Samsung UN J5500AF Series User manual

LED TV
SERVICEManual
LED TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UN**J5500AF
Chassis : UWK50
Model : UN32J5500AF
UN40J5500AF
UN48J5500AF
UN50J5500AF

Contents
1. Precautions.............................................................................................................. 1-1
1-1. Safety Precautions ......................................................................................................... 1-1
1-1-1. Warnings .............................................................................................................. 1-1
1-1-2. Servicing the LED TV........................................................................................... 1-1
1-1-3. Fire and Shock Hazard ........................................................................................ 1-1
1-1-4. Product Safety Notices ........................................................................................ 1-2
1-2. Servicing Precautions..................................................................................................... 1-3
1-2-1. General Servicing Precautions ............................................................................ 1-3
1-3. Static Electricity Precautions .......................................................................................... 1-4
1-4. Installation Precautions .................................................................................................. 1-5
2. Product Specications............................................................................................ 2-1
2-1. Product information ........................................................................................................ 2-1
2-2. Product specication ...................................................................................................... 2-2
2-2-1. Detailed Specications......................................................................................... 2-2
2-2-2. Specications....................................................................................................... 2-7
2-3. Accessories ................................................................................................................... 2-8
3. Disassembly and Reassembly ............................................................................... 3-1
3-1. Disassembly and Reassembly ....................................................................................... 3-1
4. Troubleshooting ...................................................................................................... 4-1
4-1. Troubleshooting .............................................................................................................. 4-1
4-2. How to Check Fault Symptom ........................................................................................ 4-2
4-2-1. Video.................................................................................................................... 4-2
4-2-2. Bluetooth / WIFI Module ...................................................................................... 4-3
4-2-3. SMPS................................................................................................................... 4-5
4-2-4. Jog Function Control............................................................................................ 4-9
4-3. Factory Mode Adjustments ........................................................................................... 4-10
4-3-1. Detail Factory Option ......................................................................................... 4-10
4-3-2. Entering Factory Mode....................................................................................... 4-12
4-3-3. Factory Data ...................................................................................................... 4-13
4-4. White Balance .............................................................................................................. 4-29
4-4-1. Calibration.......................................................................................................... 4-29
4-4-2. Service Adjustment ............................................................................................ 4-29
4-4-3. Adjustment ......................................................................................................... 4-31
4-5. Software Upgrade......................................................................................................... 4-32
4-5-1. By USB .............................................................................................................. 4-32
4-5-2. By Online ........................................................................................................... 4-32
4-5-3. Alternative Software (Backup)............................................................................ 4-32
4-6. The Dimension of J5500 Models .................................................................................. 4-33

5. Wiring Diagram........................................................................................................ 5-1
5-1. Wiring Diagram............................................................................................................... 5-1
5-2. Connector ....................................................................................................................... 5-2
5-3. Connector Functions ...................................................................................................... 5-5
5-4. Cables ............................................................................................................................ 5-6
5-5. The Types of Module ...................................................................................................... 5-7
ANNEX. Exploded View & Part List [UN32J5500AFXZA TS01]......................ANNEX-1
1-1. Exploded View......................................................................................................ANNEX-1
1-1-1. Parts List ....................................................................................................ANNEX-1
2-1. Electrical Parts List ...............................................................................................ANNEX-2
ANNEX. Exploded View & Part List [UN40J5500AFXZA TS01]......................ANNEX-1
1-1. Exploded View......................................................................................................ANNEX-1
1-1-1. Parts List ....................................................................................................ANNEX-1
2-1. Electrical Parts List ...............................................................................................ANNEX-2
ANNEX. Exploded View & Part List [UN48J5500AFXZA TS01]......................ANNEX-1
1-1. Exploded View......................................................................................................ANNEX-1
1-1-1. Parts List ....................................................................................................ANNEX-1
2-1. Electrical Parts List ...............................................................................................ANNEX-2
ANNEX. Exploded View & Part List [UN50J5500AFXZA II01] ........................ANNEX-1
1-1. Exploded View......................................................................................................ANNEX-1
1-1-1. Parts List ....................................................................................................ANNEX-1
2-1. Electrical Parts List ...............................................................................................ANNEX-2

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2015 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1. Precautions
1-1. Safety Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according to•
the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

