Samsung LE32N7 User manual

LCD TV
LE32N7
LE40N7
LE46N7
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
PC DISPLAY
PICTURE IN PICTURE (PIP)
TELETEXT
Register your product at www.samsung.com/global/register
BN68-01007S-01
Contact SAMSUNG WORLD-WIDE
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care centre.
Contacte con SAMSUNG WORLD-WIDE
Si tiene alguna pregunta o comentario referente a nuestros productos, por
favor contacte con nuestro Servicio de Atención al Cliente
Country
BELGIUM
CZECH REPUBLIC
DENMARK
FINLAND
FRANCE
GERMANY
HUNGARY
ITALIA
LUXEMBURG
NETHERLANDS
NORWAY
POLAND
PORTUGAL
RUSSIA
SLOVAKIA
SPAIN
SWEDEN
U.K
UKRAINE
Customer Care Center
02 201 2418
844 000 844
38 322 887
09 693 79 554
08 25 08 65 65 (€ 0,15/Min)
01805 - 121213 (€ 0,12/Min)
06 40 985 985
199 153 153
02 261 03 710
0900 20 200 88 (€ 0.10/Min)
231 627 22
0 801 801 881
80 8 200 128
8-800-200-0400
0850 123 989
902 10 11 30
08 585 367 87
0870 242 0303
8-800-502-0000
Web Site
www.samsung.com/be
www.samsung.com/cz
www.samsung.com/dk
www.samsung.com/fi
www.samsung.com/fr
www.samsung.de
www.samsung.com/hu
www.samsung.com/it
www.samsung.lu
www.samsung.com/nl
www.samsung.com/no
www.samsung.com/pl
www.samsung.com/pt
www.samsung.ru
www.samsung.com/sk
www.samsung.com/es
www.samsung.com/se
www.samsung.com/uk
www.samsung.com/ur
BN68-01007S-01Cover.indd 1BN68-01007S-01Cover.indd 1 2006-08-24  8:16:462006-08-24  8:16:46

Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen.
• Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image retention.
This image retention is also known as "screen burn".
To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image.
• Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders displayed on the left,
right and center of the screen caused by the difference of light emission on the screen.
Playing a DVD or a game console may cause a similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
• Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.
To prevent this effect, reduce the ‘brightness’ and‘contrast’ when displaying still images.
Precauciones al mostrar en la pantalla una imagen fija
La imagen fija puede causar daños permanentes en la pantalla del televisor.
• No deje una imagen fija en la pantalla LCD durante más de dos horas ya que se podría producir una retención de la imagen en la pantalla. Este
fenómeno de retención de imágenes también se denomina “quemadura de pantalla”. Para evitar que se produzca esa persistencia de la imagen,
reduzca el nivel de luminosidad y de contraste de la pantalla cuando muestre imágenes fijas.
• El uso del televisor LCD en formato 4:3 durante un tiempo prolongado puede dejar rastros de bordes en las partes izquierda,
derecha y central de la pantalla debido a las diferencias en la emisión lumínica de la pantalla.
Reproducir un DVD o una videoconsola puede causar un efecto similar en la pantalla. La garantía no cubre estos daños.
• Ver imágenes fijas de videojuegos y PC durante más tiempo del indicado puede producir imágenes fantasma parciales.
Para evitar este efecto, reduzca el ‘brillo’ y el ‘contraste’ cuando vea imágenes fijas.
© 2006 Samsung Electronics Co., Ltd. All rights reserved.
Still.indd 1Still.indd 1 2006-07-26  9:56:102006-07-26  9:56:10

English
English-1
Contents
CONNECTING AND PREPARING YOUR TV
List of Parts................................................................................... 3
Installing the Stand ................................................................... 3
Installing the Wall Mount Kit ............................................ 3
Viewing the Control Panel...................................................... 4
Viewing the Connection Panel ............................................. 5
Viewing the Remote Control ................................................. 7
Installing Batteries in the Remote Control ....................... 7
Switching On and Off............................................................... 8
Placing Your Television in Standby Mode ......................... 8
Plug & Play.................................................................................... 8
SETTING THE CHANNELS
Storing Channels Automatically........................................... 9
Storing Channels Manually .................................................... 9
Setting the Channel Manager............................................... 10
Activating the Child Lock................................................... 11
Sorting the Stored Channels ................................................. 11
Assigning Channels Names.................................................... 12
Fine Tuning Channel Reception ........................................... 12
SETTING THE PICTURE
Changing the Picture Standard............................................ 13
Adjusting the Custom Picture............................................... 13
Changing the Colour Tone ..................................................... 14
Adjusting the Color Tone with the Preferred
Color Component ...................................................................... 14
Resetting the Picture Settings to the
Factory Defaults.......................................................................... 15
Changing the Picture Size....................................................... 15
Changing the Auto Wide (4:3)............................................... 15
Freezing the Current Picture.................................................. 16
Digital Noise Reduction........................................................... 16
DNIe Demo (Digital Natural Image engine)..................... 16
Changing the Colour Space................................................... 16
Viewing the Picture In Picture (PIP)..................................... 17
SETTING THE SOUND
Changing the Sound Standard........................................ 18
Adjusting the Sound Settings.......................................... 18
Setting the TruSurround XT (SRS TSXT)........................ 18
Adjusting the Volume Automatically ............................ 19
Selecting the Internal Mute .............................................. 19
Listening to the Sound of the Sub Picture.................. 19
Resetting the Sound Settings to the
Factory Defaults .................................................................... 20
Connecting Headphones................................................... 20
Selecting the Sound Mode ...............................................20
SETTING THE TIME
Setting and Displaying the Current Time .................... 20
Setting the Sleep Timer ...................................................... 21
Switching the Television
On and Off Automatically.................................................. 21
SETTING THE OTHERS
Choosing Your Language................................................... 22
Using Game Mode................................................................ 22
Setting the Blue Screen Mode /
Selecting the Melody .........................................................23
Using the Energy Saving Feature.................................... 23
Setting the Blue Eye............................................................. 23
Selecting the Source............................................................ 24
Editing the Input Source Names..................................... 24
BN68-01007S-00Eng.indd 1BN68-01007S-00Eng.indd 1 2006-08-08  7:53:442006-08-08  7:53:44

