Samsung RA-TIMO63PP/AA User manual

Installation manual
Quick-Connect Auto Ice Maker Kit
Free Standing Appliance
Untitled-1 1 2021-07-19  10:59:10

English2
Contents
Contents
Safety information 3
Important safety symbols and precautions: 3
State of California Proposition 65 Warning 3
Severe warning signs for transportation and site 3
Installation 4
Before connecting the water line 4
Install the Auto Ice Maker 5
Connect the water line 13
Troubleshooting 15
Auto Ice Maker 15
Warranty (U.S.A) 16
Warranty Information (CANADA) 18
Limited Warranty for Original Purchaser 18
Obligation to the Original Owner 18
Exclusions of the Warranty 18
Untitled-1 2 2021-07-19  10:59:10

English 3
Safety information
Important safety symbols and precautions:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
These warning signs are here to prevent injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe place for future reference.
State of California Proposition 65 Warning
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Severe warning signs for transportation and site
WARNING
• When transporting and installing the appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
- Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak
is detected, avoid any naked ames or potential sources of ignition and air the room
in which the appliance is standing for several minutes.
- This appliance contains a small amount of isobutane refrigerant (R-600a), a natural
gas with high environmental compatibility that is, however, also combustible. When
transporting and installing the appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Safety information
Untitled-1 3 2021-07-19  10:59:10

English4
Installation
Before connecting the water line
To use the ice maker, you must connect the water line to it. For the ice maker to operate
properly, a water pressure of 20 - 125 psi (0.138 - 0.862 mPa) is required.
WARNING
Make sure to connect the water line only to a potable water source.
CAUTION
• Do not reuse an old hose set. Use the new hose sets supplied with your refrigerator
only.
• The water line installation is not covered by the Warranty of this product. Read carefully
through these instructions to protect your property and prevent possible damage.
• Banging pipes (water banging in the pipes) can cause damage to the refrigerator, and
lead to water leakage or ooding. If you encounter this problem, contact a plumber for
professional assistance.
• To prevent burns and product damage, do not connect the water line to a hot water
source.
• Do not install the water line in areas where temperatures fall below the freezing point.
• When using any electrical device (such as a motorized drill) during installation, be sure
the device is insulated and properly grounded to prevent electric shock.
• All installations must be in accordance with local plumbing code requirements.
• The water lter must be replaced as instructed by the manufacturer or the retailer.
• To purchase additional water lters, contact the manufacturer or the retailer of the lter.
NOTE
• You can purchase the water line installation kit from your retailer. We recommend using
a kit that contains copper tubing and a 6 mm (1/4”) compression nut.
• In an area with low water pressure (below 20 psi (0.138 mPa)), you can install a booster
pump to compensate for the low pressure.
Installation
Untitled-1 4 2021-07-19  10:59:10

English 5
Installation
Install the Auto Ice Maker
To purchase a new Auto Ice Maker (part type : RA-TIMO63PP/AA), visit the Samsung
website (www.samsung.com) or contact your retailer.
Ice maker kit
Ice maker Ice bucket
Water line (Blue) Water line (White) Flexible tubes Fixers
Tools required (not provided)
Phillips screwdriver
Untitled-1 5 2021-07-19  10:59:11

Installation
English6
Installation
To install the ice maker kit
WARNING
Refrigerator must be disconnected from the source of electrical supply before attempting
the installation.
A
A
1. Remove the screws tightening the water
inlet cover (A) located on the top of the
refrigerator. Then, slide out the water
inlet cover (A) to remove.
A
2. Remove the pipe plug foam (A) from the
pipe.
A
B
3. Slide the exible tube (A) towards the
water inlet tube (B) (with a white water
line) and secure it to the water inlet tube
(B).
NOTE
Do not remove the cap plugged in at the
end of the white water line.
Untitled-1 6 2021-07-19  10:59:11

English 7
Installation
A
4. Straighten the wire (A) attached to the
white water line and put it into the
water inlet on the top of the refrigerator.
Be careful not to damage the wire.
A
B
5. Insert the water inlet tube (A) (with a
white water line) into the water inlet on
the top of the refrigerator. Secure the
water inlet tube (A) with the hook (B).
A
A
6. Slide the water inlet cover (A) back into
its place, and then fasten it with the
screws.
Untitled-1 7 2021-07-19  10:59:11

