Samsung QM85D-BR User manual

User Manual
The color and the appearance may differ depending on the product, and the
specifications are subject to change without prior notice to improve the performance.
Recommended hours of use per day of this product is under 16 hours.
If the product is used for longer than 16 hours a day, the warranty may be void.
QM85D QM85D-BR

Table of contents
Before Using the Product
Copyright 5
Safety Precautions 6
Symbols 6
Cleaning 6
Storage 7
Electricity and Safety 7
Installation 8
Operation 10
Precautions when handling the panel 13
Preparations
Checking the Components 14
Components 14
Items sold separately 15
Parts 16
Control Panel 16
Reverse Side 18
Anti-theft Lock 19
Remote Control 20
Connection Using an IR Stereo Cable
(sold separately) 22
Before Installing the Product
(Installation Guide) 23
Tilting Angle and Rotation 23
Ventilation 23
Dimensions 24
Installing the Wall Mount 25
Installing the Wall Mount 25
Wall Mount Kit Specifications (VESA) 25
Remote Control (RS232C) 26
Cable Connection 26
Connection 29
Control Codes 30
Connecting and Using a Source
Device
Before Connecting 39
Pre-connection Checkpoints 39
Connecting to a PC 39
Connection using the D-SUB cable (Analog type) 39
Connection using a DVI cable (Digital type) 40
Connection Using an HDMI-DVI Cable 40
Connection Using an HDMI Cable 41
Connection Using an DP Cable 41
Connecting to a Video Device 42
Connection Using an HDMI-DVI Cable 42
Connection Using an HDMI Cable 43
Connecting to an Audio System 43
Connecting the LAN Cable 44
Attaching the Network box (Sold separately) 45
Connecting the Network box
(Sold separately) 46
MagicInfo 46
Connecting the touch overlay 48
Connection via a network box 48
Connection via a computer 48
Changing the Input source 49
Source 49
Using MDC
MDC Program Installation/Uninstallation 50
Installation 50
Uninstallation 50
Connecting to MDC 51
Using MDC via RS-232C
(serial data communications standards) 51
Using MDC via Ethernet 52
Home feature
Multi Screen 54
Picture Mode 55
On/Off Timer 56
On Timer 56
Off Timer 56
Holiday Management 57
Network Settings 58
2

Table of contents
MagicInfo Player I 59
ID Settings 60
Device ID 60
PC Connection Cable 60
Video Wall 61
Video Wall 61
Horizontal x Vertical 61
Screen Position 62
Format 62
More settings 63
Screen Adjustment
Picture Mode 64
Backlight / Brightness / Contrast /
Sharpness / Color / Tint (G/R) 65
Color Temperature 66
White Balance 66
Gamma 67
Calibrated Value 67
Picture Options 68
Color Tone 69
Digital NR 69
HDMI Black Level 69
Film Mode 69
Auto Motion Plus 70
Dynamic Backlight 70
Picture Size 71
Picture Size 71
Zoom/Position 72
Resolution 72
Auto Adjustment 73
PC Screen Adjustment 73
Picture Off 74
Reset Picture 74
OnScreen Display
Multi Screen 75
Multi Screen 75
Rotation 80
Rotate Menu 80
Rotate Content 80
Aspect Ratio 80
Screen Protection 81
Pixel Shift 81
Timer 82
Immediate Display 83
Side Gray 83
Message Display 83
Source Info 83
No Signal Message 83
MDC Message 83
Menu Language 84
Reset OnScreen Display 84
System
Setup 85
Initial settings (System) 85
Time 86
Clock Set 86
DST 86
Sleep Timer 86
Power On Delay 86
MagicInfo I Source 87
Auto Source Switching 88
Auto Source Switching 88
Primary Source Recovery 88
Primary Source 88
Secondary Source 88
Power Control 89
Auto Power On 89
PC Module Power 89
Standby Control 90
Network Standby 90
Power Button 90
Eco Solution 91
Energy Saving 91
Eco Sensor 91
Screen Lamp Schedule 91
3

Table of contents
No Signal Power Off 92
Auto Power Off 92
Temperature Control 92
Change PIN 93
General 94
Security 94
HDMI Hot Plug 94
Reset System 95
Sound Adjustment
HDMI Sound 96
Sound on Video Call 97
Speaker Selection 97
Reset Sound 98
Support
Software Update 99
Contact Samsung 99
Go to Home 100
Multi Screen 100
Picture Mode 100
On/Off Timer 100
Network Settings 100
MagicInfo Player I 100
ID Settings 101
Video Wall 101
More settings 101
Reset All 102
Troubleshooting Guide
Requirements Before Contacting Samsung
Customer Service Center 103
Testing the Product 103
Checking the Resolution and Frequency 103
Check the followings. 104
Q & A 111
Specifications
General 113
PowerSaver 115
Preset Timing Modes 116
Appendix
Responsibility for the Pay Service
(Cost to Customers) 119
Not a product defect 119
A Product damage caused by customer's fault 119
Others 119
WEEE 120
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment) 120
Correct disposal of batteries in this product 120
Optimum Picture Quality and Afterimage
Burn-in Prevention 121
Optimum Picture Quality 121
Prevention of Afterimage Burn-in 121
License 123
Terminology 124
4

