Samsung LW46G15W User manual

LCD TV
LW46G15W
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
PICTURE INPICTURE (PIP)
TELETEXT
This dvice is a class B digital apparatus.
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 1

English - 2
Precautions When Using the Still Image
• Digital Ready TV: When you select
the regular screen (4:3) mode to
watch an SD-grade digital
broadcast (and the set-top box
output is 480p).
Although digital broadcasting must be in
the wide screen (16:9) HD format,
broadcasters sometimes show programs
made originally in the regular screen
format (4:3) by converting the signals into
digital form, in which case the left and
right side edges of the screen are
cropped.
Do not leave the screen in pause mode
for extended periods of time as you may
experience the same problem with
products by other manufacturers.
Note : If the borders at the left, right and
the center of the screen remain
fixed for an extended period of time,
the amounts of light transmission
will also remain varied and as a
result the borders may leave traces.
• Digital Ready TV: When you select
the wide screen (16:9) mode to
watch an SD-grade digital
broadcast (and the set-top box
output is 1080i).
• Digital Ready TV: When the
TV receives HD-grade signals
(and the set-top box output is 1080i).
When you watch a digital HD-grade
broadcast on a regular (4:3) TV with the
screen size “16:9” or “Panorama” selected,
you will be able to watch the program but
the top and bottom edges of the screen will
be cropped.
Do not leave the screen in pause mode
for extended periods of time as you may
experience the same problem with
products by other manufacturers.
Note : If the borders at the top, bottom
and the center of the screen remain
fixed for an extended period of time,
the amounts of light transmission
will also remain varied and as a
result the borders may leave traces.
The still image may cause permanent damage to the TV screen.
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 2

English - 3
Precautions When Using the Still Image (continued)
• Integrated Digital TV
(Wide-screen): When the TV
receives SD-grade (regular)
broadcasting signals (receives
480p regular signals).
• Digital Ready TV (wide-screen):
digital TV: When the TV receives
SD-grade (regular) broadcasting
signals (with a set-top box).
• When you watch an analogue
(regular) broadcast on a
wide-screen TV (with the 4:3
screen mode selected).
Although digital broadcasting must be in
the wide screen (16:9) HD format,
broadcasters sometimes show programs
made originally in the regular screen
format (4:3) by converting the signals into
digital form, in which case the left and
right side edges of the screen are
cropped.
Do not leave the screen in pause mode
for extended periods of time as you may
experience the same problem with
products by other manufacturers.
Note : If the borders at the left, right and
the center of the screen remain
fixed for an extended period of time,
the amounts of light transmission
will also remain varied and as a
result the borders may leave traces.
• When you watch a DVD, CD or a video
in wide screen (21:9) format on a wide-
screen (16:9) TV.
• When you connect a computer or a
game console to the TV and select the
4:3 screen mode.
If you connect a DVD player, computer or
a game console to the wide-screen TV
and watch a movie or play a game in
regular (4:3) or wide (21:9) screen mode,
the left and right side edges, or the top
and bottom edges of the screen will be
cropped.
Do not leave the screen in pause mode
for extended periods of time as you may
experience the same problem with
products by other manufacturers.
Note : If the borders at the left, right and
the center of the screen remain
fixed for an extended period of time,
the amounts of light transmission
will also remain varied and as a
result the borders may leave
traces.
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 3

