Samsung SyncMaster 711MP User manual

Install Drivers Install Pro
g
rams
SyncMaster 711MP

Notational
Failure to follow directions noted by this symbol could result in bodily harm or damage to
equipment.
Prohibited Important to read and understand at all times
Do not disassemble Disconnect the plug from the outlet
Do not touch Grounding to prevent an electric shock
Power
When not used for extended period of time, set your computer to DPMS.
If using a screen saver, set it to the active screen mode.
Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.
Do not pull the plug out by the wire nor touch the plug with wet hands.
zThis may cause an electric shock or fire.
Use only a properly grounded plug and receptacle.
zAn improper ground may cause electric shock or equipment damage.
Insert the power plug firmly so that it does not come loose.
zA bad connection may cause fire.
Do not excessively bend the plug and wire nor place heavy objects upon them,
which could cause damage.
zThis may cause an electric shock or fire.
Do not connect too many extension cords or plugs to an outlet.
zThis may cause fire.
Installation
Be sure to contact an authorized service center, when installing your monitor in a
location with the heavy dust, high or low temperatures, high humidity, chemical
substance and where it operates for 24 hours such as the airport, the train station or etc.
zFailure to do so ma
y
cause a serious dama
g
e to
y
our monitor.
Put your monitor in a location with low humidity and a minimum of dust.
zFailure to do so may cause an electric shock or fire inside the monitor.
Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.
Install the monitor base in a showcase or shelf so that the end of the base does
not protrude from the showcase or shelf.
zDropping the product may cause damage to the product or personal injury.
Do not place the product on the floor.
zSomeone, specifically children could trip over it.
Do not place the product on an unstable or small surface area.
zPlace the product on an even, stable surface, as the product may fall and
cause harm to someone walking by, specifically children.
Keep any flammable objects such as candles, insecticides or cigarettes away
from the product.
zOtherwise, this may cause a fire.
Keep any heating devices away from the power cable.
zA melted coating may lead to electric shock or fire.
Do not install the product in places with poor ventilation, for instance, a
bookshelf, closet, etc.
zAny increase in internal temperature may cause fire.
Set down the monitor carefully.
zThe monitor could be damaged or broken.
Do not place the monitor face down.
zThe TFT-LCD surface may be damaged.
Installing a wall bracket must be done by a qualified professional.

zInstallation by unqualified personnel may result in injury.
zAlways use the mounting device specified in the owner's manual.
When installing the product, make sure to keep it away from the wall (more
than 10cm/4inch) for ventilation purposes.
zPoor ventilation may cause an increase in the internal temperature of the
product, resulting in a shortened component life and degraded performance.
To prevent rainwater from running along the outdoor antenna cable and
entering the house, be sure the outdoor portion of the cable hangs down below
the point of entry.
zIf rainwater enters the product, it may cause an electric shock or fire.
If you are using an outdoor antenna, be sure to put sufficient distance between
your antenna and the electrical wires nearby so that they would not come in
contact with each other in case the antenna is knocked over by strong wind.
z
A
knocked-over antenna ma
y
cause in
j
ur
y
or an electric shock.
Clean
When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a
slightly moistened, soft fabric.
Do not spray water or detergent directly on the monitor.
zThis may cause damage, electric shock or fire.
Use the recommended detergent with a smooth cloth.
If the connector between the plug and the pin is dusty or dirty, clean it properly
with a dry cloth.
zA dirty connector may cause an electric shock or fire.

Make sure to unplug the power cord before cleaning the product.
zOtherwise, this may cause electric shock or fire.
Unplug the power cord from the power outlet and wipe the product using a
soft, dry cloth.
zDo not use an
y
chemicals such as wax, benzene, alcohol, thinners, insecticide,
air freshener, lubricant or detergent.
Contact the Service Center or Customer Center for interior cleaning once a
year.
zKeep the product's interior clean. Dust which has accumulated in the interior
over an extended period of time may cause malfunction or fire.
Others
Do not remove cover (or back).
zThis may cause an electric shock or fire.
zRefer servicing to qualified service personnel.
If your monitor does not operate normally - in particular, if there are any
unusual sounds or smells coming from it - unplug it immediately and contact
an authorized dealer or service.
zThis may cause an electric shock or fire.
Keep the product away from places exposed to oil, smoke or moisture; do not
install inside a vehicle.
zThis may cause malfunction, an electric shock or fire.
zEspeciall
y
avoid operatin
g
the monitor near water or outdoors where it could be
exposed to snow or rain.
If the monitor is dropped or the casing is damaged, turn the monitor off and
unplug the power cord. Then contact the Service Center .
zThe monitor may malfunction, causing an electric shock or fire.
Disconnect the plug from the outlet during storms or lightening or if it is not
used for a long period of time.
zFailure to do so may cause an electric shock or fire.