5
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
©2015 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
•An administration fee may be charged if either
-(a) an engineer is called out at your request and there is no defect in the product
(i.e. where you have failed to read this user manual).
-(b) you bring the unit to a repair Center and there is no defect in the product
(i.e. where you have failed to read this user manual).
•The amount of such administration charge will be advised to you before any work or home visit is carried out.
Chapter 01

6
Safety Precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been
included with this product.
Symbols
Warning
A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
Cleaning
―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
―Take the following steps when cleaning.
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
1
Power off the product and computer.
2
Disconnect the power cord from the product.
―Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
!
3
Wipe the product with a clean, soft and dry cloth.
•Do not use detergents that contain alcohol, solvent or
surface-active agents.
•Do not spray water or detergent directly on the product.
4
Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the product.
5
Connect the power cord to the product when cleaning is finished.
6
Power on the product and computer.

7
Storage
Due to the characteristics of high-glossy products, using a UV humidifier nearby may create
white-colored stains on the product.
―Contact Customer Service Center if the inside of the product needs cleaning (service fee will be
charged).
Electricity and Safety
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
•An electric shock or fire may result.
Do not use multiple products with a single power socket.
•Overheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock
may result.
!
Insert the power plug all the way in so it is not loose.
•An unsecure connection may cause a fire.
!
Connect the power plug to a grounded power socket
(type 1 insulated devices only).
•An electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the
power cord under a heavy object.
•Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
•A fire or electric shock may result.
!
Clean any dust around the pins of the power plug or the power socket with
a dry cloth.
•A fire may result.

8
Caution
Do not disconnect the power cord while the product is being used.
•The product may become damaged by an electric shock.
!
Only use the power cord provided with your product by Samsung. Do not
use the power cord with other products.
•A fire or electric shock may result.
!
Keep the power socket where the power cord is connected unobstructed.
•The power cord must be disconnected to cut off power to the product
when an issue occurs.
•Note that the product is not completely powered down by using only
the power button on the remote.
!
Hold the plug when disconnecting the power cord from the power socket.
•An electric shock or fire may result.
Installation
Warning
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
•A fire may result.
!
Have a technician install the wall-mount hanger.
•Installation by an unqualified person can result in an injury.
•Only use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or
closet.
•An increased internal temperature may cause a fire.
!
Install the product at least 10 cm away from the wall to allow ventilation.
•An increased internal temperature may cause a fire.
!
Keep the plastic packaging out of the reach of children.
•Children may suffocate.

9
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
•The product may fall and become damaged and/or cause an injury.
•Using the product in an area with excess vibration may damage the
product or cause a fire.
!
Do not install the product in a vehicle or a place exposed to dust, moisture
(water drips, etc.), oil, or smoke.
•A fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
•The product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
•The product may fall and injure children.
•As the front is heavy, install the product on a flat and stable surface.
Edible oil, such as soybean oil, can damage or deform the product. Do not
install the product in a kitchen or near a kitchen counter.
Caution
!
Do not drop the product while moving.
•Product failure or personal injury may result.
Do not set down the product on its front.
•The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the
bottom edge of the front of the product is not protruding.
•The product may fall and become damaged and/or cause an injury.
•Install the product only on cabinets or shelves of the right size.
!
Set down the product gently.
•Product failure or personal injury may result.
SAMSUNG
!
Installing the product in an unusual place (a place exposed to a lot of fine
dust, chemical substances, extreme temperatures or a significant presence
of moisture, or a place where the product will operate continuously for an
extended period of time) may seriously affect its performance.
•Be sure to consult Samsung Customer Service Center if you want to
install the product at such a place.

10
Operation
Warning
There is a high voltage inside the product. Never disassemble, repair or
modify the product yourself.
•A fire or electric shock may result.
•Contact Samsung Customer Service Center for repairs.
!
To move the product, first disconnect all the cables from it, including the
power cable.
•Otherwise, the power cord may be damaged and a fire or electric
shock may result.
!
If the product generates abnormal sounds, a burning smell or smoke,
disconnect the power cord immediately and contact Samsung Customer
Service Center.
•An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
•Children may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power
switch and disconnect the power cord. Then contact Samsung Customer
Service Center.
•Continued use can result in a fire or electric shock.
Do not leave heavy objects or items that children like (toys, sweets, etc.) on
top of the product.
•The product or heavy objects may fall as children try to reach for the
toys or sweets resulting in a serious injury.
!
During a lightning or thunderstorm, power off the product and remove the
power cable.
•A fire or electric shock may result.
!
Do not drop objects on the product or apply impact.
•A fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
•Product failure, an electric shock or fire may result from a damaged
cable.
!GAS
If a gas leakage is found, do not touch the product or power plug. Also,
ventilate the area immediately.
•Sparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
•Product failure, an electric shock or fire may result from a damaged
cable.