2-1
2. Product specications
2. Product Specications
2-1. Product information
Model UN**J5500AF
Front View
W
* W : Width H : High
H
Detail View
Color Front Color : BLACK, Stand Color : LIGHT TITAN (HAIRLINE)
Dimensions
(W x H x D)
32"
With Stand 721.4 x 471.6 x 207.6 mm / 28.40 x 18.57 x 8.17 inches
Without Stand 721.4 x 424.8 x 66.6 mm / 28.40 x 16.72 x 2.62 inches
40"
With Stand 907.6 x 585.6 x 288.1 mm / 35.73 x 23.06 x 11.34 inches
Without Stand 907.6 x 529.7 x 66.9 mm / 35.73 x 20.85 x 2.63 inches
48"
With Stand 1076.1 x 681.3 x 310.5 mm / 42.37 x 26.82 x 12.22 inches
Without Stand 1076.1 x 624.4 x 67.1 mm / 42.36 x 24.58 x 2.64 inches
50"
With Stand 1117.8 x 703.6 x 310.5 mm / 44.00 x 27.70 x 12.22 inches
Without Stand 1117.8 x 647.8 x 67.5 mm / 44.00 x 25.50 x 2.65 inches
Weight
32"
With Stand 5.1 kg / 11.24 lbs
Without Stand 4.7 kg / 10.36 lbs
40"
With Stand 8.6 kg / 18.96 lbs
Without Stand 7.7 kg / 16.98 lbs
48"
With Stand 12.3 kg / 27.17 lbs
Without Stand 11.3 kg / 27.91 lbs
50"
With Stand 13.4 kg / 29.54 lbs
Without Stand 12.4 kg / 27.33 lbs

2-2
2. Product specications
2-2. Product specication
2-2-1. Detailed Specications
NOTE
Design and specications are subject to change without prior notice.
Item UN**J5500AFXZA
General Information Product LED
Series 5
Country UNITED STATES
Display Screen Size 32"/40"/48"/50"
Resolution 1,920 x 1,080
Ultra Clear Panel N/A
Video Motion Refresh Rate 60
Dynamic Contrast Ratio Mega Contrast
Micro Dimming Micro Dimming Pro
Precision Black (Local Dimming) N/A
Nano Crystal Color N/A
Wide Color Enhancer (Plus) Yes
PurColor N/A
Auto Depth Enhancer N/A
Contrast Enhancer N/A
Auto Motion Plus N/A
Film Mode Yes
Peak Illuminator N/A
Audio Dolby Digital Plus Yes
Virtual Surround DTS Studio Sound
DTS Codec DTS Premium Sound 5.1
3D Sound N/A
Sound Customizer N/A
Sound Output (RMS) 20W(L:10W, R:10W)
Speaker Type 2CH(Down Firing + Base Reex)
Woofer N/A
HD Audio Yes
Wallmount Sound Mode Yes
Multiroom Link Yes
Smart TV Samsung SMART TV Yes
Apps Yes

2-3
2. Product specications
Item UN**J5500AFXZA
Smart TV Game N/A
Multi-Link Screen N/A
ACR (Advertisement) Yes
Info Widget N/A
Vertical Enhancement Yes
Smart Interaction Voice Interaction N/A
Voice Control N/A
Face recognition N/A
Motion control N/A
Smart Convergence TV to Mobile - Mirroring Yes
Mobile to TV - Mirroring, DLNA Yes
RVU Yes
Samsung SMART View Yes
Wireless TV On - WOL Yes
Notication - BLE Yes
Brieng On TV Yes
WiDi N/A
WiFi Direct Yes
Tuner/Broadcasting Digital Broadcasting ATSC / Clear QAM
2 Tuner N/A
CI/CI+/2CI+ N/A
Analog Tuner Yes
MHP / MHEG / HbbTV / ACAP / GINGA /
OHTV N/A
Connectivity HDMI 3
USB 2
Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (Common Use for Component Y)
Ethernet (LAN) 1
Headphone N/A
Audio Out (Mini Jack) 1
Digital Audio Out (Optical) 1
RF In (Terrestrial / Cable input / Satellite
input) 1/1(Common Use for Terrestrial)/0
Ex-Link ( RS-232C ) Yes
IR Out N/A
CI Slot N/A

2-4
2. Product specications
Item UN**J5500AFXZA
Connectivity Scart N/A
MHL Yes
Dongle Ready (3G / LTE) N/A
HDMI 3D Auto Setting N/A
HDMI A / Return Ch. Support Yes
HDMI Quick Switch N/A
Wireless LAN Adapter Support N/A
Wireless LAN Built-in Yes
Anynet+ (HDMI-CEC) Yes
Design Design R-Chamfer
Bezel Type VNB
Slim Type Slim
Front Color Black
Light Effect (Deco) N/A
Stand Type V-Shape
Swivel (Left/Right) N/A
Additional Feature Samsung 3D N/A
3D Converter N/A
Instant On Yes
Camera Built-in N/A
Wireless Copy N/A
Processor Quad
PX Ready N/A
21:9 Immersive Picture Mode N/A
SCSA Support N/A
Accessibility Voice guide/ Enlarge/ High contrast
Digital Clean View Yes
One Connect (Jack) N/A
Auto Channel Search Yes
Auto Power Off Yes
BD Wise Plus Yes
Caption (Subtitle) Yes
Channel List USB-Clone N/A
Connect Share™ (HDD) Yes
Connect Share™ Transfer N/A

