Samsung Dvd-r130s User manual

Instruction Manual

DVD-R130S

www.samsung.com

AK68-01002G-00

01002G-R130S-AFS-ENG-01-13 2006.4.18 3:41 PM Page 1

Getting Started

2- English

Warning

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMO E THE CO ER(OR BACK).

NO USER-SER ICEABLE PARTS ARE INSIDE. REFER

SER ICING TO QUALIFIED SER ICE PERSONNEL.

This symbol indicates important instructions

accompanying the product.

Do not install this equipment in a confined space such as a

bookcase or similar unit.

WARNING : To prevent damage which may result in fire or

electric shock hazard, do not expose this appliance to rain

or moisture.

CAUTION : D D RECORDERS USE AN IN ISIBLE

LASER BEAM WHICH CAN CAUSE HAZARDOUS

RADIATION EXPOSURE IF DIRECTED.

BE SURE TO OPERATE RECORDER CORRECTLYAS

INSTRUCTED.

CAUTION

THIS PRODUCT UTILIZES A LASER.

USE OF CONTROLS OR ADJUSTMENTS OR

PERFORMANCE OF PROCEDURES OTHER THAN

THOSE SPECIFIED HEREIN MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN CO ERS AND DO NOT REPAIR

YOURSELF. REFER SER ICING TO QUALIFIED

PERSONNEL.

CAUTIONS

Caution: To prevent electric shock, match wide blade of

plug to wide slot, fully insert.

Attention: Pour éviter les chocs électriques, introduíre la

lame la plus large de la fiche dans la borne correspondante

de la prise et pousser jusqu au fond.

This product satisfies FCC regulations when shielded

cables and connectors are used to connect the unit to other

equipment. To prevent electromagnetic interference with

electric appliances, such as radios and televisions, use

shielded cables and connectors for connections.

FCC NOTE (for U.S.A):

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause

harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/T technician

for help.

Caution: FCC regulations state that any unauthorized

changes or modifications to this equipment may

void the user's authority to operate it.

This symbol indicates “dangerous voltage”

inside the product that presents a risk of

electric shock or personal injury.

■

This unit can be used only where the power

supply is AC 110 ~240 , 50/60Hz.

It cannot be used elsewhere.

■

This D D Recorder is designed and

manufactured to respond to the Region

Management Information.

If the Region number of a D D disc does

not correspond to the Region number of

this D D Recorder, the D D Recorder

cannot play the disc.

■

This device is protected by U.S. Patent

Nos.4,631,603;4,577,216;4,819,098;4,907,

093; and 6,516,132.This product

incorporates copyright protection

technology that is protected by U.S. patents

and other intellectual property rights.Use of

this copyright protection technology must

be authorized by Macrovision,and is

intended for home and other limited viewing

uses only unless otherwise authorized by

Macrovision.Reverse engineering or

disassembly is prohibited.

NOTE

01002G-R130S-AFS-ENG-01-13 2006.2.24 4:29 PM Page 2

Getting Started

English - 3

Important Safet Instructions

Read these operating instructions carefully before using

the unit. Follow all the safety instructions listed below.

Keep these operating instructions handy for future

reference.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings, Install in

accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or

grounding- type plug. A polarized plug has two

blades with one wider than the other. Agrounding-

type plug has two blades and a third grounding

prong. The wide blade or the third prong are

provided for your safety. if the provided plug does

not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, and the point where they exit from the

apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as a power-supply cord

or plug is damaged, liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

Handling Cautions

• Before connecting other components to this

recorder, be sure to turn them all off.

• Do not move the recorder while a disc is being

played, or the disc may be scratched or broken, and

the recorder’s internal parts may be damaged.

• Do not put a flower vase filled with water or any

small metal objects on the recorder.

Precaution

• Be careful not to put your hand into the disc tray.

• Do not place anything other than the disc in the disc

tray.

• Exterior interference such as lightning and static

electricity can affect normal operation of this

recorder. If this occurs, turn the recorder off and on

again with the POWER button, or disconnect and

then reconnect the AC power cord to the AC power

outlet.

The recorder will operate normally.

• Be sure to remove the disc and turn off the recorder

after use.

• Disconnect the AC power cord from the AC outlet

when you don’t intend to use the recorder for long

periods of time.

• Clean the disc by wiping in a straight line from the

inside to the outside of the disc.

Maintenance of Cabinet

For safety reasons, be sure to disconnect the AC

power cord from the AC outlet.

• Do not use benzene, thinner, or other solvents for

cleaning.

• Wipe the cabinet with a soft cloth.

