Samsung DV8 Series User manual

Condensing Dryer
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
DV8 Series
DC68-03408G-05
DV4000H_DC68-03408G-05_EN.indd 1DV4000H_DC68-03408G-05_EN.indd 1 2017-07-20  5:34:182017-07-20  5:34:18

English - 2
contents
INSTALLING YOUR DRYER
11
11 Unpacking your dryer and Installing guide
11 See dryer exterior
12 Check before installing
12 Before using the product
12 Important to installer
12 Location considerations
13 Alcove or closet installation
13 Electrical requirements
13 Grounding
14 Installation side by side
14 Final installation checklist
15 Draining water without using the water tank
15 Connecting the drain hose
17 Installation stacking
18 Door Reversal
OPERATING INSTRUCTIONS, TIPS
20
20 Overview of the control panel
23 Child lock
23 Sound on/off
24 Delay end
24 Interior lamp (on some models)
25 Smart check
26 Rack dry (on some models)
27 Load the dryer properly
27 Getting started
CARE AND CLEANING
28
28 Clean the filter case
28 Clean the condenser
28 Control panel
28 Tumbler
28 Stainless steel tumbler
28 Dryer exterior
29 Dumping condensed water ( )
29 Cleaning the filter case ( )
30 Cleaning the condenser assembly
SAFETY INFORMATION
4
4What you need to know about Safety
Instructions
4Important safety symbols and precautions
DV4000H_DC68-03408G-05_EN.indd Sec9:2DV4000H_DC68-03408G-05_EN.indd Sec9:2 2017-07-20  5:34:212017-07-20  5:34:21

English - 3
SPECIAL LAUNDRY TIPS
31
31 Special laundry tips
TROUBLESHOOTING
32
32 Check these points if your dryer…
34 Information codes
APPENDIX
35
35 Fabric care chart
36 Protecting the environment
36 Specifications
37 Cycle chart
37 Consumption data
DV4000H_DC68-03408G-05_EN.indd Sec9:3DV4000H_DC68-03408G-05_EN.indd Sec9:3 2017-07-20  5:34:212017-07-20  5:34:21

English - 4
safety information
Congratulations on your new Samsung Dryer. This manual contains important
information on the installation, use, and care of your appliance. Please take the
time to read this manual to take full advantage of your dryer’s many benefits and
features.
WARNING - Risk of Fire
• Clothes dryer installation must be performed by a qualified technician.
• Install the clothes dryer according to the manufacturer’s instructions and local codes.
• To reduce the risk of severe injury or death, follow all installation instructions.
WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution, and care when installing,
maintaining, or operating your dryer.
Always contact your manufacturer about problems or conditions you do not understand.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
WARNING
Hazards or unsafe practices that may result in severe personal injury or
death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when
using your dryer, follow these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicity.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Note
Read the instructions
These warning icons are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
Read all instructions before using the appliance.
DV4000H_DC68-03408G-05_EN.indd Sec1:4DV4000H_DC68-03408G-05_EN.indd Sec1:4 2017-07-20  5:34:212017-07-20  5:34:21

English - 5
To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow
basic precautions, including the following:
1. This appliance is not to be used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
2. For use in Europe: This appliance can be used by children aged from
8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.Children shall not play
with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
3. Children should be supervised to ensure that they do not play with the
appliance.
4. If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
5. The new hose-sets supplied with the appliance are to be used and that
old hose-sets should not be reused.
6. For appliances with ventilation openings in the base, that a carpet must
not obstruct the openings.
7. For use in Europe: Children of less than 3 years should be kept away
unless continuously supervised.
8. CAUTION: In order to avoid a hazard due to inadvertent resetting of
the thermal cut-out, this appliance must not be supplied through an
external switching device, such as a timer, or connected to a circuit that
is regularly switched on and off by the utility.
9. The tumble dryer is not to be used if industrial chemicals have been
used for cleaning.
10. The lint trap has to be cleaned frequently, if applicable.
11. Lint must not to be allowed to accumulate around the tumble dryer. (not
applicable for appliances intended to be vented to the exterior of the
building)
WARNING
SAFETY INFORMATION
DV4000H_DC68-03408G-05_EN.indd Sec1:5DV4000H_DC68-03408G-05_EN.indd Sec1:5 2017-07-20  5:34:212017-07-20  5:34:21

