English > Main > Safety Instructions > Notational
Notational
Power
Installation
Cleaning
Other
Failure to follow directions noted by this symbol could result in bodily harm or damage to equipment.
Prohibited Important to read and understand at all times
Do not disassemble Disconnect the plug from the outlet
Do not touch Grounding to prevent an electric shock

English > Main > Safety Instructions > Power
Notational
Power
Installation
Cleaning
Other
When not used for extended periods of time, set your PC to DPMS. If using a screen
saver, set it to the active screen mode.
Do not use a damaged or loose plug.
zThis may cause an electric shock or fire.
Do not pull the plug out by the wire nor touch the plug with wet hands.
zThis may cause an electric shock or fire.
Use only a properly grounded plug and receptacle.
zAn improper ground may cause electric shock or equipment damage.
Do not excessively bend the plug and wire nor place heavy objects upon them,
which could cause damage.
zThis may cause an electric shock or fire.
Disconnect the plug from the outlet during storms or lightening or if it is not
used for a long period of time.
zFailure to do so may cause an electric shock or fire.
Do not connect too many extension cords or plugs to an outlet.
zThis may cause a fire.

English > Main > Safety Instructions > Installation
Notational
Power
Installation
Cleaning
Other
Do not cover the vents on the monitor cabinet.
zBad ventilation may cause a breakdown or fire.
Put your monitor in a location with low humidity and a minimum of dust.
zAn electric shock or fire could result inside the monitor.
Do not drop the monitor when moving it.
zThis may cause damage to the product or human body.
Place the monitor on a flat and stable surface.
zThe monitor can cause injury by falling.
Set down the monitor carefully.
zIt could be damaged or broken.
Do not place the monitor face down.
zThe TFT-LCD surface may be damaged.

English > Main > Safety Instructions > Cleaning
Notational
Power
Installation
Cleaning
Other
When cleaning the monitor case or the surface of the TFT-LCD, wipe with a slightly
moistened, soft fabric.
Do not spray detergent directly on the monitor.
Use the recommended detergent with a smooth cloth.
If the connector between the plug and the pin is dusty or dirty, clean it properly
with a dry cloth.
zA dirty connector can cause an electric shock or fire.
Do not set a glass of water, chemicals or any small metal objects on the monitor.
zThis may cause damage, electric shock or a fire.
zIf a foreign substance gets into the monitor, disconnect the plug and then
contact a service center.

English > Main > Safety Instructions > Ohter
Notational
Power
Installation
Cleaning
Other
Do not remove cover(or back). No user serviceable parts inside.
zThis may cause an electric shock or a fire.
zRefer servicing to qualified service personnel.
If your monitor does not operate normally - in particular, if there are any unusual
sounds or smells coming from it - unplug it immediately and contact an
authorized dealer or service.
zThis may cause an electric shock or fire.
Do not place any heavy objects on the monitor.
zThis may cause an electric shock or a fire.
For each hour of looking at the monitor, you should let your eyes rest for 5
minutes.
zThis will reduce eye fatigue.
Do not use or store inflammable substances near the monitor.
zThis may cause an explosion or fire.
Do not try to move the monitor by pulling on the wire or the signal cable.
zThis may cause a breakdown, electric shock or a fire due to damage to the
cable.
Do not move the monitor right or left by pulling only the wire or the signal cable.
zThis may cause a breakdown, electric shock or a fire due to damage to the
cable.
Never insert anything metallic into the monitor openings.
zThis may cause an electric shock, fire or injury.

English > Main > Introduction > Unpacking
Unpacking
Front
Rear
Remote Control
Please make sure the following items are included with your monitor. If any items are missing, contact
your dealer.
User's Guide and Natural Color/
Driver Installation CD Power Cord Signal Cable(15 pin D-Sub)
Monitor
Quick Setup Guide DC Adapter
Warranty Card
(Not available in all locations) TV Tuner Box (Option)
Batteries (AAA X 2) Audio Cable
Remote Control Scart Jack

English > Main > Introduction > Front
Unpacking
Front
Rear
Remote Control
For detail information concerning the monitor functions, refer to User Controls under Adjusting Your Monitor.
The monitor's front configuration may vary slightly depending on the monitor model.
1 PC mode button 6 Up-Down button / Channel
button
2 PIP mode button 7 Left-Right button / Volume
button
3 Video mode button 8 Menu button
4 Audio mode button 9 Exit button
5 Power button / Power indicator 10 Auto button
PIP(Picture in Picture)?
Feature allowing one program to be viewed on the entire screen while
one or more programs play in small windows superimposed over the
base program. PIP is also referred to as Split Windows.

English > Main > Introduction > Rear
Unpacking
Front
Rear
Remote Control
For detailed information concerning cable connections, refer to Connecting Cables under Setup.
The monitor's rear configuration may vary slightly depending on the monitor model.
A PC Connection Terminal
1 Power Connection Terminal (12V DC)
2 Computer Connection Terminal (15 Pin D-SUB)
3 Audio Connection Terminal (Audio (ST))
B AV Connection Terminal
1 AV right audio connection terminal (R)
2 AV left audio connection terminal (L)
3 AV video connection terminal
4 S-Video connection terminal
C Antenna Connection Terminal
(When TV is connected)
D Headphone connection terminal