English-2
WISELINK
Using the WISELINK Function........................................... 25
Using the WISELINK Menu................................................. 26
Using the PHOTO (JPEG) List ............................................ 26
Viewing Photo File Information....................................... 28
Selecting a Photo and Slide Show.................................. 28
Rotating.................................................................................... 29
Zooming-in ............................................................................. 30
Copying Image Files ............................................................ 31
Deleting Image Files............................................................ 31
Printing a Photo .................................................................... 32
Using the MP3 List................................................................ 32
Copying Music Files ............................................................. 33
Deleting Music Files............................................................. 33
Using the Setup Menu........................................................ 34
USING THE DTV FEATURE
Previewing the DTV Menu System...................................... 35
Basic Functions ........................................................................... 36
1. Display Screen ........................................................................ 36
2. Volume Control ...................................................................... 36
3. Select Soundtrack ................................................................. 36
4. Select Videotrack................................................................... 36
5. Service List ............................................................................... 37
6. Program Information ........................................................... 37
Operating the DTV Menu........................................................ 38
Main Menu ................................................................................... 38
1. Installation ............................................................................... 38
1.1 Select Country...................................................................... 38
1.2 Auto Scanning...................................................................... 38
1.3 Manual Scanning ................................................................ 39
1.4 Reset to Factory Defaults ................................................. 39
2. Channel Organising.............................................................. 39
2.1 Delete Frequency................................................................ 40
2.2 Delete Channel.................................................................... 40
2.3 Delete All Channels............................................................ 40
2.4 Move & Edit Channel......................................................... 40
3. Parental Lock........................................................................... 41
3.1 Set Channel Lock ................................................................ 41
3.2 Change PIN Code................................................................ 41
4. System Setup.......................................................................... 42
4.1 Language Selection ........................................................... 42
4.2 OSD Setting........................................................................... 42
4.3 Time Setting.......................................................................... 42
4.4 System Information............................................................ 43
4.5 Software Upgrade............................................................... 43
Installing the CI card................................................................. 43
USING THE TELETEXT FEATURE
Teletext Decoder................................................................... 44
Displaying the Teletext Information .............................. 44
Selecting a Specific Teletext Page .................................. 45
Using Fastext to Select a Teletext Page........................ 45
Setting Up Your Remote Control..................................... 46
Remote Control Codes........................................................ 48
SETTING THE PC
Setting up Your PC Software
(Based on Windows XP)...................................................... 51
Display Modes........................................................................ 51
Setting the PC ........................................................................ 52
RECOMMENDATIONS FOR USE
Using the Anti-Theft Kensington Lock.......................... 53
Troubleshooting:
Before Contacting Service Personnel............................ 53
Technical and Environmental Specifications ............. 54
Symbol Press Important Note One-Touch
Button
BN68-01007S-00Eng.indd 2BN68-01007S-00Eng.indd 2 2006-08-08  7:53:492006-08-08  7:53:49

English-3
List of Parts
Please make sure the following items are included with your LCD TV.
If any items are missing, contact your dealer.
Remote Control &
Batteries (AAA x 2) Power Cord Cover-Bottom Stand Screw X 4 Stand Cleaning Cloth
Owner’s Instructions Warranty card Safety Guide Registration Cards
Wall mount items (sold separately) allow you to mount the TV on the
wall.
For detailed information on installing the wall mount, see the
instructions provided with the Wall Mount items. Contact a
technician for assistance when installing the wall mounted bracket.
Samsung Electronics is not responsible for any damage to the
product or injury to yourself or others
if you elect to install the TV on your own.
Remove the stand and cover the bottom hole with a cap and
fasten with two screws.
Installing the Wall Mount Kit
< 2><3>
1. Place the TV faced down on a soft cloth or cushion on a table.
2. Put the stand into the hole at the bottom of the TV.
3. Insert screw into the hole indicated and tighten.
The stand is installed for models with the screen size of 40 inch and above.
Installing the Stand
Warranty card / Safety Guide / Registration Cards (Not available in all locations)
The stand and stand screw may not be included depending on the model.
M4 X L16
BN68-01007S-00Eng.indd 3BN68-01007S-00Eng.indd 3 2006-08-08  7:53:492006-08-08  7:53:49

