Samsung 7 Series User manual

Thank you for purchasing this Samsung product.
To receive more complete service, please
register your product at
www.samsung.com/global/register
Model Serial No.
imagine the possibilities
Plasma TV
user manual
BN68-01653A-03
Contact SAMSUNG WORLD-WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.
Comment contacter Samsung dans le monde
Si vous avez des suggestions ou des questions concernant les produits Samsung, veuillez contacter le Service
Consommateurs Samsung.
Country Customer Care Center Web Site Address
CANADA 1-800-SAMSUNG (7267864) www.samsung.com/ca
Samsung Electronics Canada Inc., Customer Service 55
Standish Court Mississauga, Ontario L5R 4B2 Canada
Samsung Electronique Canada Inc., Service à la Clientèle
55 Standish Court Mississauga, Ontario L5R 4B2
Canada
U.S.A 1-800-SAMSUNG (7267864) www.samsung.com/us Samsung Electronics America, Inc. 105 Challenger Road
Ridgefield Park, NJ 07660-0511
BN68-01653A-Eng.indb 1 2008-08-27 오후 5:11:28

English - 2
Important Warranty Information Regarding Television Format Viewing
Wide screen format PDP Displays (16:9, the aspect ratio of the screen width to height) are primarily designed to view wide
screen format full-motion video. The images displayed on them should primarily be in the wide screen 16:9 ratio format,
or expanded to fill the screen if your model offers this feature and the images are constantly moving. Displaying stationary
graphics and images on screen, such as the dark side-bars on nonexpanded standard format television video and
programming, should be limited to no more than 5% of the total television viewing per week.
Additionally, viewing other stationary images and text such as stock market reports, video game displays, station logos,
web sites or computer graphics and patterns, should be limited as described above for all televisions. Displaying stationary
images that exceed the above guidelines can cause uneven aging of PDP Displays that leave subtle, but permanent
burned-in ghost images in the PDP picture. To avoid this, vary the programming and images, and primarily display
full screen moving images, not stationary patterns or dark bars.
On PDP models that offer picture sizing features, use these controls to view different formats as a full screen picture.
Be careful in the selection and duration of television formats used for viewing. Uneven PDP aging as a result of format
selection and use, as well as burned-in images, are not covered by your Samsung limited warranty.
© 2008 Samsung Electronics Co., Ltd. All rights reserved.
U.S.A Only
The product unit accompanying this user manual is licensed under certain intellectual property rights of certain
third parties. In particular, this product is licensed under the following US patents: 5,991,715, 5,740,317, 4,972,484,
5,214,678, 5,323,396, 5,539,829, 5,606,618, 5,530,655, 5,777,992, 6,289,308, 5,610,985, 5,481,643, 5,544,247,
5,960,037, 6,023,490, 5,878,080, and under US Published Patent Application No. 2001-44713-A1.
This license is limited to private non-commercial use by end-user consumers for licensed contents. No rights are
granted for commercial use. The license does not cover any product unit other than this product unit and the license
does not extend to any unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or
sold in combination with this product unit. The license only covers the use of this product unit to encode and/or decode
audio files conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3. No rights are granted under this license for product
features or functions that do not conform to the ISO/IEC 11172-3 or ISO/IEC 13818-3.
Other countries
The product unit accompanying this user manual is licensed under certain intellectual property rights of certain third
parties. This license is limited to private non-commercial use by end-user consumers for licensed contents. No rights
are granted for commercial use. The license does not cover any product unit other than this product unit and the license
does not extend to any unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or
sold in combination with this product unit. The license only covers the use of this product unit to encode and/or decode
audio files conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3. No rights are granted under this license for product
features or functions that do not conform to the ISO/IEC 11172-3 or ISO/IEC 13818-3.
BN68-01653A-Eng.indb 2 2008-08-27 오후 5:11:28

English - 3
User Instructions
Screen Image retention
Do not display a still image (such as on a video game) on the plasma display panel for more than several minutes as it can
cause screen image retention. This image retention is also known as “screen burn”. To avoid such image retention, refer to
page 32 of this manual to reduce the degree of brightness and contrast of the screen when displaying a still image.
Altitude
The PDP can only operate normally at heights under 6500ft.
Heat on the top of the Plasma TV
The top side of the product may be hot after long periods of use as heat dissipates from the panel through the vent hole in
the upper part of the product.
This is normal and does not indicate any defect or operation failure of the product.
However, children should be prevented from touching the upper part of the product.
The product is making a ‘cracking’ noise.
A ‘cracking’ noise may occur when the product contracts or expands due to a change of surrounding environment such as
temperature or humidity. This is normal and not a defect of the unit.
Cell Defects
The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which require sophisticated
technology to produce. However, there may be a few bright or dark pixels on the screen. These pixels will have no impact
on the performance of the product.
Avoid operating the TV at temperatures below 5°C (41°F)
A still image displayed too long may cause permanent damage to the PDP Panel.
Watching the Plasma TV in 4:3 format for a long period of time may leave traces of borders
displayed on the left, right and center of the screen caused by the difference of light emission on
the screen.
Playing a DVD or a game console may cause similar effects to the screen.
Damages caused by the above effect are not covered by the Warranty.
After-images on the Screen.
Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.
To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images for a long time.
Warranty
Warranty does not cover any damage caused by image retention.
Burn-in is not covered by the warranty.
BN68-01653A-Eng.indb 3 2008-08-27 오후 5:11:28