English - 4
Contents
◆CONNECTING AND PREPARING YOUR TELEVISION
■Precautions When Using the Still Image .....................................................2
■Control Panel...............................................................................................6
■Connection Panel ........................................................................................7
■Inserting the Batteries into the Remote Control...........................................8
■Infrared Remote Control..............................................................................9
■Wall Installation Instructions......................................................................10
■Using the Anti-Theft Lock ..........................................................................12
■Connecting to an Aerial or Cable Television Network ...............................13
■Connecting a Satellite Receiver or Decoder..............................................13
■Switching Your Television On and Off.......................................................14
■Placing Your Television in Standby Mode.................................................14
■Familiarizing Yourself with the Remote Control.........................................15
■Plug & Play Feature...................................................................................16
■Choosing Your Language..........................................................................17
◆SETTING THE CHANNELS
■Storing Channels Automatically.................................................................18
■Sorting the Stored Channels .....................................................................19
■Storing Channels Manually........................................................................20
■Editing the Channels .................................................................................22
■Assigning Names to Channels ..................................................................23
■Fine Tuning Channel Reception................................................................24
◆USING YOUR TELEVISION
■Using the LNA (Low Noise Amplifier) Feature...........................................25
■Displaying Information...............................................................................25
■Changing the Picture Standard .................................................................26
■Customizing the Picture Settings...............................................................27
■Customizing the Picture Settings (PC or DVI mode) .................................28
■DNIeTM (Digital Natural Image engine) ...........................................29
■Viewing Picture In Picture (PIP) ................................................................30
■Setting the My Colour Control Mode (Easy Control) .................................32
■Setting the My Colour Control Mode (Detail Control) ................................33
■Setting the Dynamic Contrast....................................................................34
■Setting the Brightness Sensor...................................................................34
■Setting the Colour Weakness Enhancement.............................................35
■Selecting the Picture Size..........................................................................36
■Setting the Blue Screen Mode...................................................................37
■Freezing the Current Picture .....................................................................37
■Changing the Sound Standard ..................................................................38
■Customizing the Sound Settings ...............................................................39
■Adjusting the Volume Automatically ..........................................................40
■Setting up SRS TSXT................................................................................41
■Setting the Sub Woofer Output..................................................................42
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 4

English - 5
Contents (continued)
◆USING YOUR TELEVISION (continued)
■Setting up the Melody Sound ....................................................................43
■Selecting the Sound Mode ........................................................................44
■Setting and Displaying the Current Time...................................................45
■Setting the Sleep Timer.............................................................................46
■Switching the Television On and Off Automatically...................................47
■Auto Screen Adjustment in PC Mode........................................................48
■Setting the Image Lock in PC Mode..........................................................49
■Setting the Screen Position in PC Mode ...................................................50
■Initializing the Screen Settings in PC Mode...............................................51
■Viewing an External Signal Source ...........................................................52
■Redirecting an Input to the External Output ..............................................53
◆USING THE TELETEXT FEATURE
■Teletext Feature ........................................................................................54
■Displaying Teletext Information .................................................................55
■Selecting Display Options..........................................................................56
■Selecting a Teletext Page..........................................................................57
◆ADDITIONAL INFORMATION AND CONNECTIONS
■Connecting to External Input/Output .........................................................58
■Connecting to the RCA Input.....................................................................59
■Connecting to the S-Video Input................................................................59
■Connecting Headphones...........................................................................60
■Connecting to the Digital Audio Input ........................................................60
■Connecting to the HDMI Input ...................................................................61
■Connecting to the Component Input..........................................................61
■Connecting to the Active Sub Woofer Speaker .........................................62
■Connecting to the DVI Input ......................................................................63
■Connecting to the PC(RGB) Input .............................................................63
■Setting up Your PC Software (Windows only)...........................................64
■Input Mode (PC/DVI) .................................................................................65
■Pin Configurations .....................................................................................66
◆RECOMMENDATIONS FOR USE
■Programming the Remote Control for Other Components ........................67
- VCR Remote Control Codes ...................................................................68
- Cable box (CATV) Remote Control Codes..............................................69
- DVD Remote Control Codes ...................................................................69
■Troubleshooting: Before Contacting Service Personnel............................70
■Technical and Environmental Specifications.............................................71
☛➢
Press Important Note
Symbols
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 5