11
!
Do not use or keep combustible spray or an inflammable substance near
the product.
•An explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
•An increased internal temperature may cause a fire.
100
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects
that burn easily (paper, matches, etc) into the product (via the vent or input/
output ports, etc).
•Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
•Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•Product failure, an electric shock or fire may result.
Caution
!
Leaving the screen fixed on a stationary image for an extended period of
time may cause afterimage burn-in or defective pixels.
•Activate power-saving mode or a moving-picture screen saver if you
will not be using the product for an extended period of time.
-_-
!
Disconnect the power cord from the power socket if you do not plan on
using the product for an extended period of time (vacation, etc).
•Dust accumulation combined with heat can cause a fire, electric shock
or electric leakage.
!
Use the product at the recommended resolution and frequency.
•Your eyesight may deteriorate.
Do not hold the product upside-down or move it by holding the stand.
•The product may fall and become damaged or cause an injury.
!
Looking at the screen too close for an extended period of time can
deteriorate your eyesight.
Do not use humidifiers or stoves around the product.
•A fire or electric shock may result.

12
!
Rest your eyes for more than 5 minutes for every 1 hour of product use.
•Eye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an
extended period of time as it will become hot.
!
Store small accessories out of the reach of children.
!
Exercise caution when adjusting the product angle or stand height.
•Your hand or finger may get stuck and injured.
•Tilting the product at an excessive angle may cause the product to fall
and an injury may result.
Do not place heavy objects on the product.
•Product failure or personal injury may result.
When using headphones or earphones, do not turn the volume too high.
•Having the sound too loud may damage your hearing.
Be careful that children do not place the battery in their mouths when
removed from the remote control. Place the battery in a location that
children or infants cannot reach.
•If children have had the battery in their mouths, consult your doctor
immediately.
When replacing the battery, insert it with the right polarity (+, -).
•Otherwise, the battery may become damaged or it may cause fire,
personal injury or damage due to leakage of the internal liquid.
!
Use only the specified standardized batteries, and do not use a new battery
and a used battery at the same time.
•Otherwise, the batteries may be damaged or cause fire, personal injury
or damage due to a leakage of the internal liquid.
!
The batteries (and rechargeable batteries) are not ordinary refuse and must
be returned for recycling purposes. The customer is responsible for returning
the used or rechargeable batteries for recycling.
•The customer can return used or rechargeable batteries to a nearby
public recycling center or to a store selling the same type of the
battery or rechargeable battery.

13
Precautions when handling the panel
Do not stand the product as shown in the image. The panel is fragile and
can get damaged.
!
Lay the product down to handle it as shown in the image. (the packaging
can be used).
!
Ensure you use the handles on the back when moving the product.
15 mm
Do not hold or grasp any area of the product within 15 mm from the front.

14
-Contact the vendor where you
purchased the product if any
components are missing.
-The appearance of the components and
items sold separately may differ from the
image shown.
Checking the Components
Components
―Components may differ in different locations.
Quick setup guide Warranty card
(Not available in some locations) Regulatory guide Power cord
+
+
-
-
Batteries
(Not available in some locations) Remote Control DP cable Touch Pen (1EA) (QM85D-BR Model Only)
External IR cable
(QM85D-BR Model Only)
Preparations
Chapter 02

15
Items sold separately
-The following items can be purchased
at your nearest retailer.
Wall-mount Kit RS232C-Stereo cable DVI cable HDMI-DVI cable
DP-DVI cable
(Used to connect a network
box)
HDMI cable D-SUB cable RS232C(IN) adapter RS232C(OUT) adapter Stereo cable
RCA stereo cable LAN cable Network Box
-The RS232C adapter can be used to
connect to another monitor using the
D-SUB (9-pin) type RS232C cable.
-Ensure you connect each of the adapters
to the correct RS232C IN or OUT port on
the product.