English - 4
Symbols Press One-Touch
Button
➢
Note
Contents
English
General Information
 List of Features ........................................................................5
 Accessories..............................................................................5
 Viewing the Control Panel........................................................6
 Viewing the Connection Panel.................................................7
 Remote Control........................................................................8
 Installing Batteries in the Remote Control................................ 9
Connections
 Connecting VHF and UHF Antennas ....................................... 9
 Connecting Cable TV............................................................. 10
 Connecting a DVD Player or Cable Box / Satellite receiver
(Set-Top Box) via HDMI ......................................................... 11
 Connecting a DVD Player or Cable Box / Satellite receiver
(Set-Top Box) via DVI ............................................................ 11
 Connecting a DVD Player or Cable Box / Satellite receiver
(Set-Top Box) via Component cables .................................... 12
 Connecting a Camcorder.......................................................12
 Connecting a VCR .................................................................13
 Connecting a Digital Audio System........................................ 14
  ......................14
 Connecting a PC....................................................................15
Operation
 Turning the TV On and Off.....................................................16
 Plug & Play Feature...............................................................16
 Changing Channels ...............................................................18
 Adjusting the Volume .............................................................19
 Viewing the Display................................................................19
 Viewing the Menus.................................................................19
 Using the Remote Control Backlight Buttons.........................20
 Using the TOOLS Button .......................................................20
 Memorizing the Channels ......................................................20
 To Select the Source..............................................................22
 To Edit the Input Source Name..............................................22
Picture Control
 Changing the Picture Standard..............................................23
 Customizing the Picture Settings...........................................23
 Adjusting the Detailed Settings..............................................24
 ...................................................27
 Resetting the Picture Settings to the Factory Defaults .......... 34
 Viewing Picture-in-Picture......................................................34
Sound Control
 Changing the Sound Standard...............................................36
 Customizing the Sound..........................................................36
 Setting the TruSurround XT ...................................................37
 Choosing Preferred Language...............................................38
 Choosing a Multi-Channel Sound (MTS) Track .........................38
 Automatic Volume Control .....................................................39
 Setting the Speaker ...............................................................39
 Listening to the Sound of the Sub (PIP) Picture .................... 40
 Resetting the Sound Settings to the Factory Defaults ...........40
 Connecting Headphones (Sold separately) ...........................40
Channel Control
 Managing Channels...............................................................41
 Clearing Scrambled Channels - Digital..................................47
 Fine Tuning Analog Channels................................................ 47
 Checking the Digital-Signal Strength .....................................48
PC Display
 Using Your TV as a Computer (PC) Display ..........................49
 Display Modes .......................................................................49
 Setting up the TV with your PC..............................................50
Time Setting
 Setting the Time.....................................................................52
Function Description
 Selecting a Menu Language .................................................. 56
 Using the V-Chip....................................................................57
 Viewing Closed Captions (On-Screen Text Messages)
- Digital...................................................................................65
 Viewing Closed Captions (On-Screen Text Messages)
- Analog..................................................................................66
 Adjusting the TV On/Off Melody Sound ................................. 67
 Setting the Light Effect...........................................................67
 Setting the Entertainment mode ............................................68
 Using the Energy Saving Feature..........................................68
 Upgrading the Software .........................................................69
 Self diagnosis.........................................................................70
WISELINK Pro
 Using the WISELINK Pro Function ........................................ 71
 Using the Photo List...............................................................72
 ...................................................................74
 Viewing a Photo or Slide Show..............................................78
 Using the Music List...............................................................82
  List...................................................................83
 Playing a Music File...............................................................87
 Using the Movie List...............................................................89
  ..................................................................90
 ...............................................................93
  ...........................................................95
WISELINK Pro-DLNA
  .....................................................96
  ..............................................97
  ...................................................98
 .....................................................103
Content Library
  ....................................................105
 ...........................................106
 Using Additional Content Using External USB Memory
Storage ................................................................................ 110
Network Settings and InfoLink
  .................................................111
 ............................................ 113
  ................................................................ 113
 ........................................................... 114
 ....................................................... 116
  ...................................................................... 119
 ......................................................................122
 ......................................................................123
About Anynet+
 What is Anynet+?.................................................................124
 Connecting Anynet+Devices...............................................124
 Setting Up Anynet+ ..............................................................125
 Scanning and Switching between Anynet+Devices ............ 126
 Recording.............................................................................127
 Listening through a Receiver (Home theater)...................... 128
 Troubleshooting for Anynet+ ................................................ 128
Appendix
 Troubleshooting ...................................................................129
 Auto Wall-mount adjustment (Sold separately)
(PN50A760T1F)...................................................................130
 ..................................131
 ............. 132
 How to attach the Stand-Base .............................................132
 .......................................................................133
 Dimensions (PN50A760T1F)...............................................134
 Dimensions (PN58A760T1F)...............................................135
 Dimensions (PN63A760T1F)...............................................136
BN68-01653A-Eng.indb 4 2008-08-27 오후 5:11:28

English - 5
General Information
List of Features
• Adjustable picture settings that can be stored in the TV’s memory.
• Automatic timer to turn the TV on and off.
• A special sleep timer.
• V-Chip function.
• Excellent Digital Interface & Networking :
With a built-in HD digital tuner, non-subscription HD broadcasts can be viewed with no Cable Box/Satellite receiver (Set-
Top Box) needed.
• HDMI/DVI connection of your PC to this TV.
• Excellent Picture Quality
- DNIe technology provides life-like clear images.
• SRS TruSurround XT
- SRS TruSurround XT provides a virtual surround system.
Accessories
Please make sure the following items are included with your TV. If any items are missing, contact your dealer.
Remote Control (BN68-00695A) /
AAA Batteries (4301-000103)
Power Cord
(3903-000144)
Owner’s Instructions /
Quick Setup Guide
Warranty Card /
Safety Guide Manual
(Not available in all locations)
Cleaning Cloth
(BN63-01798B)
Cover-Bottom / Screws (2ea)
PN50A760T1F / PN58A760T1F only
(Refer to page 131)
Ferrite Core for Power Cord
(3301-001305)
PN50A760T1F only : 5ea
PN58A760T1F only : 3ea
Program CD
➢See the bottom of the page for Ferrite Core usage.
The following parts are sold separately and are available at most electronics stores.
➢If you do not use a good quality cable, some noise may appear on the screen.
S-VIDEO Cable (BN39-00149A) HDMI Cable (BN39-00641A) HDMI/DVI cable (BN39-00643A) Component Cables (RCA)
(BN39-00279A)
PC Cable
(BN39-00115A)
PC Audio Cable
(BN39-00061B)
Optical Cable Antenna Cable
(BN39-00333A)
LAN Cable
➢Ferrite Core
The ferrite cores are used to shield the
cables from interference.
When connecting a cable, open the ferrite
core and clip it around the cable near the
plug.
Power Cord
(PN58A760T1F /
PN63A760T1F)
Power Cord
(PN50A760T1F
only) S-Vídeo Cable Component
Cable
Side HDMI Cable/ Audio Cable
/ Video Cable
(PN50A760T1F only)
BN68-01653A-Eng.indb 5 2008-08-27 오후 5:11:31