English-4
Viewing the Control Panel
SOURCE
Toggles between all the available input sources
(TV, Ext.1, Ext.2, AV, S-Video, Component, PC, HDMI1, HDMI2,
DTV). In the on-screen menu, use this button as you use the
ENTER button on the remote control.
MENU
Press to see an on-screen menu of your TV’s features.
Press to decrease or increase the volume.
In the on-screen menu, use the buttons
as you use the and buttons on the remote control.
Press to change channels.
In the on-screen menu, use the buttons
as you use the and buttons on the remote
control. (Without the Remote Control, you can turn
on the TV by using the Channel buttons.)
Speakers
( Power)
Press to turn the TV on and off.
Power Indicator
Blinks and turns off when the power is on and lights
up in stand-by mode.
Remote Control Sensor
Aim the remote control towards this spot on the TV.
The product colour and shape may vary depending on the model.
BN68-01007S-00Eng.indd 4BN68-01007S-00Eng.indd 4 2006-08-08  7:53:512006-08-08  7:53:51

English-5
Viewing the Connection Panel
Power Input
Whenever you connect an external device to your TV, make sure that power on the unit is turned off.
When connecting an external device, match the colour of the connection terminal to the cable.
[Side Panel Jacks][Rear Panel Jacks]
Connecting an Aerial or Cable Television Network
To view television channels correctly, a signal must be received by the set from one of the following sources:
- An outdoor aerial / A cable television network / A satellite network
Connecting HDMI/DVI
- Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players, AV receivers and digital TVs).
- No additional Audio connection is needed for an HDMI to HDMI connection.
What is HDMI?
- “High Definition Multimedia Interface” allows the transmission of high definition digital video data and multiple
channels of digital audio ( 5.1 channels).
- The HDMI/DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied).
The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP
(High Bandwidth Digital Copy Protection) coding feature installed, and supports multi - channel digital audio.
You should use the DVI-to-HDMI cable or DVI-HDMI Adapter for the connection, and the “R - AUDIO - L” terminal on DVI for
sound output.
- When connecting this product via HDMI or DVI to a Set Top Box, DVD Player or Games Console etc, make sure that
it has been set to a compatible video output mode as shown in the table below.
Failure to observe this may result in picture distortion, image breakup or no picture.
Supported modes for DVI or HDMI
- Do not attempt to connect the HDMI/DVI connector to a PC or Laptop Graphics Card.
(This will result in a blank screen being displayed)
50 Hz
60 Hz
Component
480i
X
X
O
480p
O
O
O
576i
X
X
O
576p
O
X
O
720p
O
O
O
1080i
O
O
O
BN68-01007S-00Eng.indd 5BN68-01007S-00Eng.indd 5 2006-08-08  7:53:522006-08-08  7:53:52

English-6
Connecting Set-Top Box, VCR or DVD
- Connect the VCR or DVD SCART cable to the SCART connector of the VCR or DVD.
- If you wish to connect both the Set-Top Box and VCR (or DVD), you should connect the Set-Top Box to the VCR (or DVD) and connect
the VCR (or DVD) to your set.
Connecting External A/V Devices
- Connect RCA or S-VIDEO cable to an appropriate external A/V device such as VCR, DVD or Camcorder.
- Connect RCA audio cables to “R - AUDIO - L” on the rear of your set and the other ends to corresponding audio out connectors
on the A/V device.
- Headphone may be connected to the headphone output ( ) on the rear of your set.
While the headphone is connected, the sound from the built-in speakers will be disabled.
SERVICE
- Service connection for qualified service engineer.
Connecting AUDIO
- Connect RCA audio cables to “R - AUDIO - L” on the rear of your set and the other ends to corresponding audio in
connectors on the Amplifier or DVD Home Theater.
Connecting Computer
- Connect the D- Sub cable (optional) to “PC (PC IN)” on the rear of your set and the other end to the Video Card of your computer.
- Connect the stereo audio cable (optional) to “AUDIO (PC IN)” on the rear of your set and the other end to “Audio Out” of the
sound card on your computer.
Connecting Component Devices (DTV/DVD)
- Connect component video cables (optional) to component connector (“PR”, “PB”, “Y”) on the rear of your set and the other
ends to corresponding component video out connectors on the DTV or DVD.
- If you wish to connect both the Set-Top Box and DTV (or DVD), you should connect the Set-Top Box to the DTV (or DVD)
and connect the DTV (or DVD) to component connector (“PR”, “PB”, “Y”) on your set.
-
The PR, PB and Y connectors on your component devices (DTV or DVD) are sometimes labeled Y, B-Y and R-Y or Y, Cb and Cr.
- Connect RCA audio cables (optional) to “R - AUDIO - L” on the rear of your set and the other ends to corresponding audio
out connectors on the DTV or DVD.
- This LCD TV displays its optimum picture resolution in 720p mode.
- This LCD TV displays its maximum picture resolution in 1080i mode.
Kensington Lock
- The Kensington lock (optional) is a device used to physically fix the system when used in a public place.
- If you want to use a locking device, contact the dealer where you purchased the TV.
- The place of the Kensington Lock may be different depending on its model.
DIGITAL AUDIO OUT (OPTICAL)
- Connect to a Digital Audio Component.
Connecting CI (Common Interface) CARD
- When not inserting "CI CARD" in some channels,
"Scrambled Signal" is displayed on the screen.
- The pairing information containing a telephone number,
CI CARD ID, Host ID, and other information will be
displayed
in about 2~3 minutes. If an error message is displayed,
please contact your service provider.
- When the channel information configuration has finished,
the message "Updating Completed" is displayed,
indicating that the channel list is now updated.
You must obtain a CI CARD from a local cable service provider.
Remove the CI CARD by carefully pulling it out with your
hands since dropping the CI CARD may cause damage to it.
Service Port
- Service connection for qualified service engineer.
Please insert
the card as
shown
CI CARD
TV Rear Panel
BN68-01007S-00Eng.indd 6BN68-01007S-00Eng.indd 6 2006-08-08  7:53:532006-08-08  7:53:53

