Samsung NX58 751 Series User manual

Free-Standing Gas Range
User manual
NX58*565***/NX58*560*** /NX58*751***
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 1 2020-06-23 오전 9:09:37

2 English
ANTITIP DEVICE
WARNING
Tip-Over Hazard
• A child or adult can tip the range and be killed.
• Install the anti-tip device on the range and/or
structure as per the installation instructions in this
manual.
• Engage the range with the installed anti-tip device.
• Re-engage the anti-tip device if the range is moved.
• Failure to follow these instructions can result in
death or serious burns to children or adults.
WARNING
If the information in this manual is not followed exactly, a re
or explosion may result causing property damage, personal
injury or death.
• DO NOT store or use gasoline or other ammable vapors
and liquids in the vicinity of this or any other appliance.
• DO NOT store, place or use ammable or combustible
materials such as charcoal, paper, plastic, pot holders,
linens, curtains, gasoline or other ammable vapors or
liquids near or inside the range.
• WHAT TO DO IF YOU SMELL GAS:
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch.
- DO NOT use any phone in your building.
- Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the re
department.
• Installation and service must be performed by a qualied
installer, service agency, or the gas supplier.
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 2 2020-06-23 오전 9:09:37

English 3
FEATURES OF YOUR NEW RANGE
Enhanced convenience. Better cooking. Easy maintenance. Your
new gas range has been designed to bring you these benets
and more.
Bigger is better
With a capacity of 5.8 cubic feet, your new range has more
space than many other leading brands in the United States and
Canadian markets. This means greater convenience for you
when cooking for the holidays or when entertaining.
A cooktop with 5 burners
Power burners, simmer burners, as well as a center oval burner
provide exible cooktop heat for a variety of cookware.
The center oval burner provides even heating over large areas,
so it is perfect for griddle cooking.
To prevent accidental tipping of the range, attach an
approved anti-tip device to the oor. (See Installing the
Anti-Tip Device in the Installation Instructions.) Check for
proper installation by carefully tipping the range forward.
The anti-tip device should engage and prevent the range
from tipping over.
If the range is pulled out away from the wall for any
reason, make sure the anti-tip device is reengaged after
the range has been pushed back into place.
Follow the installation instructions found in the Installation
Manual. Failure to follow these instructions can result in
death, serious personal injury, and/or property damage.
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 3 2020-06-23 오전 9:09:37

4 English
Contents
ContentsContents
Important safety instructions 5
SAFETY SYMBOLS 5
CALIFORNIA PROPOSITION 65 WARNING 6
IMPORTANT SAFETY PRECAUTIONS 6
GAS WARNINGS 11
IN THE COMMONWEALTH OF MASSACHUSETTS 12
ELECTRICAL WARNINGS 13
GROUNDING INSTRUCTIONS 14
INSTALLATION WARNINGS 14
SURFACE BURNER WARNINGS 17
OVEN WARNINGS 19
ELECTRIC WARMING DRAWER OR LOWER STORAGE DRAWER WARNINGS 21
SELF-CLEANING OVEN WARNINGS 21
PROPER COOKING OF MEAT AND POULTRY 22
Introducing your new range 23
Overview 23
Surface cooking 26
Lighting a gas surface burner 26
Manually lighting a gas surface burner 26
Flame size selection 26
Gas surface burners and control knobs 26
Cookware usage 27
Center burner grate 28
Wok grate (NX58*565*** Only) 28
Using the griddle 29
Operating the oven 30
Oven control panels and displays 30
Setting the clock 33
Setting the timer on/off 34
Positioning the oven racks 35
Using the gliding rack (NX58*565*** Only) 36
Oven vent 37
Oven light 37
Baking 38
Convection baking and roasting 39
Timed cooking 42
Delay timed cooking 44
Broiling 46
Keep warm 48
Using the easy cook feature 48
Air Fry mode (Model NX58*751***) 50
Favorite cooking 52
Sabbath function 54
Extra features 56
Using the warming drawer 58
About the warming drawer (Model NX58*565*** Only) 58
Turning the warming drawer on or off 58
Maintaining your appliance 59
Care and cleaning of the oven 59
Care and cleaning of the cooktop 63
Changing the oven light 67
Removing and replacing the oven door 67
Removing and replacing the warming drawer
(Model NX58*565***) 69
Removing and replacing the storage drawer
(Model NX58*560***, NX58*751***) 70
Self-cleaning oven 71
Troubleshooting 74
Troubleshooting 74
Troubleshooting and information codes 80
Warranty (U.S.A) 80
Warranty (CANADA) 82
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 4 2020-06-23 오전 9:09:37