Installation
English8
Installation
A
7. Open the freezer door, and then remove
the shelf (A).
A
A
8. Remove the screws fastening the cover
(A) on the inner upper corner of the
freezer. Then, remove the cover (A) by
pulling it to the front.
A
9. Connect the wire harness (A) of the
white water line (which you have
inserted through the water inlet on
the top of the refrigerator) to the right
socket in the freezer. Make sure the
connector is fully inserted. (You should
hear a clicking sound.)
A
10.Connect the wire harness (A) of the ice
maker to the left socket in the freezer.
Make sure the connector is fully inserted
to prevent system failure.
Untitled-1 8 2021-07-19  10:59:12

English 9
Installation
A
B
B
11.Insert the ice maker into the front side
of the grommets (A) as shown. Then,
push the ice maker (B) inwards to the
end. To prevent deviation of the ice
maker, make sure the ice maker ts into
position.
A
12.Tighten the provided screws (x2) to
attach the ice maker (A) rmly to the
refrigerator.
- Make sure the screw holes are
aligned with each other before
tightening the screws.
A
13.Put the ice bucket (A) on the shelf as
shown. By design, the ice bucket (A) is
supposed to sit behind the ice maker.
Otherwise, the ice cubes from the ice
maker will not collect in the bucket as
intended.
A
14.Unscrew the screws to remove the
compressor compartment cover (A) at
the back of the refrigerator.
WARNING
Be careful not to get a cut on your
hands when removing the compressor
compartment cover (A).
Untitled-1 9 2021-07-19  10:59:12

Installation
English10
Installation
A
B
15.Remove the cap at the end of the white
water line and slide the exible tube (A)
to the white water line. Then, connect
the white water line to the bottom of
the valve (B) (with a blue water line).
NOTE
Dispose the cap immediately after
removing it from the water line. Do not
play with the cap or put it in your mouth.
A
NOTE
There is line (A) marked on the white water
line. Make sure to insert the water line up
to the marked line when you connect it to
the valve.
A
16.Connect the valve connector (A) to the
port in the compressor compartment.
(See the gure for the location of the
port.) Make sure the connector is fully
inserted. (You should hear a clicking
sound.)
A
17.Secure the valve bracket (A) to the
refrigerator as shown in the gure.
Untitled-1 10 2021-07-19  10:59:13

English 11
Installation
NOTE
• Make sure to arrange the water lines as
shown in the gures.
• Make sure the water lines are not
pinched or kinked during the process.
A
18.Reattach the compressor compartment
cover (A).
NOTE
Make sure the water lines are not pinched
or kinked during the process.
A
19.Use the 3 xers (A) to secure the water
lines.
NOTE
• Do not remove the cap plugged in at
the end of the blue water line until you
connect the blue water line to a water
source.
• If the water hose is loose, use a tape
to rmly attach it to the back of the
refrigerator.
CAUTION
Do not mount the water lter on any part
of the refrigerator. This may damage the
refrigerator.
Untitled-1 11 2021-07-19  10:59:13

Installation
English12
Installation
NOTE
If you must relocate the refrigerator after
connecting the water line, make sure the
joined section of the water line is straight.
Untitled-1 12 2021-07-19  10:59:13

English 13
Installation
Connect the water line
Install a Water Filter
The water lter and the water lter installation kit containing necessary parts illustrated
in this section are not provided. You must purchase the water lter and the water lter
installation kit at a local hardware store.
To connect to the water supply line
01
02
03
07
06 05 04
09
10
08
01 Cold water line
02 Pipe clamp
03 Plastic line
04 Compression nut
05 Compression sleeve
06 Packing nut
07 Shut off valve
08 Filter cartridge
09 Cartridge holder
10 Cut vertically by 90 degrees
1. Shut off the main water line and turn the ice maker off.
2. Locate the nearest cold potable water line.
3. Follow the instructions mentioned in the water lter installation kit.
4. After connecting the water line to the inlet of the cartridge holder with the plastic line
fully inserted, insert and tighten the lter cartridge.
5. Turn on the water line and ush 11 liters of water (approximately 6 minutes) through
the lter before use.
CAUTION
• The water line must be connected
outside of the refrigerator.
• Do not use copper lines.
• If cutting the tubing for resizing, make
sure the ends of the tubing are vertically
clean cut.
Untitled-1 13 2021-07-19  10:59:14