English-7
1. Lift the cover at the back of the remote control upward as shown in the figure.
2. Install two AAA size batteries.
Make sure to match the “+” and “–” ends of the batteries with the diagram inside the compartment.
3. Replace the cover.
Remove the batteries and store them in a cool, dry place if you won’t be using the remote control
for a long time. The remote control can be used up to about 23 feet from the TV.
(Assuming typical TV usage, the batteries last for about one year.)
If the remote control doesn’t work, check the following:
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power outage, or is the power cord unplugged?
5. Is there a special fluorescent light or neon sign nearby?
Installing Batteries in the Remote Control
The performance of the remote control may be affected by bright light.
This is a special remote control for the visually impaired, and has Braille points
on the Power, Channel and Volume buttons.
Viewing the Remote Control
Selects a target device to be controlled by
the Samsung remote control
(TV, DVD, STB, CABLE, VCR)
(Refer to page 46~50)
Television Standby button
Number buttons for direct channel access
One/Two-digit channel selection
It displays "Channel Manager" on the screen.
Selects the TV and DTV mode directly
VCR/DVD Functions Rewind, Stop,
Play/Pause, Fast/Forward
Volume increase
Volume decrease
Temporary sound switch-off
Menu display and change confirmation
Electronic Program Guide (EPG) display
Picture-In-Picture On / Off
Not available
Sound effect selection
This key is also used to back to the
previous page in D.MENU.
SET: Adjusts 5 separate devices - TV, DVD,
STB, CABLE, or VCR.
RESET: When your remote does not work,
change the batteries and press the “RESET”
button for 2-3 seconds before use.
When pressing this button, a number of
buttons on the remote control (e.g.
Selects a target device, volume, channel
and MUTE buttons) light up for a few
seconds and then turn off to save power.
This function is to conveniently use the
remote control at night or when dark.
Available source selection
Previous channel
DTV menu display
This function enables you to load saved
photo (JPEG) and audio files (MP3) and to
view or play them on the TV.
P: Next channel
P : Previous channel
Exit the OSD
Control the cursor in the menu
Use to see information on the current
broadcast
Toggle between the TV and Radio channel
Not available
Picture freeze
Select the soundtrack/videotrack
list for the current service
Teletext Functions
Exit from the teletext display
Teletext index
Teletext hold
Teletext size selection
Teletext mode selection (LIST/FLOF)
Teletext sub page
P: Teletext next page
P : Teletext previous page
Teletext cancel
Teletext reveal
Alternately select Teletext, Double, or Mix.
Fastext topic selection
Teletext store
BN68-01007S-00Eng.indd 7BN68-01007S-00Eng.indd 7 2006-08-08  7:53:542006-08-08  7:53:54

English-8
Switching On and Off
Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when you wish
to interrupt viewing temporarily (during a meal, for example).
1. Press the POWER button on the remote control.
The screen is turned off and a red standby indicator appears on the front of your set.
2.
To switch your set back on, simply press the POWER , numeric buttons (0~9) or channel up/down ( /) button again.
Do not leave your set in standby mode for long periods of time (when you are away on holiday, for example).
It is best to unplug the set from the mains and aerial.
Placing Your Television in Standby Mode
The mains lead is attached to the rear of your set.
1. Plug the mains lead into an appropriate socket.
The standby indicator lights up on the front of the set.
2. Press the button on the front of the set.
You also can press the POWER button or the TV/DTV button on the remote control to turn the TV on.
The programme that you were watching last is reselected automatically.
3. Press the numeric button (0~9) or channel up/down ( /) button on the remote control or
button on the right side of the set.
When you switch the set on for the very first time, you will be asked to choose language in which the menus are to be
displayed.
4. To switch your set off, press the POWER button again.
When the TV is initially powered on, several basic settings proceed automatically and
subsequently. The following settings are available.
1. Press the POWER button on the remote control.
The message “Iniciar Plug & Play” is displayed with “Aceptar” selected.
2. Select the appropriate language by pressing the or button.
Press the ENTER button to confirm your choice.
3. The message “Check antenna input.” is displayed with “OK” selected.
Press the ENTER button.
Please check that the antenna cable is connected correctly.
4. Select the appropriate country by pressing the or button.
Press the ENTER button to confirm your choice.
5. The “Auto Store” menu is displayed with the “Start” selected.
Press the ENTER button.
The channel search will start and end automatically.
After all the available channels are stored, the “Clock Set” menu appears.
Press the ENTER button at any time to interrupt the memorization process.
6. Press the ENTER button.
Select the “Hour” or “Minute” by pressing the or button.
Set the “Hour” or “Minute” by pressing the or button.
You can also set the hour and minute by pressing the number buttons on the remote control.
7. Press the ENTER button to confirm your setting.
The DTV channel scan menu appears and the DTV channel is automatically updated.
If the DTV channel is updated, the Source in the source list of the Input menu is
automatically changed to DTV.
For detailed descriptions about DTV channel update, refer to page 43 of this manual.
Plug & Play
Language: Select your language.
Country: Select your country.
Auto Store:
Automatically scans for and stores channels available in the local area.
Clock Set: Sets the current time for the TV clock.
BN68-01007S-00Eng.indd 8BN68-01007S-00Eng.indd 8 2006-08-08  7:53:572006-08-08  7:53:57

