SAMSUNG CAMERA
Digimax Power Pack
SNB-2312 KIT
User Manual
6 7
Thank you for purchasing the Samsung Digimax Power Pack. This manual contains important
safety and operating instructions for your power pack. Be sure to read and understand the
instructions before using your power pack.
Specifications
Specifications are subject to change without prior notice.
Be sure to read this manual carefully before using your power pack.
Keep this manual handy for future reference.
Safety Instructions
Memo
6806-2264
3. Place the (-) and (+) terminals of the battery in the correct
position. Press the (+) terminal to set the battery correctly
as shown in the figure.
The red Charge indicator indicates normal charging. When
charging is complete, the indicator turns green.
How to charge the Ni-MH Battery (SNB-2312)
If the charge indicator illuminates as green when you insert the battery, your battery is
already charged to full capacity and cannot be charged any longer.
If the charge indicator blinks as red, it indicates a battery charging error.
- If the battery is not properly inserted
- If the 2 terminals (+, -) are dirty or damaged
If the battery is inserted properly and the charge indicator continues to blink, contact the
nearest Samsung Camera Service Center.
The battery charger (SBC-N1) has a discharge function.
Ni-MH cells have a memory effect. For long battery life, it is best to fully charge or
discharge the battery. When batteries are charged in the battery charger (SBC-N1), the
charger first discharges residual capacity and then starts charging. If the Charge indicator
shows yellow when the battery is put in the charger, it means that the charger is
discharging the battery. In this case, the process may take from several minutes to about
two hours, depending on the residual capacity of the battery.
After the completion of discharge, the Charge indicator turns red and charging starts.
It may take about four hours to charge a battery, based on 2300mAh.
If the temperature of charger exceeds 65 C, charging is stopped and the lamp to check
charging flashes. In this case, charge the battery again after the temperature of charger is
dropped.
Notice
The charger (SBC-N1) is dedicated for Samsung Ni-MH cells only.
Charging Ni-Cadmium cells or low capacity Ni-MH cells may generate severe heat in the
battery. We recommend using Ni-MH cells with a capacity of over 2000mAh.
Warning
Identification of features
Using the Battery Charger
1. Insert the AC cord into the charger. 2. Plug the AC cord's power plug into the wall
outlet.
With the AC cord
When power is supplied to the charger, the charge indicator will illuminate for 1 second.
(Orange Color)
Notice
ENGLISH
Cell Type Ni-MH Cell x 2
Cell Capacity 2,300mAh
Voltage 1.2V
Charging Time Approximately 240 Minutes
Input AC 100-250V/ 50-60Hz
Output Ni-MH Cell : 1.5V 0.6A
Rechargeable Battery Type Ni-MH battery (SNB-2312)
Ni-MH battery
(SNB-2312 )
Battery Charger
(SBC-N1)
[ Battery Charger & Battery ]
Charge Indicator
- Red Light: charging in process
- Green Light: charging completed
- Yellow Light: discharging in process
- Red Light Flickering: charging error
Positive (+)
Terminal
Charge
Indicator
Negative (-)
Terminal
(-) Terminal
(+) Terminal

2 53
DANGER
Keep batteries out of the reach of children.
Neglecting to do so can result in children accidentally swallowing a battery or small part.
If a child has swallowed a battery, seek medical attention immediately.
Do not put a battery into a microwave oven or high-pressure container.
Do not store the battery in temperatures below 0 C or above 40 C.
Doing so may result in malfunction.
If you are going to store the battery for over 3 months, do so after charging it to full capacity.
If a problem arises with the battery, keep it in a safe place and then contact a Samsung Camera
Service Center.
Checking the Contents
Please check the contents before using this product.
Ni-MH battery (SNB-2312)
DANGER
Do not place the battery in strong direct sunlight or locations with a high temperature, such as in
the trunk or on the dashboard of a vehicle.
Exposing the battery to strong direct sunlight may result in the battery pack leaking, overheating,
or exploding, which in turn will cause fire or other hazards. Exposing the battery to high
temperatures may also result in deformation of the case. When using the battery charger to
charge the rechargeable batteries, always do so in a well-ventilated area.
Do not store the battery in humid or dusty locations.
Doing so may result in fire, electric shock, or other hazards.
Do not touch the (+) and (-) terminals with a metal object.
Do not store the battery with metal objects, such as metallic necklaces or hairpins. Doing so may
result in a short circuit or fire.
Cover the exposed battery terminals with electrician's tape before disposing of the battery.
An improperly disposed battery could be short-circuited by metal parts of other objects and result
in a fire or explosion. Always dispose of the batteries in a special recycle bin.
Do not heat the battery or dispose of it in a fire.
The battery may explode. Do not charge or leave the battery near fires, stoves, or other locations
with high temperatures. If the battery leaks or emits unusual odors, immediately ensure that it is
away from any flames.