Disc Handling

• Use discs with regular

shapes. If an irregular disc

(a disc with a special

shape) is used, this D D

Recorder may be damaged.

Holding discs

• Avoid touching the surface of a

disc where recording is

performed.

DVD-RAM, DVD-RW and DVD-R

• Clean with an optional D D-RAM/PD

disc cleaner (LF-K200DCA1 where

available). Do not use cleaners or

cloths for CDs to clean D D-RAM/D D-

RW/D D-R discs.

DVD-Video, CD

• Wipe off dirt or contamination on the disc with a soft

cloth.

Cautions on handling discs

• Do not write on the printed side with a ball-point pen

or pencil.

01002G-R130S-AFS-ENG-01-13 2006.2.24 4:29 PM Page 3

Getting Started

4- English

• Only MP3 files with the ".mp3", ".MP3" extension

can be used.

• For MP3 files recorded with a BR( ariable Bit

Rates), from 32 Kbps to 320 Kbps, the sound may

cut in out.

• Playable bitrate range is from 56Kbps to 320Kbps.

• The unit can handle a maximum of 1000 files and

folders.

• Only JPEG files with the ".jpg", ".JPG" extension can

be used.

• The unit can handle a maximum of 1000 files and

folders.

• Maximum size of progressive JPEG is 3M pixels.

• MOTION JPEG is not supported.

• Use a 700MB(80 minutes) CD-R/-RW disc.

If possible, do not use a 800MB(90 minutes) or

above disc, as the disc may not play back.

• If the CD-R/-RW disc was not recorded as a closed

session, you may experience a delay in the early

playback time, and all recorded files may not play.

• Some CD-R/-RW discs may not be playable with this

unit, depending on the device which was used to

burn them.

For contents recorded on CD-R/-RW media from

CDs for your personal use, playability may vary

depending on contents and discs.

DVD-R Disc Pla back and Recording

• Once a D D-R recorded in ideo Mode is finalized,

it becomes D D- ideo.

• You can record onto the available space on the disc

and perform editing functions such as giving titles to

discs and programs and erasing programs before

finalizing.

• When programming is erased from a D D-R, that

space does not become available. Once an area on

a D D-R is recorded on, that area is no longer

available for recording, whether the recording is

erased or not.

• It takes about 30 seconds for the unit to complete

recording management information after recording

finishes.

• This product optimizes the D D-R for each

recording. Optimizing is carried out when you start

recording after inserting the disc or turning on the

unit. Recording onto the disc may become

impossible if optimizing is carried out too many

times.

• Playback may be impossible in some cases due to

the condition of recording.

• This unit can play back D D-R discs recorded and

finalized with a Samsung D D video recorder. It may

not be able to play some D D-R discs depending on

the disc and the condition of the recording.

• Do not use record cleaning sprays or antistatic. Also,

do not use volatile chemicals, such as benzene or

thinner.

• Do not apply labels or stickers to discs. (Do not use

discs fixed with exposed tape adhesive or leftover

peeled-off stickers.)

• Do not use scratch-proof protectors or covers.

• Do not use discs printed with label printers available

on the market.

• Do not load warped or cracked discs.

Disc Storage

Be careful not to harm the disc because the data on

these discs is highly vulnerable to the environment.

• Do not keep under direct sunlight.

• Keep in a cool ventilated area.

• Store vertically.

• Keep in a clean protection jacket.

• If you move your D D Recorder suddenly from a

cold place to a warm place, condensation may

generate on the operating parts and lens and cause

abnormal disc playback. When this occurs, do not

connect the plug to the power outlet. Wait for two

hours, then insert the disc and try to playback again.

It will work properly when condensation has

evaporated.

Disc Specifications

DVD-Video

• A digital versatile disc (D D) can contain up to 135-

minutes of images, 8-language audio and 32 subtitle

languages. It is equipped with MPEG-2 picture

compression and Dolby 3D surround sound, allowing

you to enjoy vivid and clear theater quality images in

the comfort of your own home.

• When switching from the first layer to the second

layer of a double-layered D D ideo disc, there may

be momentary distortion in the image and sound.

This is not a malfunction of the unit.

• Once a D D-R/-RW recorded in ideo Mode is

finalized, it becomes D D- ideo.

Audio CD

• An audio disc on which 44.1kHz PCM Audio is

recorded

• Plays CD-DA format audio CD-R and CD-RW discs.

The unit may not be able to play some CD-R or CD-

RW discs due to the condition of the recording.