English-9
You can store up to 100 channels, including those received via cable networks.
When storing channels manually, you can choose:
Whether or not to store each of the channels found.
The programme number of each stored channel which you wish to identify.
1. Press the MENU button to display the menu.
Press the or button to select “Channel”, then press the ENTER button.
2. Press the or button to select “Manual Store”, then press the ENTER button.
3. Press the ENTER button to select “Programme”.
4. To assign a programme number to a channel, find the correct number by pressing the or button and
then press the ENTER button.
You can also set a programme number by pressing the number buttons on the remote control.
Storing Channels Manually
- Storing Channels Automatically
- Storing Channels Manually
If you want to reset this feature...
1. Press the MENU button to display the menu.
Press the or  button to select “Setup”, then press the ENTER button.
2. Press the ENTER button again, to select “Plug & Play”.
3. The message “Start Plug & Play” is displayed.
You can scan for the frequency ranges available to you (and availability depends on your country).
Automatically allocated programme numbers may not correspond to actual or desired programme numbers.
However, you can sort numbers manually and clear any channels you do not wish to watch.
1. Press the MENU button to display the menu.
Press the or button to select “Channel”, then press the ENTER button.
2. Press the ENTER button to select “Country”.
3. Select the appropriate country by pressing the or button.
Press the ENTER button to confirm your choice.
4. Press the or button to select “Auto Store”, then press the ENTER button.
5. Press the ENTER button.
The TV will begin memorizing all of the available channels.
Press the ENTER button at any time to interrupt the memorization process and return to the “Channel” menu.
6. After all the available channels are stored, the “Sort” menu appears.
Storing Channels Automatically
BN68-01007S-00Eng.indd 9BN68-01007S-00Eng.indd 9 2006-08-08  7:53:582006-08-08  7:53:58

English-10
Programme: Selects a program number for the channel.
Colour System: Sets the colour supporting system.
Sound System: Sets the sound supporting system.
Channel: Selects a channel.
Search: Scans for the frequency value for the channel.
Store: Saves your settings.
Set the channels according to your preference.
You can easily delete, add, or lock the channel you want.
1. Press the MENU button to display the menu.
Press the or button to select “Channel”, then press the ENTER button.
2. Press the or button to select “Channel Manager”, then press the ENTER button.
3. Press the ENTER button again, to select “Channel Manager”.
4. Press the button to select “ ” line.
5. Press the or button to select the undesired channel, then press the
ENTER button to cancel.
6. Repeat steps 5for each channel to be selected or canceled
7. Press the EXIT button to exit.
“ ” is active when “Child Lock” is selected to “On”.
Setting the Channel Manager
` You can select these options
by simply pressing the
CH MGR button on the remote
control.
5. Press the or button to select “Colour System”, then press the ENTER button.
6. Select the colour standard required by pressing the or button then, press the ENTER button.
7. Press the or button to select “Sound System”, then press the ENTER button.
8. Select the sound standard required by pressing the or button, then press the ENTER button.
If there is an abnormal sound or no sound, re-select the sound system required.
9. If you know the number of the channel to be stored, press the or button to select “Channel”.
Press the ENTER button.
Select C(Air channel) or S(Cable channel) by pressing the or button. Press the  button to select channel.
Select the required number by pressing the or button and then press the ENTER button.
Channel mode: P (Programme mode), C (Air channel mode), S (Cable channel mode)
You can also set a channel number by pressing number buttons on the remote control.
10. If you do not know the channel numbers, press the or button to select “Search”.
Press the ENTER button. Search by pressing the or button and then press the ENTER button.
11. Press the or button to select “Store”. Press the ENTER button to select “OK”.
12. Repeat steps 3to 11 for each channel to be stored.
BN68-01007S-00Eng.indd 10BN68-01007S-00Eng.indd 10 2006-08-08  7:53:592006-08-08  7:53:59