English - 6
Control Panel
( 1 ) SOURCE
External input selection.
Confirm your choice(Store or Enter) on
the on-screen menu.
( 2 ) MENU
Press to open or exit from the on-screen
menu, or return to the previous menu.
( 3 ) Power IndicatorIndicator
Power off : Red
Power on : Off
Timer on : Green
( 4 )
- +
Adjust the volume.
Also used to select or adjust items on the
on-screen menu.
( 5 ) Remote Control Sensor
Aim the remote control towards this spot
on the TV.
( 6 )
C/P.
Select channels.
Auto power on. Also used to move up or
down in the on-screen menu.
( 7 ) Light Detecting Sensor
Senses the ambient light and adjusts the
brightness automatically.
Checks the connection status of all input
sources or selects an item from the menu
screen.
( 8 ) (Power)
Press to turn the TV on and off.
( 9 ) Speakers
TV Front View
12 5 6 7 8
3 4
99
➢◆You can use the C/P. buttons to switch on the TV when it is in standby mode depending on
the model.
◆The - +and C/P. buttons have the same function as the ▲/▼/œ/√buttons
on the remote control.
◆If the remote control no longer works or your have misplaced it, you can use the controls on the panel
of the TV.
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 6

English - 7
Connection Panel
➢For further details about the connections, refer to pages 58~63.
☛Whenever you connect an audio or video system to your television, ensure that all elements are switched
off. Refer to the documentation supplied with your equipment for detailed connection instructions and
associated safety precautions.
( 1 ) OPTICAL AUDIO OUT
Connect to the optical audio input jack for
amplifier with optical audio input.
The optical out is available only when you use
the HDMI digital in.
( 2 ) HDMI IN
Connect to the HDMI output jack for device
with HDMI output.
( 3 ) DVI IN/DVI AUDIO IN
Connect to the digital video and audio output
jack for device with DVI output.
( 4 ) PC IN/PC AUDIO IN
Connect to the video and audio output jack on
your PC.
( 5 ) COMPONENT IN/ COMPONENT AUDIO IN
Connect to the Y, PB, PR(Component video)
and L-AUDIO-R (Component audio) inputs for
device with component out.
( 6 ) EXT 1 (RGB), EXT 2(YC), EXT 3 (RGB)
Connect to the video and audio inputs for
external devices, such as a camcorder or VCR.
( 7 ) ANT. IN
75Ωcoaxial connector for aerial/cable
network.
( 8 ) SUB WOOFER OUT
Connect for active subwoofer speaker.
( 9 ) SERVICE PORT
Connect for service only.
( 10 ) AC POWER IN
TV Side View TV Rear View
Video Input
S-Video Input
Headphone
Audio Input
n
l
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 7

English - 8
You must insert or replace the batteries in the remote control when
you:
◆Purchase the television.
◆Find that the remote control is no longer operating
correctly.
1Remove the cover on the rear of the remote control by pressing
the symbol ( ) downwards , then pulling firmly to remove it.
2Insert two R03, UM4, “AAA” 1.5V or equivalent batteries taking
care to respect the polarities:
◆ - on the battery against - on the remote control
◆ + on the battery against + on the remote control
3Replace the cover by aligning it with the base of the remote
control and pressing it back into place.
➢Do not mix battery types, i.e. alkaline and manganese.
Inserting the Batteries into the Remote Control
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 8