2-5
2. Product specications
Item UN**J5500AFXZA
Additional Feature ConnectShare™ (USB 2.0) Yes
AC/DC TV N/A
Sports Mode Basic
Embeded POP Yes
EPG Yes
Extended PVR N/A
Game Mode Yes
IP Video Closed Caption Yes
OSD Language English, Spanish, French
Picture-In-Picture Yes
BT HID Built-in Yes
USB HID Support Yes
Feature Upgrade (Evolution Kit Ready) N/A
ATSC 3.0 Ready N/A
Teletext (TTXT) N/A
Time Shift N/A
Analog Clean View N/A
Ultra Clean View Yes
Eco Feature Energy Star Energy Star 6.1
Eco Sensor Yes
Accessory 3D Active Glasses (Included) N/A
Remote Controller Model TM1260C
Batteries (for Remote Control) Yes
Samsung Smart Touch Control (Included) N/A
PX (Included) N/A
Ultra Slim Wall Mount Supported N/A
Mini Wall Mount Supported Yes
Vesa Wall Mount Supported Yes
Floor Stand Support 32" : N/A Yes
TV Camera (Included) N/A
IR Extender Cable (Included) N/A
Wireless Keyboard (Included) N/A
Wireless PC Mirroring Adaptor (Included) N/A
Composite to Scart Gender (Included) N/A
User Manual Yes

2-6
2. Product specications
Item UN**J5500AFXZA
Accessory E-Manual Yes
ANT-Cable N/A
Power Cable Yes
Slim Gender Cable N/A

2-7
2. Product specications
2-2-2. Specications
Specications
Model UN**J5500AF
Item Description
Screen Size (Diagonal) 32 inches 40 inches 48 inches 50 inches
LCD Panel FHD 60Hz
Display Resolution 1920 x 1080
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Environmental
Considerations
Operating Temperature: 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity: 10% ~ 80%, non-condensing
Storage Temperature: -4˚F ~ 113˚F (-20˚C ~ 45˚C)
Storage Humidity: 5% ~ 95%, non-condensing
AC Power Voltage &
Frequency AC110-120V 60Hz
Sound (Output) 20W(L:10W, R:10W)

2-8
2. Product specications
2-3. Accessories
NOTE
The items’ colors and shapes may vary depending on the model.•
Cables not included in the package contents can be purchased separately.•
The part code for some accessories may differ depending on your region.•
Product Description Code. No Remark
Remote Control &
Batteries
(AAA x 2)
BN59-01223A
-
4301-000103
Power Cord 3903-000853
Manual Users BN68-06969A
Holder-Wire Stand BN61-08370A

3-1
3. Disassembly and Reassemble
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED TV.
WARNING
This LED TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
If there is no additional coment, it is same for all inches.3.
Description Picture Description Screws
1
Place TV face down on cushioned table.
2
Remove Screws from the ASSY GUIDE
P-STAND and Remove ASSY GUIDE
P-STAND.
32" : 3 EA•
40"/48"/50"/55" : 4 EA•
Torque :
9~ 10Kgf.cm
6003-001782
3
Remove Screws of ASSY COVER
P-REAR.
32" : 12 EA•
Torque :
9~ 10Kgf.cm
6003-001782
Torque :
7~ 8Kgf.cm
6003-002755

3-2
3. Disassembly and Reassemble
Description Picture Description Screws
40" : 16 EA•
48" : 18 EA•
50" : 20 EA•
55" : 23 EA (ONLY MEXICO)•

3-3
3. Disassembly and Reassemble
Description Picture Description Screws
4
Remove the ASSY COVER P-REAR.
5
Remove 10 Screws of ASSY PCB MAIN
and DC VSS-LED TV PD BD. Torque :
7~ 8Kgf.cm
6001-002756
6
Remove the ASSY SPEAKER P (R/L) and
Power Cables. ASSY SPEAKER P
Power Cable
ASSY BOARD P-BT
MODULE Cable
ASSY SPEAKER P
Cable
