Samsung PS42P4A1X User manual

PLASMA DISPLAY TV
Chassis : D68A(P)Europe42”_DNIe3
Model : PS42P4A1X/XEC
PLASMA DISPLAY TV CONTENTS
Specifications
Alignment and Adjustments
Exploded View and Parts List
Service Item
Schematic Diagrams
1.
2.
3.
4.
5.
SERVICE Manual

ELECTRONICS
This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
©Samsung Electronics Co., Ltd. Nov. 2004
Printed in Korea
AA82-02078A

Specifications
Samsung Electronics 1-1
1. Specifications

Alignment and Adjustments
Samsung Electronics 2-1
2. Alignment and Adjustments
2-1 Service Mode
2-1-1 SERVICE MODE Entry Method (General Transmitter)
■For the General Transmitter
1. Turn the power off and set to stand-by mode.
2. Press the buttons of the transmitter in this order; INFO-MENU-MUTE-POWER ON to turn the set on.
3. The set turns on and enters service mode.
■For the Factory Transmitter
1. Turn the power on.
2. Press the buttons of the transmitter in this order : INFO-Factory.
3. The set enters service mode.
* If you fail to enter service mode, repeat steps 1 and 2 above.
2-1-2 Initial DISPLAY State of SERVICE MODE
2-1-2(A) OSD DISPLAY
2-1-2(B) Button Operations in SERVICE MODE
Menu Displays all menus
UP/DOWN Cursor move to select items
LEFT/RIGHT Enable to increase and decrease the data of the selected items
(ENTER) Confirm your choice(Store OR Enter)
☞Indicates selected input mode
☞Picture Adjustment
☞Setting the Initial Values
☞Setting the Special Features
☞Options-1 : Options of the Product Particulars
☞Options-2 : Options of the PDP Properties
☞Initializing after saving the adjustments
☞Software Version Information
Factory Mode Current Input Mode
01. Picture Improvement ▶
02. Initial Setting ▶
03. PIP/TTX/Test Pattern ▶
04. Option-1 ▶
05. Option-2 ▶
06. Reset ▶
Release : Oct 06 2004 11 : 41 : 14
Version : T-NPL42PEU1-1215

Alignment and Adjustments
2-2 Samsung Electronics
2-2 WHITE Balance Coordinates
2-2-1 PS42P4A1 White Balance Adjustment
1. W/B Adjustment is required for the following four modes: DVI-> COMPONENT-> PC->VIDEO
2. Adjustment Method
(Signal equipment : MSPG-925LTH, Measurement equipment : CA210)
(1) Adjust the target set by adjusting the panel logic and the video DNIe adjustment register in
order to determine the referential W/B of the panel with a DVI input, which is the full digital path.
(2)For Component adjustment, adjust the adjustment register of AD9883 to align the DTV signal
to the DNIe and logic panel value which was fixed with a DVI adjustment so that they are
in effect considered to be the same signals. (At this time, do not adjust the gain of AD9883 -> the Highlight W/B does not need
to be adjusted since its deviation falls within valid distribution range.)
(3)PC adjustment is same as Component adjustment. (The offset can be applied to the values obtained through DTV adjustment.
However, additional adjustment is required for Y, Cb, and Cr of Component since PC processes R, G, and B signals.)
* Attention for Component/PC adjustment
- Load the Auto color pattern. (Pattern #21)
- Excute Auto color of factory mode to adjust gain and offset.
- Load the Toshiba Pattern.(Pattern #16) and then adjust W/B.
(4)Video adjustment is performed with the Toshiba pattern (in-house signal) and differs from the VG828 signals in the above
three modes. Hence, it should be performed with the same method of (1) DVI adjustment.
Also, Video adjustment should be performed with Video port and Graphic port separately.
* Thus, Micom saves the W/B data separately for each memory mode of the block (See the block diagram given below) during W/B
adjustment.

Alignment and Adjustments
Samsung Electronics 2-3
1-3-1 Factory OSD Main Menu
1-3 Factory Data
01.Picture Improve
H/L
L/L
x
y
Y(fL)
x
y
Y(fL)
VIDEOI
268
263
32
268
263
1.6
Component
268
263
32
268
263
1.4
PC
283
295
30
283
295
0.9
DVI
283
295
28
283
295
0.9
1-2-2 White Balance Coordinates by Mode
☞Indicates selected input mode
☞Picture Adjustment
☞Setting the Initial Values
☞Setting the Special Features
☞Setting the Options of the Product Particulars
☞Setting the Options of the PDP Properties
☞Initializing after saving the adjustments
☞Software Version Information
Factory Mode Current Input Mode
01. Picture Improvement ▶
02. Initial Setting ▶
03. PIP/TTX/Test Pattern ▶
04. Option-1 ▶
05. Option-2 ▶
06. Reset ▶
Release : Oct 06 2004 11 : 41 : 14
Version : T-NPL42PEU1-1215
☞White Balance Adjustment
☞Color Adjustment
☞Contrast & Brightness Enhancement
☞Detail Enhancement Sharpness Adjustment
☞Y/C Delay Setting according to the System and
Input Modes
☞Motion Enhancing Adjustment
☞DNIe Registers
☞DNIe Registers
☞Logic Registers of the Panel
☞Picture Size Registers
01.Picture Improvement Current Input Mode
01. White Balance ▶
02. Color ▶
03. Cont/Bri Enhancement ▶
04. Detail Enhancement ▶
05. Y/C Delay ▶
06. Motion ▶
07. DNIe ▶
08. DNIe Additional ▶
09. Logic ▶
10. Picture Size ▶