English - 9
Infrared Remote Control
PICTURE SIZE
MENU DISPLAY/
TELETEXT INDEX
TELEVISION STANDBY
INFORMATION DISPLAY/
TELETEXT REVEAL
EXIT FROM ANY DISPLAY
TELETEXT SUB-PAGE
TELETEXT SIZE SELECTION
AUTOMATIC SWITCH-OFF/
TELETEXT PAGE HOLD
SOUND MODE SELECTION
CONFIRM YOUR CHOICE
(STORE OR ENTER)
TruSurround XT
MODE SELECTION
DIRECT CHANNEL SELECTION
EXTERNAL INPUT SELECTION
SWITCH REPEATEDLY BETWEEN THE
LAST TWO CHANNELS DISPLAYED
NEXT CHANNEL/
TELETEXT NEXT PAGE
IF YOUR REMOTE CONTROL IS NOT
FUNCTIONING PROPERLY, REMOVE
THE BATTERIES AND PRESS THE
RESET BUTTON FOR ABOUT 2~3
SECONDS. RE-INSERT THE
BATTERIES AND TRY USING THE
REMOTE CONTROL AGAIN.
PREVIOUS CHANNEL/
TELETEXT PREVIOUS PAGE
DNIe ON/OFF/DEMO
PIP FUNCTIONS;
-PIP ACTIVATION OR DEACTIVATION
(PIP ON)
-SWAPPING THE MAIN AND THE SUB
PICTURE (SWAP)
-SELECTING THE CHANNEL OF THE
SUB PICTURE (P / )
SELECT THE DEVICE (TV, VCR, CABLE
BOX, DVD PLAYER, STB) FOR THE
REMOTE CONTROL
VCR/DVD FUNCTIONS;
-BACKWARDS (REW)
-STOP
-PLAY/PAUSE
-FAST FORWARDS (FF)
PICTURE EFFECT SELECTION
INCREASE VOLUME
TEMPORARY SOUND SWITCH-OFF
DECREASE VOLUME
TELETEXT DISPLAY/
MIX BOTH TELETEXT INFORMATION
AND THE NORMAL BROADCAST
CHANNEL ADD/DELETE
PC INPUT SELECTION/
TELETEXT CANCEL
➢The performance of the remote control may be affected by bright light.
WHEN YOU PRESS A BUTTON , ‘
’
APPEARS ALONG WITH THE SELECTED
MODE (TV, VCR, CATV, DVD, OR STB) AND
THE REMAINING BATTERIES ON THE LCD
TUNER/CABLE NETWORK
SELECTION
CONTROL THE CURSOR
IN THE ON-SCREEN MENU
SOUND EFFECT SELECTION
PICTURE FREEZE
FASTEXT TOPIC SELECTION
REMOTE CONTROL SETUP
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 9

English - 10
Wall Installation Instructions
Wall Mount Bracket
List of Contents (Sold Separately)
Plastic Screw
Anchors
Screws
Installation Notes
◆ The wall attachment panel is sold separately.
◆ Do not install the product in any location other than a vertical wall.
◆ To protect the performance of your product and prevent problems, avoid the following locations:
- Any place vulnerable to vibration or impact: The product may come off and break.
- Near smoke and fire detectors: The sprinkler may be activated upon detecting heat from the product.
- Near high voltage: The reception for your product may be interrupted.
- Near heat sources: The product may get overheated.
How to Adjust Mounting Angle
1Attach the TV to the wall bracket.
(Follow the instructions below.)
2Pull the upper part of the TV (which has been
attached to the bracket) forward in the
direction of the arrow and adjust the angle.
3You can adjust the angle to your liking
between 0-15˚. (±2˚)
The wall mount bracket is delivered
separately. Please tighten the captive
screw in the direction of the arrow after
assembling the bracket.
Captive screw
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 10

English - 11
Wall Installation Instructions (continued)
1Remove the 6 screws from the back of the TV.
3Assemble the plastic screw anchors and the
screws.
5Put the four holders on the back of the TV into the holes on the wall bracket !, lower the TV @and hang
the TV on the bracket. Fasten the TV securely to the wall bracket with stick screws as shown in #so that
the two will not separate.
2Separate the stand from the TV.
4Tighten the screw assemblies (as shown in
Picture 3) to the back of the TV.
TV
Wall Bracket
Wall
!
@
#
How to Attach the TV to the Bracket (sold separately)
6 screw assemblies.
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 11

English - 12
Using the Anti-Theft Lock
The kensington lock is a device used to physically secure the TV when using it in a public place.
◆The TV is designed to use the anti-theft lock.
◆The lock device is used to secure the TV when it is used in a public place.
◆The appearance and locking method may differ depending on the manufacturer. Please refer to
the owner’s instructions provided with the lock for proper use.
Sold
Separately
Figure 2
Figure 1
1Insert the locking device into the kensington slot on the TV (Fig. 1), and turn it in the
locking direction (Fig. 2).
2Connect the kensington lock cable.
3Secure the kensington lock to a desk or a heavy stationary object.
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 12

