Samsung LH015I SERIES User manual

Samsung Electronics LED Display Installation
LED Display
Installation Manual
LH015I ***** (P1.5)
LH020I ***** (P2.0)
LH025I ***** (P2.5)
Ver. 2.1

Samsung Electronics LED Display Installation
Table of Contents
1. Specification
1-1 Product Concept
1-2 Specification
1-3 Dimension spec
1-4 Exploded View
1-5 Viewing the Connection
1-6 Accessary [Components]
2. How to install
2-1 How to handle (warning/caution)
2-2 Installation Requirements
2-3 Physical Installation
2-4 Data cabling
2-5 Power cabling
3. Example of Installation
4. Feature
4-1 PC Control Program
4-2 LED Color correction

Samsung Electronics LED Display Installation
[Leeum, Samsung Museum of Art, P1.5 8x4]
1. Specification
1-1 Product Concept
1. LED Display of high-brightness for Indoors
- Product's lineup consist of 1.5mm ,2.0mm and 2.5mm pixel pitch.
- High brightness product for Indoor display(1.5mm/2.0mm 800nit, 2.5mm 2000nit)
- Various sizes of screen configuration
: Users can configure multiple size of screen by LED cabinet unit

Samsung Electronics LED Display Installation
1. Specification
1-1 Product Concept
2. S-BOX solution for Picture Quality Enhancement and various video input
- Support various modes
- Able to adjust picture quality (Brightness, Contrast, etc.,)
- Support HDBT input and output for long distance video signals and control transmission
- Various input port : DP, HDMI, DVI, USB, RJ45
LED Signage BOX LED Display

Samsung Electronics LED Display Installation
Category
P1.5 Cabinet P2.0 Cabinet P2.5 Cabinet
LED
Cabinet
Pixel Pitch 1.5mm 2.0mm 2.5mm
LED Package RGB 3 In 1 1010 RGB 3 In 1 1010 RGB 3 In 1 2121
Pixel 320x360 240x270 192x216
Size 480x540x96.3mm 480x540x96.3mm 480x540x96.7mm
Area 0.26㎡0.26㎡0.26㎡
Aspect Ratio 8:9 8:9 8:9
Weight 9.2kg 9.2kg 9.2kg
Brightness (max)
Min : 25% of max 800nits 800nits 2,000nits
C/R 3,000:1 3,000:1 5,000:1
Brightness Level 15.5bit 15.5bit 15.5bit
Power Consumption 210W 210W 150W
Name of Work Temp 0~40℃0~40℃0~40℃
FHD Size 133.1”(3x6) 173.5”(4x8) 216.8”(5x10)
1. Specification
1-2 Specification

Samsung Electronics LED Display Installation
1-2 Specification
Cabinet Composition and the Number of Cabinets
in the standard of Full HD
SBB-IS08E Reference Picture
(LED Signage Box)
1. Specification
Model Cabinet SBB-IS08E
LH015I*****
(Pitch 1.5) 3 x 6 (18 units)
1 unit
LH020I*****
(Pitch 2.0) 4 x 8 (32 units)
1 unit
LH025I*****
(Pitch 2.5)
5 x 10
(50 units
)
1 unit

Samsung Electronics LED Display Installation
1. Specification
1-3 Dimension spec (unit : mm)
[except the depth of LED ]
P1.5/P2.0: 0.6mm
P2.5 : 1.0mm

Samsung Electronics LED Display Installation
1. Specification
1-4 Exploded View
No.
Item
Qty.
1
POWER INLET
1
2
CIRCUIT BREAKER
1
3
ASSY COVER P
-REAR 1
3.1
COVER REAR
1
3.2
HINGE
2
3.3
CAPTIVE SCREW
1
3.4
SHEET INSULATOR
1
4
SMPS
1
5
MAIN PCB
1
6
COVER HANDLE
2
7
COVER FRAME TOP
1
8
COVER FRAME BOTTOM
1
9
ASSY BRACKET P
-FRONT 1
9.1
BRAKET
-FRONT 1
9.2
INLAY
TERMINAL 1
9.3
HOLDER
-WIRE 2
9.4
HOLDER MAGNET
48
9.5
MAGNET
48
10
COVER
-TOP
BOTTOM LEFT RIGHT
4
11
LED MODULE
6

Samsung Electronics LED Display Installation
1. Specification
1-5 Viewing the Connection

Samsung Electronics LED Display Installation
1. Specification
1-6 Accessary [Components]
Components may vary based on the country.