English - 6
12. Adequate ventilation has to be provided to avoid the back flow of gases
into the room from appliances burning other fuels, including open fires.
13. Do not dry unwashed items in the tumble dryer.
14. Items that have been soiled with substances such as cooking oil,
acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes
and wax removers should be washed in hot water with an extra amount
of detergent before being dried in the tumble dryer.
15. Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows fitted with foam
rubber pads should not be dried in the tumble dryer.
16. Fabric softeners, or similar products, should be used as specified by the
fabric softener instructions.
17. The final part of a tumble dryer cycle occurs without heat (cool down
cycle) to ensure that the items are left at a temperature that ensures that
the items will not be damaged.
18. Remove all objects from pockets such as lighters and matches.
19. WARNING: Never stop a tumble dryer before the end of the drying
cycle unless all items are quickly removed and spread out so that the
heat is dissipated.
20. Exhaust air must not be discharged into a flue which is used for
exhausting fumes from appliances burning gas or other fuels.
21. The appliance must not be installed behind a lockable door, a sliding
door or a door with a hinge on the opposite side to that of the tumble
dryer, in such a way that a full opening of the tumble dryer door is
restricted.
22. Heat pump model only : The instructions shall also include the
substance of the following:
WARNING: In the appliance enclosure or in the built-in structure, keep
ventilation openings clear of obstruction.
WARNING: Do not damage the refrigerant circuit.
safety information
DV4000H_DC68-03408G-05_EN.indd Sec1:6DV4000H_DC68-03408G-05_EN.indd Sec1:6 2017-07-20  5:34:212017-07-20  5:34:21

English - 7
SEVERE WARNING SIGNS FOR INSTALLATION
The installation of this appliance must be performed by a qualified technician or service
company.
- Failure to do so may result in electric shock, fire, an explosion, problems with the product, or
injury.
Plug the power cord into an AC 220-240 V 50 Hz wall socket or higher and use the socket for
this appliance only. In addition, do not use an extension cord.
- Sharing a wall socket with other appliances using a power strip or extending the power cord
may result in electric shock or fire.
- Ensure that the power voltage, frequency and current are the same as those of the product
specifications. Failure to do so may result in electric shock or fire. Plug the power plug into
the wall socket firmly.
Remove all foreign substances such as dust or water from the power plug terminals and contact
points using a dry cloth on a regular basis.
- Unplug the power plug and clean it with a dry cloth.
- Failure to do so may result in electric shock or fire.
Keep all packaging materials well out of the reach of children, as packaging materials can be
dangerous to children.
- If a child places a bag over its head, it may result in suffocation.
This appliance must be properly grounded.
Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
- This may result in electric shock, fire, an explosion, or problems with the product
- Never plug the power cord into a socket that is not grounded correctly and make sure that it
is in accordance with local and national codes.
Do not install or keep the product exposed to the outdoor elements.
Do not use a damaged power plug, damaged power cord or loose wall socket.
- This may result in electric shock or fire.
If the plug (power supply cord) is damaged, it must be replaced by the manufacturer or its
service agent or a similar qualified technician in order to avoid a hazard.
This appliance should be positioned to be accessible to the power plug after installation.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the power cord, insert
the power cord between objects, or push the power cord into the space behind the appliance.
- This may result in electric shock or fire.
Do not pull the power cord, when unplugging the power plug.
- Unplug the power plug by holding the plug.
- Failure to do so may result in electric shock or fire.
This appliance must be properly grounded. Never plug the power cord into a receptacle that
is not grounded adequately and in accordance with local and national codes. See installation
instructions for grounding this appliance.
Install this appliance in a location with solid, level floor.
- Failure to do so may result in abnormal vibrations, noise or problems with the product.
Since an ingredient in hair spray may degrade the hydrophile property of the heat exchanger
so that dew may appear on the outer surface of the appliance when the cooling operation is
running, do not install the appliance in a beauty salon.
This appliance should be positioned so that the power plug, the water supply taps, and the drain
pipes ar e accessible.
WARNING
SAFETY INFORMATION
DV4000H_DC68-03408G-05_EN.indd Sec1:7DV4000H_DC68-03408G-05_EN.indd Sec1:7 2017-07-20  5:34:212017-07-20  5:34:21