English - 13
Connecting a Satellite Receiver or Decoder
In order to watch television programmes broadcast via a
satellite network, you must connect a satellite receiver to
the back of the TV. Also, in order to descramble a coded
transmission signal, you must connect a decoder to the
back of the TV.
◆Using a SCART cable
Connect the receiver (or decoder) SCART cable to one
of the SCART connectors at the back of the television.
◆Using a coaxial cable
Connect a coaxial cable to the:
- Receiver (or Decoder) output socket.
- Television aerial input socket.
➢If you wish to connect both a satellite receiver
(or decoder) and a VCR, you should connect the:
◆Receiver (or Decoder) to the VCR
◆VCR to the television
Otherwise, connect the receiver (or decoder) directly
to the television.
TV Rear View
Satellite receiver/Decoder
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
◆A satellite network
1In the first three cases, connect the aerial or network input cable to
the 75Ωcoaxial socket at the back of the television.
2If you are using an indoor aerial, you may need to adjust it when
tuning your television until you obtain a picture that is both sharp
and clear.
For further details, refer to:
◆“Storing Channels Automatically” on page 18.
◆“Storing Channels Manually” on page 20.
Connecting to an Aerial or Cable Television Network
TV Rear View
Cable Television
Network
or
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 13

English - 14
Switching Your Television On and Off
TV
The mains lead is attached to the back of your television.
1Plug the mains lead into an appropriate socket.
➢
The main voltage is indicated on the back of the television
and the frequency is 50 or 60Hz.
2Press the “ ” button (On/Off) on the front of the television.
Result:The Standby indicator on the front of the television
lights up.
3Press the POWER ()button on the remote control to switch the
television on.
Result :The programme that you were watching last is re-
selected automatically.
➢
◆If your television isn’t turned on when the POWER ()
button is pressed, press the SELECT button to check if
“TV” mode has been chosen.
◆If you have not yet stored any channels, no clear picture
appears. Refer to “Storing Channels Automatically” on
page 18 or “Storing Channels Manually” on page 20.
4To switch your television off, press the “ ” button (On/Off) again.
Placing Your Television in Standby Mode
Your television can be placed in Standby mode, in order to reduce
the power consumption.
Standby mode can be useful when you wish to interrupt
viewing temporarily (during a meal, for example).
1Press the POWER ()button on the remote control.
Result:The screen is turned off and the Standby indicator on
the front of the television lights up.
2To switch the television back on, simply press the POWER ()
button again or a number button.
➢
You can also switch the TV back on by pressing the TV (),
P /or a number button.
☛Do not leave your television in Standby mode for long
periods of time (when you are away on holiday, for
example). Turn your television off by pressing the “ ”
button (On/Off) on the front of the television. It is best to
unplug the set from the mains and aerial.
TV
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 14

English - 15
Familiarizing Yourself with the Remote Control
The remote control is used mainly to:
◆Change channels and adjust the volume
◆Set up the television using the on-screen menu system
The following table presents the most frequently used buttons and
their functions.
Button Viewing Function Menu Function
Used to display the next -
stored channel.
Used to display the
-
previous stored channel.
to Used to display the corresponding channels.
➢For double digit channels, the second digit must be
pushed immediately after the first. Failure to do this will
result in a single digit channel being displayed.
PRE-CH Press the PRE-CH button. The TV will switch to the last
() channel viewed.
To quickly switch between two channels that are far apart,
select the first channel, then use the number buttons to
select the second channel. Then, use the PRE-CH button to
quickly alternate between them.
Used to increase the -
volume.
Used to decrease the
-
volume.
MUTE Used to switch the sound off temporarily.
() ➢To turn the sound back on, press this button again, or
press the or button.
MENU Used to display the Used to return to the previous
() on-screen menu system. menu or normal viewing.
- Used to:
◆Display a submenu
containing selections for
the current menu option.
◆Increase/decrease a
menu option value.
- Used to confirm your choice.
TV Used to switch the Used to exit from the menu
() television on when it is system and return to normal
in standby mode. viewing directly.
EXIT - Used to exit from any
() display.
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 15