Installation
English14
Installation
To connect the water line to the refrigerator
01 02
04
03
01 Cartridge holder
02 Plastic clip
03 Plastic line
04 Filter cartridge
1. Connect the plastic line from the rear of the refrigerator to the outlet of the cartridge
holder until the plastic line is fully inserted.
2. Clamp both ends of the cartridge holder using the plastic clips.
3. Turn the water line on and check for leaks.
CAUTION
• Use only potable water.
• The lter cartridge is not provided. You must purchase it at a local hardware store.
• When moving the refrigerator for line connection, use caution so that you don't step on
the power cord or water line.
Untitled-1 14 2021-07-19  10:59:14

English 15
Troubleshooting
Auto Ice Maker
Symptom Possible causes Solution
The ice maker does
not produce ice.
• The freezer room is not cold
enough.
• Make sure the cold air outlet
is not clogged.
• The ice maker is turned off.
• Make sure the ice maker
is turned on. Turn on the
switch located at the top of
the refrigerator, and check if
the ice maker starts working.
• The wire connector of the
ice maker is not connected
properly.
• Make sure the wire
connector from the wire
housing is connected
properly.
• The water line owing to the
ice maker is bent or kinked.
• Make sure the water line in
the rear of the refrigerator is
not bent or kinked.
Troubleshooting
Untitled-1 15 2021-07-19  10:59:14

English16
Warranty (U.S.A)
LIMITED WARRANTY TO ORIGINAL PURCHASER
This Samsung brand ice maker, as supplied and distributed by Samsung Electronics
America, Inc. (Samsung) and delivered new, in the original carton to the original consumer
purchaser is warranted by Samsung against manufacturing defects in materials and
workmanship for a limited warranty period of:
One (1) year Parts on the ice maker.
This limited warranty begins on the original date of purchase, and is valid only on
products purchased from SAMSUNG or a SAMSUNG authorized reseller and used in the
United States. Before receiving warranty service, SAMSUNG or its agents may require that
you respond to questions designed to assist with diagnosing potential issues and follow
SAMSUNG’s procedures for obtaining warranty service. You must contact SAMSUNG at
the number provided below. Warranty service can only be performed by a SAMSUNG
authorized service center. The original dated bill of sale must be presented upon request
as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. In the event
SAMSUNG determines, in its sole discretion, that the product is eligible for warranty
service, and subject to the conditions and exceptions stated in this limited warranty,
SAMSUNG will repair or replace this product, at our option and at no charge. SAMSUNG
may, at SAMSUNG’s option, use rebuilt, reconditioned or new parts or components when
repairing the product, or may replace the product with a rebuilt, reconditioned or new
product. If return of the product is required, you must ship the product to the specied
SAMSUNG authorized service center or other address provided by SAMSUNG in its original
or equivalent packaging. You are responsible for the shipping charges. You are advised to
ship any product to SAMSUNG or its designated service center with the benet of tracking
information, as SAMSUNG is not responsible for any damage or loss to the product while in
transit. In the case of replacements, ownership of the original product, parts or components
will be transferred to SAMSUNG and SAMSUNG will not return the original product, parts or
components to you. Replacement product, parts and components assume the remainder of
the original warranty, or ninety (90) days, whichever is longer.
This limited warranty covers manufacturing defects in materials and workmanship
encountered in normal, reasonable, noncommercial use of this product and shall not apply
to the following: damage that occurs in shipment, delivery or installation; damage caused
by applications and uses for which this product is not intended or designed; damage
caused by ordinary wear and tear; product alterations or modications; products with
a serial number that has been removed, defaced, damaged, altered or made illegible;
cosmetic damage or damage to the exterior nish; damage caused by accidents, abuse,
neglect, misuse, mishandling; damage due to liquid spills; re, water, lightning, or other
acts of nature or God; damage that results from the use of products, equipment, systems,
utilities, services, parts, supplies, accessories, applications, installations, repairs, external
wiring or connectors not supplied or authorized by SAMSUNG; damage caused by
connections to incorrect or improper power supply; electrical current uctuations; power
surges; damage caused by failure to follow operating instructions or user manuals or
failure to perform preventive maintenance; product removal and reinstallation; or problems
caused by pest infestations.
SAMSUNG does not warrant uninterrupted or error-free operation of the product.
Untitled-1 16 2021-07-19  10:59:14

