PLASMA DISPLAY TV
Chassis : D68A(N_R1)_Mozart_37"
Model : HPP3761X/XAA (HP-P3761)
PLASMA DISPLAY TV CONTENTS
1.
2.
3.
4.
5.
6.
Specifications
Alignment and Adjustments
Troubleshooting
Exploded View and Parts List
Service Item
Schematic Diagrams
SERVICE Manual

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
©Samsung Electronics Co., Ltd. DEC. 2004
Printed in Korea
AA82-01908A
ELECTRONICS

Specifications
Samsung Electronics 1-1
1. Specifications
Model HP-P3761
Screen Size 92 Cm / 37 Inches (16:9)
Dimensions Display 951.5(W) x 89.9(D) x 670(H)mm / 37.5(W) x 3.5(D) x 26.4(H)inches
Remote Control 59(W) x 22(D) x 209(H)mm / 2.3(W) x 0.87(D) x 8.2(H)inches
Weight Display 30.5kg / 67lbs(Without Stand)
Remote Control 0.36 Ib(164g) (Including batteries) / 0.33lbs
Voltage 120V~, 60Hz
Power Consumption 330 Watts
Number of Pixels 1024(H) X 1024(V)
ANTENNA input VHF, UHF (75Ωunbalanced)
VIDEO Input
AV1, AV2
S-VIDEO
COMPONENT1 (480i/480p/720p/1080i)
COMPONENT2 (480i/480p/720p/1080i)
DVI-D
AUDIO Intput
AV1
AV2 / S-VIDEO
COMPONENT1, COMPONENT2
DVI-D
Monitor Output VIDEO, AUDIO(L/R)
Speaker Output 10W + 10W (8Ω)
Accessory Remote Control, AAA Batteries, Power Cord, Antenna Cable,
Owner's Instructions

1-2 Samsung Electronics
MEMO

2-1-1 SERVICE MODE Entry Method (General Transmitter)
■Using the Customer Remote
1. Turn the power off and set to stand-by mode.
2. Press the remote buttons in this order; POWER OFF-MUTE-1-8-2- POWER ON to turn the set on.
3. The set turns on and enters service mode.
2-1-2 Initial SERVICE MODE DISPLAY State
2-1-2(A) OSD DISPLAY
2-1-2(B) Button Operations in SERVICE MODE
♣
♣While in Tuner mode, the direct access buttons can be used to select and change channels.
Menu Displays all menus
UP/DOWN Cursor moves to select items
LEFT/RIGHT To increase and decrease the data of the selected items
(ENTER) Confirm your choice(Store OR Enter)
SOURCE button Change input source
Alignment and Adjustments
Samsung Electronics 2-1
2. Alignment and Adjustments
2-1 Service Mode
☞Indicates selected input mode
☞Picture Adjustment
☞Setting the Initial Values
☞Setting the Special Features
☞Options-1 : Particular Product Options
☞Options-2 : PDP Properties Options
☞Initializing after saving the adjustments
☞Software Version Information
Factory Mode Current Input Mode
01. Picture Improvement ▶
02. Initial Setting ▶
03. PIP/Test Pattern ▶
04. Option-1 ▶
05. Option-2 ▶
06. Reset ▶
Release : Aug 13 2004 10:50:22
Version : T-WFGNUS-1004