CD-R/-RW

• Only CD-R discs with MP3 files recorded with

ISO9660 or JOLIET format can be played back

MP3 CD-R/-RW

JPEG CD-R/-RW

Using CD-R/-RW

01002G-R130S-AFS-ENG-01-13 2006.2.24 4:29 PM Page 4

Getting Started

English - 5

DVD-RW Disc Pla back and Recording

• Recording and playback can be performed on D D-

RW discs in both the ideo and R Modes.

• Once a D D-RW recorded in R Mode or ideo mode

is finalized, you cannot perform addtional recording.

• Once a D D-RW recorded in ideo Mode is finalized,

it becomes D D- ideo.

• In both modes, playback can be performed before and

after finalization, but additional recording, deleting and

editing can not be performed after finalization.

• If you want to record the disc in R Mode and then

record in Mode, be sure to execute Format.

Be careful when executing Format because all the

recorded data may be lost.

• A D D-RW blank disc is initialized to R Mode when

first initialized.

•DVD-RW (VR mode)

- This is a format that is used for recording data on a

D D-RW disc. You can record multiple titles, edit,

delete, partial delete, create a playlist, etc.

- A disc that is recorded in this mode will not play in

standard D D players.

•DVD-RW (Video mode)

- This is a format that is used for recording data on a

D D-RW or D D-R disc. The disc can be played by

an existing D D player once it has been finalized.

- If a disc that has been recorded in ideo Mode by a

different maker’s recorder but has not been finalized,

it cannot be played or additionally be recorded by

this recorder.

DVD-RAM Disc Pla back

• D D-RAM discs come with or without a cartridge.

For this product, we recommend D D-RAM discs that

come without cartridges.

• You cannot play a D D-RAM in most D D players

due to compatibility issues.

• Only D D-RAM standard ersion 2.0. discs can be

played in this unit.

• For cartridge type D D-RAM discs, remove the

cartridge and use the disc only.

Protection

This D D Recorder can allow you to protect the

contents of your discs, as described below.

• Program-protected: See page 73 “Locking a Title”

• Disc-protected: See page 85 “Disc Protection”

✻

D D-RAM/D D-RW/D D-R discs that are

incompatible with the D D- IDEO format cannot be

played with this product.

✻

For more information on D D recording compatibility,

consult your D D-RW/D D-R manufacturer.

✻

If poor quality D D-RW/D D-R discs are used, your

recordings may fail.

Do not use the following discs!

• LD, CD-G, CD-I, CD-ROM and D D-ROM discs

should not be used in this product.

[Note]

Disc types that can be played :

CD/CD-R/CD-RW/MP3/JPEG/D D- ideo/D D-

RAM/D D-RW/ D D-R.

D D+R/+RW cannot record, but the finalized +R/+RW

can be played.

For a D D-R/D D-RW disc, which has been recorded

in ideo Mode on another component, it can play only

when finalized.

• Some commercial discs and D D discs purchased

outside your region may not be playable with this

product. When these discs are played, either “No

disc." or "Please check the regional code." will be

displayed.

• If your D D-RW disc is an illegal copy or is not in

D D video format, it may also not be playable.

High Speed Recording discs can be used in this unit.

• Not all brands of discs will be compatible with this

unit.

• The latest firmware upgrade to improve recording &

playback quality can be downloaded from our web

site. (Download Center at www.samsung.com)

• If disc compatibility problems continue, or there is an

issue upgrading your recorder, contact the Call

Center.

COPY PROTECTION

•

Many D D discs are encoded with copy protection.

Because of this, you should only connect your D D

Recorder directly to your T , not to a CR.

Connecting to a CR results in a distorted picture

from copy-protected D D discs.

•

This product incorporates copyright protection

technology that is protected by methods claims of

certain U.S. patents and other intellectual property

rights owned by Macrovision Corporation and other

rights owners. Use of this copyright protection

technology must be authorized by Macrovision

Corporation, and is intended for home and other

limited viewing uses only unless otherwise

authorized by Macrovision Corporation. Reverse

engineering or disassembly is prohibited.