English 17
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED
ABOVE AND ALL OTHER WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, IS EXPRESSLY DISCLAIMED, AND NO OTHER EXPRESS WARRANTY
OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS
PRODUCT SHALL BE BINDING TO SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS
OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY
OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE
OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH
THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILTY OF
SUCH DAMAGES; NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN
AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING
THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL
RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S
PROPERTY AND TO OTHER AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR
INABILITY TO USE THIS PRODCUT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE
NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE
OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND
STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the
exclusion or limitation of incidental or consequential damages, so the above limitations or
exclusions may not apply to you. This warranty gives you specic rights, and you may also
have other rights, which vary from state to state.
To obtain warranty service, please contact SAMSUNG at:
SAMSUNG CUSTOMER CARE CENTER
Samsung Electronics America, Inc.
85 Challenger Road
Ridgeeld Park, NJ 07660
1-800-SAMSUNG (726-7864)
www.samsung.com/us/support
Untitled-1 17 2021-07-19  10:59:14

English18
Warranty Information (CANADA)
Limited Warranty for Original Purchaser
This Samsung ice maker is warranted by Samsung Electronics Canada Inc. (hereafter
referred to as SECA) against manufacturing defects in material or workmanship for the
following periods:
Parts : 1 year
SECA further warrants that if this product fails to operate properly within the specied
warranty period and the failure is due to defective material, SECA will repair or replace the
ice maker. In-home service is not available in all areas. Contact us to nd out if in-home
service is currently available in your area by using the contact information at the back of
this warranty.
All warranty repairs or replacements must be performed by a SECA Authorized Service
Center. (To nd the nearest SECA Service Center, call 1-800-SAMSUNG (7267864) or visit
our web site at www.samsung.com/ca)
Obligation to the Original Owner
The original dated sales receipt must be retained by the customer and is the only
acceptable proof of purchase. It must be presented to a SECA Authorized Service Center
at the time service is requested before warranty services are rendered. On all carry-in
models, transportation to and from the Authorized Service Center is the responsibility of
the customer.
Exclusions of the Warranty
This warranty does not cover damage due to accident, re, ood, and/or other Acts of God,
misuse, incorrect line voltage, improper installation, improper or unauthorized repairs,
commercial use, or damage that occurs during shipping. Customer adjustments which are
explained in this owners manual are not covered under the terms of this warranty. This
warranty will automatically be voided for any unit found with a missing or altered serial
number. This warranty is valid only on products purchased and used in the Canada.
SAMSUNG CUSTOMER CARE CENTER
Samsung Electronics Canada Inc.
2050 Derry Road West
Mississauga, Ontario L5N 0B9
Canada
1-800-SAMSUNG (726-7864)
www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
Untitled-1 18 2021-07-19  10:59:14

Memo
Untitled-1 19 2021-07-19  10:59:14

Scan the QR code* or visit
www.samsung.com/spsn
to view our helpful
How-to Videos and Live Show
s
* Requires reader to be installed on your
smartphone
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG Customer Care Center.
Country Contact Center Web Site
U.S.A 1-800-SAMSUNG (726-7864)
1-844-SAM-PAYS (726-7297) www.samsung.com/us/support
CANADA 1-800-SAMSUNG(726-7864)
1-844-SAM-PAYS (726-7297)
www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
DA68-03648A-04
Untitled-1 20 2021-07-19  10:59:14