2-2 WHITE Balance Coordinates
2-2-1 HP-P3761 White Balance Adjustment
1. W/B Adjustment is required for the following five modes :
DVI →Component(720p) →Component(1080i) →VIDEO (Video port) →VIDEO (Graphic port)
2. Adjustment Method (Signal equipment : MSPG-925LTH, Measurement equipment : CA210)
■MSPG-925LTH
Equipment that outputs analog and digital signals simultaneously
(Analog / Digital signal output / TV signal output (S-Video included) / HDTV signal output)
-. Digital Serial : TMDS (DVI24, SiI160) + DVI-I (Analog, Digital)
-. Monitor Signal (Analog): R, G, B, HS, VS, CS
-. TV Signal (CVBS) : NTSC M, NTSC J (7.5 IRE On/Off) (BNC or RCA), PAL B, D, G, H, I, PAL M, Nc
-. D-TV Signal (1080i, 720p, 480p)
♣
♣MSPG-925 is used to adjust the W/B.
■CA210 : Color Analyzers adjusting brightness, chromaticity and etc.
-. R.G.B monochrome correction, brightness and gamma character adjustment
-. White Balance and flickering measurement
(a) DVI
1) Input Toshiba Pattern at 720p resolution using MSPG-925LTH (model:#6, pattern:#16).
2) These are the point of measurement using CA210.
3) Press "MUTE-1-8-2-POWER ON" to enter the factory mode.
4) Change to "'DVI" Mode to key in "SOURCE" button.
5) Select "01.Picture Improvement" →"01.White Balance"
6) Keep the value of Y as adjusting "07.Sub Contrast(for HIGH)" & "08.Sub Brightness(for LOW)".
7) Keep the coordinate value of x and y as adjusting the value of R,G,B.
Adjust the coordinate x as the value of Red, and the coordinate y as the value of Blue.
<※Generally, the value of Green is fixed.>
-. Adjust the value of "Drive(01~03)" as the high point and the value of "Cutoff(04~06)" as low point.
-. the Y,x and y data refer to the "White Balance Coordinates by Mode" table on page 2-4.
(b) Component
1) Input Toshiba Pattern at 720p resolution (model:#6, pattern:#16).
2) Change to "COMPONENT1" Mode to key in "SOURCE" button.
3) Select "01.Picture Improvement" →"01.White Balance".
4) Adjust White Balance by selecting and adjusting Items 01. - 08. as performed in DVI mode.
5) Change input to Toshiba Pattern at 1080i resolution (model:#5, pattern:#16).
6) Adjust White Balance by selecting and adjusting Items 01. - 08. as performed in DVI mode.
Alignment and Adjustments
2-2 Samsung Electronics
HIGH-LIGHT
LOW-LIGHT

Alignment and Adjustments
Samsung Electronics 2-3
(c) Video
The video signal uses the video port when there is no other input signal.
However, signal uses the graphic port in PIP mode, which includes other input signals (PC, DVI, Component, etc.), Video
adjustment should be performed with Video port and Graphic port separately.
1) Input Toshiba Pattern to Video Input (model:#2, pattern:#16).
2) Change to "'AV1" Mode to key in "SOURCE" button.
3) Select "04.Option-1" →"10.Video Port."
4) Set "10. Video Port" equal to "Video".
5) At Main SVC Menu, select "01.Picture Improvement" →"01.White Balance."
6) Adjust Items 01 - 08 as performed in DVI mode.
7) Return to Main SVC menu and select "04.Option-1" →"10.Video Port."
8) Set "10. Video Port" equal to "Graphic".
9) At Main SVC Menu, select "01.Picture Improvement" →"01.White Balance".
10) Adjust Items 01 →08 as performed in DVI Mode.
DVI
(D-RGB)
VSP9437 FLI2310
V-PEAKING Y-Delay
C-Delay
Brightness
Contrast
Saturation
RF
VIDEO
TTX-mode
RGB
Scaler
RGB/YUV
CONTRAST
BRIGHT
ASI510
RGB-cont
RGB-bri
R-gamma
G-gamma
B-gamma
DNIe
Bri-offset
Con-offset
Different adjustment values will be applied
to DVI, DTV(Component) and Video, mode.
Adjustment
Reg
Memory Mode
- DVI
- Video
- Component(DTV)
DS90C385
Progressive
to
Interface
Y/R-gain
Cr/B-gain
Cb/G-gain
Y/R-offset
Cr/b-offset
Cb/G-offset
Adjustment
Reg
Memory
Mode
DTV Mode
Logic
SIL169
SW
IC
R-dri
G-dri
B-dri
R-cutoff
G-cutoff
B-cutoff
Adjustment
Reg
MST9883
CXA2101
YPbPr
DTV
COMPONENT
1, 2
Graphic
Port
Memory Mode
- DVI
- Video
- Component(DTV)
Video
Port
※Thus, Micom saves the W/B data separately for each memory mode of the block (See the block diagram given below) during
W/B adjustment.
TV
SIF
MONO IN
TEA6422
TEA6422
Stereo
Input
Output
S/W
Component
DVI
TEA6422
TEA6422
Stereo
Input
Output
S/W
Video
MSP4440G
MSP4440G
Multi-
standard
Sound
Processor
NSP6241A
NSP6241A
Digital
Audio
Signal
Processor
TAS5112
TAS5112
True Digital
Audio
Amp
Monitor
Out