English - 6
Viewing the Control Panel
Buttons on the Lower-Right Part of the Panel
The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu.
To use the more advanced features, you must use the remote control.
1 SOURCE
Toggles between all the available input sources
(TV, AV1, AV2, S-Video, Component1, Component2,
PC, HDMI1, HDMI2/DVI, HDMI3, HDMI4, USB, DLNA).
➢In the on-screen menu, use this button as you
would use the ENTER button on the remote control.
2 MENU
Press to see an on-screen menu of your TV’s features.
3 + VOL –
Press to increase or decrease the volume. In the on-
screen menu, use the + VOL –buttons as you would
use the ◄and ►buttons on the remote control.
4 CH
Press to change channels.
In the on-screen menu, use the CH buttons as
you would use the ▲and ▼buttons on the remote
control.
5 POWER INDICATOR
Blinks and turns off when the power is on and lights up
in stand-by mode.
6 REMOTE CONTROL SENSOR
Aim the remote control towards this spot on the TV.
7 SPEAKERS
8 ( POWER)
Touch the silver sensor below the ( ) mark to turn the
TV on and off.
➢The product color and shape may vary depending on the model.
Front Panel buttons
Touch each button to
operate.
Silver sensor
BN68-01653A-Eng.indb 6 2008-08-27 오후 5:11:32

English - 7
Viewing the Connection Panel
Rear Panel Jacks
Use the rear panel jacks to connect A/V components that will be connected continuously, such as VCR or DVD players.
For more information on connecting equipment, see pages 9~15. The product color and shape may vary depending on the
model.
1 POWER IN
Connect the supplied power cord.
2 DIGITAL AUDIO OUT (OPTICAL)
Connect to a Digital Audio component.
3 AUDIO OUT (R/L)
Audio outputs to external devices.
4 PC IN[PC]/[AUDIO]
Connect to the video and audio output jack on your PC.
5 DVI IN (HDMI 2) (AUDIO-R/L)
Connect to the DVI audio output jack of an external device.
6 HDMI IN 1, 2, 3
Connect to the HDMI jack of a device with an HDMI
output. (HDMI 2 supports HDMI-DVI IN and connection
from a PC.)
- HDMI 2 can also be used as a DVI connection with
separate analog audio inputs. An optional HDMI/DVI
cable will be necessary to make this connection.
- When using an optional HDMI/DVI adapter, the DVI
analog audio inputs on your TV allow you to receive left
and right audio from your DVI device.
7 ANT IN
 
Network.
8 LAN
Connect a LAN cable to this port to connect to the
Network (SAMSUNG's InfoLink Service). (See page 96)
9 COMPONENT IN 1, 2 / AV IN 1
Connects Component video/audio.
The COMPONENT IN 1 jack is also used as the AV IN 1
jack.
- Connect the video cable to the COMPONENT IN 1
[Y/VIDEO] jack and the audio cable to the COMPONENT
IN 1 [R-AUDIO-L] jacks.
0 EX-LINK
Connect this to the jack on the optional wall mount
bracket. This will allow you to adjust the TV viewing
angle using your remote control.
➢The model PN58A760T1F/PN63A760T1F cannot
be wall mounted. The EX-LINK jack on the
PN58A760T1F functions as RS-232C control jack.
The EX-LINK jack on the PN63A760T1F functions
as a service jack.
Side Panel Jacks
Use the right side panel jacks to connect a component that is used only occasionally, such as a camcorder or video game.
The product color and shape may vary depending on the model.
1 HDMI IN 4
Connect to the HDMI jack of a device with an HDMI output.
2 WISELINK PRO
Connect a USB mass storage device to view photo files (JPEG), play audio files (MP3) and
movie files(AVI).
3 S-VIDEO
S-Video input for external devices with an S-Video output.
4 AV IN 2
Video and audio inputs for external devices.
5 HEADPHONE
You can connect a set of headphones if you wish to watch a television program without
disturbing other people in the room.
BN68-01653A-Eng.indb 7 2008-08-27 오후 5:11:32