English - 8
SEVERE WARNING SIGNS FOR USING
Do not let children or pets on or into the product. In addition, when disposing of this
product, disassemble the door lock (lever).
- This may result in children falling and injuring themselves.
- If children become locked in the product, there is a danger of suffocation.
Do not try to access the inside of the product when the drum is rotating.
Do not sit on the product or lean against the door.
- This may result in the product turning over and resulting in injury.
Dry the laundry only after it was spun by an appropriate washing machine.
Do not dry unwashed items in the tumble dryer.
Do not drink the condensed water.
Never stop a tumble dryer before the end of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
Do not dry laundry contaminated by inflammable materials such as gasoline, kerosene,
benzene, thinner, alcohol, etc.
- This may result in electric shock, fire or explosion.
Do not let pets chew or play with the dryer.
- This may result in electric shock or injury.
When disposing of the product, separate the door and the power cord before disposing of
the product.
- Failure to do so may result in damage to the power code or injury.
Do not touch the power plug with wet hands.
- This may result in electric shock.
When gas (city gas, propane gas, LP gas) leaks, do not touch this appliance or the power
cord, ventilate immediately.
- At this time, do not use the ventilating fan.
- A spark may cause an explosion or fire.
Do not repair, replace, or attempt to service any part of the appliance unless specifically
recommended in the user-repair instructions. You must also have the skills necessary to
service this appliance.
Do not attempt to repair, disassemble, or modify the appliance yourself.
- Do not use any fuse(such as copper, steel wire, etc.) other than the standard fuse.
- When repairing or reinstalling the appliance is required, contact your nearest service
center.
- Failure to do so may result in electric shock, fire, problems with the product, or injury.
The product you have purchased is designed for domestic use only.
The use for business purposes qualifies as product misuse. In this case, the product will not
be covered by the standard warranty provided by Samsung and no responsibility can be
attributed to Samsung for malfunctions or damages resulting from such misuse.
If the product generates strange noise, smells of something burning, or generates smoke,
immediately cut-off the power and contact the service center.
- Otherwise, it may cause an electric shock or fire as a result.
Do not let children (or pets) play in or on your product. The product door does not open
easily from the inside and children may be seriously injured if trapped inside.
WARNING
safety information
DV4000H_DC68-03408G-05_EN.indd Sec1:8DV4000H_DC68-03408G-05_EN.indd Sec1:8 2017-07-20  5:34:212017-07-20  5:34:21

English - 9
CAUTION SIGNS FOR USING
Do not stand on top of the appliance or place objects (such as laundry, lighted candles,
lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
- This may result in electric shock, fire, problems with the product, or injury.
Do not touch the glass door and inside of the drum during or just after drying as it is hot.
- This may result in burns.
Do not press the buttons using sharp objects such as pins, knives, fingernails, etc.
- This may result in electric shock or injury.
Do not dry laundry containing forming rubber (latex) or similar rubber textures.
- If forming rubber is heated, it may start a fire.
Do not dry laundry contaminated by vegetable oil or cooking oil as a large amount of the oil
will not be removed when washing the laundry. In addition, use the Cool Down cycle so that
the laundry is not heated.
- The oxidization heat of the oil may start a fire.
Make sure that the pockets of all clothing to be dried are empty.
- Hard, sharp objects, such as coins, safety pins, nails, screws, or stones can cause
extensive damage to the appliance.
Do not dry clothing with large buckles, buttons, or other heavy metal (zippers, hooks and
eyelets, button-up covers).
If necessary, use the laundry net for small and lightweight laundry such as fabric tie belt ,
apron strings, and underwire bras which can dissolve or break during a cycle.
Recommend against using drying sheets to reduce static electricity as this could lead to
damage to your laundry and also potential damage to the appliance.
- This may result in damage to the laundry.
Do not use the dryer near dangerous powders such as coal dust, wheat flour, etc.
- This may result in electric shock, fire or an explosion.
Do not place inflammable materials near the product.
- This may result in toxic gases from the product, damage to parts, electric shock, fire or
an explosion.
- The appliance should not be placed behind lockable doors etc.
Do not touch the rear side of the appliance during or immediately after drying is complete.
- The appliance remains hot, resulting in a burn.
CAUTION
SAFETY INFORMATION
DV4000H_DC68-03408G-05_EN.indd Sec1:9DV4000H_DC68-03408G-05_EN.indd Sec1:9 2017-07-20  5:34:212017-07-20  5:34:21