Alignment and Adjustments
2-4 Samsung Electronics
2-3-1 Factory OSD Main Menu
2-3 Factory Data
☞Indicates selected input mode
☞Picture Adjustment
☞Setting the Initial Values
☞Setting the Special Features
☞Setting particular product options
☞Setting PDP Properties Options
☞Initializing after saving the adjustments
☞Software Version Information
01.Picture Improvement
Factory Mode Current Input Mode
01. Picture Improvement ▶
02. Initial Setting ▶
03. PIP/Test Pattern ▶
04. Option-1 ▶
05. Option-2 ▶
06. Reset ▶
Release : Aug 13 2004 10:50:22
Version : T-WFGNUS-1004
☞White Balance Adjustment
☞Color Adjustment
☞Contrast & Brightness Enhancement
☞Detail Enhancement Sharpness Adjustment
☞Y/C Delay Setting according to the System and
Input Modes
☞Motion Enhancing Adjustment
☞DNIe Registers
☞DNIe Registers
☞Logic Registers of the Panel
☞Picture Size Registers
01.Picture Improvement Current Input Mode
01. White Balance ▶
02. Color ▶
03. Cont/Bri Enhancement ▶
04. Detail Enhancement ▶
05. Y/C Delay ▶
06. Motion ▶
07. DNIe ▶
08. DNIe Additional ▶
09. Logic ▶
10. Picture Size ▶
2-2-2 White Balance Coordinates by Mode
Video Component DVI
H/L
x 263 263 270
y 267 267 290
Y(fL) 30.0 26.0 26.0
L/L
x 263 263 275
y 267 267 290
Y(fL) 0.9 0.8 0.9

Alignment and Adjustments
Samsung Electronics 2-5
01.Picture Improve →
→01.White Balance Adjustment
01~06 : Logic
07~08 : DNIe
09~15 : MST9883
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
01.White Balance Range Mode-1 Mode-2 Mode-3
01. R Drive
0 ~ 255 Logic
130 120 127
02. G Drive 120 120 120
03. B Drive 125 130 125
04. R Cutoff 119 114 116
05. G Cutoff 120 120 120
06. B Cutoff 125 118 121
07. Sub contrast 0 ~ 63 DNIe 33 31 24
08. Sub Brightness 0 ~ 127 45 62 89
09. R Gain
-MST9883 Not Used
128
Not Used
10. G Gain 145
11. B Gain 128
12. R/Cr Offset 63
13. G/Y Offset 54
14. B/Cb Offset 63
15. Auto Color Inhibit Inhibit Inhibit Inhibit
※Input modes require respective storing the changes after adjustments have been made.

Alignment and Adjustments
2-6 Samsung Electronics
01.Picture Improve →
→02.Color Adjustment
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
02. Color Range Mode-1 Mode-2 Mode-3
01. U-Saturation
0 ~ 63
VSP9437
32
Not Used Not Used
02. V-Saturation 32
03. RGB/YUV U-SAT 30
04. RGB/YUV V-SAT 32
05. RGB/YUV Tint 192 ~ 255
0 ~ 63 3
06. FLI-Saturation 0 ~ 255 FLI2310 124
07. R Gamma
0 ~ 63 ASI510
31 31 31
08. G Gamma 32 32 32
09. B Gamma 32 32 32
10. Gain-Sel 0 ~ 3
CXA2151Q
111
11. Cr Gain
0 ~ 7
777
12. Cb Gain 777
13. Y Gain 111
01~05 : VSP9437
06 : FLI2310
07~09 : ASI510
10~13 : CXA2151Q

Alignment and Adjustments
Samsung Electronics 2-7
01.Picture Improve →→04.Detail Enhancement
01~04 : uPD64083
05~10 : VSP9437
11~13 : FLI2310
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
04. Detail Enhancement Range Mode-1 Mode-2 Mode-3
01. VAPGAIN 0 ~ 7
uPD64083
4
Not Used Not Used
02. VAPINV 0 ~ 31 16
03. YPFT 0 ~ 3 3
04. YPFG 0 ~ 15 5
05. APK-1st-BPM 0 ~ 15
VSP9437
1
06. APK-2nd-BPM 0 ~ 7 1
07. Denoise-BPM 0 ~ 3 0
08. APK-1st-HPM 0 ~ 15 4
09. APK-2nd-HPM 0 ~ 7 3
10. Denoise-HPM 0 ~ 3 0
11. HenhGain
0 ~ 255 FLI2310
64
12. HLEGain 64
13. HChrEnGain 32
01.Picture Improve →03.Contrast & Brightness Enhancement
01~04 : VSP9437
05~06 : FLI2310
07~12 : ASI510
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
03. Cont/Bri Enhancement Range Mode-1 Mode-2 Mode-3
01. Contrast
0 ~ 63
VSP9437
32
Not Used Not Used
02. Brightness 48
03. RGB/YUV Contrast 32
04. RGB/YUV Brightness 128 ~ 255
0 ~ 127 15
05. FLI-Contrast 0 ~ 255 FLI2310 128
06. FLI-Brightness 128
07. R Contrast
0 ~ 127
ASI510
32 32 32
08. G Contrast 32 32 32
09. B Contrast 32 32 32
10. R Brightness 192 ~ 255
0~ 63
0 0 0
11. G Brightness 0 0 0
12. B Brightness 0 0 0