English - 8
Remote Control
You can use the remote control up to a distance of about 23 feet from the TV.
➢The performance of the remote control may be affected by bright light.
1 POWER
Turns the TV on and off.
2 TV
Selects the TV mode directly.
3 NUMERIC BUTTONS
Press to directly select the channel.
4
Press to select additional channels
(digital and analog) being broadcast
by the same station. For example,
to select channel “54-3”, press “54”,
then press “ ” and “3”.
5 MUTE
Press to temporarily cut off the
sound.
6 VOL
Press to increase or decrease the
volume.
7 SOURCE
Press to display and select the
available video sources.
8 CH LIST
Used to display Channel Lists on the
screen.
9 TOOLS
Use to quickly select frequently used
functions.
0 UP▲ / DOWN▼ / LEFT◄ /
RIGHT► / ENTER
Press the Up/Down/Left/Right
sections of the wheel button and
Enter to select on-screen menu
items and change menu values.
You can navigate up and down the
menu, switch channels and adjust
the volume by turning the wheel
button. (See pages 18~19)
While using MENU, TOOLS, and
WISELINK, the screen goes back
to the regular display if idle for more
than 20 seconds.
! INFO
Press to display information on the
TV screen.
@ COLOR BUTTONS
Use these buttons in the Channel list
and WISELINK, etc.
# CC
Controls the caption decoder.
$ E.MODE
Press to select the preset display
and sound modes for sports, cinema
and games.
% Use these buttons in the DMA,
WISELINK and Anynet+ modes.
( : This remote can be used
to control recording on Samsung
recorders with the Anynet+ feature)
^ ON/OFF
Press to backlight the buttons on the
remote.
This function is convenient for using
at night or when the room is dark.
(Using the remote control with the
ON/OFF( ) light button set to On
will reduce the battery usage time.)
& PRE-CH
Tunes to the previous channel.
* CH
Press to change channels.
( MENU
Displays the main on-screen menu.
) W.LINK(WISELINK)
This function enables you to view
and play photo and music files
from an external device. (Refer to
pages 72 (Photo), 87 (Music) and 93
(movie))
a RETURN
Returns to the previous menu.
b EXIT
Press to exit the menu.
c INFO.L
Press to use the News, Stock
Market and Weather Forecast
information services available over
Samsung's network.
(see page 119)
d DMA (Digital Media Adapter)
Use this when connecting a
Samsung DMA device through an
HDMI interface and switching to
DMA mode.
For more information on the
operating procedures, refer to the
user manual of the DMA.
➢This button is available when
“Anynet+(HDMI-CEC)” is “On”.
(see page 125)
e CONTENT
This function enables you to view
“Content Library”.
f FAV.CH
Press to switch to your favorite
channels.
BN68-01653A-Eng.indb 8 2008-08-27 오후 5:11:33

English - 9
Connections
Connecting VHF and UHF Antennas
If your antenna has a set of leads that look like this, see “Antennas with 300 Ω Flat
Twin Leads” below.
If your antenna has one lead that looks like this, see “Antennas with 75 Ω Round
Leads”.
If you have two antennas, see “Separate VHF and UHF Antennas”.
Antennas with 300 Ω Flat Twin Leads
If you are using an off-air antenna (such as a roof antenna or “rabbit ears”) that
has 300 Ω twin flat leads, follow the directions below.
1 
supplied).
Use a screwdriver to tighten the screws.
2Plug the adaptor into the ANT IN terminal on the back of the TV.
Antennas with 75 Ω Round Leads
1
Plug the antenna lead into the ANT IN terminal on the back of the TV.
Separate VHF and UHF Antennas
If you have two separate antennas for your TV (one VHF and one UHF), you must
combine the two antenna signals before connecting the antennas to the TV. This
procedure requires an optional combiner-adaptor (available at most electronics
shops).
1Connect both antenna leads to the combiner.
2Plug the combiner into the ANT IN terminal on the bottom of the back panel.
Installing Batteries in the Remote Control
1 Lift the cover at the back of the remote control upward as shown in the figure.
2 Install two AAA size batteries.
➢Make sure to match the “+” and “–” ends of the batteries with the diagram inside the
compartment.
➢Using the remote control with the ON/OFF( ) light button set to On will reduce the
battery usage time.
3 Close the cover as shown in the figure.
➢
Remove the batteries and store them in a cool, dry place if you won’t be using the
remote control for a long time. The remote control can be used up to about 23 feet
from the TV. (Assuming typical TV usage, the batteries last for about one year.)
➢If the remote control doesn’t work, check the following:
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power cut, or is the power cord unplugged?
5. Is there a special fluorescent light or a neon sign nearby?
ANT IN
ANT IN
UHF
VHF
ANT IN
UHF
VHF
BN68-01653A-Eng.indb 9 2008-08-27 오후 5:11:34

English - 10
Connecting Cable TV
To connect to a cable TV system, follow the instructions below.
Cable without a Cable Box
1 Plug the incoming cable into the ANT IN terminal on the back of the TV.
➢Because this TV is cable-ready, you do not need a cable box to view
unscrambled cable channels.
1 Find the cable that is connected to the ANT OUT terminal on your cable box.
➢This terminal might be labeled “ANT OUT”, “VHF OUT” or simply, “OUT”.
2 Connect the other end of this cable to the ANT IN terminal on the back of the TV.
Connecting to a Cable Box that Descrambles All Channels
Connecting to a Cable Box that Descrambles Some Channels
If your cable box descrambles only some channels (such as premium channels), follow the instructions below.
You will need a two-way splitter, an RF (A/B) switch, and four lengths of Antenna cable. (These items are available
at most electronics stores.)
1 Find and disconnect the cable that is
connected to the ANT IN terminal on your
cable box.
➢This terminal might be labeled “ANT
IN”, “VHF IN” or simply, “IN”.
2 Connect this cable to a two-way splitter.
3 Connect an Antenna cable between an
OUTPUT terminal on the splitter and the IN
terminal on the cable box.
4 Connect an Antenna cable between the
ANT OUT terminal on the cable box and the
B–IN terminal on the RF(A/B) switch.
5 Connect another cable between the other
OUT terminal on the splitter and the A–IN
terminal on the RF (A/B) switch.
6 Connect the last Antenna cable between
the OUT terminal on the RF (A/B) switch
and the ANT IN terminal on the rear of the
TV.
After you have made this connection, set the A/B switch to the “A” position for normal viewing. Set the A/B switch to the “B”
position to view scrambled channels. (When you set the A/B switch to “B”, you will need to tune your TV to the cable box’s
output channel, which is usually channel 3 or 4.)
ANT OUT
ANT IN
ANT IN
ANT IN
Splitter
Cable Box
RF (A/B)
Switch
Incoming
cable
Splitter
Incoming
cable
Splitter
Cable Box
Incoming
cable
Splitter
Incoming
cable
TV Rear
RF (A/B)
Switch
ANT IN
ANT IN
Splitter
Incoming
cable
RF (A/B)
Switch
Cable Box
BN68-01653A-Eng.indb 10 2008-08-27 오후 5:11:35

