Samsung F22T45 F Series User manual

LCD Monitor Manual
1. Precautions.................................................................................................................... 2
2. Disassembly................................................................................................................... 4
3. Exploded View ............................................................................................................... 10
4. Spare parts..................................................................................................................... 12
5. Maintenance.................................................................................................................. 13
6. Self Diagnosis................................................................................................................ 14
7. Troubleshooting Guide................................................................................................. 15
Contents
Project Model
T45F F22T45*F**
F24T45****
F27T45*F**
T37F F24T37*F**

1. Precautions
1-1. Safety Precautions
WARNING
•A serious or fatal injury may result if instructions are not followed.
CAUTION
•Personal injury or damage to properties may result if instructions are not
followed.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO
USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage
is present inside. It is dangerous to make
any kind of contact with any internal part
of this product.
AC voltage: Rated voltage marked with
this symbol is AC voltage.
This symbol indicates that this product
has included important literature
concerning operation and maintenance.
DC voltage: Rated voltage marked with
this symbol is DC voltage.
Class II product: This symbol indicates
that a safety connection to electrical
earth (ground) is not required. If this
symbol is not present on a product with
a mains lead, the product MUST have a
reliable connection to protective earth
(ground).
Caution. Consult instructions for use:
This symbol instructs the user to consult
the user manual for further safety related
information.
2
LCD Monitor

1-1-1. Electricity and Safety
WARNING
•Do not use a damaged power cord or plug, or a loose power socket.
•Do not use multiple products with a single power socket.
•Do not touch the power plug with wet hands.
•Insert the power plug all the way in so it is not loose.
•Connect the power plug to a grounded power socket (type 1 insulated devices
only).
•Do not bend or pull the power cord with force. Be careful not to leave the power
cord under a heavy object.
•Do not place the power cord or product near heat sources.
•Clean any dust around the pins of the power plug or the power socket with a dry
cloth.
CAUTION
•Do not disconnect the power cord while the product is being used.
•Only use the power cord provided with your product by Samsung. Do not use the
power cord with other products.
•Keep the power socket where the power cord is connected unobstructed.
– The power cord must be disconnected to cut off power to the product when
an issue occurs
•Hold the plug when disconnecting the power cord from the power socket.
3
LCD Monitor

2. Disassembly
※ Reassembly procedures are in the reverse order of disassembly procedures.
※ The exterior & inner parts may differ depending on the product.
•For information about purchasing parts and jigs for EU region, please visit http://www.samsung.com/
support. Samsung ASC can purchase listed Jigs on GSPN.
Delphinus
(BH81-00001A)
Assembly Misc P-jig-2017
(BN81-14946A)
Assembly Misc P-jig-2017
(BN81-14946B)
1-1 Disassemble two screws assembled between COVER-STAND and SET. Remark
Model : T45F
1-2
Model : T37F
4
LCD Monitor

2•Place jig BH81-00001A in the decomposition hole on the lower left, and
make a gap by lowering it down. Remark
* Be careful not
to damage
the source
PCB when
decomposing
DECO.
* Be careful not
to damage the
product when
using Jig.
3•After decomposing COVER-DECORATION, Disassemble the lower hook
assembled between COVER-REAR and PANEL. Remark
* Be careful not
to damage
the source
PCB when
decomposing
COVER-REAER.
5
LCD Monitor

4 •Disassemble the hooks hanging on the PANEL from the bottom of both
sides of COVER-REAR. It breaks down from both ends to the center. Remark
Hook
Hook
* Be careful not
to damage
the source
PCB when
decomposing
COVER-REAER.
6
LCD Monitor

5 •Hold the center of COVER-REAR and PANEL and lift it up. Remark
6-1 •COVER-REAR decomposition complete. Remark
Model : T45F
6-2
Model : T37F
7
LCD Monitor

7•22” 24” : Remove the cable and screw and disassemble the main board and
SMPS.
• Fix the function cable so that it does not go under the hook and through
the hole.
Remark
Screw
(M4xL8)
8•27” : Remove the cable and screw and disassemble the main board and
SMPS.
• Fix the function cable so that it does not go under the hook and through
the hole.
Remark
Screw
(M4xL8)
8
LCD Monitor

9 •When disassembling the Function Bracket, press the side of the jig BH81-
00001A to remove it. Remark
10 •Finish Remark
9
LCD Monitor

3. Exploded View
3-1. Structure
•T45F
No. Part Name No. Part Name
1LCD-PANEL 7HOLDER-FUNCTION
2ASSY PCB MAIN 8ASSY BOARD P-FUNCTION
3DC VSS-POWER BOARD 9COVER-TERMINAL SIDE
4ASSY COVER P-REAR 0BRACKET-VESA
5ASSY STAND P-COVER BODY !INSULATIOR SMPS
6ASSY STAND P-COVER BOTTOM
10
LCD Monitor
