Samsung HG43BU800AJ User manual

1. List of Parts
•The provided accessories mayvary depending on the model.
123
Samsung Smart Remote Power Cable
Warranty Card / Quick Setup Guide /
Regulatory Guide
(Not available in some locations)
4 5
Data Cable
(Not available in some locations) Antenna adapter
2. The Samsung Smart Remote
Pairing the TV to the Samsung Smart Remote
When you turn on the TV for the first time, the Samsung Smart Remote pairs
to the TV automatically. If the Samsung Smart Remote does not pairto the TV
automatically, point it at the remote control sensorof the TV, and then press
and hold the buttons labelled and as shown in the figure on the left
simultaneously for 3 seconds or more.
Charging the battery
Solar Cell
Expose to light when the remote is not in use. This will extend the remote's
operating time.
USB port (C-type) for charging
Used forquick charging. The LED on the front will light when charging.
When the battery is fully charged, the LED will turn off.
•The USB Cable is not provided.
– It is recommended to use an original Samsung charger. Otherwise, it may cause performance degradation or failure
of the product. In this case, the warranty service is not applicable.
– When the remote control does not work due to low battery, charge it by using the USB-C type port.
3. Installing the LED TV Stand
Assembling the Stand and Components
When installing the stand, use the provided components and parts.
Stand Holder-Cable x 2
125 mm
•Place a soft cloth over the table to protect the TV, and then place the TV so that its screen faces down toward the
table surface.
2
•Insert the Stands into the slot on the bottom of the TV.
•Slide and assemble it to the end line in the direction of arrow.
Quick Setup Guide
To registerthis product please visit www.samsung.com
-00
343″
50-65″
NOTE
•Make sure to distinguish between the front and back of each component when assembling them.
•Make sure that at least two persons lift and move the TV.
4. The Connection Panel
O
HDD
ARC
USB
LAN
ANT IN
DATA
AV
BACK OF TELEVISION

5. Connecting the antenna adapter
Connect the provided antenna adapter to an antenna terminal on the wall, and then connect the antenna cable, which is
connected to ANT on the TV, to the antenna adapter.
The connected antenna adapter prevents overload that may occurdue to potential difference between the antenna
terminal on the wall and the antenna cable, consequently being able to prevent product damage orfire.
•Be sure to use the provided antenna adapter.
•The method forconnecting the antenna adapter and the markings on the antenna terminals may differ depending on
the model and geographical region.
•If you use the antenna adapterwhere antenna signals are weak, the screen may become blurry.
6. Wall Mount Kit Specifications (VESA)
Install yourwall mount on a solid wall, perpendicularto the floor. When attaching to other building materials, please
contact your nearest dealer. If installing on a ceiling or slanted wall, TV may fall and result in severe personal injury.
•Standard dimensions for wall mount kits are shown in the table below.
•Samsung wall mount kits contain a detailed installation manual. All parts necessary forassembly are provided.
Do not install yourwall mount kit while your TV is turned on. This may result in personal injury from electric
shock.
•Do not use screws that are longer than the standard dimension or do not complywith the VESA standard screw
specifications. Screws that are too long may cause damage to the inside of the TV set.
•Forwall mounts that do not complywith the VESA standard screw specifications, the length of the screws may differ
depending on the wall mount specifications.
•Do not fasten the screws too firmly. This may damage the product orcause the product to fall, leading to personal
injury. Samsung is not liable forthese kinds of accidents.
•Samsung is not liable forproduct damage or personal injury when a non-VESA or non-specified wall mount is used or
when the consumerfails to follow the product installation instructions.
•Do not mount the TV at more than a 15 degree tilt.
•Always have two people mount the TV onto a wall.
TV
Wall mount
bracket
C
•The Product shape may differ depending on the model.
TV size in
inches
VESA screw hole specs
(* ) in millimetres (mm)(mm)(mm)C (mm)Standard Screw Quantity
43
200 x 200
382.8 192.2 167.7
11-13 M8 4
50 459.2 207.4 237.2
55 516.1 239.3 269.5
65 400 x 300 525.5 264.0 267.9
Do not install yourwall mount kit while your TV is turned on. This may result in personal injury from electric
shock.
7. Specifications
Model Name HG43BU800AJ HG50BU800AJ
Display Resolution 3840 x 2160 3840 x 2160
Screen Size
Measured Diagonally 43 inches 50 inches
Sound (Output) 20 W20 W
Dimensions (W x H x D)
Body
With stand
965.5 x 559.9 x 25.7 mm
965.5 x 599.0 x 205.6 mm
1118.3 x 644.6 x 25.7 mm
1118.3 x 683.6 x 228.8 mm
Weight
Without Stand
With Stand
8.4 kg
8.7 kg
11.5 kg
11.8 kg
Model Name HG55BU800AJ HG65BU800AJ
Display Resolution 3840 x 2160 3840 x 2160
Screen Size
Measured Diagonally 55 inches 65 inches
Sound (Output) 20 W20 W
Dimensions (W x H x D)
Body
With stand
1232.1 x 708.8 x 25.7 mm
1232.1 x 787.8 x 228.8 mm
1450.9 x 831.9 x 25.7 mm
1450.9 x 869.6 x 281.8 mm
Weight
Without Stand
With Stand
15.5 kg
15.8 kg
20.9 kg
21.3 kg
Environmental Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
10 °C to 40 °C (50 °F to 104 °F)
10 % to 80 %, non-condensing
-20 °C to 45 °C (-4 °F to 113 °F)
5 % to 95 %, non-condensing
•This device is a Class B digital apparatus.
•The design and specifications are subject to change without prior notice.
•Forinformation about the power supply, and more information about power consumption, referto the label-rating
attached to the product.
•The screen size on the energy label and package may have the tolerance within ±1 cm.
•You can see the label-rating attached to the back of the TV. (Forsome models, you can see the label-rating inside the
cover terminal.)
•Your TV and its accessories may look different than the product images presented in this manual, depending on the
model.
•All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the
dimensions before installing yourTV. Not responsible for typographical or printed errors.
8. Licences
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks orregistered trademarks of HDMI Licensing
Administrator, Inc. in the United States and othercountries.
Open Source License Notice
Open Source used in this product can be found on the following webpage. (https://opensource.samsung.com)