English - 11
Connecting a DVD/Blu-Ray Player or Cable Box / Satellite receiver (Set-Top Box)
via DVI
This connection can only be made if there is a DVI Output jack on the external device.
1 Connect a HDMI/DVI Cable
or DVI-HDMI Adapter
between the HDMI IN 2
jack on the TV and the DVI
jack on the DVD/Blu-Ray
Player or Cable Box/Satellite
receiver (Set-Top Box).
2 Connect Audio Cables
between the DVI IN (HDMI 2)
[R-AUDIO-L] jack on the TV
and the DVD/Blu-Ray Player
or Cable Box / Satellite
receiver (Set-Top Box). ➢Each DVD/Blu-Ray Player or Cable Box / Satellite receiver (Set-Top Box) has a
different back panel configuration.
➢When connecting a DVD/Blu-Ray Player or Cable Box / Satellite receiver (Set-Top
Box), match the color of the connection terminal to the cable.
➢When using an HDMI / DVI cable connection, you must use the HDMI IN 2 jack.
Connecting a DVD/Blu-Ray Player or Cable Box / Satellite receiver (Set-Top Box)
via HDMI
This connection can only be made if there is an HDMI Output jack on the external device. This connection will
provide the highest quality picture.
1 Connect an HDMI Cable
between the HDMI IN (1, 2, 3
or 4) jack on the TV and the
HDMI jack on the DVD/Blu-
Ray Player or Cable Box /
Satellite receiver (Set-Top
Box).
What is HDMI?
• HDMI, or high-definition multimedia interface, is an interface that enables the
transmission of digital audio and video signals using a single cable.
• The difference between HDMI and DVI is that the HDMI device is smaller in size and
has the HDCP (High Bandwidth Digital Copy Protection) coding feature installed.
➢DVI also requires a separate audio connection (see below).
➢Each DVD/Blu-Ray Player or Cable Box / Satellite receiver (Set-Top Box) has a
different back panel configuration.
➢The TV may not output sound and pictures may be displayed with abnormal color
when DVD/Blu-Ray Player or Cable Box / Satellite receivers supporting HDMI
versions older than 1.3 are connected. When connecting an older HDMI cable and
there is no sound, connect the HDMI cable to the HDMI IN 2 jack and the audio
cables to the DVI IN (HDMI2) [R-AUDIO-L] jacks on the back of the TV. If this
happens, contact the company that provided the DVD/Blu-Ray Player or Cable Box
/ Satellite receiver to confirm the HDMI version, then request an upgrade.
➢HDMI cables that are not 1.3 may cause annoying flicker or no screen display.
DVD/Blu-Ray Player or Cable Box /
Satellite receiver (Set-Top Box)
TV Rear Panel
Audio Cable (Not supplied)2
HDMI/DVI Cable (Not supplied)1
HDMI Cable (Not supplied)1
DVD/Blu-Ray Player or Cable Box /
Satellite receiver (Set-Top Box)
TV Rear Panel TV Side Panel
or
BN68-01653A-Eng.indb 11 2008-08-27 오후 5:11:38

English - 12
Connecting a Camcorder
The side panel jacks on your TV make it easy to connect a camcorder to your TV.
They allow you to view the camcorder tapes without using a VCR.
1 Connect a Video Cable
(or S-Video Cable) between
the AV IN 2 [VIDEO]
(or S-VIDEO) jack on the TV
and the VIDEO OUT jack on
the Camcorder.
2 Connect Audio Cables
between the AV IN 2
[L-AUDIO-R] jacks on the TV
and the AUDIO OUT jacks on
the Camcorder. ➢Each Camcorder has a different back panel configuration.
➢
When connecting a Camcorder, match the color of the connection terminal to the cable .
Camcorder
TV Side Panel
S-Video Cable(Not supplied)
1
Video Cable (Not supplied)1
Audio Cable (Not supplied)2
or
Connecting a DVD/Blu-Ray Player or Cable Box / Satellite receiver (Set-Top Box)
via Component cables
The rear panel jacks on your TV make it easy to connect a DVD/Blu-Ray Player/Cable Box/Satellite receiver (Set-
Top Box) to your TV.
1 Connect a Component Cable
between the COMPONENT
IN (1 or 2) [Y, PB, PR]
jacks on the TV and the
COMPONENT [Y, PB, PR]
jacks on the DVD/Blu-
Ray Player or Cable Box /
Satellite receiver(Set-Top
Box).
2 Connect Audio Cables
between the COMPONENT
IN (1 or 2) [R-AUDIO-L] jacks
on the TV and the AUDIO
OUT jacks on the DVD/Blu-
Ray Player or Cable Box /
Satellite receiver (Set-Top
Box). ➢Component video separates the video into Y (Luminance (brightness)), PB(Blue)
and PR(Red) for enhanced video quality. Be sure to match the component video
and audio connections. For example, if connecting a Component video cable to
COMPONENT IN 1, connect the audio cable to COMPONENT IN 1 also.
➢Each DVD/Blu-Ray Player or Cable Box / Satellite receiver (Set-Top Box) has a
different back panel configuration.
➢When connecting a DVD/Blu-Ray Player or Cable Box / Satellite receiver (Set-Top
Box), match the color of the connection terminal to the cable.
DVD/Blu-Ray Player or Cable Box /
Satellite receiver (Set-Top Box)
TV Rear Panel
Audio Cable (Not supplied)2
Component Cable (Not supplied)1
BN68-01653A-Eng.indb 12 2008-08-27 오후 5:11:39