Do not directly solder the battery.
The protection device of the battery's positive (+) terminal may become deformed due to the heat
of the solder.
Do not disassemble or modify the battery.
Do not remove the plastic wrap from the battery.
Do not throw the battery or subject it to strong impact.
Do not subject the battery to continuous mechanical shocks.
Do not drop or submerge the battery in any water.
It could generate heat or corrode and result in poor performance.
Do not insert the battery with the (+) and (-) terminals reversed.
Do not charge the battery with the (+) and (-) terminals reversed.
The battery could explode.
Use only the battery charger specified by Samsung Techwin.
If a battery is leaking, do not let the electrolyte get on your skin or clothing.
If the electrolyte gets into your eyes, flush your eyes immediately with clear, cold running water
and seek medical attention immediately.
4
Do not allow the charger to get wet.
If water has gotten inside the charger, unplug the power cord from the power outlet, remove the
battery, and contact the store from which the purchase was made, or contact a Samsung Camera
Service Center. Using the charger in such conditions will result in fire, electric shock, or damage
to the charger.
If water is spilled into or onto the charger, it will result in fire or electric shock.
Do not store the battery pack in temperatures below 0 C or above 40 C . Doing so may result in
malfunction.
DANGER
Keep the charger out of reach of children.
Neglecting to do so could result in a child accidentally swallowing a battery or small part. If a child
has swallowed a battery, seek medical attention immediately.
If you notice any unusual odors, noise, or smoke around the charger, immediately unplug the power
cord.
Neglecting to do so could result in fire or electric shock. Immediately unplug the power cord from the
wall outlet. Make sure all smoke and odors have completely dissipated. You must then, contact the
store from which the purchase was made, or contact a Samsung Camera Service Center.
Do not apply excessive shock or force to the charger.
Do not cut, damage, or place heavy objects on the power cord. Doing so could result in electric
shock. Replace the damaged charger.
Do not pull on the DC plug excessively.
Do not drop the charger or subject it to strong impact, as this could result in damage or
malfunction of the product. If the case is damaged due to impact, contact the store from which the
purchase was made.
Do not clean this charger with benzene, thinner, rubbing alcohol, or other such inflammable
solvents. The use of such solvents could result in a fire.
Once charging is complete, unplug the power plug.
If you use this product over a prolonged period of time, it may become hot and result in
deformation of the material or a fire. Once charging is complete, unplug the charger from the
outlet and disconnect the charger and the power cord to prevent fire or other hazards.
Do not touch the power cord with wet hands.
Doing so could result in electric shock. When unplugging the power cord always grasp the plug,
not the cord. Pulling on the cord could cause the wires to break or expose the wires at the edge of
the plug and result in fire or electric shock.
If the battery does not recharge within the specified charging time, stop charging and contact the
store from which the purchase was made. Neglecting to do so could cause the battery to ignite,
explode, or leak.
Do not charge the disposable battery.
The leakage may damage the charger and the battery may explode.
WARNING
Different types of graphic symbols are used throughout this manual to alert the user to personal
safety hazards or to identify conditions that may result in equipment or property damage. The icons
and their meanings are as follows:
DANGER
This symbol indicates a hazard, which if not avoided, will result in serious
injury, including death, or equipment and property damage.
WARNING
This symbol indicates a hazard, which if not avoided, can result in minor
injury, or equipment and property damage.
Icons used in this manual
Battery Charger (SBC-N1)
Do not disassemble or modify any part of the charger.
Do not disassemble or touch the inside of the charger. There is a risk of electric shock.
Do not modify the charger for other purposes.
We recommend to use the Ni-MH battery(SNB-2312) provided by the Company.
Attempting to charge non-rechargeable batteries or other types of rechargeable batteries will
result in the batteries generating heat, exploding, or leaking, which in turn will cause fire, injury,
or soiling of the battery compartment.
Do not attempt to charge any other device with this charger. Doing so may cause personal
injury and damage to the charger.
The input voltage of the charger is AC 100V to 250V.
Keep the charger free from moisture.
If the charger is suddenly moved from a cold place to a warm place, condensation will form on
or within the charger and may result in malfunction, fire, or electric shock.
Use in a dry, well-ventilated, and shaded area.
Use only in indoor areas.
Do not use in wet areas, such as bathrooms or showers.
Do not place in direct sunlight or near a heat source (such as a radiator).
Do not short-circuit the (+) and (-) terminals of the charger with any metal object.
Do not short-circuit the (+) and (-) terminals of the charger with any metal object while power is
being supplied to the charger.
Do not let water or other liquids come in contact with any part of the (+) and (-) terminals.
DANGER
Battery Charger
(SBC-N1) AC Cord
Ni-MH battery
(SNB-2312)