English 5
Important safety instructions
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
All electrical and gas equipment with moving parts can be
dangerous. Please read the important safety instructions for
this appliance in this manual. The instructions must be followed
to minimize the risk of injury, death, or property damage.
Save this manual. Please Do Not Discard.
SAFETY SYMBOLS
What the icons and signs in this user manual mean:
WARNING
There is a risk of death or serious personal injury.
CAUTION
There is a risk of personal injury or property damage.
CAUTION
To reduce the risk of re, explosion, electric shock, or personal
injury when using your gas range, follow these basic safety
precautions:
Important safety instructions
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power cord from the electrical outlet.
Make sure the range is plugged into an earth grounded
electrical outlet to prevent electric shock. An outlet
equipped with a Ground Fault Interrupter (GFI) is highly
recommended.
Call the service center for help. see page 85.
Note
These warning icons are here to prevent injury to you and
others.
Please observe them explicitly.
Do not discard this manual. Please keep it in a safe place for
future reference.
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 5 2020-06-23 오전 9:09:37

6 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
IMPORTANT SAFETY PRECAUTIONS
WARNING
Follow basic precautions when installing and using this range
to reduce the risk of re, electrical shock, injury, or death to
persons, including:
Installation and Service
This range must be properly located and installed in
accordance with the installation instructions before it is
used.
Professional installation is strongly recommended.
Due to the size and weight of the range, it is highly
recommended that two or more people move or install this
appliance.
All ranges can tip over and cause severe injuries. Install
the anti-tip device packed with this range following the
instructions found in the Installation Instructions.
Never try to repair or replace this appliance on your own
unless it is specically recommended in this manual. This
appliance should be serviced only by a qualied service
technician.
Know the location of the gas shut-off valve and how to
shut it off if necessary.
Properly remove or destroy the packaging materials after
the appliance is unpacked.
Electrical/Mechanical
Unplug or disconnect power before servicing.
Do not tamper with the controls.
Grates and griddles (if equipped) are heavy. They can be
dangerous if dropped.
The inner portion of the split oven rack (if equipped) could
drop down accidentally if not assembled properly. Place
the inner rack in the proper position within the outer rack.
Always position the oven racks at the same level on each
cavity side. Uneven racks could cause food to slide to the
lower side, posing a risk of burns.
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 6 2020-06-23 오전 9:09:37

English 7
Important safety instructions
SAVE THESE INSTRUCTIONS
Danger to Children
Do not store any object of interest to children on the
cooktop or backguard of the range. Children climbing
on the range to reach items could be killed or seriously
injured.
The inner rack of the Split Rack can be dropped if it is not
assembled properly. Place the Inner rack in the proper
place on the Outer rack. Always insert the rack or split
rack assembly (if equipped) on the same level of the oven
cavity side.
Keep children away from the door when opening or
closing it as they may bump themselves on the door or
catch their ngers in the door.
Keep all packaging materials out of reach of children.
Children may play with them. Failure to dispose of plastic
bags could result in suffocation.
Do not leave children alone or unattended in an area
where a range is in use. They should never be allowed to
sit or stand on any part of a range.
Do not let little children touch the range.
The cooktop grates and griddle (if equipped) are heavy
and presents a risk of injury if dropped on a foot. Teach
children not to touch or play with grates or griddle.
Teach children not to touch or play with the controls or
any part of the range.
We recommend you utilize the control/door lockout
feature to reduce the risk of mis-use by children.
Before disposing of the range, cut off the power cord
to prevent it from being connected to a power source.
Remove the door to prevent children and animals from
getting trapped.
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 7 2020-06-23 오전 9:09:37