16
Parts
Control Panel
Panel Key
Speaker
―The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve
quality.
Panel Key
Buttons Description
Power on the product.
If you press the button when the product is turned on, the control menu will be
displayed.
―To exit the OSD menu, press and hold the panel key for at least one second.
Move to the upper or lower menu. You can also adjust the value of an option.
Move to the left or right menu.
―You can adjust the volume by moving the panel key left or right when the control
menu is not displayed.
Remote sensor
Press a button on the remote control pointing at the sensor on the front of the
product to perform the corresponding function.
―Using other display devices in the same space as the remote control of this
product can cause the other display devices to be inadvertently controlled.
Use the remote control within 7 m to 10 m from the sensor on the product at an angle of 30 from the left and right.
―Store used batteries out of reach of children and recycle.
―Do not use a new and used battery together. Replace both batteries at the same time.
―Remove batteries when the remote control is not to be used for an extended period of time.
Remote sensor

17
―If you press the button on the panel key when the product is turned on, the
control menu will be displayed.
Control menu
Buttons Description
Source
Select the connected input source.
Move the panel key right to select Source in the control menu. When the list of
input sources is displayed, move the panel key left or right to select the desired input
source. Next, press the panel key.
Menu
Display the OSD menu.
Move the panel key left to select Menu in the control menu. The OSD control
screen will appear. Move the panel key right to select the desired menu. You can
select a sub-menu item by moving the panel key up, down, left, or right. To change
settings, select the desired menu and press the panel key.
Home Enter Go to Home mode.
Move the panel key up to select Home in the control menu.
Power O
Power off the product.
Move the panel key down to select
Power O
in the control menu. Next, press
the panel key.
Return Exit the control menu.
Return

18
Reverse Side
―The color and shape of parts may differ from what is shown. Specifications are
subject to change without notice to improve quality.
DVI IN /
MAGICINFO IN
RGB / DVI /
HDMI /
AUDIO IN
RJ45
IR /AMBIENT
SENSOR IN
HDMI IN 3
HDMI IN 2
HDMI IN 1
USB
DP IN 3
(UHD 30Hz)
DP IN 2
(UHD 60Hz)
DP IN 1
(UHD 60Hz)
RGB IN
IR OUT
AUDIO OUT
RS232C OUT RS232C IN
Port Description
IR /AMBIENT SENSOR IN
Supplies power to the external sensor board or receives the light sensor signal.
―If you connect an external IR that has the illumination sensor function to
the QMD-BR model, the Eco Sensor starts to operate.
HDMI IN 1, HDMI IN 2, HDMI IN 3
Connects to a source device using a HDMI cable or HDMI-DVI cable.
DP IN 3 (UHD 30Hz)
Connects to a PC using a DP cable.
―Obtain sharp picture quality when viewing UHD content at 30 Hz.
―The recommended resolution for the DP IN 3 (UHD 30Hz) port is 3840 x
2160 @ 30 Hz. The resolution can be changed to the optimal resolution of
3840 x 2160 @ 30 Hz, if required.
DP IN 2 (UHD 60Hz)
Connects to a PC using a DP cable.
―Obtain sharp picture quality when viewing UHD content at 60 Hz.
DP IN 1 (UHD 60Hz)
DVI IN / MAGICINFO IN
DVI IN: Connects to a source device using a DVI cable or HDMI-DVI cable.
MAGICINFO IN: To use MagicInfo, make sure to connect the DP-DVI cable.
RJ45
Connects to MDC using a LAN cable.
IR OUT
Receives the remote control signal via the external sensor board and outputs the
signal via LOOP OUT.
RS232C OUT
Connects to MDC using an RS232C adapter.
RS232C IN
USB
Connects to a USB device when upgrading software.
RGB IN
Connects to a source device using a D-SUB cable.
AUDIO OUT
Connects to the audio of a source device.
RGB / DVI / HDMI / AUDIO IN
Receives sound from a PC via an audio cable.

19
Anti-theft Lock
―An anti-theft lock allows you to use the product securely even in public places.
―The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details.
To lock an anti-theft locking device:
1
Fix the cable of your anti-theft locking device to a heavy object such as a desk.
2
Put one end of the cable through the loop on the other end.
3
Insert the locking device into the anti-theft lock slot at the back of the product.
4
Lock the locking device.
-An anti-theft locking device can be purchased separately.
-Refer to the user guide provided with your anti-theft locking device for details.
-Anti-theft locking devices can be purchased at electronics retailers or online.

20
-Remote control button functions may
differ for different products.
Remote Control
―Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.
―A button without a description in the image below is not supported on the product.
HOME
MENU
POWER
OFF
VOL
CH
MagicInfo
Player I
.QZ
1
ABC
2
DEF
3
GHI
4
JKL
5
MNO
6
SYMBOL
0
PRS
7
TUV
8
WXY
9
MUTE
DEL-/--
SOURCE
CH LIST
Power off the product.
Number buttons
Enter the password in the OSD menu.
Mute the sound.
Unmuting the sound: Press MUTE again or press
the volume control(+ VOL -) button.
Go to Home Launch Button.
Display or hide the onscreen display menu, or
return to the previous menu.
Power on the product.
Adjust the volume.
Change the input source.
MagicInfo Player I Launch Button.
Not Available.Not Available.