Disc compatibilit

01002G-R130S-AFS-ENG-01-13 2006.2.24 4:29 PM Page 5

Getting Started

6- English

Contents

Getting Started

Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Precaution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . .3

Handling Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Maintenance of Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . .3

Disc Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Disc Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Disc Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

General Features . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Before Reading the Instruction Manual . . . . . . . . . .9

How to use the D D Recorder . . . . . . . . . . . . . . . . .9

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Front Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Tour of the Remote Control . . . . . . . . . . . . . . . . . . . . . .13

Connecting & Setting UP

Quick Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Step 1 : Connecting the Antenna cable . . . . . . . . .15

Antenna + D D Recorder + T : No Cable box . . . . . .15

Antenna + Cable box + D D Recorder + T : Cable box

with many scrambled channels . . . . . . . . . . . . . . . . . . .16

Antenna + D D Recorder + Cable box +T : Cable box

with a few scrambled channels . . . . . . . . . . . . . . . . . . .17

Step 2 : Connecting the ideo Cable . . . . . . . . . . .18

Connecting to a ideo input jack . . . . . . . . . . . . . . . . . .18

Connecting to an S-video input jack . . . . . . . . . . . . . . .19

Connecting to Component video input jacks(Y,PB,PR) 20

Step 3 : Connecting the Audio cable . . . . . . . . . . . .21

Connecting to your T . . . . . . . . . . . . . . . . . . . . . . . . . .21

Connecting to a stereo amplifier with analog

input jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Connecting to an A amplifier with a digital

input jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Step 4 : Connecting External Devices . . . . . . . . . . .24

Connecting a CR, Set-Top Box(STB)

or D D Player to the A 1 IN jacks . . . . . . . . . . . . . . . .24

Connecting a Camcorder to the A 2 IN jacks . . . . . . .25

Connecting a Camcorder to the D IN jack . . . . . . . . . .26

Step 5 : Connecting the Power Cord . . . . . . . . . . . .27

Step 6 : Preparing the Remote Control . . . . . . . . . .27

S stem Setup

Using the Setup Menu . . . . . . . . . . . . . . . . . . . . . . .28

Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

1. OSD Language Setup . . . . . . . . . . . . . . . . . . . . . . . .29

2. Clock Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

3. Channel Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

4. Setting Up the Audio Options . . . . . . . . . . . . . . . . . . .32

5. Setting Up the T Aspect . . . . . . . . . . . . . . . . . . . . .34

System Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

CM Skip Time Setting . . . . . . . . . . . . . . . . . . . . . . . . . . .35

EP Mode Time Setting . . . . . . . . . . . . . . . . . . . . . . . . . .36

Automatic Chapter Creation . . . . . . . . . . . . . . . . . . . . . .36

Quick Recording Setting . . . . . . . . . . . . . . . . . . . . . . . .37

Language Setting . . . . . . . . . . . . . . . . . . . . . . . . . .38

ideo (Display) Setting . . . . . . . . . . . . . . . . . . . . . .39

Parental Control . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Recording

Before Recording . . . . . . . . . . . . . . . . . . . . . . . . . .43

Recordable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Recording Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Record Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Unrecordable video . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

About INFO button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Checking the available disc space

(Disc Information) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

01002G-R130S-AFS-ENG-01-13 2006.2.24 4:29 PM Page 6

Getting Started

English - 7

Recording the current T program you are

watching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Recording from External Equipment . . . . . . . . . . . .47

Copying from a Camcorder . . . . . . . . . . . . . . . . . . .48

Making a One Touch Recording (OTR) . . . . . . . . . .49

Setting a Timer Recording . . . . . . . . . . . . . . . . . . . .50

Flexible Recording (for Timer Recording only) . . . .51

Editing the Scheduled Record List . . . . . . . . . . . . .51

Deleting the Scheduled Record List . . . . . . . . . . . .52

Recording the Scheduled Record List . . . . . . . . . . .53

Pla back

Before Playing . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Region code (D D- ideo only) . . . . . . . . . . . . . . . . . . .54

Disc types that can be played . . . . . . . . . . . . . . . . . . . .54

Discs that cannot be played . . . . . . . . . . . . . . . . . . . . . .54

Playing a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Using the Disc Menu & Title Menu . . . . . . . . . . . . . . . .56

Using the Search Functions . . . . . . . . . . . . . . . . . . . . . .56

Slow Motion Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Step Motion Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

About ANYKEY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Using the Repeat Function . . . . . . . . . . . . . . . . . . . . . .58

Selecting the Subtitle . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Selecting the Audio language . . . . . . . . . . . . . . . . . . . .60

Changing the Camera Angle . . . . . . . . . . . . . . . . . . . . .61

Zooming-In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Using Bookmarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

Using Markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Playing an Audio CD/MP3 . . . . . . . . . . . . . . . . . . .64

Playing an Audio CD (CD-DA)/MP3 . . . . . . . . . . . . . . .64

Playing a Picture CD . . . . . . . . . . . . . . . . . . . . . . . .67

Playing the Title List . . . . . . . . . . . . . . . . . . . . . . . . .68

Editing

Basic Editing (Title List) . . . . . . . . . . . . . . . . . . . . . .72

Renaming(Labeling) a Title . . . . . . . . . . . . . . . . . . . . . .72

Locking(Protecting) a Title . . . . . . . . . . . . . . . . . . . . . . .73

Deleting a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Deleting a Section of a Title . . . . . . . . . . . . . . . . . . . . .74