Alignment and Adjustments
2-8 Samsung Electronics
01.Picture Improve →
→05.Y/C Delay Setting according to the System and Input Modes
01.Picture Improve →06.Motion Enhancing Adjustment
01~04 : VSP9437
05~06 : FLI2310
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
05. Y/C Delay Range Mode-1 Mode-2 Mode-3
01. NTSC 240 ~ 255
0 ~ 15
VSP9437
251
Not Used Not Used
02. NTSC-AV 250
03. RGB/YUV-Y 0 ~ 127 58
04. RGB/YUV-UV 58
05. FLI-Y 0 ~ 7 FLI2310 5
06. FLI-C 0 ~ 15 11
01 : VSP9437-M
02 : VSP9437-S
03 : FLI2310
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
06. Motion Range Mode-1 Mode-2 Mode-3
01. SLLTHD_RF3CH 0 ~ 3 VSP9437-M 2
Not Used Not Used
02. SLLTHD_ETC VSP9437-S 2
03. V-motion Tresh 0 ~ 255 FLI2310 32
04. ISHFTM 0 ~ 3 1
05. ISHFTS 1

Alignment and Adjustments
Samsung Electronics 2-9
01.Picture Improve →→07.DNIe Registers
01~23 : DNIe
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
07. DNIe Range Mode-1 Mode-2 Mode-3
01. SUB BRIGHT 0
DNIe
Being Controlled by white balance menu.
Impossible to control in here.
02. SUB CONT
03. SCALE MAX
0 ~ 255
48 48 48
04. SCALE MIN 16 16 16
05. DCE CUTOFF 10 10 10
06. DCE UPPER 240 240 240
07. R GAIN 1X 0 ~ 63 555
08. CE UPPER 0 ~ 255 220 220 220
09. CE CUTOFF 32 32 32
10. R GAIN 1Y 0 ~ 63 666
11. R D ALPHAL 0 ~ 255 64 64 64
12. R GAIN 2X 0 ~ 63 544
13. R GAIN 2Y 222
14. R ND ON 0 ~ 1 111
15. R CORING ON 111
16. PATT SET 0 ~ 19 000
17. R CORING TH1
0 ~ 7
222
18. R CORING TH2 222
19. R CORING TH3 222
20. BLACK GAIN 0~65535 2200 2200 2200
21. WHITE GAIN 834 834 834
22. WTE GAIN 0~1023 300 300 300
23. CTE GAIN 0 ~ 255 0 48 48

Alignment and Adjustments
2-10 Samsung Electronics
01.Picture Improve →→08.DNIe Additional Register
01~06 : DNIe
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
08. DNIe Additional Range Mode-1 Mode-2 Mode-3
01. R D ALPHAU 0 ~ 255
DNIe
75 75 75
02. R BLACK GAIN MAX 0 ~ 511 375 300 300
03. R BLACK TILT 0 ~ 255 128 90 90
04. R WHITE GAIN MAX 0 ~ 511 358 300 300
05. DNIe GAMMA 0 ~ 7 000
06. R GAIN3 X 0 ~ 63 000
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
09. Logic Range Mode-1 Mode-2 Mode-3
01. CNDC(READ)
Not Used
DNIe
000
02. ERRS 000
03. ERRC(READ) 000
04. DSPBIT 111
05. QMODE 222
06. CCFMD
0 ~ 1
000
07. DCBON 111
08. DSETEN 000
09. CCFON 000
10. CCFORM 000
11. GAMSEL 0 ~ 7 222
12. R-RATIO
0 ~ 255
255 255 255
13. G-RATIO 235 220 235
14. B-RATIO 240 230 240
15. GAMOO 31 31 31
16. PWMP 0 ~ 1 111
17. PWMAX 0 ~ 3 333
18.DSET 0 ~ 1 000
01.Picture Improve →09.Logic Registers
01~18 : DNIe