English-11
You can exchange the numbers of two channels, in order to:
Modify the numeric order in which the channels have been
automatically stored.
Give easily remembered numbers to the channels that you watch most often.
1. Press the MENU button to display the menu.
Press the or button to select “Channel”, then press the ENTER button.
2.
Press the or button to select “Sort”, then press the ENTER button.
3. Select channel number that you wish to change by pressing the or button
repeatedly. Press the ENTER button.
The selected channel number and name are moved to right side.
4.
Press the or  button to move to the position in which you would like to change and then
press the ENTER button.
The selected channel is exchanged with the one previously stored to the chosen number.
5. Repeat steps 3to 4for another channel to be sorted.
6. Press the EXIT button to exit.
Sorting the Stored Channels
This feature allows you to prevent unauthorized users, such as children, from watching
unsuitable programmes by muting out video and audio. Child Lock cannot be released using
the buttons on the side.
Only the remote control can release the Child Lock setting, so keep the remote control away
from children.
1. Press the MENU button to display the menu.
Press the or button to select “Channel”, then press the ENTER button.
2. Press the or button to select “Channel Manager”, then press the ENTER button.
3. Press the or button to select “Child Lock”, then press the ENTER button.
4.
Press the or button to select “On”.
Press the ENTER button.
5. Press the or button to select “Channel Manager”,then press the ENTER button.
6. Press the button to select “ ” line.
7. Press the or button to select the channels you want to lock, then
press the ENTER button.
8. Repeat steps 7for each channel to be locked or unlocked.
9. Press the EXIT button to exit.
Select “On” or “Off” in “Child Lock” to easily turn the channels which
selected on
“”to be active or inactive.
Activating the Child Lock
BN68-01007S-00Eng.indd 11BN68-01007S-00Eng.indd 11 2006-08-08  7:54:002006-08-08  7:54:00

English-12
Use fine tuning to manually adjust a particular channel for optimal reception.
1. Use the number buttons to directly select the channel that you want to fine tune.
2. Press the MENU button to display the menu.
Press the or button to select “Channel”, then press the ENTER button.
3. Press the or button to select “Fine Tune”, then press the ENTER button.
4. Press the or button to adjust the fine tuning.
Press the ENTER button.
5. Press the EXIT button to exit.
Fine tuned channels that have been saved are marked with an asterisk “*” on the right-
hand side of the channel number in the channel banner. And the channel number turns red.
To reset the fine-tuning, select “Reset” by pressing the or button and then press the
ENTER button.
Fine Tuning Channel Reception
Channel names will be assigned automatically when channel information is broadcast.
These names can be changed, allowing you to assign new names.
1. Press the MENU button to display the menu.
Press the or button to select “Channel”, then press the ENTER button.
2.
Press the or button to select “Name”, then press the ENTER button.
3. If necessary, select the channel to be assigned to a new name by
pressing the or  button. Press the ENTER button.
The selection bar is displayed around the name box.
4.
The characters available are :
Letters of the alphabet (A~Z) / Numbers (0~9) / Special characters (
-
, space)
5. Repeat steps 3to 4for each channel to be assigned to a new name.
6. Press the EXIT button to exit.
Assigning Channels Names
To...
Select a letter, number or symbol
Move on the next letter
Move back the previous letter
Confirm the name
Then...
Press the
or  button
Press the
 button
Press the
 button
Press the ENTER button
BN68-01007S-00Eng.indd 12BN68-01007S-00Eng.indd 12 2006-08-08  7:54:012006-08-08  7:54:01

English-13
You can select the type of picture which best corresponds to your viewing requirements.
1. Press the MENU button to display the menu.
Press the or button to select “Picture”, then press the ENTER button.
2. Press the ENTER button again, to select “Mode”.
Press the ENTER button again.
3.
Press the or  button to select the desired picture effect.
Press the ENTER button.
4. Press the EXIT button to exit.
Dynamic: Selects the picture for high-definition in a bright room.
Standard: Selects the picture for optimum display in a normal environment.
Movie: Selects the picture for comfortable display in a dark room.
Custom: Select to view your favorite display settings.
(Refer to “Adjusting the Custom Picture”)
The Picture mode must be adjusted separately for each input source.
You can return to the factory defaults picture settings by selecting the “Reset”.
(Refer to “Resetting the Picture Settings to the Factory Defaults” on page 15)
Changing the Picture Standard
Contrast: Adjusts the lightness and darkness between objects and the background.
Brightness: Adjusts the brightness of the whole screen.
Sharpness: Adjusts the outline of objects to either sharpen them or make them more dull.
Colour: Adjusts the colours, making them lighter or darker.
Tint (NTSC only): Adjusts the colour of objects, making them more red or green for a more natural look.
Your set has several settings which allow you to control picture quality.
1. To select the desired picture effect, follow the “Changing the Picture Standard”
instructions number 1 to 3.
2. Press the or button to select a particular item.
Press the ENTER button.
3. Press the or button to decrease or increase the value of a particular item.
Press the ENTER button.
4. Press the EXIT button to exit.
Adjusting the Custom Picture
The adjusted values are stored according to the selected Picture mode.
In PC Mode, Only “Contrast”, “Brightness” and “Colour” can be adjusted
BN68-01007S-00Eng.indd 13BN68-01007S-00Eng.indd 13 2006-08-08  7:54:022006-08-08  7:54:02