8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
Fire
Do not touch oven burners, drawer burners, or interior
surfaces of the oven during or immediately after cooking.
Cooking surfaces, grates, cooktop burners, and caps, as
well as oven walls may be hot even though they are dark
in color. Interior oven surfaces can become hot enough
to cause burns. During and after use, do not touch or
let clothing or other ammable materials contact oven
burners, drawer burners, or interior surfaces of the oven
until they have had sufcient time to cool.
Do not let a pot holder touch a hot heating element. Do not
use a towel or other bulky cloth as a pot holder.
Do not use your range to heat unopened food containers
or to dry wet items or clothing.
Keep oven vent ducts unobstructed. Clean vents frequently
to avoid grease buildup. See page 37. There can be slight
popping sound during oven cooking. This sound may occur
during the normal oven burner cycling, when the oven
burner ame is extinguished.
Never use your range for any purposes but cooking. Doing
so could result in carbon monoxide poisoning and/or
overheating of the oven.
Do not wear loose-tting or hanging garments while using
this appliance.
DO NOT STORE OR USE combustible materials, gasoline,
or other ammable vapors or liquids in the vicinity of this
appliance. See WHAT TO DO IF YOU SMELL GAS under the
Gas Warnings.
Do not pour water into the cooktop well while cleaning
the cooktop. This could leak down into the range gas and
electrical systems creating a risk of electrical shock or high
levels of Carbon Monoxide, due to corrosion of the gas
valves or ports.
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 8 2020-06-23 오전 9:09:37

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
Do not use water on a grease re. Water might cause a
grease re to explode, spreading the re and creating a
larger re and health hazard. To put out a grease re, turn
off the heat source and smother the re with tight-tting
lid or use a multipurpose dry chemical or foam-type re
extinguisher.
Never leave surface units unattended at high heat settings.
Boilovers cause smoke, and greasy spillovers could ignite.
Do not use a ame to check for gas leaks. Instead, use a
brush to spread a soapy water mixture around the area
you are checking. If there is a gas leak, you will see small
bubbles in the soapy water mixture at the point of the
leak.
Do not place portable appliances, or any other object other
than cookware on the cooktop. Damage or re could occur
if the cooktop is hot.
Do not attempt to operate this appliance if it is damaged,
malfunctioning, or has missing or broken parts.
Never place plastic, paper, or other items that could melt
or burn near the oven vents or any of the surface burners.
If the self-clean mode malfunctions, turn the oven off and
disconnect the power supply. Refer to pages 80 and 82 to
contact a qualied service technician.
There can be slight popping sound during oven cooking.
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 9 2020-06-23 오전 9:09:38

10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
Steam and Vapors
Use care when opening the oven door. Let hot air or steam
escape before removing or placing food in a hot oven.
Use only dry pot holders. Putting moist or damp pot
holders on hot surfaces may result in burns from steam.
Surface Burner Warnings
• The burner spreader can be blocked by food or dust.
Clean the spreader if it appears blocked. If you clean
the spreader with water, assemble it only after it is
completely dry. If the spreader is wet, it might prevent
the burners from igniting.
• Do not pour water on the cooktop for cleaning. It can
get inside the range and cause the parts inside to rust.
• Only ignite the cooktop burners with the burner caps
in place. If the burner caps are not in place, you can
damage the controls or cause an unintended large or
dangerous ame.
• Heating of beverages can result in delayed eruptive
boiling. To prevent delayed eruptive boiling, ALWAYS
allow heated beverages to stand at least 20 seconds
after you have turned the burner off so that the
temperature in the liquid can stabilize. In the event of
scalding, follow these FIRST AID instructions:
- Immerse the scalded area in cold water for at least
10 minutes
- Cover with clean, dry dressing
- Do not apply any creams, oils or lotions
• The ‘Spark mark’ on the Dual burner spreader must be
placed beside the electrode when it is assembled to
prevent an abnormal ame.
• After turning on a surface burner, check to make sure
that the burner has ignited. Adjust the level of the
ame by turning the burner knob.
• When you set a burner to simmer, do not turn the
burner knob quickly. Watch the ame to make sure it
stays on.
NX58H5 Series_AA_DG68-00526A-14_EN+MES+CFR_WEB.indb 10 2020-06-23 오전 9:09:38