Do not try to move the monitor by pulling only the wire or the signal cable.
zThis may cause a breakdown, electric shock or fire due to damage to the
cable.
Do not move the monitor right or left by pulling only the wire or the signal
cable.
zThis may cause a breakdown, electric shock or fire due to damage to the
cable.
Do not cover the vents on the monitor cabinet.
zBad ventilation may cause a breakdown or fire.
Do not place water containers, chemical products or small metal objects on the
monitor.
zThis may cause malfunction, an electric shock or fire.
zIf a foreign substance enters the monitor, unplug the power cord and contact
the Service Center .
Keep the product away from combustible chemical sprays or inflammable
substances.
zThis may cause an explosion or fire.
Never insert anything metallic into the monitor openings.
zThis may cause an electric shock, fire or injury.
Do not insert metal objects such as chopsticks, wire and gimlet or inflammable
objects such as paper and match into the vent, headphone port or AV ports.
zIt may cause a fire or an electric shock. If an alien substances or water flows
into the product, turn the product off, unplug the power connector from the wall
outlet and contact the Service Center.
If you view a fixed screen for an extended period of time, residual image or
blurriness may appear.
zChange the mode to energy save or set a screensaver to moving picture when
you need to be away from the monitor for an extended period of time.
Adjust the resolution and frequency to the levels appropriate for the model.
zInappropriate resolution may cause undesirable picture quality.
17 inch -1280 X1024

Keep the volume at a proper level when you use the headphones.
zExcessively loud volume levels may damage hearing.
Watching the monitor continuously at a too close angle may result in eyesight
damage.
To ease eye strain, take at least a five-minute break after every hour of using
the monitor.
Do not install the product on an unstable, uneven surface or a location prone to
vibrations.
zDropping the product may cause damage to the product or personal injury.
Using the product in a location prone to vibrations may shorten the lifetime of
the product or may catch fire.
When moving the monitor, turn off and unplug the power cord.
Make sure that all cables, including the antenna cable and cables connecting to
other devices, are disconnected before moving the monitor.
zFailure to disconnect cables may damage it and lead to fire or an electric
shock.
Place the product out of children's reach, as they could damage itby hanging
onto it.
zA falling product could cause physical damage even death.
When not using the product for an extended time period, keep the product
unplugged.
zOtherwise, this may cause heat emission from the accumulated dirt or
degraded insulation, leading to electric shock or fire.
Donot place children's favoriteobjects(oranything else that may be
tempting) on the product.
zChildren may try to climb on the product to retrieve an object. The product
could fall, causing physical damage or even death.
When you remove batteries from the remote, be careful that they are not
swallowed by children. Keep batteries out of the reach of children.

zIf swallowed, see a doctor immediately.
When replacing batteries, place the batteries in the correct +/- polarity position
as indicated on battery holder.
zIncorrect polarity may cause a battery to break or leak and could lead to fire,
injury, or contamination (damage).
Use only specified standard batteries. Do not use new and used batteries
together.
zThis may cause a battery to break or leak and could lead to fire, injury, or
contamination (damage).
The battery (and rechargeable battery) are not ordinary refuse and must be
returned for recycling purposes. The customer is responsible for returning the
used or rechargeable battery for recycling purposes as the consumer of the
battery.
zThe customer can return the used or rechargeable battery to a nearby public
recycling center or to a store selling the same type of the battery or
rechar
g
eable batter
y
.

Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local dealer to bu
y
o
p
tional items.
Unpacking
Monitor
Manual
Quick Setup Guide Warranty Card
(
Not available in all locations
)
User's Guide, Monitor Driver,
Natural Color software

Cable
D-Sub Cable Power Cord
A
udio Cable
Others
Remote Control Batteries (AAA X 2) Connector
[
For exam
p
le
]
Front
1. SOURCE
2. MagicBright [ ]
3. AUTO/EXIT
4. CH
5. VOL
6. MENU
7. Power button [ ]
8. Power indicator
9. Remote Control
Sensor
10. Speaker
1. SOURCE
Switches from PC mode to Video mode.
Changing the source is allowed only in external devices that are connected to the monitor
at the time.