English-14
The adjusted values are stored according to the selected Picture mode.
You can select the most comfortable colour tone to your eyes.
1. To select the desired picture effect, follow the “Changing the Picture Standard”
instructions number 1 to 3 on page 13.
2.
Press the or button to select “Colour Tone”, then press the ENTER button.
3. Press the or button to select the desired colour tone setting.
Press the ENTER button.
4. Press the EXIT button to exit.
Changing the Colour Tone
Cool2: Makes the colour temperature bluer
than “Cool1” menu.
Cool1: Makes whites bluish.
Normal: Keeps whites white.
Warm1: Makes whites reddish.
Warm2: Makes the colour temperature
redder than “Warm1” menu.
You can adjust a picture’s color tone with your preferred color component.
1. To select the desired picture effect, follow the “Changing the Picture Standard”
instructions number 1 to 3 on page 13.
2.
Press the or button to select “Colour Manager”,
then press the ENTER button.
3. Press the or button to select a particular item.
Press the ENTER button.
4. Press the or button to decrease or increase the value of a
particular item. Press the ENTER button.
5. Press the EXIT button to exit.
Adjusting the Color Tone with the Preferred Color Component
R Contrast: Lightens or intensifies the red component of the border between
objects and the background.
G Contrast: Lightens or intensifies the green component of the border between
objects and the background.
B Contrast: Lightens or intensifies the blue component of the border between
objects and the background.
R Brightness: Adjusts the brightness of the red component for the entire screen.
G Brightness: Adjusts the brightness of the green component for the entire screen.
B Brightness: Adjusts the brightness of the blue component for the entire screen.
Reset: Resets all settings to the defaults.
You cannot select a "Colour Tone" in the "Colour Manager".
BN68-01007S-00Eng.indd 14BN68-01007S-00Eng.indd 14 2006-08-08  7:54:032006-08-08  7:54:03

English-15
Auto Wide: Automatically adjusts the picture size to the "16:9" aspect ratio.
16:9: Adjusts the picture size to 16:9 appropriate for DVDs or wide broadcasting.
WIDE 4:3 : Magnify the size of the picture more than 4:3.
Zoom: Magnifies the 16:9 wide picture (in the vertical direction) to fit the screen size.
4:3: This is the default setting for a video movie or normal broadcasting.
You can select the picture size which best corresponds to your viewing requirements.
1. Press the MENU button to display the menu.
Press the or button to select “Picture”, then press the ENTER button.
2. Press the or button to select “Size”, then press the ENTER button.
3. Select the required option by pressing the or button.
Press the ENTER button.
4. Press the EXIT button to exit.
Changing the Picture Size
You can return to the factory defaults picture settings.
1. To select the desired picture effect, follow the “Changing the Picture Standard”
instructions number 1 to 3 on page 13.
2. Press the or button to select “Reset”, then press the ENTER button.
3. Press the EXIT button to exit.
The “Reset” will be set for each picture mode.
Resetting the Picture Settings to the Factory Defaults
“Auto Wide” function is available only in "TV", "Ext.1", "Ext.2", "AV", "S-Video" and "DTV"
mode.
In PC Mode, only “16:9” and “4:3” mode can be adjusted.
Zoom : Select by pressing the or buttons. Use the or button to move the
picture up and down. After selecting , use the or button to magnify or
reduce the picture size in the vertical direction.
WIDE 4:3 : Move the screen up/down using the or button after selecting the
by pressing the or ENTER button.
The Zoom mode cannot be selected in the DTV mode.
Ajusts the display picture size to 4:3 appropriate for input signal
1. Press the MENU button to display the menu.
Press the or button to select “Picture”, then press the ENTER button.
2. Press the or button to select “Auto Wide (4:3)”, then press the ENTER button.
3. Select the required option by pressing the or button.
Press the ENTER button.
4. Press the EXIT button to exit.
These functions don’t work in "Component", "HDMI1", "HDMI2" and "PC" mode.
The Zoom mode cannot be selected in the DTV mode.
Changing the Auto Wide (4:3)
16:9: Adjusts the picture size to 16:9 appropriate for DVDs or wide broadcasting.
WIDE 4:3 : Magnify the size of the picture more than 4:3.
Zoom: Magnifies the 16:9 wide picture (in the vertical direction) to fit the screen size.
4:3: This is the default setting for a video movie or normal broadcasting.
BN68-01007S-01Eng.indd 15BN68-01007S-01Eng.indd 15 2006-08-24  3:12:402006-08-24  3:12:40

English-16
If the broadcast signal received by your TV is weak, you can activate the Digital Noise
Reduction feature to help reduce any static and ghosting that may appear on the screen.
1. Press the MENU button to display the menu.
Press the or button to select “Picture”, then press the ENTER button.
2. Press the or button to select “Digital NR”, then press the ENTER button.
3. Press the or button to select “On” or “Off”.
Press the ENTER button.
4. Press the EXIT button to exit.
Digital Noise Reduction
Samsung’s new technology brings you more detailed images with contrast and white
enhancement. A new image compensation algorithm gives viewers brighter and clearer
images. DNIe technology will match every signal to your eyes. You can see how DNIe
improves the picture by setting DNIe Demo mode to On.
1. Press the MENU button to display the menu.
Press the or button to select “Picture”, then press the ENTER button.
2. Press the or button to select “DNIe Demo”, then press the ENTER button.
3. Press the or button to select “On” or “Off”.
Press the ENTER button.
4. Press the EXIT button to exit.
These functions don’t work in PC mode.
The DNle Demo is designed to show the difference between the regular and DNIe pictures.
By default, the product displays the picture with DNle applied.
DNIe Demo (Digital Natural Image engine)
Press the STILL button to freeze a moving picture into a still one.
Press again to cancel.
Freezing the Current Picture
Colour space is a colour matrix composed of red, green, and blue colours.
Select your favorite colour space and experience the world of natural colour.
1. Press the MENU button to display the menu.
Press the or button to select “Picture”, then press the ENTER button.
2. Press the or button to select “Colour Space”, then press the ENTER button.
3.
Press the or button to select “Wide” or “Auto”.
Press the ENTER button.
4. Press the EXIT button to exit.
Changing the Colour Space
Wide : Wide Colour Space offers deep and rich colour tone.
Auto : Auto Colour Space automatically adjusts to natural colour tone based on program
sources.
BN68-01007S-00Eng.indd 16BN68-01007S-00Eng.indd 16 2006-08-08  7:54:052006-08-08  7:54:05

