Samsung LE32A41B User manual

English-1
Viewing the Connection Panel
Whenever you connect an audio or video system to your set, ensure that all elements are
switched off.
Connecting an Aerial or Cable Television Network
To view television channels correctly, a signal must be received by the set from one of the following sources:
- An outdoor aerial
- A cable television network
- A satellite network
Connecting Set-Top Box, VCR or DVD
- Connect the CR or D D SCART cable to the SCART connector of the CR or D D.
- If you wish to connect both the Set-Top Box and CR (or D D), you should connect the Set-Top Box
to the CR (or D D) and connect the CR (or D D) to your set.
Input Output Specification
Power Input
Connector
SCART 1
SCART 2
Video Audio (L/R) S-Video R B Video+Audio (L/R)
Only T Out
Monitor Out
(T /Ext.1/Ext.2/A /S- HS)
Input Output
BN68-00751C-00Eng 7/20/04 5:20 PM Page 7

English-2
Installing VESA Com liant Mounting Devices (Sold separately)
<1> <2>
Align the mounting interface pad with the holes in the rear cover mounting pad and secure it with the four
screws that come with the arm-type base, wall mount hanger or other bases.
This T accepts a 200mmx100mm ESA-Compliant mounting interface pad.
Rear cover Mounting pad
1. Remove the 4 screws from the back of the T .
2. Separate the stand from the T .
3. Cover the botton hole with a cap.
<3>
Disconnecting the stand
BN68-00751C-00Eng 7/20/04 5:21 PM Page 54

English-3
Using the Anti-Theft Kensington Lock
1. Insert the locking device into the Kensington slot on the LCD TV (Figure 1), and turn it in the locking direction
(Figure 2).
2. Connect the Kensington lock ca le.
3. Fix the Kensington lock to a desk or a heavy stationary o ject.
The Kensington lock is a device used to physically fix the system when using it in a pu lic place.
The locking device has to e purchased separately. The appearance and locking method may differ from
the illustration depending on the manufacturer. Please refer to the manual provided with the Kensington lock for
proper use.
Figure 2
Figure 1
Ca le
<Optional>
BN68-00751C-00Eng 7/20/04 6:41 PM Page 55