Alignment and Adjustments
Samsung Electronics 2-11
01.Picture Improve →→10.Picture Size
02.Initial Setting Current Input Mode
01. Initial P-Mode ▶
02. P-Mode Value ▶
03. Initial Color Tone ▶
04. Color Tone Value ▶
02.Setting the Initial Values
01.Initial P-Mode Current Input Mode
01. Dynamic ▶
02. Standard ▶
03. Movie ▶
04. Custom ▶
02.Initial Setting →→01.Initial P-Mode
02. P-Mode Value Current Input Mode
01. Dynamic ▶
02. Standard ▶
03. Movie ▶
04. Custom ▶
02.Initial Setting →→02.P-Mode Value
☞Indicates selected input mode
☞Reset after saving the P-Mode adjustments
☞P-MODE the data Values
☞Reset after saving the color tone adjustments
☞Color tone the data Values
01~07 : ASI510
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
10. Picture Size Range Mode-1 Mode-2 Mode-3
01. H START OFFSET 0 ~ 31
ASI510
000
02. V START OFFSET 000
03. H END OFFSET
0 ~ 255
000
04. V END OFFSET 000
05. OVERSCAN B 63 63 63
06. OVERSCAN G 63 63 63
07. OVERSCAN R 63 63 63

Alignment and Adjustments
2-12 Samsung Electronics
03.Initial Color Tone Current Input Mode
01. Cool2
02. Cool1
03. Normal
04. Warm1
05. Warm2
※Available options for the DVI Mode are
ColorTone1, ColorTone2, ColorTone3
02.Initial Setting →→03.Initial Color Tone
01.Dynamic Current Input Mode
01. Contrast ◀100 ▶
02. Brightness ◀45 ▶
03. Sharpness ◀75 ▶
04. Color ◀55 ▶
05. Tint ◀50 ▶
02.Initial Setting →→02.P-Mode Value →01.Dynamic
02.Standard Current Input Mode
01. Contrast ◀80 ▶
02. Brightness ◀50 ▶
03. Sharpness ◀50 ▶
04. Color ◀50 ▶
05. Tint ◀50 ▶
02.Initial Setting →→02.P-Mode Value →02.Standard
03.Movie Current Input Mode
01. Contrast ◀65 ▶
02. Brightness ◀55 ▶
03. Sharpness ◀25 ▶
04. Color ◀50 ▶
05. Tint ◀50 ▶
02.Initial Setting →→02.P-Mode Value →03.Movie
04.Custom Current Input Mode
01. Contrast ◀80 ▶
02. Brightness ◀50 ▶
03. Sharpness ◀50 ▶
04. Color ◀50 ▶
05. Tint ◀50 ▶
02.Initial Setting →→02.P-Mode Value →04.Custom

Alignment and Adjustments
Samsung Electronics 2-13
04.Color Tone Value Current Input Mode
01. Cool2
02. Cool1
03. Normal
04. Warm1
05. Warm2
01.Cool2 Current Input Mode Range
01. R Drive offset 192 ~ 255, 0 ~ 63
02. G Drive offset 192 ~ 255, 0 ~ 63
03. B Drive offset 192 ~ 255, 0 ~ 63
04. R Cutoff offset 192 ~ 255, 0 ~ 63
05. G Cutoff offset 192 ~ 255, 0 ~ 63
06. B Cutoff offset 192 ~ 255, 0 ~ 63
07. R Gain 192 ~ 255, 0 ~ 63
08. G Gain 192 ~ 255, 0 ~ 63
09. B Gain 192 ~ 255, 0 ~ 63
※Adjusting and Storing the Changes :
Change the White Balance (Color Temperature)
1. Selecting an item will display the same options as
those of White Balance.
2. Available options for the DVI Mode are ColorTone1,
ColorTone2, ColorTone3.
02.Initial Setting →→04.Color Tone Value
03.PIP/Test Pattern
01~10 : ASI510
11~14 : Logic, ASI510
ITEM Relevant IC Initial Values of Input Modes
Video Component DVI
03.PIP/Test Pattern Range Mode-1 Mode-2 Mode-3
01.PIP R CONT
0 ~ 128
ASI510
32 32 32
02.PIP G CONT 32 32 32
03.PIP B CONT 32 32 32
04.PIP R BRIGHT
192 ~ 255
0 ~ 63
000
05.PIP G BRIGHT 000
06.PIP B BRIGHT 000
07.PIP FILTER LC
Not Used
000
08.PIP FILTER ML 000
09.PIP FILTER MR 000
10.PIP FILTER UC 000
11.LOG PATTERN
Logic
ASI510
000
12.LOG HIGH LEVEL 000
13.LOG LOW LEVEL 000
14.ASI COLORBAR 0 ~ 3 111