To switch Screen modes:
[PC] [TV] [EXT] [AV] [S-Video]
>>Click here to see an animation clip
For more information > Broadcasting Systems
2. MagicBright™ [ ]
MagicBright™ is a new feature providing the optimum viewing environment depending on
the contents of the image you are watching.
Then push button again to circle through available preconfigured modes.
( Entertain Internet Text Custom )
>>Click here to see an animation clip
- Available in PC Mode only
3. AUTO / EXIT
AUTO : Adjusts the screen display automatically.
>>Click here to see an animation clip
- Available in PC Mode only
EXIT : Exits from the menu screen.
4. CH
Moves from one menu item to another vertically or adjusts selected menu values.
In TV mode, selects TV channels.
>>Click here to see an animation clip
5. VOL
Moves from one menu item to another horizontally or adjusts selected menu values.
Adjusts the audio volume.
>>Click here to see an animation clip
6. MENU
Use this button to open the on-screen menu and step back in the menu.
7. Power button [ ]
Use this button to turn the monitor on and off.
8. Power indicator
Power Indicator shows PowerSaver mode by green blinking.
9. Remote Control Sensor
Aim the remote control towards this spot on the Monitor.
10. Speaker
You can hear sound by connecting the soundcard of your PC to the monitor.
See PowerSaver described in the manual for further information regarding power saving functions.
For ener
gy
conservation, turn
y
our monitor OFF when it is not needed or when leavin
g
it unattended
for long periods.
Rear

(The configuration at the back of the monitor may vary from product to product.)
1. POWER
Power cord, plugs into monitor and wall receptacle.
This product may be used with 100 ~ 240VAC (+/- 10%).
2. PC IN
Computer Connection Terminal (15 Pin D-SUB)
3. EXT(RGB)
EXT(RGB) Connection Terminal
- EXT(RGB) is mainly used in Europe.

4. ANT IN
TV Connection Terminal
For more information > Connecting TV
5.PCAUDIO IN
Audio Connection Terminal
6. AV Connection Terminal
1. Headphone Connection Terminal (Output)
2. Left(L) / Right(R) audio Connection Terminal (Input)
3. Video Connection Terminal (Input)
4. S-Video Connection Terminal (Input)
7. Kensington Lock
The Kensington lock is a device used to physically fix the
system when using it in a public place.
(The locking device has to be purchased separately. )
See Connecting the Monitor for further information regarding cable connections.

Remote Control
The performance of the remote control may be affected by a TV or other electronic devices
o
p
erated near the monitor, causin
g
malfuction due to interference with fre
q
uenc
y
.
1. POWER
2. number
3. -/--
4. (Volume)
5. MUTE
6. TTX/MIX
7. MENU
8. ENTER
9. P
10. SOURCE
11. INFO
12. EXIT
13. Up-Down Left-Right Buttons
14. AUTO / PRE-CH
15. (MagicBright™)
16. DUAL l - ll
17. SLEEP
18. P.MODE
1. POWER
Use this button to turn the monitor on and off.
2. number
Selects TV channels in the TV mode. You may use this button in PIP mode as well.
3. -/-- (One/Two-Digit CHANNEL selection )
Use to select a CHANNEL numbered ten or over.
Press this button, and the "--" symbol is displayed.
Enter the two-digit CHANNEL number.
4. (Volume)
6. TTX/MIX
TV channels provide written information services via teletext.
For more information > TTX / MIX
7. MENU
Use this button to open the on-screen menu and step back in the menu.
8. ENTER
Activates a highlighted menu item.
9. P
In TV mode, selects TV channels.
10. SOURCE
Adjusts the audio volume.
5. MUTE
Press to mute the sound temporarily.
Displayed on the bottom left of the screen.
Press the MUTE button again to cancel the Mute function. Alternatively press the
buttons to cancel the Mute function.
>>Click here to see an animation clip