English - 13
Connecting a VCR
Video Connection
These instructions assume that you have already connected your TV to an antenna or a cable TV system (according
to the instructions on pages 9~10). Skip step 1 if you have not yet connected to an antenna or a cable system.
➢If you have a “mono” (non-stereo) VCR, use a Y-connector (not supplied) to
connect to the right and left audio input jacks of the TV. Alternatively, connect the
cable to the “R” jack.
If your VCR is stereo, you must connect two cables.
➢Each VCR has a different back panel configuration.
➢When connecting a VCR, match the color of the connection terminal to the cable.
➢When connecting to AV IN 1, the color of the AV IN 1 [Y/VIDEO] jack (Green) does
not match the color of the video cable (Yellow).
VCR Rear Panel
TV Rear Panel
Audio Cable(Not supplied)5
Video Cable(Not supplied)4
Antenna cable(Not supplied)3
S-Video Connection
Your Samsung TV can be connected to an S-Video jack on a VCR.
(This connection delivers a better picture as compared to a standard VCR.)
1 To begin, follow steps 1–3
in the previous section to
connect the antenna or cable
to your VCR and your TV.
2 Connect an S-Video Cable
between the S-VIDEO OUT
jack on the VCR and the AV
IN 2 [S-VIDEO] jack on the
TV.
3 Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the AV
IN 2 [R-AUDIO-L] jacks on
the TV.
An S-Video cable may be included with your VCR. (If not, check your local electronics
store.)
➢Each VCR has a different back panel configuration.
➢When connecting a VCR, match the color of the connection terminal to the cable.
VCR Rear Panel
TV Rear Panel
Audio Cable (Not supplied)
3
S-Video Cable(Not supplied)2
Antenna cable(Not supplied)1
1 Unplug the cable or antenna
from the back of the TV.
2 Connect the cable or antenna
to the ANT IN terminal on the
back of the VCR.
3 Connect an Antenna Cable
between the ANT OUT
terminal on the VCR and the
ANT IN terminal on the TV.
4Connect a Video Cable
between the VIDEO OUT
jack on the VCR and the AV
IN 1 [Y/VIDEO] or AV IN 2
[VIDEO] jack on the TV.
5Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the AV
IN 1 (or AV IN 2) [R-AUDIO-L]
jacks on the TV.
TV Side Panel
TV Side Panel
BN68-01653A-Eng.indb 13 2008-08-27 오후 5:11:42

English - 14
Connecting an Amplifier / DVD Home Theater
1 Connect Audio Cables
between the AUDIO OUT
[R-AUDIO-L] jacks on the TV
and AUDIO IN [L-AUDIO-R]
jacks on the Amplifier/DVD
Home Theater.
When an audio amplifier is
connected to the AUDIO OUT
[R-AUDIO-L] jacks terminals :
Decrease the volume of the
TV, and adjust the volume
level with the Amplifier’s
volume control. ➢Each Amplifier / DVD Home Theater has a different back panel configuration.
➢When connecting an Amplifier / DVD Home Theater, match the color of the
connection terminal to the cable.
Amplifier / DVD Home Theater
TV Rear Panel
Audio Cable (Not supplied)
Connecting a Digital Audio System
The rear panel jacks on your TV make it easy to connect a Digital Audio System(Home theater/Receiver) to your
TV.
1 Connect an Optical Cable
between the DIGITAL AUDIO
OUT (OPTICAL) jacks on
the TV and the Digital Audio
Input (OPTICAL) jacks on the
Digital Audio System.
When a Digital Audio System
is connected to the DIGITAL
AUDIO OUT (OPTICAL) jack:
Decrease the volume of the
TV, and adjust the volume
level with the system’s
volume control.
What is OPTICAL?
• An optical cable converts an electric signal into an optical light signal, and transmits
it through glass fibers. S/PDIF is a transmission system of digital audio in the form of
a light wave that uses a glass conductor.
➢5.1CH audio is possible when the TV is connected to an external device
supporting 5.1CH.
➢Each Digital Audio System has a different back panel configuration.
➢When the receiver (home theater) is set to On, you can hear sound output from
the TV’s Optical jack. When the TV is displaying a DTV(air) signal, the TV will send
out 5.1 channel sound to the Home theater receiver. When the source is a digital
component such as a DVD and is connected to the TV via HDMI, only 2 channel
sound will be heard from the Home Theater receiver.
If you want to hear 5.1 channel audio, connect the DIGITAL AUDIO OUT
(OPTICAL) jack on the DVD/Blu-Ray Player or Cable/Satellite Box directly to an
Amplifier or Home Theater, not the TV.
Digital Audio System
TV Rear Panel
Optical Cable (Not supplied)
BN68-01653A-Eng.indb 14 2008-08-27 오후 5:11:45

English - 15
Using the D-Sub Cable
1 Connect a D-Sub Cable
between PC IN [PC] jack on
the TV and the PC output
jack on your computer.
2 Connect a PC Audio Cable
between the PC IN [AUDIO]
jack on the TV and the Audio
Out jack of the sound card on
your computer.
Using the HDMI/DVI Cable
1 Connect a HDMI/DVI cable
between the HDMI IN 2 jack
on the TV and the PC output
jack on your computer.
2
Connect a 3.5 mm Stereo plug
to 2RCA cable between the
DVI IN (HDMI2) [R-AUDIO-L]
jack on the TV and the Audio
Out jack of the sound card on
your computer.
➢Each PC has a different back panel configuration.
➢When connecting a PC, match the color of the connection terminal to the cable.
➢When using an HDMI/DVI cable connection, you must use the HDMI IN 2 terminal.
Connecting a PC
PC
TV Rear Panel
PC Audio Cable (Not supplied)2
D-Sub Cable (Not supplied)1
Using the D-Sub Cable
Using the HDMI/DVI Cable
TV Rear Panel
PC
3.5 mm Stereo plug to 2RCA Cable (Not supplied)
2
HDMI/DVI Cable (Not supplied)1
BN68-01653A-Eng.indb 15 2008-08-27 오후 5:11:49