Alignment and Adjustments
2-14 Samsung Electronics
04.Option-1
05.Option-2 Current Input Mode
Not Used ◀▶
01. Shift Test ◀0 ▶(0 ~ 1)
02. Pixel Number ◀1 ▶(1 ~ 4)
03. Shift Line ◀1 ▶(1 ~ 4)
Not Used ◀▶
Not Used ◀▶
Not Used ◀▶
07. FLi Memory Clock ◀11 ▶(0 ~ 31)
08. DNIe DEMO ◀On ▶(On/Off)
09. PILOT HIGH ◀21 ▶(0 ~ 31)
10. PILOT LOW ◀16 ▶(0 ~ 31)
11. CHECKSUM ◀0000 ▶
12. DRC-Level ◀40 ▶(0 ~ 63)
13. Asi Memory Clock ◀22 ▶(17 ~ 23)
05.Option-2
01. 0 : minute , 1 : SEC
02. Left,right movement Pixel
03. Upper, low movement Pixel
04.Option-1 Current Input Mode
00. AGC ◀Off ▶
01. Language ◀English ▶
02. DDC Write ◀On ▶
03. Melody Volume ◀6 ▶
04. Tuner ◀2-Tuner ▶
05. LNA ◀On ▶
06. High Deviation ◀Off ▶
07. SD Delay ◀3 ▶
08. HD Delay ◀1 ▶
09. V Mute Time ◀5 ▶
10. Video Port ◀Graphic ▶
11. LNA Plus ◀On ▶
12. V-Chip ◀USA ▶
06. High Deviation : To prevent Sound Buzz resulting from regional conditions of the input signal.
07. SD Delay : AV mode Delay
- 1.8ms delay --------- delay 0
- 38ms delay --------- delay 1
- 54ms delay --------- delay 2
- 108ms delay (max) --------- delay 3
08. HD Delay : DTV/DVI mode Delay
- 1.8ms delay --------- delay 0
- 38ms delay --------- delay 1
- 54ms delay --------- delay 2
- 108ms delay (max) --------- delay 3
10. Video Port : Setting of Aurora Input Port for VIDEO signal
- Graphic : Input Video Signal though Graphic port of Aurora (In case of NON-PIP VIDEO)
- Video : Input Video Signal though Graphic port of Aurora (In case of PIP VIDEO)

Alignment and Adjustments
Samsung Electronics 2-15
2-4 Module Block
SMPS X-SUS Y-SUS
LOGIC
ABUSL ABUSR
MAIN SUB
CN805
CN801
CN802 CN804
CN 23
CN 22
CN 21
CN 26
CN 42
CN 41
CN 09
CN 02
CN 01
CN 11
CN 03
CN 03
CN32
CN31
CN36
CN 52 CN 51
CN1203
CN1204
CN1201 JA1001
CONTROL IRPower S/W
CN201 CN2
CN1
CN102 CN101
Test
Test
Point
Point
VR644(VS)
VR644(VS)
VR501(VA)
VR501(VA)
Adjustment
Adjustment
Point
Point
☞Notes
1. When the SMPS-PCB is replaced, the Va, Vs voltages must be checked and adjusted to the proper levels indicated on the
panel sticker.

Alignment and Adjustments
2-16 Samsung Electronics
2-5 Disassemble and Reassemble
Shield
P-EMI
Holder
Bracket
①Remove the stand after you lay the set down.
2-5-1 PDP Set
③You can replace a defective SMPS & Speaker in this
step. Loosen the screws, and remove the terminal
back.
⑤Loosen the screws, and remove the shield P-EMI.
②Loosen the screws(31EA), and remove the back cover.
④You can replace a defective PCB in this step.
Loosen the screws, and remove the sub back.
⑥You can replace a defective P-function B'd in this step.
You can separate Module & Holder Bkt from cover
front after loosening the screws.
