Samsung NSE6D 81 Series User manual

Electric Range
User manual
NSE6D*81****

2 English
WARNING
To reduce the risk of tipping the range, the range must be secured
by a properly installed Anti-Tip device. AFTER THE RANGE HAS
BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN
PROPERLY INSTALLED AND VERIFY THAT THE ANTI-TIP DEVICE IS
PROPERLY ENGAGED. Refer to the installation manual for instructions.
a) If the Anti-Tip device is not installed, a child or adult can tip the
range and be killed.
b) Verify that the Anti-Tip device has been properly installed and
engaged at the rear right (or rear left) of the range bottom.
c) If you move the range and then move it back into place, ensure
the Anti-Tip device is re-engaged at the right or left rear of the
range bottom.
d) Do not operate the range without the Anti-Tip device in place and
engaged.
e) Failure to do so can result in death or serious burns to children or
adults.
WARNING
Do not step, lean, or sit on the doors of the range. You can cause the
range to tip, resulting in burns or serious injuries.
Conrm that the Anti-Tip device is installed properly. Then, to verify
that the Anti-Tip device is engaged, grasp the top rear edge of the
range and carefully attempt to tilt it forward. The Anti-Tip device
should prevent the range from tilting forward more than a few inches.
If you pull the range out from the wall for any reason, make sure the
Anti-Tip device is properly engaged when you push the range back
against the wall. If it is not, there is a risk of the range tipping over
and causing injury if you or a child stand, sit, or lean on the open door.
Never completely remove the leveling legs. If you remove the leveling
legs, the range will not be secured to the Anti-Tip device properly.
Anti-tip device

English 3
Radio Apparatus Notice
CAUTION
Any changes or modications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
The remote enable equipment installed on this
product complies with Part 15 of FCC Rules and
Innovation, Science and Economic Development
Canada’s license-exempt RSS(s). Operation is
Subject to following two conditions:
1) This equipment may not cause harmful
interference, and
2) This equipment must accept any interference
received including interference that cause
undesired operation.
For products available in the US/Canadian markets,
only channels 1~11 are available. You cannot
select any other channels.
1.FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with part 15 of FCC Rules. Operation is Subject
to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products sold in the US and Canadian markets, only channels
1–11 are available. You cannot select any other channels.
Regulatory Notice

4 English
Regulatory Notice
Radio Apparatus STATEMENT:
This equipment has been tested and found to
comply within the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules and
Canadian ICES-003. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off
and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
FCC STATEMENT:
This equipment has been tested and found to comply within the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different circuit
than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for
help.

English 5
• Reorienting or relocating the receiving antenna
• Increasing the separation between the
equipment and receiver
• Connecting the equipment to an outlet that is on
a different circuit than the radio or TV
• Consulting the dealer or an experienced radio/
TV technician for help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
2.IC Notice
The term “IC” before the radio certication number only signies
that Industry Canada technical specications were met. Operation
is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only channels
1–11 are available. You cannot select any other channels.

6 English
Regulatory Notice
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits
set forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC and IC RSS-
102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should
be installed and operated so there is at least
8 inches (20 cm) between the radiator and your
body. This device and its antenna(s) must not be
co-located or operated in conjunction with any
other antenna or transmitter.

English 7
Contents
Contents
Important safety instructions 8
What you need to know about safety instructions 8
California Proposition 65 Warning 8
For your safety 9
Surface Cooking Units 11
Electrical Safety 12
Child safety 13
Oven 13
Remote Operation 14
Self-cleaning ovens 14
Ventilating hood 15
Glass/Ceramic cooking surfaces 15
Critical installation warnings 16
Critical usage warning 17
Usage cautions 20
Critical cleaning warnings 21
Introducing your new range 22
Overview 22
What’s included with your range 22
Before you begin 23
Energy saving tips 23
Surface cooking 23
About surface cooking 23
How to set the appliance for surface cooking 25
Using the proper cookware 27
Choosing the proper cookware 28
Protecting the cooktop 28
Operating the oven 29
The oven control panel 29
Oven lock 30
Setting the clock 30
Setting the kitchen timer 30
Cook Time 30
Delay Start 31
Turning the oven light on and off 31
Oven cooking 31
Cooking mode 32
Using the oven racks 32
Baking 34
Broiling 35
Using the special function 36
Using the keep warm feature 36
Smart control 37
Voice control 37
Special features 38
Using the options function 39
Maintaining your appliance 41
Self-cleaning 41
Steam-cleaning 43
Care and cleaning of the oven 44
Care and cleaning of the glass cooktop 46
Removing and reinstalling the oven door 47
Removing and reinstalling the storage drawer 49
Changing the oven light 49
Troubleshooting 50
Troubleshooting 50
Information codes 54
Warranty (U.S.A) 56
Warranty (CANADA) 57
Appendix 59
Open Source Announcement 59

8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
CAUTION
To reduce the risk of re, explosion, electric shock, or personal injury
when using your range, follow these basic safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Important safety instructions
Read and follow all instructions before using your range to prevent
the risk of re, electric shock, personal injury, or damage when using
the range. This guide does not cover all possible conditions that may
occur. Always contact your service agent or the manufacturer about
problems that you do not understand.
WHAT YOU NEED TO KNOW ABOUT
SAFETY INSTRUCTIONS
Warnings and Important safety instructions in this manual do not
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury
or property damage.

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
FOR YOUR SAFETY
When using electrical appliances, you should follow basic safety
precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as described in
this Owner’s Manual.
• Potentially hot surfaces include the cooktop, areas facing the
cooktop, the oven vent opening, surfaces near the opening, and
crevices around the oven door.
Be sure your appliance is properly installed and grounded by a
qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual. All
other servicing should be referred to a qualied technician.
Always disconnect the power to the appliance before servicing
by removing the fuse or switching off the circuit breaker.
• Do not enter the oven.
• Do not store items of interest to children in cabinets above
the range or on the back guard of the range. Children
climbing on the range to reach items could be seriously
injured.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
• Never use your appliance for warming or heating the room.
• Do not use water on grease res. Turn off the oven to avoid
spreading the ames. Smother the re or ames by closing
the door or use a dry chemical, baking soda, or foam-type
extinguisher.
• Avoid scratching or striking the glass doors, the cooktop, or
the control panel. Doing so may lead to glass breakage. Do
not cook on a product with broken glass. Shock, re, or cuts
may occur.

10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
• Use only dry potholders. Placing moist or damp potholders
on hot surfaces may result in burns from steam. Do not let
the potholder touch hot heating elements. Do not use a towel
or other bulky cloth.
• Teach children not to play with the controls or any other part
of the range.
• For your safety, do not use high-pressure water cleaners or
steam jet cleaners to clean any part of the range.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarly qualied persons
to avoid creating a hazard.
• The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• Do not lean on the range as you may turn the control knobs
inattentively.
• If there is a re in the oven during self-cleaning, turn the
oven off and wait for the re to go out. Do not force the
door open. The introduction of fresh air at self-cleaning
temperatures may lead to a burst of ame from the oven.
Failure to follow these instructions may result in severe
burns.
• If the oven is heavily soiled with oil, self-clean the oven
before using the oven again. Leaving the oil in place creates
a risk of re.
• Wipe up heavy soil on the oven bottom with a paper towel or
rag before self-cleaning. Self-cleaning the oven when there
is heavy soil on the oven bottom requires longer cleaning
cycles and produces more smoke.
• Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure all
packing materials are removed from the appliance before
operating it. Keep plastics, clothes, and paper away from
parts of the appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or hanging
garments while using the appliance.
Important safety instructions
