unpack the product packaging with
care.
4. Put the straps and all of the packing
materials from around the dishwasher
inspecting them for any signs of
damage.
5. Locate and set aside the dishwasher's
kick plate. The Kick plate is attached to
packing material of the dishwasher.
Kick plate
Kick plate
6. Lift the dishwasher from the packing tray, and then place it on the oor.
CAUTION
• ALWAYS LIFT THE DISHWASHER TO MOVE IT. Sliding it over rough surfaces can
damage the dishwasher’s feet and sliding the feet over nished surfaces can, in some
cases, damage that nish or the underlying surface.
7. There is also packing inside the dishwasher that you may want to leave in place until
the dishwasher is installed.
8. DO NOT, under any circumstances, remove the sound-absorbent padding that
surrounds the exterior of the tub of the dishwasher.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 15DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 15 2023-02-03  10:56:042023-02-03  10:56:04

Installation
Installation
English16
Inspecting
Mechanical
1. Check the plastic base assembly to ensure that it is intact
2. Check the dishwasher’s feet to ensure they are in place and can be adjusted so you can
level and secure the dishwasher.
3. Check all the visible components on the bottom of the dishwasher to ensure they are
intact and secure.
4. Check the door latch, the operation of the hinges, and conrm the door is properly
secured to the dishwasher.
Plumbing
1. Check the hot water connection on the back left-side of the base of the dishwasher.
The mounting plate should be secured to the back of the base, the threads inside the
connection should be smooth and shiny, and the area should be clean and free of any
debris.
2. Make sure the dishwasher and the accessories are all included in the package to ensure
these assemblies are not cracked and that all connections are secure.
3. Check the drain hose for any holes or deformities that could allow a water leak during
draining.
Electrical
1. Conrm the junction box cover is secured to the junction box on the front right-side of
the base of the dishwasher.
2. Conrm the electrical box was not damaged during shipping and that it is secured to
the base of the dishwasher.
Appearance
1. Conrm there are no dents or scratches on the front of the dishwasher.
2. Check the edges of the doors for any roughness or cracking.
3. Check the control panel to ensure it is clear and unscratched, and that all the control
markers are in their proper places.
Parts
Conrm you have all the parts listed in STEP 1 on page 6.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 16DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 16 2023-02-03  10:56:042023-02-03  10:56:04

English 17
Installation
STEP 6 Mounting the Bespoke panel (applicable models only)
1. Open the door and t the Bespoke
panel in the front bottom of the door.
Make sure that the ribs of the panel t
into the corresponding holes (totaling 6)
of the door.
2. While holding the door and the
Bespoke panel with both hands, press
the panel evenly from bottom to top to
lock into the dishwasher.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 17DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 17 2023-02-03  10:56:042023-02-03  10:56:04

Installation
Installation
English18
3. When both sides of the panel lock
into place, press the top center of the
Bespoke panel to secure it to the top of
the door.
NOTE
• Make sure that the Bespoke panel ts in
the dishwasher properly.
• If the gap between the dishwasher
and the Bespoke panel is below 2 mm,
proper installation is done. For 2 mm or
more, remove the Bespoke panel and
try again.
4. Unpack the caps and screws (two for
each) included in the product package.
5. Tighten the screws on either side of the
dishwasher.
NOTE
When tightening the screw on either side,
make sure to check the gap between either
side as the Bespoke door may lean in
either side.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 18DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 18 2023-02-03  10:56:052023-02-03  10:56:05

English 19
Installation
NOTE
After inserting the panel, check it with
bare eyes.
If the panel is not correctly inserted, or
the gaps are not even in all four corners,
reinstall the panel.
Reinstallation
Remove the screws on both sides of the
door. Then, put the suction cups on the
panel, one in the top left area of the panel
and the other in the top right. Pull up the
handles of the suction cups to remove the
panel, then install the panel again.
CAUTION
• Using the cups in the center area may
bend the panel. Make sure to put the
suction cups in the top left and top right
areas of the panel. Then, pull up the
handle just once for each.
• Make sure the door is secured and
stable before using the suction cups.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 19DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 19 2023-02-03  10:56:052023-02-03  10:56:05

Installation
Installation
English20
6. Insert the caps on either side. Make
sure the rib of the cap ts in the hole of
the dishwasher in the right direction.
7. This is the completion of mounting the
Bespoke panel.
CAUTION
Any third-party panel other than Samsung’s Bespoke panel (available in Samsung
authorized retailers) is not allowed for attachment. The customer is responsible for any
problem resulting from such a third-party panel.
DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 20DW7000B_DW80B7070_AA_DD68-00242A-02_EN.indd 20 2023-02-03  10:56:052023-02-03  10:56:05