English - 16
Operation
Turning the TV On and Off
Press the POWER button on the remote control.
You can also use the POWER button on the TV.
➢It may take a little while before you see a full picture.
Plug & Play Feature
The first time you turn on your new TV, choose your basic settings for language, input source and channels, and
time of day using the plug and play feature. The TV will store these settings in memory. Storing the channels in
memory will allow you to scan the stored channels rather than have to enter their digits each time you want to
change channels.
When the TV is initially powered on, basic settings proceed automatically:
1Press the POWER button on the remote control.
The message Menu Language, Store Demo, Channels, and Time will be
set. is automatically displayed.
2Press the ENTER button to enter the language.
ENTER button.
The message Select 'Home Use’ when installing this TV in your home. is
automatically displayed.
➢
The Screen Saver is activated if there is no remote control key input for
longer than 1 minute while Plug & Play is running.
฀➢
The Screen Saver is activated if there is no operating signal for longer than
15 minutes.
3 Store Demo or Home Use, then press the
ENTER button.
฀➢We recommend setting the TV to Home Use mode for the best picture in
your home environment.
฀➢Store Demo mode is only intended for use in retail environments.
฀➢If the unit is accidentally set to Store Demo mode and you want to return
to Home Use (Standard) mode: Press the Volume button on the TV.
When the volume OSD is displayed, press and hold the MENU button on
the TV for 5 seconds.
4 
then press the ENTER button.
฀➢Air: Air antenna signal.
Cable: Cable antenna signal.
Auto: Air and Cable antenna signals.
฀➢In Cable mode, you can select the correct analog signal source among
STD, HRC, and IRC
ENTER button. If you have Digital cable, select the signal source for both
Analog and Digital. Contact your local cable company to identify the type of
cable system that exists in your particular area.
Continued...
Plug & Play
Menu Language, Store Demo, Channels, and Time will
be set.
Enter
OK
Plug & Play
Select Language of the OSD.
  
Enter
Plug & Play
Select ‘Home Use’ when installing this TV in your
home.
Home Use
Store Demo
EnterMove
Plug & Play
Select Language of the OSD.
Enter
Menu Language : English
Move
English
Español
Français
SkipEnter
Plug & Play
Select the Antenna source to memorize.
Air
Cable
Auto
Start
Start
Move
Start
Plug & Play
Selects the cable system.
Analog
Digital
HRC IRC
HRC IRC
SkipEnter
STD
Move
Start
STD
BN68-01653A-Eng.indb 16 2008-08-27 오후 5:11:51

English - 17
5The TV will begin memorizing all of the available channels.
After all the available channels are stored, the TV starts to remove scrambled
channels (see page 47). The Auto program menu then reappears.
Press the ENTER button when channel memorization is complete.
The Clock Mode menu is displayed.
฀➢ENTER button with
stop selected.
6 Press the ENTER button.
Manual for setting the current time
manually, then press the ENTER button.
The message Set current date and time. is displayed.
฀➢If you select Auto, Set to daylight saving time. is displayed, then go to
step 9.
7 Month, Day, Year, Hour, Minute, or
am/pm.

ENTER button.
฀➢You can set the month, day, year, hour, and minute directly by pressing the
number buttons on the remote control.
8The message Enjoy your watching. is displayed.
 ENTER button.
฀➢Even if the ENTER button is not pressed, the message will automatically
disappear after several seconds.
Setting the Clock Automatically
9Press the ENTER button.
 Off or On, then the ENTER button.
The message Select the time zone in which you live. is displayed.
10 
to move the highlight to the appropriate time zone on the map of the United
States).
Press the ENTER button.
If clock is not automatically set, see page 53 to set the clock.
11 The message Enjoy your watching. is displayed.
 ENTER button.
฀➢Even if the ENTER button is not pressed, the message will automatically
disappear after several seconds.
Continued...
Plug & Play
Auto Program is completed.
56 channels are memorized.
DTV Air : 20 Air : 11
DTV Cable : 15 Cable : 10
OK
Enter Skip
Plug & Play
Auto Program in Progress.
Stop
Enter Skip
Air 6
3%
DTV Air : 02 Air:11
DTV Cable : 23 Cable: 21
OK
Plug & Play
Enjoy your watching.
Plug & Play
Set current date and time
01
Month
01
Day
2008
Year
12
Hour
00
Minute
am
am/pm
SkipEnterAdjustMove
OK
Plug & Play
Enjoy your watching.
Plug & Play
Select the time zone in which you live.
Newfoundland
Atlantic
Eastern
Central
Mountain
Pacific

SkipEnter
Move
Plug & Play
Set the Clock Mode.
Clock Mode : Auto
Auto
Manual
EnterMove Skip
Plug & Play
Set to daylight saving time.
DST : Off
Off
On
EnterMove Skip
Plug & Play
Stop
Enter Skip
Removing scrambled channel.
DTV Cable 41
77%
DTV Air : 05 Air:12
DTV Cable : 25 Cable: 32
BN68-01653A-Eng.indb 17 2008-08-27 오후 5:11:51