English - 16
When the television is initially powered on several basic customer
settings proceed automatically and subsequently. The following
settings are available.
1If the television is in Standby mode, press the POWER ()button
on the remote control.
Result:The message Plug & Play is displayed.
2To start Plug & Play, press the ENTER ()button.
Result:The Language menu is displayed.
3Select the appropriate language by pressing the ▲or ▼button.
Press the ENTER ()button to confirm your choice.
Result:The message Check antenna input. is displayed.
4Make sure that the antenna is connected to the TV, then press the
ENTER ()button.
Result:The Country menu is displayed.
5Select your country by pressing the ▲or ▼button. Press the
ENTER ()button to confirm your choice.
Result:The Auto Store menu is displayed.
6To start channel store, press the ENTER ()button.
Result:The search will end automatically. Channels are sorted
and stored in the order which reflects their position in
the frequency range (with lowest first and highest last).
When it has finished, the Clock Set menu is
displayed.
➢To stop the search before it has finished or return to normal
viewing, press the MENU ()button.
7Press the œor √button to move to the Hour or Minute.
Set these by pressing the ▲or ▼button.
➢You can also set the Hour and Minute by pressing the
number buttons directly.
8Press the ENTER ()button.
9When the setting has all finished, the message Enjoy your
watching is displayed, then the channel which has been stored
will be activated.
Plug & Play Feature
Language
English
Deutsch
Français
Nederlands
††
Plug & Play
Move Enter Skip
Country ▲
United Kingdom
Eastern Europe
Others
Plug & Play
Move Enter Skip
Plug & Play
Check antenna input.
Plug & Play
Enter Skip
OK
Auto Store
Enter Skip
Start
P 1 C 2 76MHz
0%
Clock Set
œœ√√
Move Adjust Skip
TV
Hour Minute
00 00
Enjoy your watching
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 16

English - 17
If you want to reset this feature...
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button to select Setup.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button to select Plug & Play.
Press the ENTER ()button.
Result:This feature starts with the message Plug & Play
being displayed.
5For further details on setting up options, refer to the page 16.
Plug & Play Feature (continued)
Setup
Move Enter Return
Time √√
Plug & Play √√
Language : English √√
Blue Screen : Off √√
AV Setup √√
Colour Weakness : Off √√
Melody : On √√
PC √√
TV
Setup
Move Enter Return
Time √√
Plug & Play √√
Language : English √√
Blue Screen : Off √√
AV Setup √√
Colour Weakness : Off √√
Melody : On √√
PC √√
TV
Setup
Move Enter Return
Time
Plug & Play
Language : English
Blue Screen : Off √√
AV Setup √√
Colour Weakness : Of √√
Melody : On
PC
TV
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button to select Setup.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button to select Language. Press the ENTER
()button.
Result:The available languages are listed.
5Select the appropriate language by pressing the ▲or ▼button.
6Press the ENTER ()button to confirm your choice.
Choosing Your Language
English
Deutsch
Français
Nederlands
Español
Italiano
Svenska
†
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 17

English - 18
You can scan for the frequency ranges available to you, (availability
depends on your country). Automatically allocated programme
numbers may not correspond to actual or desired programme
numbers. However you can sort numbers manually and clear any
channels you do not wish to watch.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button to select Channel.
Result:The options available in the Channel group are
displayed.
3Press the ENTER ()button.
Result:Country is selected.
4Press the ENTER ()button again. Select your country by
pressing the ▲or ▼button.
The countries are displayed in the following order:
Belgium - Germany - Spain - France - Italy - Netherlands -
Switzerland - Sweden - United Kingdom - Eastern Europe -
Others.
➢If you have selected the Others option but do not wish to
scan the PAL frequency range, store the channels manually
(see page 20).
5Press the ENTER ()button to confirm your choice.
6Press the ▲or ▼button to select Auto Store. Press the
ENTER ()button.
7Press the ENTER ()button to start the search.
Result:The search will end automatically. Channels are sorted
and stored in the order which reflects their position in
the frequency range (with lowest first and highest last).
The programme originally selected is then displayed.
➢To stop the search before it has finished or return to normal
viewing, press the MENU ()button.
8When searching and storing are complete, the Sort menu is
displayed.
◆ To sort the stored channels into the desired numerical order,
go to step 5of the “Sorting the Stored Channels” procedure on
page 19.
◆ To exit from the channel store function without sorting the
channels, press the MENU ()button repeatedly until the
menus disappear.
9When the channels have been stored, you can:
◆ Sort them in the order required (see page 19)
◆ Assign names to the stored channels (see page 23)
◆ Clear a channel (see page 22.)
◆ Fine-tune channel reception if necessary (see page 24)
◆ Activate/deactivate the LNA (Low Noise Amplifier) feature
(See page 25)
Storing Channels Automatically
Channel
Move Enter Return
Country : Others √√
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Name √√
Fine Tune √√
LNA :On √√
TV
Channel
Move Enter Return
Country : Others √√
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Name √√
Fine Tune √√
LNA :On √√
TV
Channel
Move Enter Return
Country : Belgium
Auto Store
Manual Store
Add/Delete
Sort
Name
Fine Tune
LNA : On
TV
▲
Sweden
United Kingdom
Eastern Europe
Others
Auto Store
Enter Return
Start
P 1 C 2 49MHz
0%
Auto Store
Enter Return
Stop
P 1 C 2 76MHz
15%
Sort
TV
Prog. Ch. Name
1C2
2C4
3C15
4S2
5S6
Move Enter Return
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 18