English - 10
SEVERE WARNING SIGNS FOR CLEANING
Do not clean the appliance by spraying water directly onto it.
Do not use benzene, thinner or alcohol to clean the appliance.
- This may result in discolouration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, unplug the appliance from the wall socket.
- Failure to do so may result in electric shock or fire.
Clean the filter case before and after using the dryer.
Clean the inside of the product on a regular basis by asking an authorized service engineer.
Clean the condenser with water once a month.
The interior of the dryer should be cleaned periodically by qualified service personnel.
WARNING
safety information
DV4000H_DC68-03408G-05_EN.indd Sec1:10DV4000H_DC68-03408G-05_EN.indd Sec1:10 2017-07-20  5:34:212017-07-20  5:34:21

English - 11
installing your dryer
UNPACKING YOUR DRYER AND INSTALLING GUIDE
Hire a professional to install this dryer properly. If there is a service call performed as a result of poor setup,
adjustment, and connection, it is considered the responsibility of the installer. It is recommended that a
professional is called to install this appliance, especially for more difficult installations involving draining to
the mains water supply or product stacking. If problems of installation result in a service visit to fix a fault,
this is typically considered to be the responsibility of the installer.
Make sure you have everything necessary for proper installation (AC 220-240 V 50 Hz).
A GROUNDED ELECTRICAL OUTLET is required. See Electrical Requirements (See page 13).
SEE DRYER EXTERIOR
Cover Top
Water Tank
Control Panel
Filter Case
Door
Condenser
Levelling Feet
Parts
Hose guide Cable tie Hose connector Long drain hose (2m) Manual book
INSTALLING YOUR DRYER
DV4000H_DC68-03408G-05_EN.indd Sec3:11DV4000H_DC68-03408G-05_EN.indd Sec3:11 2017-07-20  5:34:212017-07-20  5:34:21

English - 12
CHECK BEFORE INSTALLING
• Do not plug the power cord into the wall outlet before completing the dryer installation.
• Check the appearance of the product for any damaged parts before starting the product installation.
• If there are any parts that appear to be damaged, please contact your nearest Samsung Customer
Service Center.
• When moving the product, do not move the product by yourself.
• Take care of the edges of the dryer as they can be sharp.
• Do not install the dryer in a location exposed to frost. Cold water may damage the product.
• Use the product indoors only.
• Do not place the dryer on one side when lifting it, and do not move the dryer in such a way that the
internal parts shake. This may result in damage to the internal parts of the product.
BEFORE USING THE PRODUCT
• Check if there are any accessories remaining inside the drum.
• Plug in the power cord just before operating the product.
• Do not block the air inlet hole of the cooling grill at the front of the dryer.
• Do not place inflammable objects near the dryer and keep the surroundings clean.
• Keep the dryer level with the ground.
• Do not remove the adjustable levelling feet of the dryer. They are necessary to keep the product level
with the ground.
IMPORTANT TO INSTALLER
Please read the following instructions carefully before installing the dryer. These instructions should be kept
for future reference.
REMOVE THE DOOR FROM ALL DISCARDED APPLIANCES TO AVOID THE DANGER OF A CHILD
SUFFOCATING.
LOCATION CONSIDERATIONS
Because a condensing type has been adopted, which condenses and processes air inside the dryer,
external ventilation is not required.
Therefore, The dryer can be installed and used in any location where the temperature is between 5 and
35 degrees centigrade, unlike a conventional dryer that requires an external exhaust system.
WARNING
installing your dryer
DV4000H_DC68-03408G-05_EN.indd Sec3:12DV4000H_DC68-03408G-05_EN.indd Sec3:12 2017-07-20  5:34:222017-07-20  5:34:22