Advanced Editing (Playlist) . . . . . . . . . . . . . . . . . . .76

Creating a Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Playing Entries in the Playlist . . . . . . . . . . . . . . . . . . . .77

Renaming a Playlist Entry . . . . . . . . . . . . . . . . . . . . . . .78

Editing a Scene for the Playlist . . . . . . . . . . . . . . . . . . .79

Copying a Playlist Entry to the Playlist . . . . . . . . . . . . . .82

Deleting a Playlist Entry from the Playlist . . . . . . . . . . . .83

Disc Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

Editing the Disc Name . . . . . . . . . . . . . . . . . . . . . . . . . .84

Disc Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Formatting a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Deleting All Title Lists . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Finalizing a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Unfinalizing a Disc ( / R mode) . . . . . . . . . . . . . . . . .88

Additional Information

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .89

Solution to Error Message . . . . . . . . . . . . . . . . . . . .93

Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95

01002G-R130S-AFS-ENG-01-13 2006.2.24 4:29 PM Page 7

Getting Started

8- English

General Features

The DVD-R130S allows you to record and play high

quality digital video on DVD-RW DVD-R discs. You can

record and edit digital video on DVD-RW DVD-R discs as

if they were VCR tapes.

High quality digital audio and video recording

and playback

Record up to 8-hours of video or images with a 4.7 GB

DVD-RW DVD-R disc, depending on the recording mode.

Selectable Record Mode

You can set your recorder to one of five different recording

speeds, each varying in recording quality and length. EP

mode yields the most recording time, LP & SP modes

provide less recording time with higher quality recording,

and XP mode gives you the highest quality recording.

There's also the FR (Flexible Recording) mode that lets

you record with the best picture quality possible for the

recording time and remaining space on the disc in timer

recording.

Automated Quality Adjustment for imer

Recording

If FR mode is selected, the video quality is adjusted

automatically so that all video for the scheduled time can

be recorded onto the free disc space. (See page 51.)

Create a DVD video title using a DVD-RW/DVD-R

disc

With the DVD-R130S, you can create your own DVD

video title on 4.7 GB DVD-RW DVD-R discs.

Copying data from a digital camcorder using

a DV input jack

Record digital camcorder video onto DVD-RW, DVD-R

discs using the DV input jack (IEEE 1394-4pin). (See

page 48.)

High quality progressive scan

Progressive scanning provides high resolution and flicker

free video.

The 10-bit 54-MHz DAC and 2D Y C Separating Circuitry

provides the highest video playback and recording quality.

(See page 20.)

A variety of functions with an easy-to-use

user interface

The integrated menu system and the messaging function

allow you to perform desired operations both easily and

conveniently. With a DVD-RW disc, you can edit recorded

images, create a playlist, and edit video in a specific

sequence according to your requirements.

01002G-R130S-AFS-ENG-01-13 2006.4.18 3:42 PM Page 8

Getting Started

English - 9

How to use the DVD

Recorder

Step 1

Select the disc type

Step 2

Format the disc to start recording

This unit can record on the following types of discs.

If you want to repeatedly record on the same disc

or you want to edit the disc after recording, select a

rewritable DVD-RW type disc.

If you want to sa e recording without any change,

choose a non-rewritable DVD-R.

Unlike a VCR, the recorder automatically starts

formatting when an unused disc is inserted. This is

required for the preparation of disc recording.

Using a DVD-RW

This type of disc can be formatted in either DVD-

Video format (Video mode) or DVD-Video Recording

format (VR mode). For an unused disc, a message

that asks whether to initialize or not is displayed.

You can play a Video mode disc in standard DVD

players. A VR mode disc allows more aried

editing.

Using a DVD-R

This type of disc can be formatted in DVD Video

format.

After formatting is complete, you can record on the

disc.

You can play this type of disc on arious DVD

components only when they ha e been finalized.

Before Reading the

Instruction Manual

About the use o this Instruction Manual

1) Be sure to be familiar with Safety Instructions before

using this product. (See pages 2~3)

2) If a problem occurs, check the Troubleshooting.

(See pages 89~92)

All rights reser ed; No part or whole of this user’s manual

may be reproduced or copied without the prior written

permission of Samsung Electronics Co.

Make sure to check the following before reading the

user’s manual.

Icons that will be used in manual

Icon Term Definition