Switches from PC mode to Video mode.
Changing the source is allowed only in external devices that are connected to the monitor at
the time.
[PC] [TV] [EXT] [AV] [S-Video]
11. INFO
Current picture information is displayed on the upper left corner of the screen.
12. EXIT
Exits from the menu screen.
13. Up-Down Left-Right Buttons
Moves from one menu item to another horizontally, vertically or adjusts selected menu
values.
14. AUTO / PRE-CH
PC mode : Adjusts the screen display automatically.
TV mode : This button is used to return to the previous channel immediately.
15. (MagicBright™)
PC Mode :
MagicBright™ is a new feature providing the optimum viewing environment depending on
the contents of the image you are watching.
Then push button again to circle through available preconfigured modes.
( Entertain Internet Text Custom )
16. DUAL l - ll
STEREO / MONO can be operated depending on broadcasting type by using DUAL button
on the remote control while watching TV.
17. SLEEP
Turns the monitor off after a pre-determined period of time.
18. P.MODE
When you press this button, current mode is displays on the lower center of the screen.
TV / Ext. / AV / S-Video Mode :
The Monitor has four automatic picture settings that are preset at the factory.
Then push button again to circle through available preconfigured modes.
( Dynamic Standard Movie Custom )

1. Connecting to a Computer
Connecting the Monitor
1. Connect the power cord for your monitor to the power port on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
2. Using the D-sub (Analog) connector on the video card.
Connect the signal cable to the 15-pin, D-sub connector on the back of your monitor.
3. Connect the audio cable for your monitor to the audio port on the back of your computer.
4. Turn on both your computer and the monitor.
2. Connecting to a Macintosh

1. Using the D-sub (Analog) connector on the video card.
Connect the signal cable to the D-SUB port on the Macintosh computer.
2. For old model Macintoshes, you need to adjust the resolution control DIP switch on the Macintosh
adapter (optional) referring to the switch configuration table shown on its rear.
3. Turn on the monitor and Macintosh.
Connecting to Other Devices
This monitor allows the user to connect it to such input devices as a DVD player,a VCR, a
camcorder, a DTV, or a TV without disconnecting the PC.
For detailed information on connecting AV input devices, refer to User Controls under Ad
j
ustin
g
y
our
monitor.
The configuration at the back of the monitor may vary from product to product.
1-1. Connecting AV Devices
The monitor has AV connection terminals to connect AV input devices like DVD, VCR or
Camcorder. You may enjoy AV signals as long as the monitor is turned on.
1. Input devices such as DVD, VCR or Camcorder are connected to the Video or S-Video terminal of
the monitor using the S-Video cable.
S-Video cable are optional.

2. Connect the Audio (R) and Audio (L) terminals of a DVD, VCR or Camcorders to the monitor's R
and L audio input terminals using audio cables.
3. Then, start the DVD, VCR or Camcorders with a DVD disc or tape inserted.
4. Select AV or S-Video using the SOURCE button.
1-2. Connecting EXT(RGB) - It only applies to AV DEVICE that supports EXT(RGB).
Connect to the DVD Devices input if the device has a EXT(RGB).
You can watch DVD simply by hooking up the DVD with the monitor as long as the power is on.
1. Connect the SCART cable to the DVD SCART connector.
2. Select Ext. using the SOURCE button.
2. Connecting TV
You may view television programs on the monitor if it is connected to an antenna or a CATV cable
without installing any separate TV reception hardware or software on your computer.
1. Connect the CATV or antenna coaxial cable to the antenna terminal on the rear of the monitor.
You need to use a coaxial antenna cable.
2. Turn on the monitor.
3. Select TV using SOURCE button among the external signal adjustment buttons.
4. Select a desired TV channel after channel search.
When using an interior antenna terminal:
Check the antenna terminal on the wall first and connect the antenna cable.
When using an outdoor antenna:
If you are using an outdoor antenna, use a professional for installation if possible.
To connect the RF cable to the antenna input terminal:
Keep the copper wire portion of the RF cable straight.
Is weak signal causing poor reception?
Purchase and install a signal amplifier for better reception.
In areas where antenna cable is not supported, first, attach connector to TV antenna .

3. Connecting Headphone
You may connect your headphones to the monitor.
1. Connect your headphones to the Headphone connection terminal.
Using the Stand
This monitor supports various types of VESA-standard bases. You need to either fold or remove the
base in use in order to install a VESA base.
1. Folding the Base
The monitor may be reclined 0 to 19 degrees.