English - 13
ALCOVE OR CLOSET INSTALLATION
To operate safely and properly, your new Dryer requires minimum clearances of:
Sides – 25 mm Rear – 51 mm
Top – 25 mm Front – 465 mm
If both the washing machine and a dryer are installed together, the front of the alcove or closet must have at
least 465 mm unobstructed air opening.
ELECTRICAL REQUIREMENTS
Electrical Requirements is AC 220~240 V / 50 Hz.
• Improper connection of the equipment grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in doubt as to whether your dryer is
properly grounded. Do not modify the plug provided with your dryer – if it doesn’t fit the outlet,
have a proper outlet installed by a qualified electrician.
• To prevent unnecessary risk of fire, electrical shock, or personal injury, all wiring and grounding
must be done in accordance with local codes, or in the absence of local codes, It is your
responsibility to provide adequate electrical services for your dryer.
GROUNDING
Your dryer must be grounded. If your dryer malfunctions or breaks down, grounding will reduce the risk of
electric shock by providing a path of least resistance for the electric current.
Your dryer comes with a power cord having a three-prong grounding plug for use in a properly installed and
grounded outlet.
Never connect the ground wire to plastic plumbing lines, gas lines, or hot water pipes.
Improperly connecting the equipment-grounding conductor can result electrical shock.
Check with a qualified electrician or serviceman if you are unsure if the dryer is properly grounded. Do
not modify the plug provided with the dryer. If it does not fit the outlet, have a proper outlet installed by a
qualified electrician.
If the product is not grounded, there is a danger of fire or electric shock.
WARNING
WARNING
INSTALLING YOUR DRYER
DV4000H_DC68-03408G-05_EN.indd Sec3:13DV4000H_DC68-03408G-05_EN.indd Sec3:13 2017-07-20  5:34:222017-07-20  5:34:22

English - 14
INSTALLATION SIDE BY SIDE
For proper installation, we recommend that you hire a professional. To install:
1. Move your dryer to an appropriate location for installation. Consider
installing the dryer and washer side-by-side. Lay two of the carton
cushion-tops on the floor. Tip your dryer on its side so it will lay across
both cushion-tops.
2. Set your dryer back in an upright position.
3. To ensure that the dryer provides optimal drying performance, it must
be level. To minimize vibration, noise, and unwanted movement,the
floor must be a perfectly level, solid surface.
To set the dryer to the same height as the washer, fully retract the
levelling feet by turning them counterclockwise, then loosen the legs
by turning them clockwise.
Adjust the levelling feet only as much as necessary to level the dryer. Extending the levelling feet more
than necessary can cause the dryer to vibrate.
4. Review Electrical Requirements section (See page 13).
BEFORE OPERATING OR TESTING.
5. With a level, check your dryer and make necessary adjustments to the levelling legs.
6. Plug in your dryer, and check operation by using the checklist below.
FINAL INSTALLATION CHECKLIST
Dryer is plugged into electrical outlet and is properly grounded.
Dryer is leveled and is sitting firmly on the floor.
Start your dryer to confirm that it runs, heats, and shuts off.
installing your dryer
Retract fully Then loosen
Level
Levelling feet
DV4000H_DC68-03408G-05_EN.indd Sec3:14DV4000H_DC68-03408G-05_EN.indd Sec3:14 2017-07-20  5:34:222017-07-20  5:34:22

English - 15
DRAINING WATER WITHOUT USING THE WATER TANK
You can use the dryer without using the water tank by following the procedures below.
CONNECTING THE DRAIN HOSE
The Dryer can pump the condensed water outside of the DRYER directly
with drain hose provided.
The procedures to connect the drain hose are as follows.
1. Disconnect the drain hose A.
2. Connect the drain hose Ato the other part.
3. Connect accessory hose (long drain hose) Bto the hole
next to the part that is connected to drain hose A.
• Because the dryer’s drain pump can only pump up
the drain water to 90 cm height, when you connect
the drain hose Bto the drain point, make sure that
the height of drain point does not exceed 90 cm.
A drainage error may occur if the drain point exceeds
90 cm. If a drainage error occurs, the control panel displays an error code.
• After connecting the drain hose, you can directly drain the condensed water via the
drain-outlet through the connected drain hose or through the washstand or the drain-
outlet of the washstand.
CAUTION
INSTALLING YOUR DRYER
A
A
B
DV4000H_DC68-03408G-05_EN.indd Sec3:15DV4000H_DC68-03408G-05_EN.indd Sec3:15 2017-07-20  5:34:222017-07-20  5:34:22