Samsung Electronics LED Display Installation
2. How to Install
2-1 How to Handle (Warning / Caution)
Location Picture Cautions Estimated
Failure Issue
[No Vibration, Shock or Drop]
▶
Do not give shocks to the LED side or
drop the SET after uncovering the
protection from the product before .
LED cracked
▶
Beware not to lay the product over a
vibrating subject or drop the set on the
back side of the product.
LED cracked
[Caution for Corner Damage]
▶
Beware of corner damage on the LED
module particularly, due to contacts on
the exterior.
LED cracked
[Do not let panel face down]
▶
Do not lay the product having the LED
side as the bottom side after uncovering
the protection from the product before
LED cracked
Front
Upper –Long
Right - Short
Left –Short
Lower –Long
MODULE
Corner edge
MODULE
Front
Front
Upper –Long
Right - Short
Left –Short
Lower –Long
Front
Upper –Long
Right - Short
Left –Short
Lower –Long
Front
Upper –Long
Right - Short
Left –Short
Lower –Long
MODULE

Samsung Electronics LED Display Installation
2. How to install
Location Picture Cautions Estimated
Failure Issue
[Beware of LED Damage due to Static]
▶
Do not work on the LED surface with
hands not wearing antistatic glove
LED cracked
[Beware of LED Damage due to
Attachment of Metal Substances]
▶
There is magnetic on the front side of
LED. Beware not to have any metal
substances be attached to the surface.
▶
When any metal substances are
attached, use air gun or magnetic to
remove them. When you use magnetic to
remove the substances, the module may
be unlocked. So determine whether to
remove after separating it or having it
attached depending on the attachment
status.
LED damage in
the shape of
magnetic goods
that were used
during the
damage
Front
Upper –Long
Right - Short
Left –Short
Lower –Long
Front
Upper –Long
Right - Short
Left –Short
Lower –Long
Metal Dust
2-1 How to Handle (Warning / Caution)

Samsung Electronics LED Display Installation
2. How to install
1. If LED display area is under construction, you should cover the LED surface with
protection sheet to prevent dust (metal dust) stick to LED surface.
LED surface must be cover if display area is under construction
2-1 How to Handle (Cleaning metal dust)
2. Clean dust on the LED surface with Cleaner machine (must use a soft brush head)
Soft brush

Samsung Electronics LED Display Installation
2. How to install
2-1 How to Handle (Cleaning metal dust) Magnet
3. Each LED Module have 8 magnet positions (picture 1)
So depend on environment , the metal dust may stick to LED surface.
So have to check the LED surface again at Magnet position.
Incase of Metal Dust stick to LED surface, we can remove it by
- Remove LED module with metal dust (Refer to page 45)
- Putting a magnet clock on LED surface
- Slowly move it around the metal dust area.
- Metal Dust will stick to Magnet Block.
- Remove Magnet Block and clean it for next times using.
Metal Dust
Magnet
block
Magnet block after
removing from LED surface
[Picture 1]

Samsung Electronics LED Display Installation
2. How to install
2-2 Installation Requirements (Circuit)

Samsung Electronics LED Display Installation
2. How to install
2-2 Installation Requirements (Circuit)
Static Electricity Precautions

Samsung Electronics LED Display Installation
2. How to install
2-2 Installation Requirements (Circuit)
Installation Precautions

Samsung Electronics LED Display Installation
2. How to install
2-2 Installation Requirements (Software)
-Desktop or Notebook PC installed with Operating System of below:
∙Windows 7 32bit/64bit
∙Windows 8 32bit/64bit
-Software
∙.Net Framework 4.5 or above

Samsung Electronics LED Display Installation
2. How to install
2-2 Installation Requirements (Mechanical)
- Support structure for Product Installation
The types of support structure may vary, because it is determined differently according to
the customers’ taste and needs. Thus, spec all differs. Below items should be considered in
detail before is carried out.
1. Weight tolerances : Check whether the SET structure gets to be supported by the floor
or to be hung on a wall. Installation should be done considering the weight of the
product.
2. Environmental conditions : If the level of humidity and temperatures are high in the
surroundings, those conditions should be considered.
3. Locations : This product is for indoors, and should be located in a place where the
product is not likely to be affected by direct sunlight.
4. Ground stability
5. Front clearances: Check whether there are enough space and viewing angle in front of
the display to provide the most optimal impact to viewers.
6. Rear clearances : Needs to secure enough space to a worker in all kinds of structure.
7. Local regulations should be considered for each type of

Samsung Electronics LED Display Installation
2. How to install
2-2 Installation Requirements
-Make sure to have enough space at least 60cm from the rear of set, when a
support structure is installed on the floor, to accommodate a worker and a tool,
for a example, ladder, etc. When the height of a structure is too high, Samsung
recommend to install ‘ Cat Walk’ at the rear of set and a lift in the front of set so
that workers can work easily in a high area.
At least 60cm
Cat Walk
Lift