English - 19
This operation allows you to change the programme numbers of
stored channels. This operation may be necessary after using the
auto store. You can delete those channels you do not want to keep.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button to select Channel.
Result:
The options available in the Channel group are
displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button to select Sort. Press the ENTER ()
button.
Result:The Sort menu is displayed.
5Select the channel that you wish to move by pressing the ▲or ▼
button. Press the ENTER ()button.
6Select the number of the programme to which the channel is to be
moved by pressing the ▲or ▼button. Press the ENTER ()
button.
Result:The channel is moved to its new position and all other
channels are shifted accordingly.
7Repeat Steps 5to 6until you have moved all the channels to the
required programme numbers.
Sorting the Stored Channels
Sort
TV
Prog. Ch. Name
1C2
2C4
3C15
4S2
5S6
Move Enter Return
Sort
TV
Prog. Ch. Name
2C4
3C15
4S2
5S6
Move Enter Return
Channel
Move Enter Return
Country : Others √√
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Name √√
Fine Tune √√
LNA :On √√
TV
C 2
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 19

English - 20
Storing Channels Manually
You can store the television channels, including those received via
cable networks.
When storing channels manually, you can choose:
◆Whether or not to store each of the channels found
◆The programme number of each stored channel which
you wish to identify
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button to select Channel.
Result:
The options available in the Channel group are
displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button to select Manual Store. Press the
ENTER ()button.
Result:The options available in the Manual store group are
displayed with the Programme selected.
5Press the ENTER ()button again.
6To assign a programme number to a channel, find the correct
number by pressing the ▲or ▼button, then press the ENTER
()button.
7If necessary, select the broadcasting standard required. Press the
▲or ▼button to select Colour System , then press the ENTER
()button. The colour standards are displayed in the following
order.
AUTO - PAL - SECAM - NTSC4.43
8Select the desired colour system by pressing the ▲or ▼button.
Press the ENTER ()button to confirm your choice.
9Press the ▲or ▼button to select Sound System, then press the
ENTER ()button. The sound standards are displayed in the
following order.
B/G - D/K - I - L
10 Select the desired sound system by pressing the ▲or ▼button.
11 Press the ENTER ()button to confirm your choice.
Channel
Move Enter Return
Country : Others √√
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Name √√
Fine Tune √√
LNA :On √√
TV
Manual Store
Adjust Enter Return
Programme : P 1
Colour System : AUTO
Sound System : B/G
Channel : C 2
Search : 49 MHz
Store : ?
TV
P 1
Manual Store
Move Enter Return
Programme : P 1
Colour System : AUTO
Sound System : B/G
Channel : C
--
Search : 76 MHz
Store : ?
TV
AUTO
PAL
SECAM
NTSC4.43
Manual Store
Move Enter Return
Programme : P 1
Colour System : AUTO
Sound System : B/G
Channel : C
--
Search : 76 MHz
Store : ?
TV
B/G
D/K
I
L
BN68-00746A(GAIA2_Euro_ENG) 2004/07/27 06:49 PM Page 20