English - 16
Connecting the drain hose
The end of the drain hose can be positioned in three ways:
1. Over the edge of a wash basin: The drain hose must be placed lower than 90 cm. If the end
of the drain hose needs to be placed above the ground, we recommend a height of 60 cm
~ 90 cm. To keep the drain hose spout bent, use the supplied plastic hose guide. Secure
the guide to the wall with a hook or to the tap with a piece of string to prevent the drain hose
from moving.
Drain hose
Hose guide
90 cm
Cable Tie
2. Assemble the drain hose and the hose guide and fix them with the cable-tie.
3. You can drain the condensed water by connecting the accessory hose (long drain hose) to
the drain-outlet directly.
Connecting the direct-hose
You can immediately drain the condensed water that comes out while drying, by connecting the
drain hose to the tap.
1. Assemble the hose connector and the hose.
Since there is a danger of water leaking from the hose
connecter and accessory hose, make sure that they are
connected firmly.
2. Connect the end of the hose to the tap.
CAUTION
installing your dryer
Hose Connecter
DV4000H_DC68-03408G-05_EN.indd Sec3:16DV4000H_DC68-03408G-05_EN.indd Sec3:16 2017-07-20  5:34:222017-07-20  5:34:22

English - 17
INSTALLATION STACKING
In case of purchasing the additional stacking kit, contact our Samsung service center or local
distributers. [Part no. SK-DH / SK-DA / SKK-DF]
The stacking kit differs depending on the model.
1. Carefully lay the dryer on its side. Use the packing material
so you don’t scratch the finish on the dryer.
2. Install rubber pads to dryer base.
• Locate the 4 rubber pads in the parts package. Insert
the rubber pads into the holes at the bottom of the
levelling legs.
• Purchase the stacking-kit package additionally.
3. Set the dryer upright.
The stacking kit can only be installed for Samsung family
products.
4. Install bracket to dryer.
• Remove washer top cap screw from the rear left. Align left
bracket holes with top cap screw hole on rear left of the
unit and replace screw.
Leave screw loose so dryer hole alignment will be easier.
• Repeat the above step with the right side.
5. Install dryer and bracket on washer
• Lift the dryer on top of the washer. Protect the washer
control panel with cardboard or other protection. Be
sure to lift the dryer high enough to clear the washer
control panel.
• More than two people are recommended to lift the
dryer into position because of its weight and size.
Failure to do so could result in injury.
• Align the holes in the bracket with the holes in the
back of the dryer.Using a screwdriver, attach the M4x12 tapping screws.
• Tighten the washer bracket screws ; then tighten all stacking kit screws.
CAUTION
WARNING
INSTALLING YOUR DRYER
Bracket-Stacking
Screw
Dryer
Washer
DV4000H_DC68-03408G-05_EN.indd Sec3:17DV4000H_DC68-03408G-05_EN.indd Sec3:17 2017-07-20  5:34:222017-07-20  5:34:22