Alignment and Adjustments
2-4 Samsung Electronics
01.Picture Improve => 01.White Balance Adjustment
01.White Balance
01.R Drive
02.G Drive
03.B Drive
04.R Cutoff
05.G Cutoff
06.B Cutoff
07.Sub Contrast
08.Sub Brightness
09.R Gain
10.G Gain
11.B Gain
12.R/Cr Offset
13.G/Y Offset
14.B/Cb Offset
15.Auto color
TV
128
128
128
120
120
120
31
63
X
X
X
X
X
X
on/off
Mode-1
128
128
128
120
120
120
W/B
W/B
x
x
x
x
x
x
x
Mode-2
128
128
128
120
120
120
W/B
W/B
128
144
128
64
53
64
X
Mode-3
128
128
128
120
120
120
W/B
W/B
128
128
128
64
64
64
X
Mode-4
128
128
128
120
120
120
W/B
W/B
x
x
x
x
x
x
x
Initial Values of Input Modes
Video Component PC DVI
Relevant IC
DNIe
ASI510
AD9883
ITEM
hInput modes require respective storing the changes after adjustment.
01~06 : DNIe
07~08 : ASI510
09~15 : AD9883

Alignment and Adjustments
Samsung Electronics 2-5
01.Picture Improve => 02.Color Adjustment
02.Color
01.U-Saturation
02.V-saturation
03.RGB/YUV U-SAT
04.RGB/YUV V-SAT
05.RGB/YUV Tint
06.FLI-saturation
07.R Gamma
08.G Gamma
09.B Gamma
10.Gain-Sel
11.Cr Gain
12.Cb Gain
13.Y Gain
14.FLI - Y/G Bir
15.FLI - Cr/R Bir
16.FLI - Cb/B Bir
TV
32
34
24
24
3
120
32
32
32
1
7
7
1
0
0
0
Mode-1
32
34
24
24
3
120
32
32
32
1
7
7
1
0
0
0
Mode-2
x
x
x
x
x
x
32
32
32
x
x
x
x
0
0
0
Mode-3
x
x
x
x
x
x
32
32
32
x
x
x
x
0
0
0
Mode-4
x
x
x
x
x
x
32
32
32
x
x
x
x
0
0
0
Initial Values of Input Modes
PC DVI
Relevant IC
VSP9437
FLI2310
ASI510
CXA2151
FLI2310
ITEM
01 ~05 : VSP9437
07~09 : ASI510
06 , 14~16 : FLI2310
10~13 : CXA2151
Video Component

Alignment and Adjustments
2-6 Samsung Electronics
01.Picture Improve => 03.Contrast & Brightness Enhancement
03.Cont/Bri Enhancement
01.Contrast
02.Brightness
03.RGB/YUV Contrast
04.RGB/YUV Brightness
05.FLI-Contrast
06.FLI-Brightness
07.R Contrast
08.G Contrast
09.B Contrast
10.R Brightness
11.G Brightness
12.B Brightness
TV
32
45
37
10
100
128
32
32
32
0
0
0
Mode-1
32
45
37
10
100
128
32
32
32
0
0
0
Mode-2
x
x
x
x
x
x
32
32
32
0
0
0
Mode-3
x
x
x
x
x
x
32
32
32
0
0
0
Mode-4
x
x
x
x
x
x
32
32
32
0
0
0
Initial Values of Input Modes
PC DVI
Relevant IC
VSP9437
FLI2310
ASI510
ITEM
01~04 : VSP9437
07~12 : ASI510
05~06 : FLI2310
Video Component

Alignment and Adjustments
Samsung Electronics 2-7
01.Picture Improve => 04.Detail Enhancement
04.Detail Enhancement
01.VAPGAIN
02.VAPINV
03.YPFT
04.YPFG
05.APK-1st-BPM
06.APK-2nd-BPM
07.Denoise-BPM
08.APK-1st-HPM
09.APK-2nd-HPM
10.Denoise-HPM
11.HenhGain
12.HLEGain
13.HChrEnGain
TV
x
x
x
x
1
2
1
5
2
0
64
64
32
Mode-1
x
x
x
x
1
2
1
5
2
0
64
64
32
Mode-2
x
x
x
x
x
x
x
x
x
x
x
x
x
Mode-3
x
x
x
x
x
x
x
x
x
x
x
x
x
Mode-4
x
x
x
x
x
x
x
x
x
x
x
x
x
Initial Values of Input Modes
PC DVI
Relevant IC
uPD64083
VSP9437
FLi2310
ITEM
01~04 : uPD64083
05~10 : VSP9437
11~13 : FLI2310
Video Component