English-17
You can display a sub picture within the main picture of set
programme or video input. In this way, you can watch the picture of set programme or video
input from any connected equipment while watching the main picture.
1. Press the MENU button to display the menu.
Press the or button to select “Picture”, then press the ENTER button.
2. Press the or button to select “PIP”, then press the ENTER button.
3. Press the ENTER button again.
Press the or button to select “On”, then press ENTER button.
If the PIP is activated, the size of the main picture turns to “16:9”.
4. Press the or button to select “Source”, then press ENTER button.
Select a source of the sub picture by pressing the or button and press the
ENTER button.
The sub picture can serve different source selections based on what the main picture
is set to.
5. Press the or button to select “Swap”.
To interchange the main picture and the sub picture, select “Swap” option and press the
ENTER button.
The main picture and the sub picture are interchanged.
If main picture is in “PC” mode, “Swap” is not available.
6. Press the or button to select “Size” of the sub picture and then press the
ENTER button. Select a size of the sub picture by pressing the or button and
then press the ENTER button.
If main picture is in “PC” mode, “Size” is not available.
7. Press the or button to select “Position”, then press the ENTER button.
Select the position of the sub picture by pressing the or button and then press the
ENTER button.
8. Press the or button to select “Programme” and then press the ENTER button.
You can select the channel that you want to view through sub picture by pressing
the or button. Press the ENTER button.
The “Programme” can be active when the sub picture is set to TV.
9. Press the EXIT button to exit.
You may notice that the picture in the PIP window becomes slightly unnatural when you
use the main screen to view a game or karaoke.
Viewing the Picture In Picture (PIP)
Press the PIP button on the
remote control repeatedly to
activate or deactivate the “PIP”.
Source: Used to select a source of the sub
picture.
Swap: Used to interchange the main
picture and the sub picture.
Size: Used to select a size of the sub picture.
Position: Used to move the sub picture.
Programme: Used to Change the sub picture.
PIP Settings
(O: PIP operates, X: PIP doesn’t operate)
TV
Ext.1
Ext.2
AV
S-Video
Component
PC
HDMI1
HDMI2
DTV
TV
X
X
X
X
X
X
O
O
O
X
Ext.1
X
X
X
X
X
X
O
O
O
X
Ext.2
X
X
X
X
X
X
O
O
O
X
AV
X
X
X
X
X
X
O
O
O
X
S-Video
X
X
X
X
X
X
X
O
O
X
Component
X
X
X
X
X
X
X
O
O
X
PC
X
X
X
X
X
X
X
X
X
X
HDMI1
O
O
O
O
O
O
X
X
X
X
HDMI2
O
O
O
O
O
O
X
X
X
X
DTV
X
X
X
X
X
X
X
X
X
X
Sub
Main
BN68-01007S-00Eng.indd 17BN68-01007S-00Eng.indd 17 2006-08-08  7:54:062006-08-08  7:54:06

English-18
You can select the type of the special sound effect to be used when watching a given
broadcast.
1. Press the MENU button to display the menu.
Press the or button to select “Sound”, then press the ENTER button.
2. Press the ENTER button again, to select “Mode”.
3. Select the required sound effect by pressing the or button repeatedly and then
press the ENTER button.
4. Press the EXIT button to exit.
Standard: Selects the normal sound mode.
Music: Emphasizes music over voices.
Movie: Provides live and full sound for movies.
Speech: Emphasizes voices over other sounds.
Custom: Selects your custom sound settings.
(Refer to “Adjusting the Sound Settings”)
Changing the Sound Standard
The sound settings can be adjusted to suit your personal preferences.
1. Press the MENU button to display the menu.
Press the or button to select “Sound”, then press the ENTER button.
2. Press the or button to select “Equalizer”, then press the ENTER button.
3. Press the or button to select a particular item.
Press the ENTER button.
4. Press the or  button to reach the required setting.
Press the ENTER button.
5. Press the EXIT button to exit.
If you make any changes to these settings, the Sound Mode is automatically switched to
“Custom”.
Adjusting the Sound Settings
TruSurround XT is a patented SRS technology that solves the problem of playing 5.1
multichannel content over two speakers.
TruSurround delivers a compelling,virtual surround sound experience through any two-
speaker playback systems, including internal television speakers. It is fully compatible with
all multichannel formats.
1. Press the MENU button to display the menu.
Press the or button to select “Sound”, then press the ENTERbutton.
2. Press the or button to select “SRS TSXT”, then press the ENTER button.
3.
Press the or button to select “On” or “Off”. Press the ENTER button.
4. Press the EXIT button to exit.
Setting the TruSurround XT (SRS TSXT)
TruSurround XT, SRS and symbol are trademarks of
SRS Labs, Inc. TruSurround XT technology is incorporated under license
from SRS Labs, Inc.