English - 18
6. Finalise the installation
• Refer to the washer Installation Instructions to complete the washer installation.
• Refer to the dryer Installation Instructions to complete the dryer installation.
• Carefully slide or walk the stacked washer and dryer into place. Use felt pads or other
sliding device to assist moving and to protect flooring.
Do not push on the dryer once installed to top of the washer. Pushing on the dryer may result in
pinched fingers.
DOOR REVERSAL
Depending on your requirements (installation location, space constraints), you can change the direction the
door opens.
This is done according to the customer’s needs. The qualified technician or customer can do this
themselves directly.
1. Unplug the power cord.
2. Remove the two screws from the door-hinge.
3. Lift the door to separate it.
4. Remove the 16 screws.
Disassemble the air seal and remove the 6 screws.
(Only for Crystal Gloss door models)
5. After removing the screw, rotate the Assy hinge door,
the handle door by 180° as shown in the figure.
• Work carefully so that the door-seal is not removed.
6. Fasten the 16 screws in the correct positions.
Fasten the 6 screws and replace the air seal.
(Only for Crystal Gloss door models)
7. Note that two of the screws have a different length from the others.
(Use the longer screws for the door-lever.)
WARNING
WARNING
CAUTION
Frame-Front
Assy-Door
Hinge-Door
Crystal Gloss Door
Door-Glass
Assy hinge door
Handle Door
Crystal Gloss Door
installing your dryer
DV4000H_DC68-03408G-05_EN.indd Sec3:18DV4000H_DC68-03408G-05_EN.indd Sec3:18 2017-07-20  5:34:232017-07-20  5:34:23

English - 19
8. Move the position of the screw at the back of the door-hinge.
9. Fasten the screw in the bottom hole.
10. Remove the two screws holding the front-frame at the left.
11. Remove the two screws holding the holder-lever at the left.
12. Now, move to the right side of the product and fasten the two screws
holding the front-frame and the two screws holding the lever-holder.
13. Align the door with the fixing holes.
14. Fasten the two screws holding the door-hinge.
You can restore the direction the door opens by following the procedures above, if necessary.
Holer-Lever
Inside the drum
INSTALLING YOUR DRYER
DV4000H_DC68-03408G-05_EN.indd Sec3:19DV4000H_DC68-03408G-05_EN.indd Sec3:19 2017-07-20  5:34:232017-07-20  5:34:23

English - 20
operating Instructions, tips
To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS before operating this appliance.
If the Wrinkle Prevent option is not selected, take out the laundry immediately after it is washed and
dried. Leaving the laundry inside the drum may produce wrinkles.
OVERVIEW OF THE CONTROL PANEL
٣ ٤ ٥ ٦ ٧١ ١٠٨ ٩ ١١
٢
1Digital Graphic
Display
Displays the remaining drying cycle time, all cycle information, and error messages.
The display window shows the estimated time remaining in the cycle after you
have pressed the Start/Pause button. The estimated time remaining may
fluctuates as the cycle progresses.
The Drying light will illuminate and remain lit until the cycle is complete.
When your dryer is in the cool-down phase, the Cooling light will illuminate. When
your dryer is in the Wrinkle Prevent phase, the “Wrinkle Prevent light” will illuminate.
When the cycle is complete, “End” (or “0”) will appear in the display panel until you
push the Start/Pause button or the Power button. If your dryer is paused during
a cycle, the indicators will light up until you press the Start/Pause button.
2Cycle Selector
When you turn on your dryer, the [Cotton] CUPBOARD DRY cycle is
selected as default.
Turn the Cycle Selector to select the cycle you want.
Cotton - For averagely or lightly soiled cottons, bed linen, table linen,
underwear, towels, shirts, etc.
• EXTRA DRY - Use for heavy-duty fabrics or items that should be very dry.
• CUPBOARD DRY - Use this cycle to dry loads such as cotton,
underwear, and linen (NOT appropriate for jeans).
• IRON DRY - Finishes the dry cycle in a moist state appropriate for Ironing.
Synthetics - For averagely or lightly soiled blouses, shirts, etc., made of
polyester (diolen, trevira), polyamide (perlon, nylon) or other similar blends.
• EXTRA DRY - Use for heavy-duty fabrics or items that should be very dry.
• CUPBOARD DRY - Use this cycle to dry loads such as shirts, blouses, bed
linen and table linen. (NOT appropriate for jeans).
• IRON DRY - Finishes the dry cycle in a moist state appropriate for Ironing.
QUICK DRY - 29 min is automatically set as the drying time.
WARM AIR - For small items, pre-dried laundry and normal fabrics in
20 minutes.
COOL AIR - For all fabrics to need freshing tumbles without heating.
WARNING
DV4000H_DC68-03408G-05_EN.indd Sec5:20DV4000H_DC68-03408G-05_EN.indd Sec5:20 2017-07-20  5:34:232017-07-20  5:34:23