English - 18
If you want to reset this feature...
1 Press the MENU button to display the menu.
Setup, then press the ENTER button.
2Press the ENTER button to select Plug & Play. For further details on setting
up options, refer to the pages 16~17.
฀➢The Plug & Play feature is only available in the TV mode.
Changing Channels
Using the Channel Buttons
1 Press the CH or CH button to change channels.
➢When you press the CH or CH button, the TV changes channels in
sequence. You will see all the channels that the TV has memorized.
(The TV must have memorized at least three channels). You will not
see channels that were either erased or not memorized. See page 20 to
memorize channels.
➢To increase the channel number, turn the wheel clockwise when the Channel
Display is displayed. To decrease the channel number, turn the wheel
counterclockwise.
Using the Number Buttons
1 Press the number buttons to go directly to a channel. For example, to select
channel 27, press 2, then 7.
The TV will change channels when you press the second number.
➢For quick channel change, press the number buttons, then press the ENTER
button.
➢You can press number buttons on Remote control for direct channel access,
press the same Number button again to switch between digital and analog
TV channels broadcast by the same station.
Using the - Button
The “ ” button is used to select stations that broadcast a digital signal.
1 For example, for Channel 7-1, press 7, then , then 1.
➢HD indicates the TV is receiving a Digital High Definition signal.
SD indicates the TV is receiving a Standard Definition signal.
➢For quick channel change, press the number buttons, then press the ENTER
button.
Using the PRE-CH Button to select the Previous Channel
Use the number buttons to quickly tune to any channel.
1 Press the PRE-CH button. The TV will switch to the last channel viewed.
➢To quickly switch between two channels that are far apart, tune to one
channel, then use the number button to select the second channel.
Then use the PRE-CH button to quickly alternate between them.
Plug & Play 
Language : English
Time
Network Selection : Cable
Cable Network Setup
Wireless Network Setup
V-Chip
Caption
Setup
Plug & Play
Menu Language, Store Demo, Channels, and Time will
be set.
Enter
OK
Return
BN68-01653A-Eng.indb 18 2008-08-27 오후 5:11:52

English - 19
Adjusting the Volume
Using the Volume Buttons
1 Press the VOL or VOL
EXIT
button to increase or decrease the volume.
➢To turn the volume up, turn the wheel clockwise when the Volume
Control window is displayed. To turn the volume down, turn the wheel
counterclockwise.
Using the Mute Button
At any time, you can cut off the sound using the MUTE button.
1 Press MUTE and the sound cuts off.
will displayed on the screen.
2 To turn mute off, press the MUTE button again, or simply press the VOL or
VOL button.
Viewing the Menus
1 With the power on, press the MENU button.
The main menu appears on the screen. The menu’s left side has icons:
Picture, Sound, Channel, Setup, Input, Application.
2 
Then press the ENTER button to access the icon’s sub-menu.
➢To move to a lower menu, turn the wheel clockwise when the menu Display is on
the screen. To move to a higher menu, turn the wheel counterclockwise.
3 Press the EXIT button to exit.
➢It takes about one minute until the on-screen menu disappears.
Mode :Standard
Cell Light : 7
Contrast : 95
Brightness : 45
Sharpness : 50
Color : 50
Tint (G/R) : G50/R50
Detailed Settings
Viewing the Display
The display identifies the current channel and the status of certain audio-video settings.
1 Press the INFO button on the remote control.
The TV will display the channel, the type of sound, and the status of certain
picture and sound settings.
Press the INFO button once more or wait approximately 10 seconds and it disappears
automatically.
TV #1 Sun, Sep 3 1:45 pm
M. Spillane’s Mike Hammer
Bonocrunch
DTV Air
13-1
Dolby Digital
480i 4:3 English
12:59 pm - 1:59 pm
BN68-01653A-Eng.indb 19 2008-08-27 오후 5:11:53

English - 20
Memorizing the Channels
Your TV can memorize and store all of the available channels for both air and cable channels. After the available
channels are memorized, use the CH or CH button to scan through the channels. This eliminates the need
to change channels by entering the channel digits. There are three steps for memorizing channels: selecting a
broadcast source, memorizing the channels (automatic) and adding and deleting channels (Channel Lists).
Selecting the Video Signal-source
Before your television can begin memorizing the available channels, you must
specify the type of signal source that is connected to the TV (i.e. an Air or a Cable
system).
1 Press the MENU button to display the menu.
Channel, then press the ENTER button.
2 Press the ENTER button to select Antenna.
Air or Cable, then press the ENTER button.
Press the EXIT button to exit.
Continued...
Using the Remote Control Backlight Buttons
Use this feature in dark surroundings and when you are unable to see the remote control buttons clearly.
1Press the ON/OFF light button
➢Pressing the ON/OFF light button toggles between ON and OFF.
➢When ON, the button backlight is turned on for a moment.
➢Pressing a remote control button when the remote control is on turns the button backlight on for a moment. If
you touch or move the remote control and the motion is detected by the sensor of the remote control, the button
backlight will be turned on for a moment.
➢Since there is a vibrating device inside the remote control, shaking the remote control will result in a sound
generated by the device.
➢The button backlight will not be turned on when the remote control is turned off.
Using the TOOLS Button
You can use the TOOLS button to select your frequently used functions quickly and easily. The TOOLS menu
changes depending on which external input mode you are viewing.
1Press the TOOLS button.
The TOOLS menu will appear.
2 ENTER button.
3 ENTER buttons to display, change, or use the selected
items. For a more detailed description of each function, refer to the
corresponding page.
Antenna : Air
Auto Program
Clear Scrambled Channel
Channel List
Fine Tune
Signal Strength
Air
Cable
ChannelChannel
Antenna : Air 
Auto Program
Clear Scrambled Channel
Channel List
Fine Tune
Signal Strength
Anynet+ (HDMI-CEC)
Multi-Track Sound : Stereo
Picture Size : 16:9
Picture Mode : Standard
Sound Mode : Custom
Sleep Timer : Off
Add to Favorite
Switch to Cable
Tools
Move Enter Exit










BN68-01653A-Eng.indb 20 2008-08-27 오후 5:11:53
